Wonders Technology DS-1060 BLUETOOTH CLOCK RADIO WITH DUAL ALARM User Manual USERS MANUAL

Wonders Technology Co., Ltd. BLUETOOTH CLOCK RADIO WITH DUAL ALARM USERS MANUAL

USERS MANUAL

Plug the included AC/DC power adapter
into the DC POWER INPUT on the unit and
an AC power outlet to power the dock.
DC IN 5VFM ANT. AUX IN DC OUTPUT 5V
AL 1 / AL 2 SLEEP CLK SET/MEM SOURCE
VOLUMETUNING
+
+
POWER
TALK/END PAIR
SNOOZE/DIMMER
USB Charging Port
ICB352B
Warning: Changes or modications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
• The apparatus shall not be exposed to dripping or splashing and that no
objects lled with liquids, such as vases, shall be placed on apparatus.
 L’appareilnedoitpasêtreexposéauxécoulementsouauxéclaboussuresetaucun
objetnecontenantdeliquide,telqu’unvase,nedoitêtreplacésurl’objet.
• Main plug is used as disconnect device and it should remain readily operable during
intended use. In order to disconnect the apparatus from the mains completely, the
mains plug should be disconnected form the mains socket outlet completely.
Laprisedusecteurnedoitpasêtreobstruéeoudoitêtrefacilement
accessiblependantsonutilisation.Pourêtrecomplètementdéconnectéde
l’alimentationd’entrée,laprisedoitêtredébranchéedusecteur.
• Battery shall not be exposed to excessive heat such as sunshine, re or the like.
Lespilesnedoiventpasêtreexposéesàdefortechaleur,telqu’àla
lumièredusoleil,aufeuouautreschosesdesemblable.
• Caution marking is located at the rear or bottom of the apparatus.
 Attentionmarquageestsituésurlepaneauarrièreouinférieurdel’unité.
• The marking information is located at the rear or bottom of apparatus.
 Lemarquageestsituésurlepaneauarrièreouinférieurdel’unité.
1. Read these Instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized
or grounding - type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong are
provided for your safety. When the provided plug
does not t into your outlet, consult an electrician
for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. Only use attachments/accessories
specied by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table
specied by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury
from tip-over. Unplug this apparatus during lightning
storms or when unused for long periods of time.
13. Refer all servicing to qualied
service personnel. Servicing
is required when the apparatus
has been damaged in any way,
such as power-supply cord or
plug is damaged, liquid has been
spilled or objects have fallen
into the apparatus, the apparatus
has been exposed to rain or
moisture, does not operate
normally, or has been dropped.
• CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
• WARNING:To reduce the risk of re or electric shock, do
not expose this apparatus to rain or moisture.
• AVERTISSEMENT: Pour réduire le risque d’incendie ou de choc
électrique, ne pas exposer cet appareil sous la pluie et l’humidité.
• CAUTION: Use of controls or adjustments or performance of procedures
other than those specied may result in hazardous radiation exposure.
• WARNING: Changes or modications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
• WARNING: Do not place the unit on top of any soft, porous, or sensitive surfaces to avoid
damaging the surface. Use a protective barrier between the unit and surface to protect the surface.
• WARNING: Use of this unit near uorescent lighting may cause interference
regarding use of the remote. If the unit is displaying erratic behavior move
away from any uorescent lighting, as it may be the cause.
• CAUTION:Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
• PRÉCAUTION:Dangerd’explosionsilespilessontremplacéesdefaçonincorrect.
Remplacerlespilesseulementparlemêmetypedepileoul’équivalent.
• WARNING: There is a danger of explosion if you attempt to charge standard
Alkaline batteries in the unit. Only use rechargeable NiMH batteries.
• WARNING: The remote control’s button cell battery contains mercury. Do
not put in the trash, instead recycle or dispose of as hazardous waste
• WARNING:Lithium batteries, like all rechargeable batteries are recyclable and should be
recycled or disposed of in normal household waste. Contact your local government for disposal
or recycling practices in your area. They should never be incinerated since they might explode.
• WARNING: Shock hazard - Do Not Open.
• AVIS:RISQUEDECHOCÉLECTRIQUE-NEPASOUVRIR
Mains plug is used as disconnect device and it should remain readily operable during
intended use. In order to disconnect the apparatus from the mains completely, the
mains plug should be disconnected form the mains socket outlet completely.
Laprisedusecteurestutilisépourdéconnecterlesystème.
Laprisedusecteurnedoitpasêtreobstruéeoudoitêtrefacilement
accessiblependantsonutilisation.Pourêtrecomplètementdéconnectéde
l’alimentationd’entrée,laprisedoitêtredébranchéedusecteur.
