Yaesu Musen 10623X20 Portable Transceiver User Manual USERS MANUAL

Yaesu Musen Co., Ltd. Portable Transceiver USERS MANUAL

USERS MANUAL

FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
1
Important Notice!
FCC RF Exposure Compliance Requirements for Occupational Use Only:
This Radio has been tested and complies with the Federal Communications Commission
(FCC) RF exposure limits for Occupational Use/Controlled exposure environment. In
addition, it complies with the following Standards and Guidelines:
FCC 96-326, Guidelines for Evaluating the Environmental Effects of Radio-Frequency
Radiation.
FCC OET Bulletin 65 Edition 97-01 (1997) Supplement C, Evaluating Compliance with
FCC Guidelines for Human Exposure to Radio Frequency Electromagnetic Fields.
ANSI/IEEE C95.1-1992, IEEE Standard for Safety Levels with Respect to Human
Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz.
ANSI/IEEE C95.3-1992, IEEE Recommended Practice for the Measurement of
Potentially Hazardous Electromagnetic Fields - RF and Microwave.
This radio is NOT approved for use by the general population in an uncontrolled
environment. This radio is restricted to occupational use, work related operations only
where the radio operator must have the knowledge to control its RF exposure
conditions.
When transmitting, hold the radio in a vertical position with its microphone 1 to 2 inches
(2.5 to 5 cm) away from your mouth and keep the antenna at least 1 inch (2.5 cm) away
from your head and body.
The radio must be used with a maximum operating duty cycle not exceeding 50%, in
typical Push-to-Talk configurations. DO NOT transmit for more than 50% of total radio
use time (50% duty cycle). Transmitting more than 50% of the time can cause FCC RF
exposure compliance requirements to be exceeded. The radio is transmitting when the
red LED on the top of the radio is illuminated. You can cause the radio to transmit by
pressing the P-T-T button.
Always use Vertex Standard authorized accessories.
About the BRS (Business Radio Service) Radio
The BRS frequencies are a part of the FCC’s Industrial/Business Pool for the operation of a
commercial activity.
You must obtain a license for a BRS system. Application for a BRS license is made on a
FCC Form 601. Form 601 and 159 (Remittance Advice) can be downloaded via the Internet
at www.fcc.gov/forms.
Call 1-800-418 FORM to have the forms mailed to you, or call 1-202-418-0177 from your
FAX machine to have them faxed to you on the FCC Fax-On-Demand System.
Before your filling up your FCC Form 601 Application Technical Data Section, you must
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
2
decide the frequency (or frequencies) which you will operate on.
Applications for BRS may be mailed to Federal Communications Commission, Wireless
Bureau Applications, P.O. Box 358130, Pittsburgh, PA 15251-5130.
NOTICE
There are no user-serviceable points inside this transceiver. All service jobs must be
referred to your Authorized Service Center.
An FCC License is required for operation on BRS (Business Radio Service) channels.
Introduction
The Vertex Standard VXA-710 is a compact, stylish, solid hand-held transceiver providing
communication (transmit and receive) capability on the International Aircraft Communication
Band (“COM” band: 118 ~ 136.975 MHz), and it additionally provides VOR and CDI
navigation features on the “NAV” band (108 ~ 117.975 MHz). What’s more, it also is
operational on the BRS (Business Radio Service) band, for those operators appropriately
licensed by the FCC (or the appropriate licensing authority in your country).
The VXA-710 includes Temperature display with our exclusive Omni-GlowTM display back-
light for minimal degradation of your night vision, NOAA weather band monitoring, 8-
character Alpha/Numeric Display, 70 Memory Channels, and 90 “Book Memory” Channels.
We recommend that you read this manual in its entirety, so as to understand the many
features of the VXA-710 completely. Keep this manual handy, so you may use it for
reference.
NOTE: The VXA-710’s VOR and CDI Navigation features are supplemental aids to
navigation only, and are not intended to be a substitute for accurate (primary) VOR/CDI or
landing service equipment.
Congratulations!
You now have at your fingertips a valuable communications tool-a Vertex Standard two-way
radio! Rugged, reliable and easy to use, your Vertex Standard radio will keep you in
constant touch with your colleagues for years to come, with negligible maintenance down-
time.
Please take a few minutes to read this manual carefully. The information presented here will
allow you to derive maximum performance from your radio, in case questions arise later on.
We’re glad you joined the Vertex Standard team. Call on us anytime, because
communications is our business. Let us help you get your message across.
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
3
Controls & Connectors (Top Panel)
1. Antenna Jack
This SMA jack accepts the supplied flexible antenna, or another antenna designed to
provide 50 Ohm impedance on the Aircraft Communication Band and BRS Band.
2. MIC/SP Jack
You may connect the supplied CT-96 Headset Cable, optional MH-44B4B
Speaker/Microphone to this jack.
Never connect any Speaker/Microphone that is not recommended by the manufacturer.
Because these jack connections are unique, using a Speaker/Microphone that is not
specified by Vertex Standard may damage the VXA-710.
3. VOL Knob
This control adjusts the audio volume level. Clockwise rotation increases the volume
level.
4. DIAL Selector Knob
This 20-position detented rotary switch tunes the operating frequency or selects the
memory channels.
Controls & Connectors (Front Panel)
1. LCD (Liquid Crystal Display)
The display shows the current operating conditions, including frequency, etc.
2. PWR (Power) Switch
Press and hold this switch for 3 seconds to toggle the transceiver power on and off.
3. Keypad
Several keys have triple functions.
The primary functions are labeled on the key top (activated by simply pressing the key
momentarily).
The secondary functions are labeled in yellow above the top edge of the key (activated
by pressing the key first, then the indicated key).
The third functions are labeled in black above the top edge of the key (activated by
press and holding the indicated key for 2 seconds).
These functions are described in detail on the page 6.
4. BUSY/TX Indicator Lamp
This lamp glows green when a signal is being received and red when transmitting.
You may customize the color setup via the Menu mode.
5. Loudspeaker
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
4
The internal speaker is located in this position.
6. Microphone
Speak across this opening in a normal voice level while pressing the PTT switch, to
transmit.
7. Battery Pack Latch
Open this latch for battery removal.
Primary Function
(Press Key)
Secondary Function
(Press + [F])
Third Function
(Press & Hold)
[1(VOR)TN] Frequency entry digit
“1.”
Activates VOR
mode.
Recalls Menu Item
“SQL Type” (for
activating the
CTCSS or DCS
operation on the
BRS mode).
[2(TO)CD] Frequency entry digit
“2.”
Selects “TO” VOR
mode
Recalls Menu Item
“TONE Set” (for
selecting the
CTCSS tone
frequency on the
BRS mode)
[3(FROM)DT] Frequency entry digit
“3.”
Selects “FROM”
VOR mode
Activates the DTMF
Autodialer function.
[4(CDI)] Frequency entry digit
“4.”
Activates the Course
Deviation Indicator
mode.
None
[5(APO)] Frequency entry digit
“5.”
None Recalls Menu Item
“APO” (for setting
of the Automatic
Power Off time).
[6(TAG)] Frequency entry digit
“6.”
Selects the display
type (Frequency or
Alpha-numeric Tag)
during Memory
operation.
None
[7(SPL)ST] Frequency entry digit
“7.”
None Recalls Menu Item
“Step” (for setting
of the synthesizer
steps).
[8(BEEP)] Frequency entry digit
“8.”
None Recalls Menu Item
“Beep” (for setting
of the keypad
beeper).
[9(SKIP)] Frequency entry digit
“9.”
None Sets the Memory
Skip (Omit) feature
to the current
memory channel.
[0(SQ)] Frequency entry digit
“0.”
None Recalls Menu Item
“SQL” (for setting
the squelch
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
5
threshold level.
[BAND(MODE)] Select the operation
band between the
AIR band and FM BC
band in the VFO
mode.
Select the operation
mode between the
FM and Narrow FM
on the BRS mode.
None
[121.5(HOME)] Selects the
Emergency Channel
(121.5 MHz).
Switches operation
to the “Home”
(favorite frequency)
channel.
None
[MW(SPL.W)] None Split-Memory “Write”
Command.
Memory “Write”
Command.
[SCAN(DW)MT] Activates the
Scanner.
Activates Dual
Watch.
Activates the
“Memory Tune”
mode while in the
Memory Recall
mode.
[SEL(SET)] Select the tuning
methods among the
VFO, MR, BMR, WX,
and BRS1.
Enter the “Set”
(Menu) mode.
None
[USER(KEY)]Ú2Activate the
Automatic Noise
Limiter during AM
reception.
Lock the Keypad. Switches the
frequency display
between the “Large
Character” and
“Small Character”
mode.
[F] Activates the
“Secondary” key
mode.
None None
Ú1: VFO: Variable Frequency Oscillator
MR: Memory Recall
BMR: Pre-Programmed Memories
WX: Weather Channel Memories
BRS: Business Radio Service
Ú2: The Primary and Third function of the [USER(KEY)] key may be customized by user
via the Menu mode. See page ??.
Controls & Connectors (Side Panel)
1. PTT (Push To Talk) Switch
Press this button to transmit when you are operating in the COM band or BRS band.
Release this button to return to the “Receive” mode. See page 15.
2. MONITOR Switch
This button may be pressed to “Open” the squelch manually, allowing you to listen for
very weak signals. Press and hold this button for 2 seconds to “Open” the squelch
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
6
continuously. Press this button again to resume normal (quiet) monitoring. See page
17.
3. EXT DC Jack
When an external 12-Volt DC power source is available, you may connect the (optional)
E-DC-5B DC Cable w/Noise Filter or E-DC-6 DC Cable here.
Do not connect any wire to this jack if that wire is connected directly to a 28-Volt DC
source. Connecting the VXA-710 directly to a source which exceeds 15.0 Volts DC will
result in damage to the unit.
