Wease Electrical & Information Engineering Ltd. Resit Users Manual

Users Manual

Comfort
Convenient assembly and wireless
operation notications to smart remote
and applet
US, European and
Israeli standards
compliant
Safety
Child car seat alert system
Redefining Child Safety
Cutting-Edge
A
s
s
u
r
i
n
g
y
o
u
r
c
h
i
l
d
’
s
s
a
f
e
t
y
a
n
d
y
o
u
r
p
e
a
c
e
o
f
m
i
n
d
Health
No ionization and
no health hazards
www.resit.co.il
Advanced Israel design
with intuitive control unit,
smart remote, sensing
pillow and IOS/Android
applet
Assuring your child’s safety and your peace of mind
System Handling and Safety Instructions
1
1. Introduction
Dear parent we recommend reading the following information regarding
RESIT system advanced features, including a variety of tips to help make
system assembly and utilization easy, comfortable and efcient.
2. Before getting started, a few clarifications and important notes:
1.No modication to the system is allowed without the manufacturer’s explicit
approval.
2.Warning! Parents, you are personally responsible for the safety of the children
in your car. Installing the system does not absolve you of responsibility.
3.The system is made of plastic, PVC, and fabric and has undergone heat and
moisture resistance testing.
4. The system is intended for use only after reading the manual guide and/or
after receiving proper guidance for operation and installation.
5.Do not use the system after contact with water or if water has penetrated it.
6.Do not use the system if it is damaged in any way.
7.The company is not responsible for opening the system and/or making any
adjustments to the hardware or software.
8.It should be claried that the system warranty is not applicable in cases of
breakage, hardware or software manipulation, rupture of the sensing pillow
or power cord, or when the system has been used for any purpose other than
those dened by the manufacturer’s instructions.
9.The sensing pillow is intended for seating children only. Do not place objects
on it.
10. When using the applet on your mobile phone, make sure that there is a web
browsing package for regular operation and enabling GPS location in your
mobile settings.
11. Do not use the system in the case of damage to any of its parts.
12. Do not charge the control unit and/or the smart remote in the car. When
necessary, charging the unit and remote should be done at the customer’s
home and only with a V5.0 mA 2100 charger. You can use the mobile phone
charger (and an appropriate charging cable).
3. Know the Product
The product includes the following parts:
1. Sensing pillow & control unit
2. Smart remote
3. Free mobile applet
4. Manual guide
4. General Instructions
1.Check the integrity of the system in each application detailed below.
2.The system is encoded and aligned through all its parts, therefore it is
imperative to follow the LED indicators for the remote control and its audio
alerts.
3.When the battery LED of the remote lights-up or the low battery icon appears
in the applet, you should immediately charge the remote control and control
unit batteries or consult the instructions.
4.The system complies to international standards and can be used safely
granted it is properly installed and operated according to the installation
instructions.
5.The system follows international regulations for electro-magnetic elds and
should work accordingly, granted proper operation in accordance with the
user-guide instructions.
6.The system is equipped with a 3.7V polymer battery and does not pose a
public hazard. No battery replacement is required. The battery can be charged
using a micro USB cable. Proper notication is given when the battery needs
2
1. Sensing pillow & control
2. Smart Remote
3. Free mobile applet
The way the pillow is placed on the seat
Child car seat alert system
Redefining Child Safety
Speaker
ChargeActivationLinkReset
3
to be charged using a home charger. Minimum charger requirements are V5.0
mA 2100.
7.Protecting the environment: The system should not be disposed of with
household waste, but rather at a recycling collection facility. The system
adheres to international standards such as CB, RHOS, FCC, CE, including
the Israel Standards Institute.
To fully clarify: The system does not replace the presence
of a responsible adult in the vehicle. Responsibility for the
child‘s safety rests solely with the responsible adult. Neither
the manufacturer, nor the importer is responsible for any
circumstances in which a child is forgotten in a vehicle.
Getting Started Guide
Control Unit and Smart Remote
1. Unzip the side of the sensor pillow and pull out the control unit. Press the
power button on the control unit to turn it on as part of the initial activation and/
or after charging the battery or if the device is turned off.
2. When the control unit is activated, the sensor pillow will sound a single beep.
4
Speaker
Pause
Reset
Link
Buckle
Charge
Power Switch
3. The remote control must be activated by turning the power switch to the active
position. A single beep will then be heard indicating that the smart remote has
been switched on.
4. Press the center of the sensing pillow. There will be three beeps from the
control unit and the smart remote at intervals of several seconds. This indicates
an active connection between the sensing pillow and the smart remote as well
as the integrity of the sensor in the sensing pillow.
