User manual

User’s manual

TL91270

DECT 6.0 cordless

telephone with BLUETOOTHBLUETOOTH®

wireless technology

Getting started

If you subscribe to high-speed Internet service (digital subscriber line - DSL)

through your telephone line, you must install a DSL filter between the

telephone line cord and the telephone wall jack. The filter prevents noise and

caller ID problems caused by DSL interference. Please contact your DSL service

provider for more information about DSL filters.

Follow the steps below to install the telephone.

NOTE: The telephone base comes without the wall-mount bracket for tabletop use. If you

want to mount your telephone on a wall, refer to Wall-mount installation on

pages 10-11 for details.

Telephone base installation

Plug one end of

the telephone

line cord into the

telephone jack on

the bottom of the

telephone base.

DSL filter (not included) is

required if you have DSL

high-speed Internet service.

Telephone line cord

Route the cords

through the slots.

Plug the small

end of the larger

power adapter

into the power

jack on the

bottom of the

telephone base.

Plug the large end

of the larger power

adapter into an

electrical outlet not

controlled by a wall

switch.

Plug the other end

of the telephone

line cord into a

telephone wall jack.

Raise the antenna.4.

Getting started

IMPORTANT INFORMATION:

Use only the power adapter(s) provided with this product. To obtain a replacement, visit our

website at www.telephones.att.com or call 1 (800) 222-3111. In

Canada, dial 1 (866) 288-4268.

The power adapters are intended to be correctly oriented in a vertical or floor mount

position. The prongs are not designed to hold the plug in place if it is plugged into a ceiling,

under-the-table or cabinet outlet.

Charger installation

Plug the power adapter into an electrical outlet not

controlled by a wall switch.

Getting started

Battery installation & charging

Battery charging

Install the battery as shown on the next page. Once you have installed the

battery, the screen indicates the battery status (see table below). If necessary,

place the handset in the telephone base or charger to charge the battery.

For best performance, keep the handset in the charger when not in use. The

battery is fully charged after 16 hours of continuous charging. See the table

on page 93 for battery operating times.

If the screen is blank, you need to charge the handset without interruption

for at least 10 minutes to give the handset enough charge to use the

telephone for a short time. The screen shows Low battery and the backlight

is off until you have charged the battery without interruption for at least

one hour. The following table summarizes the battery charge indicators and

actions to take.

Battery indicators Battery status Action

The screen is blank. Battery has no charge and the

handset cannot be used.

Charge without interruption

until the screen shows Low

battery (at least 10 minutes).

The screen show No battery. Battery is not installed

probably, but the handset is

placed on the telephone base

or charger

See the Battery installation

section on page 9 for battery

installation.

The screen shows Place in

charger and flashes

Battery has very little charge

and the handset cannot be

used.

Charge without interruption

until the screen shows

Low battery (at least four

minutes).

The screen shows Low

battery and flashes.

Battery has enough charge to

be used for a short time.

Charge without interruption

until the screen shows

HANDSET X (at least one

hour).

The screen shows HANDSET X

and the battery icon shows

, or .

Battery is charged. To keep the battery charged,

place it in the telephone

base or charger when not

in use.

NOTE: If you are on a call in low battery mode, you hear four short beeps every minute.

Getting started

Battery installation & charging

Battery installation

Install the battery as shown below.

Plug the battery

connector securely

into the socket inside

the handset battery

compartment, matching

the color-coded label.

Insert the supplied

battery with the label

THIS SIDE UP facing

up as indicated.

To replace the battery, press the tab and slide

the battery compartment cover downwards. Lift

out the old battery and disconnect it from the

handset. Follow the instructions above to install

and charge the new battery.

Align the cover flat

against the battery

compartment, then

slide it upwards until

it clicks into place.

2. Charge the handset by

placing it face up in

the telephone base or

charger. The CHARGE

light is on when

charging.

IMPORTANT INFORMATION:

Use only the supplied rechargeable battery or replacement battery (model BT166342). To order,

visit our website at www.telephones.att.com, or call 1 (800) 222-3111.

In Canada, dial 1 (866) 288-4268.

CHARGE light

Getting started

Wall-mount installation

Your telephone base is ready for tabletop use. If you want to mount yourIf you want to mount your

telephone on a wall, use the provided wall bracket to connect with a

standard dual-stud telephone wall-mounting plate. If you do not have this

mounting plate, you can purchase one from many hardware or consumer

electronics retailers. You may need a professional to install the mounting

plate.

Tabletop to wall-mount installation

1. Position the telephone base as shown below. Insert the extended tabs

(marked B) of the wall-mount bracket into the slots on the back of the

telephone base (marked B). Push the telephone base down until it is securely

in place.

2. If you are using a DSL filter, plug the line cord into the filter now. Route

the telephone line cord (or DSL filter) through the wall mount bracket hole.

Route the power cord out of the bottom of the telephone.

3. Plug the telephone line cord (or DSL filter) into the wall jack. Plug the

power adapter into a power outlet not controlled by a wall switch.

4. Align the holes on the bracket with the standard wall plate and slide the

bracket down until it locks securely. Bundle the telephone line cord and

power adapter cord neatly with a twist tie.

Getting started

Wall-mount installation

Wall-mount to tabletop installation

To change the telephone base from the wall-mount position to tabletop

position, follow the steps below.

1. Remove the wall-mount bracket from the wall. If the telephone line cord

and power adapter cord are bundled, untie them first.

2. Lift the telephone base up to detach it from the plastic wall-mount

bracket. Unplug the telephone line cord (or DSL filter) from the wall. Unplug

the power adapter from the power outlet.

3. See Telephone base installation on page 6.

Appendix

Important safety information

This symbol is to alert you to important operating or servicing instructions that may appear

in this user’s manual. Always follow basic safety precautions when using this product to reduce

the risk of injury, fire, or electric shock.

Safety information

Read and understand all instructions in the user’s manual. Observe all markings on the

product.

Avoid using a telephone during a thunderstorm. There might be a slight chance of electric

shock from lightning.

Do not use a telephone in the vicinity of a gas leak. If you suspect a gas leak, report it

immediately, but use a telephone away from the area where gas is leaking. If this product is a

cordless model, make sure the base is also away from the area.

Do not use this product near water, or when you are wet. For example, do not use it in a

wet basement or shower, or next to a swimming pool, bathtub, kitchen sink, or laundry tub.

Do not use liquids or aerosol sprays for cleaning. If the product comes in contact with any

liquids, unplug any line or power cord immediately. Do not plug the product back in until it

has dried thoroughly.

Install this product in a protected location where no one can trip over any line or power

cords. Protect cords from damage or abrasion.

If this product does not operate normally, read Troubleshooting section on pages 75-86

of this user’s manual. If you cannot solve the problem, or if the product is damaged, refer

to Limited warranty section on pages 92-93. Do not open this product except as may be

directed in your user’s manual. Opening the product or reassembling it incorrectly may

expose you to hazardous voltages or other risks.

Replace batteries only as described in your user’s manual (pages 8-9). Do not burn or

puncture batteries — they contain caustic chemicals.

This power adapter is intended to be correctly oriented in a vertical or floor mount position.

The prongs are not designed to hold the plug in place if it is plugged into a ceiling or an

under-thetable/cabinet outlet.

CAUTION: Use only the power adapter provided with this product. To obtain a replacement,

visit our website at www.telephones.att.com, or call 1 (800) 222–3111.

In Canada, dial 1 (866) 288-4268.

Especially about corded telephones

Privacy: The same features that make a cordless telephone convenient create some

limitations. Telephone calls are transmitted between the telephone base and the handset

by radio waves, so there is a possibility that your cordless telephone conversations could

be intercepted by radio receiving equipment within range of the cordless handset. For this

reason, you should not think of cordless telephone conversations as being as private as those

on corded telephones.

Electrical power: The telephone base of this cordless telephone must be connected to a

working electrical outlet which is not controlled by a wall switch. Calls cannot be made from

the handset if the telephone base is unplugged, switched off or if the electrical power is

interrupted.

•

Appendix

Important safety information

Potential TV interference: Some cordless telephones operate at frequencies that may cause

interference to TVs and VCRs. To minimize or prevent such interference, do not place the

telephone base of the cordless telephone near or on top of a TV or VCR. If interference

is experienced, moving the cordless telephone farther away from the TV or VCR will often

reduce or eliminate the interference.

Rechargeable batteries: This product contains nickel-metal hydride rechargeable batteries.

Exercise care in handling batteries in order not to create a short circuit with conductive

material such as rings, bracelets, and keys. The battery or conductor may overheat and cause

harm. Observe proper polarity between the battery and the battery charger.

Nickel-metal hydride rechargeable batteries: Dispose of these batteries in a safe manner. Do

not burn or puncture. Like other batteries of this type, if burned or punctured, they could

release caustic material which could cause injury.

The RBRC™ Seal means that the manufacturer is voluntarily participating in

an industry program to collect and recycle nickel-metal hydride rechargeable

batteries when taken out of service within the United States. These batteries

may be taken to a participating local retailer of replacement batteries or

recycling center. Or you may call 1 (800) 8-BATTERY for locations accepting

spent Ni-MH batteries.

Precautions for users of implanted cardiac pacemakers

Cardiac pacemakers (applies only to digital cordless telephones): Wireless Technology Research,

LLC (WTR), an independent research entity, led a multidisciplinary evaluation of the interference

between portable wireless telephones and implanted cardiac pacemakers. Supported by the U.S.

Food and Drug Administration, WTR recommends to physicians that:

Pacemaker patients

Should keep wireless telephones at least six inches from the pacemaker.

Should NOT place wireless telephones directly over the pacemaker, such as in a breast

pocket, when it is turned ON.

Should use the wireless telephone at the ear opposite the pacemaker.

WTR’s evaluation did not identify any risk to bystanders with pacemakers from other persons

using wireless telephones.

SAVE THESE INSTRUCTIONS

•

Appendix

FCC part 68 and ACTA

This equipment complies with Part 68 of the FCC rules and with technical requirements adopted

by the Administrative Council for Terminal Attachments (ACTA). The label on the back or

bottom of this equipment contains, among other things, a product identifier in the format US:

AAAEQ##TXXXX. This identifier must be provided to your local telephone company upon request.

The plug and jack used to connect this equipment to premises wiring and the telephone network

must comply with the applicable Part 68 rules and technical requirements adopted by ACTA. A

compliant telephone cord and modular plug is provided with this product. It is designed to be

connected to a compatible modular jack that is also compliant. An RJ11 jack should normally be

used for connecting to a single line and an RJ14 jack for two lines. See Installation Instructions

in the user’s manual.

The Ringer Equivalence Number (REN) is used to determine how many devices you may connect

to your telephone line and still have them ring when you are called. The REN for this product is

encoded as the 6th and 7th characters following the US: in the product identifier (e.g., if ## is

03, the REN is 0.3). In most, but not all areas, the sum of all RENs should be five (5.0) or less. For

more information, please contact your local telephone company.

This equipment may not be used with Party Lines. If you have specially wired alarm dialing

equipment connected to your telephone line, ensure the connection of this equipment does

not disable your alarm equipment. If you have questions about what will disable the alarm

equipment, consult your telephone company or a qualified installer.

If this equipment is malfunctioning, it must be unplugged from the modular jack until the

problem has been corrected. Repairs to this telephone equipment can only be made by the

manufacturer or its authorized agents. For repair procedures, follow the instructions outlined

under the Limited Warranty.

If this equipment is causing harm to the telephone network, the telephone company may

temporarily discontinue your telephone service. The telephone company is required to notify

you before interrupting service. If advance notice is not practical, you will be notified as soon as

possible. You will be given the opportunity to correct the problem and the telephone company

is required to inform you of your right to file a complaint with the FCC. Your telephone company

may make changes in its facilities, equipment, operation, or procedures that could affect the

proper functioning of this product. The telephone company is required to notify you if such

changes are planned.

If this product is equipped with a corded or cordless handset, it is hearing aid compatible.

If this product has memory dialing locations, you may choose to store emergency telephone

numbers (e.g., police, fire, medical) in these locations. If you do store or test emergency numbers,

please:

Remain on the line and briefly explain the reason for the call before hanging up.

Perform such activities in off-peak hours, such as early morning or late evening.

Industry Canada

Operation is subject to the following two conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any interference, including interference that may

cause undesired operation.

The term ‘’IC:‘’ before the certification/registration number only signifies that the Industry

Canada technical specifications were met.

The Ringer Equivalence Number (REN) for this terminal equipment is 0.1. The REN is an indication

of the maximum number of devices allowed to be connected to a telephone interface. The

termination on an interface may consist of any combination of devices subject only to the

requirement that the sum of the RENs of all the devices does not exceed five.

This product meets the applicable Industry Canada technical specifications.

•

Appendix

FCC part 15

This equipment has been tested and found to comply with the requirements for a Class B digital

device under Part 15 of the Federal Communications Commission (FCC) rules.

These requirements are intended to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications to this equipment not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause undesired operation. Privacy of

communications may not be ensured when using this telephone.

To ensure safety of users, the FCC has established criteria for the amount of radio frequency

energy that can be safely absorbed by a user or bystander according to the intended usage

of the product. This product has been tested and found to comply with the FCC criteria. The

handset may be safely held against the ear of the user. The telephone base shall be installed

and used such that parts of the user’s body other than the hands are maintained at a distance of

approximately 20cm (8 inches) or more.

This Class B digital apparatus complies with Canadian ICES-003.

•

Appendix

Limited warranty

The AT&T brand is used under license - any repair, replacement or warranty service, and all

questions about this product should be directed to: In the United States of America, call

1 (800) 222-3111 or visit www.telephones.att.com; In Canada, call

1 (866) 288-4268.

What does this limited warranty cover?

The manufacturer of this AT&T-branded product warrants to the holder of a valid proof of

purchase (“CONSUMER” or “you”) that the product and all accessories provided in the sales

package (“PRODUCT”) are free from defects in material and workmanship, pursuant to the

following terms and conditions, when installed and used normally and in accordance with the

PRODUCT operating instructions. This limited warranty extends only to the CONSUMER for

products purchased and used in the United States of America and Canada.

What will be done if the PRODUCT is not free from defects in materials and workmanship

during the limited warranty period (“materially defective PRODUCT”)?

During the limited warranty period, the manufacturer’s authorized service representative

repairs or replaces at the manufacturer’s option, without charge, a materially defective

PRODUCT. If the manufacturer repairs the PRODUCT, they may use new or refurbished

replacement parts. If the manufacturer chooses to replace the PRODUCT, they may replace

it with a new or refurbished PRODUCT of the same or similar design. The manufacturer

retains the defective parts, modules, or equipment. Repair or replacement of the PRODUCT,

at the manufacturer’s option, is your exclusive remedy. The manufacturer returns the repaired

or replacement products to you in working condition. You should expect the repair or

replacement to take approximately 30 days.

How long is the limited warranty period?

The limited warranty period for the PRODUCT extends for ONE (1) YEAR from the date of

purchase. If the manufacturer repairs or replaces a materially defective PRODUCT under the

terms of this limited warranty, this limited warranty also applies to repaired or replacement

PRODUCT for a period of either (a) 90 days from the date the repaired or replacement

PRODUCT is shipped to you or (b) the time remaining on the original one-year limited

warranty; whichever is longer.

What is not covered by this limited warranty?

This limited warranty does not cover:

PRODUCT that has been subjected to misuse, accident, shipping or other physical damage,

improper installation, abnormal operation or handling, neglect, inundation, fire, water, or

other liquid intrusion; or

PRODUCT that has been damaged due to repair, alteration, or modification by anyone

other than an authorized service representative of the manufacturer; or

PRODUCT to the extent that the problem experienced is caused by signal conditions,

network reliability or cable or antenna systems; or

PRODUCT to the extent that the problem is caused by use with non-AT&T accessories; or

PRODUCT whose warranty/quality stickers, PRODUCT serial number plates or electronic

serial numbers have been removed, altered or rendered illegible; or

PRODUCT purchased, used, serviced, or shipped for repair from outside the United States

of America or Canada, or used for commercial or institutional purposes (including but not

limited to products used for rental purposes); or

PRODUCT returned without valid proof of purchase (see item 6 below); or

Charges for installation or setup, adjustment of customer controls, and installation or

repair of systems outside the unit.

•

Appendix

How do you get warranty service?

To obtain warranty service in the United States of America, visit

www.telephones.att.com or call 1 (800) 222-3111; in Canada, please

dial 1 (866) 288-4268. NOTE: Before calling for service, please review the user’s

manual. A check of the PRODUCT controls and features might save you a service call.

