An ASSA ABLOY Group brand
1900 Series
Traditional Door Control
finishes
Product will be painted with a combination of waterborne acrylic and polyester powder coat. Closers will withstand
100 hours of salt spray. (The ANSI requirement is 25 hours.)
Sprayed Finishes
Description Specify Designation
(ANSI/BHMA) Complements the following finishes Old Designation
Aluminum 689 625, 628, 629, 630, 651, 652 SB
Statuary Bronze 690 613, 640, 695 STAT
Dull Bronze 691 612, 637, 639 BL
Black 693 315 315
Medium Amber 694 312 312
Gold 696 605, 606, 632, 633 GB
Prime Coat* 600 — SRI
*600 is a special rust-inhibiting prime coat. Closers can be ordered prime coat only (specify closer x 600). An additional charge
applies if finish coat is required over prime coat (ex: 1902/4 x 600 x 690).
The Yale® 1900 Series Traditional Surface Closer offers conventional
closer styling in combination with contemporary closer control and the
installation convenience of a one-size closer shell. Only two spring sizes
are required to provide control for the complete range of door sizes. The
1900 Series Door Closers are designed for traditional and period decor
while at the same time meeting the strict requirements of engineers
worldwide.
The Yale® 1900 Series Traditional Closers are available for standard arm,
parallel arm or corner bracket installation. Rigid heavy-duty arms are
available for Parallel Rigid and UNI Stop™ Parallel arm installations. Each
type of installation is available with non-hold open or hold open arms. A
variety of accessories is available to meet most installation requirements.
contents
Introduction .................... 2
Overview ...................... 3
Features ...................... 4
Applications...................5-6
Technical Details ..............7-10
Accessories.................11-16
Parts List ...................17-21
How To Order ................. 22
1900 series door closer
the engineer's choice
2
3
overview
Spring Power
Adjustment
Aluminum Alloy Shell
Regulating Valve
Size Designation
2/4 = Sizes 2 thru 4
5/6 = 5 & 6
Regulating Valve
specifications
Closer for interior (and) exterior doors shall be rack-and-pinion type enclosed in a cast aluminum alloy shell. Closer
spring shall be clock-type coil spring and shall be adjustable through a range of closing power. Closer fluid shall
maintain lubricity and contain anti-oxidation agents. Closer shall be equipped with a single hex-key operated
regulating valve for control of both closing and latch speeds. Closer shall have adjustable backcheck. Closer shall
be Yale® 1900 Series Traditional Surface Closer or equivalent.
compliance standards
All 1900 Series closers comply with ANSI/BHMA A156.4 Grade 3 Specifications. All Yale® series 1900 closers
with non-hold open arms are listed by Underwriters Laboratories for labeled fire doors. This includes compliance to
UL10C and for 3-hour assemblies. The product is manufactured in an ISO 9001 facility.
1900 series door closer
Page Revised Electronically 2/14
One-Size Aluminum Housing
Closer is housed in special aluminum
alloy shell selected for its ability to
provide optimum performance. One
body size provides simplified templating
and installation.
Adjustable Spring Power
Clock-type coil spring allows incremental
adjustment of closer power to meet
individual installation needs. Permits
a fine adjustment of the closer to the
environment.
Rack and Pinion Design
Provides a smooth constant control of
the door through its full opening and
closing cycle.
Adjustable Closing Speed/Latch
Speed
A dual-purpose regulating valve, hex-key
operated, permits independent adjustment
of both sweep and latch speed.
Adjustable Backcheck Cushioning
An independent regulating valve, hex-
key-operated, provides an adjustable
hydraulic cushion to the door opening
speed toward the end of the opening
cycle. This feature is standard with all
but delayed action closers. Backcheck is
not available with delayed action closers.
Non-Hold Open Arms
Standard closer will be supplied with a
non-hold open arm. This arm is non-
handed.
Adjustable Power Standard
Installation Jamb Bracket
Provides a ±7-1/2% power adjustment
by relocation of the forearm pin in the
jamb bracket. Supplied standard with all
standard installation and corner bracket
installation non-hold open closers.
Hold Open Arms
Closer arm has adjustable hold open
feature (90° to 180°). This arm is non-
handed for regular arm application only.
It is handed for all friction hold open
parallel arm installations.
Field Reversible
Closer spring can be reversed to
accommodate the hand of the door. It
is recommended that wherever possible
the closer be ordered handed. Parallel
hold open arms and delayed action
closers are not reversible.
