Yamaha DGX500 Owner's Manual

[4.6MB] dgx300 Manual Library - Yamaha - United States

User Manual: Yamaha DGX500 Owner's Manual

Open the PDF directly: View PDF PDF.
Page Count: 112 [warning: Documents this large are best viewed by clicking the View PDF Link!]

2
PLEASE KEEP THIS MANUAL
This product utilizes batteries or an external power supply (adapter). DO
NOT connect this product to any power supply or adapter other than one
described in the manual, on the name plate, or specifically recommended
by Yamaha.
This product should be used only with the components supplied or; a cart,
rack, or stand that is recommended by Yamaha. If a cart, etc., is used,
please observe all safety markings and instructions that accompany the
accessory product.
SPECIFICATIONS SUBJECT TO CHANGE:
The information contained in this manual is believed to be correct at the
time of printing. However, Yamaha reserves the right to change or modify
any of the specifications without notice or obligation to update existing
units.
This product, either alone or in combination with an amplifier and head-
phones or speaker/s, may be capable of producing sound levels that could
cause permanent hearing loss. DO NOT operate for long periods of time at
a high volume level or at a level that is uncomfortable. If you experience
any hearing loss or ringing in the ears, you should consult an audiologist.
IMPORTANT: The louder the sound, the shorter the time period before
damage occurs.
NOTICE:
Service charges incurred due to a lack of knowledge relating to how a
function or effect works (when the unit is operating as designed) are not
covered by the manufacturer’s warranty, and are therefore the owners
responsibility. Please study this manual carefully and consult your dealer
before requesting service.
ENVIRONMENTAL ISSUES:
Yamaha strives to produce products that are both user safe and environ-
mentally friendly. We sincerely believe that our products and the produc-
tion methods used to produce them, meet these goals. In keeping with
both the letter and the spirit of the law, we want you to be aware of the fol-
lowing:
Battery Notice:
This product MAY contain a small non-rechargeable battery which (if appli-
cable) is soldered in place. The average life span of this type of battery is
approximately five years. When replacement becomes necessary, contact
a qualified service representative to perform the replacement.
This product may also use “household” type batteries. Some of these may
be rechargeable. Make sure that the battery being charged is a recharge-
able type and that the charger is intended for the battery being charged.
When installing batteries, do not mix batteries with new, or with batteries of
a different type. Batteries MUST be installed correctly. Mismatches or
incorrect installation may result in overheating and battery case rupture.
Warning:
Do not attempt to disassemble, or incinerate any battery. Keep all batteries
away from children. Dispose of used batteries promptly and as regulated
by the laws in your area. Note: Check with any retailer of household type
batteries in your area for battery disposal information.
Disposal Notice:
Should this product become damaged beyond repair, or for some reason
its useful life is considered to be at an end, please observe all local, state,
and federal regulations that relate to the disposal of products that contain
lead, batteries, plastics, etc. If your dealer is unable to assist you, please
contact Yamaha directly.
NAME PLATE LOCATION:
The name plate is located on the bottom of the product. The model num-
ber, serial number, power requirements, etc., are located on this plate. You
should record the model number, serial number, and the date of purchase
in the spaces provided below and retain this manual as a permanent
record of your purchase.
Model
Serial No.
Purchase Date
SPECIAL MESSAGE SECTION
92-BP
(bottom)
3
1. IMPORTANT NOTICE: DO NOT MODIFY THIS UNIT!
This product, when installed as indicated in the instructions contained
in this manual, meets FCC requirements. Modifications not expressly
approved by Yamaha may void your authority, granted by the FCC, to
use the product.
2. IMPORTANT:
When connecting this product to accessories and/or
another product use only high quality shielded cables. Cable/s supplied
with this product MUST be used. Follow all installation instructions.
Failure to follow instructions could void your FCC authorization to use
this product in the USA.
3. NOTE:
This product has been tested and found to comply with the
requirements listed in FCC Regulations, Part 15 for Class “B” digital
devices. Compliance with these requirements provides a reasonable
level of assurance that your use of this product in a residential environ-
ment will not result in harmful interference with other electronic
devices. This equipment generates/uses radio frequencies and, if not
installed and used according to the instructions found in the users
manual, may cause interference harmful to the operation of other elec-
tronic devices. Compliance with FCC regulations does not guarantee
that interference will not occur in all installations. If this product is found
to be the source of interference, which can be determined by turning
the unit “OFF” and “ON”, please try to eliminate the problem by using
one of the following measures:
Relocate either this product or the device that is being affected by the
interference.
Utilize power outlets that are on different branch (circuit breaker or
fuse) circuits or install AC line filter/s.
In the case of radio or TV interference, relocate/reorient the antenna. If
the antenna lead-in is 300 ohm ribbon lead, change the lead-in to co-
axial type cable.
If these corrective measures do not produce satisfactory results,
please contact the local retailer authorized to distribute this type of
product. If you can not locate the appropriate retailer, please contact
Yamaha Corporation of America, Electronic Service Division, 6600
Orangethorpe Ave, Buena Park, CA90620
The above statements apply ONLY to those products distributed by
Yamaha Corporation of America or its subsidiaries.
FCC INFORMATION (U.S.A.)
* This applies only to products distributed by YAMAHA CORPORATION OF AMERICA.
Entsorgung leerer Batterien (nur innerhalb Deutschlands)
Leisten Sie einen Beitrag zum Umweltschutz. Verbrauchte Batterien
oder Akkumulatoren dürfen nicht in den Hausmüll. Sie können bei einer
Sammelstelle für Altbatterien bzw. Sondermüll abgegeben werden.
Informieren Sie sich bei Ihrer Kommune.
(class B)
(battery)
OBSERVERA!
Apparaten kopplas inte ur växelströmskällan (nätet) sá länge som den
ar ansluten till vägguttaget, även om själva apparaten har stängts av.
ADVARSEL:
Netspæendingen til dette apparat er IKKE afbrudt,
sálæenge netledningen siddr i en stikkontakt, som er t endt — ogsá sel-
vom der or slukket pá apparatets afbryder.
VAROITUS:
Laitteen toisiopiiriin kytketty käyttökytkin ei irroita koko lait-
etta verkosta.
(standby)
4
PRECAUTIONS
PLEASE READ CAREFULLY BEFORE PROCEEDING
* Please keep this manual in a safe place for future reference.
WARNING
Always follow the basic precautions listed below to avoid the possibility of serious injury or even death from electrical
shock, short-circuiting, damages, fire or other hazards. These precautions include, but are not limited to, the following:
(4)-8
1/2
• Only use the voltage specified as correct for the instrument. The required
voltage is printed on the name plate of the instrument.
• Use the specified adaptor (PA-5D, PA-5C or an equivalent recommended by
Yamaha) only. Using the wrong adaptor can result in damage to the instrument
or overheating.
• Check the electric plug periodically and remove any dirt or dust which may have
accumulated on it.
• Do not place the AC adaptor cord near heat sources such as heaters or radiators,
and do not excessively bend or otherwise damage the cord, place heavy objects
on it, or place it in a position where anyone could walk on, trip over, or roll
anything over it.
• Do not open the instrument or attempt to disassemble the internal parts or
modify them in any way. The instrument contains no user-serviceable parts. If it
should appear to be malfunctioning, discontinue use immediately and have it
inspected by qualified Yamaha service personnel.
• Do not expose the instrument to rain, use it near water or in damp or wet
conditions, or place containers on it containing liquids which might spill into
any openings.
• Never insert or remove an electric plug with wet hands.
• Do not put burning items, such as candles, on the unit.
A burning item may fall over and cause a fire.
• If the AC adaptor cord or plug becomes frayed or damaged, or if there is a
sudden loss of sound during use of the instrument, or if any unusual smells or
smoke should appear to be caused by it, immediately turn off the power switch,
disconnect the adaptor plug from the outlet, and have the instrument inspected
by qualified Yamaha service personnel.
Power supply/AC power adaptor
Do not open
Water warning
Fire warning
If you notice any abnormality
CAUTION
Always follow the basic precautions listed below to avoid the possibility of physical injury to you or others, or damage
to the instrument or other property. These precautions include, but are not limited to, the following:
• When removing the electric plug from the instrument or an outlet, always hold
the plug itself and not the cord.
• Unplug the AC power adaptor when not using the instrument, or during
electrical storms.
• Do not connect the instrument to an electrical outlet using a multiple-connector.
Doing so can result in lower sound quality, or possibly cause overheating in the
outlet.
• Always make sure all batteries are inserted in conformity with the +/- polarity
markings. Failure to do so might result in overheating, fire, or battery fluid
leakage.
• Always replace all batteries at the same time. Do not use new batteries together
with old ones. Also, do not mix battery types, such as alkaline batteries with
manganese batteries, or batteries from different makers, or different types of
batteries from the same maker, since this can cause overheating, fire, or battery
fluid leakage.
• Do not dispose of batteries in fire.
• Do not attempt to recharge batteries that are not intended to be charged.
• When the batteries run out, or if the instrument is not to be used for a long time,
remove the batteries from the instrument to prevent possible leakage of the
battery fluid.
• Keep batteries away from children.
• If the batteries do leak, avoid contact with the leaked fluid. If the battery fluid
should come in contact with your eyes, mouth, or skin, wash immediately with
water and consult a doctor. Battery fluid is corrosive and may possibly cause
loss of sight or chemical burns.
• Do not expose the instrument to excessive dust or vibrations, or extreme cold or
heat (such as in direct sunlight, near a heater, or in a car during the day) to
prevent the possibility of panel disfiguration or damage to the internal
components.
• Do not use the instrument in the vicinity of a TV, radio, stereo equipment,
mobile phone, or other electric devices. Otherwise, the instrument, TV, or radio
may generate noise.
• Do not place the instrument in an unstable position where it might accidentally
fall over.
• Before moving the instrument, remove all connected adaptor and other cables.
• Use only the stand specified for the instrument. When attaching the stand or
rack, use the provided screws only. Failure to do so could cause damage to the
internal components or result in the instrument falling over.
Power supply/AC power adaptor
Battery
Location
5
Always turn the power off when the instrument is not in use.
When using a power adaptor, even when the power switch is in the “STANDBY” position, electricity is still flowing to the instrument at the minimum level. When you are not
using the instrument for a long time, make sure you unplug the AC power adaptor from the wall AC outlet.
Make sure to discard used batteries according to local regulations.
●
Three of the demo-songs (or compositions) included in this keyboard are as follows:
Composition Title: Just The Way You Are
Composer’s Name: Joel 0273671
Copyright Owner’s Name: EMI MUSIC PUBLISHING LTD
Composition Title: Ribbon In The Sky
Composer’s Name: Wonder 0404386
Copyright Owner’s Name: Black Bull Music / Jobete Music Co Ltd
Composition Title: Look Of Love
Composer’s Name: Bacharach/David 0093316
Copyright Owner’s Name: Screen Gems - EMI Music Ltd
CAUTION: All Rights Reserved, Unauthorized copying, public performance and broadcasting are strictly prohibited
regarding the above three demo-songs.
●
COPYRIGHT NOTICE
This product incorporates and bundles computer programs and contents in which Yamaha owns copyrights or with respect to which it has
license to use others’ copyrights. Such copyrighted materials include, without limitation, all computer software, styles files, MIDI files,
WAVE data and sound recordings. Any unauthorized use of such programs and contents outside of personal use is not permitted under relevant
laws. Any violation of copyright has legal consequences. DON’T MAKE, DISTRIBUTE OR USE ILLEGAL COPIES.
●
Trademarks
• Apple and Macintosh are trademarks of Apple Computer, Inc., registered in the U.S. and other countries.
• Windows is the registered trademark of Microsoft
®
Corporation.
All other trademarks are the property of their respective holders.
Yamaha cannot be held responsible for damage caused by improper use or modifications to the instrument, or data that is lost or destroyed.
• The illustrations and LCD screens as shown in this owner’s manual are for instructional purposes only, and may be different from the ones on your instrument.
• Unless otherwise indicated, the example panel control illustrations, Keyboard illustrations and LCD screenshots are taken from the DGX-500.
• Before connecting the instrument to other electronic components, turn off the
power for all components. Before turning the power on or off for all
components, set all volume levels to minimum. Also, be sure to set the volumes
of all components at their minimum levels and gradually raise the volume
controls while playing the instrument to set the desired listening level.
• When cleaning the instrument, use a soft, dry cloth. Do not use paint thinners,
solvents, cleaning fluids, or chemical-impregnated wiping cloths.
• Do not insert a finger or hand in any gaps on the instrument.
• Never insert or drop paper, metallic, or other objects into the gaps on the panel
or keyboard. If this happens, turn off the power immediately and unplug the
power cord from the AC outlet. Then have the instrument inspected by qualified
Yamaha service personnel.
• Do not place vinyl, plastic or rubber objects on the instrument, since this might
discolor the panel or keyboard.
• Do not rest your weight on, or place heavy objects on the instrument, and do not
use excessive force on the buttons, switches or connectors.
• Do not operate the instrument for a long period of time at a high or
uncomfortable volume level, since this can cause permanent hearing loss. If you
experience any hearing loss or ringing in the ears, consult a physician.
Saving and backing up your data
For instruments with RAM that retains data by using dry cell batteries
or a power adaptor
• As long as dry cell batteries are installed or the power adaptor is connected, the
instrument retains the internal data when the power is turned off. If you remove
the batteries and disconnect the adaptor, the data will be lost. Save important
data to a floppy disk/external media such as the Yamaha MDF3 MIDI data filer.
Keep the power adaptor connected while you replace the batteries to prevent
loss of data.
Backing up the floppy disk
• To protect against data loss through media damage, we recommend that you
save your important data onto two floppy disks.
Connections
Maintenance
Handling caution
Saving data
(4)-8
2/2
6
Congratulations on your purchase of the Yamaha DGX-500/300 Portable Grand
™
!
You now own a portable keyboard that combines advanced functions, great sound and
exceptional ease-of-use in a highly compact package. Its outstanding features also
make it a remarkably expressive and versatile instrument.
Read this Owner’s Manual carefully while playing your new DGX-500/300 in order to
take full advantage of its various features.
Main Features
The DGX-500/300 is a sophisticated yet easy-to-use keyboard with the following features and functions:
■ MUSIC DATABASE ............................. page 53
The DGX-500/300 has an advanced, easy-to-use Music Database feature that automatically selects the style, voice, and
effect settings for playing in a specific type of music. This can be a big help if you know what genre of music you want
to play, but you don’t know what settings to make. Just select the genre, and the DGX-500/300 takes care of the rest!
■ Disk Drive ............................. page 73
The DGX-500/300 also features a convenient floppy disk drive letting you load and save your own original User Songs
or load the Style Files. The DGX-500/300 is also compatible with a wide variety of disk formats, allowing you to play
back song data on commercially available GM, DOC, and Clavinova Disklavier Piano Soft disks.
It also allows you to save and play back Standard MIDI File (SMF) format 0 data,making it possible to use song data
with your favorite sequencer or sequencingsoftware.
■ Powerful Speaker System
The built-in stereo amplifier/speaker system of the DGX-500/300 with a special Bass Boost feature — provides excep-
tionally powerful, high-quality sound, letting you hear the full dynamic range of the DGX-500/300’s authentic voices.
■ GM System Level 1
“GM System Level 1” is an addition to the MIDI standard which ensures that any GM-compatible music data can be
accurately played by any GM-compatible tone generator, regardless of manufacturer. The GM mark is affixed to all
software and hardware products that support GM System Level.
