User Manual
User Manual - INTRODUCTION
Copyright 2003 - eXI Wireless Systems Inc. Page XX 980-000003 – 002. R1.01
TAG LINK
The eXI Tag Link device automates tag administration by providing a localized
eLink between the Halo or Assetrac application software and the targeted tag
device.
The Tag Link communicates directly with the system computer through a serial
port and may be powered by an internal 9 volt battery or accessory AC wall
adapter. The Tag Link enables the software application to transparently interact
with the tags.
Tag Link Views
PHOTO ILLUS: TAG LINK WITH PTAG
WITH LED HIGHLIGHTED
PHOTO ILLUS: TAG LINK WITH MOTHER TAG
User Manual - INTRODUCTION
Copyright 2003 - eXI Wireless Systems Inc. Page XX 980-000003 – 002. R1.01
Tag Link Range
The communication range for Tag Link is designed to be typically less than 12
inches. Therefore, it is recommended that the tags be located within 6 to 12
inches of Tag Link. Those tags with ‘off body’ sensor must be placed on the front
panel in the marked area. This will assure that the alarm TIC message is not
transmitted.
Tag Link Functions
The following table lists the functions that are performed transparently in
response to commands from the application software:
COMMAND TAG LINK ACTION LED
Power Up Powers up from sleep mode none
Power Down Return to sleep mode immediately or after 30
seconds if no application command
none
Check RF Noise Measures and reports interference at 307 kHz
Measures and reports interference at 433.92 MHz
Green Flashes
Red Flashes
Test Tag TIF Interrogates tag and returns ID and tag status See next table
Test Tag TIC Tag Link waits for TIC signal from specified tag See next table
Set TLM Tag Link issues eLink TLM set command See next table
Disable TLM Tag Link issues eLink TLM disable command See next table
Check TLM Tag Link queries tag and reports rate to application See next table
Assign MTAG Reads Mother Tag ID and assigns dynamic ID See next table
MTAG Bond Sends baby tag ID(s) to Mother Tag, Mother Tag is
then bonded to the assigned tag(s)
See next table
Each operation is performed for a maximum of 10 seconds. During application
the following audio-visual signals are output:
ACTION BEEPER LED’s
Command received Very short beep None
Command succeeded Longer beep random
Command failed 4 short beeps Both briefly on
User Manual - SUPERVISOR
Copyright 2003 - eXI Wireless Systems Inc. Page 137 980-000003 – 002. R1.01
Restricted Rights
eXI's commercial software and commercial computer software documentation is provided to United States Government
agencies in accordance with the terms of this Agreement, and per subparagraph "(c)" of the "Commercial Computer
Software - Restricted Rights" clause at FAR 52.227-19 (June 1987). For DOD agencies, the restrictions set forth in the
"Technical Data-Commercial Items" clause at DFARS 252.227-7015 (Nov 1995) shall also apply.
FCC Regulations
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) This device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for Class B Digital Device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures.
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
eXI Wireless Systems Model No.: Tag Link
CANADA: 287710217261A
FCC ID: HE7TGL
* This device complies with Part 15 of the FCC Rules. Operation is subject to the following two rules: (1)
This device may not cause harmful interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation.
Made in Canada
