VANTAGE VX1 User Manual HTML Version

Users Manual

Ê¿²¬¿¹» ÊÈï Bluetooth® Headset

User Manual

BTH-510 DIAGRAM

1. Charging port 2. Ear loop

3. Soft gel ear tips 4. Multifunction button

5. Volume control button 6. Status Indicator light

7. Microphone

EAR TIP ADJUSTMENT and SELECTION

1 2 3 4

The BTH-510 headset comes with three (large, medium, and small)

soft-gel ear tips and an optional ear loop. The ear loop and

mid-sized ear tip are installed on the headset in the package.

1.Turn the ear tip clockwise to position R and fix it on the right ear.

2.Turn the ear tip counter-clockwise to position L and fix it on the

left ear.

3.Hang the headset on your ear and examine if it fits. If not, then

replace it with a suitable one.

4.Turn the ear tip to position Nas shown in the diagram and it can

be removed. To avoid damaging the ear tip, please hold the

bottom of the ear tip as shown on the arked spot?before

pulling it out.

5.Hold the ear tip downward to position N and fix it on the

headset. Then, turn it to position R or L.

6.When not in use, please lock the ear tip at either R or L position

to avoid drop-off.

Marked spot

4 5

EAR LOOP

The ear loop was installed on the headset. It enhances the stability

of the headset. To switch it to the other ear, you may remove it from

the headset, turn it over to the other side, and re-install it on the

headset.

CHARGING YOUR HEADSET

Warning: Use the supplied charger only.

One must fully charge the battery before first use. Generally, the

process takes about two hours.

1. Connect the USB cable to BTH-510 and USB car charger,

the computer, or other power sources.

2. While charging, the status indicator light turns red constantly. It

will be turned off when charging is complete.

3. Detach the USB cable from BTH-510 and USB car charger, the

computer, or other power sources.

Warning: For your safety, if you need to answer the headset,

please disconnect it from the power source.

LOW BATTERY:

The headset needs to be recharged when it flashes red.

POWER ON/OFF

Power on: Long-press the multifunction button for about 6~8

seconds, till the status indicator light turns blue.

Power off: Long-press the multifunction button for about 3~4

seconds, till the red status indicator light turns on.

PAIRING and LINK

Before using the headset for the first time, one must pair it with the

Bluetooth® phone or other Bluetooth® devices. BTH-510 can pair up

to eight (8) Bluetooth® devices or link to two Bluetooth® devices at

the same time (double stand-by). Note that a few models of

SonyEricsson mobile phones are unable to do double-standby with

BTH-510. The following procedure describes how to do paring

WORK WITH TWO Bluetooth® DEVICES

BTH-510 can be linked to two Bluetooth® devices simultaneously.

This is called dual-linking. This feature lets you control two

Bluetooth® devices using a single headset. When your Bluetooth®

headset is in the dual-linking state and there is an incoming call

from handset A, then your headset will tear down the link to

handset B. It will restore the link to handset B when the call from

handset A is terminated. Note that some SonyEricsson handsets

cannot do dual linking with BTH-510.

USING BTH-510

Call answering: Short-press the multifunction button to answer an

incoming call or to answer the call using the Bluetooth® device and

then transfer the call to BTH-510.

Call termination: Short-press the multifunction button to terminate

an active call or hang up the call using the Bluetooth® device.

Make a phone call: Make a phone call from the Bluetooth® device

and the call will switch automatically to the headset. The procedure

may be different depending on the setup of the Bluetooth® device..

Volume adjustment: Press the Volume Control Button back and

forth to change the volume level during the call.

Last-number redial: Double-click the multifunction button to redial

the last number.

Voice-activated dialing：Short-press the multifunction button and

make a voice after you hear a beep to start dialing. The call may

get transferred to the headset automatically. To use voice-activated

dialing, one must enable the voice dialing capability on the

Bluetooth® device. Make sure that the voice for activating the call is

recorded in advance.

Call

ejection: Long-press the multifunction button for 2 seconds

will reject the incoming call.

Mute: Double-click the multifunction button will put the call on hold.

In this case, the call is muted.

Switch Calls: long-press the multifunction button for 2 seconds will

switch an active call from the headset to the Bluetooth® device, or

vice versa.