Adjustable Delayed Action Closing
Closer’s initial closing speed at the
beginning of the closing cycle (from full
open down to approximately 70°) is
adjustable, allowing slow-moving traffic
to pass through the opening before the
closer begins its normal closing speed.
For regular arm non-hold open closers
only. Delayed action closers are not
available with backcheck cushioning.
Delayed action closers are handed.
4
1900 series door closer
features
Adjustable Delayed Action Closing*
(Supplied in lieu of backcheck feature) An optional
hydraulic feature that adds a third speed range to the
closing cycle. This feature becomes effective when
the door is opened and released at any point beyond
70°. The amount of time delay depends upon the
combination of the angle of door release and valve
adjustment. The valve can be adjusted with a 1/8"
(3mm) hex key from no delay time up to maximum
delay times of:
Suggested Applications
Delayed action closing allows slow-
moving traffic to clear the opening
before the door closer’s normal closing
cycle begins. This feature can be
helpful in health care facilities such as
hospitals and nursing homes. It provides
sufficient time for persons on crutches
or in wheelchairs to pass through a
door without concern of it closing. At
the same time, it can accommodate
*Note: Regular arm (NHO units only) are
handed - not reversible
the facility's staff with movement of food
service carts, beds, and other wheeled
traffic. Use of delayed action closers on
many doors throughout industrial and
commercial buildings can also assist the
flow of traffic. Locations where additional
time to clear the opening is advantageous
are doors between office and factory/
warehouse facilities, doors to workshops
or laboratories, to kitchen and food
processing areas, etc.
Door Opened and
Released at
Approximate Time
of Delay Cycle
180° 4-5 minutes
120° 2-3 minutes
90° 25-30 seconds
optional features
5
1900 series door closer
applications
This is the only pull-side application where a double
lever arm is used. It is the most power-efficient
application for a door closer. Sufficient frame, door
and/or ceiling clearance must be considered. Since
the arm assembly projects directly out from the
frame, this application may present an aesthetics
issue or be prone to vandalism.
Regular Arm
This application provides the most appealing
design appearance for a surface-mounted door
closer having a double lever arm. This also makes
it beneficial in vandalism-prone areas. It is on the
push side of the door and the arm assembly extends
almost parallel to the door. In the closed position,
there is very little or no hardware projecting beyond
the frame face in most situations.
Due to the geometry of the arm it is approximately
25% less power-efficient than a regular arm
application.
The entire closer and arm assembly are mounted
below the frame stop, requiring a top rail of 5-3/8"
(137mm) to mount the body. Clearance to the
bottom of the closer body from the top of the door
is 7-3/8" (187mm). (Based on a 5/8" (16mm) high
frame stop.)
Parallel Arm
6
1900 series door closer
applications
Parallel Rigid Arm
An enhanced variation of the standard parallel
arm assembly that is intended for use in heavy
traffic areas where auxiliary door stops are
installed. Hold open available - specify hand
when ordering.
UNI Stop™ Arm (Parallel Arm applications only)
UNI Stop™ arms combine the features of a double-
lever arm overhead door stop/holder with the
backcheck feature of the door closer to reduce door
stopping shock loads to a minimum. The UNI Stop
arm uses a compression spring buffer at the soffit
plate/arm shoe that will absorb 30 lbs. of force, 5°
prior to the door’s dead stop. Coupled with the door
closer’s backcheck feature, this arm provides the
most controlled stop available with a surface door
closer.
There are three different length arm assemblies. Each
length is designed for a specific range of door widths
to provide precise door control. This further lessens
the dead stop impact on the door’s hinges/pivots.
E
7
1900 series door closer
regular arm installation
All dimensions are for reference only. Dimensions are given in inches (mm) unless otherwise noted. Door sizing information is
based on installation on standard weight doors, 7'0" (2.13m) high x 1-3/4" (44mm) thick, hung on anti-friction hinges and operating
under normal conditions.
* Template position for 100° door opening
Body mounting holes are spaced 4-1/8" (105mm) horizontally and 1-3/8" (76mm) vertically.
