1. Core Engine Approvals Guide
2. Core Engine Developers Guide

Core Engine Approvals Guide

All trademarks and copyrights are the property of Xircom, Inc., an Intel company

Core Engine (PCS 1900)

GSM Wireless Terminal

Approvals Guide

(Preliminary Draft – 7/6/2001)

Core Engine Approvals Guide Preliminary Draft: 07/06/01 2

Part Number: 07100029, Revision: 002 Confidential

All trademarks and copyrights are the property of Xircom, Inc., an Intel company

1.1 Revision History

Date Revision Description

3/21/01 001 Initial draft revision for internal review (preliminary).

7/6/01 002 Revised In: Customer Device Approvals Section

North American Homologation

Radio Approvals Section

Added In: Customer Device Approvals Section

North American Homologation

RF Exposure – SAR

Miscellaneous Approvals

Section 255 Compliance

E911 Compliance

Leveraging Modular Approvals Section

PTCRB Approval and IMEI Assignment

Xircom Assistance with Approvals Section

Miscellaneous Items

Audio Testing

Integration Testing

Added Section: 4.5 Labeling and Documentation

Requirements

Remove all references to Dual-Band 900/1800

1.2 Disclaimer

Xircom, Inc., an Intel company (hereafter “Xircom”) shall not be liable for consequential or

incidental damages, injury to any person or property, anticipated or lost profits, loss of time, or

other losses incurred by Customer or any third party in connection with the implementation of the

Protocol or Customer's failure to comply with the information and instructions contained herein.

The information in this document is preliminary and subject to change by Xircom.

Core Engine Approvals Guide Preliminary Draft: 07/06/01 3

Part Number: 07100029, Revision: 002 Confidential

All trademarks and copyrights are the property of Xircom, Inc., an Intel company

1 IMPORTANT INFORMATION....................................................................................................... 2

1.1 Revision History ............................................................................................................................ 2

1.2 Disclaimer ..................................................................................................................................... 2

2 APPROVALS OVERVIEW ........................................................................................................... 5

2.1 Scope of This Document ............................................................................................................... 5

2.1.1 GSM FTA Testing.................................................................................................................. 5

2.1.2 North American Homologation...............................................................................................5

2.2 References.................................................................................................................................... 5

3 CORE ENGINE MODULAR APPROVALS................................................................................... 7

3.1 GSM FTA Testing.......................................................................................................................... 7

3.2 North American (United States and Canada) Homologation.......................................................... 7

3.2.1 Radio Approvals .................................................................................................................... 7

3.2.2 Product Safety ....................................................................................................................... 8

3.2.3 Electromagnetic Compatibility (EMC)..................................................................................... 8

4 CUSTOMER DEVICE SYSTEM APPROVALS ............................................................................ 9

4.1 Type Approval ............................................................................................................................... 9

4.2 North America (United States and Canada) Homologation............................................................ 9

4.2.1 Radio Approvals .................................................................................................................... 9

4.2.2 Product Safety ....................................................................................................................... 9

4.2.3 Electromagnetic Compatibility (EMC)................................................................................... 10

4.2.4 RF Exposure - SAR ............................................................................................................. 10

4.3 Miscellaneous Approvals............................................................................................................. 10

4.3.1 Section 255 Compliance...................................................................................................... 10

4.3.2 E911 Compliance ................................................................................................................ 10

4.4 Labeling and Documentation Requirements................................................................................ 11

4.4.1 Instructions to Manufacturer of the End Device Incorporating the Core Engine.................... 11

4.4.2 Responsibilities of the Manufacturer of the End Device Incorporating the Core Engine in a

Fixed or Mobile Application........................................................................................................... 12

4.4.3 Specific Responsibilities for Portable Products and Applications.......................................... 13

4.4.4 Specific Responsibilities for Mobile Products and Applications ............................................ 13

4.4.5 Specific Responsibilities for Fixed Products and Applications.............................................. 14

4.4.6 Labeling the Product............................................................................................................ 14

Core Engine Approvals Guide Preliminary Draft: 07/06/01 4

Part Number: 07100029, Revision: 002 Confidential

All trademarks and copyrights are the property of Xircom, Inc., an Intel company

5 LEVERAGING MODULAR APPROVALS.................................................................................. 15

5.1 Type Approval ............................................................................................................................. 15

5.2 North American (United States and Canada) Homologation........................................................ 15

5.3 PTCRB Approval and IMEI Assignment....................................................................................... 15

6 XIRCOM ASSISTANCE WITH APPROVALS ............................................................................ 16

6.1 Type Approval ............................................................................................................................. 16

6.1.1 GSM Testing........................................................................................................................ 16

6.1.2 Materials.............................................................................................................................. 16

6.1.3 Schedule.............................................................................................................................. 17

6.2 Safety.......................................................................................................................................... 17

