NURIT 8000 User Manual
LIPMAN USA, INC.
Instruction Guide Series
NURIT 8000
User Manual
INSTRUCTION GUIDE SERIES
NURIT 8000 User
Manual
Lipman USA Inc.
50 Gordon Drive
Syosset, New York, USA 11719
Phone 516.484.9898 • Fax 516.484.9057
WARNING
Changes or modifications to this unit not expressly approved by
the party responsible for compliance could void the user's
authority to operate the equipment.
FCC compliance statement
This equipment has been tested to be found to comply with the limits
for class A digital
device, pursuant to Part 15 of the FCC Rules. Operation is subject to the following
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that m
ay cause undesired operation.
Class A limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio frequency energy
and, if not installed and used in ac
cordance with the instructions, may cause interference to
radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception
, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
•
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult your dealer or an experienced technician for help.
FCC requirements
The Federal Communications Commission (FCC) has establish
ed rules permitting this
device to be directly connected to the telephone network. Standardized jacks are used for
these connections. This equipment should not be used on party or coin lines.
If this devise is malfunctioning, it may be causing harm to the
telephone network; this devise
should be disconnected until the source of the problem can be determined and until repair
has been made. If this is not done, the telephone company may temporarily disconnect
service.
The telephone company may make changes in
its technical operations and procedures; if
such changes affect the compatibility or use of this devise, the telephone company is
required to give adequate notice of the changes. You will be advised to file a complaint with
the FCC.
If the telephone compa
ny requests information on what equipment is connected to their
lines, inform them of:
One.The telephone number this unit is connected to
Two.The ringer equivalence number: 0.3B
iiii
Three.The USOC jack required: RJ-11C
Four.The FCC Registration number: 3D7ISR-25066-DT-E
The Ring
er Equivalence Number (REN) is used to determine how many devices can be
connected to your telephone line. In most areas, the sum of the RENs of all devices on any
one line should not exceed five (5). If too many devices are attached, they may not ring
properly.
For a product that has the potential to be used in a body worn configuration and has not
been certified with a specific accessory device(s):
"For body worn operation, this device has been tested and meets FCC RF exposure
guidelines when used with
an accessory that contains no metal and that positions the device
a minimum of 1.5cm from the body. Use of other accessories may not ensure compliance
with FCC RF exposure guidelines."
11
Chapter
1
CHAPTER
1
OPERATION
OPERATIONAL OVERVIEW
This chapter explains the various instructions required in operating the NURIT
8000
POS
/EDC Terminal. The terminal keyboard allows for selecting specific transaction
types, entering of data, and performing various functions. In this manual, transactions,
operations, and specific functions available with the NURIT 8000 is explained.
Setting Time and Date
If the time and date need to be adjusted in the NURIT 8000, it can be changed
manually. Please refer to page 39 for the correct procedure.
Performing a Sale
To perform a credit card sale:
1. At the CREDIT.....SALE, ACCOUNT ?
prompt, swipe the credit
card, or manually key in the account number and expiration date.
2.
The terminal will prompt to enter in the amount (DO NOT PRESS THE
DECIMAL POINT).
3. The terminal will then
dial, process, give an approval code, and print a
receipt that reads SALE on top.
Credit Return
A refund to a customer’s credit card account can be done if the original sale is from a
different batch (if the sale and refund are in the same batch refer to page 3 -
Voids ),
otherwise, a refund is done as follows:
1. At CREDIT.....SALE, ACCOUNT? press the <éé > or <êê >
keys repeatedly until the terminal reads
:
CREDIT......RETURN, ACCOUNT ?
2. Swipe the card, or key in the account number manually.
3. Key in the amount to be refunded, and press <ENTER>.
4.
Terminal will then prompt you to enter an authorization
number. Key in the six digit approval code on the
original
sale receipt, and press <ENTER>.
5. The terminal will print a receipt that reads RETURN
on
top.
Verify
This function is used to ensure that a customer has adequate funds on their
credit card (THIS DOES NOT CHARGE THE CUSTOMER’S
ACCOUNT).
1. At CREDIT.....SALE, ACCOUNT? press the <éé > or <êê >
keys repeatedly until the terminal reads:
CREDIT...VERIFY,
ACCOUNT ?
2.
Swipe the credit card, or key in the account number and
expiration date manually.
3. Type in the amount to be verified, and press <ENTER>.
4. The terminal will dial and process the transaction.
5. A receipt will print, and read VERIFIED on top.
NOTE: The author
ization number given during the verification can be
used for a Forced Sale. There is no need to call for a second
authorization.
Forced Transaction
When voice authorization has been obtained on a customer’s credit card, a
Forced Sale should be done to process the transaction.
1. At CREDIT.....SALE, ACCOUNT? press the <éé > or <êê >
keys repeatedly until the terminal reads:
CREDIT.....
FORCED, ACCOUNT ?
2.
Swipe the card, or key in the account number and expiration
date manually.
3. Enter in the amount that has al
ready been authorized and press
<ENTER>.
4.
The terminal will then prompt to enter the authorization
number that was obtained through voice authorization.
5.
The terminal will then display, “APPROVED.” A receipt will
print and read TICKET ONLY on top.
NOTE: S
ince an authorization has already been obtained, there is no
need for the terminal to dial out for a second approval. This is also
dependent on the host protocols. However, the customer does have to
sign the receipt.
VOIDS
Void a Credit Sale
A void of a cr
edit card sale can be done, if the original sale was performed in
the same batch. To void a transaction:
1. At CREDIT.....SALE, ACCOUNT? press the <éé > or <êê >
keys repeatedly until the terminal reads:
CREDIT....VOID/SALE, ACCOUNT ?
2. Swipe the credit card or
key in the account number and
expiration date manually.
3.
Enter in the amount of the SALE to be voided, and press
<ENTER>.
Depending on how your terminal has been
programmed, the terminal may, or may not dial for an approval.
Void a Return
A Void Refund is done, if the original return is from the same batch. If the
refund is from a different batch, you will not be able to perform a void
return, (check with your processing bank for instructions on handling the
transaction), otherwise, a void refund is done as follows:
1. At CREDIT.....SALE, ACCOUNT? press the <éé > or <êê >
keys repeatedly until the terminal reads:
CREDIT....VOID/
RTRN, ACCOUNT ?
2.
Swipe the credit card or key in the account number and
expiration date manually.
3. Enter in the amount of the RETURN
to be voided, and press
<ENTER>.
4.
The terminal will display “APPROVED” and print a
receipt. Depending on how your terminal has been
programmed, the terminal may or may not dial for an
approval.
Void a Forced Sale
A void of a credit forced sale is done if the original forced sale was
performed in the same batch. (If the forced sale is from a different batch
refer to page 1 - RETURN ), otherwise, a Void Forced Sale is done as
follows:
1. At CREDIT.....SALE, ACCOUNT? press the <éé > or <êê >
keys repeatedly un
til the terminal reads:
CREDIT.....VOID/FRCD, ACCOUNT ?
2.
Swipe credit card or key in account number and expiration
date manually.
3.
Enter in amount of FORCED SALE to be voided and press
<ENTER>.
4.
Terminal will display “APPROVED” and print a receipt.
Dependi
ng on how your terminal has been programmed, the
terminal may or may not dial in for an approval. Void Forced is
used only to void a transaction with “TICKET ONLY” printed on
top of the original receipt.
OR
Follow the steps in Chapter 2, on page 55 to v
oid by transaction
number.
DEBIT TRANSACTIONS
A debit transaction can only be done using a bank issued debit card, and
there must be a PIN pad connected to the terminal.
Debit Sale
Follow these steps to process a debit card:
1. At CREDIT.....SALE, ACCOUNT ?, press <ENTER>
, until
your terminal displays: DEBIT...SALE, ACCOUNT ?
2. Swipe the debit card (debit account numbers can NOT
be
keyed in manually). It must be swiped.
3. Key in the amount of the sale, and press <ENTER>.
4. The terminal will prompt to enter in a CASH BACK
amount. If the customer does not want to get cash back,
press <ENTER> to bypass this option.
5. The terminal will display:
PLEASE ENTER PIN ON THE
PIN PAD>>.
PIN pad will beep and prompt the customer to
enter PIN number on the pad.
6. The terminal will dial, process, and print receipt.
Debit Return
Please keep in mind, that this transaction is host specific. Therefore, this transaction
may not be available.
1. At CREDIT.....SALE, ACCOUNT ?, press <ENTER>
,
until your terminal displays: DEBIT...SALE,
ACCOUNT ?
2. Press the <éé > or <êê >
keys repeatedly until the terminal
reads: DEBIT….RETURN, ACCOUNT.
3. Swipe the debit card (debit account numbers can NOT
be
keyed in manually). It must be swiped.
4. Key in the amount of the return, and press <ENTER>.
5. The te
rminal will then prompt to enter the authorization
from the original sale receipt. Key in six digit code and
press <ENTER>.
6. The terminal will display:
PLEASE ENTER PIN ON THE
PIN PAD>.
PIN Pad will beep and prompt the customer
to enter the PIN number on the pad.
7.
The terminal will dial, process, and print receipt reading
RETURN at the top.
Debit Forced Sale, Void Sale/Return/Forced, and Verify
These transaction types are not available with most host processors.