Maximum Door Size
Wood or Metal
Inches (cm)
Model Number
E
Minimum
Ceiling Clearance
Inches (mm)
Interior Exterior Non-Hold
Open
Hold
Open
Non-Hold
Open Hold Open
48"
(122)
36"
(91) 1902/4 1912/4
1-1/2"
(38)
2-1/8"
(54)
—44"
(112) 1905/6 1915/6
8
1900 series door closer
parallel arm installation
All dimensions are for reference only. Dimensions are given in inches (mm) unless otherwise noted. Door sizing information is
based on installation on standard weight doors, 7'0" (2.13m) high x 1-3/4" (44mm) thick, hung on anti-friction hinges and operating
under normal conditions.
* Template position for 130° door opening
Body mounting holes are spaced 4-1/8" (105mm) horizontally and 1-3/8" (76mm) vertically.
Maximum Door Size
Wood or Metal
Inches (cm)
Model Number
B
Minimum
Top Rail with 5/8" (16mm) frame stop
Inches (mm)
Interior Exterior Non-Hold
Open
Hold
Open Without Drop Plate With 1988
Drop Plate
42"
(107)
36"
(91) PA1902/4 PA1912/4
5-3/8"
(137)
2-1/2"
(64)
—44"
(112) PA1905/6 PA1915/6
9
1900 series door closer
parallel rigid arm
All dimensions are for reference only. Dimensions are given in inches (mm) unless otherwise noted. Door sizing information is
based on installation on standard weight doors, 7'0" (2.13m) high x 1-3/4" (44mm) thick, hung on anti-friction hinges and operating
under normal conditions.
* Template position for 130° door opening
Body mounting holes are spaced 4-1/8" (105mm) horizontally and 1-3/8" (76mm) vertically.
Maximum Door Size
Wood or Metal
Inches (cm)
Model Number
B
Minimum Top Rail with 5/8" (16mm)
frame stop
Interior Exterior Non-Hold Open Hold
Open
Without
Drop Plate
With 1988
Drop Plate
48"
(122)
36"
(91) PR1902/4 PR1912/4
5-3/8"
(137)
2-1/2"
(64)
— 44"
(112) PR1905/6 PR1915/6
10
1900 series door closer
uni stop™ arm
All dimensions are for reference only. Dimensions are given in inches (mm) unless otherwise noted. Door sizing information
is based on installation on standard weight doors, 7'0" (2.13m) high x 1-3/4" (44mm) thick, hung on anti-friction hinges and
operating under normal conditions.
Maximum Door Size
Inches (cm) Model Number
Interior Exterior Non-Hold
Open
Hold
Open
x Specify Door
Width
28-41”
(71-104)
28-36”
(71-91) UNI1902/4 UNI1912/4
42-48”
(107-122)
37-48”
(94-122) UNI1905/6 UNI1915/6
Door Width
Inches
(cm)
B
Minimum Top Rail
5/8" (16mm) Frame Stop C
Template Position for Hold Open at Listed Angle or Dead Stop at
Listed Angle plus 5˚
D
Arm
Extension
Beyond
Closer
Without
Drop Plate
With 1988
Drop Plate 85° 90° 95° 100° 105° 110°
28-32"
(71-81)
5-5/8"
(143)
2-3/4"
(70)
10"
(254)
9-3/8"
(238)
8-3/4"
(222)
8-1/4"
(210)
7-3/4"
(197)
7-1/2"
(191)
8-7/8"
(225)
33-41"
(84-104)
12-1/4"
(311)
11-5/8"
(295)
11"
(279)
10-1/2"
(267)
10"
(254)
9-5/8"
(244)
10-3/8"
(264)
42-48"
(107-122)
14-5/8"
(371)
13-7/8"
(352)
13"
(330)
12-1/2"
(318)
12"
(305)
11-1/2"
(292)
11-7/8"
(302)
Body mounting holes are spaced 4-1/8" (105mm) horizontally and 1-3/8" (76mm) vertically.
11
1900 series door closer
regular arm
Molded/Bull Nose Trim - #291 Bracket:
For use where the door frame has molded
or bull nose trim which will not accept a
standard non-hold open shoe. The bracket
is mortised into the frame rabbet and
projects beyond the face of the frame. It will
accommodate a frame rabbet up to 2" (51
mm) deep.
Molded/Bull Nose Trim - #292
Bracket: For use where the door
frame has molded or bull nose trim
which will not accept a standard hold
open shoe. It is mortised into the frame
rabbet, and projects beyond the face
of the frame. It will accommodate a
rabbet up to 2" (51mm) deep. This
bracket is used in combination with the
standard hold open mounting shoe.
