Wintop Electronics TWS598 BlueTooth Earphone User Manual
Wintop Electronics Co., Limited BlueTooth Earphone Users Manual
Users Manual
User Guide
TRUE WIRELESS STEREO EARPHONES
BH003
www.iteknic.com
NORTH AMERICA
E-mail: Support.US@iTeknic.com
US Distributor: SUNVALLEYTEK INTERNATIONAL INC.
Address:46724 Lakeview Blvd, Fremont, CA 94538
JAPAN
E-mail:support.jp@iTeknic.com (JP)
Address:Kyoubasihigasi 9F,3-18-6 PMO,Hatchobori,Chuo-ku,
Tokyo,104-0032,Japan.
EUROPE
EU Importer：SOURCE CONNECTION LTD
E-mail: Support.UK@iTeknic.com Support.DE@iTeknic.com
Support.FR@iTeknic.com Support.ES@iTeknic.com
Support.I T @iTeknic.com
Address:The Coach House,1 Howard Road, Reigate,
Surrey,England,RH2 7JE,UK
Manufacturer
Address:Shenzhen NearbyExpress Technology Development Company
Limited 333 Bulong Road, Shenzhen, China, 518129
BH003
①
②
③
④
⑤
EN
Product Diagram
1. Charging Indicators
2. USB Output Port
3. LED Indicator
4. Multi-Function Buttons
5. Charging Contacts
FR
Schéma du Produit
1. Voyants de Charge
2. Port de Sortie USB
3. Voyant à LED
4. Bouton de Multifonction
5. Contacts de Charge
IT
Schema del Prodotto
1. Indicatori di Ricarica
2. Porta in Uscita USB
3. Indicatore LED
4. Tasto Multifunzione
5. Contatti di Ricarica
DE
Produktabbildung
1. Ladeanzeigen
2. USB-Ausgang
3. LED-Anzeige
4. Mehrfunktionale Drucktaste
5. Ladekontakte
ES
Diagrama del Producto
1. Indicador de Carga
2. Puerto de Salida USB
3. Indicador LED
4. Bóton Multifuncional
5. Contactos de Carga
JP
製品図
1.充電表示
2.USB出力ポート
3.LED表示
4.多機能ボタン
5.充電面
01/02
EN
DANGER:
This product contains lithium battery. Never expose it to
strong sunlight or toss it into fire to avoid explosion.
Package Contents
· 1 x Charging Case
· 2 x Earbuds
· 1 x USB Charging Cable
· 6 x Ear Tips (two are equipped on the earphones)
· 1 x User Manual
How to Use
How to Wear
Charging the Charging Case
Connect the Micro USB charging port with any USB output port, and
charging will start automatically. The charging indicators will light up
progressively.
Note:
·Never use excessive force on charging components.
·Please charge the earbuds and the charging case before first time
use or after a long time idle.
Pairing
Couple Earbuds Mode
· Take out the earbuds from the charging case, and they will connect
with each other automatically with the blue light and the red light
flashing at the same time (If the earbuds failed to enter the pairing
mode, please press and hold the control button for 2 seconds). Once
connected, The LED indicator on the left earbud is off, and the blue
LED indicator on the right earbud is on for 2 seconds.
Charging
Charging the Earbuds
Put the earbuds into the charging case properly, and charging will start
automatically. The LED indicator will flash blue slowly during charging
and will turn off once fully charged.
03/04
05/06
Single Earbud Mode
·Take out one of the earbuds from the charging case, and the LED
indicator will flash red and blue. Press the control button twice to bring
the earbud into pairing mode.
·Turn on the Bluetooth function on your device, search for nearby
devices. Find “iTeknic IK-BH003” in the searching results and click the
name to connect.
Operation and Functions
Press the Control Button on either of the
earbuds once to Answer;Press the
Control Button on either of the earbuds
twice to Hang Up Phone Call.
Hold pressing the control button on either
of the earbuds for 2 seconds
Press the control button on the left earbud
three times
Press the control button on the right
earbud three times
Press the control button on either of the
earbuds twice
Press the control button on the right
earbud once
Press the control button on the left
earbud once
When paired successfully, press and hold
the control button on either of the earbuds for
2 seconds to activate Siri, or activate it with a
voice command. Click to exit the Voice Dial
state and return to the previous state.
· Turn on the Bluetooth function on your device and search for nearby
devices. At this time, the red and blue light of the earbuds will
alternately flash slowly. Find “iTeknic IK-BH003” in the searching
results. Click the name to connect. Once connected, the LED indicators
on both earbuds will flash blue for 2 seconds.
If the pairing failed, the blue light will flash slowly, and the earbuds will
automatically shut down after 10 minutes.
Put the earbuds back into the charging box and they will disconnect
automatically and start charging. If the mobile phone is disconnected or
out of Bluetooth range, a new pairing will be performed.
Note:
If you want to change from Couple Earbuds Mode to Single Earbud Mode,
you need to put both earbuds back into the charging box at the same time,
then the earbuds will automatically shut down, (If the earbuds failed to turn
off automatically, press and hold the control button for 6 seconds, then put
it back in the charging box) and take both earbuds out from the charging
case to pair.