Except as provided by applicable law, you assume the risk of loss or damage during transit

and transportation and are responsible for delivery or handling charges incurred in the

transport of the PRODUCT(s) to the service location. The manufacturer will return repaired or

replaced PRODUCT under this limited warranty. Transportation, delivery or handling charges

are prepaid. The manufacturer assumes no risk for damage or loss of the PRODUCT in transit.

If the PRODUCT failure is not covered by this limited warranty, or proof of purchase does not

meet the terms of this limited warranty, the manufacturer notifies you and requests that you

authorize the cost of repair prior to any further repair activity. You must pay for the cost of

repair and return shipping costs for the repair of products that are not covered by this limited

warranty.

What must you return with the PRODUCT to get warranty service?

You must:

Return the entire original package and contents including the PRODUCT to the service

location along with a description of the malfunction or difficulty; and

Include “valid proof of purchase” (sales receipt) identifying the PRODUCT purchased

(PRODUCT model) and the date of purchase or receipt; and

Provide your name, complete and correct mailing address, and telephone number.

Other limitations

This warranty is the complete and exclusive agreement between you and the manufacturer

of this AT&T branded PRODUCT. It supersedes all other written or oral communications

related to this PRODUCT. The manufacturer provides no other warranties for this PRODUCT.

The warranty exclusively describes all of the manufacturer’s responsibilities regarding the

PRODUCT. There are no other express warranties. No one is authorized to make modifications

to this limited warranty and you should not rely on any such modification.

State/Provincial Law Rights: This warranty gives you specific legal rights, and you might also

have other rights that vary from state to state or province to province.

Limitations: Implied warranties, including those of fitness for a particular purpose and

merchantability (an unwritten warranty that the PRODUCT is fit for ordinary use) are limited

to one year from date of purchase. Some states/provinces do not allow limitations on how

long an implied warranty lasts, so the above limitation might not apply to you. In no event

shall the manufacturer be liable for any indirect, special, incidental, consequential, or similar

damages (including, but not limited to lost profits or revenue, inability to use the PRODUCT

or other associated equipment, the cost of substitute equipment, and claims by third parties)

resulting from the use of this PRODUCT. Some states/provinces do not allow the exclusion or

limitation of incidental or consequential damages, so the above limitation or exclusion might

not apply to you.

Please retain your original sales receipt as proof of purchase.

Limited warranty

Appendix

Technical specifications

RF frequency band 1921.536MHz — 1928.448MHz

Channels 5

Operating temperature 32°F — 122°F

0°C — 50°C

Telephone base voltage

(AC voltage, 60Hz)

96 — 129 Vrms

Telephone base voltage

(AC adapter output)

6VDC @400mA

Handset voltage 2.4 — 3.2 VDC

Charger voltage

(AC adapter output)

6VAC @300mA

Replacement battery 2.4V 750mAH

Operation time* Talk time (handset): up to eight hours

Talk time (speakerphone): up to five hours

Standby: up to seven days

* Operating times varies depending on your actual use and the age of the battery.

DECT 6.0 digital technology

The AT&T DECT 6.0 products offer unsurpassed range performance and sound

clarity. This is achieved through a unique antenna design and advances in

noise-filtering technology. An independent laboratory has confirmed that

AT&T DECT 6.0 products perform up to 45% better in range competitions.

Now calls can be taken in the basement, backyard and garage with

exceptional sound quality.

Telephone operating range

This cordless telephone operates within the maximum power allowed by

the Federal Communications Commission (FCC). Even so, this handset and

telephone base can communicate over only a certain distance — which can

vary with the locations of the telephone base and handset, the weather, and

the construction of your home or office.

Extended range and clarity

This telephone base comes with an antenna which gives much better clarity

and covers a longer range than before.

User’s manual

TL92270/TL92370

DECT 6.0 cordless

telephone/answering

system with BLUETOOTHBLUETOOTH®

wireless technology

The Bluetooth® word mark and logos are owned by Bluetooth SIG, Inc. and any use of such marks by Advanced

American Telephones and its parent, VTech Holdings Limited, is under license. VTech Holdings Limited is a

member of Bluetooth SIG, Inc. Other trademarks and trade names are those of their respective owners.

the AT&T logo are trademarks of AT&T Intellectual Property licensed to

Advanced American Telephones, San Antonio, TX 78219. Printed in China.

Congratulations

on purchasing your new AT&T product. Before using this AT&T product, please

read the Important safety information on pages 88-89 of this user’s manual.

Please thoroughly read the user’s manual for all the feature operations and

troubleshooting information you need to install and operate your new AT&T

product. You can also visit our website at www.telephones.att.com or

call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

The ENERGY STAR® program (www.energystar.gov)

recognizes and encourages the use of products that save

energy and help protect our environment. We are proud to

mark this product with the ENERGY STAR® label indicating it

meets the latest energy efficiency guidelines.

Compatible with

Hearing Aid T-Coil

TIA-1083

Telephones identified with this logo have reduced noise

and interference when used with most T-coil equipped

hearing aids and cochlear implants. The TIA-1083 Compliant

Logo is a trademark of the Telecommunications Industry

Association. Used under license.

Model #: TL92270 (two handsets)

TL92370 (three handsets)

Type: DECT 6.0 cordless telephone/answering system

with Bluetooth wireless technology

Serial #:

Purchase date:

Place of purchase:

Both the model and serial number of your AT&T product can be found on the

bottom of the telephone base.

Parts checklist

Your telephone package contains the following items. Save your sales receipt

and original packaging in the event warranty service is necessary.

Telephone line cord

Power adapter for

telephone base

Cordless handset

(2 for TL92270)

(3 for TL92370)

Telephone base

Charger for cordless

handset with power

adapter installed

(1 for TL92270)

(2 for TL92370) Wall-mount bracket

Battery for cordless

handset

(2 for TL92270)

(3 for TL92370)

Battery compartment

cover

(2 for TL92270)

(3 for TL92370)

User’s manual Quick start guide

User’s manual

TL92270/TL92370

DECT 6.0 cordless

telephone/answering

system with BLUETOOTHBLUETOOTH®

wireless technology

Quick start guide

TL92270/TL92370

DECT 6.0 cordless

telephone/answering

system with BLUETOOTHBLUETOOTH®

wireless technology

User’s manual

TL92270/TL92370

DECT 6.0 cordless

telephone/answering

system with BLUETOOTHBLUETOOTH®

wireless technology

Table of contents

Getting started

Quick reference guide -

telephone base...................................... 1

Quick reference guide - handset.. 2

Installation ............................................... 5

Telephone base installation ............ 6

Battery installation & charging...... 8

Battery charging ................................... 8

Battery installation .............................. 9

Wall-mount installation...................10

Tabletop to wall-mount

installation .............................................10

Wall-mount to tabletop

installation .............................................11

Bluetooth

Introducing Bluetooth......................12

Glossary of terms...............................13

Bluetooth setup...................................14

Pairing a device...................................14

Auto connection..................................15

Pair a headset......................................16

Auto connection..................................17

Paired devices........................................ 18

Rename a paired device..................18

Remove a paired device..................19

Active devices ........................................ 20

Replace an active device................21

Bluetooth operation..........................22

Add an active device ........................22

Remove an active device................23

Change PIN............................................23

Download directory...........................24

Interruption to directory

download................................................26

View the directory download

information ............................................26

Handset settings

Telephone settings.............................27

Ringer volume......................................27

Ringer tone............................................27

LCD language .......................................28

Clear voicemail....................................28

Key tone..................................................29

Website....................................................29

Set date/time.......................................30

CID time synchronization................31

Dial mode...............................................31

Home area code..................................32

Cell area code......................................32

Answer ON/OFF..................................33

Announcement ....................................34

Delete your announcement...........35

Call screening.......................................36

Number of rings..................................36

Remote access code.........................37

Message alert tone............................37

Telephone operation

Making, answering and ending a

call .............................................................38

Making a call.........................................38

Options while on calls .....................39

Handset speakerphone....................42

Volume control ....................................42

Silencing the ringer...........................42

Mute ..........................................................42

Temporary tone dialing ...................43

Hold...........................................................43

Handset locator...................................44

Chain dialing.........................................45

Redial stack...........................................46

Review the redial list........................46

Dial a redial entry...............................46

Save a redial entry to the

directory..................................................47

Delete a redial entry.........................47

Intercom..................................................48

To initiate an intercom call............48

Answer an incoming call during

an intercom call ..................................49

Call transfer and sharing................50

Share an outside call........................50

Transferring an outside call...........50

Equalizer setting .................................52

Directory

Directory .................................................53

Create a new entry in the home

directory..................................................54

Character chart....................................55

Review the directory.........................56

3-character alphabetical search .56

Dial, Edit or delete a directory.....57

Dial a directory entry........................57

Edit the type of a directory

entry..........................................................58

Delete a directory entry..................58

Remove a downloaded

directory..................................................58

Caller ID

About caller ID.....................................59

Information about caller ID with

call waiting ............................................59

Caller ID history ..................................60

Caller ID operation ............................61

Memory match.....................................61

Missed calls indicator.......................61

Caller ID operation ............................62

Review the call log............................62

View dialing options..........................62

Dial a call log entry...........................63

Save a call log entry to the

directory..................................................63

To delete a single entry ..................64

To delete all entries ..........................64

Reasons for missing caller ID

information ............................................64

Answering system

About the answering system........65

Answering system and

voicemail.................................................65

Message capacity ...............................65

New message indication.................66

Call screening at the telephone

base...........................................................66

Call intercept ........................................66

Telephone base ringer volume ....66

Temporarily turning off the

message alert tone............................66

Voice prompts ......................................66

Message playback..............................67

Delete all old messages..................68

Record and play memos.................68

To play back a memo.......................68

Base message counter

displays....................................................69

Message window displays..............69

Remote access.....................................70

To remotely access the

answering system...............................70

Remote commands............................70

Appendix

Handset screen icons.......................71

Alert tones and lights.......................72

Handset alert tones...........................72

Telephone base alert tones...........72

Handset indicator lights..................72

Telephone base indicator

lights .........................................................72

Screen messages................................73

Display screen messages................73

Expand your telephone system...76

Add and register a handset

(optional).................................................76

Replace a handset .............................77

To deregister all handsets..............77

Maintenance..........................................87

Important safety information........88

Table of content

Safety information..............................88

Especially about corded

telephones .............................................88

Precautions for users of implanted

cardiac pacemakers...........................89

Pacemaker patients...........................89

Especially about telephone

answering systems.............................89

FCC part 68 and ACTA.....................90

FCC part 15 ...........................................91

Limited warranty.................................92

Technical specifications...................94

DECT 6.0 digital technology..........94

Telephone operating range ...........94

Extended range and clarity ...........94

Index ..............................................................95

Table of content

Quick reference guide - telephone base

Message counter

Number of messages

(or during playback,

message number

currently playing).

IN USE light

Flashes when there

is an incoming call,

or another telephone

sharing the same line is

in use.

On when the handset is

in use.

DEVICE1/DEVICE2 lights

On when the telephone

base is paired and

connected with a

Bluetooth device.

Flash while pairing a

Bluetooth device.

X DELETE

Press to delete the

message currently

playing (page 67).

When the phone is not

in use, press twice to

delete all previously

reviewed messages

(page 68).

REPEAT

Press to repeat a

message or press twice

to play the previous

message (page 67).

ANSWER ON

Press to turn the

answering system on or

off (page 33).

VOLUME

Press to adjust the

volume during playback

(page 67).

When the phone is not

in use, press to adjust

the telephone base

ringer volume (page 66).

SKIP

Press to skip to the next

message (page 67).

HANDSET LOCATOR

Press to page all

system handsets

(page 43).

/PLAY/STOP

Press to play messages

(page 67).

Press to stop message

playback (page 67).

Getting started

CHARGE light

On when the handset is charging in the

telephone base or charger.

CID/-VOLUME

Press to scroll down while in menu.

Press to decrease the volume level during

a call (page 42).

Press to show the caller ID history when

the telephone is not in use (page 62).

While entering names or numbers in the

directory, press to move the cursor to the

left (page 54).

MENU/SELECT

Press to display the menu (page 4).

Once in the menu, press to select an item

or save an entry or setting.

CELLULAR

Press to make or answer a cell call

(page 38).

During a cell call, press to answer an

incoming call when you hear a call waiting

alert (page 39).

Flashes quickly when there is an incoming

cell call.

Flashes slowly when a cell call is on hold.

HOME/FLASH

Press to make or answer a home call

(page 38).

During a home call, press to answer an

incoming call when you hear a call waiting

alert (page 39).

Flashes quickly when there is an incoming

call.

Flashes slowly when a home call is on

hold.

While reviewing a caller ID history entry,

press repeatedly to add or remove 1 in

front of the telephone number before

dialing or saving it in the directory

(page 62).

TONE

Press to switch to tone dialing temporarily

during a call if you have pulse service

(page 43).

SPEAKER

Press to turn on the handset

speakerphone, press again to resume

normal handset use (page 42).

Quick reference guide - handset

Getting started

DIR/+VOLUME

Press to scroll up while in menu.

Press to increase the volume level

during a call (page 42).

Press to show directory entries

when the telephone is not in use

(page 56).

While entering names or numbers

in the directory, press to move the

cursor to the right (page 54).

REDIAL/PAUSE

Press repeatedly to view the last

five numbers dialed (page 46).

While entering numbers, press

and hold to insert a dialing pause

(page 54).

OFF/CLEAR

While using menus, press to cancel

an operation, back up to the

previous menu, or exit the menu

display (page 4).

During a call, press to hang up

(page 38).

Press and hold while the telephone

is not in use to erase the missed

calls indicator (page 61).

Press repeatedly to display other

dialing options when reviewing a

caller ID history entry (page 62).

HOLD

Press to put a call on hold

(page 43).

MUTE/DELETE

During a call, press to mute

microphone (page 42).

While pre-dialing, press to delete

digits (page 38).

While reviewing the redial stack,

directory or caller ID history,

press to delete an individual entry

(page 47, 57 and 64).

Quick reference guide - handset

Getting started

Quick reference guide - handset

Feature menu

Play messages (page 67)

Answering sys (page 65)

Directory (page 56)

Call log (page 59)

Intercom (page 48)

Bluetooth (page 12)

Ringers (page 27)

Settings (page 28)

Website (page 29)

Main menu

The selected menu item

will be highlighted.

Play messages

Answering sys

Directory

Call log

Bluetooth

During an outside call, intercom

call, message or announcement

playback, press to change the

audio tone (page 52).

Using menus

Press MENU/SELECT in idle mode

(when the telephone is not in

use) to enter the main menu.

Use CID or DIR to scroll

through menu items

Press MENU/SELECT to select or

save the highlighted item.

-OR-

Press OFF/CLEAR to cancel

an operation, back up to the

previous menu or exit the menu

display.

-OR-

Press and hold OFF/CLEAR to

return to idle mode.

NOTE: If no key is pressed, the handset

automatically return to idle mode after

30 seconds.

Getting started

Install the telephone base close to a telephone jack and a power outlet

not controlled by a wall switch. The telephone base can be placed on a flat

surface or vertically mounted on the wall (page 10). For optimum range and

better reception, place the telephone base in a central and open location.

You may hear interference if your cellular phone is too close to the

telephone base during a CELLULAR call. Make sure that your Bluetooth

enabled cellular phone is between one to 12 feet away from the telephone

base in order to maintain a clear and consistent connection between your

Bluetooth cell phone, telephone base and cell tower.

If you subscribe to high-speed Internet service (digital subscriber line -

DSL) through your telephone line, you must install a DSL filter between the

telephone line cord and the telephone wall jack (page 6). The filter prevents

noise and caller ID problems caused by DSL interference. Please contact your

DSL service provider for more information about DSL filters.

Your product may be shipped with a protective sticker covering the handset

or telephone base display - remove it before use.

For customer service or product information, visit our website at

www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial

1 (866) 288-4268.

Avoid placing the telephone base too close to:

Communication devices such as: television sets, VCRs, or other cordless

telephones.

Excessive heat sources.

Noise sources such as a window with traffic outside, motors, microwave

ovens, refrigerators, or fluorescent lighting.

Excessive dust sources such as a workshop or garage.

Excessive moisture.

Extremely low temperature.

Mechanical vibration or shock such as on top of the washing machine or

work bench.

•

You must install and charge

the handset battery before

using the cordless handset.

See pages 8-9 for easy

instructions.

Installation

Getting started

If you subscribe to high-speed Internet service (digital subscriber line - DSL)

through your telephone line, you must install a DSL filter between the

telephone line cord and the telephone wall jack. The filter prevents noise and

caller ID problems caused by DSL interference. Please contact your DSL service

provider for more information about DSL filters.

Follow the steps below to install the telephone.

NOTE: The telephone base comes without the wall-mount bracket for tabletop use. If you

want to mount your telephone on a wall, refer to Wall-mount installation on

pages 10-11 for details.