CHECK TRANSACTIONS
To perform a check transaction, follow these steps:
1. At CREDIT.....SALE, ACCOUNT ?, press <ENTER>
until
the terminal displays: CHECK... VERIFY, AMOUNT ?
2. Enter the amount of the check, and press <ENTER>.
3.
Enter the MICR number (this number is usually the account
number on the
bottom of the check), or feed check through
a check reader. The terminal will prompt different
information depending on the check host.
4. Press <ENTER>. Terminal will print receipt.
ELECTRONIC BENEFITS TRANSFER (EBT)
A special EBT card must be used to perform a sale or receive cash. Follow
these steps to process an EBT card:
1. At CREDIT.....SALE, ACCOUNT ?, press
<ENTER>
until your terminal displays: EBT ...SALE, ACCOUNT?
2.
Swipe the EBT card, or manually enter the account
number including the expiration
date, or if required, the
‘GEN’ number.
3. Terminal will display:
1. FOODSTAMP
2. CASH BENEFIT
4.
Make selection by pressing correct numbered key.
Terminal will display: EBT…..SALE, AMOUNT 0.00
5. Enter in the amount of the sale and press <ENTER>.
6. If option 2, CASH BENEFIT
was selected, terminal will
prompt to enter in a cash back amount. If the customer
does not want to receive cash back, press <ENTER>
to
bypass this option.
7. The terminal will display:
PLEASE ENTER PIN ON PIN
PAD, and PIN pad will beep to prompt
the customer to
enter the PIN number on the pad.
8. The terminal will dial, process, and print out a receipt.
CASH TRANSACTIONS
The Cash EDC mode must be turned on, to perform cash transactions.
Refer to Chapter 2, page 30.
To perform a Cash Sale:
1. At CREDIT.....SALE, ACCOUNT ?, press
<ENTER>
until your terminal displays: CASH ...SALE, AMOUNT?
2. Key in the amount of the sale and press <ENTER>
.
Terminal will print receipt.
To perform a Cash Return:
1. At CREDIT.....SALE, ACCOUNT ?, press
<ENTER>
until your terminal displays: CASH ...SALE, AMOUNT?
8. Press the <éé > or <êê >
keys repeatedly until the terminal
reads: CASH….RETURN, AMOUNT.
2.
Key in the amount of the return. Terminal will print a
receipt.
NOTE: Transaction types Void Sale, Void Return, Void Forced,
Forced, and Verify are not applicable with Cash EDC.
Phone Card Activation
To Activate a Phone Card:
1. At CREDIT.....SALE, ACCOUNT ?, press
<ENTER>
until your terminal displays:
PHONE CARD, SWIPE
CARD?
2. Swipe Phone Card to be activated.
3. Key in amount of activation and press <ENTER>.
4. Key in Clerk Number and press <ENTER>.
5.
Confirm correct amount for activation and press
<ENTER>.
6.
Terminal will dial, and print receipt with confirmation of
activation.
NOTE: Transaction types Void Sale, Void Return, Void Forced,
Return,
Forced, and Verify are not applicable with Phone Card Activation
Batching
To perform a batch release, or settlement of transactions stored in the
NURIT 8000 memory, the following must be done at the end of each work
day:
1. At CREDIT.....SALE, ACCOUNT ?, press <F>.
2. Terminal will display:
CHOOSE A FUNCTION
1. REPORT 3. REVIEW
2. BATCH 4. FIND
Press <ENTER> to see
the list of hot keys.
3. Press <6>. Terminal will display:
1. CREDIT HOST (host name)
2. DEBIT HOST (host name)
3. EBT HOST (host name)
4. Press the corr
ect numbered key. Terminal will dial out to
the host processor. If batch was approved, a batch response
will print, and a current report will be generated.
Auto Close
If a terminal is programmed for auto batch, the host will close the batch
automatically each night, at a specific time, and print a batch report.
However, the report will only clear at the time of the first attempted sale,
after your set batch time. Although your terminal will be programmed for
auto batch, you may still have the option to batch manually.
CHAPTER 2
MENU
The NURIT 8000 has a menu with several options that control some of the
terminal’s basic operational functions, and can be manually changed (refer to
Appendix B). The menu is divided into main menus and sub-menus that can
be accessed by pressing the <MENU/ESC> key.
1. At the CREDIT.....SALE, ACCOUNT ?,
prompt, press
<MENU/ESC>.
2.
Press the number of the Main Menu to be viewed (the
terminal will automatically take you into the sub-
menu), or
you can use the <éé > and <êê > keys to
scroll through the
options and menus.
REPORTS
The first menu in the NURIT 8000 is the Report Menu, which generates
seven different types of reports; Default Report, Current Report, History
Report, Display Transactions, Last Receipt, Performance Report, a
nd Report
Setup. Pressing <MENU/ESC> at the CREDIT.....SALE, ACCOUNT ?
prompt, will access this menu.
Default Report
This is a report of the terminal's daily transactions, which has been
customized, or has set defaults from the Current Report (see Current
Report
on the following page).
1. Terminal will display: (
the actual screen will display up to
(7) seven menu items at one time)
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
2.
You will notice that the first menu is already highlighted.
The <éé > and <êê >
keys can be used to scroll up and
down the menu. To enter the Report menu, press
<ENTER> to make selection. Terminal will display:
REPORTS:
1. Default Report
2. Current Report
3. History Report
3. Press <ENTER>.
Terminal will print a defaulted
current report.
Current Report
Current report will print the terminal's daily transactions, and can be
customized with specific options. This is where the Default Report would be
set.
1. At MENU SCREEN: 1. REPORTS, press <ENTER>.
2. Terminal will display:
REPORTS:
1. Default Report
2. Current Report
3. History Report
Using the <êê > key, scroll down to number 2. Current
Report
3. Press <ENTER>. Terminal will display:
CUR. REPORT TYPE:
1. Condensed Rprt
2. Short Report
3. Journal Report
4. The terminal will display four options; use the <êê >
key
to scroll through the options, or press the corresponding
number:
1. Condensed Report -
will print transaction number,
card type, transaction type, last four digits of the
account number, and amount of sale.
2. Short Report - will print type of transaction,
and
amount of sale.
3. Journal Report - will print a full copy of transaction.
4. Totals Only – will print daily totals only
5. When you have highlighted the type of current report,
press <ENTER>, terminal will display:
CHOOSE EDC TYPE:
1. ALL
2. CREDIT
3. DEBIT
Highlight the selection using the <êê >and press
<ENTER> to make selection.
6. Terminal will display:
ENTER CARD TYPE:
1. ALL
2. VISA
3. MasterCard
Use the <FORCED> key to highlight the selection
needed and then press <ENTER>.
7. Terminal will display:
SORT METHOD BY:
1. By Trans #
2. By Card Type
3. By Clerk ID
Use the <êê > key to highlight the selection and press
<ENTER>.
8. Terminal will display:
CHOOSE TRAN. TYPE:
1. ALL
2. SALE
3. FORCED
Use the <FORCED> key to highlight the selection and
press <ENTER>. There will be eight different transaction
types.
9. Terminal will display:
Set Cur. Defaults, ENTER=Yes,
ESC=No. This will customize the Default Report.
History Report
This report will allow you to print previous batch totals from the last 30 days.
You can print a total report of several batches, or you can print a report
showing totals per batch. To do so, follow these steps:
1. At MENU SCREEN: 1. REPORTS, press <ENTER>.
2. Terminal will display:
REPORTS:
1. Default Report
2. Current Report
3. History Report
3. Using the <êê > key, highlight number 3. HISTO
RY
REPORT.
4. Press <ENTER>. Terminal will display:
FROM BATCH
DATE: MM/DD/YY
. Terminal will always display first
of the month.
5. Press <ENTER>
to keep date shown, or type in the date
needed for a specific batch.
6. Terminal will display:
TO BATCH DATE:
MM/DD/YY.
7. Type in the desired date, and terminal will display:
HISTORY REPORTS:
1. Total
2. Per Batch
Use the <êê > key to highlight desired selection and press
<ENTER>.
8. Terminal will display:
CHOOSE EDC TYPE:
1. ALL
2. CREDIT
3. DEBIT
Use the <êê > key to highlight desired selection and press
<ENTER>.
9. Terminal will display:
ENTER CARD TYPE:
1. ALL
2. VISA
3. Master Card
Use the <êê >
key to highlight desired selection, and press
<ENTER>.
10. Terminal will display:
ENTER TRAN. TYPE:
1. ALL
2. TOTALS ONLY
3. SALE
Use the <êê > key to highlight desired selection and press
<ENTER>.
Display Transaction
This option will allow you to view daily transactions on the terminal display.
You can view these transactions several ways. To do so, follow these steps:
1. At MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
Highlight Reports, and press <ENTER>.
2. Terminal will display:
REPORTS:
1. Default Report
2. Current Report
3. History Report
Using the <êê > key to highlight number 4. DISPLAY
TRANS, and press <ENTER>.
3. Terminal will display:
DISPLAY TRANS:
1. Scroll All
2. By Invoice #
3. By Clerk #
Using the <êê >
key highlight one of the options and press
<ENTER> to make selection.
4. Terminal will display:
CHOOSE EDC TYPE:
1. CREDIT
2. DEBIT
3. EBT
Use the <êê > key to highlight an EDC type, and press
<ENTER> to make selection.