6.2.1 Materials.............................................................................................................................. 17

6.2.2 Schedule.............................................................................................................................. 17

6.3 Emissions.................................................................................................................................... 17

6.3.1 Materials.............................................................................................................................. 18

6.3.2 Schedule.............................................................................................................................. 18

6.4 Miscellaneous Items.................................................................................................................... 18

6.4.1 Audio Testing....................................................................................................................... 18

6.4.2 Integration Testing............................................................................................................... 18

APPENDIX A ................................................................................................................................. 20

Core Engine Approvals Guide Preliminary Draft: 07/06/01 5

Part Number: 07100029, Revision: 002 Confidential

All trademarks and copyrights are the property of Xircom, Inc., an Intel company

2 A

The responsibility for an overall compliant product, per world wide regulatory standards, rests with the

Core Engine customer who incorporates the Core Engine into their device.

Currently some countries allow for a modular approval. This allows the Core Engine module to be

used in numerous products without testing and submitting the Core Engine module portion again for

certification. Some countries do not allow this and will require every product that the Core Engine is

integrated into to be tested and certified on it’s own.

2.1 Scope of This Document

The goal of this document is to provide a guidance note for our customers to help them better

understand the process that is required to incorporate the Core Engine module into their custom

device.

This document describes the approvals (agency, safety and emissions) that have been obtained by

Xircom for the Core Engine module, as well as those, which must be obtained for any end user device

incorporating a Core Engine module.

2.1.1 GSM FTA Testing

Full Type Approval (FTA) testing is not regulatory but rather a pre-requisite for market entry. It is used

to indicate that a GSM terminal complies with the terminal conformance testing specification, currently

known as:

• PCS 11.10 (1900 MHz)

• 3GPP TS 51.010-1 (Successor to PCS 11.10)

2.1.2 North American Homologation

Within North America (United States and Canada), Core Engine regulatory approvals are required in

the following areas to meet the requirements of the Federal Communications Commission (FCC in the

United States) and of Industry Canada (IC in Canada):

• Radio Authorization (FCC and IC Certification)

• EMC (emissions only)

In addition, product safety evaluation, approval and marking of any product incorporating the Core

Engine are required. Such approvals can be obtained from approved agencies in the United States

and Canada, including (but not limited to):

• Underwriters Laboratories

• Canadian Standards Association

2.2 References

[1] PCS 11.10 for 1900MHz Specification

[2] 3GPP TS 51.010-1

Core Engine Approvals Guide Preliminary Draft: 07/06/01 6

Part Number: 07100029, Revision: 002 Confidential

All trademarks and copyrights are the property of Xircom, Inc., an Intel company

[3] FCC’s OET Bulletin 65 on Specific Absorption Rates (SAR)

[4] FCC Part 15, Subpart B

[5] FCC Part 24, Subpart E (Broadband PCS)

[6] FCC Part 2, Subpart J (Equipment Authorization)

[7] UL 1950

[8] Canadian RSS-133 (PCS)

[9] RS-122 (Radio Certification Procedure)

[10] Safety Code 6 (RF Exposure)

[11] Canada ICES-003

Core Engine Approvals Guide Preliminary Draft: 07/06/01 7

Part Number: 07100029, Revision: 002 Confidential

All trademarks and copyrights are the property of Xircom, Inc., an Intel company

The following testing, authorizations and approvals are applicable to the Core Engine module.

3.1 GSM FTA Testing

"FTA" is used to indicate that a GSM terminal complies with the terminal conformance testing

specification, currently known as PCS 11.10 (1900 MHz). The successor to this specification is 3GPP

TS 51.010, which will become the single GSM/GPRS/EDGE terminal conformance specification

document.

Not regulatory but rather a pre-requisite for market entry, operators and industry groups drive the FTA.

The GSM NA Operators - PCS Terminal Certification Review Board (PTCRB) of GSM-North America

drives the 1900 MHz band.

Since the Core Engine is not a complete GSM terminal (it does not have a SIM), technically, it cannot

be Type Approved (i.e., pass all FTA testing requirements and grant of an IMEI). However, as much

FTA testing as possible is done in a reference configuration. This leaves only a small amount of

incremental testing to be performed on the end device incorporating the Core Engine.

FTA testing includes:

• Layer 1 – Transmitter, receiver and transceiver performance; spurious emissions; cell

selection

• Layer 2 – Test of the Layer 2 signaling functions

• Layer 3 – General protocol, handover, location update, RLM, SIM, SMS, RLP (data), SS

(supplementary services), GPRS protocol

• Audio – Currently only handset audio testing is supported by GSM 11.10

NOTE: All testing is defined in PCS 11.10 and its successor (3GPP TS 51.010-1).

3.2 North American (United States and Canada) Homologation

The Core Engine will be tested to and shown to comply with the applicable radio, electromagnetic

compatibility and safety requirements and standards of the Federal Communications Commission

(FCC), Industry Canada (IC), and Underwriters Laboratory.

