Getting started
Telephone settings
Telephone operation
Answering system settings
Answering system operation
Appendix
Index

Online user’s manual

Models:

CS6124/CS6124-11/

CS6124-2/CS6124-21/

CS6124-31

w w w.v t e c h c a n ad a . c o m

Congratulations

on purchasing your new VTech product. Before using this telephone, please

read Important safety instructions on page 40 of this manual.

This manual has all the feature operations and troubleshooting necessary

to install and operate your new VTech telephone. Please review this manual

thoroughly to ensure proper installation and operation of this innovative and

feature rich VTech product. For support, shopping, and everything new at

VTech, visit our website at www.vtechcanada.com.

The ENERGY STAR® program (www.energystar.gov) recognizes

and encourages the use of products that save energy and help protect

our environment. We are proud to mark this product with the ENERGY

STAR® label indicating it meets the latest energy efciency guidelines.

Compatible with

Hearing Aid T-Coil

TIA-1083

Telephones identied with this logo have reduced noise and interference

when used with most T-coil equipped hearing aids and cochlear implants.

The TIA-1083 Compliant Logo is a trademark of the Telecommunications

Industry Association. Used under license.

Table of contents

Getting started . . . . . . . . . . . . . . 1

Parts checklist . . . . . . . . . . . . . . . 1

Telephone base and charger

installation.................2

Wall mounting (optional). . . . . . . . 2

Battery installation . . . . . . . . . . . . 3

Battery charging . . . . . . . . . . . . . . 3

Handset layout . . . . . . . . . . . . . . . 4

Telephone base layout . . . . . . . . . 6

Telephone settings. . . . . . . . . . . 7

Using the menu . . . . . . . . . . . . . . 7

Ringer volume (telephone base) . 7

Ringer volume (handset) . . . . . . . 7

Ringer tone..................7

LCD language................8

Clear voicemail. . . . . . . . . . . . . . . 8

Key tone....................9

Set date and time . . . . . . . . . . . . . 9

Home area code. . . . . . . . . . . . . 10

Dial mode..................10

Website....................10

Telephone operation . . . . . . . . 11

Make a call.................11

Predial a call. . . . . . . . . . . . . . . . 11

Answer a call . . . . . . . . . . . . . . . 11

End a call ..................11

Volume....................11

Mute . . . . . . . . . . . . . . . . . . . . . . 11

Call waiting.................11

Temporary ringer silencing. . . . . 12

Temporary tone dialing. . . . . . . . 12

Find handset. . . . . . . . . . . . . . . . 12

Multiple handset use . . . . . . . . . 13

Chain dialing. . . . . . . . . . . . . . . . 13

Redial list ..................14

Review and dial from the

redial list .................14

Delete a redial entry . . . . . . . . . . 14

Directory...................14

Add a directory entry . . . . . . . . . 15

Review and dial from

the directory . . . . . . . . . . . . . . 16

Alphabetical search . . . . . . . . . . 16

Edit a directory entry. . . . . . . . . . 17

Delete a directory entry . . . . . . . 17

About caller ID . . . . . . . . . . . . . . 18

Call log . . . . . . . . . . . . . . . . . . . . 18

Missed call indicator . . . . . . . . . . 19

Memory match . . . . . . . . . . . . . . 19

Review and dial from the

call log...................19

View dialing options . . . . . . . . . . 20

Save a call log entry to

the directory . . . . . . . . . . . . . . 20

Delete the call log entries . . . . . . 21

Call log display screen

messages ................21

Answering system settings. . . 22

Answering system setup. . . . . . . 22

Answer ON/OFF. . . . . . . . . . . . . 22

Call screening. . . . . . . . . . . . . . . 22

Number of rings . . . . . . . . . . . . . 23

Remote access code . . . . . . . . . 23

Message alert tone. . . . . . . . . . . 23

Recording time . . . . . . . . . . . . . . 24

Voice language. . . . . . . . . . . . . . 24

Announcement . . . . . . . . . . . . . . 25

Record your own

announcement . . . . . . . . . . . . 25

Play or delete your own

announcement . . . . . . . . . . . . 25

Answering system operation . . 26

Answering system and

voicemail.................26

Message capacity. . . . . . . . . . . . 26

New message indication. . . . . . . 27

Call intercept. . . . . . . . . . . . . . . . 27

Message playback . . . . . . . . . . . 27

Delete all messages . . . . . . . . . . 28

Record, play or delete memos . . 28

Message window displays . . . . . 29

Remote access. . . . . . . . . . . . . . 30

iii

Table of contents

Appendix..................31

Display screen messages. . . . . . 31

Handset and telephone base

indicators.................32

Handset screen icons. . . . . . . . . 32

Battery ....................33

Troubleshooting . . . . . . . . . . . . . 34

Important safety instructions. . . . 40

Precautions for users of implanted

cardiac pacemakers . . . . . . . . 41

Operating range . . . . . . . . . . . . . 41

Maintenance................41

About cordless telephones . . . . . 42

The RBRC® seal.............42

Limited warranty . . . . . . . . . . . . . 43

FCC, ACTA and IC regulations . 45

Technical specications . . . . . . . 46

Index .....................47

Parts checklist

Your telephone contains the following items. Save your sales receipt and

original packaging in the event warranty service is necessary.

To purchase a replacement battery or power adapter, visit our website at

www.vtechcanada.com or call 1 (800) 267-7377.

Getting started

Telephone base

power adapter

Telephone

line cord

Handset

(1 for CS6124/CS6124-11)

(2 for CS6124-2/CS6124-21)

(3 for CS6124-31)

Telephone base

Battery compartment

cover

(1 for CS6124/CS6124-11)

(2 for CS6124-2/CS6124-21)

(3 for CS6124-31)

Charger and charger

adapter

(1 for CS6124-2/CS6124-21)

(2 for CS6124-31)

Battery

(1 for CS6124/CS6124-11)

(2 for CS6124-2/CS6124-21)

(3 for CS6124-31)

User’s manual

Quick start guide

Use only the power adapters supplied with this product.

The power adapters are intended to be correctly oriented in a vertical or oor

mount position. The prongs are not designed to hold the plug in place if it is

plugged into a ceiling, under-the-table or cabinet outlet.

•

Getting started

Wall mounting (optional)

Your telephone comes ready for tabletop use.

To mount your telephone on the wall:

Position the top hole at the back

of the telephone base against the

top mounting stud [A].

Slide the telephone base down

on the mounting studs [A] and [B]

until it locks into place.

Telephone base

[A]

[B]

Mounting

studs

Telephone base and charger installation

Install the telephone base and charger as shown below.

If you subscribe to digital subscriber line (DSL) high-speed Internet service

through your telephone line, you must install a DSL lter between the telephone

line cord and telephone wall jack. Contact your DSL service provider for more

information about DSL lter.

Telephone base

Telephone

line cord

Electrical outlet

(not controlled

by a wall switch)

Telephone

wall jack

A DSL lter (not

included) is

required if you have

DSL high-speed

Internet service

Telephone base

power adapter

Charger

adapter

Getting started

If the handset will not be used for a long period of time, disconnect and remove

the battery to prevent any possible leakage.

Battery installation

Install the battery as shown below.

CHARGE light remains

on when charging.

Plug the battery connector

securely into the socket.

Place the battery with the wires

inside the battery compartment.

Slide the battery compartment

cover towards the center of the

handset until it clicks into place.

Place the handset in the telephone

base or charger to charge.

If you are on a call in low battery mode, the handset beeps every 50 seconds.

If you place the handset in the telephone base without plugging in the battery,

the screen displays No battery.

•

Battery charging

Once you have installed the battery, the screen indicates the battery status. For

best performance, keep the handset in the telephone base or charger when not

in use. The battery is fully charged after 16 hours of continuous charging.

Battery indicators Battery status Action

The screen is blank, or

displays Place in charger

and ashes.

Battery has very little or no

charge. The handset cannot

be used.

Charge without interruption (at

least 30 minutes).

The screen displays Low

battery and ashes.

Battery has enough charge to

be used for a short time.

Charge without interruption

(about 30 minutes).

The screen displays

HANDSET X and

-:-- --/--.

Battery is charged. To keep the battery charged,

place it in the telephone base

or charger when not in use.

Getting started

Handset layout

CID/VOL- (caller ID/volume)

Press to review the call log when the telephone is

not in use (page 19).

During a call, press to decrease the listening

volume. A double beep sounds at the lowest setting

(page 11).

Press to scroll down while in a menu, or reviewing

the directory, call log or redial list.

When entering numbers or names in the directory,

press to move the cursor to the left.

/FLASH

Press to make or answer a call (page 11).

During a call, press to answer an incoming call when

you receive a call waiting alert (page 11).

CHARGE light

On when the handset is charging in the telephone

base or charger (page 3).

CANCEL

MUTE/DELETE

While on a call, press to mute the microphone (page 11).

While using the dialing keys, press to delete digits and

characters.

While the handset is ringing, press to silence the ringer

temporarily (page 12).

When reviewing the directory, call log or redial list, press to delete the

displayed entry (page 17, 21 or 14).

TONE

While on a call, press to switch to tone dialing

temporarily when using the pulse service (page 12).

Dialing keys

Press to enter numbers or characters.

Press repeatedly to add or remove 1 in front of

the call log entry before dialing or saving it to

the directory (page 20).

Getting started

Handset layout

/VOL+ (directory/volume)

Press to review the directory when the telephone is

not in use (page 16).

During a call, press to increase the listening volume.

A double beep sounds at the highest setting (page 11).

Press to scroll up while in a menu, or reviewing the

directory, call log or redial list.

When entering numbers or names in the directory,

press to move the cursor to the right.

MENU/SELECT

Press to show the menu.

While in a menu, press to choose an item, or save an

entry or setting.

OFF/CANCEL

During a call, press to hang up.

While the handset is ringing, press to silence the ringer

temporarily (page 12).

While the telephone is not in use, press and hold to

erase the missed call indicator (page 19).

While in a menu, press to return to the previous menu.

While in a menu, press and hold to return to idle mode.

While predialing, press to delete digits (page 11).

REDIAL/PAUSE

Press repeatedly to review the redial list (page 14).

