Wonders Technology DS1685 Home Speaker User Manual FH333054 DS 1685
Wonders Technology Co., Ltd. Home Speaker FH333054 DS 1685
user manual
Home Speaker
Status indicators
Package content
Product overview
正反面印刷
SIZE：95 X 148NN
Product Type : Home speaker
Unit dimension : 11.8x2.64x5.2 inch
Unit weight : 3.46lbs
Output power :2 x 10 W | 12 W Subwoofer
Driver unit : 2.0 inch speaker x2 + 1.5 inch x3.5 inch passive radiator x 2
Frequency response : 40Hz-20kHz
Warranty: One-year limited
Power
Wonders Technology Co.,Ltd
Email:Support@dossav.com
Follow us on Facebook:
Wonders Technology Co.,Ltd
Email:Support@dossav.com
Follow us on Facebook:
Pairing the wireless speaker with your smart device
1.Place your smart device and speaker no more than one meter away from
each other .
3.Set your smart device to “discover” the speaker . Upon powering on ,
a tone will be hear , the blue LED will start flashing, accompany by a
4.Enable Bluetooth on your device and choose DOSS SoundBox XL from
the list.
5.If paring is successful, the LED will change to steady blue and your device
Mode NO. :DOSS SoundBox XL
User Manual
Home speaker x 1
Power adapter with power plug x 1
Φ3.5mm audio cable x 1
User manual x 1
1 2 4 5 6 7
3
long press to turn the device ON/OFF.
2.Mode switch:
3.LED lights①②③④ : From ①-④ indicates for Bluetooth mode,AUX in
4.Volume control
6.Play/Pause :
8.Power port :DC 12V 2.5A
9.LED charging light
Charging : steady red.
Fully charge :steady green.
10.AUX in :
11.TF card : Use it for TF card (with music) playback. Support MP3,WAV,WMV
8 910 11
1.Use the power adapter to charge your speaker with the port DC 12V 2.5A,
make sure that the power supply is within the standard as 100V-240V.
2.Make sure that the speaker is fully charge before using it at the first.
the LED will going to green .
Bluetooth
Problem
TF Card
Cannot Pair with Bluetooth
devices seconds,then have a try to pair it
again
Please select 'DOSS SoundBox
XL'as the default playback device
The song cuts off during
Maybe cause by the interference
of charging, try to put it in
another place and do not charge
it during play
Laptop prompts to install
driver
This driver is not special for DOSS
SoundBox XL,it’s for your laptop
the computer or windows
Please press the Play/Pause
service for help
The speaker do not play when
the card is inserted,and jump
directly back to Bluetooth
mode
Check whether the card format is FAT
or FAT32. If not, format it to FAT or
FAT32.
Check the song format. The speaker
only supports MP3, WAV, WMV
The song cuts off during
playback
There may be a problem with the
the same file
Output power :2 x 10 W | 12 W Subwoofer
Power adapter(supplied)
Model : DYS624-120250W-1/K
Input : 100 - 240 V~, 50 / 60 Hz, 0.8 A MAX
Output : 12 V , 2500 mAh
Wireless/Networking
Supported Bluetooth profiles : A2DP AVRCP,SPP
Warning
Do NOT drop ,hit or shake the device.
Do NOT disassemble ,repair or modify the speaker by yourself.
Do NOT use cleaning products that contain benzene,solvents or alcohol.
Do NOT expose the speaker to excessive heat or direct sunlight
Do NOT store the device in a place with humidity or dust.
Do NOT place heavy objects on top of the speaker.
Do NOT use near a microwave oven or wireless LAN products.
.5
Indicator lights on
the top
①Flashing blue
①Steady blue
②Steady red
③steady white
④Flashing red
Steady red
Steady green
The speaker has entered into
the pairing mode and it is
Indicates that the device is
successfully paired
Indicates that mode switch
to AUX in is successfully
Indicates that that mode
switch to TF card is successfully
Indicates that the power is low
FCC Statement:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following
two conditions: (1) This device may not cause harmful interference, and (2) this
device
must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class B
digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on,
the
user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the party
responsible
for compliance could void the user's authority to operate the equipment.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