Function Operation
Answer /
Hang Up Phone Call
Reject Incoming Call
Previous Track
Next Track
Play / Pause
Volume -
Volume +
Turn On /
Off Voice Control
07/08
When the mobile phone has connected to the earbuds with
music playing through Bluetooth, if there is incoming call,
the music will stop and the mobile phone will play the
incoming call ringtone. When the calling hangs up, the
phone will automatically revert to the previous phone music
via Bluetooth earbuds.
Low battery reminder. When the battery is less than 10%.
You will be prompted that the battery needs to be charged.
You will be reminded every 5 minutes.
Power synchronization display: Supports IOS/Android
mobile phone battery power synchronization indication.
When the remaining battery power is less than 10%, you
will be prompted that the battery needs to be charged. You
will be reminded every 5 minutes.
When the charging box is charging the earbuds, the blue
light is on. It will turn off when the charging is complete.
When the charging box is charging without earbuds in, the
red light is on. It will turn off when the charging is complete.
7.
8.
9.
10.
If your earbuds cannot be paired with each other, please
follow the instructions below to restore the factory settings:
press and hold the two control buttons on the earbuds for 11
seconds, then turn the earbuds back on. At this time, the
earbuds will directly enter the pairing mode. During the
cleaning process, the purple light will light for 3 seconds.
Extra attention is needed when wearing the earbuds to avoid
accidental pressing of the control button.
When restoring to factory settings, please pay close attention
to the status of the LED indicators for accurate settings.
It is not recommended to wear the two earbuds on different
people. If need to do so, please keep the 2 earbuds within
9.8ft in couple earbuds mode.
The volume cannot be adjusted in single earbud mode.
Charging box: When the power is less than 10%, the red
LED indicator will flash three times every 10 minutes. When
the power is less than 3%, the red LED indicator will flash
three times every 2 minutes. When the charging box is
charging with earbuds in, the LED indicator will turn into
purple at this time.
1.
2.
3.
4.
5.
6.
Note:
09/10
Warning
· Never dismantle or refit the product to avoid malfunction or
fire hazards.
· Keep away from corrosive liquids to avoid damages to the
product.
· Keep away from extreme temperatures.
· Keep away from children and pets.
· Don’t use the product in thunderstorm weather to avoid
malfunction or electric shock.
FAQ
Q: Failed charging of the charging case.
A: Make sure the charging cable is intact and plugged in properly.
Q: Signal of the earbuds is unstable and there is no sound in the earbuds.
A: Please wear the earbuds properly and put your phone in the
front pocket when using it outdoor.
Q: Two devices named “iTeknic IK-BH003” are found.
A: Delete both names and search again.
Q: Sound is unclear.
A: Increase the volume slowly on your phone and earbuds and
keep them close to each other.
Q: How to connect one earbud to two phones in single earbud mode?
A: 1.Connect your first phone with the earbud, turn off its Bluetooth
function.
2.Connect your second phone with the earbud, turn on the
Bluetooth on your first phone.
Q: What’s the effective range between the two earbuds?
A: Around 3 meters / 9.8 feet.
11/12
NOTE:
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following.
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for
help
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate
the equipment. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and(2) this
device must accept any interference received, including interference
that may cause undesired operation.
13/14
ES La marca Bluetooth® y los logotipos son de propiedad de
Bluetooth SIG, Inc. y se encuentra autorizado cualquier uso
de estas marcas por parte de Sunvalleytek International Inc.
Otras marcas y nombres comerciales son aquellas de sus
respectivos propietarios.
IT La parola e i loghi Bluetooth® sono marchi di fabbrica registrati
di proprietà di Bluetooth SIG, Inc. e qualsiasi utilizzo di questi
marchi da parte di Sunvalleytek International Inc. avviene su
licenza. Gli altri marchi di fabbrica e nomi commerciali
appartengono ai rispettivi proprietari.
JP Bluetooth® のワードマークおよびロゴはBluetoothSIG,Inc.
が所有する登録商標であり、SunvalleytekInternationalInc.は
これらのマークおよびロゴをライセンスに基づ いて使用してい
ます。その他の商標およびトレードネームは、それぞれの所有者
に帰 属します。
EN The Bluetooth® word mark and logos are registered trademarks
owned by the Bluetooth SIG, Inc. and any use of such marks
by Sunvalleytek International Inc. is under license. Other
trademarks and trade names are those of their respective
owners.
DE Die Marke Bluetooth® und das Bluetooth Logo sind eingetragene
Markenzeichen der Bluetooth SIG, Inc. und jegliche Verwendung
dieser Marke durch Sunvalleytek International Inc. ist lizensiert.
Die Rechte an anderen Markenzeichen liegen beim jeweiligen
Eigentümer.
FR Le terme et les logos Bluetooth® sont la propriété de Bluetooth
SIG, Inc. et toute utilisation de ces marques par Sunvalleytek
International Inc. se fait sous licence. Les autres désignations
commerciales et marques mentionnées sont détenues par
leur propriétaire respectif.
