XPLORE TECHNOLOGIES® - RIM CONFIGURATION AND USE
1 XPLORE TECHNOLOGIES CORP.
XPLORE UserManual– RIM v.02_13_03_b
Xplore Technologies
Rim 1902g and 1802g Modem Configuration Requirements
Please note these instructions are for the integrated RIM Modems only. This Unit has been configured for the
RIM module, DO NOT change any other settings than listed below, otherwise modem might not operate.
RIM OEM Radio Modem for GSM/GPRS Wireless Networks
Required information
Before you start, you should have the following information available:
• access point name (APN) for your network
• IP address for your primary domain name server (DNS)
Connecting with Windows 2000/XP
To connect the radio modem to your computer, you must perform the following tasks:
• Modify the modem init string with APN Name
• Modify the dial-up connection TCP/IP DNS information
To Modify APN in modem properties
1. On the Start menu, select Settings > Control Panel. The Control Panel window appears.
2. Double-click the Phone and Modem Options icon. The Phone and Modem Options window
3. appears.
4. Click the Modems tab.
5. On the Modems tab, select the modem 28800 standard and click Properties. The Properties window appears.
6. Click the Advanced tab.
7. In the Extra initialization commands field, Change the last to the APN name given by Provider:
at+cgdcont=1,"IP","apn_name" where apn_name is the access point name (APN) for your network
8. Click OK. The Phone and Modem Options window appears.
9. Click OK.
To Modify DSN information in dialup connection
1. Select the Dialup connect (Named GPRS) properties, hightlight, right-click, properties.
2. Click the Networking tab.
3. Click Internet Protocol (TCP/IP) and click Properties. The Internet Protocol (TCP/IP) Properties window appears.
4. Enable the Use the following DNS server addresses option. In the Preferred DNS server field, type the IP
address of your primary DNS server.
5. Click OK. The Properties window appears.
6. Click OK.
7. Click OK.
To Use the RIM 1902G GPRS Modem
Eventhough communication to the modem is possible the GPRS portion is off. This is the default every time the unit is
booted.
To turn on the radio, double click icon on desktop RIMON.
Double click on the Dialup GPRS connection. If APN is typed correctly then the module will connect.
To turn off the radio, double click icon on desktop RIMOFF.