■ XGlite
As its name implies, “XGlite” is a simplified version of Yamaha’s high-quality XG tone generation format. Naturally,
you can play back any XG song data using an XGlite tone generator. However, keep in mind that some songs may
play back differently compared to the original data, due to the reduced set of control parameters and effects.
Other powerful features include:
• The advanced
Yamaha Education Suite
— a special set of
learning tools that make it easy and fun to master the keyboard.
These tools include
Lesson
, which guides you through the
parts of a song just as a teacher would,
Grade
, which evaluates
your practice sessions and rates your performance, and
Dictio-
nary
, which teaches you how to play chords.
• Instant
Portable Grand
function, for automatically configur-
ing the DGX-500/300 for optimum piano play. Includes an
authentic Stereo Sampled Piano voice.
•
619
exceptionally
realistic and dynamic voices
, utilizing digi-
tal recordings of actual instruments.
• Special
Split voices
, with two different voices playable from
separate sections of the keyboard.
• 12 different
Drum Kit voices
, with individual drum and per-
cussion sounds on each key.
• High-quality
Reverb, DSP, and Harmony effects
for enhanc-
ing the sound of the voices — and your performance.
•
135 auto accompaniment styles
, each with Intro, Main A and
B, and Ending sections. An Auto Fill function adds dynamic
fills when switching sections.
• Powerful, easy-to-use
song recording
operations, for record-
ing and playing back up to five of your original songs.
•
Registration Memory
presets for storing all of the DGX-500/
300’s panel settings to a single button for instant and automatic
recall.
•
One Touch Setting
function for automatically calling up an
appropriate voice to match the style or song you select.
•
Touch Response
and
Dynamic Filter
that give you extraordi-
narily expressive control over the voices. They automatically
change both the volume and tone according to your playing
strength — just like a real musical instrument!
7
Panel Controls and Terminals ........................ 8
Setting Up....................................................... 10
• Power Requirements ........................................10
• Turning On the Power.......................................11
• Accessory Jacks ...............................................11
Quick Guide 12
Step 1 Voices ........................................................... 12
Step 2 Songs............................................................ 14
Step 3 Music Database............................................. 16
Step 4 Lesson .......................................................... 18
Panel Display Indications .............................20
Portable Grand............................................... 22
• Playing the Portable Grand...............................22
• Using the Metronome .......................................22
Playing Voices ...............................................24
• Playing a Voice .................................................24
• Dual Voice ........................................................26
Main Voice and Dual Voice settings ...........27
• Split Voice.........................................................28
• One Touch Setting............................................28
• Transpose and Tuning......................................29
• Pitch Bend Range.............................................31
• Touch and Touch Sensitivity.............................32
Effects............................................................. 33
• Reverb ..............................................................33
• DSP ..................................................................34
• Harmony ...........................................................35
Selecting and Playing Styles ........................ 38
• Selecting a Style ...............................................38
• Playing the styles..............................................39
• Sync Stop .........................................................43
• Changing the Tempo ........................................44
• MAIN/AUTO FILL (Main A/B and Fill-ins) ........45
• Adjusting the Accompaniment Volume .............46
• Using Auto Accompaniment
— Multi Fingering .............................................47
• Setting the Split Point .......................................49
• Dictionary..........................................................50
Using the Music Database ............................ 53
• Data stored by the Music Database..................54
Registration Memory ..................................... 55
• Registration Memory Presets ...........................55
• Recording a Registration Memory Preset.........55
• Recalling a Registration Memory Preset ..........56
Selecting and Playing Songs ....................... 57
• Selecting and Playing a Song .......................... 57
• A-B Repeat ...................................................... 58
• Melody Voice Change...................................... 59
• Changing the Tempo ....................................... 60
• Adjusting the Song Volume.............................. 61
Song Recording............................................. 62
• Recording a User Song.................................... 62
• Song Clear ....................................................... 65
• Track Clear ...................................................... 66
Song Lesson.................................................. 67
• Using the Lesson Feature................................ 67
• Select the Lesson Track .................................. 69
• Lesson 1 — Timing .......................................... 69
• Lesson 2 — Waiting......................................... 70
• Lesson 3 — Minus One ................................... 70
• Lesson 4 — Both Hands .................................. 71
• Grade ............................................................... 72
Disk Operations............................................. 73
• Disk Song Playback ......................................... 75
• Save................................................................. 76
Saving files in SMF Format 0..................... 78
• Load ................................................................. 79
• Utility – Delete.................................................. 80
• Utility – Formatting an Unformatted Disk ......... 81
• Utility – Formatting a Previously
Formatted Disk ................................................ 82
MIDI Functions............................................... 83
• What Is MIDI? .................................................. 83
• Connecting to a Personal Computer................ 85
• Local Control.................................................... 86
• Using Initial Setup Send with a Sequencer...... 87
• External Clock.................................................. 88
Troubleshooting ............................................ 89
Data Backup & Initialization ......................... 90
Voice List ....................................................... 91
Style List ........................................................ 98
Music Database List...................................... 99
Drum Kit List................................................ 100
MIDI Implementation Chart......................... 102
Effect map .................................................... 104
Keyboard Stand Assembly
(DGX-500 only)............................................. 105
Specifications .............................................. 108
Index ............................................................. 109
Contents
8
Panel Controls and Terminals
q
Power switch ([STANDBY/ON])
w
[MASTER VOLUME] dial
This determines the overall volume of the DGX-500/300.
e
[TOUCH] button
This turns the Touch function on and off. (See page 32.)
Holding down this button allows you to adjust the Touch
Sensitivity setting. (See page 32.)
r
[HARMONY] button
This turns the Harmony effect on and off. (See page 35.)
t
[SPLIT] button
This instantly calls up the last selected Split Voice. (See
page 28.)
y
[DUAL] and [SETTING
▲
/
▼
] buttons
Use the [DUAL] button to turn the Dual voice on or off.
Use the [SETTING
▲
/
▼
] buttons to set the parameters
related to the Main and Dual voices. (See page 26.)
u
Overall (left, right) buttons
These two buttons on either side of the LCD let you call up
various functions, settings, and operations of the DGX-500/
300, including effects, transpose, tuning, and MIDI. (See
page 20.)
i
[DEMO] button
This is used to play the Demo songs. (See page 14.)
o
LESSON [L] (Left) and [R] (Right) buttons
These call up the Lesson exercises for the corresponding
hand (left or right) for the selected song. (See page 68.)
!0
[DICTIONARY] button
This calls up the Dictionary function (page 50).
!1
[METRONOME] button
This turns the metronome on and off. (See page 22.) Hold-
ing down this button allows you to set the Time Signature.
!2
[PORTABLE GRAND] button
This instantly calls up the Grand Piano voice. (See page
12.)
!3
[SONG] button
This is for enabling song selection. (See page 57.)
!4
[STYLE] button
This is for enabling style selection. (See page 38.)
!5
[VOICE] button
This is for enabling voice selection. (See page 24.) Holding
down this button calls up the Melody Voice Change func-
tion. (See page 59.)
!6
[M.D.B.] (MUSIC DATABASE) button
This calls up the optimum panel settings for selected music
genre. (See page 53.)
!7
Numeric keypad, [+/YES] and [-/NO] buttons
These are used for selecting songs, voices, styles, and
M.D.B.. (See pages 25.) They are also used for adjusting
certain settings and answering certain display prompts.
!8
[ACMP] / [A-B REPEAT] button
When the Style mode is selected, this turns the auto accom-
paniment on and off. (See page 39.) This also determines
the Accompaniment Split Point. In the Song mode, this
calls up the A-B Repeat function. (See page 58.)
■
Front Panel
Live!Gnd
001
001
q
w
e
i
!8 !9 @0 @1 @2 @3 @4 @5 @6 @7
@8
o!0 !1
!2
r t y u u !7
!3
!4
!5
!6
Panel Controls and Terminals
9
!9
[SYNC STOP] button
This turns the Sync Stop function on and off. (See page
43.)
@0
[SYNC START] / [PAUSE] button
This turns the Sync Start function on and off. (See page
40.) In the Song mode, it is used to temporarily pause song
playback. (See page 59.)
@1
[START/STOP] button
When the Style mode is selected, this alternately starts and
stops the style. (See page 39.) In the Song mode, this alter-
nately starts and stops song playback. (See page 58.)
@2
[INTRO ENDING] / [ REW] button
When the Style mode is selected, this is used to control the
Intro and Ending functions. (See page 39.) When the Song
mode is selected, this is used as a “rewind” control, or
move the song playback point back toward the beginning.
@3
[MAIN/AUTO FILL] / [FF ] button
When the Style mode is selected, these are used to change
auto accompaniment sections and control the Auto Fill
function. (See page 45.) When the Song mode is selected,
this is used as a “fast forward” control, or move the song
playback point toward the end.
@4
[TEMPO/TAP] button
This button is used to call up the Tempo setting, letting you
set the Tempo with the numeric keypad or [+]/[-] buttons.
(See page 22.) It also allows you to tap out the tempo and
automatically start a selected song or style at that tapped
speed. (See page 40.)
@5
[SONG MEMORY] buttons
These buttons ([REC], [1] - [5], [A]) are used for song
recording, letting you record up to six different tracks of a
song (including a special Accompaniment track). (See
page 63.) They are also used for clearing recorded data of
all or specific tracks of a User song. (See pages 65, 66.)
@6
REGISTRATION MEMORY buttons
These are used for selecting and recording the Registration
Memory presets. (See page 55.)
@7
Disk Drive
This is for insertion of floppy disks, for loading and saving
of data. (See page 73.)
@8 Disk control buttons
These buttons are used for disk drive control.
@9 [PITCH BEND] wheel
This is used for raising or lowering the
pitch of the voices as you play.
The pitch bend range of the wheel can also
be set. (See page 31.)
■ Rear Panel
#0 #1 #2 #3
#0 MIDI IN, OUT terminals
These are for connection to other MIDI instruments and
devices. (See page 84.)
#1 FOOTSWITCH jack
This is for connection to Footswitch for control over sus-
tain, just like the damper pedal on a piano. (See page 11.)
#2 PHONES/OUTPUT jack
This is for connection to a set of stereo headphones or to an
external amplifier/speaker system. (See page 11.)
#3 DC IN 12V jack
This is for connection to a PA-5D or PA-5C AC power
adaptor. (See page 10.)
10
Setting Up
This section contains information about setting up your DGX-500/300 for playing. Make sure to
read this section carefully before using the instrument.
Power Requirements
Although the DGX-500/300 will run either from an AC adaptor or batteries,
Yamaha recommends use of an AC adaptor whenever possible. An AC adaptor is
more environmentally friendly than batteries and does not deplete resources.
■
Using an AC Power Adaptor • • • • • • • • • • • • • • • • • • • • • • • • •
q
Make sure that the [STANDBY/ON] switch of the DGX-500/300 is set to
STANDBY.
w
Connect the AC adaptor (PA-5D, PA-5C or other adaptor specifically recom-
mended by Yamaha) to the power supply jack.
e
Plug the AC adaptor into an AC outlet.
■
Using Batteries • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
For battery operation the DGX-500/300 requires six 1.5V “D” size, R20P (LR20)
or equivalent batteries. (Alkaline batteries are recommended.) When the batteries
need to be replaced, the volume may be reduced, the sound may be distorted, and
other problems may occur. When this happens, turn the power off and replace the
batteries, as described below
q
Turn the instrument upside-down on the soft cloth, then open the battery com-
partment cover located on the instrument’s bottom panel.
w
Insert the six new batteries as shown in the illustration, making sure that the
positive and negative terminals are properly aligned.
e
Replace the compartment cover, making sure that it locks firmly in place.
• Never interrupt the power sup-
ply (e.g. remove the batteries
or unplug the AC adaptor) dur-
ing any DGX-500/300 record
operation! Doing so can result
in a loss of data.
• Use ONLY a Yamaha PA-5D, PA-
5C AC Power Adaptor (or other
adaptor specifically recom-
mended by Yamaha) to power
your instrument from the AC
mains. The use of other adap-
tors may result in irreparable
damage to both the adaptor
and the DGX-500/300.
• Unplug the AC Power Adaptor
when not using the DGX-500/
300, or during electrical
storms.
we
• When the batteries run down,
replace them with a complete
set of six new batteries.
NEVER mix old and new batter
-
ies.
• Do not use different kinds of
batteries (e.g. alkaline and
manganese) at the same time.
• If the instrument is not to be in
use for a long time, remove the
batteries from it, in order to
prevent possible fluid leakage
from the battery.
• Do not open the battery com-
partment cover while the
instrument is still on the stand.
Make sure to properly turn the
instrument face down when
opening the battery compart-
ment cover.
Setting Up
11
Turning On the Power
With the AC power adaptor connected or
with batteries installed, simply press the
power switch until it locks in the ON posi-
tion. When the instrument is not in use, be
sure to turn the power off. (Press the switch
again so that it pops up.)
Accessory Jacks
■ Using Headphones• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
For private practicing and playing without dis-
turbing others, connect a set of stereo headphones
to the rear panel PHONES/OUTPUT jack.
Sound from the built-in speaker system is auto-
matically cut off when you insert a headphone
plug into this jack.
■ Connecting a Keyboard Amplifier or Stereo System • • • • • • •
Though the DGX-500/300 is equipped with a
built-in speaker system, you can also play it
through an external amplifier/speaker system.
First, make sure the DGX-500/300 and any exter-
nal devices are turned off, then connect one end
of a stereo audio cable to the LINE IN or AUX IN
jack(s) of the other device and the other end to
the rear panel PHONES/OUTPUT jack on the
DGX-500/300.
■ Using a Footswitch• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
This feature lets you use a footswitch (Yamaha
FC4 or FC5) to sustain the sound of the voices.
The footswitch functions the same way as a
damper pedal on an acoustic piano — press and
hold down the footswitch as you play the key-
board to sustain the sound.
■ Using the MIDI Terminals • • • • • • • • • • • • • • • • • • • • • • • • • • •
The DGX-500/300 also features MIDI terminals,
allowing you to interface the DGX-500/300 with
other MIDI instruments and devices. (For more
information, see page 84.)
Stereo System
• To prevent damage to the
speakers, set the volume of the
external devices at the mini-
mum setting before connect-
ing them. Failure to observe
these cautions may result in
electric shock or equipment
damage. Also, be sure to set
the volumes of all devices at
their minimum levels and grad
-
ually raise the volume controls
while playing the instrument to
set the desired listening level.
• Make sure that the footswitch
plug is properly connected to the
FOOT SWITCH jack before turn-
ing on the power.
• Do not press the footswitch while
turning the power on. Doing this
changes the recognized polarity
of the footswitch, resulting in
reversed footswitch operation.
MIDI
instrument
12
Live!Gnd
001
001
z w
zq
z
Press the [PORTABLE GRAND] button.
x
Play the keyboard.
Want to find out more? See page 22.
Live!Gnd
001
Playing the Piano
Simply by pressing the [PORTABLE GRAND] button, you can automatically reset the entire DGX-500/300 for piano play.
z
Press the [METRONOME] button.
Want to find out more? See page 22.
Playing along with the Metronome
Step 1 Voices
Quick
Guide
Step 1 Voices
13
q
Press the [VOICE] button.
Live!Gnd
001
Selecting and Playing Other Voices
The DGX-500/300 has a huge total of 619 dynamic and realistic instrument voices. Let’s try a few of them out now...
w
Select a voice.
e
Play the keyboard.
Want to find out more? See page 24.