5. Terminal will display the following:
#001 SL 1.00
549974444444444400
Terminal displays the transaction number, transaction
type, transaction amount, and card number. Use the
<êê > key to scroll through transactions.
Last Receipt
This option will print a copy of the last transaction. If a report was the last
printed item, this option cannot be used to print a copy of last transaction.
To print copy of last transaction:
1. At MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
2. Press <ENTER> , terminal will display:
REPORTS:
1. Default Report
2. Current Report
3. History Report
4. Display Transaction
Using the <êê > key, scroll down to number 5. LAST
RECEIPT and press <ENTER>.
3. Terminal will automatically print copy of last receipt.
Performance Report
This option will print a report listing the percentages of denials, approvals,
swipes, manual entries, etc.
1. At MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
4. Host Params
Highlight 1. Reports and press <ENTER>.
2. Terminal will display:
REPORTS:
1. Default Report
2. Current Report
3. History Report
4. Display Transaction
Using the <êê > key, scroll down to number 6.
PERFORMANCE and press <ENTER>.
3. Terminal will display:
CHOOSE EDC TYPE:
1. CREDIT
2. DEBIT
3. EBT
Highlight a selection by using the <êê > key and press
<ENTER>.
1. Terminal will display: Reset perf. Rprt?, ENTER=Yes,
ESC=No. Terminal is prompting if you would like to reset
performance report.
2. If YES is selected, terminal will display: Manager Card or
ESC for Password.
3. Press <MENU/ESC>. Terminal will display: ENTER
PASSWORD:
4. Type in a password, and press <ENTER>.
Report Setup
This menu give the option of having Visa and MasterCard print together
(Default) or separately.
1. At MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
4. Host Params
Highlight 1. Reports and press <ENTER>.
2. Terminal will display:
REPORTS:
1. Default Report
2. Current Report
3. History Report
4. Display Transaction
Using the <êê > key, scroll down to number 7. REPORT
SETUP and press <ENTER>.
3. Terminal will display:
Vis/Mstr Setup:
1. Separately
2. Together
Highlight a selection by using the <êê > key and press
<ENTER>.
4.
Terminal will return to the MENU SCREEN. Press
<MENU/ESC> to return to idle prompt.
MERCHANT PARAMS
This menu contains nine different functions that can be changed manually, if
necessary. The first function available is Authorizations, which allows
specific card types, and transaction types to be enabled and disabled.
Authorizations (Transaction Types)
This allows transaction types, such as Sales, Returns, Voids, etc. to
be turned off, or on. At CREDIT.....SALE, ACCOUNT ?, press
<MENU/ESC>:
1. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
4. Host Params
2. Press <2>. Terminal will display:
MERCHANT PARAMS:
1. Authorizations
2. Security Level
3. Edit Header
4. Edit Trailer
3. Press <ENTER>. Terminal will dis play:
1 - TRANS TYPES
2- CARD TYPES
4. Press <1>. Terminal will display:
5. Press <MENU/ESC>.
Terminal will display:
ENTER PASSWORD
.
Customer Service must
be called to obtain the
password.
6. Once password is entered, terminal will display:
CHOOSE EDC TYPE:
1. CREDIT
2. DEBIT
3. EBT
Use the <êê > to highlight selection and press <ENTER>.
7. Terminal will display:
MANAGE
R CARD
OR ESC
FOR
PASSWO
RD
CREDIT
1. FORCED (EN), (DIS), or (MGR)
2. VERIFY (EN), (DIS), or (MGR)
3. RETURN (EN), (DIS), or (MGR)
8. Use the <êê > to highlight an option and press <ENTER>.
9. Terminal will display:
CREDIT FORCED
1. Disabled -
transaction is disabled, and can not be
performed
2. Always Enabled - transaction is always enabled
3. Manager Only -
transaction can only be performed
with a manager card.
Use <êê > key to highlight option and press <ENTER> to
make selection. Terminal will always return to this
prompt after every selection.
10.
Scroll to next transaction type, and follow same
procedure. When all changes are completed, press
<MENU/ESC> four times to exit menu.
Authorizations (Card Types)
This allows card types, such as Visa, MasterCard, and Discover
card to be disabled:
1. At CREDIT.....SALE, ACCOUNT ?,
press
<MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <2>. Terminal will display:
MERCHANT PARAMS:
1. Authorizations
2. Security Level
3. Edit Header
4. Press <ENTER>. Terminal will display:
1-TRANS TYPES
2- CARD TYPES
5. Press <2>. Terminal will display:
6. Press <MENU/ESC>.
Terminal will
display:
ENTER PASSWORD
.
Customer Service must
be called to obtain
password.
7.
Once password is
entered the terminal will
display:
CHOOSE CARD TYPE:
1. VISA(+) or (-)
2. Master Card (+) or (-)
3. AMEX (+) or (-)
Use the <êê > key to highlight the option and press
<ENTER> to make selection.
8. Press <ENTER>
to make selection, and terminal will
TECHNIC
. CARD
OR ESC
FOR
PASSWO
RD
display:
VISA+
1. Disabled (+) - credit card type is always enabled
2. Always Enabled (-) –
credit card type is disabled, and
can not be processed
Use the <êê > key to scroll to the option needed, and
press <ENTER> to make selection.
9. Terminal will display: CREDIT 1. FORCED (+), or (-).
Terminal will always return to this prompt, after every
selection.
10.
Scroll to next card type, and follow same procedure.
When finished making all changes, press
<MENU/ESC>
three times. Terminal will return to:
CREDIT....SALE
ACCOUNT ?
Security Levels
This option allows merchants to set security levels for the Menu, Batching,
Card Security, Manual Entry of a credit card, and printing format of a credit
card number.
To set a security level for the MENU:
1. At CREDIT.....SALE, ACCOUNT ?,
press
<MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <2>. Terminal will display:
MERCHANT PARAMS:
1. Authorizations
2. Security Level
3. Edit Header
Use the <êê > key to highlight number
2. SECURITY
LEVEL and press <ENTER>.
4. Press <ENTER>. Terminal will display:
SECURITY SWITCH:
1. Menu- disables or enables access to the Menu
2. Batch –
disables or enables access to process a batch.
3. Secure Card –
prompts for last 4 digits or all digits
after swiping the card.
5. Press <ENTER>. Terminal will display:
Menu:
1. Always Enabled
2. Manager Only
6. Use the <êê >
key to highlight an option and press
<ENTER> to make selection. Always Enabled
will
allow access to the menu, and Manager Only
will prompt
for a manager card, or a password.
7. Press <MENU/ESC>
three times to return to
CREDIT…SALE ACCOUNT ?
To set a security level for BATCHING :
1. At CREDIT.....SALE, ACCOUNT ?,
press
<MENU/ESC>. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
2. Press <2>. Terminal will display:
MERCHANT PARAMS:
1. Authorizations
2. Security Level
3. Edit Header
Use the <êê > key to highlight number
2. SECURITY
LEVEL and press <ENTER>.
3. Press <ENTER>. Terminal will display:
SECURITY SWITCH:
1. Menu
2. Batch
3. Secure Card
Use the <êê > key to highlight number 2. BATCH and
press <ENTER>.
4. Terminal will display:
Batch:
1. Always Enabled
2. Manager Only
Use the <êê >
key to highlight and option and press
<ENTER> to make selection. Always Enabled
will
allow access to the menu, and Manager Only
will prompt
for a manager card, or a password.
5. Press <MENU/ESC> three times to return to
CREDIT…SALE
ACCOUNT ?
To set a security level for SECURE CARD:
1. At CREDIT.....SALE, ACCOUNT ?,
press
<MENU/ESC>. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
2. Press <2>. Terminal will display:
MERCHANT PARAMS:
1. Authorizations
2. Security Level
3. Edit Header
Use the <êê > key to highlight number
2. SECURITY
LEVEL and press <ENTER>.
3. Press <ENTER>. Terminal will display:
SECURITY SWITCH:
1. Menu
2. Batch
3. Secure Card
Use the <êê > key to highlight number 3. Secure Card
and press <ENTER>.
4. Terminal will display:
Secure Card (1):
1. No Security - no security
2. Last 4 Digits -
terminal will prompt for last four
digits of account number after card is swiped
3. All Digits -
terminal will prompt for reentry of credit
card number, after card is swiped
Use the <êê >
key to highlight an option and press
<ENTER> to make selection.
5. Press <MENU/ESC> three times to return to
CREDIT…SALE ACCOUNT ?
To set a security level for the CARD MAN. ENTRY :
1. At CREDIT.....SALE, ACCOUNT ?,
press
<MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <2>. Terminal will display:
MERCHANT PARAMS:
1. Authorizations
2. Security Level
3. Edit Header
Use the <êê > key to highlight number 2. SECURITY
LEVEL and press <ENTER>.
4. Terminal will display:
SECURITY SWITCH:
1. Menu
2. Batch
3. Secure Card
Use the <êê > key to highlight number 4. Card Man.
Entry and press <ENTER>.
5. Terminal will display:
CARD MAN ENTRY:
1. Disabled
2. Always enabled.
6. Use the <êê >
key to highlight an option and press
<ENTER> to make selection. Always Enabled
will
allow manual entries, and Manager Only
will prompt for
a manager card, or a password.
7. Press <MENU/ESC>
three times to return to
CREDIT…SALE ACCOUNT ?