3.2.1 Radio Approvals

Both the FCC and IC will authorize the Core Engine as a PCS transceiver. The Core Engine can be

incorporated into a final OEM product without the need for new or additional certification, if the

instructions and requirements of the Core Engine’s usage, regulatory requirements, testing and

approvals are followed. The manufacturer of the end device incorporating the Core Engine must

address human exposure to RF. Separate filings or approvals may be required, depending on the

specifics of the final product. Regulatory standards and documents addressing radio approvals

include:

Core Engine Approvals Guide Preliminary Draft: 07/06/01 8

Part Number: 07100029, Revision: 002 Confidential

All trademarks and copyrights are the property of Xircom, Inc., an Intel company

• FCC Part 24, Subpart E (Broadband PCS)

• FCC Part 2, Subpart J (Equipment Authorization)

• FCC OET Bulletin 65 on RF Exposure Evaluation

• IC RSS-133 (PCS)

• IC RSP-100 (Radio Equipment Certification Procedure)

• Health Canada Safety Code 6 (RF Exposure Limits)

3.2.2 Product Safety

The Core Engine will be evaluated by Underwriters Laboratory and marked as a Recognized

Component. This will simplify the product safety evaluation of the end device incorporating the Core

Engine. Any NRTL (Nationally Recognized Test Laboratory), not just UL, may be selected for

evaluation of the end device incorporating the Core Engine. The recognized component status of the

Core Engine may be leveraged as dictated by product or market requirements.

3.2.3 Electromagnetic Compatibility (EMC)

To the extent possible, the Core Engine will be evaluated to demonstrate that it complies with the

emissions and immunity requirements applicable to typical consumer products. This evaluation will be

performed with the Core Engine in a stand-alone configuration or built into a simple but representative

product. Only EM emissions are regulated in North America for the majority of products. However,

EM immunity of the Core Engine will be demonstrated during EU EMC testing. Applicable standards

include:

• FCC Part 15, Subpart B

• IC ICES-003

Core Engine Approvals Guide Preliminary Draft: 07/06/01 9

Part Number: 07100029, Revision: 002 Confidential

All trademarks and copyrights are the property of Xircom, Inc., an Intel company

The manufacturer of the end device incorporating the Core Engine is responsible for complying with all

regulatory requirements and directives as listed in but not limited to this document and as required by

the final product type. A summary of these regulatory and market approval requirements and

standards follows.

4.1 Type Approval

The end device incorporating the Core Engine requires incremental FTA testing to address those

areas that could not be tested during the initial FTA evaluation (such as SIM electrical), and to ensure

that the performance of the Core Engine has not degraded when integrated into the end device.

Xircom, our GSM Testing Lab Partner, and the manufacturer of the end device incorporating the Core

Engine will determine exact requirements on a case-by-case basis.

The manufacturer of the end device incorporating the Core Engine is responsible for completion of the

terminal approval process through the GSM NA PTCRB. At the completion of the incremental FTA

evaluation, the GSM testing laboratory will provide the necessary documentation to enable the

manufacturer of the end device incorporating the Core Engine to complete this process;

documentation of this process is found in:

• GSM NA PTCRB Document NAPRD.03 – Overview of PCS Type certification review

board (PTCRB) Mobile Equipment Type Certification and IMEI Control

• CTIA GSM-1900 Terminal Unit Certification Program Management Document

4.2 North America (United States and Canada) Homologation

The Core Engine will be tested and will comply with all applicable radio, electromagnetic compatibility

and safety as required by the Federal Communications Commission, and Underwriter’s Laboratory.

4.2.1 Radio Approvals

The Core Engine will be certified by both the FCC (USA) and Industry Canada as a PCS transceiver

and should not have to be re-tested by the manufacturer of the end device incorporating the Core

Engine as a PCS transceiver. However, additional FCC/IC certification work and filings will be

necessary to demonstrate and document RF exposure compliance. Labeling of the final product to

satisfy RF exposure requirements may be necessary, depending on the final product.

4.2.2 Product Safety

The Core Engine will be evaluated by Underwriters Laboratory and marked as a Recognized

Component. This will simplify the product safety evaluation of the end device incorporating the Core

Engine. Any NRTL (Nationally Recognized Test Laboratory) not just UL may be selected for

evaluation of the end device incorporating the Core Engine for the US market; many NRTLs also can

evaluate products for the Canadian market as well, in addition to CSA.