Telephone base installation

Plug one end of

the telephone

line cord into the

telephone jack on

the bottom of the

telephone base.

DSL filter (not included) is

required if you have DSL

high-speed Internet service.

Telephone line cord

Route the cords

through the slots.

Plug the small

end of the larger

power adapter

into the power

jack on the

bottom of the

telephone base.

Plug the large end

of the larger power

adapter into an

electrical outlet not

controlled by a wall

switch.

Plug the other end

of the telephone

line cord into a

telephone wall jack.

Raise the antenna.4.

Getting started

IMPORTANT INFORMATION:

Use only the power adapter(s) provided with this product. To obtain a replacement, visit our

website at www.telephones.att.com or call 1 (800) 222-3111. In

Canada, dial 1 (866) 288-4268.

The power adapters are intended to be correctly oriented in a vertical or floor mount

position. The prongs are not designed to hold the plug in place if it is plugged into a ceiling,

under-the-table or cabinet outlet.

Charger installation

Plug the power adapter into an electrical outlet not

controlled by a wall switch.

Getting started

Battery installation & charging

Battery charging

Install the battery as shown on the next page. Once you have installed the

battery, the screen indicates the battery status (see table below). If necessary,

place the handset in the telephone base or charger to charge the battery.

For best performance, keep the handset in the charger when not in use. The

battery is fully charged after 16 hours of continuous charging. See the table

on page 93 for battery operating times.

If the screen is blank, you need to charge the handset without interruption

for at least 10 minutes to give the handset enough charge to use the

telephone for a short time. The screen shows Low battery and the backlight

is off until you have charged the battery without interruption for at least

one hour. The following table summarizes the battery charge indicators and

actions to take.

Battery indicators Battery status Action

The screen is blank. Battery has no charge and the

handset cannot be used.

Charge without interruption

until the screen shows Low

battery (at least 10 minutes).

The screen show No battery. Battery is not installed

probably, but the handset is

placed on the telephone base

or charger

See the Battery installation

section on page 9 for battery

installation.

The screen shows Place in

charger and flashes

Battery has very little charge

and the handset cannot be

used.

Charge without interruption

until the screen shows

Low battery (at least four

minutes).

The screen shows Low

battery and flashes.

Battery has enough charge to

be used for a short time.

Charge without interruption

until the screen shows

HANDSET X (at least one

hour).

The screen shows HANDSET X

and the battery icon shows

, or .

Battery is charged. To keep the battery charged,

place it in the telephone

base or charger when not

in use.

NOTE: If you are on a call in low battery mode, you hear four short beeps every minute.

Getting started

Battery installation & charging

Battery installation

Install the battery as shown below.

Plug the battery

connector securely

into the socket inside

the handset battery

compartment, matching

the color-coded label.

Insert the supplied

battery with the label

THIS SIDE UP facing

up as indicated.

To replace the battery, press the tab and slide

the battery compartment cover downwards. Lift

out the old battery and disconnect it from the

handset. Follow the instructions above to install

and charge the new battery.

Align the cover flat

against the battery

compartment, then

slide it upwards until

it clicks into place.

2. Charge the handset by

placing it face up in

the telephone base or

charger. The CHARGE

light is on when

charging.

IMPORTANT INFORMATION:

Use only the supplied rechargeable battery or replacement battery (model BT166342). To order,

visit our website at www.telephones.att.com, or call 1 (800) 222-3111.

In Canada, dial 1 (866) 288-4268.

CHARGE light

Getting started

Wall-mount installation

Your telephone base is ready for tabletop use. If you want to mount yourIf you want to mount your

telephone on a wall, use the provided wall bracket to connect with a

standard dual-stud telephone wall-mounting plate. If you do not have this

mounting plate, you can purchase one from many hardware or consumer

electronics retailers. You may need a professional to install the mounting

plate.

Tabletop to wall-mount installation

1. Position the telephone base as shown below. Insert the extended tabs

(marked B) of the wall-mount bracket into the slots on the back of the

telephone base (marked B). Push the telephone base down until it is securely

in place.

2. If you are using a DSL filter, plug the line cord into the filter now. Route

the telephone line cord (or DSL filter) through the wall mount bracket hole.

Route the power cord out of the bottom of the telephone.

3. Plug the telephone line cord (or DSL filter) into the wall jack. Plug the

power adapter into a power outlet not controlled by a wall switch.

4. Align the holes on the bracket with the standard wall plate and slide the

bracket down until it locks securely. Bundle the telephone line cord and

power adapter cord neatly with a twist tie.

Getting started

Wall-mount installation

Wall-mount to tabletop installation

To change the telephone base from the wall-mount position to tabletop

position, follow the steps below.

1. Remove the wall-mount bracket from the wall. If the telephone line cord

and power adapter cord are bundled, untie them first.

2. Lift the telephone base up to detach it from the plastic wall-mount

bracket. Unplug the telephone line cord (or DSL filter) from the wall. Unplug

the power adapter from the power outlet.

3. See Telephone base installation on page 6.

Your new AT&T TL92270/TL92370 telephone system with Bluetooth wireless

technology has the following features:

Pair up to four Bluetooth enabled cell phones with the telephone base.

Connect a maximum of two cell phones to make and receive cell calls.

Only one cell phone can be active on a call at a time.

Connect a Bluetooth enabled headset for making and receiving home calls.

Conference cell and home calls.

Make and receive calls using your cell phone plan while utilizing the ease

and comfort of your home telephone system.

IMPORTANT INFORMATION

After plugging in the telephone base, wait at least 20 seconds before

connecting a Bluetooth device. The screen shows Bluetooth system busy if

you try to connect too soon.

Refer to the user's manual of your Bluetooth enabled cell phone or

headset for more information about how that device uses Bluetooth

connectivity.

Bluetooth wireless technology operates within a short range (about 1

to 30 feet) from the telephone base. Keep connected cell phones and

headset within this range.

If your cell phone has poor reception in your home, the TL92270/

TL92370 cannot improve the reception. However, if you have a location

in your house with better reception, you can leave your cell phone in that

location while you use the TL92270/TL92370 cell line. In order for this to

work, the telephone base must be within 30 feet of the cell phone.

Charge your cell phone while it is connected to the telephone base. Your

cell phone's battery will discharge faster while it is connected to the

telephone base via Bluetooth wireless technology.

Monitor your cell phone's usage because minutes are deducted from your

cellular plan for the duration of all cell calls.

Refer to the Bluetooth setup section (pages 14-21) to learn how to set up

your Bluetooth device. Refer to the Handset operation section (pages 22-26)

on how to operate your Bluetooth devices with your new TL92270/TL92370

AT&T telephone system with Bluetooth wireless technology. Refer to the

Troubleshooting section (pages 78-86) if you experience difficulty when

using the telephone system.

The Bluetooth® word mark and logos are owned by Bluetooth SIG, Inc. and any use of such marks by Advanced

American Telephones and its parent, VTech Holdings Limited, is under license. VTech Holdings Limited is a

member of Bluetooth SIG, Inc. Other trademarks and trade names are those of their respective owners.

•

Bluetooth

Introducing Bluetooth

Bluetooth

Below are some terms used in this user’s manual to help you become

familiar with using your Bluetooth devices and your new AT&T telephone

system.

Active devices - a maximum of two paired devices (two cell phones, or one

cell phone and one headset) on the active devices list can be connected to

the telephone base, but only one cell phone or headset can be on a call at

a time.

Bluetooth cell phone - refers to a mobile Bluetooth enabled cellular

telephone.

CELLULAR line - the communications service provided through your

Bluetooth enabled cellular telephone.

Connected - a Bluetooth enabled device (cell phone or headset) can only be

used when it is connected to the telephone base. When a Bluetooth enabled

device is connected to the telephone base and active on the active devices

list, it will be ready for use.

Disconnected - a diagonal line appears across devices 1 and/or 2 when

the corresponding Bluetooth enabled device is disconnected from the

telephone base.

Discoverable mode - before a Bluetooth enabled device can be paired, it

must be set to this mode. When pairing your cell phone, the telephone base

will be set to this mode. When pairing a headset, the headset must be set to

this mode. Depending on the manufacturer, this mode is sometimes referred

to as Find Me or Visibility.

HOME line - your conventional telephone land line. On your TL92270/

TL92370 handset, press HOME/FLASH to use the home line.

Paired devices - once a Bluetooth device has been paired with the

telephone base, it will be identified as registered to the telephone base. Only

one Bluetooth cellular phone can be paired with the telephone base.

Pairing - this refers to the process of two Bluetooth devices registering

device information with each other. The telephone base must be paired

with a Bluetooth cellular phone before the Bluetooth device can be used.

Depending on the manufacturer, this is also referred to as Bonding.

PIN - by default, the PIN is 0000 for the telephone base and for most

Bluetooth devices. PIN information must be exchanged between Bluetooth

devices before they can be used. This is also known as a passkey

or passcode.

Glossary of terms

Bluetooth

To use a Bluetooth enabled cellular phone with your telephone, you must

first pair and connect your Bluetooth cellular phone with the telephone base.

All TL92270/TL92370 handsets can be used to make or answer on the cell

phone line.

Bluetooth wireless technology operates within a short range. When you pair

a Bluetooth cell phone or Bluetooth headset to the telephone base, move

closer to the telephone base to maintain sufficient signal strength.

Pairing a device

Before you begin, make sure that you have cellular coverage and your

Bluetooth enabled cell phone is not connected to any other Bluetooth

device. Refer to your cell phone user's manual to learn how to search for or

add new Bluetooth devices.

To pair and connect a cell phone:

Press MENU/SELECT on the handset when it is not in use.

Press CID or DIR to highlight Bluetooth, then press

MENU/SELECT.

Press CID or DIR to highlight Add cellular, then

press MENU/SELECT. The screen displays ADD CELLULAR

Place cell phone next to base. Press SELECT.

If there are already four paired devices on the paired

devices list, the screen will show Maximum of 4

devices can be paired and prompt you to

replace an existing paired device (page 21).

Press MENU/SELECT. The screen displays

Please set your cell phone to search for devices, then

press SELECT.

If a device is already connected to the telephone

base, the screen displays Connected device will

be temporarily disconnected. Press SELECT. Press

MENU/SELECT to temporarily disconnect the device

and continue the pairing process.

Turn on the Bluetooth feature of your cell phone and search for or add

new devices.

Press MENU/SELECT to set the telephone base to discoverable mode.

Once your cell phone finds AT&T DECT 6.0, press MENU/SELECT.

•

Answering sys

Directory

Call log

Intercom

Bluetooth

ADD CELLULAR

Plac e c ell

phone next to

base.

Press SELECT

BLUETOOTH

Download dir

Add cellular

Add headset

Active devices

Please set your

cell phone to

search for

devices, then

press SELECT

Bluetooth setup

Bluetooth

Enter the PIN of the telephone base (the

default PIN is 0000) into your cell phone to

continue the pairing process.

When a device is successfully connected, the handset

displays Paired with cellular and then Cellular setup

completed Device connected. The corresponding

status icon ( 1 or 2) displays. The corresponding

device light on the telephone base (DEVICE1 or

DEVICE2) turns on.

When you already have two devices on the active

devices list, the handset shows Maximum of 2

devices can be connected. You are prompted to replace an existing

device on the active devices list (page 21).

NOTES:

The pairing process may take up to one minute. If the pairing process fails, try again.

If you put the handset back in the telephone base or charger while pairing, the process

discontinues and the handset returns to idle mode.

Auto connection

When a device is successfully paired with the telephone

base but not connected, the handset displays Cellular

setup completed Device not connected and then

Auto-connect function enabled Press SELECT. You can

press MENU/SELECT to exit. You can connect a device

manually (page 20).

•

Base name:

AT&T DECT 6.0

CODE:0000

Cellular setup

completed

Device

connected

Bluetooth setup

Cellular setup

completed

Device not

connected

Auto-connect

function

enabled

Press SELECT

Bluetooth

Pair a headset

Before you begin, make sure that your Bluetooth enabled headset is not

connected to any other Bluetooth device. Refer to your headset user's

manual to learn how to search for or add new Bluetooth devices.

To pair and connect a headset:

Press MENU/SELECT on the handset when it is not in use.

Press CID or DIR to highlight Bluetooth, then press

MENU/SELECT.

Press CID or DIR to highlight Add headset, then

press MENU/SELECT. The screen displays ADD HEADSET

Place Bluetooth headset next to base. Press SELECT.

If there are already four paired devices on the paired

devices list, the screen will show Maximum of 4

devices can be paired and prompt you to replace an

existing paired device (page 21).

Press MENU/SELECT. The screen displays Please set your

headset to discoverable mode, then press SELECT.

If a device is already connected to the telephone

base, the screen displays Connected device will

be temporarily disconnected. Press SELECT. Press

MENU/SELECT to temporarily disconnect the device

and continue the pairing process.

Set your headset to discoverable mode.

Press MENU/SELECT to set your telephone base to

discoverable mode and search for your headset.

Once the telephone base finds your headset, press

MENU/SELECT.

Enter the PIN of your headset (the PIN for most

Bluetooth devices is 0000), then press MENU/SELECT.

•

Bluetooth setup

Answering sys

Directory

Call log

Intercom

Bluetooth

ADD HEADSET

Place Bluetooth

headset next to

base.

Press SELECT

Please set your

headset to

discoverable

mode, then

press SELECT

ADD HEADSET

Enter PIN:

----

Searching for

Bluetooth

headsets...

FOUND DEVICES

Headset

Headset B

Headset A

BLUETOOTH

Download dir

Add cellular

Add headset

Active devices

Bluetooth

When the handset displays Headset A paired to base.

Connect now? Press SELECT, then press MENU/SELECT

on the handset.

When you already have two devices on the active

devices list, the handset shows Maximum of 2 devices

can be connected. You are prompted to replace an

existing device on the active devices list (page 21).

When you already have one headset on the active

devices list, the handset shows Only 1 headset can be

connected. You are prompted to replace an existing

device on the active devices list (page 21).

When a device is successfully connected, the handset

displays Headset setup completed Device connected and the

corresponding status icon ( 1 or 2). The corresponding light on the

telephone base (DEVICE1 or DEVICE2) turns on.

NOTES:

The pairing process may take up to one minute. If the pairing process fails, try again.

If you put the handset back in the telephone base or charger while pairing, the process

discontinues and the handset returns to idle mode.

Auto connection

When a device is successfully paired with the telephone base but not

connected, the handset displays Headset setup completed

Device not connected and then

Auto-connect function enabled Press SeleCT. You can

press MENU/SeleCT to exit. You can connect a device

manually (page 21).

•

10.

Headset A

paired to base.

Connect now?

Press SELECT

Headset setup

completed

Device

connected

Bluetooth setup

Headset setup

completed

Device not

connected

Auto-connect

function

enabled

Press SELECT

Bluetooth

Paired devices

All paired devices are stored on the Paired devices list. Up to four devices

(one headset only) can be paired with the telephone base.

To use a paired device, it must be connected and on the active devices list

(page 20).

Once you have paired a device with the telephone base, you do not need

to repeat the pairing procedure again unless you delete the device from the

Paired devices list.

NOTE: Only the first 15 characters of the device name are shown on the paired devices

list.

Rename a paired device

You can change the name of a paired device on the paired devices list.

Press MENU/SELECT on the handset when it is not

in use.

Press CID or DIR to highlight Bluetooth, then press

MENU/SELECT.

Press CID or DIR to highlight Paired devices, then

press MENU/SELECT.

Press CID or DIR to highlight a selected device when

necessary, then press MENU/SELECT.

Press CID or DIR to highlight Rename, then press

MENU/SELECT. The screen displays ENTER NEW NAME.

Use the dialing keys to edit the name (page 55).

Press MUTE/DELETE to erase a character.

Press and hold MUTE/DELETE to erase all characters.

Press CID to move the cursor to the left or DIR to

the right.

Press MENU/SELECT to confirm. The handset displays

Device renamed.

•

Answering sys

Directory

Call log

Intercom

Bluetooth

BLUETOOTH

Add cellular

Add headset

Active devices

Paired devices

SELECT DEVICE

Headset A

Cell Phone AC

ENTER NEW NAME

Headset A _

Disconnect

Rename

Remove paired

Bluetooth setup

Bluetooth

Remove a paired device

If you already have the maximum of four paired devices on the paired devices

list when you want to add another device, you must first delete a paired

device from the paired devices list.

To remove a paired device:

Press MENU/SELECT on the handset when it is not in use.

Press CID or DIR to highlight Bluetooth, then press

MENU/SELECT.

Press CID or DIR to highlight Paired devices, then

press MENU/SELECT.

Press CID or DIR to highlight a selected device when

necessary, then press MENU/SELECT.