Before You Begin
Precautions
This apparatus is capable of two-way communication on channels used for critical
aviation safety communications. Therefore, it is important that this radio be kept away
from children or other unauthorized users at all times.
When making DC connections via the (optional) E-DC-5B DC cable, be absolutely
certain to observe the proper voltage level and polarity guidelines. Do not connect this
radio directly to any 24 ~ 28 Volt DC source, nor to AC power of any kind. Connecting
the VXA-710 directly to a source which exceeds 15.0 Volts DC will result in damage to
the unit.
Do not dispose of the LI-ion Battery Pack in a fire. Do not carry a LI-ion Battery Pack in
your pocket, where keys or coins could short the terminals. This could create a serious
fire/burn danger, and possibly cause damage to the LI-ion pack.
How to Install the Quick Draw Belt Clip
Connect the hanger to the rear of the VXA-710, with the notch pointing directly up, using
the supplied screw (Figure 1). Use only the screw included with the clip to mount the clip
to the back of the VXA-710!
Clip the Quick-Draw Belt Clip onto your belt (Figure 2).
To install the VXA-710 into the Quick-Draw Belt Clip, align the hanger with the Quick-
Draw Belt Clip, and slide the VXA-710 into its slot until a click is heard (Figure 3).
To remove the VXA-710 from the Quick-Draw Belt Clip, rotate the VXA-710 180 degrees,
then slide the VXA-710 out from the Quick-Draw Belt Clip (Figure 4).
Installation of FNB-80LI Battery Pack
The FNB-80LI is a high-performance Lithium-Ion battery providing high capacity in a very
compact package. Under normal use, the FNB-80LI may be used for approximately 300
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
7
charge cycles, after which operating time may be expected to decrease. If you have an old
battery pack which is displaying capacity which has become diminished, you should replace
the pack with a new one.
Install the FNB-80LI as shown in the illustration.
Close the Battery Pack Latch on the bottom of the radio.
Do not attempt to open any of the rechargeable LI-ion packs, as personal injury or damage
to the LI-ion pack could occur if a cell or cells become accidentally short-circuited.
Battery Charging
If the battery has never been used, or its charge is depleted, it may be charged by
connecting the NC-72B/C Battery Charger, as shown in the illustration, to the EXT DC jack.
If only 12 ~ 16 Volt DC power is available, the optional E-DC-5B DC Cable (w/cigarette
lighter plug) or E-DC-6 DC Cable may also be used for charging the battery, as shown in the
illustration. The “Now Charging . . .” will blink in the display while the battery is being
charged. When charging is finished (approximately five hours), the display will change to
indicate “Complete” and the BUSY/TX indicator will blink blue.
Important Notes:
Do not leave the charger connected to the transceiver for continuous periods in excess
of 24 hours. Long term overcharging can degrade the LI-ion battery pack and
significantly shorten its useful life.
If using a charger other than the NC-72B/C, or if using a battery pack other than the
FNB-80LI, follow the appropriate instructions provided with the charger/battery. Contact
your Dealer if you have any doubts about the appropriateness of the particular charger
or battery pack you intend to use.
Installation of FBA-23 Alkaline Battery Case (Option)
The optional FBA-23 Battery Case allows receive monitoring using two “AA” size Alkaline
batteries.
To Install Alkaline Batteries into the FBA-23
Slide the batteries into the FBA-23 as shown in the illustration, with the Negative (–) side
of the batteries touching the spring connections inside the FBA-23.
Open the Battery Pack Latch on the bottom of the radio.
Install the FBA-23 into the battery compartment on the back of the transceiver, then
close the Battery Pack Latch on the bottom of the radio.
The FBA-23 does not provide connections for charging, since Alkaline cells cannot be re-
charged. Therefore, the NC-72B/C, E-DC-5B, or E-DC-6 may safely be connected to the
EXT DC jack when the FBA-23 is installed.
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
8
Notes:
The FBA-23 is designed for use only with AA-type Alkaline cells.
If you do not use the VXA-710 for a long time, remove the Alkaline batteries from the
FBA-23, as battery leakage could cause damage to the FBA-23 and/or the transceiver.
Low Battery Indication
As your battery discharges during use, the voltage will gradually become lower. When
the “BATTERY” icon will blink on the LCD display, the battery pack must be recharged
before further use.
Avoid recharging Li-Ion batteries before the “Low Battery” indicator is observed, as this
can degrade the charge capacity of your Li-Ion battery pack. Vertex Standard
recommends that you carry an extra, fully-charged pack with you so you will not lose
communications capability due to a depleted Li-Ion battery.
This “deep cycling” practice will help to maintain longer overall battery life after many
recharging cycles.
AC Operation Using NC-72B/C (Receiving only)
The VXA-710 may be operated from your house current by use of the supplied NC-72B/C
Battery Charger. The NC-72B/C should only be used for reception, because it is not capable
of supplying sufficient current to support transmission.
To use the NC-72B/C, turn the transceiver off, then plug the miniature connector of the
Battery Charger into the EXT DC jack on the side of the radio. Now plug the Battery Charger
into the wall outlet. You may now turn on the transceiver.
Basic Operation
Preliminary Steps
Install a charged battery pack onto the transceiver, as described previously.
Screw the supplied antenna onto the Antenna jack. Never operate this transceiver
without an antenna connected.
If you have an optional Speaker/Microphone or headset. we recommend that it not be
connected until you are familiar with the basic operation of the VXA-710.
Operation Quick Start
To turn the radio on, press and hold in the PWR Switch for 3 seconds.
The opening message will appear on the display, then frequency display will appear.
Press the [BAND(MODE)] key to switch the operating band between the AIR band and
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
9
FM BC band.
Directly entering frequencies from the keypad is the easiest method if you know the
frequency on which you wish to operate. Just enter the five digits of the frequency to
move to that frequency. However, there is a short-cut for frequencies ending in zero -
press the [SCAN(DW)MT] key after the last non-zero digit.
For example, to set 134.35 MHz:
press [1] Æ [3] Æ [4] Æ [3] Æ [5].
To set 118.000 MHz:
press [1] Æ [1] Æ [8] Æ [SCAN(DW)MT].
To set 118.275 MHz, you do not need to press the final “5” in the frequency:
press [1] Æ [1] Æ [8] Æ [2] Æ [7].
Note: When the entered frequency is outside of the current operating band, the entry is
ignored (i.e. VXA-710 does not permit entry of a FM BC band frequency while operating
in the AIR band).
You may also turn the top panel’s DIAL selector knob to choose the desired operating
frequency. The channel frequency will appear on the LCD.
To change frequency in 1 MHz steps, press the [F] key momentarily, then rotate the
DIAL selector knob to select the MHz digit desired. Press the [F] key once more to
resume normal channel step.
Rotate the VOL knob to set the volume level. If no signal is present, press and hold in
the MONITOR button for 2 seconds; background noise will now be heard, and you may
use this noise to set the VOL knob for the desired audio level. Press the MONITOR
button momentarily to silence the noise and resume normal (quiet) monitoring.
To turn the radio off, press and hold in the PWR switch for 3 seconds.
Squelch Adjustment
Press and hold in the [0(SQ)] key for 3 seconds. This instantly recalls Menu Item “SQL:”
on the AM or FM mode or “WSQL:” on the WFM mode (for the Broadcasting Station).
Press the [SEL(SET)] key to enable adjustment of this Menu Item.
Rotate the DIAL selector knob to set the squelch threshold (0 - 8) so that the receiver is
just silenced. A higher number indicates that a higher signal level is required in order to
open the squelch.
When you have made your setting, press the [SEL(SET)] key to save the new setting,
then press the PTT key repetitively until the radio exits to normal operation.
Accessing the 121.5 MHz Emergency Frequency
The VXA-710 can quickly access the 121.500 MHz Emergency Frequency. This function
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
10
can be activated even when the keypad lock function is in use.
To access the Emergency Frequency, press the [121.5(HOME)] key momentarily.
To exit the Emergency Frequency, press the [121.5(HOME)] key momentarily.
Tuning Methods
Throughout this manual, you will see references to several different frequency setting
methods by pressing the [SEL(SET)] key. Each will be particularly useful in a particular
operating situation, and they are described below:
VFO (Variable Frequency Oscillator)
The VFO is a “tuning dial” system which allows you to tune through the AIR band and
FM BC band using the DIAL selector, the Keypad, or the scanner. To select these bands,
press the [BAND(MODE)] key momentarily.
MR (Memory Recall)
The MR (Memory Recall) mode of the VXA-710 provides the user with the ability to
store and recall as many as 68 channels in the radio’s main memory bank. These
memory channels may also be labeled by you with an alpha/numeric name of up to 8
characters in length, to aid in quick identification of the channel. See page ?? for details
of the Memory Channel Operation.
BOOK (Pre-Programmed) Memories
The Book memories are pre-programmed, either at the factory or by your Dealer
(depending on your country’s requirements), typically including the major AIR band
station frequencies used in your area. The Book memories can be changed by the user.
See page ?? for details.
WX (Weather Channel) Memories (USA version only)
Ten Weather Channels are pre-programmed at the factory. The VXA-710 will
automatically scan this special bank when it is selected by the user. See page ?? for
details of the WX Memory Channel Operation.
BRS (Business Radio Service) Memories
21 BRS Channels are pre-programmed at the factory. See page ?? for details of the
BRS Memory Channel Operation.
Transmission
To transmit, press and hold in the PTT switch. Speak into the microphone area of the
front panel grille in a normal voice level.
To return to the receive mode, release the PTT switch.
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
11
Monitor Key
When listening to a very weak signal from an aircraft or ground station, you may observe the
signal disappearing periodically as the incoming signal strength becomes too weak to
override the squelch threshold setting.