GrandPno
002
No. Voice Name
PIANO
001 Live! Grand
002 Grand Piano
003 Bright Piano
004 Honky-tonk Piano
005 MIDI Grand Piano
006 CP 80
007 Harpsichord
E.PIANO
008 Galaxy EP
009 Funky Electric Piano
010 DX Modern Elec. Piano
011 Hyper Tines
012 Venus Electric Piano
013 Clavi
ORGAN
014 Cool! Organ
015 Jazz Organ 1
016 Jazz Organ 2
017 Click Organ
018 Bright Organ
019 Rock Organ
020 Purple Organ
021 16'+2' Organ
022 16'+4' Organ
023 Theater Organ
024 Church Organ
025 Chapel Organ
026 Reed Organ
ACCORDION
027 Traditional Accordion
028 Musette Accordion
029 Bandoneon
030 Harmonica
GUITAR
031 Classical Guitar
032 Folk Guitar
033 12Strings Guitar
034 Jazz Guitar
035 Octave Guitar
036 Clean Guitar
037 60’s Clean Guitar
038 Muted Guitar
039 Overdriven Guitar
040 Distortion Guitar
BASS
041 Acoustic Bass
042 Finger Bass
043 Pick Bass
044 Fretless Bass
045 Slap Bass
046 Synth Bass
047 Hi-Q Bass
048 Dance Bass
STRINGS
049 String Ensemble
050 Chamber Strings
051 Synth Strings
052 Slow Strings
053 Tremolo Strings
054 Pizzicato Strings
055 Orchestra Hit
056 Violin
057 Cello
058 Contrabass
059 Banjo
060 Harp
CHOIR
061 Choir
062 Vocal Ensemble
063 Vox Humana
064 Air Choir
SAXOPHONE
065 Soprano Sax
066 Alto Sax
067 Sweet Tenor
068 Breathy Tenor
069 Tenor Sax
No. Voice Name
070 Baritone Sax
071 Oboe
072 English Horn
073 Bassoon
074 Clarinet
TRUMPET
075 Trumpet
076 Muted Trumpet
077 Trombone
078 Trombone Section
079 French Horn
080 Tuba
BRASS
081 Brass Section
082 Big Band Brass
083 Mellow Horns
084 Synth Brass
085 Jump Brass
086 Techno Brass
FLUTE
087 Sweet Flute
088 Flute
089 Piccolo
090 Pan Flute
091 Recorder
092 Ocarina
SYNTH LEAD
093 Square Lead
094 Sawtooth Lead
095 Voice Lead
096 Star Dust
097 Brightness
098 Analogon
099 Fargo
SYNTH PAD
100 Fantasia
101 Bell Pad
102 Xenon Pad
103 Equinox
No. Voice Name
104 Dark Moon
PERCUSSION
105 Vibraphone
106 Marimba
107 Xylophone
108 Steel Drums
109 Celesta
110 Tubular Bells
111 Timpani
112 Music Box
SPLIT
113 Acoustic Bass/Live! Grand
114 Finger Bass /Grand Piano
115 Fretless Bass/DX Modern
Elec. Piano
116 Acoustic Bass/Vibraphone
117 Fretless Bass/Brass
Section
118 Analogon/Sawtooth Lead
119 Slap Bass/Clavi
120 Classical Guitar/Sweet
Flute
121 String Ensemble/Live!
Grand
122 Vox Humana/Choir
DRUM KITS
123 Standard Kit 1
124 Standard Kit 2
125 Room Kit
126 Rock Kit
127 Electronic Kit
128 Analog Kit
129 Dance Kit
130 Jazz Kit
131 Brush Kit
132 Symphony Kit
133 SFX Kit 1
134 SFX Kit 2
No. Voice Name
● Panel Voice List
* This list includes only a portion of the total available voices.
14
Quick
Guide Step 2 Songs
Live!Gnd
001
001
z xw
q
zx
xce
Playing the Songs
The DGX-500/300 is packed with a total of 100 songs, including three Demo songs that have been specially created to show-
case the rich and dynamic sounds of the instrument. You can also try out the songs with the educational Lesson feature.
Let’s play the Demo songs now, Repeating with (001 -
003)
z
Start the Demo song.
x
Stop the Demo song.
Playing the Demo songs
You can also play back songs of other categories. Simply
select the appropriate number of the desired song during
playback.
or
• The DGX-500/300 also has a Demo Cancel function that allows you
to disable Demo playback.
To enable Demo Cancel, simultaneously hold down the [DEMO] but-
ton and turn on the power.
To restore the Demo capabilities, simply turn the power off and on
again.
Naturally, you can also individually select and play back
the DGX-500/300’s songs (001 - 205).
z
Press the [SONG] button.
x
Select a song.
c
Start (and stop) the song.
Want to find out more? See page 57.
Playing a single song
B Bailey
004
IrishEye
005
Step 2 Songs
15
Playing the Disk Song
This function lets you play songs contained on the included disk or on other song data disks.
q
Insert the disk.
w
Select a desired User song.
Filename
101
e
To start or stop playing, press the [START/
STOP] button.
Want to find out more? See page 75.
No. Song Name
DEMO
001 The Look Of Love
(DGX-500)
Ribbon In The Sky
(DGX-300)
002 Just The Way You Are
003 Ribbon In The Sky
(DGX-500)
The Look Of Love
(DGX-300)
FAVORITES
004 Bill Bailey (Won’t You
Please Come Home)
005 When Irish Eyes Are Smiling
060 Down By The Riverside
007 America The Beautiful
008 When The Saints Go
Marchin’ In
ORCHESTRA
009 Frühlingsstimmen
010 Danse Des Mirlitons From
“The Nutcracker”
011 “Orphée Aux Enfers”
Ouverture
012 Slavonic Dances No.10
013 La Primavera
(From Le Quattro Stagioni)
014 Méditation De Thais
015 Guillaume Tell
016 Camptown Races
017 Frühlingslied
018 Ungarische Tänze Nr.5
PIANIST
019 Dolly’s Dreaming And
Awakening
020 La Candeur
021 Arabesque
022 Pastorale
023 Petite Réunion
024 Innocence
025 Progrès
026 Tarentelle
027 La Chevaleresque
028 Etude Op.10-3
“Chanson De L’adieu”
029 Marcia Alla Turca
030 Turkish March
031 Valse Op.64-1 “Peiti Chien”
032 Menuett
033 Nocturne Op.9-2
034 Moments Musicaux Op.94-3
035 The Entertainer
036 Prelude (Wohltemperierte
Klavier 1-1)
037 La Viollette
038 Für Elise
PRACTICE
039 Little Brown Jug
040 Loch Lomond
041 Oh! Susanna
042 Greensleeves
043 Aura Lee
044 Londonderry Air
045 Ring De Banjo
046 Wenn Ich Ein Vöglein Wär ?
047 Die Lorelei
048 Funiculi-Funicula
049 Turkey In The Straw
050 Old Folks At Home
051 Silent Night
052 Jingle Bells
053 Muss I Denn
No. Song Name
054 Liebesträume Nr.3
055 Jesu, Joy Of Man’s Desiring
056 Symphonie Nr.9
057 Song Of The Pearl Fisher
058 Gavotte
059 String Quartet No.17 2nd
Mov. “Serenade”
060 Menuett
061 Canon
062 The Danube Waves
063 From “The Magic Flute”
064 Piano Sonate Op.27-2
“Mondschein”
065 “The Surprise” Symphony
066 To A Wild Rose
067 Air de Toréador “Carmen”
068 O Mio Babbino Caro
(From “Gianni Schicchi”)
DUET
069 Row Row Row Your Boat
070 On Top Of Old Smoky
071 We Wish You A Merry
Christmas
072 Scarborough Fair
073 Im Mai
074 O Christmas Tree
075 Mary Had A Little Lamb
076 Ten Little Indians
077 Pop Goes The Weasel
078 Twinkle Twinkle Little Star
079 Close Your Hands, Open
Your Hands
080 The Cuckoo
081 O Du Lieber Augustin
082 London Bridge
No. Song Name
CHORD LESSON
083 Twinkle Twinkle Little Star
084 The Cuckoo
085 London Bridge
086 American Patrol
087 Beautiful Dreamer
088
Battle Hymn Of The Republic
089 Home Sweet Home
090 Valse Des Fleurs
(From “The Nutcracker”)
091 Aloha Oe
092 I’ve Been Working On The
Railroad
093 My Darling Clementine
094 Auld Lang Syne
095 Grandfather’s Clock
096 Amazing Grace
097 My Bonnie
098 Yankee Doodle
099 Joy To The World
100 Ave Maria
No. Song Name
● Song List
* For the songs #004 - #100, refer to the included Song Book.
16
Quick
Guide
Live!Gnd
001
001
x
zb zv
z
Press the [M.D.B.] (MUSIC DATABASE) button.
x
Select a Music Database.
Refer to the Music Database List on page 99.
AlvFevr
001
Croco RK
002
Music Database
Here’s a convenient feature that lets you instantly reconfigure the
DGX-500/300 for playing in different music styles. If you want to
perform in a certain genre but don’t know what settings to make,
simply select the genre from the Music Database — and the DGX-
500/300 makes all the right settings for you!
Left hand
Auto accompaniment
(for example,
bass + guitar + drums)
Right hand
Melody
+
Accompaniment area
• For more infomation on playing proper chords for the auto accompa-
niment, see “Using Auto Accompaniment — Multi Fingering” on page
47 and “Looking up Chords in the Dictionary” on the next page.
c
Play a chord with your left hand.
The style starts as soon as you play the keyboard. For
more on chords, see “Looking up Chords in the Dictio-
nary” on the next page.
v
Stop the style.
Want to find out more? See page 53.
Accompaniment area
Step 3 Music Database
Step 3 Music Database
17
Looking up Chords in the Dictionary
The convenient Dictionary function teaches you how to play chords by showing you the individual notes. In the example
below, we’ll learn how to play a GM7 chord...
Keys for entering
the chord type
(C3 — B4)
Keys for entering
the chord root
(C5 — B5)
Keys for entering the chord
(DGX-500 : A-1 — B2) (DGX-300 : E0 — B2)
z
Press the [DICTIONARY] button.
x
Specify the root note of the chord (in this case,
G).
c
Specify the chord type of the chord (in this
case, M7).
Learning how to play a specific chord
GM7
Root note Chord type
Example:
Dict.
v
Play the notes of the chord as indicated in the
keyboard diagram in the display. The chord
name flashes when the chord is played prop-
erly.
b
To leave the Dictionary function, press the
[DICTIONARY] button again
Want to find out more? See page 50.
Chord area
18
Quick
Guide
Live!Gnd
001
001
v
zx x
z
z
Select one of the Lesson songs.
For instructions on selecting songs, see page 67.
x
Select the part you wish to work on (left or
right) and the Lesson step.
If you want to work on the right-hand part, press the
[R] button; to work on the left, press the [L] button.
Timing
r1
• Each press of the corresponding button ([L] or [R]) alternately selects
Lessons 1 - 3. Pressing both buttons simultaneously calls up Lesson
4, Both Hands.
Using the Lesson Feature
Songs 001 to 100 are specially designed for use with the educational Lesson feature. Lesson makes it fun and easy to master
these songs. You can practice the left- and right-hand parts of each song individually: simply press the appropriate button, [L]
(left) or [R] (right). The practice steps below apply to either hand.
Lesson 1 — Timing . . . . . . . . .This lesson step lets you practice just the timing of the notes.
Lesson 2 — Waiting . . . . . . . .In this lesson step, the DGX-500/300 waits for you to play the correct notes before continu-
ing playback of the song.
Lesson 3 — Minus One . . . . .This lesson step plays back the song with one part muted — letting you play and master the
missing part yourself.
Lesson 4 — Both Hands . . . . .This lesson step is the same as “Minus One,” except in that both the left- and right-hand
parts are muted — letting you play and master both hands.
c
Start the Lesson.
v
When you’re finished, stop the Lesson.
• You can also exit from the Lesson by pressing one the LESSON but-
tons ([L] or [R]) repeatedly until song name is shown in the display.
Step 4 Lesson
Step 4 Lesson
19
Grade
The DGX-500/300 has a built-in evaluation function that
monitors your practicing and — like a real teacher — tells
you how well you did each exercise. Four grades are
assigned, depending on your performance: “OK,” “Good,”
“Very Good!,” and “Excellent!.”
Want to find out more? See page 72.
Changing the Tempo
Naturally, you can change the tempo (speed) of the song
to your liking, letting you slow down difficult passages
and bring up the tempo gradually until you master them at
normal speed.
z
Press the [TEMPO/TAP] button.
x
Use the numeric keypad to set the desired
tempo.
TEMPO
120
• The DGX-500/300 also has a convenient Tap Tempo function that
allows you to “tap” a new tempo in real time. (See page 40.)
This step lets you work on the timing of the notes. In Les-
son 1, the particular note you play on the keyboard is
unimportant. The DGX-500/300 checks your timing and
how rhythmically “tight” your playing is.
Want to find out more? See page 69.
In Lesson 2, you practice playing the notes correctly as
they appear in the display notation. The accompaniment
pauses and waits for you to play the notes correctly before
it continues.
Want to find out more? See page 70.
In Lesson 3, one of the parts is muted, and you practice
the missing part in time with the rhythm.
Want to find out more? See page 70.
Lesson 4 is just like Lesson 3, except that the parts for
both hands are muted, letting you practice the missing
parts in time with the rhythm.
Want to find out more? See page 71.
Lesson 1 — Timing
Lesson 2 — Waiting
Lesson 3 — Minus One
Lesson 4 — Both Hands
Timing
r1
Waiting
r2
MinusOne
r3
BothHand
Lr4
20
Panel Display Indications
The DGX-500/300 features a large multi-function display that shows all important settings for
the instrument. The section below briefly explains the various icons and indications in the dis-
play.
Live!Gnd
001
001
eIndicators
wOverall indicator
oNotation
!0 Keyboard
tBeat
marks
yChord
qSong/Voice/Style name and
number, Tempo
!2 Sync Stop indicator
!3 Accompaniment On
indicator
iSong track
indicators
!4 Touch indicator
!5 Harmony indicator
!6 Dual indicator
uTrack Octave
indicator
!7 Battery Level indicator rMeasure
!1 8va / 15va
qSong/Voice/Style name and number,
Tempo
This portion of the display indicates the name and
number of the currently selected song, voice, or style.
It also displays the name and current value or setting
of the Overall functions and the Function parameters,
as well as other important operation messages.
When the tempo setting is active, the value is shown.
wOverall indicator
The Overall buttons (on either side of the LCD) let
you access the Function operations and settings of the
DGX-500/300. The currently selected setting is indi-
cated by a dark bar that appears next to its name
(printed on the panel).
eIndicators
These indicate the operating condition of the DGX-
500/300 as shown below:
Using the numeric keypad selects
voice numbers. Pressing the
[START/STOP] button starts song
playback.
Using the numeric keypad selects
voice numbers. Pressing the
[START/STOP] button starts style
playback.
Using the numeric keypad selects
song numbers. Pressing the
[START/STOP] button starts song
playback.
Using the numeric keypad selects
style numbers. Pressing the
[START/STOP] button starts style
playback.
Panel Display Indications
21
r Measure
These show the current measure during playback of a
song or style.
tBeat marks
These marks (one large, three small) flash in sequence
and in time with the song or style. The large arrow
indicates the first beat of the measure.
yChord
When a song (with chords) is being played back, this
indicates the current chord root and type. It also indi-
cates chords played in the accompaniment area of the
keyboard when the Style mode and auto accompani-
ment are on.
uTrack Octave indicator
When a disk song is playing and the note data exceeds
the range limit of A-1 – C7 (DGX-500) and E0 – G6
(DGX-300), an “OVER” indication flashes and
Q
or
W
appears in the display.