While dialing or entering numbers into the directory,

press and hold to insert a dialing pause (pages 11

and 15).

Press repeatedly to show other dialing options when

reviewing a call log entry (page 20).

CANCEL

Getting started

Telephone base layout

/FIND HANDSET

Press once and then

release to page all system

handsets (page 12).

Message window

Shows the number of

messages and other

answering system

information (page 29).

X/DELETE

Press to delete the

message currently playing

(page 27).

When the telephone is

not in use, press twice

to delete all previously

reviewed messages

(page 28).

/ANS ON/OFF

Press to turn the answering

system on or off (page 22).

/PLAY/STOP

Press to play messages

(page 27).

Press to stop message

playback (page 27).

/ /VOLUME

Press to adjust the volume during playback

(page 27).

When the phone is not in use, press to adjust

the telephone base ringer volume (page 7).

IN USE light

Flashes when there is an

incoming call, or another

telephone sharing the

same line is in use.

On when the telephone is

in use, or the answering

system is answering a call.

/SKIP

Press to skip to the next

message (page 27).

/REPEAT

Press to repeat the message

or press twice to play

the previous message

(page 27).

Using the menu

To enter the handset menu:

Press MENU/SELECT when the telephone is not in use.

Press CID or until the screen displays the desired feature menu.

Press MENU/SELECT to enter that menu.

To return to the previous menu, press OFF/CANCEL.

To return to idle mode, press and hold OFF/CANCEL.

Ringer volume (telephone base)

Press /VOLUME or /VOLUME on the telephone base to adjust the ringer

volume when the telephone is not in use. When you set the ringer volume to

zero, the base ringer is off and the system announces, “

Base ringer is off.”

Ringer volume (handset)

You can adjust the ringer volume or turn the ringer off.

Press MENU/SELECT when the handset is not in use.

Press CID or until the screen displays Ringers,

then pressress MENU/SELECT twice.

The screen displays Volume: with the current setting

ashing. Press CID or to choose Off, Low or High.

A sample of each ringer volume plays as you scroll

through the choices.

Press MENU/SELECT to save your selection. You hear a

conrmation tone.

Ringer tone

You can change the handset ringer tone.

Press MENU/SELECT when the handset is not in use.

Press CID or until the screen displays Ringers,

then press MENU/SELECT.

Press CID or until the screen displays

Ringer tone, then press MENU/SELECT.

The screen displays Tone: with the current setting

ashing. PressPress CID or to choose 1, 2, 3, or 4.

A sample of each ringer tone plays as you scroll through

the choices.

Press MENU/SELECT to save your selection. You hear a

conrmation tone.

•

Telephone settings

Ringers

Volume:High

If the ringer volume is set to Off, Ringer off is displayed on the idle screen.

When the ringer volume is set to Off, the handset still rings when you press

/FIND HANDSET.

•

If you turn off the ringer volume, you will not hear ringer

tone samples.

•

Ringers

Ringer tone

Tone: 1

Telephone settings

LCD language

The LCD language is preset to English. You can select English, French or

Spanish to be used in all screen displays.

To select a language:

Press MENU/SELECT when the handset is not in use.

Press CID or until the screen displays Settings,

then press MENU/SELECT twice.

Press CID or to choose English, Français or

Español, then press MENU/SELECT to save your setting.

You hear a conrmation tone.

Clear voicemail

If you subscribe to voicemail service offered by your telephone service

provider, New voicemail and are displayed on the handset when you have

new voicemail messages. Contact your telephone service provider for more

information about using your voicemail service.

After you have listened to all new voicemail messages, the indicators on the

handset turn off automatically.

Use the clear voicemail feature when the telephone indicates that there is

new voicemail but there are none (for example, when you have accessed your

voicemail while away from home). The clear voicemail feature only turns off the

indicators; it does not delete your voicemail messages. As long as you have

new voicemail messages, your telephone service provider continues to send

the signal that turns on the indicators.

To manually turn off these indicators:

Press MENU/SELECT when the handset is not in use.

Press CID or until the screen displays Settings,

then press MENU/SELECT.

Press CID or until the screen displays

Clr voicemail, then press MENU/SELECT. The screen

displays Clear VM icon?

Press MENU/SELECT to conrm your selection. You hear

a conrmation tone.

Your telephone service provider may alert you of new

messages with a stutter (broken) dial tone. Contact your

telephone service provider for details.

Settings

LCD language

Settings

Clr voicemail

Clear VM icon?

Telephone settings

Key tone

You can turn the key tone on or off.

Press MENU/SELECT when the handset is not in use.

Press CID or until the screen displays Settings,

then press MENU/SELECT.

Press CID or until the screen displays Key tone,

then press MENU/SELECT.

Press CID or to choose On or Off, then press

MENU/SELECT to conrm your selection. You hear a

conrmation tone.

Set date and time

The answering system announces the date and time of each message prior

to playing it. Before using the answering system, set the date and time as

follows. If you subscribe to caller ID service, the day, month and time are set

automatically with each incoming call. However, the year must be correct so

that the day of the week can be calculated from the caller ID information.

To change the setting:

Press MENU/SELECT when the handset is not in use.

Press CID or until the screen displays Settings,

then press MENU/SELECT.

Press CID or until the screen displays

Set date/time, then press MENU/SELECT.

When the month is ashing, press CID or until

the screen displays the correct month and then press

MENU/SELECT; or, press the dialing keys (0-9) to enter

the current month (for example, if the month is March,

you must enter 03).

Repeat step 4 to set the correct date and year and then

press MENU/SELECT to advance to time setting.

When the hour is ashing, press CID or until the

screen displays the correct hour and then press

MENU/SELECT; or, press the dialing keys (0-9) to enter

the current hour (for example, if the time is two o’clock,

you must enter 02).

Repeat step 6 to set the correct minute. When AM or PM

is ashing, press CID or to select AM or PM. Press

MENU/SELECT to save your settings. You hear a conrmation tone.

If the date and time are not set when a message is recorded, the system

announces, “Time and date not set,” before each message plays.

When there is a power failure or after battery replacement, the date and time

need to be reset.

•

Settings

Key tone

Settings

Set date/time

Date: 03/25/10

Time: 02:35 PM

Telephone settings

Home area code

If you dial local calls using only seven digits (area code not required), you can

program your home area code so that when you receive a call within your local

area, the telephone number is automatically stored in the call log without the

area code.

To change the setting:

Press MENU/SELECT when the handset is not in use.

Press CID or until the screen displays Settings,

then press MENU/SELECT.

Press CID or until the screen displays

Home area code, then press MENU/SELECT. The

screen displays the current stored home area code.

Use the dialing keys (0-9) to enter the desired home

area code.

Press MUTE/DELETE to delete a digit.

Press and hold MUTE/DELETE to delete all digits.

Press MENU/SELECT to conrm. You hear a conrmation tone.

Dial mode

The default dial mode is tone dialing. If you have pulse (rotary) service, you

need to change the dial mode to pulse dialing.

To change the setting:

Press MENU/SELECT when the handset is not in use.

Press CID or until the screen displays Settings, then press

MENU/SELECT.

Press CID or until the screen displays Dial mode, then press

MENU/SELECT.

Press CID or to choose Tone or Pulse, then press MENU/SELECT to

conrm your selection. You hear a conrmation tone.

Website

Use this feature to view the VTech website address.

Press MENU/SELECT when the handset is not in use.

Press CID or until the screen displays Website, then press

MENU/SELECT. The screen displays the VTech website address.

•

Home area code

___

If, in the future, your telephone service provider requires you to dial the area code

when making a local call, or, if you move to a location that requires it, delete the

home area code you have already programmed following the steps above. After

you have deleted the home area code, _ _ _ appears.

Telephone operation

Make a call

Press /FLASH and then use the dialing keys (0-9) to

dial the telephone number.

Predial a call

Enter the telephone number using the dialing keys (0-9),

then press /FLASH to dial.

Answer a call

Press /FLASH or any of the dialing keys (0-9, TONE or #).

End a call

Press OFF/CANCEL or put the handset to the telephone base or charger.

Volume

During a call, press CID/VOL- or /VOL+ to adjust

the listening volume.

Mute

The mute function allows you to hear the other party but

the other party cannot hear you.

During a call, press MUTE/DELETE on the handset.

The handset screen displays Muted until the mute

function is turned off.

Press MUTE/DELETE again to resume the conversation.

The handset screen temporarily displays Microphone on.

Call waiting

When you subscribe to call waiting service from your telephone service

provider, you hear an alert tone if there is an incoming call while you are on

another call.

Press /FLASH to put the current call on hold and take the new call.

Press /FLASH at any time to switch back and forth between calls.

•

Muted

10:15 PM

12/25

CANCEL

The screen shows the elapsed time as you talk (in hours, minutes

and seconds).

When predialing (preview numbers before dialing), press MUTE/DELETE or

OFF/CANCEL to backspace and delete; press and hold REDIAL/PAUSE to insert

a dialing pause (a P appears).

If the handset is moved out of range while on a call, it will beep three times.

•

Telephone operation

Temporary ringer silencing

When the telephone is ringing, you can temporarily silence the ringer of the

handset or telephone base without disconnecting the call. The next call rings

normally at the preset volume.

To silence the handset ringer:

Press OFF/CANCEL or MUTE/DELETE and then

Ringer muted displays.

To silence the telephone base ringer:

Press /VOLUME once.

Temporary tone dialing

If you have pulse (rotary) service only, you can switch from pulse to tone dialing

temporarily during a call. This is useful if you need to send touch-tone signals to

access your telephone banking or long distance services.

During a call, press TONE .

Use the dialing keys to enter the number. The telephone sends

touch-tone signals.

The telephone automatically returns to pulse dialing mode after you end

the call.

Find handset

Use this feature to nd all system handsets.

To start paging:

Press /FIND HANDSET on the telephone base

once and then release when the telephone is not

in use.

All idle system handsets ring and ** Paging **

ashes on the screen for 60 seconds.

To end paging:

Press /FIND HANDSET on the telephone base

once and then release.

-OR-

Press /FLASH or any of the dialing keys (0-9, TONE or #) on the handset to

stop the paging tone.