To disable the squelch temporarily, press and hold the MONITOR key for 2 seconds on the
left side of the radio, just below the PTT button. The squelch will remain open and you
should have a better chance of hearing weak signals.
To return to normal operation, press the MONITOR key momentarily.
ANL (Automatic Noise Limiter) Feature
For reduction of impulse noise in the AM mode, such as that produced by an engine’s
ignition system, the ANL feature may prove helpful.
To activate the ANL feature, press the [USER(KEY)] key momentarily. The “ANL” icon
will appear on the display, and you should observe a reduction in the ignition noise.
To turn the ANL feature off, press the [USER(KEY)] key again; the “ANL” icon will
disappear from the display.
Note: The ANL feature is only activated on the Air Band.
LOCK Function
The lock function prevents accidental changes to the frequency setting and the keypad
controls.
To activate the lock feature, press the [F] key followed by [USER(KEY)] key.
In the LOCK mode, the “LOCK” icon will appear on the display.
To turn the lock feature off, press the [F] key followed by [USER(KEY)] key again.
You can still access the 121.500 MHz Emergency Frequency when the LOCK function is
on. Simply press the [121.5(HOME)] key momentarily (this key never locks). Pressing
this key also unlocks the radio.
Beep On/Off
The VXA-710’s key/button beeper provides convenient audible feedback whenever a button
is pressed. Each key and button has a different beep pitch, and each function has a unique
beep combination.
When you are scanning, the beeper will be heard each time the scanner halts on a busy
channel. This may be distracting in some environments; if you want to turn the beeper off (or
back on again):
Press and hold the [8(BEEP)] key for 2 seconds. This instantly recalls Menu Item
“Beeper.”
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
12
Press the [SEL(SET)] key to enable adjustment of this Menu Item.
Rotate the DIAL selector knob to select the desired selection.
On: Sounds a keypad beeper corresponding to a musical note.
DTMF: Sounds a keypad beeper corresponding to a DTMF tone.
Off: Keypad beeper is “off.”
When you have made your selection, press the [SEL(SET)] key to save the new setting,
then press the PTT key repetitively until the radio exits to normal operation.
Reception of Weather Channel Broadcasts (USA version only)
The VXA-710 can receive VHF Weather Channel broadcasts, which may assist your flight
planning. The VXA-710 includes a ten-channel auto-search feature, which simplifies access
to Weather Channels when you are in an unfamiliar location.
To receive Weather Channels, press the [SEL(SET)] key (repeatedly, if necessary) to
select the Weather Channel mode. In the Weather Channel mode, “WX” will appear
upper left corner of the display.
The VXA-710 will now scan quickly though the ten standard Weather Channels, and will
stop on the first active station found.
If there are two or more weather channels audible in your area, you may select the
alternate channel(s) by pressing the PTT switch. Pressing the PTT switch re-initiates the
scanning process.
If there are no Weather Channels in your area, the scanner will not stop. Press the
MONITOR button to stop the scanner.
You can also select Weather Channels manually by rotating the DIAL selector knob.
To exit the Weather Channel mode, press the key momentarily to return to the VFO
mode.
Note 1: In the event of extreme weather disturbances, such as storms and hurricanes, the
NOAA (National Oceanic and Atmospheric Administration) sends a weather alert
accompanied by a 1050 Hz tone and subsequent weather report on one of the NOAA
weather channels. You may setup the Alert function when receiving the Weather Alert signal
via Menu Item (6. Misc Setup, 3. WX Alert), if desired.
Note 2: The Weather Channel mode memorizes the last Weather Channel you have used,
and will retain this information until the radio is turned off.
Receive Battery Saver Setup
An important feature of the VXA-710 is its Receive Battery Saver, which “puts the radio to
sleep” for a time interval, periodically “waking it up” to check for activity. If somebody is
talking on the channel, the VXA-710 will remain in the “active” mode, then resume its “sleep”
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
13
cycles. This feature significantly reduces quiescent battery drain, and you may change the
amount of “sleep” time between activity checks using the Menu System:
Press the [F] key, then press the [SEL(SET)] key to activate the Menu (“SET”) mode.
Rotate the DIAL selector knob to select Menu Item “3. Receive,” then press the
[SEL(SET)] key.
Rotate the DIAL selector knob to select Sub Menu Item “5. RX Save,” then press the
key.
Press the [SEL(SET)] key again to enable adjustment of this Menu Item.
Rotate the DIAL selector knob to select the desired “duty cycle” (receive:sleep). The
selections available are 1:1, 1:2, 1:3, 1:4, 1:5, and ABS* or oFF. The default value is
ABS.
When you have made your selection, press the [SEL(SET)] key to save the new setting,
then press the PTT key repetitively until the radio exits to normal operation.
*ABS: Automatic Battery Saver, based on activity on the receiver.
The setting of 1:5 will promote the greatest conservation of battery capacity, but the
receiver’s response time to incoming calls will be slowed somewhat.
Note: This feature does not operate during Scan, Dual Watch, or Spectrum Scope
Monitoring.
Memory Operation
The VXA-710 provides 70 user-programmable Main memories, labeled “MR1” through
“MR68,” “MRLch,” and “MRUch,” up to 90 pre-programmed memories, designated “Book”
Memories, labeled “BMR1” through “BMR90,” and one Home channel, allowing storage and
quick recall of favorite operating frequency.
The Main memories and “Book” Memories can be assigned alpha-numeric names of up to
eight characters.
Memory System Operation
The VXA-710’s Main Memory system allows the user to store, label, and recall channel
frequencies which you may want to use frequently. You may store VFO frequencies, “Book”
Memory frequencies, and/or Weather Channel frequencies (USA version only) into the Main
Memory system.
Memory Storage
Select the desired frequency in the VFO mode, or recall the “Book” Memory channel,
Weather channel, or BRS channel to be stored in the Main Memory.
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
14
Press and hold in the [MW(SPL.W)] key for 2 seconds. The display will indicate “MW”
and a channel number will blink on the LCD.
Within five seconds of pressing the [MW(SPL.W)] key, rotate the DIAL selector knob to
select the desired memory channel number for storage. In order to prevent writing over
memory channels, an “Open Door” icon will appear at the right of the channel number to
indicate if the memory channel is vacant.
Now press and hold in the [MW(SPL.W)] key for 2 seconds; you will now see the
blinking “A” character on the LCD. To attach an alpha/numeric name (label) to the
memory, proceed to the next step; otherwise press and hold in the [MW(SPL.W)] key for
2 seconds to save the entry and exit.
To label a memory with an alpha/numeric name, the next step is to use the DIAL selector
knob to select any of the 125 available characters (including letters, numbers, and
special symbols). Press the [USER(KEY)] key repeatedly to recall the desired letter,
number, and symbol in the first character slot (a Æ . Æ 0 Æ A Æ a ...). When the desired
first character appears, press the [SEL(SET)] key momentarily to select it and move on
to the next character.
Select succeeding characters in the same manner, pressing the [SEL(SET)] key
momentarily after each selection.
After entering the entire name (eight characters maximum), press the [MW(SPL.W)] key
for 2 seconds to save all data for the channel and exit.
Recalling the Memories
Press the [SEL(SET)] key, repeatedly if necessary, until “MR” (Memory Recall) appears
on the display. In the MR mode, you will see the previously-selected channel number
appearing at the bottom of the “MR” icon on the LCD.
Rotate the DIAL selector knob to select the desired memory channel.
You may change the readout structure of the Memory display between “Frequency
Indication” and “Frequency Indication plus Alpha-numeric Label” by pressing the [F] key
followed by [6(TAG)] key.
To exit the Memory mode, press the [SEL(SET)] key three times to return to the VFO
mode.
Note 1: In either the Memory mode or the “Book” Memory mode, an easy way to recall
memories is to key in the memory channel number (except memory channel “Lch” and
“Uch.” For example, to recall memory channel #06, press the [0] key followed by [6] key. To
recall memory channel #60, press the [6] key followed by [0] key.
Note 2: In either the Memory mode or the “Book” Memory mode, you can change memory
channels in 10-channel steps: press the [F] key momentarily, then rotate the DIAL selector
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
15
knob. The “F” icon will show at the left bottom of the display when the 10-channel-step
tuning mode is active. Press the [F] key once more to resume normal channel selection in
one-channel steps.
Memory Offset Tuning
Once you have recalled a particular memory channel, you may easily tune off that channel,
as though you were in the “VFO” mode.
With the VXA-710 in the Memory Recall mode, select the desired memory channel.
Now press and hold in the [SCAN(DW)MT] key for 2 seconds. The “MR” indicator will be
replaced by one which says “MT” (Memory Tuning).
Rotate the DIAL selector knob, as desired, to tune to a new frequency. The synthesizer
steps selected for VFO operation on the current band will be the steps used during
Memory Tuning.
If you wish to return to the original memory frequency, press and hold in the
[SCAN(DW)MT] key for 2 seconds. The “MT” indicator will be replaced by “MR.”
If you wish to store a new frequency set during Memory Tuning, just press and hold in
the [MW(SPL.W)] key for 2 seconds, per normal memory storage procedure.
Note: The Memory Tune feature dose not activated on the memory channel which is stored
the WX or BRS channel frequency.
Deleting Memories
With the VXA-710 in the Memory mode, rotate the DIAL selector knob to select the
memory channel you wish to delete.
Press the [F] key, then press and hold the [MW(SPL.W)] key for 2 seconds. The
previously-selected memory will be deleted.
Note: Once deleted, channel data cannot be recovered!
Home Channel Memory
A special “HOME” channel is available, to allow quick recall of a favorite operating frequency.
Memory storage is simple to accomplish:
Select the desired frequency in the VFO mode, or recall the “Book” Memory channel,
Weather channel, or BRS channel to be stored in the “HOME” channel.