When a disk song is playing and the track octave set-
ting is raised or lowered, one of +2, +1, -1 and -2 indi-
cations appears in the display.
iSong track indicators
In the song recording and playback, these indicate the
status of the tracks. (See page 63.)
oNotation / !0 Keyboard
These two portions of the display conveniently indi-
cate notes. When a song is being played back, they
show the melody or chord notes in succession. When
you play the keyboard yourself, the display shows the
notes you play.
!1 8va / 15va
Notes played outside the displayable area are indi-
cated by octave marks (“8va” or “15va”).
!2 Sync Stop indicator
This appears when the Sync Stop function is turned
on. (See page 43.)
!3 Accompaniment On indicator
This appears when the auto accompaniment has been
turned on. (See page 39.)
!4 Touch indicator
This appears when the Touch function is turned on.
(See page 32.)
!5 Harmony indicator
This appears when the Harmony effect is turned on.
(See page 35.)
!6 Dual indicator
This appears when the Dual function is turned on.
(See page 26.)
!7 Battery Level indicator
This appears when the battery power is too low to
ensure proper operation. (See page 10.)
• For a few specific chords, not all notes may be shown in the nota-
tion section of the display. This is due to space limitations in the
display.
Music Rest
Insert the bottom edge of the included music rest into
the slot located at the top rear of the DGX-500/300 con-
trol panel.
22
Portable Grand
This convenient function lets you instantly call up the Grand Piano voice.
Playing the Portable Grand
Press the [PORTABLE GRAND] button.
Doing this automatically calls up the special “Stereo Sampled Piano” Live! Grand
voice.
Using the Metronome
1Call up the Tempo setting.
Press the [TEMPO/TAP] button.
2Change the value.
Use the numeric keypad to set the desired Tempo value, or use the [+]/[-]
buttons to increase or decrease the value.
Current Tempo value
TEMPO
068
Ft
Portable Grand
23
3Turn on the Metronome.
Press the [METRONOME] button.
To turn the Metronome off, press the [METRONOME] button again.
1Indicates the beat number
in the measure.
Setting the Metronome Time Signature
The time signature of the Metronome can be set to var-
ious quarter-note based meters.
Hold down the [METRONOME] button (until “TIME
SIG” appears in the display), then press the button on
the numeric keypad that corresponds to the desired
time signature (see chart at right).
• The time signature changes automatically when a style or song is
selected.
Numeric
keypad
Time signature
01 1/4 — Plays only “1” beats (all high clicks)
02 2/4
03 3/4
04 4/4
: :
15 15/4
0 Plays no “1” beats (all low clicks)
Indicates current beat number
TIME SIG
04
Adjusting the Metronome Volume
You can adjust the volume of the Metronome sound independently of the other DGX-500/300 sounds. The volume
range is 000 - 127.
1Call up the Metronome Volume setting.
Press the left Overall button until “MTR VOL” appears in the display.
2Change the value.
Use the numeric keypad to set the desired Metronome Volume value, or use the
[+]/[-] buttons to increase or decrease the value.
Indicates Metronome
Volume is selected
Current Metronome Volume value
MTR VOL
100
1
Restoring the Default Met-
ronome Volume Value
To restore the default Metro-
nome Volume value (100),
press both [+]/[-] buttons
simultaneously (when Metro-
nome Volume is selected in
the Overall menu).
24
Playing Voices
The DGX-500/300 features a total of 619 authentic voices — all of which have been created with
Yamaha’s sophisticated AWM (Advanced Wave Memory) tone generation system. These
include 480 XG voices, plus special Split voices, DJ voices and drum kits.
The DGX-500/300 also has a Dual Voice function that lets you combine two different voices in a
layer, and play the two together across the keyboard.
The voices are divided into various instrument categories, and the names are printed on the panel for conve-
nience. For a complete list of available voices, see page 91.
Special Split voices (#113 - #122) feature two different voices that you can play from separate area of the key-
board — for example, playing a bass voice with your left hand and a piano voice with your right.
A special set of DJ voices (#615 - #619) provides dynamic, exciting voices for playing many of today’s popular
music styles. (See page 97.)
The Voice mode also features special effect sections that let you enhance the sound of the voice. These include
Reverb and Harmony, as well as a “DSP” section that provides miscellaneous effects, such as tremolo, echo,
delay, equalization, and wah. (See page 34.)
There’s also a Touch Sensitivity control (page 32), which determines how the voices respond to your playing
technique.
The DGX-500/300 also includes special Drum Kit voices — #123 - #134 — that let you play various drum and
percussion sounds from the keyboard. (Refer to the Drum Kit Voice list on page 100.)
When a voice is selected, the most suitable DSP Type (page 36) and Harmony Type (page 37) for the voice are
automatically called up.
Playing a Voice
1Press the [VOICE] button.
2Select the desired voice number.
Use the numeric keypad. The voice categories and their numbers are shown
on the panel. A complete list of the available voices is given on page 91.
Indicates Voice mode
is selected
Voice name and number
Live!Gnd
001
001
Playing Voices
25
There are two ways to select voices: 1) directly entering the voice number
with the numeric keypad, or 2) using the [+]/[-] buttons to step up and down
through the voice numbers.
■ Using the numeric keypad
Enter the digits of the voice number as indicated on the panel. For example,
to select voice #109, press “1” on the numeric keypad, then “0”, “9.” For
voice numbers beginning with zeroes (such as #042 or #006), the initial
zeroes may be omitted. In this case, there is a short pause before the indica-
tion appears.
■ Using the [+]/[-] buttons
Press the [+] button to select the next voice number, and press the [-] button
to select the previous voice. Holding down either button continuously
scrolls up or down through the numbers.
3Play the selected voice.
Since either the Style or Song mode is active in the background (as indicated
by the illustration in the display), you can also play styles or songs, respec-
tively, in the Voice mode by simply pressing the [START/STOP] button. The
last selected style or song will be played.
Celesta
109
• Each voice is automatically called
up with the most suitable octave
range setting. Thus, playing mid-
dle C with one voice may sound
higher or lower than another
voice at the same key.
Playing Voices
26
Dual Voice
The Dual Voice function lets you combine two different voices in a layer — one
the Main voice, which is selected normally, and the other the Dual voice, which is
selected here. You can also set various parameters independently for these voices,
such as giving them separate volume, octave, Reverb and DSP settings. This lets
you create an optimum mix for the voices, and enhance the way they blend
together.
1Turn the Dual voice on or off.
Press the [DUAL] button.
C3
Ride Cymbal 1
Tambourine
Cowbell
Vibraslap
Bongo L
Hi-Hat Open
Crash Cymbal 1
Hi-Hat Pedal
Conga H Open
Timbale L
Agogo L
Brush Slap
Castanet
Sticks
Open Rim Shot
Side Stick
Brush Tap
Hand Clap
Hi-Hat Closed
Maracas
Guiro Short
Claves
Cuica Mute
Triangle Mute
Shaker
Chinese Cymbal
Ride Cymbal Cup
Splash Cymbal
Crash Cymbal 2
Ride Cymbal 2
Bongo H
Conga H Mute
Mid Tom L
Mid Tom H
High Tom
Low Tom
Floor Tom H
Conga L
Snare H Soft
Bass Drum Soft
Bass Drum Hard
Bass Drum
Snare M
Snare H Hard
Floor Tom L
Brush Swirl
Brush Tap Swirl
Snare Roll
Seq Click H
Timbale H
Agogo H
Cabasa
Samba Whistle H
Samba Whistle L
Guiro Long
Wood Block H
Wood Block L
Cuica Open
Triangle Open
Jingle Bell
Bell Tree
Surdo Open
Whip Slap
Scratch Push
Finger Snap
Metronome Click
Seq Click L
Metronome Bell
Click Noise
Surdo Mute
Hi Q
Scratch Pull
Drum Kit Voice Chart (voices 123 - 134)
When one of the 12 Drum Kit voices are selected you
can play different drums and percussion instruments on
the keyboard.
Std.Kit1
123
No. Name LCD
123 Standard Kit 1 Std.Kit1
124 Standard Kit 2 Std.Kit2
125 Room Kit Room Kit
126 Rock Kit Rock Kit
127 Electronic Kit Elct.Kit
128 Analog Kit AnlogKit
129 Dance Kit DanceKit
130 Jazz Kit Jazz Kit
131 Brush Kit BrushKit
132 Symphony Kit SymphKit
133 SFX Kit 1 SFX Kit1
134 SFX Kit 2 SFX Kit2
● For example, when 123 “Standard Kit 1” is selected:
Indicates Dual is turned on
Live!Gnd
001
001001
Playing Voices
27
2Select one of the parameters for the Main and Dual voices.
Press the [SETTING ▲] or [SETTING ▼] button, repeatedly if necessary,
until the desired parameter’s name appears in the display.
3Set the parameter’s value.
Use the numeric keypad or the [+]/[-] buttons. (Refer to the parameter list
below.)
M.Volume
104
001
• The Dual Voice function is not
available in the Lesson.
Main Voice and Dual Voice settings
The parameters below provide all settings for both the Main Voice and Dual Voice — letting you change or enhance
the sound of these voices independently.
• Main Volume • Dual DSP Level • Main DSP Level
• Dual Reverb Level • Main Reverb Level • Dual Octave
• Dual Voice • Dual Volume
● Parameters
Parameter Name Display Name Range /
Settings
Main Voice Volume M.Volume 0 – 127 This determines the volume of the Main voice, letting you create an optimum mix
with the Dual voice.
Dual Voice DSP D. DspLv1 0 – 127 This determines how much of the Dual voice’s signal is sent to the DSP effect.
Higher values result in a louder DSP effect for the Dual voice.
Main Voice DSP M. DspLv1 0 – 127 This determines how much of the Main voice’s signal is sent to the DSP effect.
Higher values result in a louder DSP effect for the Main voice.
Dual Voice Reverb D. RevLv1 0 – 127 This determines how much of the Dual voice’s signal is sent to the Reverb effect.
Higher values result in a louder Reverb effect for the Dual voice.
Main Voice Reverb M. RevLv1 0 – 127 This determines how much of the Main voice’s signal is sent to the Reverb ef-
fect. Higher values result in a louder Reverb effect for the Main voice.
Dual Voice Octave D. Octave -2 – 2
(Octaves)
This determines the octave of the Dual voice.
Dual Voice Select D. Voice name 1 – 619 This selects the Dual voice.
Dual Voice Volume D. Volume 0 – 127 This determines the volume of the Dual voice, letting you create an optimum mix
with the Main voice.
Playing Voices
28
Split Voice
Split Voices let you play two different instrument sounds from separate areas of
the keyboard. For example, you can play a bass voice with your left hand and a
piano voice with your right.
1Call up a Split Voice.
Press the [SPLIT] button.
This instantly calls up the last selected Split Voice.
One Touch Setting
This special “voice” is actually a convenient feature which automatically selects a
suitable voice for you when you select a style. The voice is selected to best match
the style or song you’ve called up.
1Select voice #000 (One Touch Setting).
You can also turn on One Touch Setting by simultaneously pressing both the
[+]/[-] buttons.
Split Point
Split Voice Main Voice
• The Split Point setting for the
voice is the same as that of the
Accompaniment Split Point. (See
page 49.)
AcB/Pno
113
001
One Touch Setting is selected
Live!Gnd
000
001
Playing Voices
29
Transpose and Tuning
You can also adjust the tuning and change the transposition (key) of the entire
DGX-500/300 sound with the Transpose and Tuning functions.
■ Transpose • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
Transpose determines the key of both the main voice and the bass/chord accompa-
niment of the selected style. It also determines the pitch of the songs. This allows
you to easily match the pitch of the DGX-500/300 to other instruments or singers,
or play in a different key without changing your fingering. The Transpose settings
can be adjusted over a range of ± 12 semitones (± 1 octave).
1Select the Transpose function.
Press the left Overall button, repeatedly if necessary, until “TRANSPOS”
appears in the display.
2Change the value.
Use the numeric keypad to set the desired Transpose value (-12 – +12). To
transpose the pitch down, simultaneously press and hold the [-] button, and
use the numeric keypad to type in the (negative) value. You can also use the
[+]/[-] buttons to increase or decrease the value. Holding down either button
continuously increases or decreases the value.
• The Transpose function has no
effect on the DJ voices (#615 -
#619) or the Drum Kits voices
(#123 - #134).
Indicates Transpose is selected
Current Transpose value
TRANSPOS
00
001
Restoring the Default Trans-
pose Value
If you’ve changed the Transpose
setting, you can instantly restore
the default setting of “00” by press-
ing both [+]/[-] buttons simulta-
neously (when Transpose is
selected).
Playing Voices
30
■ Tuning • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
Tuning determines the fine pitch setting of both the main voice and the bass/chord
accompaniment of the selected style. It also determines the pitch of the songs.
This allows you to accurately match the tuning with that of other instruments.
The Tuning settings can be adjusted over a range of ± 100 (approx. ± 1 semitone).
1Select the Tuning function.
Press the left Overall button, repeatedly if necessary, until “TUNING”
appears in the display.
2Change the value.
Use the numeric keypad to set the desired Tuning value (-100 – +100). To
tune the pitch down, simultaneously press and hold the [-] button, and use
the numeric keypad to type in the (negative) value. You can also use the [+]/
[-] buttons to increase or decrease the value. Holding down either button
continuously increases or decreases the value.
Indicates Tuning is selected
Current Tuning value
TUNING
000
001
• The Tuning settings have no
effect on the Drum Kit voices
(#123 - #134).
Restoring the Default Tuning
Value
If you’ve changed the Tuning set-
ting, you can instantly restore the
default setting of “00” by pressing
both [+]/[-] buttons simultaneously
(when Tuning is selected).
Playing Voices
31
Pitch Bend Range
The DGX-500/300 has a [PITCH BEND] wheel that lets you change the pitch of
the voices in real time, as you play. The Pitch Bend Range parameter determines
the amount that pitch is raised or lowered when using the [PITCH BEND] wheel.
At the minimum setting, moving the [PITCH BEND] wheel up or down changes
the pitch by a maximum of 1 semitone or half-step in either direction. At the max-
imum setting of 12, pitch is changed over a range of ± one octave (12 semitones).
The [PITCH BEND] wheel affects the voices played in the right-hand section of
the keyboard. (It has no effect on the auto accompaniment.)
1Select the Pitch Bend Range parameter.
Press the left Overall button, repeatedly if necessary, until “PB RANGE”
appears in the display.
2Set the Pitch Bend Range value.
Use the numeric keypad or [+]/[-] buttons to set the desired range: 1 - 12
(semitones).
3Play the keyboard and move the [PITCH BEND] wheel.
Indicates Pitch Bend Range is selected
Current Pitch Bend Range value.
PB RANGE
02
001
Playing Voices
32
Touch and Touch Sensitivity
The Touch function gives you dynamic, expressive control over the voices, letting
you determine how loud or soft the sound is by your playing strength.
Turn the Touch function on or off as desired by pressing the [TOUCH] but-
ton.
Touch Sensitivity lets you set how the DGX-500/300 responds to your playing
strength, allowing you to customize this expressive function to suit your own
playing style.
1Select the Touch Sensitivity control.
Press and hold the [TOUCH] button until the Touch Sensitivity setting and
name appears in the display.
2Change the value.
Use the numeric keypad or [+]/[-] buttons to set the desired setting: 1, 2, or 3
(explained below).