To set a security level for the PRINT ACCOUNT :
1. At CREDIT.....SALE, ACCOUNT ?,
press
<MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <2>. Terminal will display:
MERCHANT PARAMS:
1. Authorizations
2. Security Level
3. Edit Header
Use the <êê > key to highlight number
2. SECURITY
LEVEL and press <ENTER>.
4. Press <ENTER>. Terminal will display:
SECURITY SWITCH:
1. Menu
2. Batch
3. Secure Card
Use the <êê > key to highlight number 5. PRINT
ACCOUNT and press <ENTER>.
5. Terminal will display:
PRINT ACCOUNT:
1. Always full
2. Full on report
3. Always short
6. Use the <êê >
key to highlight an option and press
<ENTER> to make selection. Always Full
will print full
account number on receipt an
d report, Full on Report will
print last 4 digits on receipt and full account number on
report, and Always Short will print last 4 digits on both
receipt and reports.
7. Press <MENU/ESC>
three times to return to
CREDIT…SALE ACCOUNT ?
Edit Header/Trailer
T
he receipt header and trailer can be changed manually through the terminal.
A specific line, character, or entire header/trailer can be changed, if needed.
To make a change, follow these steps:
1. At CREDIT.....SALE, ACCOUNT ?
, press
<MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <2>. Terminal will display:
MERCHANT PARAMS:
1. Authorizations
2. Security Level
3. Edit Header
Use the <êê > key to highlight number 3. EDIT HEADER,
or 4. EDIT TRAILER.
4. Terminal will display, HEADER (TRAILER) TEXT 1N
,
and the first line of your current receipt header will
appear. The N stands for Normal print. N
ormal print
allows 23 characters.
5. Use the <BS> key to move backspace and use the <éé >
and <êê > keys to move up and down.
6. Type the n
umber that contains the letter you wish to use
and then hold down the <F>
key and then press
<ALPHA > to change to alphanumeric characters.
Each
press of the <ALPHA> while still holding the <F>
key
will change the input to a different character.
7. When all changes are completed, press <ENTER>
, and
then press <MENU/ESC> two times to return to
CREDIT…SALE ACCOUNT?
Set Cash EDC
Cash will be an addition to your Payment Modes, and will record cash transactions, if
necessary. To turn this option on, follow these steps:
1. At CREDIT.....SALE, ACCOUNT ?
, press
<MENU/ESC>
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <2>. Terminal will display:
MERCHANT PARAMS:
1. Authorizations
2. Security Level
3. Edit Header
4. Use the <êê > key to scroll down to number
5. SET CASH
EDC.
4. Terminal will display:
Manager Card, or ESC for
Password.
6. Press <MENU/ESC>. Terminal will display:
ENTER
PASSWORD.
If password is unknown, call customer
service.
7. Once password is entered, terminal will display:
CASH EDC SET:
1. WITH CASH
2. WITHOUT CASH
Highlight an options and press <ENTER>
to make your
selection.
Surcharge Rate
This will allow a merchant to add a surcharge rate to a debit transaction. To
add a surcharge rate:
1. At CREDIT.....SALE, ACCOUNT ?, press
<MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <2>. Terminal will display:
MERCHANT PARAMS:
1. Authorizations
2. Security Level
3. Edit Header
Use the <êê > key to scroll down to number 6. Surcharge
Rate and press <ENTER>.
4. Terminal will display:
Technic. Card or ESC for
Password.
5. Press <MENU/ESC >. Terminal will display:
ENTER
PASSWORD. Type in password, and press <ENTER>.
6. Terminal will display:
SURCHARGE: $ 0.00
NEW RATE: 0.00
7. Enter amount of surcharge rate and press <ENTER>
.
Terminal will display:
On CashBack Only
ENTER=Yes, ESC=No
8. Make the proper selection and then press
<MENU/ESC>
twice to return to, CREDIT…SALE ACCOUNT ?
Set Batch Time
This option will allow the batch time in the terminal to be set for a specific
time. This will print a batch report, and will not actually dial to batch. To
change the batch time:
1. At CREDIT.....SALE, ACCOUNT ?,
press
<MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <2>. Terminal will display:
MERCHANT PARAMS:
1. Authorizations
2. Security Level
3. Edit Header
Use the <êê > key to scroll down to number
7. Set Batch
Time.
4. Press <ENTER>. Terminal will display:
Manager Card,
or ESC for Password.
5. Press <MENU/ESC>. Terminal will display:
ENTER
PASSWORD
. If password is unknown, call customer
service.
6. Once password is entered, terminal will display:
SET
BATCH TIME: HH:MM.
7.
Enter the desired time (military time), and press
<ENTER>, and then press <MENU/ESC>
twice to exit
menu.
Server ID/Invoice
This will allow the terminal to prompt for a server or invoice number, or
both. This option can be used for both retail and restaurant applications. To
turn this option on, or off:
1. At CREDIT.....SALE, ACCOUNT ?
, press
<MENU/ESC>
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Parms
3. Merch. Options
4. Hosts Params
3. Press <2>. Terminal will display:
MERCHANT PARAMS:
1. Authorizations
2. Security Level
3. Edit Header
4. Edit Trailer
Use the <êê > key to scroll down to number
8.
Server/Invoice and press <ENTER>.
4. Terminal will display:
SERVER ID MODE:
1. OFF
2. ON
Use the <êê > key to scroll to highlight an options and press
<ENTER> to make selection.
5. Terminal will then display:
INVOICE MODE:
1. OFF
2. ON
3. AUTO
Use the <êê > key to scroll to highlight an option and press
<ENTER> to make selection.
(In the Restaurant application, there are two more options after Invoice;
Table #’s and Guest #’s. In the Bar application, there is Tab open.
This will have a preset amount for a Tab, and it can be changed.)
6. Then press <MENU /ESC> twice to exit menu.
Site ID
This option is used mainly for programming purposes; it allows customer
service to view, or change the terminal number.
MERCHANT OPTIONS
This Main Menu has nine options that can be enabled or disabled, manually
through the terminal.
Paper Type
Changes paper type to double, single ply, or customized. Single ply prints
two receipts, double ply prints one receipt, and customized prints two
receipts for every transaction.
1. Press <MENU/ESC> at the
CREDIT.....SALE,
ACCOUNT ? prompt.
2. Terminal will display
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <3>. Terminal will display:
MERCH. OPTIONS:
1. Paper Type
2. No-Paper Mode
3. Buzzer Set
4. Press <ENTER>. Terminal will display:
PAPER TYPE:
1. Single Ply
2. Double Ply
3. Customized
5. Scroll through options, using the <êê >
key, and press
<ENTER> to make selection.
6. Press the <MENU/ESC> key two times to exit the menu.
No Paper Mode
This option disables the printer, and will not print a receipt for any transaction.
To disable a printer:
1. At CREDIT.....SALE, ACCOUNT ?,
press
<MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <3>. Terminal will display:
MERCH. OPTIONS:
1. Paper Type
2. No-Paper Mode
3. Buzzer Set
4. Operation Mode
4. Use the <êê > key to scroll to 2. No-Paper Mode
and press
<ENTER>.
5. Terminal will display:
Manager Card, or ESC for
Password.
6. Press <MENU/ESC>. Terminal will display:
ENTER
PASSWORD
. If password is unknown, call customer
service.
7. Once password is entered, terminal will display:
NO PAPER MODE:
1. YES – disables the printer
2. NO – enables the printer
8. Press <ENTER>
to make your selection. Terminal will
display: Are You Sure? ENTER=Yes, ESC=No.
Make
selection, and press <MENU/ESC> twice to exit menu.
Buzzer Set
Enables or disables
tone when performing certain terminal
functions. To turn on the buzzer:
1. At CREDIT.....SALE, ACCOUNT ?,
press
<MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <3>. Terminal will display:
MERCH. OPTIONS:
1. Paper Type
2. No-Paper Mode
3. Buzzer Set
4. Use the <êê > key to scroll to 3. BUZZER SET
and press
<ENTER>.
5. Terminal will display:
BUZZER SET:
1. OFF
2. ON
Use the <êê >
key to highlight option and press
<ENTER> to make selection. Press
<MENU/ESC>
twice to exit menu.
Operation Mode
This option allows the terminal to be set at two different modes,
Normal or Demo (Demo mode for training; Normal mode for live
transactions). If the terminal is set in Demo mode for training
purposes, revert back to Normal mode for live
transactions. To
place terminal in Demo mode follow these steps:
1. At CREDIT.....SALE, ACCOUNT
?, press
<MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <3>. Terminal will display:
MERCH. OPTIONS:
1. Paper Type
2. No-Paper Mode
3. Buzzer Set
4. Use the <êê > key to scroll to 4. OPERATION MODE
and
press <ENTER>.
5. Terminal will display:
OPERATION MODE
1. Demo Mode
2. Normal Mode
6. Use the <êê >
key to highlight an option and press
<ENTER>.
7. Terminal will display: Are You Sur
e? Enter=Yes,
ESC=No.
8. Press <ENTER>, and then <MENU/ESC>
twice to exit
menu.
Battery Saver
This menu gives several options for the battery. Available in the
NURIT 3010 only. To select an option:
1. At CREDIT.....SALE, ACCOUNT ?,
press
<MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <3>. Terminal will display:
MERCH. OPTIONS:
1. Paper Type
2. No-Paper Mode
3. Buzzer Set
Use the <êê > key to highlight 5. BATTERY SAVER and
press <ENTER>.