Press and hold in the [MW(SPL.W)] key for 2 seconds. The display will indicate “MW”
and a channel number will blink on the LCD.
Within five seconds of pressing the [MW(SPL.W)] key, press and hold in the
[121.5(HOME)] key for 2 seconds. The frequency and other data (if any) will now be
stored in the special “HOME” channel register.
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
16
To recall the “HOME” channel, press the [F] key followed by [121.5(HOME)] key.
You may also attach an alpha/numeric name (label) to the “HOME” channel.
Recall the “HOME” channel, by pressing the [F] key followed by [121.5(HOME)] key.
Now press and hold in the [MW(SPL.W)] key for 2 seconds; you will now see the
blinking “A” character on the LCD. Use the DIAL selector knob to select any of the 125
available characters (including letters, numbers, and special symbols). Press the
[USER(KEY)] key repeatedly to recall the desired letter, number, and symbol in the first
character slot (a Æ . Æ 0 Æ A Æ a ...). When the desired first character appears, press
the [SEL(SET)] key momentarily to select it and move on to the next character.
Select succeeding characters in the same manner, pressing the [USER(KEY)] key
momentarily after each selection.
After entering the entire name (eight characters maximum), press the [MW(SPL.W)] key
for 2 seconds to save all data for the channel and exit.
Press the [F] key followed by [6(TAG)] key to change the readout structure of the
Memory display between “Frequency Indication” and “Frequency Indication plus Alpha-
numeric Label.”
Scanning Operation
Basic Scan
The VXA-710 allows you to scan automatically in the VFO*1, Main Memory, “Book” Memory,
Weather Channel*2, or BRS channel modes. It pauses on signals encountered, so you can
talk to the station(s) on that frequency, if you like.
*1: In the VFO mode, the automatic scanner is only available in the current operating band
(AIR band or FM BC band). Furthermore, on the AIR band, the automatic scanner is only
available in the COM band (118.000 - 136.975 MHz); when the scanner reaches the
uppermost frequency in the COM band, it will revert to the bottom end of the COM band and
repeat the scanning process until you cancel the scanning process.
*2: USA version only.
If you wish to scan in the NAV band (108.000 - 117.975 MHz), you can do so manually, as
described below.
Scanning operation is basically the same in each of the above modes.
Press the [SCAN(DW)MT] key momentarily to start the automatic scanner upward
(toward a higher frequency or a higher channel number).
When the scanner encounters a signal, scanning pauses and the radio remains on that
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
17
channel until one second after the signal disappears, after which scanning will resume.
While the scanner remains paused on a frequency, the decimal point of the frequency
display blinks. The display will be illuminated unless the Scan Lamp Feature is turned
off.
To change the scan direction, turn the DIAL selector knob one click in the opposite
direction.
To stop the automatic scanner, press the PTT switch or the [SCAN(DW)MT] key
momentarily.
The VXA-710’s automatic scanner is not operational in the NAV band (108.000 - 117.975
MHz), because the NAV stations (ILS, etc.) transmit constantly (thereby causing the scanner
to stop repeatedly). However, you can scan manually in the NAV band, per the following
procedure:
Press and hold the [SCAN(DW)MT] key to start the manual scanner. Scanning will
continue as long as the key is depressed.
Release the [SCAN(DW)MT] key to stop the manual scanner immediately.
Note: When scanning upward in frequency, when the frequency reaches the COM Band
(118.000 - 136.975 MHz) via manual scanning, the VXA-710 will switch to the automatic
scanner mode.
Channel-Skip Scanning
Continuous-carrier stations like ATIS (Automatic Terminal Information Service) or Weather
Broadcast stations inhibit scanner operation. Since these stations are always active, the
scanner will be halted repeatedly on their channels. Such channels can be set to be
“skipped” during Memory scanning (MR, Book, WX, or BRS modes), if you like, so as not to
interfere with automatic channel scanning:
Recall the Memory Channel to be skipped during scanning.
Press and hold the [9(SKIP)] key for 2 seconds. The “ icon will appear at the left of the
frequency display, indicating that the channel is to be ignored during scanning.
Later, to re-enable the memory channel for scanning, repeat the first two steps. The
icon will disappear by the channel you have just re-enabled.
Note: A memory set to be “skipped” is still accessible for manual memory selection using
the DIAL selector knob.
Programmable (Band Limit) Memory Scan (PMS)
This feature allows you to set sub-band limits for either scanning or manual VFO operation.
For example, you might with to set up a limit of COM band (118.000 MHz to 136.975 MHz.
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
18
Here’s how to do this:
Set the radio to the VFO mode by pressing the [SEL(SET)] key and set the radio to the
AIR band by pressing the [BAND(MODE)] key, if necessary.
Using the techniques learned earlier, store 118.000 MHz into Memory Channel “Lch”
(the “Lch” designates the Lower sub-band limit).
Likewise, store 136.975 MHz into Memory Channel “Uch” (the “Uch” designates the
Upper sub-band limit).
Switch to the Memory mode by pressing the [SEL(SET)] key once, then rotate the DIAL
to select Memory Channel “Lch.”
Press and hold in the [SCAN(DW)MT] key for 2 seconds to start PMS operation; the
“MR” label will be replaced by “PMS” in the upper left-hand corner of the display.
Tuning and scanning (pressing the [SCAN(DW)MT] key) will now be limited within the
just-programmed range.
Note: The PMS feature does not activated on the WX and BRS frequencies.
Dual Watch Operation
The Dual Watch feature automatically checks for activity on a “Priority” channel* while you
are operating on another channel. During Dual Watch operation, the current channel and the
Priority channel will each be polled for a 500 ms interval, as the VXA-710 looks for activity
on each channel.
To start Dual Watch, press the [F] key followed by [SCAN(DW)MT] key.
The “DW” icon will appear on the display.
While receiving on the “current” channel (not the Priority channel), you may push the
PTT switch at any time to transmit on that channel.
When a signal is received on the Priority channel, operation immediately shifts to the
Priority channel; the “DW” icon will blink, and the display will become illuminated.
While receiving on the priority channel, if you momentarily press the PTT switch, Dual
Watch will be disabled. You may then transmit on the Priority Channel.
To stop Dual Watch, press the [F] key followed by [SCAN(DW)MT] key.
If you wish, you may use both the Dual Watch and Scan features simultaneously. To do
this, start the Dual Watch first, then start the Scanner.
* The “Priority” channel is defined as the last-used Memory Channel (when using the VFO,
“Book” memory, and BRS channel modes) or Memory Channel “1” (when using the Main
Memory mode).
Priority Dual Watch Operation
Similar to Dual Watch operation (described on previous page), Priority Dual Watch is an
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
19
enhanced version which includes the following additional features:
The receiving time interval (ratio) between the current channel and the Priority channel
may be customized via the Menu Item “PRI Time.” See page ?? for details.
Irrespective of which channel is currently being received, when the PTT button is
pushed transmission will always occur on the Priority channel.
Before initiating Priority Dual Watch, Menu Item “DW/PRI” must be set to the “PRI” mode
(instead of “DW”). See page ?? for details.
To start Priority Dual Watch, press the [F] key followed by [SCAN(DW)MT]. The “DW”
icon will appear on the display.
While receiving on the “current” (non-Priority) channel, pressing the PTT button once
causes the radio to switch to the Priority channel and cancels Dual Watch. Press the
PTT button again to transmit on the Priority channel.
When a signal is received on the Priority channel, reception immediately shifts to the
Priority channel; the “DW” icon will blink, and the display will become illuminated unless
the Scan Lamp Feature is turned off.
While receiving on the Priority channel, if you momentarily press the PTT switch, Priority
Dual Watch will be disabled. You may then transmit on the Priority Channel.
To stop Priority Dual Watch, press the [F] key followed by [SCAN(DW)MT].
Spectrum Scope Monitor
If you assign the Spectrum Scope Monitor feature to the [USER(KEY)] key (see page ??),
you may view operating activity on channels above and below the current operating channel
while operating in the VFO, Memory Tune, and PMS modes.
The display indicates the relative signal strength on channels immediately adjacent to the
current operating frequency.
Set the radio to the VFO mode by pressing the [SEL(SET)] key, if necessary.
Press (or press and hold in) the [USER(KEY)] key to activate the Spectrum Scope
Monitor.
Once the Spectrum Scope Monitor is activated, press the [SEL(SET)] key to change the
visible bandwidth between ±15 channel and ±30 channel (default: ±30 channels). The
visible bandwidth, however, depends on the selected channel step size, so match the
channel step to those typically used in your area.
To turn the Spectrum Scope Monitor off and operate on the centered (and displayed)
channel, simply press PTT switch.
Note: Audio output will be interrupted during Spectrum Analyzer operation. This is normal.
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
20
VOR Navigation (Air Band)
To Select the VOR Mode
When entering the NAV band (108.000 - 117.975 MHz), the VXA-710 selects the VOR
mode automatically. The “Course Indicator” will appear on the display, and the “TO” or
“FROM” indicator will appear at the right of the “Course Indicator” on the display.
Note: The “Course Indicator” indicates “---°” when either your aircraft is too far away
from the VOR station or if the frequency is not correctly set to that of the VOR station.
Conversely, the “Course Indicator” will indicate “Loc” when a localizer signal is being
received.
The “TO” or “FROM” flag indicators indicate whether the VOR navigation information is
based on a course leading to the VOR station or leading away from the VOR station.
To change the flag from “TO” to “FROM” or vice versa, press the [F] key followed by
[3(FRM)DT] key or press the [F] key followed by [2(TO)CD] keys, respectively.
The (small) frequency indication may be toggled to display using larger characters (but
“Course Indicator” and “TO”/“FROM” flag are reduced in size), if you assign the “XFER”
feature to the [USER(KEY)] key. See page ?? for details.