● Settings:
When Touch is turned off, a constant volume (corresponding to a velocity
value of 80) is produced.
1 (Soft) This results in limited touch response, and produces a relatively narrow
dynamic range, no matter how lightly or strongly you play the keys.
2 (Medium) This lets you play over a normal dynamic range (soft to loud).
3 (Hard) This is designed for playing very soft passages, giving you slightly more
detailed control in the soft volume range.
Indicates Touch
function is on
TUNING
000
001
Current Touch Sensitivity setting
Medium
2
001
Restoring the Default Touch
Sensitivity Value
The default Touch Sensitivity is 2
(Medium). To restore the default
value, press both [+]/[-] buttons
simultaneously (when Touch Sensi
-
tivity is selected).
33
Effects
The DGX-500/300 is equipped with a wide variety of effects that can be used to enhance the
sound of the voices. The DGX-500/300 has three separate effect systems — Reverb, DSP, and
Harmony — and each has many different effect types to choose from.
Reverb
The Reverb effect reproduces the natural ambient “wash” of sound that occurs
when a instrument is played in a room or concert hall. A total of eight different
Reverb types simulating various different performance environments are avail-
able.
1Select the Reverb function.
2Set the Reverb Type, if desired.
Use the numeric keypad or [+]/[-] buttons to set the desired Reverb Type.
(For a list of the available Reverb Types, see page 36.) To turn the Reverb
effect off, select Reverb Type #9.
Current Reverb Type name and number.
Indicates Reverb is selected
Hall1
1
001
• Twelve additional Reverb Types
are available when controlling the
DGX-500/300 from a MIDI
device. (For details, See page
104.)
• Each style of the DGX-500/300
has its own independent Reverb
setting.
• You can also determine the
Reverb level. (See page 26.)
Restoring the Default Reverb
Type
If you’ve changed the Reverb Type,
you can instantly restore the
default setting by pressing both [+]
/
[-] buttons simultaneously (when
Reverb is selected).
Effects
34
DSP
The DSP effect section provides distortion and chorus effects, plus a wealth of
other useful and dynamic effects for enhancing and changing the sound of the
voices. Included among these miscellaneous effects are reverse gate reverb,
phaser, rotary speaker, tremolo, echo, delay, distortion, equalization, and wah. A
total of thirty-eight DSP types are available.
1Select the DSP function.
Press the right Overall button, repeatedly if necessary, until the dark bar indi-
cation appears next to DSP.
2Set the DSP Type, if desired.
Use the numeric keypad or [+]/[-] buttons to set the desired DSP Type. (For
a list of the available DSP Types, see page 36.) To turn the DSP effect off,
select DSP Type #39.
Current DSP Type name and number.
Indicates DSP is selected
Stage2
06
001
• Each voice of the DGX-500/300
has its own independent DSP
setting.
• Fifty-one additional DSP Types
are available when controlling the
DGX-500/300 from a MIDI
device. (For details, see page
104.)
• You can also determine the DSP
level. (See Page 26.)
Restoring the Default DSP Type
If you’ve changed the DSP Type,
you can instantly restore the
default setting by pressing both [+]
/
[-] buttons simultaneously (when
DSP is selected).
Effects
35
Harmony
The Harmony section features a variety of performance effects that enhance the
melodies you play when using the accompaniment styles of the DGX-500/300. A
total of twenty-six Harmony types are available.
Trill, Tremolo and Echo types can be used even if accompaniment is off.
There are five different Harmony Types that automatically create harmony parts
(for notes played in the upper section of the keyboard) to match the accompani-
ment chords.
1Turn on the Harmony effect.
Press the [HARMONY] button.
2Select the Harmony function.
Press the right Overall button, repeatedly if necessary, until the dark bar indi-
cation appears next to HARMONY.
3Set the Harmony Type, if desired.
Use the numeric keypad or [+]/[-] buttons to set the desired Harmony Type.
(For a list of the available Harmony Types, see page 37.)
Indicates that Harmony is on Indicates Harmony is selected
Current Harmony Type name and number.
Block
03
001
• For the first five Harmony Types
(Duet, Trio, Block, Country, and
Octave), chords must be played
in the Accompaniment area of
the keyboard.
• The speed of the Trill, Tremolo,
and Echo effects depends on the
Tempo setting (page 37).
• Each voice of the DGX-500/300
has its own independent Har-
mony setting.
Restoring the Default Harmony
Type
If you’ve changed the Harmony
Type, you can instantly restore the
default setting by pressing both [+]
/
[-] buttons simultaneously (when
Harmony is selected).
Effects
36
■ Effect Types
● Reverb Types
● DSP Types
No. Reverb Type Display Name Description
1 Hall 1 Hall1 Concert hall reverb.
2 Hall 2 Hall1
3 Room 1 Room1 Small room reverb.
4 Room 2 Room2
5 Stage 1 Stage1 Reverb for solo instruments.
6 Stage 2 Stage2
7 Plate 1 Plate1 Simulated steel plate reverb.
8 Plate 2 Plate2
9 Off Off No effect.
No. DSP Type Display Name Description
1 Hall 1 Hall1 Concert hall reverb.
2 Hall 2 Hall2
3 Room 1 Room1 Small room reverb.
4 Room 2 Room2
5 Stage 1 Stage1 Reverb for solo instruments.
6 Stage 2 Stage2
7 Plate 1 Plate1 Simulated steel plate reverb.
8 Plate 2 Plate2
9 Early Reflection 1 ER1 Early reflections only.
10 Early Reflection 2 ER2
11 Gate Reverb Gate1 Gated reverb effect, in which the reverberation is quickly cut off for special ef-
fects.
12 Reverse Gate Gate2 Similar to Gate Reverb, but with a reverse increase in reverb.
13 Chorus 1 Chorus1 Conventional chorus effect with rich, warm chorusing.
14 Chorus 2 Chorus2
15 Flanger 1 Flanger1 Pronounced three-phase modulation with slight metallic sound.
16 Flanger 2 Flanger2
17 Symphonic Symphony Exceptionally rich & deep chorusing.
18 Phaser Phaser Pronounced, metallic modulation with periodic phase change.
19 Rotary Speaker 1 Rotary1 Rotary speaker simulation.
20 Rotary Speaker 2 Rotary2
21 Tremolo 1 Tremolo1 Rich Tremolo effect with both volume and pitch modulation.
22 Tremolo 2 Tremolo2
23 Guitar Tremolo Guitar Tremolo Simulated electric guitar tremolo.
24 Auto Pan AutoPan Several panning effects that automatically shift the sound position (left, right,
front, back).
25 Auto Wah AutoWah Repeating filter sweep “wah” effect.
26 Delay Left - Center -
Right
DelayLCR Three independent delays, for the left, right and center stereo positions.
27 Delay Left - Right DelayLR Initial delay for each stereo channel, and two separate feedback delays.
28 Echo Echo Stereo delay, with independent feedback level settings for each channel.
29 Cross Delay CrossDly Complex effect that sends the delayed repeats “bouncing” between the left
and right channels.
30 Karaoke Karaoke Deep, pronounced echo effect.
31 Distortion Hard D Hard Hard-edged, warm distortion.
32 Distortion Soft D Soft Soft, warm distortion.
33 Overdrive Overdrv Natural distortion, like that of an overdriven amplifier.
34 Amp Simulation AmpSimu Characteristic sound of a guitar amplifier/speaker.
35 EQ Disco EQ Disco Equalizer effect that boosts both high and low frequencies, as is typical in
most disco music.
36 EQ Telephone EQ Tel Equalizer effect that cuts both high and low frequencies, to simulate the sound
heard through a telephone receiver.
37 3Band EQ 3BandEQ Equalizer with three separate frequency bands.
38 2Band EQ 2BandEQ Equalizer with two separate frequency bands.
39 No Effect Off No effect
Effects
37
● Harmony Types
No. Harmony Type Display Name Description
1 Duet Duet Harmony types 1 - 5 are pitch-based and add one-, two- or three-
note harmonies to the single-note melody played in the right hand.
These types only sound when chords are played in the auto accom-
paniment area of the keyboard.
2 Trio Trio
3 Block Block
4 Country Country
5 Octave Octave
6 Trill 1/4 note Tril1/4 Types 6 - 26 are rhythm-based effects and add embellishments or
delayed repeats in time with the auto accompaniment. These types
sound whether the auto accompaniment is on or not; however, the
actual speed of the effect depends on the Tempo setting (page 44).
The individual note values in each type let you synchronize the ef-
fect precisely to the rhythm. Triplet settings are also available: 1/6
= quarter-note triplets, 1/12 = eighth-note triplets, 1/24 = sixteenth-
note triplets.
• The Trill effect Types (6 - 12) create two-note trills (alternating
notes) when two notes are held.
• The Tremolo effect Types (13 - 19) repeat all held notes (up to
four).
• The Echo effect Types (20 - 26) create delayed repeats of each
note played.
7 Trill 1/6 note Tril1/6
8 Trill 1/8 note Tril1/8
9 Trill 1/12 note Tril1/12
10 Trill 1/16 note Tril1/16
11 Trill 1/24 note Tril1/24
12 Trill 1/32 note Tril1/32
13 Tremolo 1/4 note Trem1/4
14 Tremolo 1/6 note Trem1/6
15 Tremolo 1/8 note Trem1/8
16 Tremolo 1/12 note Trem1/12
17 Tremolo 1/16 note Trem1/16
18 Tremolo 1/24 note Trem1/24
19 Tremolo 1/32 note Trem1/32
20 Echo 1/4 note Echo1/4
21 Echo 1/6 note Echo1/6
22 Echo 1/8 note Echo1/8
23 Echo 1/12 note Echo1/12
24 Echo 1/16 note Echo1/16
25 Echo 1/24 note Echo1/24
26 Echo 1/32 note Echo1/32
3
3
3
3
3
3
3
3
3
38
Selecting and Playing Styles
The DGX-500/300 provides dynamic rhythm/accompaniment patterns (styles) — as well as
voice settings appropriate for each style — for various popular musical categories.
A total of 135 different styles are available, in several different categories. Each style is made up of separate
“sections” — Intro, Main A and B, and Ending — letting you call up different accompaniment sections as you
perform.
The style features that are built into the rhythms add the excitement of instrumental backing to your perfor-
mance, letting you control the accompaniment by the chords you play. Auto accompaniment effectively splits
the keyboard into two areas: The upper is used for playing a melody line, and the lower (set by default to keys
F#2 and lower) is for the auto accompaniment function.
The DGX-500/300 also features the convenient Dictionary function (page 50). Dictionary provides you with a
built-in “chord encyclopedia” that teaches you how to play any chord you specify by showing you the appropri-
ate notes in the display.
The DGX-500/300 can also be used with the included disk or commercially available Style File data, allowing
you to load additional styles (auto accompaniment patterns) to the instrument. Style File data is loaded individ-
ually as style number 136, and can be played just like the preset styles.
Selecting a Style
1Press the [STYLE] button.
2Select the desired style number.
Use the numeric keypad. The basic categories of styles and their numbers
are shown at the left of the panel. A complete list of the available styles is
given on page 98.
Style numbers can be selected in the same way as with the voices (see page
25). You can use the numeric keypad to directly enter the style number, or
use the [+]/[-] buttons to step up and down through the styles.
Indicates Style mode
is selected
Style name and number
8BtModrn
001
001
Selecting and Playing Styles
39
Playing the styles
The panel buttons below function as style controls.
1Turn on the auto accompaniment.
Press the [ACMP] button to turn on (enable) the auto accompaniment.
2Start the style.
You can do this in one of the following ways:
■ Pressing the [START/STOP] button
The rhythm starts playing immediately without bass and chord accompani-
ment. The currently selected Main A or B section will play.
Pressing this button alternately
enables and cancels the Sync
Stop function. (See page 43.)
Pressing this button switches
between the Main A and Main B
sections, automatically adding a
fill-in pattern before changing the
section. (See page 45.)
Pressing this button alternately
enables and cancels the bass
and chord accompaniment.
(See below.)
Pressing this button alter-
nately starts and stops
style playback.
Pressing this button alternately
enables and cancels the Sync Start
function. (See page 40.)
This controls the Intro
and Ending sections.
(See pages 41, 42.)
Indicates that auto accompaniment is on.
Selecting and Playing Styles
40
You can select the Main A or B section by pressing the appropriate button —
[MAIN A/B] — before pressing the [START/STOP] button. (The display
briefly shows the letter of the selected section: “MAIN A” or “MAIN B.”)
■ Using Tap Tempo to Start
This useful feature lets you tap out the speed (tempo) of the style and auto-
matically start the style at that tapped speed.
Simply tap the [TEMPO/TAP] button four times (or three times for a 3/4
time style), and the style starts automatically at the tempo you tapped. You
can also change the tempo while the style is playing by tapping the
[TEMPO/TAP] button twice at the desired tempo.
■ Using Sync Start
The DGX-500/300 also has a Sync Start function that allows you to start the
style by simply pressing a key on the keyboard. To use Sync Start, first press
the [SYNC START] button (the beat marks all flash to indicate Sync Start
stand-by), then press any key on the keyboard. (When auto accompaniment
is on, play a key or chord in the auto accompaniment area of the keyboard.)
Indicates selected section (Main A or B).
MAIN A
Auto accompaniment area
Selecting and Playing Styles
41
Starting with an Intro section
Each style has its own two- or four-measure Intro section. When used with the auto accompaniment, many of the
Intro sections also include special chord changes and embellishments to enhance your performance.
To start with an Intro section:
1) Press the [MAIN/AUTO FILL] button — to select which section (A or B) is to follow the Intro.
2) Press the [INTRO ENDING] button.
To actually start the Intro section, press the [START/STOP] button.
Using Sync Start with an Intro section
You can also use the Sync Start function with the special Intro section of the selected style.
To use Sync Start with an Intro section:
1) Press the [MAIN/AUTO FILL] button — to select which section (A or B) is to follow the Intro.
2) Press the [INTRO ENDING] button.
3) Press the [SYNC START] button to enable Sync Start, and start the Intro section by playing any key on the
keyboard. (When auto accompaniment is on, play a key or chord in the auto accompaniment area of the key-
board.)
Indicates selected section (Main A or B).
MAIN A
Indicates Intro standby.
INTRO≥A
Indicates selected section (MAIN A or B).
MAIN A
Indicates Intro standby.
INTRO≥A
Auto accompaniment area
Selecting and Playing Styles
42
3Change chords using the auto accompaniment feature.
Try playing a few successive chords with your left hand, and notice how the
bass and chord accompaniment change with each chord you play. (Refer to
page 47 for more information on how to use auto accompaniment.)
4Stop the style.
You can do this in one of three ways:
■ Pressing the [START/STOP] button
The style stops playing immediately.
■ Using an Ending section
Press the [INTRO ENDING] button. The style stops after the Ending section
is finished.
■ Pressing the [SYNC START] button
This immediately stops style and automatically enables Sync Start, letting
you re-start the style by simply playing a chord or key in the auto accompa-
niment area of the keyboard.
• The [ACMP] button can also be
used to turn off and on the bass/
chord accompaniment while play
-
ing — allowing you to create
dynamic rhythmic breaks in your
performance.
• You can use the Sync Stop func-
tion to create a similar, yet even
more dramatic break. With Sync
Stop on (page 43), you can con-
trol breaks in the rhythm and
accompaniment simply by releas
-
ing your fingers from the keys.
As long as you play and hold a
chord, the accompaniment con-
tinues. When you release it, the
accompaniment stops. You can
also use this feature to create
exciting rhythmic stutter effects,
chord hits, and accents by play-
ing staccato chords.