Molded/Bull Nose Trim - #291A Bracket:
This bracket is similar to - but longer than - the
291 bracket. It is designed to accommodate frame
rabbets from 2" to 2-7/8" (51 to 73mm) deep.
brackets for non-hold open arms
bracket for hold open arms
12
1900 series door closer
parallel arm
brackets for non-hold open arms
Standard Installation - #289 Soffit Plate:
This soffit plate is supplied standard with parallel arm
closers. It can be mounted where the frame soffit is as
narrow as 1" (25mm).
Mounting Between Doors - #413A Soffit Bracket: For
use where insufficient space between companion doors does
not permit use of other soffit plates. This bracket permits
mounting of the closer between doors with as little as 4-1/8"
(105mm) of header space. Permits closer arm to clear up to a
5/8" (16mm) high stop.
Narrow Frame/Removable Stop - #297 Soffit Plate: For
use where a narrow frame or frame with removable stop
does not permit use of the standard soffit plate. This plate
may be mounted on the frame soffit or the frame rabbet
where the stop does not exceed 5/8" (16mm) in height. All
of the screw holes are in a straight line, requiring as little
as 1-1/4" (32mm) of frame reveal to mount bracket and
maintain good closer arm geometry. Where the frame soffit
is as wide as 2" (51mm), this soffit plate may be used to
clear weatherstripping that is up to 1-3/8" (35mm) wide and
5/8" (16mm) in height.
Blade/Applied Stop - #299 Soffit Plate: For use where
a blade or applied stop does not permit installation of the
standard soffit plate. Mounts to either the frame soffit or
rabbet. Since this soffit plate projects 7/8" (22mm) less than a
standard soffit plate, it requires a minimum frame reveal of 2"
(51mm). Permits closer arm to clear up to a 5/8" (16mm) high
stop.
Flush Transom - 589L Angle Bracket: For use where
rabbeted or flush transom conditions prevent installation of
a soffit plate. Used in combination with the 289 soffit plate,
or it may be used in combination with the 290 soffit plate
when it is necessary for the closer arm to clear a separate
overhead door holder.
Extra-Clearance - #290 Offset Soffit Plate: For use where
the need for additional clearance prevents use of the standard
soffit plate. This plate mounts to the frame soffit to provide up
to 2" (51mm) of clearance when a separate overhead door
holder is used. Standard mounting requires a 2-5/8" (67mm)
wide frame soffit. It may also be used where unusually high
frame stops or weatherstripping prevents the use of other
soffit plates.
13
1900 series door closer
parallel rigid arm
Flush Transom - #293L Angle Bracket: For
use where flush transom conditions prevent
installation of the standard hold open soffit plate.
Used for parallel hold open arms.
Standard - #293S Spacer Block: For use where
a narrow frame soffit does not provide adequate
support for the soffit plate. Supplied as standard
with all rigid parallel arm closers.
Clearance/Support Blade Stop - #891
Spacer Block: For use where the frame has
a blade stop and the soffit plate must be
mounted on the frame rabbet. This accessory
is used in combination with the standard
Spacer Block to provide clearance of the
blade stop.
Narrow Frame - #890 Support Bracket: For
use where the frame is narrow, and the soffit plate
cannot be mounted directly to the frame soffit or
rabbet. Used in combination with the #891 Spacer
Block on blade stop frames to provide extra
support and needed clearance of the blade stop.
1-1/2
(38)
1-1/2
(38)
brackets for non-hold open and hold open arms
Narrow Top Rail - #1988 Drop Plate: For use
where a narrow top rail prevents the closer from
being mounted directly to the door surface.
closer mounting plates
14
1900 series door closer
uni stop™ arm
brackets
Flush Transom - 589L Angle Bracket: For
use where rabbeted or flush transom conditions
prevent installation of a soffit plate. Used in
combination with the 289 soffit plate, or it may
be used in combination with the 290 soffit plate
when it is necessary for the closer arm to clear a
separate overhead door holder.
Additional Support - #6190 Reinforcing Bracket:
Standard for use with all parallel arm UNI Stop door
controls. Provides additional support to the soffit
plate on installations with door frame reveals from
1-7/8" to 4-5/8" (48 to 117mm).
Wide Frame - #6191 Reinforcing Kit: Optional for use with all parallel
arm UNI Stop door controls. Used to support the soffit plate on installations
with wide frames. Clamps may be used with or without the spacer block,
depending on frame conditions.