4. Terminal will display:
PRT DSCLMR MODE
1. OFF- battery saver off
2. Radio Only –
will shut off only the radio after a
specific amount of time is set in terminal
3. Radio+Auto off –
will shut off radio and terminal
after a specific amount of time set in terminal
4. Auto Off Only – only the terminal
will shut off after
a specific amount of time set in the terminal.
Radio will stay on.
Use the <êê >
key to highlight an option, and press
<ENTER>. Then press <MENU/ESC>
twice to exit
menu.
Prints Disclaimer
This option will print the following statement at the end of a credit card
transaction:
“
I AGREE TO PAY ABOVE TOTAL AMOUNT
ACCORDING TO CARD ISSUER AGREEMENT
(MERCHANT AGREEMENT IF CREDIT VOUCHER
).” To
turn on this option:
1. At CREDIT.....SALE, ACCOUNT ?,
press
<MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <3>. Terminal will display:
MERCH. OPTIONS:
1. Paper Type
2. No-Paper Mode
3. Buzzer Set
Use the <êê > key to highlight 6. PRT DISCLAIMER and
press <ENTER>.
4. Terminal will display:
PRT DSCLMR MODE
1. OFF
2. ON
Use the <êê > key to highlight an option
and press
<ENTER>. Then press <MENU/ESC>
twice to exit
menu.
Menu Type
The menu in the terminal can be set to scroll automatically, or
manually. Follow these steps:
1. At CREDIT.....SALE, ACCOUNT ?
, press
<MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <3>. Terminal will display:
MERCH. OPTIONS:
1. Paper Type
2. No-Paper Mode
3. Buzzer Set
4. Use the <êê > key to scroll highlighter to
7. Set Menu
Type.
5. Press <ENTER>. Terminal will display:
CHOOSE MENU TYPE:
1. Auto Scroll
2. Manual Scroll
6. Use the <êê >
key to highlight an options and press
<ENTER>
to make selection. If auto scroll is selected
terminal will prompt for scroll speed (1-
9). Type in a
speed and press <ENTER>.
7. Then press <MENU/ESC> twice to exit menu.
Set Halo
This option sets a limit that the cashier should not exceed for sales,
refunds, and cash back.
1. At CREDIT.....SALE, ACCOUNT ?
, press
<MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <3>. Terminal will display:
MERCH. OPTIONS:
1. Paper Type
2. No-Paper Mode
3. Buzzer Set
Use the <êê > key to scroll to 8. Set Halo
and press
<ENTER>.
4. Terminal will display:
Manager Card, or ESC for
Password.
5. Press <MENU/ESC>. Terminal will display: ENTE
R
PASSWORD.
If password is unknown, call customer
service.
6. Once password is entered, terminal will display:
HALO FOR SALE:
1. OFF
2. ON
Use the <êê >
key to highlight an option and press
<ENTER>.
7. If option 2, is selected, terminal will display:
Halo: $0.00
New Rate: 0.00
8. Enter maximum amount for a sale, and press <ENTER>.
Terminal will display:
HALO FOR RETURN:
1. OFF
2. ON
Use the <êê > key to select an option and press <ENTER>
.
Follow the same steps above for Return Halo and Cash
Back Halo.
Print Setup
This
option will print a setup report. It will show all the options
that have been turned on for the terminal. To print this report:
1. At CREDIT.....SALE, ACCOUNT ?,
press
<MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <3>. Terminal will display:
MERCH. OPTIONS:
1. Paper Type
2. No-Paper Mode
3. Buzzer Set
Use the <êê > key to scroll to 9. PRINT SETUP
and press
<ENTER> to print.
HOST PARAMETERS
This menu allows you to change host parameters, such as merchant numbers,
terminal IDs, and authorization numbers. Each host has different individual
parameters, and should only be changed, if advised by the processing bank,
or NURIT technical support. There are six sub-menus in Host Parameters.
Host Parameters
This allows you to edit merchant and/or terminal IDs for your host
processor. To do so, follow these steps:
1. At CREDIT.....SALE, ACCOUNT ? press <MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <4>. Terminal will display:
HOST PARAMS:
1. Hosts Params
2. Hosts Phone
3. Prnt EDC Setup
4. Press <ENTER>. Terminal will display:
ENTER
PASSWORD.
Type in password (if password is not
known, call customer service), and press <ENTER>.
5. Terminal will display:
EDC PARAMETERS:
1. Host Name CR
2. Host Name DB
3. Host Name CHK
Use the <êê > key to scroll through the different hosts.
Highlight an option and press <ENTER> to make
selection.
6. Terminal will display:
HOST NAME:
1. MERCHANT ID
(Please keep in mind, this display will
differ according to each host).
Use the <êê >
key to scroll through the options, and press
<ENTER> to enter new information.
7. When changes are completed, press <ENTER>
and then
<MENU/ESC>.
8. Terminal will display:
Save Parameters?
ENTER=Yes, ESC=No
9. Press <ENTER> and then <MENU/ESC> three
times to
exit menu.
Host Phones
This option allows the changing of authorization phone numbers and batch
phone numbers for the host processor. To make any phone number
changes:
1. At CREDIT.....SALE, ACCOUNT ?
, press
<MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <4>. Terminal will display:
HOST PARAMS:
1. Hosts Params
2. Hosts Phone
3. Prnt EDC Setup
Use the <êê > key to scroll to 2. Hosts Phone,
and press
<ENTER>.
4. Terminal will display, ENTER PASSWORD
. Type in
p
assword (if password is not known, call customer
service), and press <ENTER>.
5. Terminal will display:
PHONE MENU:
1. Host Name CR
2. Host Name DB
3. Host Name CHK
Use the <êê > key to highlight an option. Press
<ENTER>
to make selection.
6. Terminal will display:
PHONE TYPE:
1. Auth. Phones:
2. Batch Phones:
Use the <êê >
key to highlight an options and press
<ENTER> to make a selection.
7. Press <ENTER>. Terminal will display:
EDIT PHONE:
1. Phone Number 1
2. Phone Number 2
3. Phone Number 3
Use the <FORCED> key to scroll through prima
ry and
secondary phone numbers and press <ENTER>
to edit
phone number.
8. When changes are completed, press <ENTER>
, and then
<MENU/ESC> until terminal displays:
Save
Parameters?, ENTER=Yes, ESC=No.
9. Press <ENTER> and then <MENU/ESC>
three times to
exit menu
.
Print EDC Setup
This report prints host information such as merchant numbers, phone
numbers, baud rates, and capture type. To print this report:
1. At CREDIT.....SALE, ACCOUNT ?
, press
<MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <4>. Terminal will display:
HOST PARAMS:
1. Hosts Params
2. Hosts Phone
3. Prnt EDC Setup
Use the <êê > key to scroll to 3. Prnt EDC Setup, and
press <ENTER> to print.
4. Press <ENTER> and then <MENU/ESC>
three times to exit
menu.
Protocol Version
This displays the protocol/host version. Mainly viewed by programmers.
To view:
1. At CREDIT.....SALE, ACCOUNT ?
, press
<MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <4>. Terminal will display:
HOST PARAMS:
1. Hosts Params
2. Hosts Phone
3. Prnt EDC Setup
Use the <êê > key to scroll to 4. Protocol Version
and press
<ENTER> to view.
4. Press <ENTER> and then <MENU/ESC>
three times to
exit menu.
AutoDial Setup
This menu allows you to enable and set batch
ing autodial times and intervals.
To set:
1. At CREDIT.....SALE, ACCOUNT ?
, press
<MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
Use the <êê > key to scroll to 5. AutoDial Setup
and press
<ENTER> to view.
3. Terminal will display:
Technic. Card or ESC for
Password.
4. Press <MENU/ESC>. Terminal will display:
ENTER
PASSWORD
. If password is unknown, call customer
service.
5. Once password is entered, terminal will display: (
If there
is only one host then you will see only one option)
CHOOSE HOST:
2. Host Name CR
3. Host Name DB
Use the <êê > key to scroll and press <ENTER> to select.
6. Terminal will display:
AUTODIAL SETUP:
1. OFF
2. ON
Press <2> to select On.
7. Terminal will display:
START AD AT:
03:00
Type in the starting AutoDial time
using the HH:MM 24 hr
format.
8. Terminal will display:
PRESS ENTER
03:00
(This will show the time that you entered in the
previous step)
Press <ENTER>.
9. Terminal will display:
STOP AD AT:
04:00
Type in the stopping AutoDial time using the HH:MM 24
hr format.
10. Terminal will display:
PRESS ENTER
04:00
(This will show the time that you entered in the
previous step)
Press <ENTER>.
11. Terminal will display:
PRESS ENTER
AD INTERVAL:
5
Type in the AutoDial interval and press <ENTER>
12. Press <MENU/ESC> twice to exit menu.
Host Radio Address
This menu allows you to view and manually change the host radio
destination addresses for authorization and batching.
1. At CREDIT….SALE, ACCOUNT?
Press
<MENU/ESC>
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
Use the <êê > key to scroll to 6. Host Radio Address
and
press <ENTER> to view.
3. The terminal will display:
Radio Addresses
1. Host Name H C
2. Host Name H D
Press either <1> of <2> to make your selection.