• Chords played in the auto accom
-
paniment area of the keyboard
are also detected and played
when the style is stopped. In
effect, this gives you a “split key-
board,” with bass and chords in
the left hand and the normally
selected voice in the right.
• To have the Ending section grad-
ually slow down (ritardando) as it
is playing, press the [INTRO
ENDING] button twice quickly.
Selecting and Playing Styles
43
Sync Stop
This convenient feature lets you stop (or pause) the style by releasing your fingers
from the auto accompaniment area of the keyboard. Playing the chord again
restarts the style. This is ideal for putting dynamic breaks in your performance —
for example, stopping the rhythm and accompaniment briefly while you play a
melodic break or solo with your right hand.
1Press the [ACMP] button.
To turn accompaniment on.
2Press the [SYNC STOP] button.
Setting Sync Stop to on before starting the style automatically sets Sync
Start to on as well, letting you immediately start the style by playing the key-
board.
3Play a chord on the keyboard (in the auto accompaniment
area of the keyboard).
The style starts as soon as you play a chord.
4Stop the style by releasing the chord.
5To start the style again, play a chord.
To turn Sync Stop off, press the [SYNC STOP] button again. To stop the
style completely, press the [START/STOP] button.
Indicates that auto accompaniment is on.
Indicates that Sync Stop is on.
Auto accompaniment area
Selecting and Playing Styles
44
Changing the Tempo
The tempo of style playback can be adjusted over a range of 32 - 280 bpm (beats
per minute).
1Call up the Tempo setting.
Press the [TEMPO/TAP] button.
2Change the value.
Use the numeric keypad to set the desired Tempo value, or use the [+]/[-]
buttons to increase or decrease the value.
• When style playback is stopped
and a different style is selected,
the tempo returns to the default
setting of the new style. When
switching styles during playback,
the last tempo setting is main-
tained. (This allows you to keep
the same tempo, even when
changing styles.)
Current Tempo value
TEMPO
120
001
Restoring the Default Tempo
Value
Each song and style has been
given a default or standard Tempo
setting. If you’ve changed the
Tempo, you can instantly restore
the default setting by pressing both
[+]/[-] buttons simultaneously
(when Tempo is selected).
• You can also use the convenient
Tap Tempo function to change
the tempo by “tapping” a new one
in real time. (See page 40.)
Selecting and Playing Styles
45
MAIN/AUTO FILL (Main A/B and Fill-ins)
While the style is playing, you can add variation in the rhythm/accompaniment by
pressing the [MAIN/AUTO FILL] button. This switches between the Main A and
Main B sections, automatically playing a fill-in pattern to smoothly lead into the
next section. For example, if the Main A section is currently playing, pressing this
button automatically plays a fill-in pattern, followed by the Main B section. (See
below.)
You can also select either the Main A or B section to start by pressing the [MAIN/
AUTO FILL] button before starting the style.
• Rhythm sounds and fill-in sec-
tions are not available when one
of the Pianist styles (#124 - #135)
are selected.
This appears while the fill-in pattern is playing.
Fill A≥B
1234123412341233
About the Fill-in Patterns
If you press the
[MAIN/AUTO FILL]
button before beat 4...
...a fill-in pattern
plays immediately
until the end of the
measure...
...and the Main A
or B section
begins here.
If you press the
[MAIN/AUTO FILL] button
here, after beat 4...
...a fill-in pattern
plays from here...
...and the Main
A or B section
begins here.
1st measure 2nd measure 3rd measure
beat
Selecting and Playing Styles
46
Adjusting the Accompaniment Volume
The playback volume of the style can be adjusted. This volume control affects
only the accompaniment volume. The volume range is 000 - 127.
1Select the Accompaniment Volume function.
Press the left Overall button, repeatedly if necessary, until “ACMP VOL”
appears in the display.
2Change the value.
Use the numeric keypad to set the desired Accompaniment Volume value
(000 - 127). You can also use the [+]/[-] buttons to increase or decrease the
value. Holding down either button continuously increases or decreases the
value.
Indicates Accompaniment Volume is selected
Current Accompaniment Volume value
ACMP VOL
100
001
• Accompaniment Volume cannot
be changed unless the Style
mode is active.
Restoring the Default Accom-
paniment Volume Value
If you’ve changed the Accompani-
ment Volume setting, you can
instantly restore the default setting
of “100” by pressing both [+]/[-] but
-
tons simultaneously (when Accom-
paniment Volume is selected).
Selecting and Playing Styles
47
Using Auto Accompaniment — Multi Fingering
When it is set to on (page 39), the auto accompaniment function automatically
generates bass and chord accompaniment for you to play along with, by using
Multi Fingering operation. You can change the chords of the accompaniment by
playing keys in the auto accompaniment area of the keyboard using either the
“Single Finger” or “Fingered” method. With Single Finger you can simply play a
one-, two- or three-finger chord indication (see Single Finger Chords below). The
Fingered technique is that of conventionally playing all the notes of the chord.
Whichever method you use, the DGX-500/300 “understands” what chord you
indicate and then automatically generates the accompaniment.
■ Single Finger Chords • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
Chords that can be produced in Single Finger operation are major, minor, seventh
and minor seventh. The illustration shows how to produce the four chord types.
(The key of C is used here as an example; other keys follow the same rules. For
example, Bb7 is played as Bb and A.)
■ Fingered Chords • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
Using the key of C as an example, the chart below shows the types of chords that
can be recognized in the Fingered mode.
CCm C7Cm7
To play a major chord:
Press the root note of
the chord.
To play a minor chord:
Press the root note
together with the nearest
black key to the left of it.
To play a seventh chord:
Press the root note
together with the nearest
white key to the left of it.
To play a minor seventh
chord: Press the root note
together with the nearest
white and black keys to
the left of it (three keys
altogether).
● Example for “C” chords
* Notes enclosed in parentheses are optional; the chords will be recognized without them.
C
Cm
7
C
( )
CM
( )
7
C(9) C
( )
(9)
6
Caug Cm6Cm7
( )
Cm b5
7CmM b5
7
Cm
( )
(9)
7
Cm(9)
CmM7
( )
CmM (9)
7
( )
Cdim Cdim7
C(9)
7
( )
C(13)
7
( )
C(b9)
7
( )
C(b13)
7
Csus4
C1+2+5
C b5
7
C6
( )
( )
CM7(9) 7
CM (#11)
( )
7
CM b5
C(b5)
( )
C(#11)
7C(#9)
7
( )
C aug
7
Cm7(11)
( )
( )
CM aug
7
( )
C sus4
7
( )
Selecting and Playing Styles
48
Chord Name/[Abbreviation] Normal Voicing Chord (C) Display
Major [M] 1 - 3 - 5 C C
Add ninth [(9)] 1 - 2 - 3 - 5 C(9) C(9)
Sixth [6] 1 - (3) - 5 - 6 C6 C6
Sixth ninth [6(9)] 1 - 2 - 3 - (5) - 6 C6(9) C6(9)
Major seventh [M7] 1 - 3 - (5) - 7 or
1 - (3) - 5 - 7
CM7 CM7
Major seventh ninth [M7(9)] 1 - 2 - 3 - (5) - 7 CM7(9) CM7(9)
Major seventh add sharp eleventh [M7(#11)] 1 - (2) - 3 - #4 - 5 - 7 or
1 - 2 - 3 - #4 - (5) - 7
CM7(#11) CM7(#11)
Flatted fifth [(b5)] 1 - 3 - b5C(b5) Cb5
Major seventh flatted fifth [M7b5] 1 - 3 - b5 - 7 CM7b5 CM7b5
Suspended fourth [sus4] 1 - 4 - 5 Csus4 Csus4
Augmented [aug] 1 - 3 - #5 Caug Caug
Major seventh augmented [M7aug] 1 - (3) - #5 - 7 CM7aug CM7aug
Minor [m] 1 - b3 - 5 Cm Cm
Minor add ninth [m(9)] 1 - 2 - b3 - 5 Cm(9) Cm(9)
Minor sixth [m6] 1 - b3 - 5 - 6 Cm6 Cm6
Minor seventh [m7] 1 - b3 - (5) - b7 Cm7 Cm7
Minor seventh ninth [m7(9)] 1 - 2 - b3 - (5) - b7 Cm7(9) Cm7(9)
Minor seventh add eleventh [m7(11)] 1 - (2) - b3 - 4 - 5 - (b7) Cm7(11) Cm7(11)
Minor major seventh [mM7] 1 - b3 - (5) - 7 CmM7 CmM7
Minor major seventh ninth [mM7(9)] 1 - 2 - b3 - (5) - 7 CmM7(9) CmM7(9)
Minor seventh flatted fifth [m7b5] 1 - b3 - b5 - b7 Cm7b5 Cm7b5
Minor major seventh flatted fifth [mM7b5] 1 - b3 - b5 - 7 CmM7b5 CmM7b5
Diminished [dim] 1 - b3 - b5 Cdim Cdim
Diminished seventh [dim7] 1 - b3 - b5 - 6 Cdim7 Cdim7
Seventh [7] 1 - 3 - (5) - b7 or
1 - (3) - 5 - b7
C7 C7
Seventh flatted ninth [7(b9)] 1 - b2 - 3 - (5) - b7 C7(b9) C7(b9)
Seventh add flatted thirteenth [7(b13)] 1 - 3 - 5 - b6 - b7 C7(b13) C7(b13)
Seventh ninth [7(9)] 1 - 2 - 3 - (5) - b7 C7(9) C7(9)
Seventh add sharp eleventh [7(#11)] 1 - (2) - 3 - #4 - 5 - b7 or
1 - 2 - 3 - #4 - (5) - b7
C7(#11) C7(#11)
Seventh add thirteenth [7(13)] 1 - 3 - (5) - 6 - b7 C7(13) C7(13)
Seventh sharp ninth [7(#9)] 1 - #2 - 3 - (5) - b7 C7(#9) C7(#9)
Seventh flatted fifth [7b5] 1 - 3 - b5 - b7C7b5C7b5
Seventh augmented [7aug] 1 - 3 - #5 - b7 C7aug C7aug
Seventh suspended fourth [7sus4] 1 - 4 - (5) - b7 C7sus4 C7sus4
One plus two plus five [1+2+5] 1 - 2 - 5 C1+2+5 C
• Notes in parentheses can be
omitted.
• Playing two same root keys in the
adjacent octaves produces
accompaniment based only on
the root.
• A perfect fifth (1 + 5) produces
accompaniment based only on
the root and fifth which can be
used with both major and minor
chords.
• The chord fingerings listed are all
in “root” position, but other inver-
sions can be used — with the fol-
lowing exceptions:
m7, m7
b
5, 6, m6, sus4, aug,
dim7, 7
b
5, 6(9), 1+2+5.
• Inversion of the 7sus4 and
m7(11) chords are not recog-
nized if the notes shown in
parentheses are omitted.
• The auto accompaniment will
sometimes not change when
related chords are played in
sequence (e.g. some minor
chords followed by the minor sev
-
enth).
• Two-note fingerings will produce
a chord based on the previously
played chord.
Selecting and Playing Styles
49
Setting the Split Point
The Split Point determines the highest key for the auto accompaniment area. The
accompaniment can be played with the keys up to and including the Accompani-
ment Split Point key.
1Select the Split Point control.
Press and hold the [SPLIT] button until “S_POINT”appears in the display.
2Change the value.
Use the numeric keypad or [+]/[-] buttons to set the desired value: 0 (C-2) -
127 (G8).
To leave the Split Point function, simply go on to another operation or function.
• This setting also affects the split
point for the special Split voices.
Split Point
Auto accompaniment area
Current Split Point value
Indicates current Split Point.
S–POINT
054
001
Restoring the Default Split
Point Value
If you’ve changed the Split Point
setting, you can instantly restore
the default setting of “54” (F
#
2) by
pressing both [+]/[-] buttons simul-
taneously (when Split Point is
selected).
Selecting and Playing Styles
50
Dictionary
The Dictionary function is essentially a built-in “chord book” that shows you the
individual notes of chords. It is ideal when you know the name of a certain chord
and want to quickly learn how to play it.
1Press the [DICTIONARY] button.
2Specify the root of the chord.
Press the key on the keyboard that corresponds to the desired chord root (as
printed on the panel).
3Specify the type of the chord (major, minor, seventh, etc.).
Press the key on the keyboard that corresponds to the desired chord type (as
printed on the panel).
• Pressing the [DICTIONARY] but-
ton automatically turns on the
auto accompaniment.
Dict.
001
Dict.
001
Pressing this key selects the root G.
Individual notes of chord (keyboard)
Pressing this key selects the
major seventh chord type (M7).
Notation of chord
Chord name (root and type)
Dict.
001
• For a few specific chords, not all
notes may be shown in the nota-
tion section of the display. This is
due to space limitations in the
display.
• You can also show the inversion
of chord when using [+]/[-] button.
Selecting and Playing Styles
51
4Play the chord.
Play the chord (as indicated in the display) in the auto accompaniment area
of the keyboard. The chord name flashes in the display (and a “congratula-
tions” melody is played) when the correct notes are held down. (Inversions
for many of the chords are also recognized.)
To leave the Dictionary function, press the [DICTIONARY] button again.
Dict.
001 Indicates notes to be played.
Flashes when correct notes
are held.
Auto accompaniment area
• • • • • • • • • • • • • • • • • • • • • • • • What is a Chord? • • • • • • • • • • • • • • • • • • • • • • • •
The simple answer: Three or more notes played simultaneously is a chord. (Two notes played
together is an “interval” — an interval being the distance between two different notes. This is also
referred to as a “harmony.”) Depending on the intervals between the three or more notes, a chord
can sound beautiful or muddy and dissonant.
The organization of notes in the example at left — a triad chord — pro-
duces a pleasant, harmonious sound. Triads are made up of three notes
and are the most basic and common chords in most music.
In this triad, the lowest note is the “root.” The root is the most important note in the chord, because
it anchors the sound harmonically by determining its “key” and forms the basis for how we hear the
other notes of the chord.
The second note of this chord is four semitones higher than the first, and the third is three semitones
higher than the second. Keeping our root note fixed and changing these notes by a semitone up or
down (sharp or flat), we can create four different chords.
Keep in mind that we can also change the “voicing” of a chord — for example, change the order of
the notes (called “inversions”), or play the same notes in different octaves — without changing the
basic nature of the chord itself.
Major chord
(ex. C)
Minor chord
(ex. Cm)
Augmented chord
(ex. Caug)
Diminished chord
(ex. Cdim)
Minor 3rd Major 3rd Major 3rd Minor 3rd Major 3rd Major 3rd Minor 3rd Minor 3rd
Inversion examples for the key of C
G
E
C
C
G
E
E
C
G
Selecting and Playing Styles
52
Beautiful sounding harmonies can be built in this manner. The use of intervals and chords is one of
the most important elements in music. A wide variety of emotions and feelings can be created
depending on the types of chords used and the order in which they are arranged.
• • • • • • • • • • • • • • • • • • • • • •Writing Chord Names • • • • • • • • • • • • • • • • • • • • • •
Knowing how to read and write chord names is an easy yet invaluable skill. Chords are often writ-
ten in a kind of shorthand that makes them instantly recognizable (and gives you the freedom to
play them with the voicing or inversion that you prefer). Once you understand the basic principles
of harmony and chords, it’s very simple to use this shorthand to write out the chords of a song.
First, write the root note of the chord in an uppercase letter. If you need to specify sharp or flat,
indicate that to the right of the root. The chord type should be indicated to the right as well. Exam-
ples for the key of C are shown below.