•

Ringer muted

10:15 PM

12/25

Do not press and hold /FIND HANDSET for more than four seconds. It may

lead to handset deregistration. If Not registered displays on the handset, refer to

Troubleshooting on page 34 to register the handset to the telephone base.

Telephone operation

Chain dialing

Use this feature to initiate a dialing sequence from numbers stored in the

directory, call log or redial while you are on a call. Chain dialing can be useful

if you wish to access other numbers (such as bank account numbers or access

codes) from the directory, call log or redial list.

To access a number in the directory while on a call:

Press MENU/SELECT twice to select Directory.

Press CID or to scroll to the desired entry.

Press MENU/SELECT to dial the displayed number.

To access a number in the call log while on a call:

Press MENU/SELECT and then press CID or to select Call log.

Press MENU/SELECT and then press CID or to scroll to the

desired entry.

Press MENU/SELECT to dial the displayed number.

To access a number in the redial list while on a call:

Press REDIAL/PAUSE.

Press CID, or REDIAL/PAUSE repeatedly to browse to the

desired entry.

Press MENU/SELECT to dial the displayed number.

You cannot edit a directory entry while on a call. For more details about the

directory, see page 14.

You cannot copy a call log entry into the directory while on a call. For more

details about the call log, see page 18.

You cannot erase a redial entry while on a call. For more details about the

redial memory, see page 14.

Press OFF/CANCEL to exit the directory, call log or redial list when you are on

a call.

•

Multiple handset use (for multi-handset models only)

You can use both handsets at the same time on an outside call.

To share an outside call:

When a handset is already on a call and you would like to join the call, press

/FLASH on the other handset to join the call.

To end the call, press OFF/CANCEL or place the handset in the telephone

base or charger. The call continues until all handsets hang up.

•

Telephone operation

Redial list

The telephone stores the ve most recently dialed numbers.

When there are already ve entries, the oldest entry is

deleted to make room for the new entry.

Entries are shown in reverse chronological order.

Review and dial from the redial list

Press REDIAL/PAUSE when the handset is not in use.

Press CID, or REDIAL/PAUSE repeatedly until the desired

entry displays.

Press /FLASH to dial.

-OR-

Press /FLASH when the handset is not in use.

Press REDIAL/PAUSE and then press CID, or REDIAL/PAUSE

repeatedly until the desired entry displays.

Press MENU/SELECT to dial.

Delete a redial entry

Press REDIAL/PAUSE when the handset is not in use.

Press CID, or REDIAL/PAUSE repeatedly to browse to the

desired entry.

Press MUTE/DELETE to delete the displayed number. You hear a

conrmation tone.

Directory

When entering a name in the directory, the rst letter of each word is

automatically capitalized. Press the number key repeatedly until the desired

character appears.

•

Telephone operation

Review and dial from the directory

Entries are sorted alphabetically.

Press when the handset is not in use. Press CID or

to browse.

When the desired entry displays, press /FLASH to dial.

-OR-

When the handset is not in use, press MENU/SELECT

then scroll to Directory and press MENU/SELECT again.

Press CID or to select Review.

Press MENU/SELECT and then press CID or to browse.

When the desired entry displays, press /FLASH to dial.

Alphabetical search

To start an alphabetical search:

Press when the handset is not in use.

-OR-

When the handset is not in use, press MENU/SELECT then scroll to

Directory and press MENU/SELECT again. Press CID or to select

Review. Press MENU/SELECT again.

Use the dialing keys to enter the letters associated with the name. For

example, if you have entries for Jenny, Jessie, Kristen and Laura in your

directory, press 5 (JKL) once to see Jenny (when Jenny displays, press

CID to see Jessie), twice to see Kristen, or three times to see Laura. If

there is no name entry matching your search, the next closest match in

alphabetical order appears. If necessary, press CID or to browse.

Mike Smith

800-267-7377

Review

Telephone operation

Edit a directory entry

Search for the desired entry in the directory (see Review and dial from the

directory or Alphabetical search on page 16).

When the desired entry appears, press MENU/SELECT. The screen displays

Edit number and the stored number.

If the number has more than 11 digits, the screen only

displays the stored number.

Use the dialing keys to edit the number.

Press MUTE/DELETE to backspace and erase a digit.

Press and hold MUTE/DELETE to erase the entire entry.

Press CID or to move the cursor to the left or right.

Press and hold REDIAL/PAUSE to insert a dialing pause (a P appears).

Press MENU/SELECT to move to the name. The screen

displays Edit name and then the stored name.

Use the dialing keys to enter the name (up to

15 characters). Additional key presses show other

characters of that particular key.

Press MUTE/DELETE to backspace and erase

a character.

Press and hold MUTE/DELETE to erase the entire entry.

Press CID or to move the cursor to the left

or right.

Press MENU/SELECT to conrm. The screen displays Saved and then you

hear a conrmation tone.

Delete a directory entry

Search for the desired entry in the directory (see Review

and dial from the directory or Alphabetical search on

page 16).

When the desired entry appears, press MUTE/DELETE.

The screen displays Delete Contact? and the number.

Press MENU/SELECT to conrm. The screen displays

Deleting ... and then Contact deleted. You hear a

conrmation tone.

•

Edit name

Mike Smith_

Edit number

800-267-7377_

Delete contact?

800-267-7377

Deleting...

Contact deleted

Telephone operation

About caller ID

This product supports caller ID services provided by most telephone service

providers. Caller ID allows you to see the name, number, date and time of

calls. Some names and numbers may not show because they are not available

or blocked by the caller. The caller ID information shows after the rst or

second ring.

Information about caller ID with call waiting

Caller ID with call waiting lets you see the name and telephone number of the

caller before answering the telephone, even while on another call.

It may be necessary to change your telephone service to use this feature.

Contact your telephone service provider if:

You have both caller ID and call waiting, but as separate services (you may

need to combine these services).

You have only caller ID service, or only call waiting service.

You do not subscribe to caller ID or call waiting services.

There are fees for caller ID services. In addition, services may not be available

in all areas.

Call log

If you subscribe to caller ID service, information about each caller will appear

after the rst or second ring. If you answer a call before the caller information

appears on the screen, it will not be saved in the call log.

The call log stores up to 30 entries. Each entry has up to 24 digits for the

phone number and 15 characters for the name. If the telephone number has

more that 15 digits, only the last 15 digits appear. If the name has more than

15 characters, only the rst 15 characters are shown and saved in the call log.

You can review, redial and copy an entry into the directory.

Entries appear in reverse chronological order.

When the call log is full, the oldest entry is deleted to make room for new

incoming call information.

XX missed call(s) displays when there are new call log entries that have not

been reviewed.

Call log empty displays when there are no records in the call log.

Call log entries are shared by all system handsets (for multi-handset models

only). Any deletions made on one handset are reected on the other handset.

Only one handset can review the call log at a time (for multi-handset models

only). If a handset tries to enter the call log while another handset is already in

it, Not available displays.

•

For call log entries with numbers between 16 and 24 digits, in order to view the

entire number, you must save the entry to the directory (see page 20).

If the phone number has more than 24 digits, it will not be saved or shown in

the call log.

•

Telephone operation

Missed call indicator

When there are calls that have not been reviewed in the call

log, the handset displays XX missed calls.

Each time you review a call log entry marked NEW, the

number of missed calls decreases by one.

When you have reviewed all the missed calls, the missed call

indicator no longer displays.

If you do not want to review the missed calls one by one,

press and hold OFF/CANCEL on the idle handset to erase the

missed call indicator. All the entries are then considered old.

Memory match

When the incoming telephone number matches the last seven digits of a

telephone number in your directory, the screen displays the stored name of the

directory entry.

For example, if Linda Jones calls, her name appears as Linda if this is how you

entered it into your directory.

Review and dial from the call log

Press CID when the handset is not in use.

Press CID or to browse.

When the desired entry displays, press /FLASH to call.

-OR-

Press MENU/SELECT when the handset is not in use. Press CID or to

select Call log.

Press MENU/SELECT twice and then press CID or to browse.

When the desired entry displays, press /FLASH to call.

xx missed calls

10:15 PM

12/25

Mike Smith

267-7377

10:15 PM

12/25

NEW

The number shown in the call log is in the format sent by the telephone service

provider. It usually delivers 10-digit telephone numbers (area code plus phone

number). If the last seven digits of the incoming telephone number does not

match a number in your directory, the name appears as it is delivered by the

telephone service provider.

You hear a double beep when you reach the beginning or end of the call log.

Telephone operation

View dialing options

Although the call log entries received have 10 digits (the area code plus the

seven-digit number), in some areas, you may dial only the seven digits, or a 1

plus the seven digits, or a 1 plus the area code plus the

seven digits. You can change the number of digits that

you dial from or store to the directory.

While reviewing the call log, press # (pound key)

repeatedly to show different dialing options for local and

long distance numbers before dialing or saving

the telephone number in the directory.

Press 1 repeatedly if you need to add or remove

1 in front of the telephone number before dialing

or saving it in the directory.

When the number is shown in the correct format

for dialing, press /FLASH on the handset to call

the number.

Save a call log entry to the directory

When in the call log (see Review and dial from the call log on page 19),

press CID or to browse.

When the desired entry appears, press MENU/SELECT.

The screen displays Edit number and the stored number.

Use the dialing keys to edit the number.

Press MUTE/DELETE to backspace and erase a digit.

Press and hold MUTE/DELETE to erase the entire entry.

Press CID or to move the cursor to the left or right.

Press and hold REDIAL/PAUSE to insert a dialing pause (a P appears).

Press MENU/SELECT to move to the name. The screen

displays Edit name and then the stored name.

Use the dialing keys to enter the name (up to

15 characters). Additional key presses show other

characters of that particular key.

Press MUTE/DELETE to backspace and erase

a character.

Press and hold MUTE/DELETE to erase the entire entry.

Press CID or to move the cursor to the left

or right.

Press MENU/SELECT to conrm. The screen displays Saved and then you

hear a conrmation tone.

•

If you have programmed the home area code (see page 10), only the last seven

digits of the incoming phone numbers from that area code will be displayed while

reviewing the call log. Press # repeatedly to display all possible dialing options.

