Electrical
Power Packs
Before you connect the terminal power pack to an electrical outlet, check that the on/off power switch on the terminal is off. If the terminal
does not have an on/off switch, check that the power cable connector is removed from the terminal’s power port.
or
When connecting the terminal to a power pack, always connect the plug of the power pack to an electrical wall outlet first. Then connect
the power cable to the terminal’s power port.
The power pack is rated as follows:
Input Voltage: 100 - 240 V AC, 50/60 Hz
Output Voltage: 12 V DC, 2 A
AC Adapter
The AC adapter is designed to ensure your personal safety and to be compatible with this equipment. Please follow these guidelines:
• Do not use the adapter in a high moisture environment. Never touch the adapter when your hands or feet are wet.
• Allow adequate ventilation around the adapter. Avoid locations with restricted airflow.
• Connect the adapter to a proper power source. The voltage and grounding requirements are found on the product case and/or
packaging.
• Do not use the adapter if the cord becomes damaged.
• Do not attempt to service the adapter. There are no serviceable parts inside. Replace the unit if it is damaged or exposed to excess
moisture.
Separate Power Sources
Some peripherals require a separate power source. Before connecting a check reader or similar device, remove the power cable
connector from the terminal’s power port.
Peripherals
Before connecting any peripheral device, turn off power to the terminal and check that the power cable connector is removed from the
terminal’s power port. Turn on power only after you are finished connecting the peripheral device(s). For complete information about
peripheral installation and use, please refer to the user documentation supplied with those devices.
Telecommunication Cord
Caution: To reduce the risk of fire, use only No. 26 AWG or larger UL Listed or CSA Certified Telecommunication Line Cord.
Disconnecting Power
Disconnecting power during a transaction may cause transaction data files that are not yet stored in terminal memory to be lost.
Location – Electrical Considerations
CAUTION: Due to risk of electrical shock or terminal damage, do not use the terminal near water, including a bathtub, wash bowl, kitchen
sink or laundry tub, in a wet basement, or near a swimming pool. Also, avoid using this product during electrical storms.
Avoid locations near electrical appliances or other devices that cause excessive voltage fluctuations or emit electrical noise (for example,
air conditioners, neon signs, high-frequency or magnetic security devices, or electric motors).
Equipment
Repairs
Do not, under any circumstances, attempt any service, adjustments, or repairs on this equipment. Instead, contact your local VeriFone
distributor or service provider for assistance. Failure to comply may void the product warranty.
Location – Environmental Considerations
Do not plug the power pack into an outdoor outlet or operate the terminal outdoors. It is not waterproof or dustproof, and is for indoor use
only. Any damage to the unit from exposure to rain or dust may void your warranty.
Do not use the terminal where there is high heat, dust, humidity, moisture, or caustic chemicals or oils. Keep the terminal away from direct
sunlight and anything that radiates heat, such as a stove or a motor.
Vx670 Certifications and Regulations
FCC Compliance
The following device has been tested and certified as compliant with the regulations and guidelines set forth in Part 68 of FCC
Rules:
Manufacturer: VeriFone, Inc.
Brand, Model: Vx670
Part 15 of FCC Rules
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Part 68 of FCC Rules
This equipment complies with Part 68 of the FCC Rules. On the modem board inside full featured base stations is a label that
contains, among other information, the FCC registration number and ringer equivalence number (REN) for this equipment. If
requested, this information may be provided to the telephone company.
The REN is used to determine the quantity of devices that may be connected to the telephone line. Excessive RENs on the
telephone line may result in the device not ringing in response to an incoming call. In most, but not all areas, the sum of the RENs
should not exceed five (5.0). To be certain of the number of devices that may be connected to the line, as determined by the total
RENs, contact the telephone company to determine the maximum RENs for the calling area.
This terminal cannot be used on telephone-company-provided coin service. Connection to Party Line Service is subject to state
tariffs.
This equipment uses the following USOC jacks: (RJ11C).
An FCC-compliant telephone cord and modular plug is provided with this equipment. This equipment is designed to be connected
to the telephone network or premises wiring using a compatible modular jack that is Part 68 compliant.
