XinHuaMei Electronics YM-Z38 Bluetooth speaker User Manual
Shenzhen XinHuaMei Electronics Limited Company Bluetooth speaker
User manual
1Bluetooth Speaker 2USB charging cable
Bluetooth 3.0, high speed and low
power consumption.
Built in rechargeable lithium battery.
Built in microphone for hands free
phone calls.
Support TF card playback.
AUX in function for non-bluetooth devices.
3AUX input cable 4Warranty card
Bluetooth Speaker
User Guide
YM-Z38
1
1 Power on/off.
Play/Pause/Mode button
Next
Vol+
Phone button
PREV
Vol-
Aux jack
DC 5V charging port
TF card slot
2
3
4
5
6
7
8
9
10
2 3 4
5 6 7
8
9
10
Read this manual carefully before putting
the appliance into operation and keep
this manual for future reference.
Do not insert any metal object into the
device.
To avoid a static charge, do not use the
device in an extremely dry climate.
Do not attempt to repair the device
yourself.
Batteries (battery pack or batteries
installed) shall not be exposed to
excessive heat such as sunshine,
fire or the like.
Bluetooth version 3.0
Bluetooth profiles HSP, HFP, A2DP
and AVRCP
Bluetooth operating
distance
10 meters (equal to
33 feet)
Output power 5wX2
Frequency response
100Hz-20kHz
Distortion ≤1%
Microphonesensitivity
-40db
Playback time Music time 6 hours,
talk time 8 hours
Charging input power
DC 5V
Charging time Approx3 hours
Unit INCH 6.3*2.4*1.6 INCH
1.Press and hold the Power on/off button
until you hear a tone, the Bluetooth status
LED will flash red and blue, indicating that
the Bluetooth speaker is in pairing mode.
2.Set your Bluetooth-enabled device to
search for Bluetooth devices.
3.When the Bluetooth-enabled device finds
the Bluetooth speaker, select “YM-Z38”
from the list of found devices.
4.After a successful pairing, a beep tone
will be heard indicating that the device is
paired and the Bluetooth status LED will
stay solid blue.
If a previously paired device is in range
when the Bluetooth speaker is turned on,
the Bluetooth speaker will connect to it
automatically.
YM-Z38
YM-Z38
The screenshots above are typical of many
Bluetooth-ebabled devices in the market
today,andare used to assist in the
explanation of the pairing process. Your
Bluetooth-enabled devices’s interface and
interaction with the Bluetooth Speaker may
differ slightlyfrom the illustrations slightly
above.
Using the Bluetooth Speaker
Press and hold the button for about 3 seconds.
Qucik press button to play or pause music.
Press and hold button for about 3 seconds to
switch between Switch between Bluetooth, TF
card playback, and AUX mode.
Press button to increase volume.
Press button to decrease the volume.
Double quick press the button, the last
number called will be redialed.
Press button to skip to the next song.
Press button to skip to the previous song.next
song.
To answer a call, quick press the button.
To end a call, quick press the button again.
Charging the Bluetooth speaker
Make sure you charge your Bluetooth
speaker for at least 4 hours before using
it for the first time.
Insert TF card into the TF card slot.
Press button to turn on the Bluetooth speaker.
Press Mode button to switch the Bluetooth
speaker to TF card playback mode.
Play/Pause/Mode button
To charge the Bluetooth speaker, connect
the supplied micro USB cable to the USB
charging port and the other end to your
computer or USB charging device. The
LED indicator will flash when charging.
When charging is completed, the LED
indicator will stop flashing and stay solid
green.