Core Engine Approvals Guide Preliminary Draft: 07/06/01 10

Part Number: 07100029, Revision: 002 Confidential

All trademarks and copyrights are the property of Xircom, Inc., an Intel company

4.2.3 Electromagnetic Compatibility (EMC)

To the extent possible, the Core Engine will be evaluated to demonstrate that it complies with the

emissions and immunity requirements applicable to typical consumer products. The end device

incorporating the Core Engine must comply with the appropriate emissions standards for its product

type and application. Emissions requirements for typical products are given in:

• FCC Part 15, Class A or B (both radiated and AC power line conducted)

• IC ICES-003 Class A or B

4.2.4 RF Exposure - SAR

The manufacturer of the end device incorporating the Core Engine must address human exposure to

RF in consideration of the application, antenna type, etc. Regulatory standards and documents

addressing human exposure to RF include:

• FCC OET Bulletin 65 on RF Exposure Evaluation

• Health Canada Safety Code 6 (RF Exposure Limits)

Preliminary RF exposure measurements should be performed as soon as feasible during development

of the final OEM product. Specific Absorption Rate (SAR) is a strong function of the product form

factor and position relative to the body. Preliminary testing will show if SAR is an issue in the current

form factor and allow for some redesign (move the antenna as far from head as possible, antenna

pattern shaping, etc.) if there are issues.

RF exposure evaluation is not the responsibility of Xircom. The Core Engine, as a PCS (GSM 1900)

terminal is limited to 1 W output; FCC Part 24 rules limits EIRP to 2 W, thus placing a limit of 3 dB on

antenna gain (for a mobile/portable device). Specific implementation details, including antenna type,

gain and position relative to the user's body during usage is beyond Xircom's control.

Xircom can provide software support for preliminary SAR testing to put the EUT into the worst-case

operating mode from an RF exposure perspective (2 transmit slots, maximum power, etc.).

4.3 Miscellaneous Approvals

Additional or alternate regulatory or market testing, approvals and/or documentation may be required,

depending on the type of device into which the Core Engine is incorporated.

4.3.1 Section 255 Compliance

TDMA systems in general, and GSM specifically, may cause audible rectification (at GSM frame rate)

in hearing aids. Since there may be larger issues here than just speaker HAC compliance, the

manufacturer of the end device incorporating the Core Engine should ensure that their product

provides accessible input, control, and mechanical functions, as well as accessible output, display and

control functions.

4.3.2 E911 Compliance

Xircom attends GSM-NA PTCRB meetings (operator and manufacturer terminal approval forum) to

stay abreast of terminal requirements, including E911. Xircom also works with operators directly.

GSM-NA Operators will soon adopt a single E911 technology across the board. Thus, we recommend

that all parties continue to evaluate the situation to ensure that there are no surprises in the future

regarding E911.

Core Engine Approvals Guide Preliminary Draft: 07/06/01 11

Part Number: 07100029, Revision: 002 Confidential

All trademarks and copyrights are the property of Xircom, Inc., an Intel company

4.4 Labeling and Documentation Requirements

The manufacturer of the end device incorporating the Core Engine is responsible for complying with all

labeling and documentation requirements as outlined in but not limited to the following sections.

4.4.1 Instructions to Manufacturer of the End Device Incorporating the Core Engine

To comply with the requirements of the National Environmental Policy Act (NEPA) of1969, operation of

an FCC-regulated transmitter may not result in human exposure to radio frequency radiation in excess

of the applicable health and safety guidelines established by the FCC. Further information on RF

exposure issues may be found in the FCC's Office of Engineering and Technology (OET) Bulletin

Number 65, "Evaluating Compliance with FCC Guidelines for Human Exposure to Radio Frequency

Electromagnetic Fields" and Supplement C, "Additional Information for Evaluating Compliance of

Mobile and Portable Devices with FCC Limits for Human Exposure to Radio Frequency Emissions."

Both of these documents are available via the Internet at the OET web site: http://www.fcc.gov/oet.

Industry Canada (IC) standards for 2 GHz PCS transmitters are established in RSS-133 (2 GHz

Personal Communications Services). This document requires that the procedures of RS-122

(Evaluation Procedure for Mobile and Portable Radio Transmitters with respect to Health Canada’s

Safety Code 6 for Exposure of Humans to Radio Frequency Fields) must be followed concerning

exposure to RF fields. RS-122 calls out Health Canada Safety Code 6 (Limits of Human Exposure to

Radiofrequency Electromagnetic Fields in the Frequency Range from 3 kHz to 300 GHz), which is

available on the Internet at www.hc-sc.gc.ca/rpb. It specifies the requirements for safe use of radiation

emitting devices, in general. One thing to note, the FCC and IC definitions and requirements are

nearly identical.

The product incorporating the Core Engine is a radio transceiver, which operates under the authority

of 47 CFR Part 24, Subpart E of the FCC Rules and Regulations. When installed and operated in

accordance with the instructions provided, these devices comply with current FCC regulations

regarding human exposure to radio frequency radiation.