Press # 1-800-267-7377

Press # 267-7377

Press # 1-267-7377

Press # 800-267-7377

-OR-

Press 1 1-800-267-7377

Press 1 800-267-7377

Mike Smith

800-267-7377

10:15 PM

12/25

Edit number

800-267-7377_

Edit name

Mike Smith_

f there is no caller ID information, the screen displays Unable to save and you hear

a double beep.

Telephone operation

Delete the call log entries

To delete an entry:

When in the call log, press CID or to browse.

Press MUTE/DELETE to delete the selected entry. The screen displays

Deleting... and then you hear a conrmation tone.

To delete all entries:

Press MENU/SELECT when the handset is not in use. Press CID or to

select Call log.

Press MENU/SELECT and then press CID or to

select Del all calls.

Press MENU/SELECT and the screen displays

Delete all?

Press MENU/SELECT to conrm. The screen displays

Deleting... and then you hear a conrmation tone.

Displays When

PRIVATE NAME The caller is blocking the name information.

PRIVATE NUMBER The caller is blocking the telephone number information.

PRIVATE CALLER The caller is blocking the name and number information.

UNKNOWN NAME This caller’s name is unavailable.

UNKNOWN NUMBER This caller’s number is unavailable.

UNKNOWN CALLER No call information is available about this caller.

LONG DISTANCE

-OR-

L (before the caller’s number)

It is a long distance call.

Delete all?

Call log display screen messages

Answering system setup

Most of the answering system settings are changed with a system handset.

Answer ON/OFF

The answering system must be turned on to answer and record messages.

When the answering system is turned on, the /ANS ON/OFF light on the

telephone base turns on and ANS ON displays on the handset.

To turn on or off with the telephone base:

Press /ANS ON/OFF to turn the built-in answering system on

or off. When the answering system is turned on, it announces,

“Calls will be answered.”

When the answering system is turned

off, it announces,

“Calls will not be answered.”

To turn on or off with a handset:

Press MENU/SELECT when the handset is not in use.

Press CID or to select Answering sys, then press MENU/SELECT.

Press CID or to select Answer ON/OFF, then press MENU/SELECT.

Press CID or to choose On or Off, then press MENU/SELECT to

conrm your selection. You hear a conrmation tone.

Call screening

You can hear incoming messages at the telephone base while they are being

recorded.

To turn this feature on or off:

Press MENU/SELECT when the handset is not in use.

Press CID or to select Answering sys, then press MENU/SELECT.

Press CID or to select Ans sys setup, then press MENU/SELECT.

Press MENU/SELECT to select Call screening.

Press CID or to choose On or Off, then press MENU/SELECT to conrm

your selection. You hear a conrmation tone.

•

Answering system settings

If call screening is set to On while the answering system is answering a call,

press /PLAY/STOP on the telephone base to temporarily turn off call

screening; or, press /VOLUME to temporarily decrease the volume.

If call screening is set to Off while the answering system is answering a call,

press /PLAY/STOP or /VOLUME once on the telephone base to

temporarily turn on the call screening.

•

Answering system settings

Number of rings

You can choose from two, three, four, ve or six rings; or toll saver. With toll

saver selected, the answering system answers after two rings when you have

new messages, and after four rings when you have no new messages. This

enables you to check for new messages and avoid paying unnecessary long

distance charges if you are calling from outside your local area.

Press MENU/SELECT when the handset is not in use.

Press CID or to select Answering sys, then press MENU/SELECT.

Press CID or to select Ans sys setup, then press MENU/SELECT.

Press CID or to select # of rings, then press MENU/SELECT.

Press CID or to choose from 6, 5, 4, 3, 2 or Toll saver, then press

MENU/SELECT to conrm your selection. You hear a conrmation tone.

Remote access code

A two-digit security code is required to access the answering system remotely

from any touch-tone telephone. The preset code is 19. You can set the code

from 00 to 99.

Press MENU/SELECT when the handset is not in use.

Press CID or to select Answering sys, then press MENU/SELECT.

Press CID or to select Ans sys setup, then press MENU/SELECT.

Press CID or to select Remote code, then press MENU/SELECT.

Press the dialing keys (0-9) to enter the code or CID or to select from

00 to 99, then press MENU/SELECT to conrm your selection. You hear a

conrmation tone.

Message alert tone

This telephone beeps every 10 seconds to alert you of new messages. The

tone stops when all new messages have been reviewed. Press MENU/SELECT

when the handset is not in use.

To turn this feature on or off:

Press MENU/SELECT when the handset is not in use.

Press CID or to select Answering sys, then press MENU/SELECT.

Press CID or to select Ans sys setup, then press MENU/SELECT.

Press CID or to select Msg alert tone, then press MENU/SELECT.

Press CID or to choose On or Off, then press MENU/SELECT to

conrm your selection. You hear a conrmation tone.

The answering system must be turned on for the message alert tone

to function.

Press any key on the telephone base (except /FIND HANDSET) to temporarily

silence the message alert tone.

•

Answering system settings

Recording time

You can set the recording time for each incoming message.

Press MENU/SELECT when the handset is not in use.

Press CID or to select Answering sys, then press MENU/SELECT.

Press CID or to select Ans sys setup, then press MENU/SELECT.

Press CID or to select Recording time, then press MENU/SELECT.

Press CID or to choose from 3 minutes, 2 minutes or 1 minute,

then press MENU/SELECT to conrm your selection. You hear a

conrmation tone.

Voice language

The voice prompt language is preset to English. You can select English or

French to be used for the voice prompts in your answering system.

Press MENU/SELECT when the handset is not in use.

Press CID or to select Answering sys, then press MENU/SELECT.

Press CID or to select Ans sys setup, then press MENU/SELECT.

Press CID or to select Voice language, then press MENU/SELECT.

Press CID or to select choose English or Français, then press

MENU/SELECT to conrm your selection. You hear a conrmation tone.

Answering system settings

Announcement

The telephone is preset with a greeting that answers calls with

“Hello, please

leave a message after the tone.”

You can use this preset announcement, or

replace it with your own.

Record your own announcement

Press MENU/SELECT when the handset is not in use.

Press CID or to select Answering sys, then

press MENU/SELECT.

Press MENU/SELECT to select Announcement.

The screen displays Play [2] Del [3] Rec [7] and the

handset announces,

“To play, press 2. To record,

press 7.”

Press 7 to record.

The screen displays Record in 5 sec (it counts down to

one second) and the handset announces,

“Record after

the tone. Press 5 when you are done.”

After the tone,

speak towards the microphone of the handset.

The screen displays Recording... Stop [5]. Press 5

when nished.

The screen displays Play [2] Del [3] Rec [7] again.

Press 2 to play the recorded announcement; or 7 to

record again if desired. Press 5 to stop the playback at

any time.

Play or delete your own announcement

Press MENU/SELECT when the handset is not in use.

Press CID or to select Answering sys, then

press MENU/SELECT.

Press MENU/SELECT to select Announcement.

The screen displays Play [2] Del [3] Rec [7] and the

handset announces,

“To play, press 2. To record,

press 7.”

Press 2 to play. The screen displays Playing... Stop

[5]. Press 5 to stop the playback at any time.

Press 3 to delete your own recorded announcement.

The screen displays Annc deleted and the handset

announces, “Announcement deleted.” You hear a

conrmation tone.

•

Play Del Rec

[2] [3] [7]

Playing... Stop

[5]

Play Del Rec

[2] [3] [7]

Record in 5 sec

Recording... Stop

[5]

Announcement

Play Del Rec

[2] [3] [7]

Your announcement can be up to 90 seconds in length.

Announcements shorter than two seconds will not

be recorded.

•

Annc deleted

When your announcement is deleted, calls are answered

with the preset announcement.

•

Answering system operation

Answering system and voicemail

Your telephone has separate indicators for two different types of voice

messages: those left on its built-in answering system and those left at your

service provider’s voicemail. Your telephone’s built-in answering system

messages and voicemail messages are separate. Each alerts you to new

messages differently.

If and New voicemail display on the handset, your telephone service

provider is indicating that it has new voicemail for you. To listen to your

voicemail, you typically dial an access number provided by your telephone

service provider, followed by a security code or PIN.

If and XX new messages display on the handset and the message

window on the telephone base ashes, there are new messages recorded

on the built-in answering system. Press MENU/SELECT twice on the handset

(page 27) or /PLAY/STOP on the telephone base (page 27) to listen.

Some service providers bundle or combine multiple services like voicemail

and call waiting, so you may not be aware that you have voicemail. To check

what services you have and how to access them, contact your telephone

service provider.

To use your voicemail service rather than your answering system, turn off your

answering system. To use your answering system rather than your voicemail

service, contact your telephone service provider to deactivate your voicemail

service. You can also use your telephone answering system and voicemail

together by setting your built-in answering system to answer before voicemail

answers as described below. To learn how to program your voicemail settings,

contact your telephone service provider. Then, if you are on a call, or if the

answering system is busy recording a message and you receive another call,

the second caller can leave a voicemail message.

Set your answering system to answer calls at least two rings earlier than

your voicemail is set to answer. For example, if your voicemail answers after

six rings, set your answering system to answer after four rings. Some

voicemail providers may program the delay before answering calls in seconds

instead of rings. In this case, allow six seconds per ring when determining the

appropriate setting.

Message capacity

The answering system can record and store up to 99 messages. Each

message can be up to three minutes in length (see page 24 to change the

length). The total storage capacity for the announcement, messages and

memos is approximately 11 minutes. The actual recording time depends on

individual message characteristics. Messages remain available for replay until

you delete them.

•

Answering system operation

New message indication

When there are new answering system messages, and XX new messages

display on the handset and the message window on the telephone base

ashes. When you are reviewing a new message, and NEW display on

the handset.

If the message alert tone is turned on, the telephone base beeps every

10 seconds when there are messages that have not been reviewed.

Call intercept

If you want to talk to the person whose message is being recorded, press

/FLASH on the handset.

Message playback

If you have new messages, the telephone plays only the new messages (oldest

rst). If there are no new messages, the telephone plays back all messages

(oldest rst).

When playback begins, you hear the total number of messages followed

by the day and time of the message. After the last message, the telephone

announces,

“End of messages.”

To play messages with the telephone base:

Press /PLAY/STOP when the telephone is not in use.

Options during playback:

Press /VOLUME or /VOLUME to adjust the speaker volume.

