Verizon Connect 6500C GPS tracking device for fleet applications. User Manual

Verizon Telematics GPS tracking device for fleet applications.

User Manual

9868 Scranton Road, San Diego, CA 92121
Customer Care: 866.227.7323
Light duty plug and play installation:
No harness necessary. Connect the device to the vehicles OBD-II port.
Verify your installation.
Harness installation:
1. Connect harness to device.
2. Connect the other end of harness to the vehicle diagnostic port. Secure the
harness without interfering with the brake or accelerator pedal.
3. Mount the device inside the dash and away from metal obstruction.
4. Verify your installation.
Harness is required for heavy duty vehicles.
Do not connect more than one (1) harness to the device.
Other vehicles or accessories installation, please refer to the complete
6500 Installation Guide.
To verify successful installation:
1. Start the vehicles engine and let idle for 15 minutes.
2. Verify successful installation.
LEDs will dim after 15 minutes.
Contact Customer Care at or call 866.227.7323 for
assistance with installation.
Yellow LED slow blinking
Green LED slow blinking
Yellow & Green LED blink alternately
Yellow & Green LED blink slowly together
Modem connectivity OK
GPS fix acquired and OK
Modem connectivity and GPS OK
Device operating normally
LED pattern Device status
