WENZHOU MTLC ELECTRIC APPLIANCES MWS Receptacle User Manual USERS MANUAL
WENZHOU MTLC ELECTRIC APPLIANCES CO., LTD. Receptacle USERS MANUAL
USERS MANUAL
SPECIFICATION
-01- -02- -03-
INSTALLATION INSTRUCTIONS
Smart AC Switching Control Receptacle
Voltage(MWS-120)............................................................120VAC,60Hz
Wireless Transmitting current.........................................................40 mA
Max Wireless Range(direct)................................................within 20 feet
meets all the fire and building code
as a receptacle for air conditioner , electric heater, and fan coil for air
Smart Decorator Duplex Receptacle
conditioning . It receives and processes signals from transmit device,
make and break the circuit base on occupancy or vacancy of the room.
MWS-120,MWS-240
Voltage(MWS-240)............................................................240VAC,60Hz
Load Rating........................................................................................20A
Operating temperature........................................................30°F to 120°F
Relative Humidity........................................20% to 90% non-condensing
Operating Frequency...................................................................315MHz
Reception Sensitivity..................................................................-105dBm
Flush mount 20A Smart Receptacle
Constant System Self Testing
FEATURE
COMPONENTS
(MWS-RSC-120, and MWS-RSC-240)
Installation : Connect Hot Line wire to Black screw terminal,Neutral to
White screw Terminal, Ground to Green screw terminal.
DESCRIPTION
This flush wall mount wiring device
MWS-120 MWS-240
120 Vac
Smart
Receptacle
Figure 1
Function Button
Indicator
Controlled Receptacle
Function Button
Indicator
240 Vac
Smart
Receptacle
Controlled Receptacle
Side wired only
Have code function to ensure the uniqueness of device control
One controlled receptacle
Both are tamper resistant receptacles
Energy is the basic power for ensuring the working of all machines.To
save energy and decrease the daily consumption means that the oper-
-ation cost will be reduced and the profit will raise. The air conditioner’s
energy consumption takes up a majority of the total energy consumption.
Therefore s set of energy-saving air conditioning control system is fairly
The air conditioning auto control system is made up of three parts: two
transmit devices and one receive smart receptacle, each of which
the receptacle in a single
off, then can save
Factory Default:
TESTING
Warming Up:
After connecting power to Smart Receptacle , there are 40 seconds
warming up time.
When both LEDs of Smart Receptacle and transmit devices flash twice.
If not, go to Code Learn Mode.
Self Test Mode:
Push the Function button on Smart Receptacle only once, LED blinks
once , the system is now Self Test mode, do not plug in the load at this
time. LED blinking rapidly, solid On and Off . After 5 minutes , LED
becomes solid On , Self Test Mode is finished. If LED is off at this time,
open or close the door ,LED turns On.
Make sure transmit device is not detecting anyone, close and open the
Confirming Test:
door , keep the door open for the next 15 minutes , LED turns Off
between 10 to 15 minutes.Test complete.
CODE LEARNING MODE
The codes are factory preset in a package. However, if there is a need
of code match, push the Function button for more
will become blinking, in the next 30 seconds, transmit device's LED
turns solid,code is matched.
Note: once a new code in , the old code will be erased in the Smart
receptacle.
essential.
communicates wireless with room, to control
energy and make
the air conditioning auto on/auto
the air conditioner more intelligent.
than 5 seconds, LED
TROUBLE SHOOTING
LED on Receptacle keep flashing:
Run Self Test Mode, if end of batteries , replace them.
Power Off 15 minutes even if occupancy:
RF signal is blocked from the transmit device to the receptacle
Power On 10-15 minutes even if vacancy:
RF signal is blocked from the transmit device to the receptacle
Receptacle can not recognize signals from Sensor:
Refer to the CODE LEARNING MODE.
Our company warranties its products to be free of defects in materials
and workmanship for a period of two (2) years. There are no obligations
or liabilities on the part of our company for consequential damages
arising out of or in connection with the use or performance of this product
or other indirect damages with respect to loss of property, revenue , or
profit ,or cost of removal, installation or reinstallation.
Feb,2012
WARRANTY INFORMATION
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