If this equipment causes harm to the telephone network, the telephone company will notify you in advance that temporary
discontinuance of service may be required. If advance notice is not practical, the telephone company will notify the customer as
soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary.
The telephone company may make changes in its facilities, equipment, operations, or procedures that could affect the operation of
this equipment. If this happens, the telephone company will provide advance notice in order for you to make the necessary
modifications to maintain uninterrupted service.
If trouble is experienced with this equipment, please contact VeriFone, or your local VeriFone distributor or service center in the
U.S.A. for repair and/or warrant information. If the trouble is causing harm to the telephone network, the telephone company may
request you to remove this equipment from the network until the problem is resolved. No repairs can be done by a customer on this
equipment.
It is recommended that the customer install an AC surge arrestor in the AC outlet to which this device is connected. This is to avoid
damage to the equipment caused by local lightning strikes and other electrical surges.
RF Exposure Information
This device was verified for RF exposure. To comply with Council Recommendation 1999/519/EC and FCC RF exposure
requirements, a minimum separation distance of 20 cm must be maintained between the user’s body and the device, including the
antenna. Any metallic components should be far from this device. Conditions that do not meet these requirements may not comply
with Council Recommendation 1999/519/EC and FCC RF exposure requirements and should be avoided.
Wi-Fi Only
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be
installed and operated with a minimum distance of 2.5cm between the radiator and your body. For additional compliance
information, please reference FCC ID: MXF-F910131.
SAR Labeling
GSM/GPRS
USA
SAR compliance for body worn operating configurations is limited to the specific accessories that have no metallic component in the
assembly. The highest reported SAR values under the FCC ID B32OMNI56XXG are: PMS modes (Part 22) – Body-worn 0.753mW/g,
PCS mode (Part 24) - Body-worn: 0.564mW/g.
Australia Required Warning Statement
Please switch off and do not operate the equipment when in an area with a potentially explosive atmosphere, such as refueling points,
fuel depots or storage areas, chemical plants, and blasting operations.
Recycling: DO NOT DISCARD!
UNIT MUST BE RECYCLED OR DISPOSED OF PROPERLY
For proper disposal instructions go to http://recycle.verifone.com/ Please retain this sheet for future reference.
continued on rear cover
VERIFONE
DRAFT
VERIFONE
DRAFT
Vx670 Declaration of Conformity
DECLARATION OF CONFORMITY
according to ISO/IEC Guide 22 and EN 45014
C0682
______________________________________________________________________
Manufacturer’s Name VeriFone, Inc.
Manufacturer’s Address VeriFone, Inc.
3755 Atherton Road
Rocklin, CA
95765-3701 USA
Declares, that the product
Product Name:V
x670
Model Number: P267-xxx-xx; M267-xxx-xx
Product Options:All
Conforms to the following product specifications:
Safety: IEC 60950-1 (2001-10); EN 60950-1, 2001
EC recommendation 1999/519/EC
EMC: EN 301: 489-1, August 2000, v1.2.1
EN 301: 489-17, September 2000, v1.1.1
CISPR: 22:1997/EN 55022:1998 Class B1
CISPR: 24: 1997+A1+A2/EN55024:1998+A1+A2
IEC 61000-3-2: 1995/EN 6100-3-2:1995+A14
IEC 61000-3-3: 1994/EN 6100-3-3:1995
Telecom: TBR 21:1998 for Analog PSTN Access Products
RF Spectrum Efficiency: EN 301 511, v7.0.1
EN 300 328, July 200v 1.1.1
Wireless: EN300 607-(GSM 11.10.10-1)
SAR: EC recommendation 1999/519 EC
Supplementary Information:
The product herewith complies with the requirements of the Low Voltage Directive 73/23/EEC, the EMC Directive 89/336/EEC,
R&TTE Directive 1999/5/EC (Annex II) and carries the CE marking accordingly.
Dated: 09 March, 2006
Dave Faoro, VP Systems Engineering
European contact for regulatory topics only: VeriFone UK Ltd.
Salamander Quay South
Park Lane, Harefield
Middlesex, UB9 6NY
United Kingdom
Tel: 44-1895-824031