Press /SKIP to skip to the next message.

Press /REPEAT to repeat the message currently playing. Press /REPEAT

twice to listen to the previous message.

Press X/DELETE to delete the current message. The system advances to

the next message.

Press /PLAY/STOP to stop.

To play messages with a handset:

Press MENU/SELECT twice when the telephone is not

in use. When you have messages, the screen displays

Repeat [4] Del [3] Skip [6] and the handset announces the

total number of messages.

Options during playback:

Press CID/VOL- or /VOL+ to adjust the volume.

Press 6 to skip to the next message.

Press 4 to repeat the message currently playing. Press 4 twice to listen to

the previous message.

Press 3 to delete the current message. The system advances to the

next message.

Press 5 to stop.

•

During message playback, if there is an incoming call or another handset makes

a call, message playback will be stopped.

•

Repeat Del Skip

[4] [3] [6]

Answering system operation

Delete all messages

To delete all messages with the telephone base:

Press X/DELETE when the phone is not in use.

The telephone announces, “To delete all old messages, press DELETE

again.” Press X/DELETE again. All previously heard messages are erased

and the telephone announces, “All old messages deleted.”

To delete all messages with a handset:

Press MENU/SELECT when the handset is not in use.

Press CID or to select Answering sys, then press MENU/SELECT.

Press CID or to select Delete all old, then press MENU/SELECT.

The handset shows Delete all msg?

Press MENU/SELECT to conrm your selection. The screen displays

Deleting ... and then No old messages. You hear a conrmation tone.

Record, play or delete memos

Memos are your own recorded messages used as reminders for yourself or

others using the same answering system. You can record your own memos

using a system handset. Playback and delete them in the same way as

incoming messages.

To record a memo:

Press MENU/SELECT when the handset is not in use.

Press CID or to select Answering sys, then press MENU/SELECT.

Press CID or to select Record memo, then press MENU/SELECT.

The screen displays Record in 5 sec (it counts down to one second) and

the handset announces,

“Record after the tone. Press 5 when you are done.”

After the tone, speak towards the microphone of the handset.

Press 5 when nished recording. The handset announces,

“Recorded.”

If you record a memo when the answering system memory is full, “Memory is

full” will be announced.

Each memo can be up to three minutes in length and memos shorter than two

second are not recorded.

When the answering system has less than three minutes of recording time left,

“Less than three minutes to record” is announced at the telephone base and the

handset displays Rec mem low.

When F and number of messages are ashing alternately in the message

window and the handset displays Rec mem full, the memory is full. Delete

some messages to make room for more.

•

You can only delete old messages, which are messages you have played.•

Answering system operation

When the memory is full, the answering system answers incoming calls after

10 rings and announces, “Memory is full. Enter the remote access code.”

•

Window display Description

0No messages.

1-99 Total number of old messages recorded.

Current message number during old message playback.

0-99 (ashing) Total number of new messages recorded, or the current message

number during new message playback.

The clock needs to be set.

1-99 & F (alternating) Memory is full with total number of messages recorded.

1-8 Telephone base speaker volume level while adjusting.

-- The telephone is busy with a call or in the call log

The answering system is being accessed.

0-6 Telephone base ringer level while adjusting.

Message window displays

Answering system operation

Remote access

A two-digit security code is required to access the answering system remotely

from any touch-tone telephone. The preset code is 19; see Remote access

code on page 23 to change it.

Dial your telephone number from any touch-tone telephone.

When the system plays your announcement, enter the two-digit

security code.

Then you can enter one of the following remote commands.

Hang up or press 8 to end the call.

Command Function

1Play all messages.

2Play only new messages.

3Delete the current message (during playback).

33 Delete all old messages.

4Repeat the current message (during playback).

44 Skip to the previous message (during playback).

5Stop.

*5 Hear a list of remote commands.

6Skip to the next message (during playback).

*7 Record a new announcement.

8End the call.

0Turn the answering system on or off.

If you do not press any key after you enter the remote access code, all new

messages play. If there are no new messages, all old messages play.

Once the new messages have played, the telephone announces the help menu

options. If you do not press any key within 20 seconds, the remote access call

automatically disconnects.

When the answering system is turned off, the telephone answers after 10 rings,

and announces, “Please enter your remote access code.”

•

Appendix

Annc deleted Your recorded announcement is deleted.

Call log empty There are no call log entries.

Directory empty There are no directory entries.

Directory full The directory is full.

Ended X:XX:XX You have just ended a call.

Incoming call There is an incoming call.

Line in use A system handset or another telephone on the same line is in use.

Low battery The battery needs to be recharged.

Microphone on MUTE is turned off and the person on the other end can hear you.

Muted You have turned off the handset microphone. The other party cannot

hear you but you can hear the other party.

New voicemail There are new voicemail message(s) from the telephone service

provider.

No battery No battery is installed. Follow the directions for battery installation on

page 3 to install the battery before charging.

No line There is no telephone line connected.

No message There are no messages in the answering system.

No signal Communication between the handset and the telephone base is lost

during a call.

Not available One handset is reviewing the call log and the other handset tries to

review it; or one handset is accessing the answering system and the

other handset tries to access it.

Not registered The handset may be deregistered from the telephone base. Follow the

instructions on page 34 to register the handset to the telephone base.

Number repeated The telephone number entered is already stored in the directory.

Out of range or

no pwr at base

The handset cannot communicate with the telephone base. Check the

telephone base power connection or move the handset closer to the

telephone base.

Phone X:XX:XX The handset is on a call.

Place in charger The battery is very low. Place the handset in the telephone base or

charger for recharging.

Rec mem full The answering system has no recording time left.

Rec mem low The answering system has less than three minutes recording time left.

Record in X sec You can record your own announcement or memo after the tone

is played.

Ringer muted The handset ringer is muted temporarily during an incoming call.

Ringer off The handset ringer is turned off.

Saved Your selection has been saved.

XX missed calls There are calls that have not been reviewed in the call log.

XX new messages There are new messages in the answering system.

** Paging ** All system handsets are being paged.

Display screen messages

Appendix

Battery status - ashes when the battery is low and needs charging.

Battery status - animates when the battery is charging.

Battery status - becomes solid when the battery is fully charged.

New voicemail - indicates you have received new voicemail message(s) from

the telephone service provider.

New answering system message - indicates you have new message(s) on

the built-in answering system.

NEW

New call log entry or new answering system message - indicates you have

new missed call(s) in the call log or new message(s) on the built-in answering

system.

ANS ON Answering system is turned on.

Message number - indicates the number of messages currently playing and

total number of messages recorded.

Handset screen icons

Handset and telephone base indicators

Handset light

CHARGE On when the handset is charging in the telephone base or charger.

Telephone base light

IN USE On when the telephone is in use.

On when the answering system is answering a call.

Flashes quickly when there is an incoming call.

Flashes when another telephone sharing the same line is in use.

/ANS ON/OFF On when the answering system is turned on.

1/13

Appendix

Battery

It takes up to 16 hours for the battery to be fully charged. When it is fully charged,

you can expect the following performance:

Operation Operating time

While in use (talking*) Seven hours

While not in use (standby**) Five days

*Operating times vary depending on your actual use and the age of the battery.

**Handset is not charging or in use.

The battery needs charging when:

A new battery is installed in the handset.

The handset beeps every 50 seconds while on a call.

The handset beeps and Low battery displays on the handset.

Place in charger displays on the handset.

A battery is properly installed and the screen is blank.

CAUTION:

To reduce the risk of re or injury, read and follow these instructions:

Use only the battery(ies) provided or equivalent. To order a replacement, visit our

website at www.vtechcanada.com or call 1 (800) 267-7377.

Do not dispose of the battery(ies) in a re. Check with local waste management codes

for special disposal instructions.

Do not open or mutilate the battery(ies). Released electrolyte is corrosive and may

cause burns or injury to the eyes or skin. The electrolyte may be toxic if swallowed.

Exercise care in handling batteries in order not to create a short circuit with

conductive materials.

Charge the battery(ies) provided with or identied for use with this product only in

accordance with the instructions and limitations specied in this manual.

Observe proper polarity orientation between the battery and metallic contacts.

To prevent re or shock hazard, do not expose this product to water or any type

of moisture.

•

Appendix

Troubleshooting

If you have difculty with your telephone, please try the suggestions below.

For customer service, visit our website at www.vtechcanada.com or call

1 (800) 267-7377.

My telephone does not work at all.

Make sure the battery is installed and charged correctly (pages 3). For optimum daily

performance, return the handset to the telephone base or charger after use.

Make sure the power adapter is securely plugged into an outlet not controlled by a

wall switch.

Make sure the telephone line cord is plugged rmly into the telephone base and the

wall jack.

Unplug the electrical power to the telephone base. Wait for approximately 15 seconds,

then plug it back in. Allow up to one minute for the cordless handset and telephone base

to synchronize.

Charge the battery in the handset for up to 16 hours.

If the battery is completely depleted, it may take up to 30 minutes to charge the handset

before Low battery appears on the screen (page 3).

Remove and install the battery again. If that still does not work, it may be necessary to

purchase a new battery.

Disconnect the telephone base from the telephone wall jack and plug in a working

telephone. If the other telephone does not work, the problem is probably in the wiring or

the local telephone service. Contact your telephone service provider.

There is no dial tone.

First, try all the above suggestions.

Move the handset closer to the telephone base. It may be out of range.

The telephone line cord may be defective. Install a new telephone line cord.

Disconnect the telephone base from the telephone wall jack and connect a different

telephone. If there is no dial tone on this telephone either, the problem is in your wiring or

local telephone service. Contact your telephone service provider.

I cannot dial out.

First, try all the above suggestions.

Make sure there is a dial tone before dialing. It is normal if the handset takes a second or

two to synchronize with the telephone base before producing a dial tone. Wait an extra

second before dialing.

If other telephones in your home are having the same problem, the problem is in the

wiring or local telephone service. Contact your telephone service provider (charges

may apply).

Eliminate any background noise. Mute the cordless handset before dialing, or dial from

another room in your home with less background noise.

Not registered appears on the handset and it does not work at all.

The handset may be deregistered from the telephone base. Follow the steps below to

1. Remove the handset from the telephone base.

2. Press and hold /FIND HANDSET on the telephone base for about four seconds until

the red IN USE light turns on.

