Wave Wireless DM2 Wireless Data Link User Manual DMII

Wave Wireless Corporation Wireless Data Link DMII

Product Data Sheet

General Description
The DataMetro II wireless router provides wide area connectivity for
pack oriented networking of multiple locations up to 30 miles (50 km)
apart. This technology delivers very low bit error rate links that have
high immunity to interference. This self-contained wireless router with
Ethernet and antenna ports is easily installed. Deployment is also
simple since licensing is not required in most countries.
DataMetro II is ideally suited as a cost-effective wireless solution for
Internet Service Providers (ISP) as well as organizations with dispersed
sites needing to connect their computers or LANs.
Features
■Self contained wireless router
with Ethernet and antenna ports
■Range up to 30 miles (50 km)
per hop, supports multiple hops
■Wired WAN-like data throughput
approaches T1 performance
■Supports multiple physical topologies;
Star, Mesh, and Point-to-Point
■End-to-end SNMP support
monitoring network and radio
performance remotely
DataMetro™
II
Wireless Remote Access Router
PRELIMINARY
Typical Applications
Radio Specifications
Frequency 2.400-2.4835 GHz
(“S-band”)
RF Channels 9 overlapped
(DataMetro II 1280)
14 overlapped
(DataMetro II 320)
Transmit Power 1-800 mW (0-28 dBm)
Receive Sensitivity –86 dBm (DataMetro II 1280)
@ 10E–6 BER –92 dBm (DataMetro II 320)
Antenna Options 0-24 dBi gain
System Specifications
Performance
Data Rate (burst) DataMetro II 1280:
1.28 Mbps
DataMetro II 320:
320 kbps
Bit-Error Rate Better than 10–10 unfaded
Max. Users 127 WAN nodes
per cluster
Routable Protocols IP
IPX
Dynamic Routing IP: RIP v1/v2
Protocols IPX: IPX-RIP
System/Network SNMP
Administration Remote configuration
(BOOTP, TFTP)
Statistics, history, alarm,
and events groups
System log capability
Software download via
RS-232C or network via
Ethernet or wireless link
(TFTP)
Range
(Single hop maximum 30 miles depending on power,
network topology, terrain, antennas, cable, data rate)
Power
Power Supply 100-240 VAC @
50/60 Hz, 25.9 W
Environmental
Temperature 0 to 50° C (32° to 122° F)
Size and Weight
Dimensions 1.75 H x 17 W x 10 D inches
(44 H x 432 W x 254 D mm)
Weight 10.3 lbs (4.7 kg)
Ordering Information
Model Number Description
DM1280S-0P?A DataMetro II 1280
DM320S-0P?A DataMetro II 320
Certifications and Regulatory
Certifications FCC
Warranty
Includes standard 3-year warranty
DataMetro™
II
©1999 P-Com Inc. M0206 1/99
Wireless Remote Access Router
ETHERNET
REMOTE STATION
ETHERNET
BASE STATION
REMOTE STATION
REMOTE STATION
REMOTE STATION
ETHERNET
ETHERNET
P-Com Headquarters 3175 S. Winchester Blvd., Campbell, CA 95008
Toll Free: 1.800.791.7779 ■Tel: 1.408.866.3666 ■Fax: 1.408.866.3655 ■www.p-com.com
For International P-Com Sales offices please visit us on the World Wide Web at www.p-com.com
Specifications subject to change without notice. Performance specifications are for optimum conditions and may be affected by location, environment, and other operating considerations.
The P-Com logo design, AirPro, AirLink, DataMetro, and VoiceXtender are trademarks of P-Com Corporation in the U.S. and various countries.