Press CID or DIR to highlight Remove paired, then

press MENU/SELECT. The handset displays Remove

device from paired list? Press SELECT.

Press MENU/SELECT to confirm. The handset displays

Device removed from paired list.

Answering sys

Directory

Call log

Intercom

Bluetooth

BLUETOOTH

Add cellular

Add headset

Active devices

Paired devices

SELECT DEVICE

Headset A

Cell Phone AC

Connect

Rename

Remove paired

Remove device

from paired

list?

Press SELECT

Device removed

fro m

paired list

Bluetooth setup

Bluetooth

Active devices

Only devices on the active devices list can establish a Bluetooth connection

with the telephone base. Although two paired devices can be connected to

the telephone base, only one Bluetooth cell phone or a headset can be on a

call at a time.

NOTE: When adding, removing, or replacing a Bluetooth device on the active devices list, all

connected devices will be temporarily disconnected until the procedure is complete. It may

take up to two minutes to reconnect.

Review the active devices list

Press MENU/SELECT on the handset when it is not

in use.

Press CID or DIR to highlight Bluetooth, then press

MENU/SELECT.

Press CID or DIR to highlight Active devices, then

press MENU/SELECT.

Connect/Disconnect an active device

While in the active devices menu, you may connect or

disconnect your active device.

Press MENU/SELECT on the handset when it is not

in use.

Press CID or DIR to highlight Bluetooth, then press

MENU/SELECT.

Press CID or DIR to highlight Active devices, then

press MENU/SELECT.

Press CID or DIR to highlight a device when

necessary, then press MENU/SELECT.

Press

CID or DIR

to highlight Connect/Disconnect

(whichever is applicable), then press MENU/SELECT to confirm. The

handset displays Device connected/Device disconnected.

NOTE: When your active device is connected, you will be prompted to select Disconnect.

When your active device is disconnected, you will be prompted to select Connect.

Answering sys

Directory

Call log

Intercom

Bluetooth

SELECT DEVICE

1 Headset A

2 Cell Phone AC

Disconnect

Remove active

BLUETOOTH

Download dir

Add cellular

Add headset

Active devices

Bluetooth setup

Bluetooth

Replace an active device

When you already have two devices on the active devices list, you can

replace an active device with a device on the paired devices list.

To replace an active device:

Press MENU/SELECT on the handset when it is not

in use.

Press CID or DIR to highlight Bluetooth, then press

MENU/SELECT.

Press CID or DIR to highlight Paired devices, then

press MENU/SELECT.

Press

CID or DIR

to highlight a device, then press

MENU/SELECT.

Press CID or DIR to highlight Connect,

then press

MENU/SELECT. The handset displays Maximum of

2 devices can be connected and then Replace an

existing active device with cellular? Press SELECT.

Press MENU/SELECT. You are prompted to select a device

on the paired devices list.

Press CID or DIR to highlight the device to be

replaced, then press MENU/SELECT. The handset displays

Device removed from active list and then Connecting

Cell Phone B to the base...

Depending on your cell phone settings, you may

need to press a key on your cell phone to confirm the

connection. When you successfully replace and connect

an active device with a paired device, the handset

displays Device connected.

Answering sys

Directory

Call log

Intercom

Bluetooth

SELECT DEVICE

1 Headset A

2 Cell Phone AC

BLUETOOTH

Add cellular

Add headset

Active devices

Paired devices

Connect

Rename

Remove paired

REPLACE DEVICE

1 Cell Phone A

2 Cell Phone BC

Repla c e a n

existing active

device with

cellular?

Press SELECT

Bluetooth setup

Bluetooth

Add an active device

You can have a maximum of two devices on the active devices list.

To add an active device:

Press MENU/SELECT on the handset when it is not in use.

Press CID or DIR to highlight Bluetooth, then press

MENU/SELECT

Press CID or DIR to highlight Active devices, then

press

MENU/SELECT

Press

CID or DIR

to highlight

an empty position, then

press

MENU/SELECT

When Add displays, press MENU/SELECT. You are

prompted to select a device from the paired devices list.

Press CID or DIR to select one paired device, then

press MENU/SELECT. The handset displays Device added

to active list and then Connecting Cell Phone B to the

base...

Depending on your cell phone settings, you may

need to press a key on your cell phone to confirm the

connection.

When you successfully add and connect an

active device, the handset displays Device connected.

Answering sys

Directory

Call log

Intercom

Bluetooth

SELECT DEVICE

1 Cell Phone B

2 Cell Phone CC

SELECT DEVICE

1 Cell Phone A

2 Empty

BLUETOOTH

Dowload dir

Add cellular

Add headset

Active devices

Add

Bluetooth operation

Bluetooth

Remove an active device

You can remove an active device from the active devices

list.

To remove an active device:

Press MENU/SELECT on the handset when it is not

in use.

Press CID or DIR to highlight Bluetooth, then press

MENU/SELECT.

Press CID or DIR to highlight Active devices, then

press MENU/SELECT.

Press

CID or DIR

to highlight the desired device,

then

press MENU/SELECT.

Press CID or DIR to highlight Remove active, then

press MENU/SELECT. The handset displays Device

removed from active list.

NOTE: Even though the active device is removed from the active

devices list, it is still on the paired devices list.

Change PIN

You are required to enter a PIN when establishing a Bluetooth connection.

The default PIN of your telephone base is 0000.

To change the PIN:

Press MENU/SELECT on the handset when it is not in use.

Press CID or DIR to highlight Bluetooth, then press

MENU/SELECT.

Press CID or DIR to highlight Change PIN, then press

MENU/SELECT. The handset displays ENTER NEW PIN

and the existing PIN.

Use the dialing keys to enter a new four-digit code.

Press MUTE/DELETE to erase a digit.

Press and hold MUTE/DELETE to erase all digits.

Press CID to move the cursor to the right or DIR to the left.

Press MENU/SELECT to save.

•

Answering sys

Directory

Call log

Intercom

Bluetooth

BLUETOOTH

Download dir

Add cellular

Add headset

Active devices

SELECT DEVICE

1 Cell Phone B

2 Cell Phone CC

Disconnect

Remove active

Device removed

fro m

active list

BLUETOOTH

Add headset

Active devices

Paired devices

Change PIN

ENTER NEW PIN

0000

Bluetooth operation

Bluetooth

Download directory

You can download up to four cell phone directories (phonebooks) to your

TL92270/TL92370 telephone system via Bluetooth wireless technology.

Each downloaded directory can store up to 1,500 entries with up to

30 digits for each phone number and 15 characters for each name.

Before downloading the directory, make sure the cell phone is paired to

your TL92270/TL92370 and on the active devices list. Make sure the

handset battery is charged for at least 10 minutes.

Place your cell phone next to the telephone base when you download a

cell phone directory to your TL92270/TL92370.

To download a cell phone directory:

Press MENU/SELECT on the handset when it is not

in use.

Press CID or DIR to highlight Bluetooth, then press

MENU/SELECT.

Press MENU/SELECT to choose Download dir.

If there is no cell phone paired to the system, the

handset displays No cellular device paired. Press

SELECT to add cellular.

Press CID or DIR to select a desired device, then

press MENU/SELECT.

If the selected device is on the paired devices list but

not on the active devices list, the handset displays No

cellular on active devices list. Press SELECT to add.

If the selected device is on the active devices list but

disconnected, the handset displays Not connected. To connect cell

place it next to the base. Press SELECT.

If the selected device’s directory has already been downloaded to

TL92270/TL92370 before, the handset displays Directory Cell Phone

A will be erased. To download press SELECT. If you press

MENU/SELECT to continue the download process, the directory stored

on the TL92270/TL92370 for that cell phone will be erased and

replaced with the current cell phone directory. If you have edited the

downloaded entries (page 57), those changes will be lost.

If you already have four downloaded directories, the handset displays

Memory is full. Replace current directory? Press SELECT when you

try to download another cell phone directory. Press MENU/SELECT and

the system prompts you to replace an existing directory.

•

BLUETOOTH

Download dir

Add cellular

Add headset

Active devices

Answering sys

Directory

Call log

Intercom

Bluetooth

SELECT DEVICE

Cell Phone A

Cell Phone BC

Bluetooth operation

Bluetooth

Press CID or DIR to highlight one of the following

options:

Phone memory - download all contacts stored in

your phone memory.

SIM card only - download all contacts stored in your

SIM card.

Phone and SIM - download all contacts stored in

both your phone memory and SIM card.

Press MENU/SELECT. During the download, the handset

will display the progress. All system handsets will display

Cell line in use.

When the downloading process is complete, the handset

displays Download ended Total #XXXX entries saved.

Press SELECT. Press MENU/SELECT or OFF/CLEAR to

return to the download directory menu.

NOTES:

Certain cell phones do not support SIM card download. If this is the case, try

transferring the contacts from your SIM card to your cell phone memory first, then

download from your cell phone memory. For more information on how to transfer

contacts from your SIM card to your cell phone memory, see the user’s manual of your

cell phone.

When downloading the directory from your Bluetooth enabled cell phone, some data

may not transfer. For example, if you have home, mobile and work numbers for a

particular contact, the three categories may not transfer to your TL92270/TL92370.

For certain cell phones, you may need to press a key on your cell phone to confirm the

directory download.

•

Cell phone A

Downloading

entry #XXXX...

Download ended

Total #XXXX

entries saved.

Press SELECT

DOWNLOAD FROM

Phone memory

SIM card only

Phone and SIMs

Bluetooth operation

Bluetooth

Interruption to directory download

If you are downloading a directory from a cell phone and the cell phone

receives a call, the download process stops and all handsets display

Download dir aborted. When you try to view the downloaded directory, the

handset displays Last download aborted: MM/DD/YY Press SELECT. You

need to download the directory again (see page 24).

If you are downloading a directory from a cell phone and the telephone

base loses power, the download process stops. When you try to view the

directory, the handset displays No entries found. Try downloading from

SIM or Phone only Press SELECT. You need to download the directory

again (see page 24).

The download progress screen may be replaced with Downloading dir. To

go back to the downloading progress screen, do steps one through four

page 24

. The download process continues even if any of the following

occur:

You receive or make calls on the home line.

You place the handset in the telephone base or charger.

You access your cell phone menu features.

The handset battery becomes depleted or the handset loses connection

with the telephone base.

NOTE: During the download process, do not attempt to make changes to your cell phone

directory.

View the directory download information

Press MENU/SELECT on the handset when it is not in use.

Press CID or DIR to highlight Directory, then press

MENU/SELECT.

Press CID or DIR to choose the desired downloaded

directory, then press MENU/SELECT.

Press CID or DIR to highlight Last update, then press

MENU/SELECT.

•

Bluetooth operation

Cell Phone A

Last update:

12/25/09

Total #XXXX

entries saved.

Directory

Call log

Intercom

ANSWERING SYS

Announcement

Delete all old

Record memo

Answer ON/OFF

ANSWER ON/OFF

3On

Off

Answering system settings

Handset settings

Announcement

An announcement is the greeting callers hear when calls are answered by

the answering system.

The telephone is preset with a greeting that answers calls with

“Hello, please

leave a message after the tone.”

You can use this preset announcement, or

replace it with your own.

Play your announcement

Press MENU/SELECT on the handset when it is not in use.

Press CID or DIR to scroll to Answering sys, then

press MENU/SELECT.

Press CID or DIR to highlight Announcement, then

press MENU/SELECT.

The handset announces,

“To play, press 2. To record, press

7.”

Press 2 to play.

Record your own announcement

Press MENU/SELECT on the handset when it is not in use.

Press CID or DIR to scroll to Answering sys, then

press MENU/SELECT.

Press CID or DIR highlight Announcement, then press

MENU/SELECT.

The handset announces,

“To play, press 2. To record, press

7.”

Press 7 to record.

The handset announces, “Record after the tone. Press 5

when you are done.” After the tone, speak towards the

microphone of the handset.

Press 5 when you finish recording.

The handset automatically plays back the newly recorded announcement.

Press 5 to stop the playback at any time; 2 to replay the recorded

announcement; or 7 to record again if desired.

NOTES:

Your announcement can be up to 90 seconds in length.

Announcements shorter than two seconds will not be recorded.

Answering system settings

ANNOUNCEMENT

2- Play

3-Delete

7-Record

ANSWERING SYS

Play messages

Announcement

Delete all old

Record memo

Recording

announcement...

5-Stop

Announcement

play b ack

Handset settings

Answering system settings

Delete your announcement

Press MENU/SELECT on the handset when it is not in use.

Press CID or DIR to scroll to Answering sys, then

press MENU/SELECT.

Press CID or DIR to highlight Announcement, then

press MENU/SELECT.

The handset announces,

“To play, press 2. To record, press

7.”

Press 3 to delete your own recorded announcement.

The handset announces, “Announcement deleted.”

NOTE: When your announcement is deleted, calls are answered with

the preset announcement.

4. ANNOUNCEMENT

2- Play

3-Delete

7-Record

ANSWERING SYS

Play messages

Announcement

Delete all old

Record memo

Handset settings

Answering system settings

In the answering system setup menu, you can change the settings for call

screening, number of rings, remote access code and message alert tone.

Call screening

The call screening feature lets you listen at the telephone

base to a caller leaving a message. You can turn this feature

on or off with a system handset.

To change the settings:

Press MENU/SELECT in idle mode to enter the main menu.

Use CID or DIR to scroll to Answering sys, then press

MENU/SELECT.

Use CID or DIR to scroll to Ans sys setup, then press

MENU/SELECT twice to select Call screening.

Press CID or DIR to choose between On and Off.

Press MENU/SELECT to confirm your setting. You hear a

confirmation tone.

Number of rings

When the answering system is turned on, it answers all incomfing home calls

after the number of rings set. You can choose from two, four, or six rings;

or toll saver. With toll saver selected, the answering system answers after

two rings when you have new messages, and after four rings when you have

no new messages. This enables you to check for new messages and avoid

paying unnecessary long distance charges if you are calling from out of your

local area.

To change the setting:

Press MENU/SELECT on the handset when it is not in use.

Press CID or DIR to highlight Answering sys, then

press MENU/SELECT.

Press CID or DIR to highlight Ans sys setup, then

press MENU/SELECT.

Press CID or DIR to highlight # of rings, then press

MENU/SELECT.

Press CID or DIR to choose from 2,4,6 or Toll saver,

then press MENU/SELECT to confirm.

ANSWERING SYS

Delete all old

Record memo

Answer ON/OFF

Ans sys setup

ANS SYS SETUP

Call screening

# of rings

Remote code

Msg alert tone

CALL SCREENING

3On

Off

ANS SYS SETUP

Call screening

# of rings

Remote code

Msg alert tone

# OF RINGS

Toll saver

Handset settings

Answering system settings

ANS SYS SETUP

Call screening

# of rings

Remote code

Msg alert tone

REMOTE CODE

ANS SYS SETUP

Call screening

# of rings

Remote code

Msg alert tone

MSG ALERT TONE

3On

Off

Remote access code

A two-digit security code is required to access the

answering system remotely from any touch tone telephone.

The preset code is 19. You can change the code to any

number from 00 to 99.

To change the setting:

Press MENU/SELECT in idle mode to enter the main menu.

Use CID or DIR to scroll to Answering sys, then press

MENU/SELECT.

Use CID or DIR to scroll to Ans sys setup, then press

MENU/SELECT.

Press CID or DIR to scroll to Remote code, then press MENU/SELECT.

Use the dialing keys (0-9) to enter a two-digit number from 00-99, then

press MENU/SELECT to confirm.

Press MUTE/DELETE to erase a digit.

Press and hold MUTE/DELETE to erase all digits.

Press CID to move the cursor to the left or DIR to the right.

Press MENU/SELECT to confirm your setting. You hear a confirmation tone.

Message alert tone

When the message alert tone is set to On, the telephone base beeps every

10 seconds to alert you of new messages. The tone stops when all new

messages have been reviewed. The message alert tone is set to off.

To change the setting:

Press MENU/SELECT in idle mode to enter the main menu.

Use CID or DIR to scroll to Answering sys, then press

MENU/SELECT.

Use CID or DIR to scroll to Ans sys setup, then press

MENU/SELECT.

Press CID or DIR to scroll to Msg alert tone, then

press MENU/SELECT.

Press CID or DIR to choose between On and Off.

Press MENU/SELECT to confirm your setting. You hear a

confirmation tone.

NOTE: The message alert tone must be turned on for the message alert tone to function.

•

Telephone operation

Making, answering and ending a call

Telephone operation

Making a call

Using a handset:

To make a home call:

Press HOME/FLASH or SPEAKER, then enter the

telephone number.

To predial a home call:

Enter the telephone number, then press HOME/FLASH or

SPEAKER.

To answer a home call:

Press HOME/FLASH or SPEAKER.