3. Then press # (pound key) on the handset. It displays Registering... and it takes about

60 seconds to complete the registration. The handset displays Registered for a few

seconds and you hear a conrmation tone when the registration process completes.

•

Appendix

Low battery shows on the handset screen.

Place the handset in the telephone base or charger for recharging.

Remove and install the battery again and use it until fully depleted, then charge the

handset in the telephone base or charger for up to 16 hours.

If the above measures do not correct the problem, replace the battery.

The battery does not charge in the handset or the handset battery does not

accept charge.

Make sure the handset is placed in the telephone base or charger correctly. The

CHARGE light on the handset should be on.

Remove and install the battery again, then charge for up to 16 hours.

If the handset is in the telephone base or charger but the CHARGE light on the handset is

not on, refer to The CHARGE light is off below.

If the battery is completely depleted, it may take up to 30 minutes to charge the handset

before Low battery appears on the screen (page 3).

Purchase a new battery. Refer to the Battery section (page 33).

The CHARGE light is off.

Clean the charging contacts on the handset, telephone base and charger each month

with a pencil eraser or a dry non-abrasive fabric.

Make sure the power adapter and telephone line cord are plugged in correctly

and securely.

Unplug the power adapter. Wait for 15 seconds before plugging it back in. Allow up to one

minute for the handset and telephone base to reset.

The telephone does not ring when there is an incoming call.

Make sure the ringer volume of the handset and telephone base are not set to off (page 7).

Make sure the telephone line cord and power adapter are plugged in properly (page 2).

The handset may be too far from the telephone base. Move it closer to the telephone base.

There may be too many extension phones on the telephone line to allow all of them to ring

simultaneously. Unplug some of them.

If other telephones in your home are having the same problem, the problem is in the wiring

or local telephone service. Contact your telephone service provider (charges may apply).

Other electronic products such as HAM radios and other DECT phones can cause

interference with your cordless phone. Try installing your phone as far away as possible

from these types of electronic devices.

Test a working telephone at the telephone wall jack. If another telephone has the same

problem, the problem is in the telephone wall jack. Contact your telephone service provider

(charges may apply).

The telephone line cord may be defective. Install a new telephone line cord.

Remove and install the battery again and place the handset in the telephone base.

Wait for the handset to synchronize with the telephone base. Allow up to one minute for

this to take place.

My handset beeps and is not performing normally.

Make sure the power cord is securely plugged into the telephone base. Plug the telephone

base into a different working electrical outlet not controlled by a wall switch.

Move the handset closer to the telephone base. It may be out of range.

•

Troubleshooting

Appendix

Reset the telephone base by unplugging the electrical power to the base. Wait for 15

seconds and plug it back in again. Allow up to one minute for the cordless handset and

the telephone base to synchronize.

Other electronic products such as HAM radios and other DECT phones can cause

interference with your cordless phone. Try installing your phone as far away as possible

from these types of electronic devices.

There is interference during a telephone conversation.

My calls fade out when I am using the cordless handset.

The handset may be out of range. Move it closer to the telephone base.

If you subscribe to high-speed Internet service (DSL - digital subscriber line) through

your telephone line, you must install a DSL lter between the telephone line cord and

the telephone wall jack. The lter prevents noise and caller ID problems caused by DSL

interference. Contact your DSL service provider for more information about DSL lters.

Appliances or other cordless telephones plugged into the same circuit as the

telephone base can cause interference. Try moving the appliance or telephone base to

another outlet.

Other electronic products such as HAM radios and other DECT phones can cause

interference with your cordless phone. Try installing your phone as far away as possible

from these types of electronic devices.

If your telephone is plugged in with a modem or a surge protector, plug the telephone

(or modem/surge protector) into a different location. If this doesn’t solve the problem,

relocate your telephone or modem farther apart from each other, or use a different

surge protector.

The location of your telephone base can impact the performance of your cordless phone.

For better reception, install the telephone base in a centralized location within your home

or ofce, away from walls or other obstructions. In many environments, elevating the

telephone base improves overall performance.

Disconnect the telephone base from the telephone wall jack and plug in a corded

telephone. If calls are still not clear, the problem is probably in the wiring or local

telephone service. Contact your telephone service provider (charges may apply).

If other telephones in your home are having the same problem, the problem is in the

wiring or local telephone service. Contact your telephone service provider (charges

may apply).

I hear other calls when using the telephone.

Disconnect the telephone base from the telephone wall jack. Plug in a different

telephone. If you still hear other calls, the problem is probably in the wiring or local

telephone service. Contact your telephone service provider.

I hear noise on the cordless handset and the keys do not work.

Make sure the telephone line cord is plugged in securely.

My caller ID features are not working properly.

Caller ID is a subscription service. You must subscribe to this service from your

telephone service provider for this feature to work on your telephone.

The caller may not be calling from an area which supports caller ID.

Both your and the caller’s telephone service providers must use equipment compatible

with the caller ID service.

The caller ID information shows after the rst or second ring.

•

Troubleshooting

Appendix

Troubleshooting

If you subscribe to high-speed Internet service (DSL - digital subscriber line) through

your telephone line, you must install a DSL lter between the telephone line cord and

the telephone wall jack. The lter prevents noise and caller ID problems caused by DSL

interference. Contact your DSL service provider for more information about DSL lters.

The telephone does not receive caller ID or the telephone does not show

caller ID during call waiting.

Make sure you subscribe to caller ID with call waiting features provided by your

telephone service provider.

The caller may not be calling from an area which supports caller ID.

Both your and the caller’s telephone service providers must use equipment compatible

with caller ID service.

If you subscribe to high-speed Internet service (DSL - digital subscriber line) through

your telephone line, you must install a DSL lter between the telephone line cord and

the telephone wall jack. The lter prevents noise and caller ID problems caused by DSL

interference. Contact your DSL service provider for more information about DSL lters.

Out of range or no pwr at base shows on the handset screen.

The handset may be out of range. Move it closer to the telephone base.

Make sure the power cord is securely plugged into the telephone base. Use a working

electrical outlet not controlled by a wall switch.

Reset your telephone by unplugging the power adapter from the telephone base.

Disconnect the battery from the cordless handset. Wait for 15 seconds, then plug in the

power adapter and install the battery again. Place the handset in the telephone base and

allow up to one minute for the handset and telephone base to synchronize.

Other electronic products such as HAM radios and other DECT phones can cause

interference with your cordless phone. Try installing your phone as far away as possible

from these types of electronic devices.

and New voicemail show on the handset display and I don’t know why.

Your telephone has voicemail indication that is separate from the built-in answering

system. If and New voicemail appear on the handset, your telephone has received

a signal from your telephone service provider that you have a voicemail message

waiting for you to retrieve from them. Contact your telephone service provider for more

information on how to access your voicemail.

I cannot retrieve voicemail messages.

Your telephone has both a built-in answering system and voicemail indication. They are

independent features and each alerts you to new messages differently (page 26). If you

subscribe to voicemail service from your telephone service provider (charges may apply),

contact your telephone service provider for more information on how to access your

voicemail.

The answering system does not answer after the correct number of rings.

Make sure the answering system is on. When the answering system is on, the

/ANS ON/OFF light on the telephone base should be lit and ANS ON should show on

the handset.

If toll saver is selected, the number of rings changes to two when there are new

messages waiting (page 23).

If the memory is full or if the answering system is off, the answering system answers after

10 rings.

•

Appendix

In some cases, the answering system is affected by the ringing system used by your

telephone service provider.

If you subscribe to voicemail service, change the number of rings so that your answering

system answers before your voicemail answers (page 26). To determine how many rings

activate your voicemail, please contact your telephone service provider.

If there is a fax machine connected to the same telephone line, try disconnecting the

fax machine. If that solves the problem, consult your fax machine documentation for

information on compatibility with answering systems.

I cannot hear any instruction from the handset when I try to record, play or

delete my own announcement.

The handset does not have a speakerphone. When recording, playing or deleting your

own announcement, the instructions are announced through the handset receiver. Make

sure you place the handset receiver close to your ear.

The outgoing announcement is not clear.

When recording the announcement, make sure you speak in a normal tone of voice

towards the microphone of the handset.

Make sure there is no background noise when recording.

The answering system does not record messages.

Make sure the answering system is on.

When the answering machine memory is full, it does not record new messages until

some old messages are deleted.

If you subscribe to voicemail service, change the number of rings so that your answering

system answers before your voicemail answers (page 26). To determine how many rings

activate your voicemail, please contact your local telephone service provider.

If there is a fax machine connected to the same telephone line, try disconnecting the

fax machine. If that solves the problem, consult your fax machine documentation for

information on compatibility with answering systems.

I cannot hear any messages from the handset.

The handset does not have a speakerphone. During message playback, the messages

are played through the handset receiver. Make sure you place the handset receiver close

to your ear.

The messages on the answering system are very difcult to hear.

Press /VOLUME on the telephone base or /VOL+ on the handset to increase the

listening volume.

The messages on the answering system are incomplete.

If a caller leaves a very long message, part of it may be lost when the answering system

disconnects the call after the preset recording time.

If the memory on the answering system becomes full during a message, the answering

system stops recording and disconnects the call.

If the caller’s voice is very soft, the answering system may stop recording and disconnect

the call.

•

Troubleshooting

Appendix

The answering system does not respond to remote commands.

Make sure your remote access code is correct (page 23).

Make sure you are calling from a touch-tone telephone. When dialing a number, there

should be tones. If there are clicks, then it is not a touch-tone telephone and cannot

activate the answering system.

The answering system may not detect the remote access code when your announcement

is playing. Wait until the announcement is over before entering the code.

There may be interference on the telephone line you are using. Press the dialing keys

rmly when dialing.

I subscribe to a nontraditional telephone service that uses my computer to

establish connections, and my telephone doesn’t work.

Make sure your computer is powered on.

Make sure your Internet connection is working properly.

Make sure that the software is installed and running for your nontraditional

telephone service.

Make sure to plug your USB telephone adapter into a dedicated USB port on your

computer. Do not plug into a multiple port USB hub (USB splitter) that is not powered.