For the purpose of determining compliance with current FCC and IC rules addressing human exposure

to radio frequency radiation, the FCC has established the following three categories of transmitting

devices:

• Portable Devices – devices where the antenna is located within 20 cm (7.87 inches) of any

person, including the user, if applicable. Portable devices operating under the authority of FCC

Part 24 (broadband PCS) and IC are limited to a maximum of 2 W EIRP.

• Mobile Devices – devices designed to be used in other than fixed locations and generally such

that the antenna is located at a minimum of 20 cm (7.87 inches) from any person, including

the user, if applicable. Mobile devices operating under the authority of Part 24 (broadband

PCS) are limited to a maximum of 2 W EIRP.

• Fixed devices – devices in which the antenna, either integral to the product or remotely

located, is physically secured at one location and is not able to be easily moved to another

location.

The following installation and operation restrictions apply to all Core Engine products for use in both

the United States and Canada:

• This device may be used in fixed, mobile, and portable applications.

• The use of this device for desktop and other applications where the antenna can easily be

relocated are considered to be mobile applications.

• In FIXED applications, a separation distance of at least 20 cm (7.87 inches) between the

antenna and the body of the user and other persons must be maintained at all times. The

Core Engine Approvals Guide Preliminary Draft: 07/06/01 12

Part Number: 07100029, Revision: 002 Confidential

All trademarks and copyrights are the property of Xircom, Inc., an Intel company

antenna gain is limited to a maximum of 3 dBi, with a corresponding Equivalent Isotropic

Radiated Power (EIRP) of 33 dBm/2 W.

• In MOBILE applications, a separation distance of at least 20 cm (7.87 inches) between the

antenna and the body of the user and other persons must be maintained at all times. The

antenna gain is limited to a maximum of 3 dBi, with a corresponding EIRP of 33 dBm/2 W.

• In PORTABLE applications, a separation distance of less than 20 cm (7.87 inches) between

the antenna and the body of the user and other persons may be possible. The antenna gain

is limited to a maximum of 3 dBi, with a corresponding EIRP of 33 dBm/2 W.

• End products must provide instructions to ensure compliance with radio frequency radiation

exposure requirements.

• When using Fixed and Mobile applications a warning label visible to all persons exposed to

the antenna and identical to that described in this manual must be displayed on or next to the

antenna.

Antenna gain is defined as gain in dBi (dB referenced to an isotropic radiator) minus cabling loss.

Note: Additional care must be taken by the installer and/or user of the products incorporating the Core

Engine to ensure proper antenna selection and installation. Adherence to the above conditions is

necessary for safe operation regarding exposure to RF radiation. Depending upon the application and

type of product into which the Core Engine module has been incorporated, additional actions and

evaluation may be required to meet these conditions. However, in all cases the primary concern is to

ensure compliance with current Federal guidelines and regulations that limit human exposure to radio

frequency radiation.

4.4.2 Responsibilities of the Manufacturer of the End Device Incorporating the Core Engine

in a Fixed or Mobile Application

In addition to any other regulatory requirements, the manufacturer of the end device incorporating the

Core Engine, and integrators must include or provide the following information, instructions, warnings

and labels with any device or product into which the Core Engine has been incorporated:

Core Engine Approvals Guide Preliminary Draft: 07/06/01 13

Part Number: 07100029, Revision: 002 Confidential

All trademarks and copyrights are the property of Xircom, Inc., an Intel company

Information Description

Detailed

Operating

Instructions

for ensuring

compliance

with current

FCC guidelines

which limit

human

exposure to

radio frequency

radiation

The manufacturer of the end device incorporating the Core Engine must provide an

operating/installation manual with the final product which clearly indicates that these operating

conditions and restrictions must be observed at all times to ensure compliance with current

FCC guidelines which limit human exposure to radio frequency radiation.

• 20 cm (7.87 inch) separation distance between the antenna and all persons must be

maintained at all times for all fixed and mobile products and applications

• Maximum antenna gain is limited to 3 dBi* in mobile and portable products and

applications

• Maximum antenna gain is limited to 3 dBi* in fixed products and applications.

• Modifications and/or additions to the Core Engine, including use of antennas with

higher gain than those authorized by the FCC, are prohibited

*dBi = antenna gain in dB relative to an isotropic radiator minus the interconnected RF

cable loss

Antenna

Avoidance

Label

Attach the following warning

label directly to or displayed

next to the antenna.

Furthermore, this label must

be visible to and easily

readable by all persons in the

immediate vicinity of the

antenna

WARNING

To comply with FCC RF exposure requirements, a separation

distance of 20 cm (7.87") or more must be maintained

between this antenna and all persons.

Human

Exposure

Compliance

Statement

Include the following

statement in the instruction

/operation manual.