4. The terminal will display:
Radio Addresses
1. Auth. Radio:
2. Batch Radio:
Press either <1> of <2> to make your selection.
5. The terminal will display:
Radio Addresses
Host Radio Addr
nnnnnnnn (
The actual 8 digit number will be
displayed.
Call your customer service representative for
assistance.) Type in
the destination address and press
<ENTER>.
6. Press <MENU/ESC> and the terminal will display:
Save
Parameters? ENTER=YES, ESC=NO
. Press
<ENTER> or <MENU/ESC> to make your selection.
7. Press <MENU/ESC> twice to exit this menu.
SYSTEM OPTIONS
This menu consists of eleven different functions that can be changed
manually, however, only a customer service representative should make
changes on six of these functions.
Set Time and Date
This allows the time and date to be changed, if needed. To change
the time and date:
1. At CREDIT.....SALE, ACCOUNT ?
press
<MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <5>. Terminal will display:
SYSTEM OPTIONS:
1. Set Time/Date
2. Edit PIN Key
3. Sel. Mstr Key
4. Press <ENTER>. Terminal w
ill display the current time
and date in terminal.
5. Press <ENTER>. Terminal will display:
Setting Date:
MM/DD/YY
Type in the month, date, and year.
6. Terminal will automatically display:
Setting Time:
HH:MM:00
Enter the correct time (military time).
7.
Terminal will display the date and time entered. Press
<MENU/ESC> three times to exit menu.
Edit PIN key
This option allows the changing or viewing of the working key for
the PIN pad (access to this menu is not available without a PIN
pad). The only
time a change should be made in this field is if
instructed by customer service.
6. At CREDIT.....SALE, ACCOUNT ?,
press
<MENU/ESC>.
7. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
8. Press <5>. Terminal will display:
SYSTEM OPTIONS:
1. Set Time/Date
2. Edit PIN Key
3. Sel. Mstr Key
Use the <êê > key to scroll to 2. Edit PIN Key
and press
<ENTER>.
9. Terminal will display:
Technic. Card or ESC for
Password.
10. Press <MENU/ESC>. Terminal will display:
ENTER
PASSWORD. Type in password, and press <ENTER>.
11. Terminal will dipslay:
EDIT WORKING KEY
0000000000000000000
7. Type in the correct working key, and press <ENTER>
.
Then press <MENU/ESC> twice to exit menu.
Select Master Key
This changes the Master key location (access to this menu is not
available without a PIN pad). Again
, this is a field that should only be
changed if instructed by customer service. To do so, follow these
steps:
1. At CREDIT.....SALE, ACCOUNT ?, press <MENU/ESC>
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <5>. Terminal will display:
SYSTEM OPTIONS:
1. Set Time/Date
2. Edit PIN Key
3. Sel. Mstr Key
Use the <êê > key to highlight 3. Sel. Mstr Key and p
ress
<ENTER>.
4. Terminal will display:
CHOOSE HOST:
6. Host Name DB
7. Host Name EBT
Use the <êê > key to highlight an option and press
<ENTER>
to make selection.
4. Terminal will display:
5. Type in correct master key location (0-
9), and press
<ENTER>. Then press <MENU/ESC> twice to exit menu.
Set Batch Number
This allows the batch number to be changed, if needed. This is also a
field
that should only be changed when instructed by customer service.
To change the batch number:
1. At CREDIT.....SALE, ACCOUNT ?, press <MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <5>. Terminal will display:
SYSTEM OPTIONS
1. Set Time/Date
2. Edit PIN Key
3. Sel. Mstr Key
Use the <êê > key to scroll to 4. Set Batch No.
4. Press <ENTER>. Terminal will display:
Technic Card or
ESC for Password.
MASTER KEY LOCATION
0
5. Press <MENU/ESC>. Terminal will display:
ENTER
PASSWORD. If password is unknown, call customer service.
6. Once password is entered, terminal will display:
CHOOSE HOST:
1. Host Name CR
2. Host Name DB
3. Host Name CHK
Use the <FORCED>
key to the host needed and press
<ENTER> to make selection.
7. Terminal will display:
8. Enter new batch number and press <ENTER>
. Then press
<MENU/ESC> twice to exit menu.
Edit Database
This sub-
menu has two options, Void Transaction, and Clear Database.
Void transaction will void a transaction by transaction number, and
Clear Database will delete a bat
ch and all its transactions in the
terminal.
To Void A Transaction:
1. At CREDIT.....SALE, ACCOUNT ?, press <MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
New Batch No:
XX
3. Press <5>. Terminal will display:
SYSTEM OPTIONS
1. Set Time/Date
2. Edit PIN Key
3. Sel. Mstr Key
Use the <êê >
key to highlight 5. EDIT DATABASE and press
<ENTER>.
4. Terminal will display:
EDIT DATABASE:
1. Void Transact.
2. Clear Database
5. Once password is entered, terminal will display:
CHOOSE EDC TYPE
1. CREDIT
2. DEBIT
3. EBT
6. Press <ENTER>. Terminal will display:
Manager Card or
ESC for Password.
7. Press <MENU/ESC>. Terminal will display:
ENTER
PASSWORD. If password is unknown, call customer service.
8. Enter transaction number to be voided, and press <ENTER>.
9. Terminal will display:
TRANSACTION # ?
1
#001 SL 1.00
549974444444444400
10.
If display is showing correct transaction to be voided, press
<ENTER>.
11. Terminal will display:
VoidTrans. #1? ENTER=Yes,
ESC=No. Press <ENTER>.
Terminal will print voided
transaction. Press <MENU/ESC> three times to exit menu.
To Clear Database:
1. At CREDIT.....SALE, ACCOUNT ?, press <MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <5>. Terminal will display:
SYSTEM OPTIONS:
1. Set Time/Date
2. Edit PIN Key
3. Sel. Mstr Key
Use the <êê > key to scroll to 5. Edit Database.
4. Press <ENTER>. Terminal will display:
EDIT DATABASE:
1. Void Transact.
2. Clear Database
Use the <êê > key to highlight option 2. Clear Database
and
press <ENTER>.
5. Terminal will display:
CHOOSE EDC TYPE:
1. ALL
2. CREDIT
3. DEBIT
Use the <FORCED>
key to scroll through different EDC
types.
6. Press <ENTER>
to make selection. Terminal will display:
Technic Card or Esc for Password.
7. Press <MENU/ESC>. Terminal will display:
ENTER
PASSWORD. If password is unknown, call customer service.
8. Once password is entered, terminal will display:
ARE YOU
SURE? ENTER=Yes, ESC=No.
9. Press <ENTER>
and terminal will print message that database
has been cleared.
Working Mode (Retail Application)
This option places terminal in AVS mode. AVS (A
ddress Verification)
will prompt for a zip code, and street address. There are three options
for AVS: • OFF – no prompt for zip code, or street address
• ON MANUAL ONLY -
will prompt for zip
code and street address on a manual entry only
• ALWAYS – will prompt
for zip code and street
address on swiped and manual entries.
1. At CREDIT.....SALE, ACCOUNT ?, press <MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Parms
3. Merch. Options
3. Press <5>. Terminal will display:
SYSTEM OPTIONS:
1. Set Time/Date
2. Edit PIN Key
3. Sel. Mster Key
Use the <FORCED> key to scroll to 6. Working Mode.
4. Press <ENTER>. Terminal will display:
ASK FOR AVS:
1. OFF
2. ON
Use the <FORCED>
key to scroll highlight an option and
press <ENTER>.
5. After selection, terminal will display Check R
ates with Your
Bank
. This is a warning that rates may be higher for manual
entries without AVS.
6. Press <MENU/ESC> three times to exit menu.
Working Mode (Restaurant Application)
This option offers different tip options. There are as follows:
• IN TIP MENU –
terminal will print a tip line on
the receipt
• IN TRANSACTION -
terminal will prompt for
tip amount during the transaction. If tip amount
unknown, press <ENTER>
to bypass, and
terminal will print a tip line.
• PRINT PERCENT – will add a percentage of the
transaction amount for the tip. A percentage
needs to be programmed
1. At CREDIT.....SALE, ACCOUNT ?, press <MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <5>. Terminal will display:
SYSTEM OPTIONS:
1. Set Time/Date
2. Edit PIN Key
3. Sel. Mstr Key
Use the <êê > key to scroll to 6. Working Mode and press
<ENTER>.
4. Terminal will display:
ASK FOR TIP:
1. In Tip Menu
2. In Transaction
3. Print Percent
Use the <êê > key to highlight an option and press <ENTER>.
5. If option 3. Print Percent
is selected, terminal will display,
Percentage of Sum
. Enter percentage amount, and press
<ENTER>.
6. Press <MENU/ESC> three times to exit menu.
Pre-dial Call
Terminal can be programmed to start dialing once the credit card is
swiped. If pre-dial
is turned off, the terminal will start dialing after
entering the dollar amount. The goal behind pre-
dial, is to save
transaction time. To turn on pre-dial:
1. At CREDIT.....SALE, ACCOUNT ?, press <MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <5>. Terminal will display:
SYSTEM OPTIONS:
1. Set Time/Date
2. Merch. Params
3. Merch. Options
Use the <êê > key to scroll to 7. PREDIAL CALL
and press
<ENTER>.