Flying to a VOR Station
The VXA-710 can indicate the deviation from the direct course to a VOR station.
Select a VOR station on your aeronautical chart and turn the DIAL selector knob (or
enter the frequency directly with the keypad) to the frequency of the VOR station.
To indicate the deviation between your current flight path and the desired course, press
the [F] key followed by [4(CDI)] key to change to the CDI (Course Deviation Indicator)
mode. The “Course Deviation Arrow” will appear on the display when your aircraft is off
the direct course to the VOR station.
When your aircraft is off course to the right, the Course Deviation Arrow display will
show bars to the left side of the diamond (“|||). When your aircraft is off course to
the left, the Course Deviation Arrow display will show bars to the right side of the
diamond (|||”). Correct your course until no bars appear on either side of the CDI
“diamond” (only () will be visible when the heading is correct).
To return to the DVOR mode, press the [F] key followed by [1(VOR)TN] key.
Entering a Desired Course
The VXA-710 can also be configured to indicate the deviation from the desired course, not
only the deviation from the path to the VOR station.
Set the frequency to the desired VOR station.
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
21
Change the “TO” or “FROM” indication to “TO,” if it is not in that mode already.
Press the [F] key followed by [4(CDI)] key to change to the CDI mode.
Set the desired course to the VOR station using the DIAL selector knob or keypad
(three-digit input; e.g. for 47°, press [0] Æ [4] Æ [7]).
Note 1: The (“|||”) or (“|||”) indication will appear on the display when your
aircraft is off the desired course.
Note 2: When your heading is correct, the ABCS function (see below) may be more
useful than the course input option.
The Course Deviation Arrow points to the right when your aircraft is off course to the left,
and it points to the left when your aircraft is off course to the right.
Note 1: To get back on course, fly right more than the number of degrees indicated by
the Course Deviation Arrow.
Note 2: If the overflow indicator “υ appears on the right side, select a heading plus 10
degrees to the desired course; if the overflow indicator τ appears on the left side,
select a heading minus 10 degrees.
Auto Bearing Center System (ABCS) Mode
In the CDI mode, the Auto Bearing Center System (ABCS) adds or subtracts the number of
degrees indicated by the CDI from the Omni Bearing Selector (OBS).
Position Cross-checking
Select two VOR stations on your aeronautical chart.
Set the frequency of one of the VOR stations in the VOR mode. The course indicator will
show the course deviation from the VOR radial. Note the radial you currently are on.
Now set the frequency of the other VOR station in the VOR mode. Note the radial from
the station you are on.
Extend the radials from each VOR station on the chart. Your aircraft is located at the
point where the lines intersect.
Split Operation
The split operation feature allows you to transmit a call to a Flight Service Station using the
COM band frequencies, while receiving a VOR station (in the NAV band). VOR stations
equipped with this capability typically are shown, on navigation charts, with the voice calling
frequency in parenthesis above the navigation frequency.
Press the [SEL(SET)] key, repeatedly if necessary, to select the VFO mode.
Set the desired VOR station frequencies in the NAV band (108.000 - 117.975 MHz)
using the DIAL selector knob or keypad.
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
22
Press the [F] key followed by [MW(SPL.W)] key. The “±” icon will blink, and the transmit
frequency will appear on the display.
Now set your radio’s transmit frequency, where the Flight Service Station will be
listening for calls, using the DIAL selector knob or keypad.
Press and hold in the [MW(SPL.W)] key for 2 seconds to save the transmit frequency
and return to the NAV band frequency.
Press and hold in the PTT switch to transmit on the split transmit frequency.
Release the PTT switch to return to the receive mode.
To disable the “Split” function, set the receiving frequency to any frequency outside of
the NAV band (the “±” icon will disappear).
Note: A split frequency can be programmed into each memory channel independently. Set a
transmit frequency before programming the memory channel, if desired. The split function
on/off setting can also be programmed into a memory channel.
BRS channel Operation
NOTICE! An FCC License is required for operation on BRS (Business Radio Service)
channels.
Recalling the BRS channels
Press the [SEL(SET)] key, repeatedly if necessary, until “BRS” (Business Radio Service)
appears on the display. In the BRS mode, you will see the previously-selected channel
number appearing at the bottom of the “BRS” icon on the LCD.
Rotate the DIAL selector knob to select the desired BRS channel.
You may change the readout structure of the BRS channel display between “Frequency
Indication” and “Frequency Indication plus Alpha-numeric Label” by pressing the [F] key
followed by [6(TAG)] key.
To exit the BRS mode, press the [SEL(SET)] key momentarily to return to the VFO
mode.
Note 1: In the BRS mode, an easy way to recall memories is to key in the BRS channel
number. For example, to recall BRS channel #04, press the [0] key followed by [4] key. To
recall memory channel #21, press the [2] key followed by [1] key.
Note 2: You may change the configuration of the BRS channel temporally, as following
procedures. However, the BRS channel does not keep the . We recommended that the into
the memory channel. See page ??
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
23
CTCSS Operation
The CTCSS operation allows to silently monitor for calls on busy channels and to transmit
CTCSS tone. The decode function monitors receiver audio through a narrow filter at the
same subaudible frequency, keeping the squelch closed until a matching tone is received,
while the transmit (encode) function superimpose a subaudible tone (at a frequency too low
to be heard) on the transmit carrier.
The CTCSS setup involves two actions: setting the Tone Mode and then setting of the Tone
Frequency. These actions are set up by using the [1(VOR)TN] and [2(TO)CD] keys, or Menu
Items (SQL Type) and (TONE Set).
Press and hold the [1(VOR)TN] key for 3 seconds. This instantly recalls Menu Item
(SQL Type).
Press the [SEL(SET)] key again to enable adjustment of this Menu Item.
Rotate the DIAL selector knob so that “T” appears at the bottom right corner on the
display; this activates the CTCSS Encoder, which allows transmit a CTCSS tone only.
Note: You may notice an additional “DCS” icon appearing while you rotate the DIAL
selector knob in this step. We’ll discuss the Digital Code Squelch system shortly.
Rotating the DIAL selector knob in above step will occasionally cause “TSQ” to appear.
When “TSQ” appears, this means that the Tone SQuelch system is active, which mutes
your VXA-710’s receiver until it receives a call from another radio sending out a
matching CTCSS tone. This can help keep your radio quiet until a specific call is
received, which may be helpful while operating in congested areas.
When you have made your selection of the CTCSS tone mode, press the [SEL(SET)]
key momentarily, then rotate the DIAL selector knob one click clockwise to select Menu
Item (TONE Set). This Menu selection allows setting of the CTCSS tone frequency to be
used.
Press the [SEL(SET)] key to enable the adjustment of the CTCSS frequency.
Rotate the DIAL selector knob until the display indicates the Tone Frequency you need
to be using.
When you have made your selection, press the [SEL(SET)] key to save the new setting,
then press the PTT key repetitively until the radio exits to normal operation.
DCS Operation
Another form of tone access control is Digital Code Squelch, or DCS. It is a newer, more
advanced tone system which generally provides more immunity from false paging than does
CTCSS. The DCS Encoder/Decoder is built into your VXA-710, and operation is very similar
to that just described for CTCSS.
Note: Just as in CTCSS operation, DCS requires that you set the Tone Mode to DCS and
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
24
that you select a Tone Code.
Press and hold the [1(VOR)TN] key for 2 seconds. This instantly recalls Menu Item
(SQL Type).
Press the [SEL(SET)] key again to enable adjustment of this Menu Item.
Rotate the DIAL selector knob until “DCS” appears on the display; this activates the
DCS Encoder/Decoder.
Press the [SEL(SET)] key momentarily, then rotate the DIAL selector knob two clicks
clockwise to select Menu Item (DCS Set).
Press the [SEL(SET)] key again to enable adjustment of this Menu Item.
Rotate the DIAL selector knob until the desired DCS Code (a three-digit number). Just
set up the DCS Code to be the same as that used by your group.
When you have made your selection, press the [SEL(SET)] key to save the new setting,
then press the PTT key repetitively until the radio exits to normal operation.
Note: Remember that the DCS is an Encode/Decode system, so your receiver will remain
muted until a matching DCS code is received on an incoming transmission. Switch the DCS
off when you’re just tuning around the band!
CTCSS/DCS Bell Operation
During CTCSS Decode or DCS operation, you may set the VXA-710 up such that a ringing
“bell” sound alerts you to the fact that a call is coming in. Here is the procedure for activating
the CTCSS/DCS Bell:
Set the transceiver up for CTCSS Decode (“Tone Squelch”) or DCS operation, as
described previously.
Press the [F] key followed by [SEL(SET)] key to activate the Menu (“SET”) mode.
Rotate the DIAL selector knob to select Menu Item “2. Sound,” then press the
[SEL(SET)] key.
Rotate the DIAL selector knob to select Sub Menu Item “2. Bell,” then press the
[SEL(SET)] key.
Press the [SEL(SET)] key again to enable adjustment of this Menu Item.
Rotate the DIAL selector knob to select “ON” (to enable the CTCSS/DCS Bell).
Press the [SEL(SET)] key to save the new setting, then press the PTT key repetitively
until the radio exits to normal operation.
When the CTCSS/DCS Bell feature is enabled, the “BELL” icon appears at the bottom
center of the display. When a station calls you whose transceiver is sending a CTCSS tone
or DCS code which matches that set into your decoder, the “BELL” icon will blinks, flashes
the BUSY/TX indicator in sequential colors, and a ringer sounds to get your attention.
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
25
Selecting the Operating Mode
The VXA-710’s BRS Band provides the two operating modes (Narrow-FM and FM). You
may select the operating mode by pressing the [F] key followed by [BAND(MODE)] key.
