VIDEOTEK VTC6110TX iBall Wireless Trailer Hitch Camera System User Manual 15 VT C6110 UserMan
VIDEOTEK COMPANY LIMITED iBall Wireless Trailer Hitch Camera System 15 VT C6110 UserMan
VIDEOTEK >
15_VT-C6110 UserMan
Outdoors Insight, Inc.
www.iballhitchcam.com
Call Toll Free 1-(877)-298-2055
1) Monitor
2) Select Up Down
3) Menu
4) *Picture Rotate.
5) Power
6) Fuse Cap
7) Camera
8) Adjustment Knobs
9) Power On Button
10) USB Charging
Port
11) USB Charging
Cable
*Your model may have either of the following two buttons:
or for the Picture Rotate button
Warranty Information: Your iBall Wireless Camera System comes with the
following warranty coverage:
• 30 Day Money Back Guarantee : If you are unsatised for any reason, send your
system back within 30 days of the original purchase date for a full refund (less
shipping).
• One Year Warranty: If your iBall Wireless Camera System fails due to a
manufacturing defect within one year of the original purchase date, we will
gladly repair or replace.
11
9
8
2
13
4
5
6
7
10
695 iBall manual 2016.indd 1 10/16/15 10:32 AM
VT-C6110
• Your iBall Wireless Trailer Hitch Camera is equipped with a rechargeable
lithium ion battery. Before rst use, charge the camera for 8 hours.
During periods of limited usage, charge the unit for 8 hours every 30
days to obtain peak battery performance. To charge, simply lift side tab
and insert supplied USB charger. A solid red light will indicate the unit
is charging.
• To Power on the Camera, press and hold for ve seconds. A red
light on the front of the camera will indicate the system is on. Place
the camera on any magnetic surface. Use the side adjustment knobs to
adjust the viewing angle.
• Plug the monitor into any 12v auxiliary port. Press the to turn on/
off the monitor. The monitor settings can be adjusted for brightness,
contrast and saturation by pressing the menu button. Use the ▲ ▼
arrows to adjust the desired settings. The camera orientation can be
adjusted by pressing the picture rotate button (#4).
SPECIFICATIONS:
Camera
5.8GHz Wireless Frequency
100’ Transmission Distance (without obstruction)
Weather Resistant
Lithium Ion Rechargeable Battery (charge using supplied USB cable)
Magnetic Mounting
120° Field of View
Monitor
3.5” Color LCD Monitor
Weather Resistant
12v Auxiliary Power Supply
6” Adjustable Gooseneck
HOW TO USE Helpful tips:
• It is not recommended to leave the camera attached to your vehicle
while traveling at high speeds, as road vibration may cause the
magnetic bond to fail.
• While the camera is weather resistant, it is not recommended to
submerse for an extended period of time.
For additional technical support, please visit our website:
www.iballhitchcam.com or call us at (877)-298-2055
PROBLEM: CAUSE: SOLUTION:
Poor image quality/
static Cause 1: Distance between
camera and
monitor too far
Cause 2: Environmental
interference
Cause 3: Low camera
battery, weak
12v monitor
connection
Solution 1: Move the camera
closer to the monitor
Solution 2: Move away from
buildings or objects
that may be affecting
wireless signal
Solution 3: Charge the camera
battery, check 12v
connection
Problem: Camera will
not turn on/off Cause 1: Power button not
being held down
long enough
Cause 2: Low camera
battery
Solution 1: Firmly hold power
button for at least ve
seconds
Solution 2: Charge camera for
eight hours
Problem: Monitor will
not turn on Cause 1: 12v outlet is not
supplying power
Cause 2: 12v connection is
not secure
Cause 3: Blown fuse in
monitor 12v power
plug
Solution 1: Try another 12v outlet
Solution 2: Firmly secure the
power plug into the
outlet
Solution 3: Replace the fuse
(3A 250v) by turning
the fuse cap (#6)
counterclockwise
Problem: Camera will
not stick to vehicle Cause 1: Non-ferrous
surface Solution 1: Mount camera to iron
surface, such as the
receiver hitch
P
O
W
E
R
695 iBall manual 2016.indd 2 10/16/15 10:32 AM
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment. This device complies with Part
15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