In a few rare instances, the USB port on your computer may not have enough power. In

these instances, try using a USB hub with its own external power supply.

If you are using a rewall, it may prevent access to your nontraditional telephone service.

Contact your service provider for more information.

Common cure for electronic equipment.

If the telephone is not responding normally, put the cordless handset in the telephone

base. If it does not respond, try the following (in the order listed):

1. Disconnect the power to the telephone base.

2. Disconnect the battery on the cordless handset.

3. Wait a few minutes before connecting power to the telephone base.

4. Install the battery again and place the cordless handset in the telephone base.

5. Wait for the cordless handset to synchronize with the telephone base. Allow up to one

minute for this to take place.

•

Troubleshooting

Appendix

Important safety instructions

When using your telephone equipment, basic safety precautions should always be followed to reduce

the risk of re, electric shock and injury, including the following:

Read and understand all instructions.

Follow all warnings and instructions marked on the product.

Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use

a damp cloth for cleaning.

Do not use this product near water such as near a bath tub, wash bowl, kitchen sink, laundry tub or

swimming pool, or in a wet basement or shower.

Do not place this product on an unstable table, shelf, stand or other unstable surfaces.

Slots and openings in the back or bottom of the telephone base and handset are provided for

ventilation. To protect them from overheating, these openings must not be blocked by placing the

product on a soft surface such as a bed, sofa or rug. This product should never be placed near

or over a radiator or heat register. This product should not be placed in any area where proper

ventilation is not provided.

This product should be operated only from the type of power source indicated on the marking label.

If you are not sure of the type of power supply in your home or ofce, consult your dealer or local

power company.

Do not allow anything to rest on the power cord. Do not install this product where the cord may be

walked on.

Never push objects of any kind into this product through the slots in the telephone base or handset

because they may touch dangerous voltage points or create a short circuit. Never spill liquid of any

kind on the product.

To reduce the risk of electric shock, do not disassemble this product, but take it to an authorized

service facility. Opening or removing parts of the telephone base or handset other than specied

access doors may expose you to dangerous voltages or other risks. Incorrect reassembling can

cause electric shock when the product is subsequently used.

Do not overload wall outlets and extension cords.

Unplug this product from the wall outlet and refer servicing to an authorized service facility under

the following conditions:

When the power supply cord or plug is damaged or frayed.

If liquid has been spilled onto the product.

If the product has been exposed to rain or water.

If the product does not operate normally by following the operating instructions. Adjust only

those controls that are covered by the operation instructions. Improper adjustment of other

controls may result in damage and often requires extensive work by an authorized technician to

restore the product to normal operation.

If the product has been dropped and the telephone base and/or handset has been damaged.

If the product exhibits a distinct change in performance.

Avoid using a telephone (other than cordless) during an electrical storm. There is a remote risk of

electric shock from lightning.

Do not use the telephone to report a gas leak in the vicinity of the leak. Under certain

circumstances, a spark may be created when the adapter is plugged into the power outlet, or

when the handset is replaced in its cradle. This is a common event associated with the closing

of any electrical circuit. The user should not plug the phone into a power outlet, and should

not put a charged handset into the cradle, if the phone is located in an environment containing

concentrations of ammable or ame-supporting gases, unless there is adequate ventilation. A

spark in such an environment could create a re or explosion. Such environments might include:

medical use of oxygen without adequate ventilation; industrial gases (cleaning solvents; gasoline

vapors; etc.); a leak of natural gas; etc.

Only put the handset of your telephone next to your ear when it is in normal talk mode.

The power adapter is intended to be correctly oriented in a vertical or oor mount position. The

prongs are not designed to hold the plug in place if it is plugged into a ceiling, under-the-table or

cabinet outlet.

SAVE THESE INSTRUCTIONS

10.

11.

12.

13.

14.

15.

16.

Appendix

Precautions for users of implanted cardiac pacemakers

Cardiac pacemakers (applies only to digital cordless telephones):

Wireless Technology Research, LLC (WTR), an independent research entity, led a multidisciplinary

evaluation of the interference between portable wireless telephones and implanted cardiac

pacemakers. Supported by the U.S. Food and Drug Administration, WTR recommends to

physicians that:

Pacemaker patients

Should keep wireless telephones at least six inches from the pacemaker.

Should NOT place wireless telephones directly over the pacemaker, such as in a breast pocket,

when it is turned ON.

Should use the wireless telephone at the ear opposite the pacemaker.

WTR’s evaluation did not identify any risk to bystanders with pacemakers from other persons using

wireless telephones.

Operating range

This cordless telephone operates with the maximum power allowed by the Federal Communications

Commission (FCC). Even so, this handset and telephone base can communicate over only a certain

distance - which can vary with the locations of the telephone base and handset, the weather, and the

layout of your home or ofce.

When the handset is out of range, the handset displays Out of range or no pwr at base.

If there is a call while the handset is out of range, it may not ring, or if it does ring, the call may not

connect well when you press /FLASH. Move closer to the telephone base, then press /FLASH to

answer the call.

If the handset moves out of range during a telephone conversation, there may be interference. To

improve reception, move closer to the telephone base.

Maintenance

Taking care of your telephone

Your cordless telephone contains sophisticated electronic parts, so it must be treated with care.

Avoid rough treatment

Place the handset down gently. Save the original packing materials to protect your telephone if you

ever need to ship it.

Avoid water

Your telephone can be damaged if it gets wet. Do not use the handset outdoors in the rain, or handle it

with wet hands. Do not install the telephone base near a sink, bathtub or shower.

Electrical storms

Electrical storms can sometimes cause power surges harmful to electronic equipment. For your own

safety, take caution when using electrical appliances during storms.

Cleaning your telephone

Your telephone has a durable plastic casing that should retain its luster for many years. Clean it only

with a soft cloth slightly dampened with water or mild soap. Do not use excess water or cleaning

solvents of any kind.

•

Remember that electrical appliances can cause serious injury if used when you are wet or standing

in the water. If the telephone base should fall into the water, DO NOT RETRIEVE IT UNTIL YOU

UNPLUG THE POWER CORD AND TELEPHONE LINE CORD FROM THE WALL. Then remove

the telephone by the unplugged cords.

Appendix

About cordless telephones

Privacy: The same features that make a cordless telephone convenient create some limitations.

Telephone calls are transmitted between the telephone base and the cordless handset by radio

waves, so there is a possibility that the cordless telephone conversations could be intercepted by

radio receiving equipment within range of the cordless handset. For this reason, you should not

think of cordless telephone conversations as being as private as those on corded telephones.

Electrical power: The telephone base of this cordless telephone must be connected to a working

electrical outlet. The electrical outlet should not be controlled by a wall switch. Calls cannot be

made from the cordless handset if the telephone base is unplugged, switched off or if the electrical

power is interrupted.

Potential TV interference: Some cordless telephones operate at frequencies that may cause

interference to televisions and VCRs. To minimize or prevent such interference, do not place

the telephone base of the cordless telephone near or on top of a TV or VCR. If interference is

experienced, moving the cordless telephone farther away from the TV or VCR often reduces or

eliminates the interference.

Rechargeable batteries: Exercise care in handling batteries in order not to create a short circuit

with conducting material such as rings, bracelets, and keys. The battery or conductor may overheat

and cause harm. Observe proper polarity between the battery and the battery charger.

Nickel-metal hydride rechargeable batteries: Dispose of these batteries in a safe manner. Do

not burn or puncture the battery. Like other batteries of this type, if burned or punctured, they could

release caustic material which could cause injury.

•

The RBRC® seal

The RBRC® seal on the nickel-metal hydride battery indicates that VTech Communications, Inc. is

voluntarily participating in an industry program to collect and recycle these batteries at the end of their

useful lives, when taken out of service within the United States and Canada.

The RBRC® program provides a convenient alternative to placing used nickel-metal hydride batteries

into the trash or municipal waste, which may be illegal in your area.

VTech’s participation in RBRC® makes it easy for you to drop off the spent battery at local retailers

participating in the RBRC® program or at authorized VTech product service centers. Please call

1 (800) 8 BATTERYTM for information on Ni-MH battery recycling and disposal bans/restrictions in

your area. VTech’s involvement in this program is part of its commitment to protecting our environment

and conserving natural resources.

RBRC® is a registered trademark of Rechargeable Battery Recycling Corporation.

Appendix

Limited warranty

What does this limited warranty cover?

The manufacturer of this VTech Product warrants to the holder of a valid proof of purchase

(“Consumer” or “you”) that the Product and all accessories provided in the sales package (“Product”)

are free from defects in material and workmanship, pursuant to the following terms and conditions,

when installed and used normally and in accordance with the Product operating instructions. This

limited warranty extends only to the Consumer for Products purchased and used in the United States

of America and Canada.

What will VTech do if the Product is not free from defects in materials and workmanship during

the limited warranty period (“Materially Defective Product”)?

During the limited warranty period, VTech’s authorized service representative will repair or replace at

VTech’s option, without charge, a Materially Defective Product. If we repair the Product, we may use

new or refurbished replacement parts. If we choose to replace the Product, we may replace it with a

new or refurbished Product of the same or similar design. We will retain defective parts, modules, or

equipment. Repair or replacement of the Product, at VTech’s option, is your exclusive remedy. VTech

will return the repaired or replacement Products to you in working condition. You should expect the

repair or replacement to take approximately 30 days.

How long is the limited warranty period?

The limited warranty period for the Product extends for ONE (1) YEAR from the date of purchase. If

VTech repairs or replaces a Materially Defective Product under the terms of this limited warranty, this

limited warranty also applies to the repaired or replacement Product for a period of either (a) 90 days

from the date the repaired or replacement Product is shipped to you or (b) the time remaining on the

original one-year warranty; whichever is longer.

What is not covered by this limited warranty?

This limited warranty does not cover:

1. Product that has been subjected to misuse, accident, shipping or other physical damage, improper

installation, abnormal operation or handling, neglect, inundation, re, water or other liquid intrusion;

2. Product that has been damaged due to repair, alteration or modication by anyone other than an

authorized service representative of VTech; or

3. Product to the extent that the problem experienced is caused by signal conditions, network

reliability, or cable or antenna systems; or

4. Product to the extent that the problem is caused by use with non-VTech accessories; or

5. Product whose warranty/quality stickers, product serial number plates or electronic serial numbers

have been removed, altered or rendered illegible; or

6. Product purchased, used, serviced, or shipped for repair from outside the United States of America

or Canada, or used for commercial or institutional purposes (including but not limited to Products

used for rental purposes); or

7. Product returned without a valid proof of purchase (see item 2 below); or

8. Charges for installation or set up, adjustment of customer controls, and installation or repair of

systems outside the unit.