NOTES:

The screen shows the elapsed time as you talk (in hours, minutes and seconds).

When predialing (preview numbers before dialing), press MUTE/DELETE or

OFF/CLEAR to backspace and delete; press and hold REDIAL/PAUSE to insert a

dialing pause (a p appears).

You cannot answer a home call using your connected cell phone.

To end a home call:

Press OFF/CLEAR or put the handset in the telephone base or charger.

Use a Bluetooth headset:

You can use a Bluetooth headset on home calls. However, you will need to

stay within 30 feet from the telephone base to maintain the Bluetooth signal.

To answer a home call using a Bluetooth headset:

Press the call key on your headset.

To end a home call you answered from a Bluetooth headset:

Press the call key on your headset.

If you make or answer a home call on a handset, you can transfer the call

to your headset. The handset remains active, but the handset earpiece and

microphone are muted. If you hang up the handset, the call will end.

To transfer a call from a handset to a Bluetooth headset:

Press MENU/SELECT twice to select Use headset.

To transfer a call from the Bluetooth headset back to the handset:

Press MENU/SELECT twice to select Use handset.

To end a call that started at the handset:

Press OFF/CLEAR or put the handset in the telephone base or charger.

NOTES:

If you answer a call using a headset, and you lose the Bluetooth connection or the

battery is depleted, the call will be lost.

If you are using a headset for a call which is transferred from a TL92270/TL92370

handset, and you lose the Bluetooth connection or the battery of the headset is

depleted, the call will be transferred back to the originating handset.

•

Telephone operation

Options while on calls

Call waiting on the home line

If you subscribe to call waiting service with your telephone service provider,

you hear a beep if someone calls while you are already on a call.

Press HOME/FLASH on the handset to put your current call on hold and

take the new call.

Press HOME/FLASH on the handset at any time to switch back and forth

between calls.

Make, answer or end a cell call

You can connect a maximum of two Bluetooth enabled cell phones to the

telephone base, but only one cell phone can be used on a cell call at a time.

All TL92270/TL92370 handsets can be used to make or answer calls on the

cell phone line.

To make a cell call:

Enter the telephone number, then press CELLULAR.

If you have only one cell phone connected to the telephone base, it is

automatically selected to make cell calls. If you have two cell phones

connected to the telephone base, the telephone system prompts you to select

a cell phone before you make a cell call.

To answer a cell call:

Press CELLULAR.

NOTE: You can also use your cell phone to answer the call. If you answer with your cell

phone, it will disconnect from the telephone base.

To end a cell call:

Press OFF/CLEAR or put the handset in the telephone base or charger.

Call waiting on the cell line

If you subscribe to call waiting service with your cell phone service provider,

you hear a beep if someone calls while you are already on a call.

Press CELLULAR on the handset to put your current call on hold and

take the new call.

Press CELLULAR on the handset at any time to switch back and forth

between calls.

-OR-

Press MENU/SELECT twice to select SWAP to switch back and forth

between calls.

•

Telephone operation

Options while on calls

Answer a cell call while on a home call

If you are on a home call and you receive an incoming cell call, you will

hear a beep and 1 or 2 displays on the handset you are using. The

telephone base and all other handsets will ring.

To answer the incoming cell call:

Press CELLULAR on the handset. The home call is automatically placed

on hold and all other handsets display Home call on hold and Cell line in

use alternatively.

To end the cell call:

Press OFF/CLEAR on the handset. The home line is still on hold. All

handsets display Home call on hold.

To resume the home call on hold:

Press HOME/FLASH on the handset.

Cell phone voicemail

If you have voicemail service active on your cell phone, and you do not

answer the incoming cell call, the call will be answered by your cell phone’s

voicemail. Contact your cell phone service provider for more information

about voicemail service.

Answer a home call while on a cell call

If you are on a cell call and you receive an incoming home call, you will hear

a beep and displays on the handset you are using. The telephone base and

all other handsets will ring.

To answer the incoming home call:

Press HOME/FLASH on the handset. The cell call is automatically placed

on hold and all other handsets display Cell call on hold and Home line in

use alternatively.

To end the home call:

Press OFF/CLEAR on the handset. The cell line is still on hold. All

handsets display Cell call on hold.

To resume the cell call on hold:

Press CELLULAR on the handset.

NOTE: If you have turned on your answering system and you do not answer the incoming

home call, the call will be answered by your answering system.

•

Telephone operation

Options while on calls

Conference home and cell calls

When you have calls established on the home and cell lines, you can create

a 3-way conference.

To conference both home and cell calls:

Press MENU/SELECT.

Press CID or DIR to highlight Conf. with home/Conf. with cell

(whichever is applicable).

Press MENU/SELECT.

To select an option while on a conference call:

Press

MENU/SELECT.

Press CID or DIR to select one of the following options:

End home call

End cell call

Press MENU/SELECT.

To end a conference call:

Press OFF/CLEAR or put the handset back in the telephone base or

charger.

Using the home and cell lines together

You can be on two different calls using the cell line and home line at the

same time using two handsets.

You cannot be on a call using the cell line and a Bluetooth headset via the

home line at the same time. These are both Bluetooth devices and only

one can be used at a time.

If you are on a call using the cell line, you cannot join the call using your

paired cell phone. However, you can join the call using another TL92270/

TL92370 handset. Your cell phone is being used for the phone call so only

features that are normally available during a call can be used.

•

Telephone operation

Options while on calls

Handset speakerphone

During a call, press SPEAKER to switch between speakerphone and normal

handset use.

Volume control

While on a call, press +VOLUME to increase or press -VOLUME to decrease

the listening volume.

If this is a cell call and the volume is too loud or quiet, try changing the

volume on your cell phone. On some cell phones, changing the volume

on the cell phone effects your cell call volume on the TL92270/TL92370

handset.

NOTE: The handset earpiece volume setting (1-5) and speakerphone volume setting (1-6)

are independent.

Silencing the ringer

When the telephone is ringing, you can temporarily silence the ringer of the

handset or telephone base without disconnecting the call. The next call rings

normally at the preset volume.

To silence the handset ringer:

Press OFF/CLEAR or MUTE/DELETE on the handset and Ringer mute

appears.

To silence the base ringer:

Press -VOLUME on the telephone base.

Mute

Use the mute function to turn off the microphone. You can

hear the caller, but the caller does not hear you.

To mute the call:

Press MUTE/DELETE. When mute is on, the handset screen

shows Muted for a few seconds and the MUTE icon

appears until you turn off mute.

To un-mute the call:

Press MUTE/DELETE and resume speaking. When mute is

off,

Microphone on appears temporarily on the handset

screen.

Mute is automatically canceled when you end the call.

•

Home 0:00:15

Microphone off

Home 0:00:15

MUTE

Telephone operation

Options while on calls

Temporary tone dialing

If you have pulse (rotary) service only, you can switch from pulse to touch

tone dialing temporarily during a call. This is useful if you need to send touch

tone signals to access your telephone banking or long distance services.

During a call:

Press TONE .

Use the dialing keys to enter the relevant number. The telephone sends

touch tone signals.

The telephone automatically returns to pulse dialing mode after you end

the call.

Hold

You can place a home or cell call on hold. You will hear an alert tone if you

have not taken the call off of hold after 14 minutes. You will hear another

alert tone 30 seconds later. At 15 minutes on hold, the call on hold

automatically disconnects.

To place a home call on hold:

Press HOLD.Home call on hold appears and

HOME/FLASH flashes.

To resume a home call on hold:

Press HOME/FLASH.

To place a cell call on hold:

Press HOLD.Cell call on hold appears and

CELLULAR flashes.

To resume a cell call on hold:

Press CELLULAR.

•

Telephone operation

This feature helps you find a misplaced handset.

To start paging:

Press HANDSET LOCATOR on the telephone

base when it is not in use. All idle handsets

ring and display ** Paging **.

To end paging:

Press HANDSET LOCATOR on the telephone

base.

-OR-

Press HOME/FLASH

SPEAKER

or any

dialing keys (0-9,#,

TONE

) on the handset.

NOTES:

If the ringer volume for all are set to off, the handset sill rings when paging.

If there is no response after 60 seconds, paging ends.

Handset locator

Telephone operation

Chain dialing

Use this feature to initiate a dialing sequence from numbers stored in the

directory, call log or redial while you are on a call.

Chain dialing can be useful if you wish to access other numbers (such as bank

account numbers or access codes) from the directory, call log or redial list.

To access a number in the directory while on a call:

Press MENU/SELECT.

Press CID or DIR to highlight Directory, then press MENU/SELECT.

Press MENU/SELECT to select Home directory.

Press CID or DIR to scroll to the desired entry or perform an

alphabetical search (page 57).

Press MENU/SELECT to dial the displayed number.

To access a number in the call log while on a call:

Press MENU/SELECT.

Press CID or DIR to highlight Call log, then press MENU/SELECT.

Press CID or DIR to scroll to the desired entry.

Press MENU/SELECT to dial the displayed number.

To access the redial list while on a call:

Press REDIAL/PAUSE.

Press DIR,CID or REDIAL/PAUSE until the desired number displays, then

press MENU/SELECT. If you do not press MENU/SELECT within two seconds,

the number displayed will be dialed automatically.

NOTES:

You cannot edit a directory entry while on a call. For more details about the directory,

see page 53.

You cannot copy a caller ID entry into the directory while on a call. For more details

about the caller ID history, see page 60.

You can only view the numbers in the directory, call log or redial while on a call and

cannot erase any entries.

Press OFF/CLEAR to exit redial, directory or caller log and return while on a call.

Telephone operation

Redial stack

The handset stores the twenty numbers (up to 30 digits each) recently called

from this handset in the redial list.

Review the redial list

Press REDIAL/PAUSE in idle mode.

Press

CID,DIR

or REDIAL/PAUSE to browse until the

desired number displays. The handset beeps twice at

the end of the list.

Press OFF/CLEAR to exit.

Dial a redial entry

Press HOME/FLASH

SPEAKER

, then press

REDIAL/PAUSE repeatedly to view the redial memory. The

displayed number you view for over two seconds will be

automatically dialed out.

-OR-

Press

REDIAL/PAUSE

in idle mode.

Press

CID,DIR

or REDIAL/PAUSE to browse until the desired number

displays. The handset beeps twice at the end of the list.

Press HOME/FLASH or SPEAKER to use the home line.

-OR-

Press CELLULAR to use the cell line.

REDIAL

888-883-2445

Telephone operation

Save a redial entry to the directory

Press REDIAL/PAUSE in idle mode.

Press

CID,DIR

or REDIAL/PAUSE to browse until the desired number

displays.

Press MENU/SELECT twice.

The handset displays ENTER NUMBER. Use the dialing keys to edit the

number, if necessary.

Press MUTE/DELETE to erase a digit.

Press and hold MUTE/DELETE to erase all digits.

Press CID to move the cursor to the left or DIR to the right.

Press and hold REDIAL/PAUSE to insert a dialing pause (a p appears).

Press MENU/SELECT.

Press CID or DIR to select one of the following types:

Home

Cell

Work

Other

Press MENU/SELECT. The handset displays ENTER NAME. Use the dialing

keys (page 55) to enter a name.

Press MUTE/DELETE to erase a character.

Press and hold MUTE/DELETE to erase all characters.

Press CID to move the cursor to the left or DIR to the right.

Press MENU/SELECT to confirm. The handset screen shows Saved and you

hear a confirmation tone.

Delete a redial entry

Press REDIAL/PAUSE when the handset is not in use.

Press

CID,DIR

or REDIAL/PAUSE to browse until the desired number

displays.

Press MUTE/DELETE to delete the displayed number.

•

Redial stack

Telephone operation

Use the intercom feature for conversations between two system handsets.

You can buy additional expansion handsets (TL90070) for this telephone

system. You can register up to 12 handsets to the telephone base.

To initiate an intercom call

Press MENU/SELECT on the handset in idle mode.

Press CID or DIR to highlight Intercom, then press

MENU/SELECT.

If you have a two-handset system, your handset displays

Calling other handset. The destination handset rings

and displays Other handset is calling. The destination

handset rings and displays Handset X is calling.

If you have more than two handsets, your handset

displays INTERCOM TO: and a list of registered

handsets. Press CID or DIR to select a destination

handset and then press MENU/SELECT. You may also

press 1-9 for HANDSET 1-9,*0 for HANDEST 10,

*1 for Handset 11 or *2 for Handset 12. Your handset displays

Calling HANDSET X. The destination handset rings and displays

HANDSET X is calling.

To answer an intercom at the destination handset:

Press

HOME/FLASH or

SPEAKER

. Both screens show Intercom.

To silence an intercom call:

Press OFF/CLEAR or MUTE/DELETE on the destination handset. Its screen

displays Ringer muted for a few seconds.

To end an intercom call:

Press OFF/CLEAR or place either handset back in the telephone base or

charger. Both handsets display Intercom ended.

NOTES:

You can cancel the intercom call before it is answered by pressing OFF/CLEAR on

your originating handset.

If the destination handset does not answer the intercom call within 100 seconds, is in

the directory or call log, or is out of range, the originating handset displays Unable to

call try again and returns to idle mode.

You can use a maximum of five handsets at a time. For example, when four handsets

are used on intercom calls, use another handset for an outside call. When two handsets

are used on an intercom call, you can use three other handsets for an outside call.

•

Intercom

INTERCOM TO:

HANDSET 2

HANDSET 3

HANDSET 4

HANDSET 5

Play messages

Answering sys

Directory

Call log

Intercom

Telephone operation

Answer an incoming call during an intercom call

When you receive an incoming home call during an intercom call, there is an

alert tone and Incoming call appears on screens. The telephone base and all

other handsets ring.

Press HOME/FLASH to answer the home call and the intercom call ends

automatically.

Press OFF/CLEAR to end the intercom call without answering the

incoming call. The telephone continues to ring.

When you receive an incoming cell call during an intercom call, there is an

alert tone and Incoming call appears on screens. The telephone base and all

other handsets ring.

Press CELLULAR to answer the cell call and the intercom call ends

automatically.

Press OFF/CLEAR to end the intercom call without answering the

incoming call. The telephone continues to ring.

•

Intercom

Telephone operation

Call transfer and sharing

Share an outside call

Another handset can join you on an outside call. That call continues until

all people hang up. You can share an outside call with up to four system

handsets.

Press HOME/FLASH or SPEAKER on another handset to join the call.

Transferring an outside call

Use the intercom feature to transfer an outside call from one

handset to a paired headset or another handset.

To transfer the outside call to a paired headset:

When on an outside call, press MENU/SELECT.

Press MENU/SELECT to select Use headset.

If you have only one headset, the original handset

shows Transferring audio to Headset 1. The outside

call is automatically transferred to the headset

If you have two headsets, press CID or DIR to select

a headset, then press MENU/SELECT.

-OR-

Press #1 or #2 to select a destination headset, then

press MENU/SELECT.

The handset shows Transferring audio to

Headset X. The outside call is automatically transferred

to the destination headset.

To transfer the outside call back to the original handset, press

MENU/SELECT on the handset. Press MENU/SELECT again to select

Use handset. The outside call continues with the original system handset.

NOTES:

Use headset only shows if a headset is paired (see pages 17-18).

The handset screen shows Transfer fail. Please turn ON headset & place next to

base. Press SELECT if the handset fails to transfer the outside call.

If the headset is not connected, the handset screen shows Headset not connected! To

connect, press SELECT. Press MENU/SELECT to connect your headset to the telephone

system. If the connection still fails, the handset shows Connection fail please turn

ON headset & place next to base. Press SELECT. Press MENU/SELECT to resume the

outside call to the original handset. You may refer to the Pair a headset section on

pages 17-18 for pairing a Bluetooth headset.

•

Use headset

Intercom

Directory

Call log

Home 0:00:12

Transferring

audio to

Headset 1

Home 0:00:15

Telephone operation

Call transfer and sharing

To transfer the outside call to a handset:

When on an outside call, press MENU/SELECT.

Press CID or DIR to highlight Intercom, then press

MENU/SELECT.

If you have a two-handset system, your handset

displays Calling other handset. The destination

handset rings and displays Other handset is calling.

If you have more than two handsets, your handset

displays INTERCOM TO: and a list of registered

handsets. Press CID or DIR to select a destination

handset and then press MENU/SELECT.

-OR-

Press 1-9 for Handset 1-9,*0 for Handset 10,*1 for Handset 11

and *2 for Handset 12 to select a destination handset and then press

MENU/SELECT.

The destination handset rings and displays Handset X is calling.

When the destination handset answers the intercom call, both screens

show Intercom.

Press MENU/SELECT on the original handset.

Press MENU/SELECT again to select Transfer to transfer

the outside call to another handset. After the call is

transferred, the original handset screen shows Call

transfered.