Xircom, Inc. Wireless Technology Group certifies that

the Core Engine Radio Module (FCC ID:XXXXXXX)

complies with the RF hazard requirements applicable to

broadband PCS equipment operating under the

authority of 47 CFR Part 24, Subpart E of the FCC

Rules and Regulations. This certification is contingent

upon installation, operation and use of the Core Engine

and its host product in accordance with all instructions

provided to both the OEM and end used. When installed

and operated in a manner consistent with the

instructions provided, the Core Engine meets the

maximum permissible exposure (MPE) limits for general

population / uncontrolled exposure at defined in Section

1.1310 of the FCC Rules and Regulations.

4.4.3 Specific Responsibilities for Portable Products and Applications

The FCC/IC must separately authorize each device or product, into which the Core Engine has been

incorporated, and which are intended for use in an application that meets the definition of “portable” for

the purposes of determining compliance with current FCC/IC guidelines limiting human exposure to

radio frequency radiation. Portable devices must be evaluated for RF exposure based on Specific

Absorption Rate (SAR) limits; further information on such evaluations is available from the FCC/IC via

the Internet.

4.4.4 Specific Responsibilities for Mobile Products and Applications

Separate or additional FCC approvals are not required for devices or products, into which the Core

Engine has been incorporated, that are used in applications that meet the definition of "mobile." For

all end products, the manufacturer of the end device incorporating the Core Engine must provide

instructions, warnings and labels to ensure that the product complies with current FCC guidelines

limiting human exposure to radio frequency radiation. Current FCC and IC regulations limit the EIRP

Core Engine Approvals Guide Preliminary Draft: 07/06/01 14

Part Number: 07100029, Revision: 002 Confidential

All trademarks and copyrights are the property of Xircom, Inc., an Intel company

of mobile devices to 2 W. Because the nominal RF output power of the Core Engine GSM transceiver

is 1.0 W (30 dBm), antenna gain for mobile products and applications cannot exceed 3 dBi.

4.4.5 Specific Responsibilities for Fixed Products and Applications

Separate or additional FCC approvals are not required for devices or products, into which the Core

Engine has been incorporated, that are used in applications, which meet the definition of "fixed.” For

all end products, the manufacturer of the end device incorporating the Core Engine must provide the

instructions, warnings and labels to ensure that the product complies with current FCC guidelines

limiting human exposure to radio frequency radiation. Current FCC and IC regulations limit the EIRP

of fixed devices to 2 W. Because the nominal RF output power of the Core Engine GSM transceiver is

1.0 W (30 dBm), antenna gain for mobile products and applications cannot exceed 3 dBi.

4.4.6 Labeling the Product

The label on the device should contain the following:

FCC ID:AAABBBBBB

Contains Transmitter FCC ID: XXXYYYYYY

CANADA: ZZZZZZZZZ

AAA is the Grantee code of the manufacturer of the end device; BBBBBB is the product code for the

end device. XXX is the Xircom Grantee Code and YYYYYY is the Core Engine product code.

ZZZZZZZZZ is the Canadian Certification ICES-003 number.

IMEI - Barcode and numeric text to match that of the Core Engine inside. This information must be on

the outside of the product.

There will be a FCC DoC (Declaration of Conformity) mark with text ("Tested to Comply with FCC

Standards; FOR HOME OR OFFICE USE"). For Canada, there should also be a statement to the

effect "Complies with Canadian ICES-003 Class B" or "ICES-003 Class B".

In addition, there will be the "normal" label text, marks and information for a product of this type. This

will include the manufacturer, model, and perhaps serial number (in addition to the IMEI) and safety

labeling requirements, ratings, NRTL, UL, others that may apply to the end device.

Core Engine Approvals Guide Preliminary Draft: 07/06/01 15

Part Number: 07100029, Revision: 002 Confidential

All trademarks and copyrights are the property of Xircom, Inc., an Intel company

The end device incorporating the Core Engine module may leverage some of the modular approvals,

which have already been obtained for the Core Engine, and in doing so the customer producing the

end device may save much time, effort and expense.

5.1 Type Approval

Xircom will leverage its previous FTA testing. Xircom, our GSM Testing Lab Partner, and the

manufacturer of the end device incorporating the Core Engine will determine exact requirements on a

case-by-case basis.

5.2 North American (United States and Canada) Homologation

The Core Engine will be certified by both the FCC (USA) and Industry Canada as a PCS transceiver

and should not have to be re-tested by the manufacturer of the end device incorporating the Core

Engine as a PCS transceiver.

The manufacturer of the end device incorporating the Core Engine is responsible for addressing

human exposure to RF (SAR) in consideration of the application, antenna type, etc. Regulatory

standards and documents addressing human exposure to RF include:

• FCC’s OET Bulletin 65 on Specific Absorption Rates (SAR)

• Safety Code 6 (RF Exposure)

The Core Engine will be evaluated by Underwriters Laboratory and marked as a Recognized

Component. This will simplify the product safety evaluation of the end device incorporating the Core

Engine. Any NRTL (Nationally Recognized Test Laboratory), not just UL, may be selected for

evaluation of the end device incorporating the Core Engine.

