WEIKING TECHNOLOGY BT08 30 PIN BLUETOOTH AUDIO RECEIVER User Manual BTR006
SHENZHEN WEIKING TECHNOLOGY CO.,LTD 30 PIN BLUETOOTH AUDIO RECEIVER BTR006
User Manual
BT08
Dock Bluetooth audio receiver
User’s manual
Before use…………………………………………………………. .1
1. About BT08………………………………………………………….1
2. System requirements………………………………………………. .1
3. Overview of BT08…………………………………………...………1
Getting started……………………………………………………. . 2
Instruction for the key……………………………………………. .2
Pairing with Bluetooth devices……………………………………..2
Remarks……………………………………………………………. .3
Specifications…………………………………………………….... .3
Welcome to use this Dock Bluetooth stereo receiver BT08. Please read this
user’s manual carefully before use.
Before use
1. About BT08
BT08 is a stereo Bluetooth audio receiver. You can put it to any 30 pin
speaker and upgrade it to be Bluetooth speakers to play music from any
Bluetooth enabled audio devices.
The product comes without battery and powered by speaker directly.
2. System requirements
Audio device with 30 pin connector. Bluetooth transmitting device
supporting A2DP profile, such as Bluetooth mobile phones, Bluetooth
MP3s ,Tablet PC etc.
3. Overview of BT08
2
3
１
1music pause/play
230 pin connector
3Led indication
1
Getting started
1) First powered on the 30 pin speaker
2) Plug the BT08 onto the 30 pin speaker; The BT08 will auto go into
pairing mode with blue led flashing;
3) Turn on the Bluetooth from your audio device and searching the name;
Name of “Dock receiver” will be shown on your audio searching list;
If need to put password,please enter “0000”to match. Pairing time is
within 1 minutes and varied from difference audio devices.A sound
will come out if paired successfully. It only need to be paired at the
first time and it will directly connect with the last audio device when
use second time.
4) Just play the music after successful connecting.
Instruction for the key
Press shortly to play or pause the current music;Press more than
3 seconds to disconnect the current audio devices.
Note:30 pin speaker could control the the audio devices to do play
/pause/next/previous .
Pairing with Bluetooth mobile phone
Ensure your mobile phone supports A2DP profile. The pairing procedures
will vary depending on different models of mobile phones. Please refer to
your mobile phone user’s manual for further information. The general
pairing procedures are as follows:
1) Place the receiver and Bluetooth mobile phone where they are easily
viewable by no more than 1 meter apart;
2) Plug the receiver onto the speaker and powered the speaker;
3) Activate your mobile phone’s Bluetooth function and set your mobile
phone to search for Bluetooth devices within range, and select “Dock
Receiver” from the list of devices shown;
4) The blue led will flashed quickly under pairing mode.
5) If need password, please enter password or PIN No: “0000”;
6) If prompted by your mobile phone to connect, select “Yes” (This will
vary among mobile phone models);
7) After successful connecting, the sound will come out and the blue LED
flashes slowly.
Remarks:
After successful pairing, the receiver and the mobile phone will
remember each other, they will no need to re-pair next time.
Every time the receiver is turned on, it will automatically connect to last
connected device. If you want to pair it with other devices, please turn
off the Bluetooth function of last connected devices first and pair the
receiver with the new device according to steps 1～7 mentioned above.
When the reveiver is turned on and doesn’t connect to any devices,
please plug out and replug in , it will automatically connect to the last
connected device.
When the receiver and the mobile phone are out of effective range to
disconnected, they can connect to each other automatically once going
back to effective range.
If the Bluetooth version of your mobile phone is V2.1 or above, it will no
need to enter PIN No. when the receiver pairs with the mobile phone.
Specifications
Bluetooth version Bluetooth V3.0
Bluetooth profiles A2DP /AVRCP/HSP/HFP
Frequency range 20Hz-20KHz
Operating distance 10 meters, Class II
Dimensions 48.6*32*9.5mm
Weight 12g
Notes:
1. This device could have memory for latest 8 devices. It will auto delete 1
device if more than 8 device name.
Federal Communications Commission (FCC) Statement
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications made to this device not expressly
approved by Shenzhen Weiking Technology Co., Ltd. may void the FCC
authorization to operate this device.
Note: The manufacturer is not responsible for any radio or tv interference
caused by unauthorized modifications to this equipment. Such modifications
could void the user’s authority to operate the equipment.