One important point: Chords are made up of notes “stacked” on top of each other, and the stacked
notes are indicated in the chord name of the chord type as a number — the number being the dis-
tance of the note from the root. (See the keyboard diagram below.) For example, the minor 6th
chord includes the 6th note of the scale, the major 7th chord has the 7th note of the scale, etc.
The Intervals of the Scale
To better understand the intervals and the numbers
used to represent them in the chord name, study this
diagram of the C major scale:
Other Chords
Major chord
C
Minor chord
Cm
Augmented chord
Caug
Diminished chord
Cdim
For simple major chords, the type is omitted.
CDEFGABCDE F
Root
2nd
4th
3rd
5th
7th
6th
Octave
11th
9th
Dominant 7th (flatted 7th)
Csus4
5th 4th
C7
Dominant
7th
Major chord
Cm7
Dominant
7th
Minor chord
CM7
7th Major chord
Cm7bb
bb5
Dominant
7th
Diminished
chord
Cm6
Minor
chord
6th
C(9)
9th
* Bbb = A
Cdim7
Diminished 7th
(double flatted 7th)
Diminished
chord
53
Using the Music Database
If you want to play in a certain genre of music but don’t know which style and voice settings
would be appropriate, simply select the desired genre from the Music Database. The DGX-500/
300 automatically makes all appropriate panel settings to let you play in that music style!
1Press the [M.D.B.] (MUSIC DATABASE) button.
The MUSIC DATABASE menu appears in the display.
2Select a ‘‘Music Database.’’
Use the numeric keypad to set the desired Music Database, or use the [+]/[-]
buttons to increase or decrease the value.
The DGX-500/300 has 208 panel setups in the Music Database and they are
divided into 12 different categories.
In this example, we’ll select #208 “Xmas Walz” and play the song “Silent
Night.” (The sheet music is provided on the next page.)
3Play the chords with your left hand and the melody lines
with your right hand along with the music.
As soon as you play a chord with your left hand, the style starts.
For information on how to enter chords, see ‘‘Multi Fingering’’ on page 47.
• Press the [M.D.B.] (MUSIC DATA
-
BASE) button to switch into the
Style mode, turn AUTO ACCOM-
PANIMENT on, and turn SYN-
CHRONIZED START on. See
page 40 for details.
AlvFevr
001
001
Croco RK
002
001
XmasWalz
208
• See pages 38 through 49 for
details about the Auto Accompa-
niment.
Using the Music Database
54
4When you reach the point in the music indicated by the
arrow above, press the [ENDING] button.
The style plays an ending phrase in ritardando.
When the ending is finished, the style automatically stops.
You can also stop the style by using the [STOP] button.
Data stored by the Music Database
Each of the Music Database settings has been specially programmed to match the selected style and each
features the best suited voice (or combination of voices), style and other settings. Pressing the [M.D.B.]
(MUSIC DATABASE) button and selecting a number lets you instantly reconfigure all relevant settings,
conveniently allowing you to start playing in the desired genre with all the appropriate sounds — without
having to make each setting one by one. For each parameter, refer to the following pages.
■VOICE PARAMETERS
MAIN Voice, Volume, Reverb Depth, DSP Depth............................................................. page 26
Dual On/Off, Voice, Octave, Volume, Reverb Depth, DSP Depth .................................... page 26
• Reverb Type ................................................................................................................... page 33
• DSP Type ....................................................................................................................... page 34
• Harmony On/Off............................................................................................................. page 35
• Harmony Type................................................................................................................ page 37
• Transpose ...................................................................................................................... page 29
• Pitch Bend Range.......................................................................................................... page 31
■STYLE PARAMETERS
• Synchro Start=ON* ........................................................................................................ page 40
• Style Number ................................................................................................................. page 38
• Accompaniment Split Point ............................................................................................ page 49
• Main A/Main B ............................................................................................................... page 45
• Tempo ............................................................................................................................ page 44
• Accompaniment Volume ................................................................................................ page 46
* Set only when the accompaniment is not playing.
82
Auto Accompaniment
area
55
Registration Memory
Registration Memory is a flexible and convenient function that lets you instantly reconfigure
virtually all settings of the DGX-500/300 with the touch of a single button. Simply save your
favorite custom panel settings to one of the Registration Memory presets (up to sixteen are
available) for future recall.
Registration Memory Presets
The DGX-500/300 has eight Registration Memory banks, each with two different
presets (a total of sixteen) for your custom panel settings. Each of the sixteen
Registration Memory can have different settings for the following parameters:
• Voice number
• Tempo
• Transpose
• Reverb Type
• DSP Type
• Harmony On/Off setting and Type
• Split Point
• Style number, and style-related settings: Accompaniment On/Off and Split Point
• Pitch Bend Range
Recording a Registration Memory Preset
1Make all desired settings for the DGX-500/300.
Virtually all of the DGX-500/300’s settings can be saved to a Registration
Memory button.
2Select the desired bank.
Press the [BANK] button, then press the desired bank number (1 - 8).
3Record the settings to the desired preset, 1 or 2.
While holding down the [MEMORY] button, press the appropriate REGIS-
TRATION MEMORY button, [1] or [2].
Selected bank number
BANK
1
001
Selected memory number
MEMORY1
1
001
Registration Memory
56
Recalling a Registration Memory Preset
1Select the appropriate Registration Memory bank.
2Press the desired Registration Memory preset button ([1] or [2]).
BANK
1
001
REGIST1
1
001
57
Selecting and Playing Songs
The DGX-500/300 features a total of 105 songs. These include 100 songs that showcase the
rich and dynamic sounds of the instrument, and 100 of these songs can be used with the edu-
cational Lesson feature (page 67), a powerful tool that makes learning songs fun and easy.
Three of the songs are special Demonstration songs that can be played automatically by
pressing the [DEMO] button. Moreover, there are five special User songs to which you can
record your own performance.
The User songs are “empty” and cannot be played until something has been recorded to them.
(For instructions on recording your own songs, see page 62.)
You can also play back songs from floppy disks; for details, see page 73.
Selecting and Playing a Song
1Press the [SONG] button.
2Select the desired song number.
Use the numeric keypad.
You can use the numeric keypad to directly enter the song number, or use the
[+]/[-] buttons to step up and down through the songs.
● Song Playback Display
These display the notes and name of
the current chord.
Current measure number
* The indication “F t” appears in the display when a song
having a “free” tempo is selected.
Certain songs have been composed or arranged in “free”
tempo, meaning that the tempo and/or the time signature
are not constant during the piece. As a result, when a
“free” tempo song plays back, the measure, beat and tim-
ing indications are not shown in the display.
Indicates the tracks currently playing back. (These can
be alternately muted and sounded during playback by
pressing the corresponding SONG MEMORY buttons.)
About the Beat Display
The arrow marks in the beat display flash in time
with the rhythm of the song or style. The first arrow
indicates the first beat of the measure, and the oth-
ers flash in sequence.
First beat of
measure
Second
beat
Third
beat
Fourth
beat
Babbino
068
012
Song name and number Indicates Song mode is selected
B Bailey
004
-01
Selecting and Playing Songs
58
3Start the selected song.
Press the [START/STOP] button. As the song plays back, the measure num-
ber and chords are shown in the display.
4Stop the song.
Press the [START/STOP] button. If playback was started by pressing the
[START/STOP] button, the selected song stops automatically.
A-B Repeat
The convenient A-B Repeat function is an ideal aid for practicing and learning. It
allows you to specify a phrase of a song (between point A and point B) and repeat
it — while you play or practice along with it.
1While playing a song, set point A (the start point).
During playback, press the [A-B REPEAT] button once, at the beginning
point to be repeated.
2Set point B (the end point).
As the song continues playing, press the [A-B REPEAT] button once again,
at the ending point to be repeated. The selected phrase repeats indefinitely
until stopped.
• You can play along with the song
using the currently selected
voice, or even select a different
voice for playing along. Simply
call up the Voice mode while the
song is playing back and select
the desired voice. (See page 24.)
REPEAT
A-
006
• The A and B points can only be
specified at the beginning of a
measure (beat 1), and not at any
point in the middle of a measure.
• To set the A point to the begin-
ning of a song, press the [A-B
REPEAT] button before starting
playback.
• If you’re repeat practicing a par-
ticularly difficult section, try slow-
ing down the Tempo to an
appropriate speed to make it eas
-
ier to play and master the part.
You may also want to slow down
the Tempo while setting the A
and B points; this makes it easier
to accurately set the points.
• You can also set the A-B Repeat
function when the song is
stopped. Simply use the
[ REW] and [FF ] buttons to
select the desired measures,
pressing the [A-B REPEAT] but-
ton for each point, then start play
-
back.
REPEAT
A-b
012
Selecting and Playing Songs
59
3Pause or stop playback as needed.
Use the [PAUSE] button or [START/STOP] button. Stopping playback does
not cancel the set A/B points or the A-B Repeat function.
4Turn off the A-B Repeat function.
Press the [A-B REPEAT] button.
Melody Voice Change
The DGX-500/300 lets you play a melody on the keyboard along with each of the
songs, either with the original melody voice or one of your own selection. The
convenient Melody Voice Change feature takes this one step further — it lets you
replace the original voice used for the melody of the song with the panel voice of
your own selection. For example, if the current voice selected on the panel is
piano but the song’s melody is being played by a flute voice, using Melody Voice
Change will change the flute melody voice to piano.
1Select the desired song.
Press the [SONG] button, then use the numeric keypad or [+]/[-] buttons to
select the desired song.
2Select the desired voice.
Press the [VOICE] button, then use the numeric keypad or [+]/[-] buttons to
select the desired voice.
B Bailey
004
-01
BritePno
003
-01
Selecting and Playing Songs
60
3Press and hold down the [VOICE] button for at least one
second.
“MELODY VOICE CHANGE” appears in the display, indicating that the
selected panel voice has replaced the song’s original melody voice.
Changing the Tempo
The tempo of song playback can be adjusted over a range of 32 - 280 bpm (beats
per minute).
1Call up the Tempo setting.
Press the [TEMPO/TAP] button.
2Change the value.
Use the numeric keypad to set the desired Tempo value, or use the [+]/[-]
buttons to increase or decrease the value.
Also, the tempo of a song returns to the default setting when selecting a dif-
ferent song.
MELODY V
-01
Current Tempo value
TEMPO
120
-01
Restoring the Default Tempo
Value
Each song has been given a
default or standard Tempo setting.
If you’ve changed the Tempo, you
can instantly restore the default
setting by pressing both [+]/[-] but-
tons simultaneously (when Tempo
is selected).
• You can also use the convenient
Tap Tempo function to change
the tempo by “tapping” a new one
in real time. (See page 40.)
Selecting and Playing Songs
61
Adjusting the Song Volume
The playback volume of the song can be adjusted. This volume control affects
only the song volume. The volume range is 000 - 127.
1Select the Song Volume function.
Press the left Overall button, repeatedly if necessary, until “SONG VOL”
appears in the display.
2Change the value.
Use the numeric keypad to set the desired Song Volume value (000 - 127).
You can also use the [+]/[-] buttons to increase or decrease the value. Hold-
ing down either button continuously increases or decreases the value.
Indicates Song Volume is selected
Current Song Volume value
SONG VOL
100
-01
• Song Volume cannot be changed
unless the Song mode is active.
(This function becomes Accom-
paniment Volume when the Style
mode is active.)
Restoring the Default Song Vol-
ume Value
If you’ve changed the Song Volume
setting, you can instantly restore
the default setting of “100” by
pressing both [+]/[-] buttons simul-
taneously (when Song Volume is
selected).
62
Song Recording
The DGX-500/300 features powerful and easy-to-use song recording features that let you
record your keyboard performances — using up to six independent tracks (including one track
for accompaniment) — for creating your own complete, fully orchestrated compositions. You
can record and save up to five User songs.
Song recording on the DGX-500/300 is similar to using a tape recorder; whatever
you play on the keyboard is recorded in real time as you play it. Also, when you
record subsequent parts to other tracks, you can hear the previously recorded parts
as you record new ones.
Recording a User Song
Data that can be recorded to the normal (melody) tracks:
• Note on/off
• Velocity
• Voice Number
• Reverb Type*
• Chorus Type*
• DSP Type*
• Sustain
• Pitch Bend data
• Tempo*, Time Signature* (if there is no such data in the Accompaniment track)
Data that can be recorded to the Accompaniment track:
• Style number*
• Chord changes and timing
• Changing sections (Intro, Main A/B, etc.)
• Reverb Type*
• DSP Type*
• Accompaniment Volume*
• Tempo, Time Signature*
1Make all desired DGX-500/300 settings.
Before you actually start recording, you’ll need to make various settings for
the song — such as selecting a style, setting the Tempo, and selecting a
voice. (See pages 38, 44, and 24.)
If desired, also make other settings. Refer to the list above for settings that
can be recorded to a song.
* These settings can only be recorded once at the beginning of a song; other
settings can be changed in the middle of a song.
User 1
rEC
001
Song Memory Capacity
• Maximum number of notes :
approximately 10,000 (when only
“melody” tracks are recorded)
• Maximum number of chords :
approximately 5,500 (when only
the accompaniment track is
recorded)
Using the Metronome
You can use the Metronome instead of a style if desired. This allows you to keep your performance “in time,” even
when recording without style. To do this, press the [METRONOME] button before recording in step #4 below. After
the song is completely recorded, simply play back the song with the Metronome turned off. (See page 22.)
Song Recording
63
2 Select a User song number for recording.
Use the numeric keypad to select the desired song: 201 - 205. If no song is
manually selected, the DGX-500/300 automatically selects the first available
empty song number.
3Select a track number for recording.
While holding down the [REC] button, press the appropriate SONG MEM-
ORY button.
■ Recording to the Accompaniment Track
A special Accompaniment track is provided for recording accompaniment
data. This is automatically recorded to the Accompaniment track (track A).
Selecting the Accompaniment track automatically turns on the accompani-
ment.
User 2
202
001
• User song numbers can be
selected in the same way as with
the voices (see page 25). You
can use the numeric keypad to
directly enter the song number,
use the [+]/[-] buttons to step up
and down through the songs.
User 2
rEC
001
• Keep in mind that all recording
operations “replace” the data.
In other words, if you record to
a track that already has
recorded data, all previous
data in the track will be erased
and replaced by the newly
recorded data.
● Muting Tracks During Playback
While recording is enabled, you can selectively mute different tracks. This is useful for when you want to clearly
hear certain tracks, and not others, during recording. Muting can also be done “on the fly” during playback. To use
muting, press the corresponding SONG MEMORY button, repeatedly if necessary, until the desired track number
in the display is off.
Each press of a SONG MEMORY button (when playback is stopped) cycles through the following settings:
Track number flashes — Track will record.*
* Cannot be selected during playback.
Track number off — Track is muted.
Track number on — Track will play back.
• If accompaniment has already
been turned on before entering
the Record mode, the Accompa-
niment track is automatically
selected.
Song Recording
64
■ Recording to a Melody Track (1 - 5)
Five independent Melody tracks are provided for recording your keyboard
performance. Normally, you’ll want to record these after you’ve recorded
the Accompaniment track. You can also record the Accompaniment track
and one of the Melody tracks simultaneously.
4Start recording.
When the beat marks and track number start flashing, you can start recording
simply by playing the keyboard (or by pressing the [START/STOP] button).
If you want to rehearse your part before recording, press the [SYNC START]
button to turn Sync Start off. After rehearsing, press [SYNC START] again
to return to the above condition.