To the extent possible, the Core Engine will be evaluated to demonstrate that it complies with the

emissions and immunity requirements applicable to typical consumer products. The end device

incorporating the Core Engine must comply with the appropriate emissions standards for the type and

application of the end product.

5.3 PTCRB Approval and IMEI Assignment

Xircom can provide the manufacturer of the end device incorporating the Core Engine with assistance

in obtaining IMEI assignments, IMEI allocation; and solving IMEI issues like uniqueness, security and

integrity for the final product. Since the Core Engine cannot be FTA approved on its own (primarily

because of the lack of a SIM), final GSM NA/PTCRB approval will be up to the manufacturer of the

end device incorporating the Core Engine. This involves submission of the FTA report (both the

results of initial and the "delta" testing) to the PTCRB/CTIA by the lab, some additional paperwork

(typically declarations provided by Xircom), and a fee. The GSM-NA administrator will then assign the

IMEI to the manufacturer of the end device incorporating the Core Engine for the final product.

Core Engine Approvals Guide Preliminary Draft: 07/06/01 16

Part Number: 07100029, Revision: 002 Confidential

All trademarks and copyrights are the property of Xircom, Inc., an Intel company

Xircom has access to both in-house and third party test facilities, equipment and personnel to assist

the customer with the process of obtaining approvals for their end device incorporating the Core

Engine module. Depending on the level of approval and the type of assistance required, a fee may be

charged for some of the services.

6.1 Type Approval

Xircom has invested in industry-accepted and validated GSM FTA test solutions from Anite

Telecommunications and other equipment providers. In addition, Xircom has partnered with a

recognized GSM test laboratory to provide the benefits of third party testing using its in-house testing

platforms. GSM test laboratory personnel using Xircom’s in-house test equipment will perform

accredited testing when required.

6.1.1 GSM Testing

Xircom's in-house FTA testing lab provides for validated GSM/GPRS FTA testing. Additional

capabilities provide tools to simulate and debug network interoperability problems.

Test capabilities include:

• GSM/GPRS RF (transmitter and receiver performance) testing on the Anite RAMS+. The

RAMS+ provides complete coverage across all bands (GSM, DCS and PCS) for all mandatory

RF test cases. Certain test cases (radiated emissions, vibration testing) where specialized

facilities or equipment is required are performed at Xircom's partnered GSM testing laboratory.

• GSM / GPRS Protocol testing on the Anite SAT system. The GSM SAT provides complete

test case coverage across all bands for all mandatory tests, with the some limited exceptions

(i.e. audio test cases). The Anite SAT also provides GPRS test case coverage. Test case

coverage not provided on Xircom’s SAT system is provided by Xircom’s partnered GSM

testing laboratory.

• SIM testing is accomplished using an ORGA Subscriber Identity Module (SIM) simulator, in a

stand-alone mode for SIM electrical tests and in combination with the SAT for SIM protocol

tests.

6.1.2 Materials

The customer must provide the following material to Xircom in order to support Xircom’s testing of the

end device:

• Hardware - Sufficient samples (3 to 6) to support simultaneous RAMS (RF), SAT (protocol)

and ORGA (Subscriber Identity Module) testing. Modifications to the hardware may be

required (addition of RF cable or connector for connection to RAMS+ or addition of a pigtail to

the SIM connector for SIM electrical testing, for example).

• RS232 or USB pass thru capability to allow direct access to the Core Engine for automated

testing and issuing manual AT commands.

Core Engine Approvals Guide Preliminary Draft: 07/06/01 17

Part Number: 07100029, Revision: 002 Confidential

All trademarks and copyrights are the property of Xircom, Inc., an Intel company

• Software - All application level software required to perform basic call functions (i.e. answer,

dial, power unit off and on, etc.).

• Documentation - A complete documentation package, including schematics, theory of

operation, and all other applicable documents is required in order to connect, operate, and test

the device.

6.1.3 Schedule

Assuming no problems are uncovered, incremental SIM electrical testing can take from one to two

days. Time required for FTA regression testing depends on several factors including the amount of

testing deemed necessary by Xircom and its partnered GSM testing laboratory, laboratory availability,

and so forth.

6.2 Safety

Xircom maintains relationships with various product safety testing organizations. Xircom can provide

the manufacturer of the end device incorporating the Core Engine with assistance in:

• Product safety evaluation

• Product safety approval services, including UL and other NTRL approvals

• CB Scheme reports

6.2.1 Materials

The customer must provide the following material to Xircom in order to support Xircom’s testing of the

end device:

• Hardware - Sufficient samples to support simultaneous UL and other NTRL approvals.

Modifications to the hardware may be required.

• Software - All application level software required to perform basic call functions (i.e. answer,

dial, power unit off and on, etc.).

• Documentation - A complete documentation package, including schematics, theory of

operation, and all other applicable documents is required in order to connect, operate, and test

the device.