Linking the Control Unit to the Smart Remote
If the connection between the sensing pillow and the smart remote is lost, the
control unit and the smart remote must be reconnected. Connection is achieved
by simultaneously pressing the third button on the smart remote and the link
button on the control unit for ve seconds. The units are now reconnected.
The smart remote must be attached to your car key
chain. Do not leave the smart remote or your mobile
phone in the car at any time.
Child car seat alert system
Redefining Child Safety
5
Applet
The applet works in parallel to the remote control and is connected to the
sensing pillow.
1. The applet must be installed on your mobile phone directly from the Apple or
Google Store. The applet installation le can be downloaded directly from the
company’s website or alternatively by scanning the QR code on the package.
Activating and Configuring the Applet
1. Open the applet on the mobile device. Open
the Bluetooth screen to connect the device. If the
Bluetooth screen is off, the red indicator should come
on and turn green. The green Bluetooth indicator
should continue to scan the device.
2. Device Scanner - Find a device called ADI and
connect to it.
3. After connecting the sensing pillow (device) to the
applet, the device will appear in the applet with the
device name, battery status, and an indicator showing
whether a child is on the sensing pillow.
* Green indicator - Sensing pillow without child.
* Red indicator - Sensing pillow with a child present.
4. After connection, you can change the device name.
(Your child’s name is a good option)
* Repeat steps 2 + 3 for each device you install in your car (up to 4 devices).
5. When you rst connect to the applet, two beeps will be heard from the device.
6. You can update up to four phone numbers to receive alerts from the system.
To do so, from the applet go to Settings -> Contacts -> You will receive a Code
->Type in the code and the phone number you wish to send alerts to
-> Press OK.
Child car seat alert system
Redefining Child Safety
6
Activating the System
1. The sensing pillow should be placed in a straight and proper position on the
car seat or child safety seat.
2. Turn the power switch, on the control unit located in the sensing pillow, to the
active position.
3. In cases where the system is turned off or after the battery has been charged,
perform step two.
4. When a child is seated on the sensing pillow three beeps will be heard,
indicating that the device is working properly. In the applet, the device status
indicator changes from green to red. The system is now active.
5.If the child is forgotten in the vehicle: After you have moved a few meters
away from the device with your mobile phone and the child is still sitting on the
sensing pillow, the smart remote will start beeping, ashing and vibrating. At
the same time, the applet will also send an alert and notication that the child
has been left in the car. Moreover, if you do not respond to the system call,
the applet will then alert by sending a message to all predened contacts.You
have 15 seconds to press the pause button and stop the applet from alerting,
after which the applet will continue to alert until the child is removed from the
seat.
6. The applet must be enabled with every system functionality.
Warning!! Installing the system does not exempt you from
responsibility. To avoid any doubt, it is hereby clarified that
this product is only a warning device to prevent forgetting
the child in the vehicle. The use of the product does not
detract from and / or transfer responsibility from the user
to the importer and / or manufacturer, even in cases where
the product did not transmit any alert. Responsibility for the
safety of the child in the vehicle is solely that of the adult
driving the vehicle.
We recommended watching the training video on our website
For service or information, we recommend visiting
our web site WWW.RESIT.CO.IL
You can also contact us by phone +972-8-6812362
Child car seat alert system
Redefining Child Safety
FCCWarningStatement
Changesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliance
couldvoidtheuser’sauthoritytooperatetheequipment.Thisequipmenthasbeentested
andfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttoPart15ofthe
FCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmful
interferenceinaresidentialinstallation.Thisequipmentgeneratesusesandcanradiate
radiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,
maycauseharmfulinterferencetoradiocommunications.However,thereisnoguarantee
thatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescause
harmfulinterferencetoradioortelevisionreception,whichcanbedeterminedbyturning
theequipmentoffandon,theuserisencouragedtotrytocorrecttheinterferencebyone
ormoreofthefollowingmeasures:
‐‐ Reorientorrelocatethereceivingantenna.
‐‐ Increasetheseparationbetweentheequipmentandreceiver.
‐‐
Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiver
isconnected.
‐‐ Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
For service and further information visit
our web site: WWW.RESIT.CO.IL
Or contact our service center at:
+ 972-8-6812362
Israeli design
Manufactured in China
Made in 2017
Produced by: WEASE ELEC & INFO
ENGINEERING LIMITED
Imported by E.F.I (1997) Ltd.
Available in pink and blue,
the sensing pillow ts carrycots,
boosters and child safety car seats
Child car seat alert system
Redefining Child Safety