You can also share the outside call with another handset.

Press MENU/SELECT during the intercom call.

Press CID or DIR to highlight Share call and then

press MENU/SELECT to share the outside call with

another handset.

NOTES:

When on intercom, you may press OFF/CLEAR on your original handset or destination

handset to end the intercom. The destination handset shows Intercom ended and the

outside call continues with the original system handset.

When on intercom, you may press HOME/FLASH on your original handset or

destination handset to reconnect with the outside call. The original handset and

destination handset shares the outside call.

•

Use headset

Intercom

Directory

Call log

INTERCOM TO:

Handset 2

Handset 3

Handset 4

Handset 5

Tra n sfe r

Share call

Intercom

Telephone operation

Equalizer setting

The equalizer feature on the handset enables you to change

the audio tone of the handset during an outside call,

intercom call or message playback.

Press EQ while on a call, intercoming or listening to a

message or announcement to select the equalizer setting

from Treble 1,Treble 2,Bass or Natural (the default setting)

for the handset. The current setting is shown on the handset

for two seconds.

NOTES:

The equalizer feature does not apply to the speakerphone on the

telephone base and the connected Bluetooth headset.

If you switch the call between the handset and speakerphone by

pressing SPEAKER, the audio setting remains unchanged.

The current equalizer setting remains unchanged until a new setting

is selected.

Treble 1

Treble 2

Bass

Natural

Directory

The home directory stores up to 200 entries with up to 30 digits for each

phone number and 15 characters for each name. Each of the downloaded

directory stores up to 1,500 entries with up to 30 digits for each phone

number and 15 characters for each name.

Directory entries are stored at the telephone base and shared by all

system handsets. Any changes made on one handset apply to all.

Only one handset can review the directory at a time. If another handset

tries to enter the directory, its screen shows Not available at this time.

When there are no records in the directory, the screen shows

Directory empty.

When the directory is full and you try to save an entry, the screen shows

List full.

When you try to save a number already stored in the directory, the screen

shows Already saved.

All of the instructions on pages 54-58 for the directories apply to the home

directory and all downloaded directories. Creating a new entry on page 52

only applies to the home directory.

You cannot create new entries in your downloaded directories from the

TL92270/TL92370 handset. Entries must be downloaded from your cell

phone (see Download directory on pages 24-25).

•

Directory

Create a new entry in the home directory

Press MENU/SELECT on the handset when it is not in use.

Press CID or DIR to highlight Directory, then press MENU/SELECT.

Press MENU/SELECT to select Home.

Press CID or DIR to highlight Add contact, then press MENU/SELECT.

The screen displays ENTER NUMBER.

Use the dialing keys to enter a telephone number.

Press MUTE/DELETE to erase a digit.

Press and hold MUTE/DELETE to erase all digits.

Press CID to move the cursor to the left or DIR to the right.

Press and hold REDIAL/PAUSE to insert a dialing pause (a p appears).

-OR-

Copy a number from the redial list.

1. Press REDIAL/PAUSE and then CID,DIR or REDIAL/PAUSE to browse

to select a number.

2. Press MENU/SELECT to copy the displayed number.

Press MENU/SELECT.

Press CID or DIR to select one of the following types:

Home

Cell

Work

Other

Press MENU/SELECT. The screen displays ENTER NAME.

Use the dialing keys (see page 55) to enter the name.

Press MUTE/DELETE to erase a character.

Press and hold MUTE/DELETE to erase all characters.

Press CID to move the cursor to the left or DIR to the right.

Press MENU/SELECT to confirm and the screen shows Saved.

NOTE: You cannot create new entries in your downloaded directories from you TL92270/

TL92370 handsets. Entries must be downloaded from your cell phone (see Download

directory on pages 24-25).

•

10.

Directory

Character chart

The directory is stored in the telephone base, and is shared by all handsets.

Changes made to the directory on any one handset apply to all.

NOTE: When entering a name in the directory, the first letter of each word is automatically

capitalized.

Directory

Number

key

Characters by number of key presses

1234567891011

11.-,()*#&/,

2ABCabc 2

3DEFde f 3

4GH I g h i 4

5JKL j k l 5

6MNOmn o 6

7PQR S p q r s 7

8TUV t uv8

9WX Y Zw x y z 9

0Space 0

Directory

Review the directory

Entries are sorted alphabetically.

To review the directory:

Press DIR in idle mode.

Press CID or DIR to choose a directory, then press MENU/SELECT. (If

you only have one directory with entries, this step is not necessary.)

Press CID or DIR to browse.

-OR-

Press MENU/SELECT on the handset when it is not in use.

Press CID or DIR to highlight Directory, then press MENU/SELECT.

Press CID or DIR to choose a directory, then press MENU/SELECT.

Press CID or DIR to highlight Review, then press MENU/SELECT.

Press CID or DIR to browse.

NOTE: When the desired entry displays, press # repeatedly to show different dialing

options.

3-character alphabetical search

You can use the enhanced 3-character search to find your contacts quickly

and efficiently.

To start the search:

Follow the steps in Review the directory above to enter the directory.

When an entry appears, use the dialing keys to enter the letters

associated with the name (see page 55). You can enter up to three letters

for the search. If there is no name matching the letter(s) entered, the

next closest match in alphabetical order appears. If necessary, use CID

or DIR to browse.

Directory

Dial, Edit or delete a directory

Dial a directory entry

You can dial a directory entry on either a home or cell line.

To dial a directory entry:

Search for the desired entry in the directory (see Review the directory or

3-character alphabetical search on page 55).

When the desired entry appears, press # repeatedly to

show different dialing options.

When the displayed number is in the correct format,

press HOME/FLASH or SPEAKER to use the home

line,or CELLULAR to use the cell line.

Edit a directory entry

You may edit any directory entry. However, be aware that if you download

from a cell phone again, the directory will be erased and replaced with the

current cell phone directory. If you have edited the downloaded entries on

the TL92270/TL98370, those changes will be lost.

Search for the desired entry in the directory (see Review the directory or

3-character alphabetical search on page 55).

When the desired entry appears, press MENU/SELECT. The screen shows

EDIT NUMBER.

Use the dialing keys to edit the number.

Press MUTE/DELETE to erase a digit.

Press and hold MUTE/DELETE to erase all digits.

Press CID to move the cursor to the left or DIR to the right.

Press and hold REDIAL/PAUSE to insert a dialing pause (a p appears).

Press MENU/SELECT.

Press CID or DIR to select one of the following types:

Home

Cell

Work

Other

Press MENU/SELECT. The screen displays ENTER NAME.

Use the dialing keys (see page 55) to enter the name.

Press MUTE/DELETE to erase a character.

Press and hold MUTE/DELETE to erase all characters.

Press CID to move the cursor to the left or DIR to the right.

Press MENU/SELECT to confirm and the screen shows Saved.

•

800-595-9511

1-800-595-9511

595-9511

1-595-9511

Directory

Dial, Edit or delete a directory

Edit the type of a directory entry

If you only want to edit the type of a directory entry:

Search for the desired entry in the directory (see Review the directory or

3-character alphabetical search on page 56).

When the desired entry appears, enter the corresponding shortcut keys

shown in the below table.

Type: Press:

Home 1

Cell 2

Work 3

Other 4

Delete a directory entry

To delete an entry:

Search for the desired entry in the directory (see Review the directory or

3-character alphabetical search on page 56).

When the desired entry appears, press the MUTE/DELETE. The screen

displays Delete contact? Press SELECT to confirm.

Press MENU/SELECT. The screen displays Contact deleted and then the

next alphabetical entry in the directory.

NOTE: Once a directory entry is deleted, it cannot be retrieved.

Remove a downloaded directory

(downloaded directories only)

Search for a desired downloaded directory in the directory menu (see

Review the directory on page 56).

When the desired downloaded directory is chosen, press CID or DIR to

highlight Remove dir and then press MENU/SELECT.

The screen displays Directory Cell Phone A will be erased. Press SELECT

to confirm. Press MENU/SELECT and the screen displays Directory

removed.

Caller ID

About caller ID

This product supports caller ID services provided by most telephone service

providers. Depending on your service subscription, you may see the caller’s

number, or the caller’s name and number from the telephone service provider

after the first or second ring. Caller ID from the home line allows you to see

the name, number, date and time of the incoming calls. However, caller ID

from the cell line only shows the number of the incoming caller; date and

time of the call is not shown. The caller ID may appear differently if the caller

is matched to a directory entry (see Memory match on page 61).

Information about caller ID with call waiting

Caller ID with call waiting lets you see the name and

telephone number of the caller before answering the

telephone, even while on another call.

It may be necessary to change your telephone service to use

this feature. Contact your telephone service provider if:

You have both caller ID and call waiting, but as separate

services (you may need to combine these services).

You have only caller ID service, or only call waiting service.

You don’t subscribe to caller ID or call waiting services.

There are fees for caller ID services. In addition, services may

not be available in all areas.

Caller ID information is available only if both you and the

caller are in areas offering caller ID service, and if both

telephone service providers use compatible equipment.

The caller ID information may not be available for every

incoming call. The callers may intentionally block their names

and/or telephone numbers. To view call log entries with

numbers between 16 and 24 digits, you must save the entry

to the directory (page 63). For instructions on viewing the

digits, see the note of Review the directory section on page 56.

NOTE: You can use this product with regular caller ID service, or you can use this

product’s other features without subscribing to caller ID or combined caller ID with call

waiting service.

•

CHRISTINE SMITH

888-722-7702

3:45am 12/25

NEW

Caller ID

Caller ID operation

Caller ID history

If you subscribe to caller ID service provided by your telephone service

provider and/or cell phone service provider, information about each caller

appears after the first or second ring. If you answer a call before the caller

information appears on the screen, it will not be saved in the call log.

The call log stores up to 50 entries. Each entry has up to 24 digits for

the phone number and 15 characters for the name. If the name has

more than 15 characters, only the first 15 characters are shown and

saved in the call log.

You can review, redial, and copy an entry into the directory.

Entries are in reverse chronological order.

When the call log is full, the oldest entry is deleted to make room for

new incoming call information.

XX Missed call(s) shows when there are new call log entries (including

missed and unreviewed calls).

Call log empty shows when there are no records in the call log.

Only one handset can review the call log at a time. If a handset tries to

enter the call log while another handset is already in it, Not available at

this time appears.

NOTE: If the phone number has more than 24 digits, it will not be saved or shown in the

call log.

•

CHRISTINE SMITH

888-722-7702

3:45am 12/25

NEW

Caller’s name

Caller’s number

Appears when there are

missed and unreviewed

calls.

Time of call

Date of call

Caller ID

Memory match

If the incoming telephone number matches the last seven

digits of a telephone number in your directory, the name

that appears on the screen matches the corresponding

name in your directory.

For example, if Christine Smith calls, her name appears as

Chris if this is how you enter it into your directory.

NOTE: The number you see on your caller ID is in the format

from the telephone service provider. It usually delievers 10-digits

telephone numbers (area code plus telephone number). If the

telephone number of the caller does not exactly match a number

in your directory, the name will appear as it is delivered by the

telephone service provider. For example, if the telephone service

provider includes the area code buy your directory number does

not, the name will appear as delivered by the telephone service

provider.

Missed calls indicator

When there are unreviewed calls in the call log, the handsets

show XX Missed call(s).

Each time you review a call log entry marked NEW, the

number of missed calls decreases by one.

When you have reviewed all the missed calls, the missed

calls indicator no longer shows.

If you do not want to review the missed calls one by one,

press and hold OFF/CLEAR to erase the missed calls

indicator. All the entries are then considered old and kept in

the call log.

Caller ID operation

Chris

888-722-7702

3:45am 12/25

NEW

HANDSET X

XX Missed calls

3:45am 12/25

Christine Smith

888-722-7702

3:45am 12/25

NEW

Caller ID

Caller ID operation

Review the call log

When a handset is in idle mode, press CID to review the caller ID history

in reverse chronological order starting with the most recent call.

-OR-

You can also review the caller ID history by pressing MENU/SELECT, then

press CID or DIR to scroll to Call log, then press MENU/SELECT twice.

Press CID or DIR to scroll through the list. A double beep sounds when

the list reaches the beginning or end of the caller ID history.

Press OFF/CLEAR to exit the caller ID history.

View dialing options

Although the call log entries received have 10 digits (the area code plus the

seven-digit number), in some areas, you may need to dial only the seven

digits, or 1 plus the seven digits, or 1 plus the area code plus the seven

digits. You can change the number of digits that you dial from the call log or

store to the directory.

While reviewing the call log, press # repeatedly

to show different dialing options for local and

long distance numbers before dialing or saving

the telephone number in the directory.

Press 1 repeatedly if you need to add or remove

1 in front of the telephone number before

dialing or saving it in the directory.

When the number shows in the correct format

for dialing, press

HOME/FLASH or SPEAKER to call the number.

888-883-2445

1-888-883-2445

883-2445

1-883-2445

888-883-2445

1-888-883-2445

883-2445

1-883-2445

Press #

Press 1

Caller ID

Call ID operation

Dial a call log entry

Search for the desired entry in the call log (see Review the call log on

page 62).

When the desired entry appears and is in the correct format for dialing,

press HOME/FLASH or SPEAKER to use the home line,or

CELLULAR to use the cell line.

Save a call log entry to the directory

Call log entries can only be saved to the Home directory.

Select a desired entry in the call log (see Review the call log on page 62).

When the desired entry appears, press # repeatedly to show different

dialing options

When the number is in the correct format, press MENU/SELECT. The screen

shows Edit number.

Use the dialing keys to edit the number.

Press MUTE/DELETE to erase a digit.

Press and hold MUTE/DELETE to erase all digits.

Press CID to move the cursor to the right or DIR to the left.

Press and hold REDIAL/PAUSE to insert a dialing pause (a p appears).

Press MENU/SELECT.

Press CID or DIR to select one of the following types:

Home

Cell

Work

Other

Press MENU/SELECT. The screen displays Edit name.

Use the dialing keys (see page 55) to edit the name.

Press MUTE/DELETE to erase a character.

Press and hold MUTE/DELETE to erase all characters.

Press CID to move the cursor to the right or DIR to the left.

Press MENU/SELECT to confirm and the screen shows Saved.

•

Caller ID

Caller ID operation

To delete a single entry

Select a desired entry in the call log (see Review the call log on page 62).

When the desired entry appears, press MUTE/DELETE. The screen shows

the previous call log entry.

To delete all entries

Press MENU/SELECT on the handset when it is not in use.

Press CID or DIR to highlight Call log, then press

MENU/SELECT.

Press CID or DIR to highlight Del all calls, then press

MENU/SELECT.

The screen displays Delete all calls? Press SELECT to confirm. Press

MENU/SELECT to clear all entries and you hear a conformation tone.

Reasons for missing caller ID information

There are also occasions when other information or no information shows for

various reasons:

On-screen message Reason

Private name The caller prefers not to show the name.

Private number The caller prefers not to show the phone number.

Private caller The caller prefers not to show the phone number

and name.

Unknown name Your telephone service provider cannot determine

the caller’s name.

Unknown number Your telephone service provider cannot determine

the caller’s number.

Unknown caller No information is available about this caller.

LIt is a long distance call.

CALL LOG

Review

Del all calls

Answering system and voicemail

Your telephone has separate indicators for two different types of voice

messages: those left on its built-in answering system and those left at

your service provider’s voicemail (fees may apply). Your telephone’s built-

in answering system messages and voicemail messages are separate. Each

alerts you to new messages differently.

If and New voicemail display on the handsets, your telephone service

provider is indicating that it has new voicemail for you. To listen to your

voicemail, you typically dial an access number provided by your telephone

service provider, followed by a security code or PIN.

To listen to messages recorded on your digital answering system, press

/PLAY/STOP on the telephone base (page 67).

Some service providers bundle or combine multiple services like voicemail

and call waiting, so you may not be aware that you have voicemail. To check

what services you have and how to access them, contact your telephone

service provider.

You can use your telephone answering system and voicemail together by

setting your built-in answering system to answer before voicemail answers.

To learn how to program your voicemail settings, contact your telephone

service provider. If you are on a call, or if the answering system is busy

recording a message and you receive another call, the second caller can

leave a voicemail message by following the instructions below.

Set your answering system to answer calls at least two rings earlier than

your voicemail is set to answer. For example, if your voicemail answers

after six rings, set your answering system to answer after four rings. Some

voicemail providers may program the delay before answering calls in seconds

instead of rings. In this case, allow six seconds per ring when determining the

appropriate setting.

Message capacity

The answering system can record and store up to 99 messages. Each

message can be up to four minutes in length. The total storage capacity

for the announcement, messages and memos is approximately 14 minutes.

