Ultralite Remote User Manual

iRespond®- UltraLite Technical Manual
Wireless eSystems
Table of Contents
UltraLite Base Unit -------------------------------------------------------- 1
Change the Channel --------------------------------------------------1
Adjust Power Output -------------------------------------------------1
Turn On/Off Channel Scan ----------------------------------------- 2
Setting Base UID -----------------------------------------------------2
Adjusting Base Offset ----------------------------------------------- 3
Turn on in Programming Mode ------------------------------------ 3
UltraLite Remote Unit ---------------------------------------------------- 4
Login by Pin ---------------------------------------------------------- 4
Login Anonymously ------------------------------------------------- 4
Answer Multiple-Choice Questions ------------------------------- 4
iRespond UltraLite Technical Manual 1
UltraLite/Lite Base Unit
Change the Base’s Channel
1. Press the power button to turn on the Lite base.
2. Immediately press F1 while Wireless eSystems scrolls across the base’s
screen.
3. When Device Address appears press ENT . (This number should not be
altered).
4. Select ENT at Output Power.
5. Output Channel should now be displayed.
6. Use the up and down buttons to change the base’s channel.
7. Press ENT four more times to save and exit configuration mode.
8. The base will automatically shut off.
Adjust the Power Output
The Power Output is set to 0 when shipped. The power output may be changed to help
strengthen the RF signal when transmitting to many remotes or at far distances.
1. Press the power button to turn on the Lite base.
2. Immediately press F1 while Wireless eSystems scrolls across the base’s
screen.
3. When Device Address appears press ENT . (This number should not be
altered).
4. Use the up and down buttons to change the power.
5. Press ENT five more times to save and exit configuration mode.
6. The base will automatically shut off.
iRespond UltraLite Technical Manual 2
Turning Channel Scan On/Off
It is best for the base and remote units to be on the same channel. However, channel
scanning can be used to allow the base unit to find the best channel with the least amount
of noise. To communicate with a base with channel scanning on, remote units must be
configured with channel hopping on.
1. Press the power button to turn on the Lite base.
2. Immediately press F1 while Wireless eSystems scrolls across the base’s
screen.
3. When Device Address appears press ENT . (This number should not be
altered).
4. Select ENT at Output Power.
5. Select ENT at Output Channel.
6. Select ENT at Channel Offset 1 and again at Channel Offset 2.
7. Use the up and down buttons to turn channel scan on (“Yes”) or off
(“NO”).
8. Press ENT again to save configuration and exit.
9. Base will automatically shut off.
Setting/Adjusting Base UID
The Lite base’s UID is set before it is shipped and should not be changed.
1. Press the power button to turn on the Lite base.
2. Immediately press F1 while Wireless eSystems scrolls across the base’s
screen.
3. Device Address should be displayed.
4. Use the Left and Right buttons to select the correct digit you wish to
change.
iRespond UltraLite Technical Manual 3
5. Use the up and down buttons to change the number.
Adjusting Base Offset
The Offset is the center frequency for all remote radios, ensuring base can
communicate with all remotes. The Lite base’s Offset is set before it is shipped and
should never be changed.
1. Press the power button to turn on the Lite base.
2. Immediately press F1 while Wireless eSystems scrolls across the base’s
screen.
3. Device Address should be displayed.
4. Press ENT three times. Base will read Offset 1.
5. Connect spectrum analyzer to base’s antenna connection.
6. Offset #1 is for Lite remotes, Offset #2 is for Touch remotes. Use the Up
and Down arrows to adjust offset until the spectrum analyzer shows the
base on the center frequency for that offset.
7. Press ENT and complete Steps 5-6 for Offset 2.
8. Press ENT twice when complete.
Turn Base on in Programming Mode
1. Press and hold the F1 button.
2. Press and release the power button without letting go of F1 button.
3. When USB Pgm v#.# appears, let go of F1 .
4. Base will shut off when it has completed programming
iRespond UltraLite Technical Manual 4
UltraLite Remote Unit
To Login by PIN
An iRespond session must be running to login to a remote.
1. Press the power button to turn on the UltraLite remote.
2. Use the A-E Buttons to enter the correct characters of your PIN.
3. If the PIN was entered incorrectly, the right light will blink red once.
4. Renter your PIN. (If you fail to log in again, verify your PIN with the
instructor)
To Login Anonymously
Instructor must have the iRespond session set up to allow anonymous logins.
1. Press the power button to turn on the Lite remote.
2. Press the A button four times; ensure left light blinks orange after each
press.
3. If the right led blinks red once, verify Allow Anonymous Logins was checked
in Session Setup.
To Answer Multiple-Choice Questions
1. Select the appropriate A-E button.
iRespond UltraLite Technical Manual 5
FCC Non-modification statement:
Changes or modifications not expressly approved by Wireless eSystems Inc. could void
the user’s authority to operate this equipment.
FCC Non-Modification Statement: This device complies with part 15 of the FCC Rules.
Operation is subject to the following conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference received. Including
interference that may cause undesired operation.
