The Science of Security™
Clifford Responder
PN 904200
Compatible with the
following systems:
20.5X
50.5X
REPLACEMENT TRANSMITTER
Model 904200, 4 Button Responder, SST, Stealth Code Remote
11/06
P/N 904200
MADE IN TAIWAN
©2006 Directed Electronics.
Vista CA 92081
All rights reserved.
1. Ignition ON: Place the key into the ignition and turn
to the ON position or start the engine.
2. Enter PIN number: Enter your PIN number using
the Plainview 2 valet switch.
Note: The Factory default PIN number is written on
the back of the system owner’s guide.
3. Press/hold/release: Immediately PRESS and
HOLD the * button until you hear one chirp and the
Status LED turns on, then RELEASE the * button.
4. PRESS/RELEASE: PRESS and RELEASE the
"blank" button once. Pause until you hear one
chirp.
5. PRESS/RELEASE: PRESS and RELEASE the *
button once. The siren will chirp once as you push
the button.
6. TRANSMIT: Press the button on you new trans-
mitter. The siren will chirp once to confirm it has
received the transmission.
7. TRANSMIT again: Press the button a second time.
The siren will chirp twice to confirm it has learned
your new transmitter.
8. IGNITION OFF: Turn the ignition off and remove
the key: The alarm will chirp three times to indicate
exiting transmitter learn routine.
9. TEST TRANSMITTER: Press the button to verify
that the transmitter is operating the alarm system.
Note: This transmitter auto-learn routine is appli-
cable to specific system/transmitter combinations,
use the following reference guide or consult your
local Clifford dealer for your particular application
904120 transmitter: GP1000T/Arrow 5/Arrow 3/Cyber 2
904065 transmitter: Arrow 5 /Arrow 3 / Cyber 2
904100 transmitter: Concept 100 / Concept 450/
Intelliguard 6000 / Cyber 4
904075 transmitter: All other systems
FCC/ID Notice
This device complies with Part 15 of FCC rules.
Operation is subject to the following conditions: (1)
This device may not cause harmful interference,
and (2) This device must accept any interference
received, including interference that may cause
undesired operation.
HHU, hand held unit
To satisfy FCC RF exposure compliance require-
ments, this device should be used in hand-held, hand
operated configurations only. The device and its
antenna must maintain a separation distance of 20
cm or more from the person’s body, except for the
hand and wrists, to satisfy RF exposure compliance.
This device is designed to be used in a person’s
hands and its operating configurations do not support
normal transmissions while it is carried in pockets or
holsters next to a persons’ body.
CAUTION! Changes or modifications not express-
ly approved by the party responsible for compli-
ance could void the user's authority to operate this
device.
