Wireless Environment MBN200 NetBright Motion Sensor User Manual
Wireless Environment LLC NetBright Motion Sensor
User Manual
Motion Sensor Features:
Motion/light sensor: Sensor instantly turns on when it detects
motion. The light sensor conserves battery life by preventing
the sensor from activating in daylight.
Durable, Weather Resistant: Tight seals and UV resistant
material allow the sensor to work in all weather conditions.
Networking: The Motion Sensor will activate any light in the
network when it detects motion.
Installation Instructions
NetBright Motion Sensor
MBN200
• 2 AA-cell alkaline batteries (per sensor)
• Drill or screwdriver
• 2 screws, 2 anchors
What you need to install:
Thank you for purchasing the Mr Beams®
NetBright Motion Sensor. We are certain that
your motion sensor will contribute to a safer
environment and provide supplemental motion for
your NetBright system.
What is included per light:
www.mrbeams.com
1. Remove the screw on the back
of the motion sensor.
2. Slide the battery cover o the
motion sensor and set aside.
3. Insert 2 new AA alkaline batteries
and replace the battery cover.
Tips:
• Use only new alkaline AA-cell batteries with 1.5V rating.
• Do not mix old and new batteries. If batteries are not new, it may cause the sensor to malfunction.
• Install batteries with polarity in correct position.
Battery Caution:
1) Do not mix old and new batteries
2) Do not mix Alkaline, Standard Carbon-Zinc, Rechargeable Nickel Cadmium or
Nickel Metal Hydride batteries
3) Do not dispose of batteries in re
4) Batteries should be recycled or disposed of as per state and local guidelines
5. To mount the sensor with the
included screw, line up the battery
cover with desired mouting
location and mark with a pencil.
Use the hole from the battery cover
screw to mark the pilot hole.
6. Use a 1/16” drill bit to create
the pilot hole. Insert the included
screw and leave some room for
the sensor to slide onto. Slide the
sensor onto the screw.
Setting up Devices to a Network
Choose a group or channel
for your device with the
dipswitches next to the
battery compartment.
Ensure all units are on the
same channel by matching
the dipswitch positions.
Motion &
Light Sensor
WARNING: This product contains chemicals known to the State of California to cause
cancer and birth defects or other reproductive harm.
FCC WARNING:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installa- tion. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or televi- sion reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modiÞcations to this device not explicitly approved by manufacturer
could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
The device has been evaluated to meet general RF exposure requirement.