Note: If Narrow-FM (NFM) is selected, the receive audio revel is increased slightly to
compensate for the reduced deviation. The receiver IF filter bandwidth is not changed via
this selection.
DTMF Operation
The VXA-710’s 16-button keypad allows easy DTMF dialing for Autopatch. Besides
numerical digits [0] through [9], the keypad includes the [»] and [#] digits, plus the [A], [B],
[C], and [D] tones often used for repeater control.
Manual DTMF Tone Generation
You can generate DTMF tones during transmission manually.
Press the PTT switch to begin transmission.
While transmitting, press the desired numbers on the keypad.
When you have sent all the digits desired, release the PTT key.
DTMF Autodialer
Ten DTMF Autodial memories are provided, allowing you to store telephone numbers for
autopatch use. You can also store short autopatch access code streams so as to avoid
having to send them manually.
Here is the DTMF Autodial storage procedure:
Press and hold in the [3(FRM)DT] key for 3 seconds to activate the DTMF Autodialer
function. The “TELEPHONE” icon will appear at the center bottom on the display.
Press the [F] key, then press and hold in the [3(FRM)DT] key for 3 seconds to activate
the DTMF Memory Edit mode.
Rotate the DIAL selector knob to select the DTMF Memory register into which you wish
to store this DTMF string.
Key in the DTMF digits you wish to store into this register.
Press the [SEL(SET)] key to save the setting. To store other numbers, repeat this
process, using a different DTMF memory register.
Press the PTT key to exit to normal operation.
To send the telephone number:
Press and hold in the [3(FRM)DT] key for 3 seconds, if needed, to activate the DTMF
Autodialer function.
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
26
Press the PTT key to begin transmission.
Press the numerical key (“1” through “0”) corresponding to the DTMF memory string you
wish to send. Once the string begins, you may release the PTT key, as the transmitter
will be held “on the air” until the DTMF string is completed.
Miscellaneous Setting
Changing the Channel Step
The VXA-710’s FM BC Band provides the option of utilizing channel steps of
5/10/12.5/15/20/25/50/100 kHz per step (factory default: 100 kHz). If you need to change the
channel step, the procedure to do so is very easy.
Press and hold in the [7(SPL)ST] key for 2 seconds. This instantly recalls Menu Item
(Step).
Press the [SEL(SET)] key again to enable adjustment of this Menu Item.
Rotate the DIAL selector knob select the new channel step size.
When you have made your selection, press the [SEL(SET)] key to save the new setting,
then press the PTT key repetitively until the radio exit to normal operation.
Automatic Power-Off (APO) Feature
The APO feature helps conserve battery life by automatically turning the radio off after a
user-defined period of time within which there has been no dial or key activity. The available
selections for the time before power-off are 0.5/1/8 hours, as well as APO Off.
The default condition for the APO is OFF, and here is the procedure for activating it:
Press the [F] key followed by [SEL(SET)] key to activate the Menu (“SET”) mode.
Rotate the DIAL selector knob to select Menu Item “6. Misc Setup,” then press the
[SEL(SET)] key.
Rotate the DIAL selector knob to select Sub Menu Item “1. APO,” then press the
[SEL(SET)] key.
Press the [SEL(SET)] key again to enable adjustment of this Menu Item.
Rotate the DIAL selector knob to select the desired time period after which the radio will
automatically shut down.
When you have made your selection, press the [SEL(SET)] key to save the new setting,
then press the PTT key repetitively until the radio exits to normal operation.
When the APO is activated, the “TIMER” icon will appear at the center bottom on the LCD. If
there is no action by you within the time interval programmed, the “TIMER” icon blinks and a
ringer sounds one minute before the APO shut-down time; one minute thereafter, the
microprocessor will shut down the radio automatically.
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
27
Just press and hold in the (PWR) switch for 3 seconds to turn the transceiver back on after
an APO shutdown, as usual.
Transmitter Time-Out Timer (TOT)
The TOT feature provides a safety switch which limits transmission to a pre-programmed
value. This will promote battery conservation by not allowing you to make excessively-long
transmissions, and in the event of a stuck PTT switch (perhaps if the radio or a Speaker/Mic
is wedged between aircraft’s seats) it can prevent interference to other users as well as
battery depletion. As configured at the factory the TOT feature is set to OFF, and here is the
procedure for activating it:
Press [F] key followed by [SEL(SET)] key to activate the Menu (“SET”) mode.
Rotate the DIAL selector knob to select Menu Item “4. Transmit,” then press the
[SEL(SET)] key.
Rotate the DIAL selector knob to select Sub Menu Item “4. T.O.T.” then press the key.
Press the [SEL(SET)] key again to enable adjustment of this Menu Item.
Rotate the DIAL selector knob to set the Time-Out Timer to the desired “Maximum TX”
time (1 minute, 3 minutes or 5 minutes).
When you have made your selection, press the [SEL(SET)] key to save the new setting,
then press the PTT key repetitively until the radio exit to normal operation.
Note 1: When your transmitting time is within 10 seconds of the Time-Out Timer expiration,
an alert bell will provide an audible warning from the speaker.
Note 2: Since brief transmissions are the mark of a good operator, try setting up your radio’s
TOT feature for a maximum transmission time of 1 minute. This will significantly improve
battery life, too!
Programming the Key Assignments
The [USER(KEY)] key is a user-programmable key that may be set up for a pair of functions
you use particularly frequently. The default [USER(KEY)] key functions, as set up at the
factory, have been assigned to the ANL feature (press key) and to the “Large Font” feature
(press and hold key) at the factory. These may be changed by the user, if you wish to utilize
another function or functions.
To program the function assigned to a key:
Press [F] key followed by [SEL(SET)] key to activate the Menu (“SET”) mode.
Rotate the DIAL selector knob to select Menu Item “5. Key Set,” then press the
[SEL(SET)] key.
Rotate the DIAL selector knob to select Sub Menu Item “3. USER 1” (for the “press key”
function) or “4. USER 2” (for the “press and hold key” function), then press the
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
28
[SEL(SET)] key.
Press the [SEL(SET)] key again to enable adjustment of this Menu Item.
Rotate the DIAL selector knob to select the function you wish to assign to the button you
selected in the previous step. The available choices are:
ANL: Activates the Automatic Noise Limiter in the AM mode.
TX Power: Selects the FM transmit power output level on the BRS band.
XFER: Exchanges the display locations between the “Frequency” and “Alpha-numeric
Tag” modes while operate on the “Memory,” “Book Memory,” and “WX” modes. This also
may be used to exchange the display location between the “Frequency” and “Course
Indicator and TO/FROM flag” options while operating on the “NAV” band.
SPEC Start: Activates the Spectrum Scope Monitor feature.
Large Font: Switches the frequency display between the “Large Character” and “Small
Character” modes.
None
When you have made your selection, press the [SEL(SET)] key to save the new setting,
then press the PTT key repetitively until the radio exits to normal operation.
Busy Channel Lock-Out (BCLO)
The BCLO feature prevents the radio’s transmitter from being activated if a signal strong
enough to break through the “Noise” squelch is present. On a frequency where stations
using different CTCSS or DCS codes may be active, BCLO prevents you from disrupting
their communications accidentally (because your radio may be muted by its own Tone
Decoder). The default setting for the BCLO is OFF, and here is how to change that setting:
Press [F] key followed by [SEL(SET)] key to activate the Menu (“SET”) mode.
Rotate the DIAL selector knob to select Menu Item “4. Transmit,” then press the
[SEL(SET)] key.
Rotate the DIAL selector knob to select Sub Menu Item “1. BCLO,” then press the
[SEL(SET)] key.
Press the [SEL(SET)] key again to enable adjustment of this Menu Item.
Rotate the DIAL selector knob to select “ON” (thus activating the BCLO feature).
When you have made your selection, press the [SEL(SET)] key to save the new setting,
then press the PTT key repetitively until the radio exits to normal operation.
Display Customization
Display Contrast
The LCD’s contrast may be adjusted using the Menu.
Press [F] key followed by [SEL(SET)] key to activate the Menu (“SET”) mode.
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
29
Rotate the DIAL selector knob to select Menu Item “1. Display,” then press the
[SEL(SET)] key.
Rotate the DIAL selector knob to select Sub Menu Item “4. Contrast,” then press the
[SEL(SET)] key.
Press the [SEL(SET)] key again to enable adjustment of this Menu Item.
Rotate the DIAL selector knob to adjust the contrast. As you make the adjustment, you
will be able to see the effects of your changes.
When you have made your selection, press the [SEL(SET)] key to save the new setting,
then press the PTT key repetitively until the radio exits to normal operation.
Display Dimmer
The LCD illumination may be adjusted using the Menu, as well.
Press [F] key followed by [SEL(SET)] key to activate the Menu (“SET”) mode.
Rotate the DIAL selector knob to select Menu Item “1. Display,” then press the
[SEL(SET)] key.
Rotate the DIAL selector knob to select Sub Menu Item “5. Dimmer,” then press the
[SEL(SET)] key.
Press the [SEL(SET)] key again to enable adjustment of this Menu Item.
Rotate the DIAL selector knob to adjust the display illumination for a comfortable
brightness level. As you make the adjustment, you will be able to see the effects of your
changes.
When you have made your selection, press the [SEL(SET)] key to save the new setting,
then press the PTT key repetitively until the radio exits to normal operation.
TX/BUSY Indicator Customization
Default TX/BUSY illumination colors have been assigned at the factory. These may be
changed by the user, if you wish to utilize another custom-designed color hue. The Red,
Green, and Blue elements of each color’s composition may be adjusted individually!
Press [F] key followed by [SEL(SET)] key to activate the Menu (“SET”) mode.
Rotate the DIAL selector knob to select Menu Item “1. Display,” then press the
[SEL(SET)] key.