The actual recording time depends on individual message characteristics.

Messages remain available for replay until you delete them.

•

About the answering system

Answering system

About the answering system

New message indication

The message window on the telephone base flashes and the handset shows

and New messages when there are new answering system messages.

If the new message alert tone is turned on, the telephone base beeps every

10 seconds when there are unreviewed messages.

Call screening at the telephone base

If the answering system is on, you hear the announcement and the incoming

message when receiving a call. Press +VOLUME or -VOLUME on the

telephone base to adjust the message volume.

-OR-

Press /PLAY/STOP on the telephone base to turn off the call screening.

The call screening setting resumes On for the next incoming message.

If the calling screening is set to off, when the answering system is answering

a call, press /PLAY/STOP or +VOLUME to initiate the call screening. The

call screening setting resumes Off for the next incoming message.

Call intercept

When a caller is leaving a message on your answering system, you can

stop recording and talk to the caller by pressing HOME/FLASH or

SPEAKER on the handset.

Telephone base ringer volume

Press +VOLUME or -VOLUME on the telephone base to adjust the ringer

volume when the telephone is not in use. When you set the ringer volume to

zero, the base ringer is off and the system announces, “Base ringer is off.”

Temporarily turning off the message alert tone

Pressing any telephone base key (except HANDSET LOCATOR) temporarily

silences the message alert tone.

If you press X DELETE when in idle mode, there is a voice prompt to direct

you to press X DELETE again to delete all old messages, and the message

alert is temporarily off.

The message alert tone is reactivated with the next incoming message.

Voice prompts

The system provides voice prompts to guide you through remote access and

recording outgoing announcements.

Answering system

Message playback

If you have new messages, the telephone plays only the new messages

(oldest first). If there are no new messages, the telephone plays back all

messages (oldest first).

When playback begins, the handset screen displays PLAYING MESSAGES

and you hear the total number of messages followed by the day and time

of the message. After the last message, the telephone announces, “End of

messages.” and the screen displays End of messages. If the recording time

is less than three minutes, you hear, “Last and three minutes to record.“ (see

Message capacity on page 65)

To listen to messages with the telephone base:

Press /PLAY/STOP to listen to messages.

Options during playback:

Press +VOLUME or -VOLUME to adjust the speaker volume.

Press SKIP to skip to the next message.

Press REPEAT to repeat the message currently playing. Press

REPEAT twice to listen to the previous message.

Press X DELETE to delete the current message. The system advances

to the next message.

Press /PLAY/STOP to stop.

To listen to messages with a handset:

Press MENU/SELECT when in idle mode.

Press MENU/SELECT again to select Play messages. If new

and old messages are saved in the answering system, the

screen displays Play new msgs and Play old msgs. Press

CID or DIR to select and then press MENU/SELECT.

Options during playback:

Press EQ button to adjust the message playback

tone.

Press +VOLUME or -VOLUME to adjust the

speakerphone volume.

Press 6 to skip to the next message.

Press 4 to repeat the message currently playing. Press

4 twice to listen to the previous message.

Press 3 to delete the current message. The system

advances to the next message.

Press 5 to stop.

The system announces the number of messages, then begins

playback. The message sequence is shown on the handset

screen. If there are no recorded messages, the handset

screen shows You have: No message with voice prompt

“You have no message.“

NOTE: If the answering system is off and there is an incoming call, the system answers

after 10 rings and announce to the caller, “Please enter your remote access code.” For

more information about remote access codes, see page 70.

•

You have:

3 New messages

PLAYING MESSAGE

3-Delete 5-Stop

4-Repeat 6-Skip

Msg#[ 2/3 ]

10:00pm 12/25

Play messages

Answering sys

Directory

Call log

Intercom

Play new msgs

Play old msgs

Answering system

Message playback

Delete all old messages

Using the telephone base:

Press X DELETE when the phone is not in use. The telephone announces,

“To delete all old messages, press DELETE again.” Press X DELETE again.

All previously heard messages are erased and the telephone announces, “All

old messages deleted.”

Using a handset:

Press MENU/SELECT on the handset when it is not in use.

Press MENU/SELECT to choose Answering sys.

Press CID or DIR to highlight Delete all old, then press MENU/SELECT.

The handset displays Delete all old messages? Press SELECT to confirm.

Then press MENU/SELECT to confirm.

NOTE: You can only delete old messages, which are messages you have played.

Record and play memos

Memos are your own recorded messages used as reminders for yourself or

others using the same answering system. You can record your own memos

using a system handset. Playback and delete them the same way as incoming

messages.

To record a memo:

Press MENU/SELECT on the handset when it is not in use.

Press MENU/SELECT to choose Answering sys.

Press CID or DIR to highlight Record memo, then press

MENU/SELECT.

The system announces, “

Recorded after the tone. Press

5 when you are done

.” After the tone, speak towards the

microphone.

Press 5 when you finish recording. The handset announces,

“

Recorded

” and then return to the previous menu.

NOTES:

The system announces “Memory is full”, if you record a memo when

the memory is full.

Each memo can be up to four minutes in length.

Memos shorter than one second are not recorded.

To play back a memo

Play memos the same way as messages. See Message playback on page 67.

Play messages

Answering sys

Directory

Call log

Intercom

ANSWERING SYS

Announcement

Delete all old

Record memo

Answer ON/OFF

Recoring

memo...

5-Stop

Answering system

Base message counter displays

Message window displays

0No messages.

0(flashing) You need to set the clock (page 30).

0-6 Show for two seconds while adjusting the telephone

base speaker base

1-99 Total number of old messages and memos, or

message number currently playing during old message

playback.

1-99 (flashing) Total number of messages and memos. The number

flashes when there are new (unreviewed) messages.

After a power failure, the number in the message

counter flashes to indicate that you need to set the

clock.

1-99 & F

(alternating)

Memory is full. You must delete some messages

before recording new messages.

The system is answering a call on the telephone base,

or someone is trying to reach it remotely. The system

is in program mode.

NOTE: When the memory is full, the answering system answers incoming calls after 10

rings and announces, “Memory is full. Enter the remote access code.“

Answering system

Remote access

You can access the answering system remotely by dialing your home

telephone number from any touch-tone telephone.

To remotely access the answering system

Dial your telephone number from any touch-tone telephone.

When the system plays your announcement, enter the two-digit remote

access code (19 is the default code, see page 37 to change it).

You can also enter the remote commands (see Remote commands on this

page).

Hang up to end the call and save all undeleted messages.

Remote commands

NOTES:

If you do not press any keys after you enter the remote access code, all new messages

play. If there are no new messages, all old messages play.

Once the new messages have played, the telephone announces the help menu options.

If you do not press any key within 20 seconds, the remote access call automatically

disconnects.

When the answering system is turned off, the telephone answers after 10 rings, and

announces,

“

Please enter your remote access code.”

When the memory is full, the answering system answers incoming calls after 10 rings and

announces,

“

Memory is full. Enter the remote access code.”

•

1Press to listen to all messages.

2Press to listen to new messages only.

3Press to delete the current message (during playback).

33 Press twice to delete all old messages.

4Press to repeat the current message (during playback).

44 Press twice to listen to the previous message.

5Press to stop any operation (including recording).

*5 Press to listen to a list of remote commands.

6Press to skip to the next message (during playback).

*7 Press to record a new announcement.

8Press to end remote access (the call is terminated).

0Press to turn the answering system on or off.

Appendix

Handset screen icons

HOME - On steadily when the home line

is in use or there is an incoming home

call.

CELL line- On steadily when the cell line

is in use or there is an incoming cell call.

1 2 Bluetooth connected device(s) - There

are Bluetooth connected devices on the

active devices list.

12 Bluetooth disconnected device(s)

- There are Bluetooth disconnected

devices on the active devices list.

Wireless Bluetooth headset - On

steadily when a wireless Bluetooth

headset is in use on the home line.

(flashing)

Battery status - Battery Low battery;

place handset in telephone base or

charger to recharge.

Battery status - Battery is charging.

Speakerphone - The speakerphone is in

use.

Ringer off - The handset ringer is turned

off.

New voicemail - New voicemail received

from the local telephone company.

ANS

Answering system on - Answering

system is turned on.

New answering system message - New

message in the answering system.

NEW New call log - Missed and unreviewed

calls.

MUTE Mute - Microphone is muted.

Msg#[10/16] Message counter - number of messages

playing.

CHRISTINE SMITH

888-722-7702

3:45am 12/25

12 ANS

Appendix

Handset alert tones

Two short beeps You are pressing DIR or CID when the volume is already at

its highest or lowest setting.

-OR-

You have reached the end of the caller ID history.

Three short beeps Out of range while the handset is on a call.

Three short high-pitched beeps The telephone has completed the command successfully.

Four short beeps Low battery warning.

Telephone base alert tones

Beeps every 10 seconds Message alert.

Alert tones and lights

Handset indicator lights

Telephone base indicator lights

CHARGE light

On when the handset is charging in the telephone base or

charger.

Backlight (lighted display and dial pad)

On when the handset is lifted from the telephone base or

charger.

On when a key is pressed.

SPEAKER light

On when the speakerphone is in use.

IN USE light

On when the handset is in use or when the

answering system is answering an incoming call.

Flashes when another telephone on the same

line is in use.

Flashes quickly when there is an incoming call.

ANSWER ON light

On when the answering system is on.

Appendix

Display screen messages

Already saved The telephone number you have entered is already stored in

the directory.

Bluetooth system You are trying to make a cell call or access Bluetooth menu

when the Bluetooth link is already being used.

Call log empty You are accessing an empty caller ID history.

Call transfered An outside call from one handset is transferred to another

handset.

Calling HANDSET X

(For TL92370 or models with

more than two handsets)

The handset is calling another handset (for intercom calls).

Calling other handset

(For TL92200 only)

The handset is calling the other handset (for intercom calls).

The handset is going to transfer an outside call to the other

handset.

Cell The cell line is in use.

Cell call on hold A call on the cell line has benn put on hold.

Cell line in use A system handset on the cell line is in use.

Connecting... The handset has lost communication with the telephone

base.

Directory empty There are no directory entries.

Downloading dir The system is downloading the directory from the cell phone.

Ended You have just ended a call.

HANDSET X is calling

(For TL92300 or models with

more than two handsets)

Another system handset is calling.

Home The home line is in use.

Home call on hold A call on the home line has been put on hold.

Home & cell

calls on hold

Calls on the home and cell lines have been put on hold.

Home & cell

lines in use

Calls on the home and cell lines are being used.

Home line in use A system handset or another telephone on the same home

line is in use.

Incoming call There is a call coming in.

Intercom The handset is on an intercom call.

Screen messages

Appendix

Screen messages

Intercom ended The intercom call has just ended.

Intercom to:

(For TL92300 or models with

more than two handsets)

You have started the intercom process, and need to enter

the number of the handset you wish to call.

List full The directory is full. You cannot save any new entries unless

you delete some current entries.

Low battery The battery needs to be charged.

Microphone off The handset microphone is off. The other party cannot hear

you but you can hear the other party.

Microphone on The handset microphone is on.

New voicemail There are new voicemail message(s) from your telephone

service provider.

No battery The battery is not probably installed, but the handset is

placed in the telephone base or charger.

No entries found. Try

downloading from SIM

only

There are no entries found when you download a cell phone

directory from the cell memory.

No entries found.

Try downloading from

Phone only

There are no entries found when you download a cell phone

directory from your SIM card.

There are no entries found in either the cell or SIM card

when you download a cell phone directory from both

memory.

No connected cellular

phones

There is no telephone line connected.

No home line There is no telephone line connected.

No messages There

No signal, call ended

Not availableat this

time

Someone else is already using the directory or caller ID

history.

Other handset

is calling

(For TL92200 only)

The other handset is calling.

Out of range

No power at

base

The handset has lost communication with the telephone

base.

There is no power connected to the telephone base.

** Paging ** The telephone base is paging all handsets.

Phone The handset is in use.

Appendix

Place

in charger

The battery is very low. The handset should be placed in the

telephone base or charger.

Rec mem full The answering system has no recording time left.

Ringer mute The ringer is muted temporarily during an incoming call.

Saved The entry in caller ID history is now in the directory.

Intercom tO:

(For TL92300)

You have started transferring a call, and need to enter the

desired handset number.

Unable to call

try again

Failed intercom or conference call (there are already two

handsets being used).

Unable to

complete call.

Check cellular.

You are trying to make a cell call when the cell line is

already being used.

Unable to save You are trying to save an entry with no name and number

from the caller ID history.

XX Missed call(s) There are new calls in the caller ID history.

XX New message(s) There are new messages recorded in the answering system.

Screen messages

Appendix

Expand your telephone system

The handsets provided with your telephone system are pre-registered.

Additional handsets registered to the telephone system are assigned

in sequential order. For instance, if you already have HANDSET 1 and

HANDSET 2, the new registered handset is assigned HANDSET 3. This

telephone system accommodates up to 12 handsets.

Add and register a handset (optional)

You can add new handsets (TL90070, purchased separately) to your

telephone system, but each handset must be registered with the telephone

base before use. When first purchased, each expansion handset shows

Press and hold

HANDSET LOCATOR

on base for 4 sec, then press # on

handset after a battery is installed. You may need to charge the handset

before registering to the telephone base. For more details on battery

charging, see the table on page 8.

To register a handset:

Press and hold HANDSET LOCATOR on the telephone base for about

four seconds until the red IN USE light turns on.

Press # on the handset. Its screen shows Registering...Please wait and it

takes up to 60 seconds to complete the registration. The handset shows

HANDSET X Registered (X represents the handset number assigned) and

you hear a beep when the registration is completed.

NOTES:

If the registration fails, the handset shows Registration failed for a few seconds and

then

Press and hold

HANDSET LOCATOR

on base for 4 sec, then press # on

handset.

Try the registration process again.

You cannot register a handset if any other system handset is in use.

Appendix

Replace a handset

If you want to replace a handset or re-assign the designated handset number

of a registered handset, you must deregister all the handsets and then

individually register each handset.

To make deregistration easier, read all of the instructions on this page before

you begin.

To deregister all handsets

Press and hold HANDSET LOCATOR on the telephone base for about 10

seconds until the IN USE light flashes, then release HANDSET LOCATOR.

Press HANDSET LOCATOR again. You must press HANDSET LOCATOR

while the IN USE light is still flashing. The IN USE light flashes for about

seven seconds.

All system handsets show Out of range OR No power at base for a few

seconds and then

Press and hold

HANDSET LOCATOR

on base for 4

sec, then press # on handset

when the deregistration is completed. The

deregistration process takes about 10 seconds to complete.

If deregistration fails, you may need to reset the telephone and try again.

To reset:

Press and hold OFF/CLEAR or place the handset back in the telephone

base.

-OR-

Unplug the power from the telephone base, then plug it back in.

After deregistering, register each handset individually. See Add and register

a handset on page 76.

•

Appendix

Troubleshooting

If you have difficulty with your telephone, please try the suggestions below.

For Customer Service, or to purchase accessories or replacement parts, visit

our website at www.telephones.att.com, or call 1 (800) 222-3111.

In Canada, dial 1 (866) 288-4268. Have the serial number, found on the

underside of your telephone, available when contacting customer service.

Please retain your receipt as your proof of purchase.

My phone doesn’t work at all.

Make sure the power cord is securely plugged in.

Make sure that the battery connector is securely plugged into the cordless

handset.

Make sure the telephone line cord is securely and firmly plugged into the

telephone base and the telephone wall jack.

Charge the battery in the cordless handset for at least 16 hours. For

optimum daily performance, return the cordless handset to the telephone

base or charger when not in use.

If the battery is depleted, it may take approximately ten minutes to charge

the handset before it shows Low battery, refer to page 8 for details.

Reset the telephone base. Unplug the electrical power. Wait for

approximately 15 seconds, then plug it back in. Allow up to one minute

for the cordless handset and telephone base to reset.

You may need to purchase a new battery. Please refer to Battery

installation & charging (pages 8-9) in this user’s manual.

•

I cannot get a dial tone.

First try all the suggestions above.

Move the cordless handset closer to the telephone base. You might have

moved out of range.

If the previous suggestions don’t work, disconnect the telephone base

from the telephone jack and connect to a different phone. If there is

no dial tone on that phone either, the problem is in your wiring or local

service. Contact your local telephone company.

Your line cord might be malfunctioning. Try installing a new line cord.

•

Appendix

Troubleshooting

I cannot dial out.

First try all the suggestions in I cannot get a dial tone, on the previous

page.

Make sure you have a dial tone before dialing. The cordless handset may

take a second or two to find the telephone base and produce a dial tone.

This is normal. Wait an extra second before dialing.

