Wavetrend Technologies TGF-A Active Duo RFID Tag TGF-A User Manual Manual
Wavetrend Technologies Limited Active Duo RFID Tag TGF-A Manual
Manual
© 2012 Wavetrend Europe Limited | All Rights Reserved | All specifications are subject to change without notice.
Europe, Australasia and Middle East – Corporate Office USA, Canada and South America
+44 (0)20 8614 7779 +1 (703) 539 8502
Key fob Tag
TGF
-
A
0
The TGF Active Key fob can be operated in two modes both sleep and wake. Whilst awake both buttons operate and the tag
has its standard beacon rate, when asleep both buttons operate and there is no beacon rate.
The LED will flash once when button one which is closest to the LED is pressed and twice when button 2 is pressed in both
Asleep and Awake settings.
Personnel
Beacon tag transmitting a unique ID & data at pre-set intervals
Ultra long-range transmitter
Low battery warning
2 Push Button alarms
Flashing LED on Alarm
Replaceable Battery
KEY FEATURES BUSINESS BENEFITS
Tag can be configured to hold standard
26-bit Wiegand numbering
Allows tag to be used with existing access control
systems separately or together with the active RFID
system.
Configurable settings include:
Site / Vendor ID
Tag ID
Various transmission repetition intervals
(default 10s)
Panic Button 1
Panic Button 2
Replaceable coin cell battery
Flashing LED
Sealed to IP50 standards
A unique code that can be allocated by Wavetrend to
each customer on request. Readers can be set to ignore
tags with incorrect site codes.
4.2 billion tag ID’s are available per site code.
Different status transmission intervals allow tags to be
used in diverse applications while offering the best
battery life spans in the market.
Transmits Motion Alert
Transmits Tamper Alert
Lifespan at 30 seconds is 3 years
Provides user visual confirmation that an alarm has been
transmitted.
Best Usage
Guide
© 2012 Wavetrend Europe Limited | All Rights Reserved | All specifications are subject to change without notice.
Europe, Australasia and Middle East – Corporate Office USA, Canada and South America
+44 (0)20 8614 7779 +1 (703) 539 8502
Key fob Tag
TGF
-
A
The TGF-A Key fob tag can be used for
both security and control purposes. In
security applications it is often used awake
with its beacon being used to locate
personnel within and zone and to detect any
alarms.
In control applications the TGF tag can be
combined with the RX211 access reader
which when suitably configured can open
either set of relays corresponding to either
button 1 or button 2 being pressed on the
TGF-A.
Model Range
The tag can be ordered using the part
number listed below:
L-Series
TGF : Standard tag
Ordering & Further Information
For more information on purchasing the
Activ TGF-A Tag
please email
Wavetrend’s Sales team:
sales@wavetrend.net
For more information on Wavetrend® visit
our website.
Specifications
IP Information
Wavetrend and the Wavetrend logo are either registered trademarks or trademarks of Wavetrend
Technologies Limited in the United States and/or other countries. All other
trademarks are the property of
their respective owners. The product(s) described in thi
s document are protected by various patents held by
Wavetrend. Refer to the URL www.wavetrend.net/IPR
for information on all patents and trademarks held,
and for Wavetrend's Policy on Intellectual Property Rights.
Typical Applications
Environmental
Operating temperature
Storage temperature
Humidity
: -30°C to +60°C
: -40°C to +70°C
: 5% to 90% (non-condensing)
Physical
Size
Weight
Colour
Material
: 57 x 35 x 10 mm
: 14 grams
: Black
: Nylon IP64
Radio Frequency
Transmit Frequency
Power Output (avg.)
Range
: 433.92 MHz
: 77 dBV/m @ 3m
: 1 to 100+ meters (actual range is determined by the
choice of reader & antenna used to detect the tag and
the environment it is used in)
Electrical
Power
: Internally powered by Replaceable lithium battery
FCC Statement of Conformity
Wavetrend , TGFA Active Duo ,
FCC ID: 06XTGF-A
This device complies with Part 15 of the FCC rules subject to the following three conditions:
1) This device may not cause harmful interference.
2) This device must accept all interference received, including interference that may cause
undesired operation.
3) This device is for commercial use only and intended for use in a confined area with an
appropriate system receiver
Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