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or rechargeable (ni-cad, ni-mh, etc) batteries.
Nomezclebateríasviejasynuevas.
Nomezclebateríasalcalinas,estándar(carbono-zinc)orecargables(ni-cad,ni-mh,etc.).
WARNING: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
ATTENTION
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
This symbol indicates that this product
incorporates double insulation between hazardous
mains voltage and user accessible parts.
The lightning ash with arrowhead symbol,
within an equilateral triangle, is intended to alert
the user to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may
be of sufcient magnitude to constitute a risk of
electric shock to persons.
IMPORTANT SAFETY INSTRUCTIONS
Introduction and Setup
FCC Warnings
Power
The battery backup is intended for
short power outages only. The clock
radio’s primary functions cannot run
off of the battery backup alone.
Requires a CR2025 battery (pre-installed)
LITHIUM BATTERY
CR 2025
3V
PUSH
OPEN
LITHIUM BATTERY
CR 2025
3V
CR2025
PUSH
OPEN
Battery Backup
Additional Warnings
WARNINGS AND PRECAUTIONS
For Warranty Information and the most up-to-date version of this User’s Guide, go to www.iLiveElectronics.com Customer Service: 1-888-999-4215
Email Support: prodinfo@dpiinc.com, Email Parts: partsinfo@dpiinc.com
Copyright © 2012 Digital Products International (DPI, Inc.) All other trademarks appearing herein are the property of their respective owners. Specications are subject to change without notice.
USER’S GUIDE
V:557-01
Charging
Charging a Device
1. Make sure the unit is
plugged into the wall.
2. Using the appropriate USB charging
cable (not included), connect one end
to the device and the other to the
USB Charging Port on the unit.
Refer to the user’s manual for your
specic device for manufacturers
required charging amperage as well
as determining the appropriate cable
for your device before charging.
3. The device will now charge.
DC IN 5VFM ANT. AUX IN DC OUTPUT 5V
Tuning +/-
Press to tune
the radio in FM
Radio Mode.
Press and hold
to search for the
next available
frequency.
Power
Press to
turn the unit
on or off.
Clock Set/Mem
In off mode, press to
set the clock.
In FM Radio mode, press and
hold to begin saving the current
radio station as a preset.
Source
Press to switch
between FM Radio,
Bluetooth and
Line In modes.
Volume
Press to adjust
the volume.
Pair
Press and hold
to begin pairing a
Bluetooth device.
Talk/End/
Play/Pause
Press to answer
or end a call.
Press to play or
pause a connected
Bluetooth device.
Alarm 1/
Alarm 2
Press
to begin
setting the
alarms.
Sleep
In FM Radio
mode, press to
begin setting
the sleep timer.
Snooze/
Dimmer
Press to delay
the alarm.
Press to adjust
the brightness
of the display.
Line In
Bluetooth Clock radio with Dual Alarm
1. If powered on, press the Power button to
turn the unit off.
2. Press the Clock Set/Mem button.
3. Press the Tuning+/- buttons to adjust the
hour.
The PM indicator will light when the hour
is set in the PM.
4. Press the Clock Set/Mem button.
5. Press the Tuning+/- buttons to adjust the
minute.
6. Press the Clock Set/Mem button again to
nish setting the time.
1. If powered on, press the Power button to
turn the unit off.
2. Press and hold the Al1 or Al2 button until
the display begins to blink, then release
the button.
3. Press the Tuning+/- buttons to adjust the
minute.
The PM indicator will light when the hour
is set in the PM.
4. Press the Tuning+/- buttons to adjust the
minute.
5. Press the Al1 or Al2 buttons to switch
between Radio and Beep.
6. Once the set alarm time is reached, the
alarm will sound.
To set the other alarm, follow the above
steps and choose the alarm not currently
set.
1. Power on the unit by pressing the Power
button.
2. Press the Source button to switch to FM
Radio mode.
3. Press the Tun+ and Tun-buttons to adjust
the radio to the desired frequency.
4. Press and hold the Tun+ and Tun- buttons
to search for the next available frequency.
5. Press the Vol+/- buttons to adjust the
volume.
6. Turn the radio off by pressing the Power
button.
Clock and Sleep Timer
Alarm
Radio
Setting the Clock
1. Power on the unit by pressing the Power
button.
2. Press the Source button to switch to FM
Radio mode.
3. Press the Sleep button repeatedly to set
the sleep timer ( 15, 30, 45, 60, 75, 90
min or OFF ).
