Shenzhen Wenhui Technology Development Co., Ltd. Wireless control user manual
user_manual
Operating Instructions for 220V Single Controller
Product parameters
1, working voltage: AC220V
2, working frequency: 433.92 MHZ
3, static current: 8.5 mA
4, load power: 1000W
5, receiving sensitivity: -108 dBM
6, working style: self-locking
7, encoding method: 1527 learning code
8, modulation method: ASK
9, operating temperature: -10 °C ~ +70 °C
10, foot inch: 72 * 38 * 26(mm)
Description of the controller product
1. The wireless controller is equipped with a wireless switch or remote
control using a 1527 learning setting. The free pairing combination
realizes one control(1 switch control 1 light) and two pairs of one(2
switches control 1 light). N to N(multiple switches control multiple
lights).
2. The controller's wiring is as shown in Figure 1: INPUT power input,
OUTPUT power output(LED feed end)
III. Controller operation instructions(as shown in Figure 2)
Clear and pair code
For code function: Long press the code key for 3 seconds, LED
indicator light with flicker 1 time, wait for LED indicator light to press
the remote control button that needs to be code, control board LED
indicator light continuous flicker 3 times code success.
Clear code function: Long press code button 8 seconds, LED indicator
light with flashing, then clear code completion, clear all previously
learned remote control key code
Fourth, the use of switch instructions:
1. Please unplug the binder before using it(as shown in Figure 3)
2. Rip off the sponge protection paper randomly attached and stick it
to the corresponding position(as shown in Figure 4);
3. After the switch and controller are paired, stick the switch to the
location that needs to be installed(the wall of the adhesive switch
should be cleaned up, and the protective paper should be attached to
the wall for about one minute to make the adhesive firm);
Points for attention
1. Do not operate the electric wiring, turn off the power supply
corresponding to a good connection, check the correct and then use
power.
2. When the switch voltage is insufficient, please replace the battery in
time(when the switch battery voltage is insufficient, the remote
control distance becomes closer).
3. When using wireless electronic products, care should be taken to
avoid metal masks, large electronic equipment, electromagnetic fields,
etc., which have strong sources of interference, so as to prevent the
remote control from being short or unable to work properly.
FCC Statement
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modifications not expressly
approved by the party.
Responsible for compliance could void the user’s authority to operate this
equipment. (Example- use only shielded interface cables when connecting to
computer or peripheral devices).
This equipment complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
FCC Radiation Exposure Statement:
The equipment complies with FCC Radiation exposure limits set forth for
uncontrolled enviroment. This equipment should be installed and operated with
minimum distance 20cm between the radiator and your body.
.