Narrow Top Rail - #1988 Drop Plate: For use
where a narrow top rail prevents the closer from
being mounted directly to the door surface.
closer mounting plates
15
1900 series door closer
corner brackets
The following frame-mounted brackets, 1950, 2950 and 964, require the use of a door closer of the opposite hand
from the hand of the door. Use the Parallel Arm Sizing Chart to select the correct size of closer to use, when the
closer is to be mounted on a corner bracket.
Corner Mounting, Standard Drop - #1950 Corner
Bracket: For use where door is required to open to
180°. Minimum soffit width 1-3/8" (35mm).
Corner Mounting, Extra Drop - #2950 Corner
Bracket: For use with a separate overhead door
holder. Drops closer 1" (25mm) lower than #1950
Standard Drop Corner Bracket to permit mounting
of an overhead holder. Permits door openings to
180°. Minimum soffit width 1-3/8" (35mm).
5/8
(16) Ref.
9-3/8
(238)
7
(178)
5/8
(16) Ref.
9-3/8
(238)
8
(203)
Arched or Circular Top Door - #974 Offset
Adjustable Bracket: For hinge side application on
arched or circular top doors. This door-mounted
bracket is adjustable to accommodate virtually any
radius of frame. Base diameter 3-5/8" (92mm).
Arched or Circular Top Door - #964 Adjustable
Bracket: For opposite hinge side application on
arched or circular top doors. This frame-mounted
bracket can be adjusted to accommodate virtually
any radius of frame. Minimum soffit width 2-1/2"
(64mm). This bracket requires the use of a door
closer of the opposite hand from that of the door.
15
(381)
6-1/2
(165)
16
1900 series door closer
adapter plates
1980 Series Adapter Plate
For use when replacing a discontinued old style 990
Series surface closer with a series 1900 Traditional
Surface Closer. The plate selected will employ the
existing holes in either door or corner bracket. The
Series 1900 closer will mount to the plate. These plates
can be used to convert regular arm, parallel arm or
bracket mount installations. Order by model number.
Size Closer
Being
Replaced
Adapter Plate
Catalog
Number
Dimensions
A B
992/993 1983 5-1/2”
(140)
2-5/8”
(67)
994 None
Required — —
995/996 1986 5-1/2”
(140)
2-5/8”
(67)
17
1900 series door closer
parts list
Arm Function Complete Arm Assembly Main Arm Main Arm
Less Rod & Shoe
Main Arm & Rod Less
Holder Shoe & Loop Assy.
Non-Hold Open Y1900-1
1900-1M
Y1900-1W N/A
Hold Open 1900-3 N/A 1900-3W
Note: Mounting hardware included with all parts ordered
regular arm
Non-Hold Open
Main Arm
Hold Open
Holder Shoe & Loop
1900-13
Jackscrew
1543R
Locknut
455
Friction Disc
1554
(not visible)
Main Arm
Rod & Shoe
1900-11
Note: Mounting hardware included with all parts ordered
18
1900 series door closer
parts list
parallel arm
Arm Function Complete Arm
Assembly Main Arm Main Arm Less
Rod & Soffit Plate
Main Arm & Rod Less
Soffit Plate Holder Assy. & Loop Assy.
Non-Hold Open Y1900-5
1900-1M
Y1900-1W N/A
Hold Open
1900-8R (Right Hand)
N/A 1900-3W
1900-8L (Left Hand)
Hold Open
Soffit Plate Holder
& Loop Assy.
1900-18
(specify hand when ordering)
Main Arm
Main Arm
Rod & Soffit Plate
1900-15
Non-Hold Open
19
1900 series door closer
parts list
parallel rigid arm assemblies
Arm Function Complete Arm Assembly Jackscrew
Non-Hold Open PR1900-5 N/A
Hold Open
PR1900-8R (Right Hand) 1543R
PR1900-8L (Left Hand) 1543L
Note: Mounting hardware included with all parts ordered
Non-Hold Open
Hold Open
Jackscrew
(see chart)
Locknut
455
Friction Disc
1554
(not visible)
20
1900 series door closer
parts list
uni stop™ arm assemblies
Main Arm
Main Arm
Door Width
(cm)
Main Arm
Length* (mm)
Complete Arm Assembly
Non-Hold Open Hold Open
28"- 32"
(71 - 81)
9-1/2"
(241) 6130-17 6130-7
33"- 41"
(84 - 104)
11"
(279) 6130-18 6130-8
42"- 48"
(107 - 122)
12-1/2"
(318) 6130-19 6130-9
Note: Mounting hardware included with all parts ordered
Non-Hold Open
Hold Open
* Center to center length
21
1900 series door closer
parts list
Type Description Arm
RA PA PR UNI STOP™
DOOR
SDST Self-Drilling Self-Tapping S S S S
MS Machine Screw S S S S
SN Sleeve Nut O O S S
TBGN Thru Bolts & Grommet Nuts O O O O
FRAME
SDST Self-Drilling Self-Tapping S S S S
MS Machine Screw S S S S
S = standard; O = optional
SN are for use on unreinforced hollow metal
doors or to prevent any hollow metal door
from collapse/dimpling. They can also be
used for thru bolting on wood doors. SN are
supplied for 1-3/4" (44mm) thick doors unless
specified for 2-1/4" (57mm).