Appendix

Limited warranty (continued)

How do you get warranty service?

To obtain warranty service in Canada, please visit our website at www.vtechcanada.com or call

1 (800) 267-7377. NOTE: Before calling for service, please review the user’s manual - a check of the

Product’s controls and features may save you a service call.

Except as provided by applicable law, you assume the risk of loss or damage during transit and

transportation and are responsible for delivery or handling charges incurred in the transport of the

Product(s) to the service location. VTech will return repaired or replaced Product under this limited

warranty. Transportation, delivery or handling charges are prepaid. VTech assumes no risk for

damage or loss of the Product in transit. If the Product failure is not covered by this limited warranty,

or proof of purchase does not meet the terms of this limited warranty, VTech will notify you and will

request that you authorize the cost of repair prior to any further repair activity. You must pay for the

cost of repair and return shipping costs for the repair of Products that are not covered by this

limited warranty.

What must you return with the Product to get warranty service?

Return the entire original package and contents including the Product to the VTech service location

along with a description of the malfunction or difculty; and

Include a “valid proof of purchase” (sales receipt) identifying the Product purchased (Product

model) and the date of purchase or receipt; and

Provide your name, complete and correct mailing address, and telephone number.

Other limitations

This warranty is the complete and exclusive agreement between you and VTech. It supersedes all

other written or oral communications related to this Product. VTech provides no other warranties for

this Product. The warranty exclusively describes all of VTech’s responsibilities regarding the Product.

There are no other express warranties. No one is authorized to make modications to this limited

warranty and you should not rely on any such modication.

State/Provincial Law Rights: This warranty gives you specic legal rights, and you may also have other

rights, which vary from state to state or province to province.

Limitations: Implied warranties, including those of tness for a particular purpose and merchantability

(an unwritten warranty that the Product is t for ordinary use) are limited to one year from the date of

purchase. Some states/provinces do not allow limitations on how long an implied warranty lasts, so

the above limitation may not apply to you. In no event shall VTech be liable for any indirect, special,

incidental, consequential, or similar damages (including, but not limited to lost prots or revenue,

inability to use the Product or other associated equipment, the cost of substitute equipment, and

claims by third parties) resulting from the use of this Product. Some states/provinces do not allow the

exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion

may not apply to you.

Please retain your original sales receipt as proof of purchase.

Appendix

FCC Part 15

This equipment has been tested and found to comply with the requirements for a Class B digital device

under Part 15 of the Federal Communications Commission (FCC) rules. These requirements are

intended to provide reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

Consult the dealer or an experienced radio/TV technician for help.

Changes or modications to this equipment not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

This device complies with Part 15 of the FCC rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause undesired operation. Privacy of

communications may not be ensured when using this telephone.

To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy

that can be safely absorbed by a user or bystander according to the intended usage of the product. This

product has been tested and found to comply with the FCC criteria. The handset may be safely held

against the ear of the user. The telephone base shall be installed and used such that parts of the user’s

body other than the hands are maintained at a distance of approximately 20 cm (8 inches) or more.

This Class B digital apparatus complies with Canadian ICES-003.

FCC Part 68 and ACTA

This equipment complies with Part 68 of the FCC rules and with technical requirements adopted by

the Administrative Council for Terminal Attachments (ACTA). The label on the back or bottom of this

equipment contains, among other things, a product identier in the format US:AAAEQ##TXXXX. This

identier must be provided to your telephone service provider upon request.

The plug and jack used to connect this equipment to premises wiring and the telephone network

must comply with applicable Part 68 rules and technical requirements adopted by ACTA. A compliant

telephone cord and modular plug is provided with this product. It is designed to be connected to a

compatible modular jack that is also compliant. An RJ11 jack should normally be used for connecting

to a single line and an RJ14 jack for two lines. See Installation Instructions in the user’s manual.

The Ringer Equivalence Number (REN) is used to determine how many devices you may connect to

your telephone line and still have them ring when you are called. The REN for this product is encoded

as the 6th and 7th characters following the US: in the product identier (e.g., if ## is 03, the REN is

0.3). In most, but not all areas, the sum of all RENs should be ve (5.0) or less. For more information,

please contact your telephone service provider.

This equipment may not be used with Party Lines. If you have specially wired alarm dialing equipment

connected to your telephone line, ensure the connection of this equipment does not disable your alarm

equipment. If you have questions about what will disable alarm equipment, consult your telephone

service provider or a qualied installer.

•

FCC, ACTA and IC regulations

Appendix

FCC, ACTA and IC regulations (continued)

Technical specications

Frequency control Crystal controlled PLL synthesizer

Transmit frequency Handset: 1921.536-1928.448 MHz

Telephone base: 1921.536-1928.448MHz

Channels 5

Nominal effective range Maximum power allowed by FCC and IC. Actual operating range

may vary according to environmental conditions at the time of use.

Power requirements Handset: 2.4V Ni-MH battery

Telephone base: 6V DC @ 400mA

Charger: 6V AC @ 300mA

Memory Handset directory:

30 memory locations; up to 30 digits and 15 characters

Handset call log:

30 memory locations; up to 24 digits and 15 characters

If this equipment is malfunctioning, it must be unplugged from the modular jack until the problem has

been corrected. Repairs to this telephone equipment can only be made by the manufacturer or its

authorized agents. For repair procedures, follow the instructions outlined under the Warranty. If this

equipment is causing harm to the telephone network, the telephone service provider may temporarily

discontinue your telephone service. The telephone service provider is required to notify you before

interrupting service. If advance notice is not practical, you will be notied as soon as possible. You will

be given the opportunity to correct the problem and the telephone service provider is required to inform

you of your right to le a complaint with the FCC. Your telephone service provider may make changes

in its facilities, equipment, operation, or procedures that could affect the proper functioning of this

product. The telephone service provider is required to notify you if such changes are planned.

If this product is equipped with a corded or cordless handset, it is hearing aid compatible.

If this product has memory dialing locations, you may choose to store emergency telephone numbers

(e.g., police, re, medical) in these locations. If you do store or test emergency numbers, please:

Remain on the line and briey explain the reason for the call before hanging up.

Perform such activities in off-peak hours, such as early morning or late evening.

Industry Canada

Operation is subject to the following two conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any interference, including interference that may cause

undesired operation.

The term ‘’IC:‘’ before the certication/registration number only signies that the Industry Canada

technical specications were met.

The Ringer Equivalence Number (REN) for this terminal equipment is 0.1. The REN is an indication of

the maximum number of devices allowed to be connected to a telephone interface. The termination on

an interface may consist of any combination of devices subject only to the requirement that the sum of

the RENs of all the devices does not exceed ve.

This product meets the applicable Industry Canada technical specications.

Appendix

Index

About caller ID 18

About cordless telephones 42

Add a directory entry 15

Alphabetical search 16

Announcement 25

Answer a call 11

Answering system and voicemail 26

Answering system setup 22

Answer ON/OFF 22

Battery 33

Battery charging 3

Battery installation 3

Caller ID 18

Call intercept 27

Call log 18

Call log display screen messages 21

Call screening 22

Call waiting 11

Chain dialing 13

Charger installation 2

Charging 3

Clear voicemail 8

Clock 9

Date 9

Delete a directory entry 17

Delete all messages 28

Delete a redial entry 14

Delete memos 28

Delete the call log entries 21

Delete your own announcement 25

Dial a call log entry 19

Dial a directory entry 16

Dial a redial entry 14

Dialing pause 15, 17, 20

Dial mode 10

Directory 14

Display screen messages 31

DSL lter 2

Edit a directory entry 17

End a call 11

Find handset 12

Flash 11

Handset indicators 32

Handset layout 4, 5

Handset light 32

Handset ringer 7

Handset screen icons 32

Home area code 10

Implanted cardiac pacemakers 41

Important safety instructions 40

Indicators 32

Installation 2

Key tone 9

Layout 4, 5, 6

LCD language 8

Limited warranty 43

Listening volume 11

Maintenance 41

Make a call 11

Memory match 19

Message alert tone 23

Message capacity 26

Message playback 27

Index

Message recording time 24

Message window displays 29

Missed call indicator 19

Multiple handset use 13

Mute 11

New message indication 27

Number of rings 23

Operating range 41

Pacemaker patients 41

Paging handset 12

Parts checklist 1

Phonebook (directory) 14

Play memos 28

Play your own announcement 25

Precautions for users of implanted

cardiac pacemakers 41

Predial a call 11

Pulse dialing 10

Range 41

Recording time 24

Record memos 28

Record your own announcement 25

Redial list 14

Remote access 30

Remote access code 23

Review the call log 19

Review the directory 16

Review the redial list 14

Ringer 7

Ringer tone 7

Ringer volume 7

Ringer volume (handset) 7

Ringer volume (telephone base) 7

Safety instructions 40

Screen display language 8

Screen icons 32

Set date and time 9

Share an outside call 13

Store a directory entry 15

Store from redial 15

Technical specications 46

Telephone base indicators 32

Telephone base installation 2

Telephone base layout 6

Telephone base light 32

Telephone base ringer 7

Temporary ringer silencing 12

Temporary tone dialing 12

Time and date setting 9

Tone 7, 9

Tone dialing 10

Troubleshooting 34

Using the menu 7

View dialing options 20

Voice language 24

Voicemail 8, 26

Volume 7, 11, 27

Wall mounting 2

Warranty 43

Website 10

VTECH TELECOMMUNICATIONS LTD.

A member of THE VTECH GROUP OF COMPANIES.

VTech is the registered trademark of VTech Holdings Limited.

Vtech Cordless Telephone Cs6124 Users Manual

CS6124-21 to the manual 0de50fea-8887-40dd-a562-00cc3b57e1c0

Navigation menu

Versions of this User Manual:

Views

Navigation