Rotate the DIAL selector knob to select Sub Menu Item “8. RX LED” when you wish to
change the BUSY indicator’s color, or Sub Menu Item “9. TX LED” when you wish to
change the TX indicator’s color, then press the [SEL(SET)] key.
Press the [SEL(SET)] key again to enable adjustment of the selected Menu item.
Rotate the DIAL selector knob to adjust the “R” (red) element of the color; you will be
able to see the effects of your changes. The degree of color hue is designated in a
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
30
numerical scale of “000” through “255,” and you may adjust the display’s red component
until it is just the way you want it. As you make the adjustment, you will be able to see
the effects of your changes.
Press the [SEL(SET)] key again, then rotate the DIAL selector knob to adjust the “G”
(green) element of the color.
Repeat the process described above to adjust the “B” (blue) element of the color.
Press the [SEL(SET)] key to save the new setting, then press the PTT key repetitively
until the radio exits to normal operation.
Note: You may also change the indicator’s color of the Emergency lamp, Weather Alert lamp,
and Over-Heating lamp by the Menu Items. See page ?? for details.
Field Programming Mode
The VXA-710’s “Book” Memories also allow the user to store, label, and recall channel
frequencies which you may want to use frequently by placing the VXA-710 into the “Field
Programming mode.”
Memory Storage
Press and hold in both the PTT switch and [MW(SPL.W)] key, while turning the radio on,
to activate the Field Programming Mode. “FD” will appear at the upper left corner on the
display.
Select the desired frequency to be stored in the Book Memory.
Press and hold in the [MW(SPL.W)] key for 2 seconds. The display will indicate a “Book”
memory channel number will blink on the LCD.
Within five seconds of releasing the [MW(SPL.W)] key, rotate the DIAL selector knob to
select the desired memory channel number for storage. In order to prevent writing over
memory channels, a “Open Door” icon will appear at the right of the channel number to
indicate if the memory channel is vacant.
Now press and hold in the [MW(SPL.W)] key for 3 seconds; you will now see the
blinking “A” character on the LCD. To attach an alpha/numeric name (label) to the
memory, proceed to the next step; otherwise press and hold in the [MW(SPL.W)] key for
2 seconds to save the entry and exit.
To label a memory with an alpha/numeric name, the next step is to use the DIAL selector
knob to select any of the 125 available characters (including letters, numbers, and
special symbols). Press the [USER(KEY)] key repeatedly to recall the desired letter,
number, and symbol in the first character slot (a Æ . Æ 0 Æ A Æ a ...). When the desired
first character appears, press the [MW(SPL.W)] key momentarily to select it and move
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
31
on to the next character.
Select succeeding characters in the same manner, pressing the [SEL(SET)] key
momentarily after each selection.
After entering the entire name (eight characters maximum), press the [MW(SPL.W)] key
for 2 seconds to save all data for the channel.
Turn the radio off, then turn the radio back on again to begin normal operation.
Deleting Memories
Press and hold in both the PTT switch and [MW(SPL.W)] key, while turning the radio on,
to activate the Field Programming Mode. “FD” will appear at the upper left corner on the
display.
Press and hold in the [MW(SPL.W)] key for 2 seconds. The display will indicate a “Book”
memory channel number will blink on the LCD.
Within five seconds of releasing the [MW(SPL.W)] key, rotate the DIAL selector knob to
select the memory channel number you wish to delete.
Press the [SEL(SET)] key momentarily. The previously-selected memory will be deleted.
Turn the radio off, then turn the radio back on again to begin normal operation.
CPU Resetting
In some instances of erratic or unpredictable operation, the cause may be corruption of data
in the microprocessor (due to static electricity, etc.). If this happens, resetting of the
microprocessor may restore normal operation. Note that all memories will be erased if you
do a complete microprocessor reset, as described below.
To clear all memories and other settings to factory defaults:
Turn the radio off.
Press and hold in the [MW(SPL.W)] key, and the MONITOR button, while turning the
radio on.
Timer Mode
The VXA-710 is provided the “STOP WATCH” timer and “COUNT DOWN” timer. These can
be used for a variety of time-keeping purposes.
Press and hold in the [MW(SPL.W)] key while tuning the radio on, activate the Timer
Mode.
Press the MONITOR key to toggle the Timer between “STOP WATCH” timer and
“COUNT DOWN” timer. If you select the “COUNT DOWN” timer, rotate the DIAL knob to
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
32
set the values for the timers (1 minutes -59 minutes).
Press the PTT switch to start/stop the timer.
Turning the radio off, then on again, will return the VXA-710 to normal operation.
Menu (“Set”) Mode
The Menu system allows certain aspects of your radio’s configuration to be customized for
your personal operating convenience. We do not recommend that any of the default settings
be changed, however, until you are thoroughly familiar with the operation of the VXA-710.
Here is the procedure for initiating Menu configuration changes:
Press [F] key followed by [SEL(SET)] key to activate the Menu (“SET”) mode.
Rotate the DIAL selector knob to select the “Main” Menu, then press the [SEL(SET)] key.
Rotate the DIAL selector knob to select the “Sub” Menu item you wish to view and/or
modify, then press the [SEL(SET)] key.
Once you have selected the desired Menu Item, press the key once to view the current
setting for the item.
Rotate the DIAL selector knob to change the setting of the item (ON to OFF, etc.).
Press the [SEL(SET)] key again to save your new setting.
Press the PTT key repetitively until the radio exits to normal operation.
MENU Listing
A listing of the Menu items available via the SET mode may be found below.
1. Display
1. Scan Lamp
Function: Enables/Disables the Scan lamp while paused during scanning.
Available Values: On/Off
Default Setting: On
2. Backlight
Function: Selects the Display illumination Mode.
Available Values: Key/Off/On
Default Setting: Key
Key: Illuminates the Display Lamp for 5 seconds when any front panel key is pressed.
Off: Disables the Display lamp.
On: Illuminates the Display lamp continuously.
3. Large Font
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
33
Function: Selects the frequency display between the “Large Character” and “Small
Character” modes.
Available Values: Off/On
Default Setting: On
4. Contrast
Function: Setting of the display contrast.
Available Values: 00 - 15
Default Setting: 06
5. Dimmer
Function: Setting of the display brightness level.
Available Values: LV 1 - LV 4
Default Setting: LV 3
6. Meter Symbol
Function: Selects the S- & TX PO meter symbol.
Available Values: Four patterns
Default Setting:
7. Display Mode
Function: Selects the display of the sensor unitsinformation.
Available Values: Off/Temp/Volt
Default Setting: Off
Off: Disables the sensor information.
Temp: Indicates the current temperature inside the transceiver case.
Volt: Indicates the battery voltage and battery type.
8. RX LED
Function: Edits the BUSY indicator color.
Available Values: Individual adjustments of the Red, Green, and Blue color hue may be
performed, on a numerical scale of “000” to “255.” See page ?? for details.
Default Setting: Green (R000, G065, B000)
9. TX LED
Function: Edits the TX indicator color.
Available Values: Individual adjustments of the Red, Green, and Blue color hue may be
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
34
performed, on a numerical scale of “000” to “255.” See page ?? for details.
Default Setting: Red (R111, G000, B000)
10. EMG LED
Function: Edits the Emergency lamp color.
Available Values: Individual adjustments of the Red, Green, and Blue color hue may be
performed, on a numerical scale of “000” to “255.” See page ?? for details.
Default Setting: White (R127, G127, B127)
11. Alert LED
Function: Edits the Weather Alert lamp color.
Available Values: Individual adjustments of the Red, Green, and Blue color hue may be
performed, on a numerical scale of “000” to “255.” See page ?? for details.
Default Setting: Green (R000, G127, B000)
12. TEMP LED
Function: Edits the Over Heating lamp color. This is a display seen when the temperature
exceeds the threshold set via the “TEMP Set” setting (see page ??).
Available Values: Individual adjustments of the Red, Green, and Blue color hue may be
performed, on a numerical scale of “000” to “255.” See page ?? for details.
Default Setting: Light Blue (R127, G000, B127)
2. Sound
1. Beeper
Function: Select the Keypad beeper tone.
Available Values: On/DTMF/Off
Default Setting: On
On: Enables the keypad beeper.
DTMF: Enables the keypad beeper with DTMF tones.
Off: Disables the keypad beeper.
2. Bell
Function: Enables/disables the Bell Ringer function.
Available Values: On/Off
Default Setting: Off
3. Power On Beep
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
35
Function: Selects the Power-on beep.
Available Values: Off/Mode 1/Mode 2/Mode 3
Default Setting: Mode 1
4. ARTS Beep
Function: Selects the beep option during ARTS operation.
Available Values: On/Off
Default Setting: On
3. Receive
1. SQL
Function: Sets the Squelch threshold level for the AM and FM modes.
Available Values: 0 - 8
Default Setting: 6
2. WSQL
Function: Sets the Squelch threshold level for the Wide FM mode (for the Broadcasting
Station).
Available Values: 0 - 8
Default Setting: 3
3. Resume
Function: Selects the Scan Resume mode.
Available Values: 5secs/Busy
Default Setting: 5secs
5secs: The scanner will hold for 5 seconds, then resume whether or not the other station is
still transmitting.
Busy: The scanner will hold until the signal disappears, then will resume when the carrier
drops.
4. DW/PRI
Function: Selects the Dual Watch/Priority Function.
Available Values: DW/PRI
Default Setting: DW
5. RX Save
Function: Selects the Receive-mode Battery Saver “sleep” ratio.
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
36
Available Values: ABS/1:1/1:2/1:3/1:4/1:5/Off
Default Setting: ABS
The setting of “1:5” will promote the greatest conservation of battery capacity, but the
receiver’s response time to incoming calls will be slowed somewhat.
ABS: Automatic Battery Saver, based on activity on the receiver.
Note: This feature cannot be activated during Scan or Dual Watch/Priority operation.