TBGN are an alternative to SN for wood
doors. TBGN are supplied standard for
1-3/4" (44mm) thick doors. They can be
specified for 1-3/8" (35mm) thick doors.
screw packs
Closer Bodies
1902/4 LAP Size 2-4 body
1905/6 LAP Size 5/6 body
Sex Nuts
SN-134 1-3/4" door
SN-214 2-1/4" door
Thru Bolts & Grommet Nuts
TBGN138-38 1-3/8" door
TBGN134-38 1-3/4" door
TBGN214-38 2-1/4" door
Springs
24BD B/D Spring
56EF E/F Spring
230BC Spring (prior to 1978 model)
230D Spring (prior to 1978 model)
230EF Spring (prior to 1978 model)
miscellaneous parts
fasteners
22
1900 series door closer
how to order
2 thru 4 - 2/4
5 or 6 - 5/6
0 - Non-Hold Open
1 - Hold Open
None - Regular Arm
PA - Parallel Arm
PR - Parallel Rigid Arm
UNI - UNI Stop™ Arm
(specify door width)
PA
PREFIX
19
CLOSER SERIES
0
ARM
FUNCTION
2/4
CLOSER SIZE
DL
SUFFIXES
689
FINISH
(see page 2)
DL - Delayed Action (Regular
Non-Hold Open Arm
Application Only), Handed
Note: Contact factory if door weight exceeds 250 lbs.
notes
1900 series door closer
23
online literature and templates
1900 series door closer
Yale Locks & Hardware is a division of Yale Security Inc., an ASSA ABLOY Group company.
Yale® is a registered trademark of Yale Security Inc., an ASSA ABLOY Group company. Uni Stop™ is a trademark of Yale Security Inc., an ASSA ABLOY Group company. Other products'
brand names may be trademarks or registered trademarks of their respective owners and are mentioned for reference purposes only. These materials are protected under U.S. copyright laws.
All contents current at time of publication. Yale Security Inc. reserves the right to change availability of any item in this catalog, its design, construction, and/or its materials. Copyright © 2001, 2014,
Yale Security Inc., an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Yale Security Inc., an ASSA ABLOY Group
company is prohibited.
YALE, with its unique global reach and range of products, is the world’s favorite lock.
ASSA ABLOY is the global leader in door opening solutions, dedicated to satisfying end-user needs for security, safety and convenience.
42066-2/14RE
An ASSA ABLOY Group brand
For the latest information on Yale Locks & Hardware products, visit our website at: www.yalelocks.com
Click on the “Product Information” button to find:
• Catalogs
• Partsmanuals
• Templates
• Specifications
• Installationinstructions
Yale® customers can click on the ebusiness symbol on the website to register for an ebusiness account to:
• Checkthestatusoforders
• CheckavailabilityofQuickShipitems
• Trackyourorderandconfirmdelivery
• Receiveemailnotificationoftemplatechanges
And More...
Or contact us at:
U.S.A.
Yale Locks & Hardware
Address: 225 Episcopal Road, Berlin, CT 06037-4004
Tel:1-800-438-1951•Fax:1-800-338-0965•www.yalelocks.com
Canada:
ASSA ABLOY Door Security Solutions Canada
Address: 160 Four Valley Drive, Vaughan, Ontario L4K 4T9
Tel:1-800-461-3007•Fax:1-800-461-8989•www.assaabloy.ca
International:
ASSA ABLOY Americas International
Tel:1-905-821-7775•Fax:1-905-821-1429•www.assaabloyai.com