6.2.2 Schedule

Approval testing duration depends on the exact tests, which are required by Xircom, our safety testing

organizations, and the manufacturer of the end device incorporating the Core Engine. An example of

an Approvals Worksheet is illustrated in Appendix A.

6.3 Emissions

Xircom works with several EMC test labs and is experienced in solving EMC issues. Xircom can

provide the manufacturer of the end device incorporating the Core Engine with assistance in:

• Initial design consultations

• Formal testing and test execution

• EMC issues that may arise when integrating it into a final product

• Acquisition of approvals

Core Engine Approvals Guide Preliminary Draft: 07/06/01 18

Part Number: 07100029, Revision: 002 Confidential

All trademarks and copyrights are the property of Xircom, Inc., an Intel company

6.3.1 Materials

The customer must provide the following material to Xircom in order to support Xircom’s testing of the

end device:

• Hardware - Sufficient samples to support EMC testing and approvals. Modifications to the

hardware may be required.

• Software - All application level software required to perform basic call functions (i.e. answer,

dial, power unit off and on, etc.).

• Documentation - A complete documentation package, including schematics, theory of

operation, and all other applicable documents is required in order to connect, operate, and test

the device.

6.3.2 Schedule

Approval testing duration depends on the exact tests, which are required by our EMC testing

organizations, Xircom and the manufacturer of the end device incorporating the Core Engine.

6.4 Miscellaneous Items

Xircom can provide the manufacturer of the end device incorporating the Core Engine with assistance

in other areas including:

• UL and other NTRL approvals, listings, and reports.

• Product labeling (i.e. FCC/IC, and UL) of the final device into which the Core Engine has

been integrated - Xircom maintains relationships with various product safety testing

organizations which provide a full range of product safety evaluation and approval services,

including CB Scheme reports.

• FTA Completion and IMEI acquisition

• Operator terminal requirements, testing and approvals

6.4.1 Audio Testing

Xircom can provide the manufacturer of the end device incorporating the Core Engine with assistance

with testing the audio functionality. If the device is more of a traditional telephone terminal than a data

terminal, PCS 11.10 audio testing may be required of the built-in audio (speaker/microphone)

functionality. Audio quality of terminals is important to network operators and operator requirements

need to be addressed. Although audio testing of headset audio implementation is currently not

supported or mandatory it should be verified whether the target operators and test lab requires testing

of the device.

Because audio performance is a combination of both the Core Engine (baseband audio circuitry) and

external speaker/microphone components, audio pre-testing is recommended as soon as feasible and

is likely a joint effort between Xircom and the manufacturer of the end device incorporating the Core

Engine.

6.4.2 Integration Testing

Some level of integration testing should be done as soon as the core is integrated into the final

product. The objective is to look for any possible interaction between the core and rest of the product.

This could be in either direction (i.e. radio channel desensitizing, performance degradations, immunity

issues due to radiated RF, etc.). Suitable testing may be rolled into "delta" FTA testing. Since FTA

Core Engine Approvals Guide Preliminary Draft: 07/06/01 19

Part Number: 07100029, Revision: 002 Confidential

All trademarks and copyrights are the property of Xircom, Inc., an Intel company

testing is conducted using coax, similar evaluation of core/product interactions in an "over the air"

(antenna attached) configuration is also advisable at an early point in the integration process.

Although the test are the prime responsibility of the manufacturer of the end device incorporating the

Core Engine, Xircom can provide assistance, participation, guidance, and test lab support either at

Xircom or in another place.

Core Engine Approvals Guide Preliminary Draft: 07/06/01 20

Part Number: 07100029, Revision: 002 Confidential

All trademarks and copyrights are the property of Xircom, Inc., an Intel company

Approvals Worksheet

FCC Part 2 FCC Part 15 FCC Part 24 SAR UL1950 CTI

PCS 11.10 E911 Section 255 RS-133

Hardware

Software

Quantit

Date Re

uired

Hardware

Software

Quantit

Date Re

uired

Status (Open/Closed)

Actual End Date

Product Label Affected

Product Documentation Affected

Remarks

Test Method & Relevant Documentation

Completion Required Date

Estimated Start Date

Actual Start Date

Test Platform

Requirements

(Final Test &

Submission

)

Test Platform

Requirements

(Initial Pre-Test)

Approval Name

Test Performed By

Test Location

Test Duration

(

weeks

)

Submission Performed By

Test Fee

(

US$

)

Regulation Fee (US$)

Xircom An Intel GEM3501 Core Engine, PCS-1900 GSM Radio Module User Manual Core Engine XGAP Specification

Xircom, An Intel Company Core Engine, PCS-1900 GSM Radio Module Core Engine XGAP Specification

Contents

Core Engine Approvals Guide

Navigation menu

Namespaces

Views

Navigation