Eliminate any background noise. Noise from a television, radio or other

appliances may cause the phone to not dial out properly. If you cannot

eliminate the background noise, first try muting the cordless handset

before dialing, or dialing from another room in your home with less

background noise.

If the other phones in your home are having the same problem, the

problem is in your wiring or local service. Contact your local telephone

company (charges may apply).

•

My cordless handset isn’t performing normally.

Make sure the power cord is securely plugged into the telephone base.

Plug the power adapter into a different, working electrical outlet not

controlled by a wall switch.

Move the cordless handset closer to the telephone base. You might have

moved out of range.

Reset the telephone base. Unplug the electrical power. Wait for 15

seconds then plug it back in. Allow up to one minute for the cordless

handset and telephone base to reset.

Other electronic products can cause interference to your cordless phone.

Try installing your phone as far away from these types of electronic

devices as possible: television sets, VCRs, or other cordless telephones.

•

Out of range OR No power at base appears on my cordless handset.

Ensure that the telephone base is powered up.

Place the cordless handset in the telephone base for one minute to allow

the cordless handset and base to resynchronize.

Move the cordless handset closer to the telephone base. You might have

moved out of range.

Reset the telephone base. Unplug the electrical power. Wait for 15

seconds then plug it back in. Allow up to one minute for the cordless

handset and telephone base to reset.

Other electronic products can cause interference with your cordless

phone. Try installing your phone as far away from these types of

electronic devices as possible: television sets, VCRs, or other cordless

telephones.

•

Appendix

Troubleshooting

The batteries do not hold a charge.

If the cordless handset is in the telephone base or charger and the charge

light does not come on, refer to The charge light is off (page 83) in this

Troubleshooting guide.

Charge the battery in the cordless handset for at least 16 hours. For

optimum daily performance, return the cordless handset to the telephone

base or charger when not in use.

If the battery is depleted, it may take approximately ten minutes to charge

the handset before it shows Low battery, refer to page 8 for details.

You may need to purchase a new battery. Please refer to Battery

installation & charging (pages 8-9) in this user’s manual.

•

I get noise, static, or weak signals even when I’m near the telephone base.

If you subscribe to high-speed Internet service (digital subscriber line

- DSL) through your telephone lines, you must install a DSL filter between

the telephone base and the telephone wall jack (see page 6). The filter

prevents noise and caller ID problems caused by DSL interference. Please

contact your DSL service provider for more information about DSL filters.

You may be able to improve the performance of your cordless phone

by installing your new telephone base as far as possible from any other

existing cordless telephone system that may already be installed.

Other electronic products can cause interference to your cordless phone.

Try installing your phone as far away from the following electronic devices

as possible: television sets, VCRs, or other cordless telephones.

Do not install this phone near a microwave oven or on the same electrical

outlet. You may experience decreased performance while the microwave

oven is operating.

If your phone is plugged in with a modem or a surge protector, plug the

phone (or modem/surge protector) into a different location. If this doesn’t

solve the problem, re-locate your phone or modem farther apart from one

another, or use a different surge protector.

Relocate your phone to a higher location. The phone will likely have

better reception when installed in a high area.

If the other phones in your home are having the same problem, the

problem is in your wiring or local service. Contact your local telephone

company (charges may apply).

•

Appendix

Troubleshooting

I experience poor sound quality when using the speakerphone.

For increased sound quality while using the speakerphone, place the

handset on a flat surface with the dial pad facing up.

When using a speakerphone, controlling background noise in your

environment is essential. While you are listening to your party, press

DELETE/MUTE to temporarily turn your microphone off. When it is

your turn to speak, remember to press DELETE/MUTE again to turn the

microphone on.

Excessive background noise will cause a speakerphone to fade in and out.

Try controlling the background noise by turning off any audio devices near

the speakerphone. Also, try to avoid interrupting the person at the other

end of the conversation while they are speaking. If background noise

cannot be controlled, you should terminate speakerphone operation and

return to normal handset mode.

•

I hear other calls while using my phone.

Disconnect the telephone base from the telephone jack, and plug in a

different telephone. If you still hear other calls, the problem is probably in

your wiring or local service. Call your local telephone company.

•

Appendix

Troubleshooting

My cordless handset does not ring when I receive a call.

Make sure that the ringer is not turned off. Refer to Ringer volume on

page 27 in this user’s manual.

Make sure the telephone line cord is plugged securely into the telephone

base and the telephone jack. Make sure the power cord is securely

plugged in.

The cordless handset may be too far from the telephone base.

Charge the battery in the cordless handset for at least 16 hours. For

optimum daily performance, return the cordless handset to the telephone

base or charger when not in use.

You may have too many extension phones on your telephone line to allow

all of them to ring simultaneously. Try unplugging some of the other

phones.

The layout of your home or office might be limiting the operating range.

Try moving the telephone base to another location, preferably on an

upper floor.

If the other phones in your home are having the same problem, the

problem is in your wiring or local service. Contact your local telephone

company (charges may apply).

Test a working phone at the phone jack. If another phone has the same

problem, the problem is the phone jack. Contact your local telephone

company (charges may apply).

Other electronic products can cause interference with your cordless

phone. Try installing your phone as far away as possible from electronic

devices such as wireless routers, or other cordless telephones.

Re-install the battery, and place the cordless handset in the telephone

base. Wait for the cordless handset to re-establish its connection with the

telephone base. Allow up to one minute for this to take place.

Your line cord might be malfunctioning. Try installing a new line cord.

•

Appendix

My calls cut in and out while I’m using my cordless handset.

Other electronic products can cause interference with your cordless

phone. Try installing your phone as far away as possible from electronic

devices such as wireless routers, or other cordless telephones.

Do not install this phone near a microwave oven or on the same electrical

outlet. You may experience decreased performance while the microwave

oven is operating.

If you plug your phone in with a modem or surge protector, plug the

phone (or modem/surge protector) into a different location. If this doesn’t

solve the problem, re-locate your phone or modem farther apart from one

another, or use a different surge protector.

Relocate your telephone base to a higher location. The phone will have

better reception when installed in a high area.

If the other phones in your home are having the same problem, the

problem is in your wiring or local service. Contact your local telephone

company (charges may apply).

Excessive background noise will cause a speakerphone to fade in and out.

Try controlling the background noise by turning off any audio devices near

the speakerphone. Also, try to avoid interrupting the person at the other

end of the conversation while they are speaking. If background noise

cannot be controlled, you should stop speakerphone operation and return

to normal handset mode.

When using a speakerphone, controlling background noise in your

environment is essential. While you are listening to your party press

DELETE/MUTE to temporarily turn your microphone off. When it is your

turn to speak, remember to press DELETE/MUTE to turn the microphone

on.

•

The charge light is off.

Make sure the power and line cords are plugged in correctly and securely.

Unplug the electrical power. Wait for 15 seconds, then plug it back in.

Allow up to one minute for the cordless handset and telephone base to

reset.

Clean the cordless handset and telephone base charging contacts each

month using a pencil eraser or cloth.

•

Troubleshooting

Appendix

My caller ID isn’t working.

Caller ID is a subscription service. You must subscribe to this service from

your telephone service provider for this feature to work on your phone.

The caller must be calling from an area that supports caller ID.

Both you and your caller’s telephone service providers must use caller ID

compatible equipment.

If you subscribe to high-speed Internet service (digital subscriber line

- DSL) through your telephone lines, you must install a DSL filter between

the telephone base and the telephone wall jack (see page 6). The filter

prevents noise and caller ID problems caused by DSL interference. Please

contact your DSL service provider for more information about DSL filters.

•

System does not receive caller ID when on a call.

Make sure you subscribe to caller ID with call waiting features provided

by your local telephone company. Caller ID features work only if both you

and the caller are in areas offering caller ID service, and if both telephone

companies use compatible equipment.

•

A icon shows on the display and I don’t know why.

Your telephone has voicemail indication that is separate from the built-in

answering system. If appears on the display, then your telephone has

received a signal from your telephone service provider that you have a

voicemail message waiting for you to retrieve from your telephone service

provider. Contact your telephone service provider for more information on

how to access your voicemail.

•

I cannot retrieve voicemail messages.

Your telephone has both a built-in answering system and voicemail

indication. They are independent features and each alerts you to new

messages differently (page 65). If you subscribe to voicemail service

from your telephone service provider (charges may apply), contact your

telephone service provider for more information on how to access your

voicemail.

•

Incomplete messages.

If a caller leaves a very long message, part of it may be lost when the

system disconnects the call after four minutes.

If the caller pauses for longer than seven seconds, the system stops

recording and disconnects the call.

If the system’s memory becomes full during a message, the system stops

recording and disconnects the call.

If the caller’s voice is very soft, the system may stop recording and

disconnects the call.

•

Troubleshooting

Appendix

Difficulty hearing messages.

Press +VOLUME to increase speaker volume on the telephone base.

Press +VOLUME to increase the listening volume on a handset.

•

System does not answer after correct number of rings.

Make sure the answering system is on. When the answering system is on,

ANS ON should show on the handset and the ANSWER ON light is lit

on the telephone base (page 33).

If toll saver is selected, the number of rings changes to two when there

are new messages waiting (page 36).

If the memory is full or the system is off, the system answers after 10

rings.

In some cases, the answering system is affected by the ringing system

used by the local telephone company.

If you subscribe to voicemail service, change the number of rings so that

your answering system answers before your voicemail answers (page 65).

To determine how many rings will activate your voicemail, please contact

your local telephone service provider.

If there is a fax machine connected to the same telephone line, try

disconnecting the fax machine. If that solves the problem, consult

your fax machine documentation for information on compatibility with

answering systems.

•

System announces “Time and day not set.”

You need to reset the answering system clock (page 30).•

System does not respond to remote commands.

Make sure to enter your remote access code correctly (page 70).

Make sure you are calling from a touch-tone phone. When you dial a

number, you should hear tones. If you hear clicks, the phone is not a

touch-tone telephone and cannot activate the answering system.

The answering system may not detect the remote access code while your

announcement is playing. Try waiting until the announcement is over

before entering the code.

There may be interference on the phone line you are using. Press dial pad

keys firmly.

•

Troubleshooting

Appendix

Troubleshooting

System does not record messages.

Make sure the answering system is on (page 33).

Make sure the memory of the answering system is not full. When the

answering machine memory is full, it does not record new messages until

some old messages are deleted.

If you subscribe to voicemail service, change the number of rings so that

your answering system answers before your voicemail answers (page 65).

To determine how many rings will activate your voicemail, please contact

your local telephone service provider.

If there is a fax machine connected to the same telephone line, try

disconnecting the fax machine. If that solves the problem, consult

your fax machine documentation for information on compatibility with

answering systems.

•

Outgoing announcement is not clear.

When you record your announcement, make sure you speak in a normal

tone of voice, about nine inches from the telephone base.

Make sure there is no background noise (TV, music, etc.) while recording.

•

Common cure for electronic equipment:

If the telephone is not responding normally, try resetting the telephone. Do

the following in the order listed:

Disconnect the power to the telephone base.

Disconnect the cordless handset battery, and spare battery, if applicable.

Wait a few minutes.

Connect power to the telephone base.

Re-install the battery, and place the cordless handset into the telephone

base.

Wait for the cordless handset to re-establish its connection with the

telephone base. Allow up to one minute for this to take place.

Appendix

Maintenance

Taking care of your telephone

Your cordless telephone contains sophisticated electronic parts, so it must

be treated with care.

Avoid rough treatment.

Place the handset down gently.

Save the original packing materials to protect your telephone if you ever

need to ship it.

Avoid water

Your telephone can be damaged if it gets wet. Do not use the handset in

the rain, or handle it with wet hands. Do not install the telephone base

near a sink, bathtub or shower.

Electrical storms

Electrical storms can sometimes cause power surges harmful to electronic

equipment. For your own safety, take caution when using electric

appliances during storms.

Cleaning your telephone

Your telephone has a durable plastic casing that should retain its luster for

many years. Clean it only with a soft cloth slightly dampened with water

or a mild soap.

Do not use excess water or cleaning solvents of any kind.

•

Remember that electrical appliances can cause serious injury if used when you are wet or

standing in water. If the telephone base should fall into water, DO NOT RETRIEVE IT UNTIL YOU

UNPLUG THE POWER CORD AND TELEPHONE LINE CORDS FROM THE WALL. Then pull the

telephone out by the unplugged cords.

Appendix

Important safety information

This symbol is to alert you to important operating or servicing instructions that may appear

in this user’s manual. Always follow basic safety precautions when using this product to reduce

the risk of injury, fire, or electric shock.

Safety information

Read and understand all instructions in the user’s manual. Observe all markings on the

product.

Avoid using a telephone during a thunderstorm. There might be a slight chance of electric

shock from lightning.

Do not use a telephone in the vicinity of a gas leak. If you suspect a gas leak, report it

immediately, but use a telephone away from the area where gas is leaking. If this product is a

cordless model, make sure the base is also away from the area.

Do not use this product near water, or when you are wet. For example, do not use it in a

wet basement or shower, or next to a swimming pool, bathtub, kitchen sink, or laundry tub.

Do not use liquids or aerosol sprays for cleaning. If the product comes in contact with any

liquids, unplug any line or power cord immediately. Do not plug the product back in until it

has dried thoroughly.

Install this product in a protected location where no one can trip over any line or power

cords. Protect cords from damage or abrasion.

If this product does not operate normally, read Troubleshooting section on pages 75-86

of this user’s manual. If you cannot solve the problem, or if the product is damaged, refer

to Limited warranty section on pages 92-93. Do not open this product except as may be

directed in your user’s manual. Opening the product or reassembling it incorrectly may

expose you to hazardous voltages or other risks.

Replace batteries only as described in your user’s manual (pages 8-9). Do not burn or

puncture batteries — they contain caustic chemicals.

This power adapter is intended to be correctly oriented in a vertical or floor mount position.

The prongs are not designed to hold the plug in place if it is plugged into a ceiling or an

under-thetable/cabinet outlet.

CAUTION: Use only the power adapter provided with this product. To obtain a replacement,

visit our website at www.telephones.att.com, or call 1 (800) 222–3111.

In Canada, dial 1 (866) 288-4268.

Especially about corded telephones

Privacy: The same features that make a cordless telephone convenient create some

limitations. Telephone calls are transmitted between the telephone base and the handset

by radio waves, so there is a possibility that your cordless telephone conversations could

be intercepted by radio receiving equipment within range of the cordless handset. For this

reason, you should not think of cordless telephone conversations as being as private as those

on corded telephones.

Electrical power: The telephone base of this cordless telephone must be connected to a

working electrical outlet which is not controlled by a wall switch. Calls cannot be made from

the handset if the telephone base is unplugged, switched off or if the electrical power is

interrupted.

•

Appendix

Important safety information

Potential TV interference: Some cordless telephones operate at frequencies that may cause

interference to TVs and VCRs. To minimize or prevent such interference, do not place the

telephone base of the cordless telephone near or on top of a TV or VCR. If interference

is experienced, moving the cordless telephone farther away from the TV or VCR will often

reduce or eliminate the interference.

Rechargeable batteries: This product contains nickel-metal hydride rechargeable batteries.

Exercise care in handling batteries in order not to create a short circuit with conductive

material such as rings, bracelets, and keys. The battery or conductor may overheat and cause

harm. Observe proper polarity between the battery and the battery charger.

Nickel-metal hydride rechargeable batteries: Dispose of these batteries in a safe manner. Do

not burn or puncture. Like other batteries of this type, if burned or punctured, they could

release caustic material which could cause injury.

The RBRC™ Seal means that the manufacturer is voluntarily participating in

an industry program to collect and recycle nickel-metal hydride rechargeable

batteries when taken out of service within the United States. These batteries

may be taken to a participating local retailer of replacement batteries or

recycling center. Or you may call 1 (800) 8-BATTERY for locations accepting

spent Ni-MH batteries.

Precautions for users of implanted cardiac pacemakers

Cardiac pacemakers (applies only to digital cordless telephones): Wireless Technology Research,

LLC (WTR), an independent research entity, led a multidisciplinary evaluation of the interference

between portable wireless telephones and implanted cardiac pacemakers. Supported by the U.S.

Food and Drug Administration, WTR recommends to physicians that:

Pacemaker patients

Should keep wireless telephones at least six inches from the pacemaker.

Should NOT place wireless telephones directly over the pacemaker, such as in a breast

pocket, when it is turned ON.

Should use the wireless telephone at the ear opposite the pacemaker.

WTR’s evaluation did not identify any risk to bystanders with pacemakers from other persons

using wireless telephones.

Especially about telephone answering systems

Two-way recording: This unit does not sound warning beeps to inform the other party that the

call is being recorded. To ensure that you are in compliance with any federal or state regulations

regarding recording a telephone call, you should start the recording process and then inform the

other party that you are recording the conversation.