4. Terminal will display: Manager Card or Esc for Password.
5. Press <MENU/ESC>. Terminal will display:
ENTER
PASSWORD. If password is unknown, call customer service.
6. Once password is entered, terminal will display:
PREDIAL CALL:
1. OFF
2. ON
Use the <êê > key to highlight an option and press
<ENTER>
to make selection, and then press <MENU/ESC>
twice to exit
menu.
PIN Pad Initialization (Only for NURITs with internal PIN Pad)
This menu
will allow you to set the PIN pad initialization to automatic
or manually. To use this option:
1. At CREDIT.....SALE, ACCOUNT ?, press <MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <5>. Terminal will display:
SYSTEM OPTIONS:
1. Set Time/Date
2. Merch. Params
3. Merch. Options
Use the <êê > key to scroll to 9. PinPad init.
and press
<ENTER>.
4. The terminal will display:
PINPAD INIT. [1
1. Auto
2. Manual
Press <1> for auto or <2> for manual.
5. Press <MENU/ESC> twice to exit this menu.
PIN Pad Function (Only for NURITs with internal PIN Pad)
This menu gives option to encrypt terminal manually for the internal
PIN Pad. To encrypt:
1. At CREDIT.....SALE, ACCOUNT ?, press <MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <5>. Terminal will display:
SYSTEM OPTIONS:
3. Set Time/Date
4. Merch. Params
5. Merch. Options
Use the <êê > key to scroll to 8. PIN Pad and press <ENTER>.
4.
Terminal will display, scrolling arrows. Proceed with regular
encryption process.
5. When encryption completed, press <MENU/ESC>
twice to
exit menu.
PIN Pad Configuration (Only for NURITs with internal PIN Pad)
Terminal can
be programmed for internal PIN Pad, or an external PIN
Pad. To change from internal to external:
1. At CREDIT.....SALE, ACCOUNT ?, press <MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <5>. Terminal will display:
SYSTEM OPTIONS:
1. Set Time/Date
2. Merch. Params
3. Merch. Options
Use the <<êê > key to scroll to 9. PIN Pad Configuration
and
press <ENTER>.
4. Terminal will display: Technic Card or Esc for Password.
5. Press <MENU/ESC>. Terminal will display:
ENTER
PASSWORD. If password is unknown, call customer service.
6. Once password is entered, terminal will display:
CHOOSE PIN PAD:
1. Built-In
2. External
Use the <<êê > key to highlight an option and press <ENTER>
to make selection, and then press <MENU/ESC> twice to exit
menu.
Test Mode
Only NURIT programmers use this menu for testing purposes.
RADIO TEST
This menu is applicable to the NURIT 2070 and 2090 (radio terminal). It allows
viewing of the radio information. The sub-menus are as follows:
Radio RSSI
This shows the rad
io strength signal (coverage area). The RSSI should
be a six or greater to obtain good reception, and base station will
always differ, depending on location. To check radio signal:
1. At “CREDIT.....SALE, ACCOUNT ?”, press <MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
Use the <êê > key to scroll to 6. RADIO TEST
and press
<ENTER>.
3. Terminal will display:
RADIO TESTS:
1. Radio RSSI
2. Host Radio Ad
3. Radio Info
4. Press <ENTER>, terminal will display:
RADIO RSSI: 14
BASE STN: 0
Keep in mind that Base Station and RSSI will vary according
to location.
3. Press <MENU/ESC> three times to exit menu.
Radio Address
This displays the radio’s MAN number. This is needed when the radio
signal provider (Bell South Wireless 1-800-662-4839) n
eeds to contact
the radio, or look up the account. An RSSI test must first be performed
before displaying the MAN# (or else MAN# = 0). To view the MAN#:
1. At “CREDIT.....SALE, ACCOUNT ?”, press <MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
Use the <êê > key to scroll to 6. RADIO TEST and press
<ENTER>.
3. Terminal will display:
RADIO TESTS:
1. Radio RSSI
2. Host Radio Ad
3. Radio Info
4. Use the <êê > key to scroll to 2. HOST RADIO ADDRESS
and
press <ENTER>.
5. Terminal will display:
MAN=15540000
Press any key…..
The MAN# identifies the radio.
6. Press <MENU/ESC> three times to exit menu.
Radio Information
Displays radio information and only used by customer service.
Battery Test
Displays battery the power. To check battery strength:
1. At “CREDIT.....SALE, ACCOUNT ?”, press <MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
Use the <êê > key to scroll to 6. RADIO TEST
and press
<ENTER>.
3. Terminal will display:
RADIO TESTS:
1. Radio RSSI
2. Host Radio Ad
3. Radio Info
Use the <êê > key to scroll to 4. BATTERY TEST
and press
<ENTER>.
4. Terminal will display:
AC POWER OK!
GOOD BATTERY
5. Press <MENU/ESC> three times to exit menu.
DOWNLOAD PARAMETERS
This menu is used for technical purposes only. When and if, the terminal needs to
be reprogrammed, a customer service representative will direct you step by step
through this operation.
COMMUNICATION
This Main Menu has four sub-menus pertaining to communication. The sub-
menus are as follows:
Minimum Retries
The amou
nt of times the terminal dials for authorization or batching
can be programmed through the terminal. To program the amount of
retries:
1. At CREDIT.....SALE, ACCOUNT ?, press <MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
Use the <êê > to scroll to 8. COMM MENU
and press
<ENTER>.
3. Terminal will display:
COMM MENU:
1. Min. retries>
2. DIAL: TONE
3. Exchange pref>
The first option 1. Min retries
should be highlighted. Press
<ENTER> to make selection.
4. Terminal will display:
5. Enter the number of retries needed, and press <ENTER>
.
Then press <MENU/ESC> twice to exit menu.
Dial: Tone/Pulse
The terminal can be set to dial at a pulse or touch tone. To change to
either option:
1. At CREDIT.....SALE, ACCOUNT ?, press <MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
Use the <êê > to scroll to 8. COMM MENU
and press
<ENTER>.
3. Terminal will display:
COMM MENU:
1. Min. retries>
2. DIAL: TONE
3. Exchange pref>
Use the <êê > key to scroll to 2. DIAL: TONE
and press
<ENTER>.
Min Num Tries:
1
4. Terminal will display:
DIAL TYPE:
1. Tone
2. Pulse
Use the <FORCED>
key to highlight an option press
<ENTER> to make selection. Then press
<MENU/ESC>
twice to exit menu.
Exchange Prefix
The terminal can be programmed to d
ial an exchange prefix before a
phone number, if needed. To add an exchange prefix:
1. At CREDIT....SALE, ACCOUNT ?, press <MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
Use the <êê > to scroll to: 8.COMM MENU,
and press
<ENTER>.
3. Terminal will display:
COMM MENU:
1. Min. retries>
2. DIAL: TONE
3. Exchange pref>
Use the <êê > to scroll to 3. Exchange pref>
and press
<ENTER>.
4. Terminal will display:
EXCHANGE PREFIX:
1. No
2. Yes
Use the <FORCED> key to highlight an opt
ion and press
<ENTER> to make selection.
5. If option 2. Yes is selected, the terminal will display:
6. Enter exchange prefix and press <ENTER>
. Then press
<MENU/ESC> twice to exit menu.
Gateway
This menu is used for technical purposes only.
ENTER PREFIX:
Suffix
This field is used when a suffix is needed at the end of a phone number. To enter a
suffix:
1. At CREDIT....SALE, ACCOUNT ?, press <MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
3. Press <8>. Terminal will display:
COMM MENU:
1. Min Retries>
2. DIAL : TONE
3. Exchange pref.
Use the <êê > key to scroll to 5. SUFFIX and press <ENTER>.
4. Terminal will display:
SUFFIX:
1. No
2. Yes
Use the <FORCED>
key to highlight an option and press
<ENTER> to make selection.
5. If YES is selected, terminal will display:
6. Enter suffix, press <ENTER>, and then press
<MENU/ESC>
twice to exit menu.
Via Line/Radio
1. At CREDIT....SALE, ACCOUNT ?, press <MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
Use the <FORCED> to scroll to 6. VIA LINE/RADIO and press <ENTER> .
3. Terminal will display:
LINE / RADIO:
1. Both:
2. Line Only
Use the <FORCED>
key to highlight an option and press
<ENTER>.
4. Then press <MENU/ESC> twice to exit menu.
ENTER SUFFIX:
Check Line
This option is used to check for a phone line. To set:
1. At CREDIT....SALE, ACCOUNT ?, press <MENU/ESC>.
2. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
Use the <êê > key to scroll to 7. CHK LINE: ON Pressing
<ENTER> will toggle between ON and OFF
Dial Tone Check
This option is used to check for a dial tone. To set:
1. Terminal will display:
MENU SCREEN:
1. Reports
2. Merch. Params
3. Merch. Options
Use the <êê > key to scroll to 8. D. ToneChk: ON Pressing
<ENTER> will toggle between ON and OFF
DIAGNOSTICS
This option allows the terminal to be controlled by customer service via remote
control. Again, this is an option used for technical purposes only.
CHAPTER 3
BASIC TROUBLESHOOTING
This section briefly descr
ibes how to troubleshoot some possible common problems that may rise
during the normal operation of the NURIT 8000
. Before requesting service for this unit, check the
list below for a possible cause of the problem you are experiencing. Some simple checks o
n your
part may solve the problem, and restore proper operation. If you are still unable to solve the
problem, contact the technical support help desk. Do NOT
try to solve the problem by
opening the terminal yourself!
