Xiamen Padmate Technology X16 Bluetooth Headset User Manual

Xiamen Padmate Technology Co.,LTD Bluetooth Headset

user manual

Instruction of X16 Bluetooth Headset
Thanks for purchasing Padmate X16 Bluetooth Headset. Please pair the headset with your
phone before using it, or you will not be able to use the headset. Please read through the
instruction below before using.
I. IMPORTANCE BEFORE USING:
The unit was designed and produced according to the related quality requests and safety
standards. Please read through the following operation instructions before using it:
- Read and keep well these instructions;
- Do not use or operate the it where it is forbidden of using, for example, airplanes and
hospitals;
- Do not use or operate the it according to the local laws and rules, for example, do not use
it when driving;
- Do not use or operate it when you are close to explosive or flammable sources, eg, gas
station etc;
- Do not hit or throw or open the unit by force as it may cause damage to the device;
- Do not put the unit near heat sources, e.g, stoves,heat registers and radiators etc;
- Keep the unit away from wet, water or other liquids that might cause short circuit or
malfunctions;
- Keep the unit and its accessories away from children to prevent being swallowed
- For special users, such as patients who use heart pacemakers, audiphones and built-in
cochlea devices etc, please follow the advice of doctors.
- Using it below minus 10 ℃ or above 50 ℃ could shorten the life span of battery.
II. About The Device
2.1 Packing list
1、Bluetooth headset (left & right) *1 pair
2、Instruction manual *1pcs
3、Micro-USB cable *1pcs
4、Silicon caps (L, S): 2 pairs
2.2 Device diagram
1、Multi Function button
2、Silicon earbuds
3、LED indicator
4、microphone
5、USB
6、volume +
7、volume –
2.3 Charging and battery
Please use the original USB cable provided for charging.
Warning: Using unmatched USB cable for charging might damage the device. Also, you
are not permitted to take the battery out of the device in case of damage and danger.
Suggested input power is DC 5V, 100mA-2A max.
and Operations
3.1 How to pair
1. Please set the distance between Bluetooth headset and mobile phone (or other
connecting device) within 1 meter, the closer the better.
2. Press power button for 2 seconds to turn on the headset (Blue LED on), then press
power button
for 3 seconds (Red and Blue LEDs alternately glitters) into the pairing status, waiting to
be paired.
3. Turn on the bluetooth application of your mobile phone and click to search Bluetooth
devices near your mobile. Once searched “X16” device name, please select it to pair.
After completely pairing, blue LED on, pairing successful and connected.
3.2 Multipoint connection
If your Bluetooth headset needs to connect two phones, you can use the following two
methods to pair:
Step 1: The first smart phone and headset paired successfully. Then turn off the first
phone's Bluetooth.
Step 2: Press the headset power button for 3 seconds to re-enter the pairing status,
pairing with the second phone.
Step 3: When the second phone is paired with the headset, open the first phone's
Bluetooth and the first phone is automatically connected to the headset.Then the
headset is connected to these two phones.
3.3 Operations
Functional
operation
LED Indicator
Voice prompt
Power on
Press power button
2 seconds
Blue LED glitters
voice prompt ”
Power on”
Power off
Long press power
button 7 seconds
Red LED glitters
voice prompt ”
Power off”
Into pairing
status
Long press ON/OFF
5 seconds
Red and Blue LEDs
Alternately glitters
voice prompt
“pairing”
Volume Plus
Click Volume +
Volume
Reduction
Click Volume-
Previous
Long press Volume -
Next
Long press Volume +
Play
Click power button
Pause
Press power button
Re-dial the
last phone
number made
before
Double click
power button
Answer
phone call
Click power button
Reject
phone calls
Double click
power button
3.4 Notice
If you fail to connect the headset with your mobile phone, please follow the below
suggestions and instructions:
- Make sure your headset has enough power and at power on mode, and paired
successfully with your mobile phone.
- Make sure the bluetooth application of your mobile phone is at open mode
- Make sure your mobile phone is within 10 meter distance to the headset and no
objectives between them, such as wall, electronic devices, metal things etc.
- If above steps confirm no problem, enter the phone's Bluetooth device pairing list, select
X16, manually connection.
- Please re-operate them again if still failed.
- If the headset can’t be paired to your mobile phone within 5 minutes at pairing mode, it
will power off automatically.
- f the headset is disconnected with your mobile phone and is not connected to your
mobile phone
- within 5 minutes, it will power off automatically.
IV.Specifications
Bluetooth version
Supported profiles
Frequency Range
Equipment Type
Power
Music time
Talk time
Standby time
Charging time
Distance
Working temperature
Product weight
Dimensions
Federal Communication Commission (FCC) Radiation Exposure Statement
The device has been evaluated to meet general RF exposure requirement, The device can
be used in portable exposure condition without restriction Federal Communication
Commission (FCC) Radiation Exposure Statement Power is so low that no RF exposure
calculation is needed.
This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications or changes to this equipment. Such modifications or changes
could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
‐ Reorient or relocate the receiving antenna.
‐ Increase the separation between the equipment and receiver.
‐Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
‐Consult the dealer or an experienced radio/TV technician for help.
FCC ID: 2AJEO-X16
