VALEO Telematik und Akustik WMI2W167 Wireless Mobile Interface User Manual nerve test case distance

Peiker acustic GmbH & Co. KG Wireless Mobile Interface Users Manual nerve test case distance

Contents

Users Manual - nerve test case distance

WMI Use Cases for Nerve-Tests
Especially the Distances to Human Body
Status : Draft
Version : 1.2
Author :Stefan Hofmann Date : 07.12.2017
________________________________________________________________________________________________________________________________
Page 1
VALEO – Product Line Valeo peiker Telematics - www.valeo.de
Using a WMI-System in the car, you will have the following normal use-cases :
1. Stay in the car and lay down the mobile on the WMI surface
Precondition, after placement the mobile on the WMI to start the system, some CAN
commands from the car are necessary.
After that, the WMI tries to detect via NFC, if an object was placed on the surface (the
process does not send out NFC-Commands, the misalignment of the NFC-antenna will be
proofen). When the detection was successful, the system switch to Qi-detection-mode.
If the detection-mode has found a mobile with Qi-standard charging possibility on the WMI,
then charging process will start.
The WMI was designed following the Qi standard to charge mobiles prepared for Qi-
charging.
But the WMI does not fulfill the whole Qi-standard, therefore no Qi Logo is declared on the
WMI and no Qi-certification exists.
If you remove the mobile during charging from the WMI, charging process is stopped.
a) Sitting on the driver seat and steering the car.
o Distance to Knee 5cm
o Leg 5cm
o Body 50cm
o Hand 10cm
o Arm 30cm
o Head 80cm
b) Sitting on the co driver-seat.
o Distance to Knee 5cm
o Leg 5cm
o Body 50cm
o Hand 10cm
o Arm 30cm
o Head 80cm
c) Sitting in the fond (left/right) side.
o Distance to Knee 5cm
o Leg 5cm
o Body 50cm
o Hand 10cm
o Arm 30cm
o Head 80cm