Terminal seems to have no power
• Make
sure the AC adapter is fully plugged into the wall outlet, and that its barrel connector
mates properly with the terminal’s PWR jack.
• If using the NURIT 3010*, try pressing <ON/STANDBY> on the keypad .
• If using the NURIT 3010, allow the battery to charge 1
0 to 12 hours with the terminal on and
AC adapter plugged into the wall (in standby mode).
“NO LINE” appears on the display
• Check that the telephone (RJ-
11) connector is securely mated with the TEL socket on the
terminal, and into the wall.
• NURIT was de
signed for a dedicated phone line. It should not be on a splitter, or on a
rollover phone system.
•
An exchange prefix may or may not be needed. Make sure terminal has correct settings for an
exchange prefix (see page 67).
• If using a NURIT 3010, make sure
that you are receiving radio coverage in the area where you
are located.
Printer does not function properly
•
Check that the paper has been fed to the printer properly (underhand). See the figure and
instructions in Appendix C. The NURIT 8000 uses thermal paper only.
• Check there is paper in the printer compartment. Replace if required.
•
If printer continues working even though the paper has been used up, check that the ‘end of
paper’ detector in the printer mechanism is not blocked by a torn piece of paper.
Card reader not working
•
Make sure that card has been swiped so that its magnetic strip is facing downward and to the
right side of the terminal.
• Be sure to swipe card from back to front of the terminal.
• Contact the technical support help desk.
Possible PIN pad error
•
Verify that the PIN pad is properly plugged into the PIN connector on back of terminal.
• Check the line to the PIN pad itself.
Receipt prints “CANCELED”
•
The terminal will display a host response, or some type of error message, as to why the
transaction was canceled.
APPENDIX A
PHONE CARD
The NURIT 8000
has phone card capabilities. A merchant can supply phone cards that can be
reused as long as the card is valid.
The phone cards work in the following manner: a customer purchases a phone card f
or any
amount desired; anywhere from $1 to $100. When the card is depleted, the customer returns to
the merchant and purchases additional calling time on the same card.
The NURIT 8000 can have this phone card option and still process by either credit, de
bit, or
check, however the idle prompt will differ with the phone card option activated. If a credit or
debit card is swiped, at the phone card prompt, the terminal will automatically switch to the credit
or debit card prompt, respectively.
This phone card option is host capture-
auto dial, meaning the terminal will automatically dial out
to the host, and batch the phone card transactions. The terminal must be on
and plugged into a
phone line for the batching procedure. The batch time, and amount of attempts can be
programmed in Merchant Parameters. The following paragraphs explain the procedures on
processing a phone card transaction for the NURIT 8000.
The merchant uses a terminal, a PIN pad (if processing debit), and printer (optional). The
custome
r enters information on PIN pad (if applicable), and merchant confirms information on
the terminal.
At CREDIT SALE….ACCOUNT, swipe the phone card:
1. Press <ENTER MODE> . Terminal will display:
ENTER AMOUNT ($) 0
Enter the amount that customer purchased
for the phone card, anywhere from $1 to
$99. It must be a rounded number, no cents will be accepted.
2. After the amount has been entered, press <ENTER>
. PIN pad (if applicable) will
display:
AMOUNT = (whatever amount entered, will be displayed here) ENTER/YES,
CLR/NO.
3. If using PIN pad, have customer press <ENTER>
on the PIN pad. Terminal will
display:
CLERK NO. (This will be host specific)
4. If you press <CLR>, terminal will display:
ENTER AMOUNT ($) 0.
At this time enter the correct amount, or press <MENU/ESC>
to cancel transaction.
5. Terminal will dial host, return with one of two responses: “ACTIVATED” or
“NOT ACTIVATED (this meaning card was not accepted, for any reason)”.
REPORTS FOR PHONE CARD
To print a report for phone card transactions, follow these steps:
1. Press <MENU/ESC> , terminal will display:
MENU SCREEN
1. Reports
2. Merch. Params
3. Merch. Options
2. Press <ENTER> . Terminal will display:
REPORTS:
1. Default Report
2. Current Report
3. History Report
3. Press <2>. Terminal will display:
CURRENT REPORT TYPE:
1. Condensed Rport
2. Short Report
3. Journal Report
4. Press <ENTER> . Terminal will display:
CHOOSE EDC TYPE:
1. ALL
2. CREDIT
3. DEBIT
4. EBT
5. Use the <êê > to scroll to 7. GENERIC and press <ENTER>.
6. Terminal will display:
CHOOSE TRANS TYPE:
1. ALL
2. SALE
3. FORCED
4. VERIFY
7. Press <ENTER>. Terminal will display:
SET CURRENT
DEFAULTS?, ENTER=YES, ESC=NO.
8. Press <ENTER>. Terminal will print report.
APPENDIX B
NURIT 8000 QUICK REFERENCE MENU TABLE
Press <MENU/ESC> to access the menu below. Use the <RETURN> and the
<FORCED> keys to scroll through menu, and <ENTER> to select.
MAIN MENU SUB-MENU FUNCTION or ACTION
1. Reports 1. Default Report Prints programmed Default Report
2. Current Report Prints report of daily transactions with
several different options.
3. History Report
Prints previous batch totals within the past
30 days.
4. Display Transaction Display daily transactions by transaction
number
5. Last Receipt Prints copy of the LAST transaction
receipt
6. Performance Report
Prints Approvals, Denials, Disconnects,
Manuals, Swipes
7. Setup Report Gives option to print Visa/MC separately
or together (Default).
2. Merchant
Params 1. Authorization Enables or disables different transaction/
card types
2. Security Level Sets security levels for different
operations
3. Edit Header Edits up to 5-line header
4. Edit Trailer Edits up to 5-line footer
5. Set Cash EDC Enable recording of cash transactions
6. Surcharge Rate Enable Surcharge for a Debit transaction
7. Set batch Time. Change batch time for Host Auto Close
mode
8. Server ID & Invoice
Adds Server ID/Invoice #/Table #/Guest #
to Transaction: 1. Off 2. On
9. Site ID View or change site ID
3. Merchant
Options 1. Paper Type * 2-ply, 1-ply, or customized
2. No Paper Mode * No receipt printed
MAIN MENU SUB-MENU FUNCTION or ACTION
3. Buzzer Set * Enable/disable tone when hitting
keyboard keys
4. Operation Mode * Set terminal in Normal or Demo mode
5. Battery Saver */** 1-Off, 2-Radio Only, 3-Radio+Auto Off, 4-
Auto Off
6. Print Disclaimer Prints Credit Disclaimer on Receipt
7. Menu type Sets menu to auto scroll or manual scroll
8. Set Halo Maximum limit for a transaction (for
sales, refunds, and cash back)
9. Print Setup Prints Setup
4. Host
Parameters 1. Merchant
Parameters Edit Merchant and/or Terminal ID# s for
all hosts used
2. Host phone
numbers Edits: 1. Credit, 2. Debit, 3. Check Host
Phone Numbers
3. Print EDC SETUP Prints: Manager Card No., Hosts, Merch-
ant and/or Terminal ID, allowed transac-
tion types, phone numbers, Header etc…
4. Protocol version Displays host protocol name and version
5. Host Radio Address
Displays host radio address in TCC
(NURIT 3010 only)
5. System
Options 1. Set Time and Date Sets terminal’s Date (mm/dd/yy) and Time
(hh:mm:00)
2. Edit PIN Key Edit host processor working key
3. Sel Mstr Key Change Master Key location
4. Set batch No. Change Batch Number
5. Edit Database Void transaction; clear database for
selected EDC type
6. Working Mode Switches to AVS for retail. Switches tip
options for restaurant/tab amount for bar
7. Pre-dial Call This will cause terminal to dial once card
is swiped, if option is turned on
8. PIN Pad Function Allows encryption of internal PIN Pad
9. PIN Pad
Configuration Option to select from an internal or
external PIN Pad
10. Test Mode Programming purposes only
MAIN MENU SUB-MENU FUNCTION or ACTION
6. Radio Test
(NURIT 3010 only)
1. Radio RSSI Displays radio received signal strength
2. Radio Address Displays the radio’s MAN number
3. Radio Inf. Displays the radio information
4. Battery Test Test the battery
7. Download
Parameters 1. Load PRM Download parameters from Service
Center
2. Connect
Parameters
1. Phone Edit phone number for parameter
download via modem
2. Exchange Prefix Sets telephone exchange prefix
3. Via Modem/Com1
4. Baud Baud rate for communication
5. Dial Tone / Pulse
8.
Communication
1. Min. Retries Number of times the NURIT will call host
processor
2. Dial: Tone Sets pulse or tone (DTMF) dialing
3. Exchange Prefix Sets an exchange prefix before phone
number.
4. Gateway Not Available
5. Suffix Sets a suffix after the phone number.
6. Via Line/Radio*
(NURIT 3010 only) Enables both radio & phone, or phone
only
7. Chk Line: ON Telephone Line Test
9. Remote
Diagnostic 1. Start Diags Remote Diagnostic controlled by the Help
Desk PC
2. Set Comm Prm Phone, Exchange Prefix, Via, Baud, Dial.
