Worldwide Accessories BP1747 SPEAKER User Manual H32

Worldwide Accessories SPEAKER H32

User_Manual

2. Can not play music: MP3 music files stored path
can not be the player identification, save the file
stored in the root directory of removable devices.
3. The speaker mute: the volume is turned on.
4. Connect the computer no sound: Computer
interface connection error, please select the correct
audio output port
5. No function or function keys wrong: try again after
shutdown.
6. Machine to provide reset button headphone hole
abnormal card machine situation, available Slender
buttons on the stick buttons.
Special Note:
1. Before using a Wireless pairing must first open
the audio power, it has been the default Wireless
mode, enter pairing status, such as using a mobile
phone: HOPESTAR-H32 find the device
displays the Wireless interface on your phone,
choose Open Wireless interface, search for Wireless
devices, search, press Select HOPESTAR-H32,
connection pairing (pairing this machine without a
password), the connection OK. Return to the menu
interface, you can use Wireless to play music.
2. Suitable for all kinds of mobile phones equipped
with Wireless technology, Wireless adapter,
Wireless players, such as mobile phones (iPhone,
Features:
1.Wireless connection
2 memory function, short broadcast
3. Support U disk
4 built-in lithium battery
5. Built-in microphone, to achieve hands-free
mobile phone voice calls.
6. Support MP3 music format decoding
7. Mobile power function
8. Use high-fidelity speakers, make the sound more
natural and delicate
9. Multi-device serial function
10. FM
11. waterproof
Charging to use:
The machine built overcharge protection circuit, can
be connected to a computer or charger for a long
time, about four hours to fully charge.Every battery
playback time will be different due to the use of
different size of the volume.
Troubleshooting:
1. Auto power off: the battery power will automatically open
the battery protection,Please charge 5 hours after use.
BP1747
SPEAKER
Portable Wireless Speaker
H32
Wireless pairing
HTC, NOKIA, MOTOROLA) and so on.
3. Bluetooth indicator: waiting to connect flash /
connect successfully or suspend the long bright
Flash slowly when playing.
4. Concatenation function: wait for the connection
status short press will automatically search for the
slave and connect A short press with the phone will
automatically disconnect the phone and automatically
search for a second Machine connection, when the
connection to the box is successful, the phone again
using Bluetooth connection
Technical Specifications:
Wireless standard: 4.2
Transmission distance: 10 meters
Output power: 5W*2
Play time:4H
Frequency effect: 100Hz ~ 18KHz
Inside the speaker : 57MM*2,4Ω5W
Input Power: DC5V 1A
Maximum current consumption: 1A
Battery type: 18650 3.7V/1800mAh
Audio signal input interface: standard Φ3.5mm
headphone
jack (stereo)
Listen wirelessy.
Charge Endlessly.
username:
contact number:
Date of purchase:
Product number:
Maintenance failure:
Product warranty
Note: The product warranty is 6 months
Wireless Speaker
Wireless Speaker
H32
Wireless Speaker
Wireless Speaker
H32
Wireless Speaker
Wireless Speaker
H32
Wireless Speaker
Wireless Speaker
H32
Wireless Speaker Wireless Speaker
Wireless Speaker Wireless Speaker
H32 H32
1. Press the previous song / long press to decrease the volume
2. Short press play pause / long press switch / radio mode, press Search
3. Short press Bluetooth serial function / Long press mode switch / Short press answer /
double click to cancel Bluetooth connection
4. Press the next song / long press the volume increase
5.DC5V interface, when inserted into the DC5V data cable defaults to charging the device
6.USB socket, when inserted into the U disk, the default U disk playback,
insert the USB data cable for the mobile power function
7. TF card interface, when inserted TF card default TF card playback
8.AUX interface, when inserted AUX data cable default AUX data playback
9.One-click recovery
FCCWarningStatement
Changesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecouldvoidtheuser’sauthoritytooperatetheequipment.This
equipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttoPart15oftheFCCRules.Theselimitsaredesignedto
providereasonableprotectionagainstharmfulinterferenceinaresidentialinstallation.Thisequipmentgeneratesusesandcanradiateradiofrequencyenergy
and,ifnotinstalledandusedinaccordancewiththeinstructions,maycauseharmfulinterferencetoradiocommunications.However,thereisnoguaranteethat
interferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,whichcanbedetermined
byturningtheequipmentoffandon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowingmeasures:
‐‐ Reorientorrelocatethereceivingantenna.
‐‐ Increasetheseparationbetweentheequipmentandreceiver.
‐‐ Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthe receiveris connected.
‐‐ Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