6. Step
Function: Setting of the synthesizer steps on the FM BC Band.
Available Values: 5k/10k/12.5k/15k/20k/25k/50k/100k
Default Setting: 100k.
7. SQL Type
Function: Selects the Tone Encoder and/or Decoder mode.
Available Values: Off/T/TSQ/DCS
Default Setting: Off
T: CTSCC Encoder
TSQ: CTCSS Encoder/Decoder
DCS: Digital Coded Squelch Encoder/Decoder
Note: This Menu Item is only selectable on the Amateur Band (you may only access this
Menu item while operating on the Amateur band).
8. TONE Set
Function: Setting of the CTCSS Tone Frequency.
Available Values: 39 standard CTCSS tones.
Default Setting: 67.0Hz
9. DCS Set
Function: Setting of the DCS Code.
Available Values: 106 standard DCS codes.
Default Setting: 023
10. PRI Time
Function: Selects the Priority Checking Time.
Available Values: 500ms/1s/1.5s/2s/2.5s/3s
Default Setting: 2s
This Menu Item allows you to define how often the Priority Channel will be checked for
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
37
activity.
Note: The Dual Watch Polling time is 500ms (fixed).
11. SPECT Width
Function: Selects the visible bandwidth of the Spectrum Analyzer.
Available Values: ±30ch/±15ch
Default Setting: ±30ch
4. Transmit
1. BCLO
Function: Enables/disables the Busy Channel Lock-Out feature.
Available Values: On/Off
Default Setting: Off
2. ARTS
Function: Enables/disables ARTS operation.
Available Values: Off/RX/TX/TRX
Default Setting: Off
Off: Disables the ARTS feature.
RX: Use this mode if you only want your radio to listen, and not poll the other station (in
which case their radio should be set to the “TX” mode). Here, your radio will beep and
display “In Service” or “Out Service” to indicate the state of connection.
TX: Likewise, this puts your radio into a transmit-only “beacon” mode where you won’t hear
the polling beeps (but you can still hear when the other station talks). When activated, you
have no display of whether the other station is in range, or not (“In Service” and “Out
Service” do not appear).
TRX: Activates the ARTS feature with both operating modes.
3. ARTS Itvl
Function: Selects the polling interval during ARTS operation.
Available Values: 15secs/25secs
Default Setting: 25secs
4. T.O.T
Function: Setting of the Time-Out Timer Countdown Time.
Available Values: Off/1min/3min/5min
Default Setting: Off
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
38
The Time-Out Timer shuts off the transceiver after continuous transmission exceeds the
programmed time.
5. TX Power
Function: Selects the TX Output Power on the BRS channel.
Available Values: Low/High
Default Setting: High
5. Key Set
1. Lock Mode
Function: Selects the Control Locking lockout combination.
Available Values: DIAL/KEY/KEY+DIAL/PTT/DIAL+PTT/KEY+PTT/ALL
Default Setting: KEY
2. [121.5]
Function: Selects the [121.5(HOME) key function.
Available Values: 121.5/HOME
Default Setting: 121.5
121.5: Pressing this key instantly recall a 121.5 MHz “Emergency” channel.
HOME: Pressing this key instantly recalls a favorite “Home” channel.
3. USER 1
Function: Programming the key assignment (momentary-press mode).
Available Values: ANL/TX Power/ARTS/XFER/SPEC Start/Large Font/None
Default Setting: ANL
See page ?? for details.
4. USER 2
Function: Programming the key (press and holding) assignment.
Available Values: ANL/TX Power/ARTS/XFER/SPEC Start/Large Font/None
Default Setting: Large Font
See page ?? for details.
6. Misc Setup
1. APO
Function: Selects the Auto Power Off time (time before power goes off).
Available Values: Off/0.5h/1h/8h
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
39
Default Setting: Off
2. Emergency
Function: Selects the Emergency feature.
Available Values: 121.5/LED+121.5/LED
Default Setting: LED+121.5
121.5: Pressing the [121.5(HOME)] key momentarily, accesses the 121.5 MHz Emergency
Frequency.
LED+121.5: Pressing the [121.5(HOME)] key momentarily, accesses the 121.5 MHz
Emergency Frequency and flashes the BUST/TX lamp.
LED: Pressing the [121.5(HOME)] key momentarily, flashes the BUST/TX lamp.
3. WX Alert
Function: Selects the Alert functions when receiving the Weather Alert Signal on the WX
Channel.
Available Values: Alrt Off/Beep/LED/Beep+LED
Default Setting: Alrt Off
Alrt Off: Disables the Alert function
Beep: Sounds a loud beep when receiving the Weather Alert Signal.
LED: Illuminate the BUST/TX lamp when receive the Weather Alert Signal
Beep+LED: Sounds a loud beep and illuminates the BUSY/TX lamp when receiving the
Weather Alert Signal.
4. TEMP Unit
Function: Selects the measurement units for the Temperature sensor.
Available Values: °F/°C
Default Setting: °F
5. TEMP Check
Function: Enables/Disables the Over-Heating Alarm
Available Values: Off/On
Default Setting: Off
6. TEMP Set
Function: When the “TEMP Check” Menu item is set to “on,” and the temperature passes
through the threshold set in this step, the BUSY/TX indicator will change colors, to alert you
to the high temperature condition. The color of the “High Temperature” indication is set via
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
40
the “TEMP LED” Menu setting (page ??).
Available Values: [32.0 °F (0 °C)] - [230.0 °F (110 °C)]
Default Setting: [230.0 °F (110 °C)]
Note: When the temperature reaches approximately 220 °F (105 °C), the radio will disable
transmission, to allow the radio to cool off.
7. Option
1. Internal MIC
Function: Internal Microphone On/Off
Available Values: Off/On
Default Setting: Off
This controls the status of the radio’s internal microphone when an external microphone
(such as the MH-44A4B Speaker Microphone or an aviation headset connected via the CT-
96 Headset Cable) is in use. In most applications, set this Menu Item to “off” for proper
operation (this disables the internal microphone). The internal microphone will still function
normally when the external microphone is disconnected.
2. TEMP Offset
Function: Correcting the Thermometer setting
Available Values: [–22.8 °F (–12.7 °C)] - [+22.8 °F (+12.7 °C)]
Default Setting: 0.0 °F (0.0 °C)
This allows you to calibrate the internal thermometer with a known-to be-accurate source.
3. Clock Shift
Function: CPU Clock Shift
Available Values: Off/On
Default Setting: Off
This function is only used to move a spurious response “birdie” should it fall on a desired
frequency. Consult your Vertex Standard dealer for details regarding this function.
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
41
Specifications
General
Frequency Range: TX 118-136.975 MHz (Air), 151.5125-158.4 MHz (BRS)
RX 88-108 MHz, 108-136.975 MHz,
151.5125-158.4 MHz, and WX-01-WX-10
Channel Spacing: 5, 10, 12.5, 20, 25, 50, 100kHz (FM BC Band)
Emission Type: TX AM (AIR Band), FM (BRS Band)
RX AM (AIR Band), FM (WX & BRS Band),
& WFM (FM BC Band)
Supply Voltage: 4.5 to 15 VDC
Temperature Range: -22 °F to +140 °F (-30 °C to +60 °C)
Case Size (W x H x D): 2.36” x 3.78” x 1.12” (60 x 96 x 28.5 mm)
Weight (Approx.): 9.9 oz (280 g) with FNB-80LI & Antenna
Receiver
IFs: AM & NFM 35.4 MHz & 450 kHz
WFM: 45.65 MHz & 10.7 MHz
Sensitivity:
@12 dB SINAD with 1 kHz, 22.5 kHz deviation: <2.0 µV (6 dBµ) 88-108 MHz (WFM)
@6 dB S/N with 1 kHz, 30% modulation: <1.0 µV (0 dBµ) 108-136.975 MHz (AM)
@12 dB SINAD with 1 kHz, 3.5KHz deviation: <0.32 µV (-10 dBµ) BRS Band (FM/NFM)
@12 dB SINAD with 1 kHz, 3.5 kHz deviation: <0.4 µV (-8 dBµ) WX-01 - WX-10 (FM)
Selectivity: >8 kHz/–6 dB (AM/FM)
>200 kHz/–6 dB (WFM)
AF Output: @7.2V 0.4W @ 8 , 10% THD
Transmit
Power Output: @ 7.2V 5 W (PEP), 1.5 W (Carrier), 118-136.975MHz, AM
2 W BRS Band, FM
Frequency Stability: Better than ± 2.5ppm (-30 °C to +60 °C)
Modulation System: Low Level Amplitude Modulation (AM)
Variable reactance (FM)
Spurious Emission: 60 dB below carrier
Ext. Mic. Impedance: 150
Specifications are subject to change without notice.
FCC ID: K6610623X20
IC ID: 511B-10623X20
Operating Manual
Vertex Standard Co., Ltd.
42
Accessories & Options
Supplied Accessories
LI-ion Battery Pack (7.2V, 1300 mAh) FNB-80LI 1
Battery Charger NC-72 1
Helical Antenna ATV-?? 1
Headset Cable CT-96 1
Operating Manual 1
Warranty Card 1
Available Options
MH-44B4B Speaker Microphone
FBA-23 Alkaline Battery Case
CD-15A Desktop Rapid Charger
E-DC-5B DC Cable w/Noise Filter
E-DC-6 DC Cable; plug and wire only
CN-3 Antenna Adapter (SMA to BNC)
Availability of accessories may vary.
Some accessories are supplied as standard per local requirements, while others may be
unavailable in some regions.
Consult your Vertex Standard Dealer for details regarding these and any newly-available
options.
Connection of any non-Vertex Standard-approved accessory, should it cause damage,
may void the Limited Warranty on this apparatus.

Navigation menu