Switch Calls During Dual-Linking: When the earphone is in the

linked mode, short-press both the multi-function key and volume

control key simultaneously, then the red indicator light will flash

twice, and the dual-linking capability will be activated; by long press

both keys, then the blue indicator light will flash twice, and the

dual-linking capability will be deactivated.

BTH-510 STATUS INDICATOR:

StatusStatus Indicator Light

Stand-by Blue light flashes every 6 seconds

Connect Blue light flashes 3 times every 10 seconds

Talking Blue light flash every 10 seconds

Powering off Red light is on steadily

Pairing mode Blue/red lights flash alternatively

Ringing Purple flashes

Low battery Red flashes

Charging battery Red light on for charging; light turns off

when charging is done

PRODUCT SPECIFICATIONS:

Version: Bluetooth® 2.1+EDR, Class 2

Range: 10 meters

Talk Time: About 5 hours

Standby Time: Approximately 150 hours

Charge Time: About 2 hours

Power: 5V DC - 150 mA

Battery Type: Lithium Ion

CONTENT OF PACKAGE:

Examine the package and make sure that it contains the following

items. If any item is missing or damaged, please contact your sales

agent immediately.

One (1) Bluetooth® headset

One (1) ear loop

Three (3) ear tips in large, medium and small size

One (1) USB charging cable

One (1) User manual.

Ð®±¼«½¬ Þ´«»¬±±¬¸ Ø»¿¼-»¬

Ì®¿¼» Ò¿³» Ê»®Ì·¨

Ó±¼»´ Ò«³¾»® ÊßÒÌßÙÛ ÊÈï

ÛËÌ Ð±©»® Î¿¬·²¹ ëÊÜÝô ïëð³ß º®±³ Þ¿¬¬»®§

Ð±©»® ß¼¿°¬»® Ó¿²«º¿½¬«®»®

×òÌòÛò

ÓÑÜÛÔæ ØÛÍðëóïîëðËðïë

×ñÐæ ïððóîìðÊô ëðóêðØ¦ô ðòîß

ÑñÐæ ëÊô ðóðòïëß

Ñ°»®¿¬·²¹ Ú®»¯«»²½§ Î¿²¹» îìðî ¢ îìèð ÓØ¦

Ó±¼«´¿¬·±² Ì»½¸²·¯«» ÙÚÍÕ º±® ïÓ¾°-å ñìóÜÏÐÍÕ º±® îÓ¾°-å

èÜÐÍÕ º±® íÓ¾°-

Ì®¿²-³·¬ Ü¿¬¿Î¿¬»

Ò«³¾»® ±º Ý¸¿²²»´- éç Ý¸¿²²»´-

ß²¬»²²¿ Í

»½·º·½¿¬·±² Ó«´¬·´¿

»® Ý¸·

ß²¬»²²¿ ñ Ù¿·²æ îòë¼Þ

between BTH-510 and typical Bluetooth® phones. The pairing

procedure to different Bluetooth® devices may vary depending on the

brand and models. Please check the user manuals of those

Bluetooth® devices for details.

1. Make sure your headset is turned off.

2. Press and hold the multifunction button till the red/blue status

indicator lights flashes alternatively.

3. Follow the instruction of the phone manual to activate the

Bluetooth® function on your phone and search for Bluetooth®

devices.

4. When the searching process is done, select TH-510?voice

device.

5. Enter the preset passkey ?000?and paring will be successful. At

this point, the headset enters the stand-by mode. If the handset

supports simplified paring capability, then there is no need to enter

the passkey. If paring fails, then repeat steps 1 through 5 of the

above procedure.

6. Confirm to link to the BTH-510 and the headset will enter the

onnect?mode.

When BTH-510 is turned on, it will automatically be linked to the last

device to which it was linked to.

NCC (DGT) NOTICE

According to the Management Rules for low-power electromagnetic waves of electrical

machinery, the product has been tested and found to comply with the related rules as follows:

Rule 12: Any company, sales agent, or user are not allowed to change the frequency, to

increase the power level, or to modify the characteristics or capabilities of the original design.

Rule 24: The use of low-power electromagnetic waves of electrical machinery shall not affect

the safety of flight objects or disturb legal communications. If it violates the rules, one shall

stop using it till the problem is corrected.

The legal communications mentioned above means wireless communications specified in the

rules for governing the communications operations. The right of electrical machinery with

low-power electromagnetic waves is lower than that of legal communications or industrial,

scientific, or medical equipment that emit electromagnetic waves.