4. Once the set sleep time has expired the
clock radio will automatically power off.
Setting the Sleep Timer
Setting the Alarm
1. Follow the instructions for Setting the
Alarm.
2. Press the Al1 or Al2 buttons repeatedly
until the indicator is no longer lit.
Cancelling the Alarm
After the alarm sounds:
Press the Sleep button to delay the alarm for
several minutes.
OR
Press the Power button to turn the alarm off
until the set alarm time is reached again.
Snooze and Alarm Reset
Tuning the AM or FM Radio
1. Follow the instructions for Tuning the
Radio and Saving a Station as a Preset.
2. Press the Clock Set/Mem button.
3. Press the Tun+ and Tun-buttons to cycle
through preset radio stations.
Tuning to a Preset Radio Station
Adjust the position of the FM Antenna to
improve FM radio reception.
Radio Reception
To download this User’s Guide in English,
Spanish, or French, or to get answers to
frequently asked questions, visit the support
section at: www.iLiveElectronics.com
Para descargar este Manual del Usuario en
inglés, español y francés, o para obtener
respuestas a preguntas frecuentes, visite la
sección de apoyo en www.iLiveElectronics.
com
Pour télécharger ce guide de l’utilisateur en
anglais, espagnol ou français, ou pour obtenir
des réponses à des questions fréquemment
posées, consultez la rubrique d’assistance
sur www.iLiveElectronics.com
International Support
For Warranty Information and the most up-to-date version of this User’s Guide, go to www.iLiveElectronics.com Customer Service: 1-888-999-4215
Email Support: prodinfo@dpiinc.com, Email Parts: partsinfo@dpiinc.com
Copyright © 2012 Digital Products International (DPI, Inc.) All other trademarks appearing herein are the property of their respective owners. Specications are subject to change without notice.
Requires a 3.5mm audio cable (not included)
1. Connect a 3.5mm audio cable to the
Line In on the unit and an audio output
on an MP3 player or other audio source.
2. Use the native controls on the
connected MP3 player or other audio
source to play and control audio
played through the clock radio.
Line In
Using the Line In
Bluetooth Setup
Pairing a Bluetooth Device for the First Time
1. Power on the unit by pressing the Power
button.
2. Press the Source button to switch to
Bluetooth mode.
Bluetooth mode is indicated by “BT” on
the display.
“PAIR”will ash slowly on the display.
3. Press and hold the Pair button until
“PAIR” ashes quickly.
When pairing, remain within 3 feet of the
unit.
4. Using the native controls on your
Bluetooth device, select the “ICB352” in
your Bluetooth settings to pair.
If your device requests a password, enter
the default password “ 0 0 0 0 ”.
Refer to the user’s manual for your specic
device for instructions on pairing and
connecting Bluetooth devices.
5. When successfully paired and connected,
the display will show “BT”.
After initial pairing, the unit will stay paired
unless unpaired manually by the user or
erased due to a reset of the device.
If your device should become unpaired or
you nd it is unable to connect, repeat the
above steps.
Note: ICB352 can store up to 8 devices.
The ninth paired device will replace the
rst stored device in the unit’s memory.
The tenth device paired will replace the
second stored unit and so on.
1. Follow the instructions in Pairing a
Bluetooth Device.
2. When a call is received, a ringtone will
sound through the speakers.
3. Press the Play/Pause/Talk/End button
to accept the call or accept the call with
the native controls on the connected
device.
4. The incoming call received through the
device will now be heard through the
speakers.
5. To end the call, press the Play/Pause/
Talk/End button or end the call using the
native controls on the connected device.
1. Follow the instructions for Pairing a
Bluetooth Device.
2. Use the native controls on the
connected Bluetooth Device to select a
track.
3. To play or pause the selected track, use
the native controls on the connected
Bluetooth Device or press the Play/
Pause/Talk/End button.
4. Audio played through the connected
Bluetooth device will now be heard
through the speakers.
Playing Audio Wirelessly
Using the Speakerphone
Saving a Station as a Preset
1. Follow the instructions for
Tuning the FM Radio.
2. Tune to the desired station.
3. Press and hold the Clock
Set/Mem button.
4. Press the Tun+/- buttons to
choose the preset number.
5. Press and hold the Clock Set/Mem
button to save the station as a preset.
Up to 20 stations may be saved as presets.
FCC warning:
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must
accept any interference received, including interference
that may cause undesired operation.
The antenna used for this transmitter must be installed to
provide a separation distance of at least 20 cm from all
persons and must not be co-located or operated in conjunction
with any other antenna or transmitter.

Navigation menu