■ When recording the Accompaniment track
With Sync Start on, play the first chord of the song in the auto accompani-
ment area of the keyboard. The accompaniment starts automatically and you
can continue recording, playing other chords in time with the accompani-
ment.
5Stop recording.
After you’ve finished playing the part, press the [START/STOP] or [REC]
button.
6Record to other tracks as desired.
To do this, simply repeat steps #3 - #5 above. Make sure that when you press
the SONG MEMORY button corresponding to the desired track, the track
number in the display flashes.
7Listen to your new recording.
To play back the song from the beginning, simply press the [START/STOP]
button again. Playback stops when the [START/STOP] button is pressed
again.
User 2
rEC
001
Indicates the current measure
Song Recording
65
Song Clear
The Song Clear operation completely erases all recorded data on all tracks of a
selected User song. Use this operation only when you’re sure you want to erase a
song and record a new one. To erase an individual track of a song while leaving
the other tracks intact, use the Track Clear operation (page 66).
1Select the desired song.
Press the [SONG] button, then use the numeric keypad or [+]/[-] buttons to
select the desired song (201 - 205).
2While holding down the [A] button, press SONG MEMORY
button [1].
All track indications in the display flash, indicating that all tracks are to be
erased.
3Press the [+/YES] button.
4At the “Sure?” prompt, press the [+/YES] button, or press
the [-/NO] button to abort.
Pressing the [+/YES] button executes the Song Clear operation.
Pressing the [-/NO] button aborts.
User 2
202
001
ClrUser2
YES
001
Song Recording
66
Track Clear
The Track Clear operation completely erases all recorded data on a selected track
of a selected User song, leaving the other tracks intact. Use this operation only
when you’re sure you want to erase a track and record a new one. To erase the
data of an entire song, use the Song Clear operation (page 65).
1Select the desired song.
Press the [SONG] button, then use the numeric keypad or [+]/[-] buttons to
select the desired song (201 - 205).
2Press and hold down the button corresponding to the track
to be erased.
Press and hold down the appropriate SONG MEMORY button ([1] - [5],
[A]) for at least one second.
3Press the [+/YES] button.
4At the “Sure?” prompt, press the [+/YES] button, or press
the [-/NO] button to abort.
Pressing the [+/YES] button executes the Track Clear operation.
Pressing the [-/NO] button aborts.
User 2
202
001
ClrTr1
YES
001
67
Song Lesson
The Lesson feature provides an exceptionally fun and easy-to-use way to learn how to read
music and play the keyboard. There are a total of 100 songs (Songs 001 to 100), specially
designed for use with the educational features. Lesson lets you practice the left- and right-
hand parts of each song independently, step by step, until you’ve mastered them and are ready
to practice with both hands together. These practices are divided into four Lesson steps, as
described below. Lessons 1 - 3 apply to each hand; press the appropriate button, [L] (left) or
[R] (right) to select the desired part for practice.
Naturally, you can also use Song data you’ve loaded from disk with the Lesson features.
■ Lesson 1 — Timing
This lesson step lets you practice just the timing of the notes — any note
can be used, as long as you play in rhythm.
■ Lesson 2 — Waiting
In this lesson step, the DGX-500/300 waits for you to play the correct notes
before continuing playback of the song.
■ Lesson 3 — Minus One
This lesson step plays back the song with one part muted, letting you play
and master the missing part yourself — in rhythm and at the proper tempo.
■ Lesson 4 — Both Hands
Lesson 4 is a “Minus One” practice essentially the same as Lesson 3,
except that both the left- and right-hand parts are muted — letting you play
and master both hands at the same time.
Using the Lesson Feature
1Select one of the Lesson songs.
Press the [SONG] button, then use the numeric keypad or [+]/[-] buttons to
select the desired song.
The Lesson songs are divided into several different categories or music
genres, with 100 songs available.
Lomond
040
-01
Song Lesson
68
2Select the part you wish to work on (left or right) and the
Lesson step.
If you want to work on the right-hand part, press the [R] button; to work on
the left, press the [L] button. Pressing either button repeatedly cycles
through the available Lesson steps in order: Lesson 1 → Lesson 2 → Lesson
3 → Off → Lesson 1, etc. The selected Lesson step is indicated in the dis-
play.
To select Lesson 4, press both [L] and [R] buttons simultaneously.
3Start the Lesson.
The Lesson and song playback start automatically (following a lead-in
count) as soon as the Lesson step is selected. When the Lesson is finished,
your performance “grade” is shown in the display (if the Grade function is
turned on; page 72). After a short pause, the Lesson begins again automati-
cally.
4Press the [START/STOP] button to stop the Lesson.
The DGX-500/300 exits from the Lesson feature automatically when the
[START/STOP] button is pressed.
Timing
L1
Waiting
L2
MinusOne
L3
Lomond
040
Timing
r1
Waiting
r2
MinusOne
r3
Lomond
040 (Song Lesson off)(Song Lesson off)
BothHand
Lr4
Asterisks appear indicating the
timing at which you should play
the notes. The line of asterisks
represents one full measure.
Sixteenth notes are indicated by
an alternating asterisk and
sharp sign.
(for songs having a “free” tempo,
no such indications appear.)
****
r1
001
Song Lesson
69
Select the Lesson Track
This function allows you to select the track number of a disk song (only SMF
format 0). (Refer to the Disk Operations chapter on page 73.)
1With Song playback stopped, press the Overall right button
to select LESSON TRACK L or R.
LESSON TRACK R appears following TRACK L.
2Set the Track number.
Use the numeric keypad number buttons [0] - [9], or the [+]/[-] buttons to
select the Lesson Track number.
Lesson 1 — Timing
This lesson step lets you practice just the timing of the notes — any note can be
used, as long as you play in rhythm. Pick a note to play. For the left hand, use a
note in the auto accompaniment area or play the appropriate left-hand note; for
the right, play a note above F#2. Simply concentrate on playing each note in time
with the rhythmic accompaniment.
1Select one of the Lesson songs.
2Select Lesson 1.
Press the [L] or [R] button (repeatedly, if necessary) until Lesson 1 is indi-
cated.
3Play the appropriate melody or chord with the song.
After the lead-in, the song starts automatically, and the appropriate notes
appear in the display. In Lesson 1, simply play one note repeatedly in time
with the music.
Regarding chords and the use of the left hand, the DGX-500/300 actually has
two different types of songs: 1) songs with normal left-hand chords, and 2)
songs in which the left hand plays arpeggios or melodic figures in combina-
tion with the right.
In the case of the first type, play the chords with your left hand in the auto
accompaniment area of the keyboard.
• If necessary, the Octave setting
can be changed for lesson track.
(See page 76.)
• The melody note does not sound
unless your playing is in time with
the rhythm.
Timing
r1
-01
Auto accompaniment area
Song Lesson
70
Lesson 2 — Waiting
In this lesson step, the DGX-500/300 waits for you to play the correct notes
before continuing playback of the song. This lets you practice reading the music
at your own pace. The notes to be played are shown in the display, one after
another, as you play them correctly.
1Select one of the Lesson songs.
2Select Lesson 2.
Press the [L] or [R] button (repeatedly, if necessary) until Lesson 2 is indi-
cated.
3Play the appropriate melody or chord with the song.
After the lead-in, the song starts automatically, and the appropriate notes
appear in the display. In Lesson 2, play the correct notes at your own pace,
until you can master playing them in rhythm.
Lesson 3 — Minus One
This lesson step lets you practice one part of the song in rhythm at the proper
tempo. The DGX-500/300 plays back the song accompaniment with one part
muted (either the left part or the right)— letting you play and master the missing
part yourself. The notes you are to play are shown continuously in the display as
the song plays back.
1Select one of the Lesson songs.
2Select Lesson 3.
Press the [L] or [R] button (repeatedly, if necessary) until Lesson 3 is indi-
cated.
Waiting
r2
-01
MinusOne
r3
-01
Song Lesson
71
3Play the appropriate part with the song.
After the lead-in, the song starts automatically, and the appropriate notes
appear in the display. In Lesson 3, listen carefully to the un-muted part, and
play the muted part yourself.
Lesson 4 — Both Hands
Lesson 4 is a “Minus One” practice essentially the same as Lesson 3, except that
both the left- and right-hand parts are muted — letting you play and master both
hands at the same time. Go on to this lesson step after you’ve mastered each
hand’s part in the previous three lesson steps. Practice both hands in time with the
rhythm along with the notation in the display.
1Select one of the Lesson songs.
2Select Lesson 4.
Press the [L] and [R] buttons simultaneously, so that Lesson 4 is indicated.
3Play both the left- and right-hand parts with the song.
After the lead-in, the song starts automatically, and the appropriate notes
appear in the display. In Lesson 4, both parts (left and right) are muted, let-
ting you play the entire song by yourself.
BothHand
Lr4
-01
Song Lesson
72
Grade
The Lesson feature has a built-in evaluation function that monitors your practicing
of the Lesson songs, and just like a real teacher, it tells you how well you did each
exercise. Four grades are assigned, depending on your performance: “OK,”
“Good,” “Very Good!,” and “Excellent!.”
1Select the Grade function.
Press the right Overall button, repeatedly if necessary, until “GRADE”
appears in the display.
2Set Grade to on or off as desired.
Use the [+]/[-] buttons to set Grade to on or off.
Excellen
on
Indicates Grade function is selected
Current Grade function setting
GRADE
on
-01
• Grade is automatically set to on
as the default setting.
GRADE
on
Grade onGrade off
73
Disk Operations
The DGX-500/300 features a convenient floppy disk drive — built right into the instrument. Let
you record and play back your own original User Songs, it allows you to save and load impor-
tant DGX-500/300 data.
Moreover, since the DGX-500/300 is compatible with a wide variety
of disk formats, you can play back song data on commercially avail-
able GM (General MIDI), DOC (Disk Orchestra Collection), and
Clavinova Disklavier Piano Soft disks.
It also allows you to save and play back Standard MIDI File (SMF)
format 0 data.
The DGX-500/300 can also be used with the included disk or com-
mercially available Style File data, allowing you to load additional
styles (auto accompaniment patterns) to the instrument. Style File
data is loaded individually as style number 136, and can be played
just like the preset styles. Once loaded, the Style File data can then
be saved in combination with User songs.
■ Data that Can be Saved or Loaded with the DGX-500/300
■ Using Commercially Available Music Data (sold separately)
The DGX-500/300 is compatible with music disks (floppy disks) that bear the fol-
lowing marks:
You can playback song files collected on these disks using the voices
defined in the GM standard. (See page 75)
“GM System Level 1” is an addition to the MIDI standard which ensures
that any GM-compatible music data can be accurately played by any
GM-compatible tone generator, regardless of manufacturer. The GM
mark is affixed to all software and hardware products that support GM
System Level 1. The DGX-500/300 supports GM System Level 1.
As its name implies, “XGlite” is a simplified version of Yamaha’s high-
quality XG tone generation format. Naturally, you can play back any
XG song data using an XGlite tone generator. However, keep in mind
that some songs may play back differently compared to the original data,
due to the reduced set of control parameters and effects.
You can playback song files collected on these disks using the voices
defined in Yamaha’s DOC format. (See page 75)
The DOC voice allocation format provides data playback compatibility
with a wide range of Yamaha instruments and MIDI devices, including
the Clavinova series.
You can load and play with the style files collected on these disks. (See
page 79)
The Style File Format — SFF — is Yamaha’s original style file format
which uses a unique conversion system to provide high-quality auto-
matic accompaniment based on a wide range of chord types. The DGX-
500/300 uses the SFF data internally, reading from optional SFF style
disks.
• While any of the disk-related dis-
plays are shown (called up by
pressing the LOAD, SAVE, or
UTILITY buttons), no panel oper-
ations can be executed (except
for disk operations), and playing
the keyboard does not produce
any sound.
Data type Extension Save Load
User Songs .USR O O
Style File .STY - O
• User Songs and Disk Style data
(style number 136) are saved
and loaded as a single file on the
DGX-500/300.
• To ensure proper data storage,
use only disks that have been
formatted on the DGX-500/300
(page 81).
• The three letters following the file
name (after the period) are
referred to as a file “extension.”
The extension indicates the type
of file.
Disk Operations
74
Using the Floppy Disk Drive (FDD) and Floppy Disk
Be sure to handle floppy disks and treat the disk drive with
care. Follow the important precautions below.
■ Compatible Disk Type
3.5" 2DD and 2HD type floppy disks can be used.
■ Inserting/Ejecting Floppy Disks
●To insert a floppy disk into the disk drive:
• Hold the disk so that the label of the disk is facing upward
and the sliding shutter is facing forward, towards the disk slot.
Carefully insert the disk into the slot, slowly pushing it all the
way in until it clicks into place and the eject button pops out.
●To eject a floppy disk:
• Before ejecting the disk, be sure to confirm that the FDD is
stopped. Press the eject button slowly as far as it will go; the
disk will automatically pop out. When the disk is fully ejected,
carefully remove it by hand.
• If the eject button is pressed too quickly, or if it is not pressed
in as far as it will go, the disk may not eject properly. The
eject button may become stuck in a half-pressed position
with the disk extending from the drive slot by only a few milli-
meters. If this happens, do not attempt to pull out the partially
ejected disk, since using force in this situation can damage
the disk drive mechanism or the floppy disk. To remove a par-
tially ejected disk, try pressing the eject button once again, or
push the disk back into the slot and then repeat the eject pro-
cedure.
●Never attempt to remove the disk or turn the power off dur-
ing recording, reading and playing back (when the DISK IN
USE lamp is lit). Doing so can damage the disk and possi-
bly the disk drive.
●Be sure to remove the floppy disk from the disk drive
before turning off the power. A floppy disk left in the drive
for extended periods can easily pick up dust and dirt that
can cause data read and write errors.
■ Cleaning the Disk Drive Read/Write Head
●Clean the read/write head regularly. This instrument
employs a precision magnetic read/write head which, after
an extended period of use, will pick up a layer of magnetic
particles from the disks used that will eventually cause
read and write errors.
● To maintain the disk drive in optimum working order
Yamaha recommends that you use a commercially-avail-
able dry-type head cleaning disk to clean the head about
once a month. Ask your Yamaha dealer about the availabil-
ity of proper head-cleaning disks.
● Never insert anything but floppy disks into the disk drive.
Other objects may cause damage to the disk drive or
floppy disks.
■ About the Floppy Disks
●To handle floppy disks with care:
• Do not place heavy objects on a disk or bend or apply pres-
sure to the disk in any way. Always keep floppy disks in their
protective cases when they are not in use.
• Do not expose the disk to direct sunlight, extremely high or
low temperatures, or excessive humidity, dust or liquids.
• Do not open the sliding shutter and touch the exposed sur-
face of the floppy disk inside.
• Do not expose the disk to magnetic fields, such as those pro-
duced by televisions, speakers, motors, etc., since magnetic
fields can partially or completely erase data on the disk, ren-
dering it unreadable.
• Never use a floppy disk with a deformed shutter or housing.
• Do not attach anything other than the provided labels to a
floppy disk. Also make sure that labels are attached in the
proper location.
●To protect your data (write-protect tab):
• To prevent accidental erasure of important data, slide the
disk’s write-protect tab to the “protect” position (tab open).
• When the DGX-500/300 is turned on, the LED below the floppy
disk slot will be lit indicating that the Disk Drive is ready to use.
This lamp is always on when the power is on,
regardless of Disk operation.
This lamp lights during disk read/write operations,
such as when a disk has been inserted, during
recording, playback, formatting, etc.
Write protect tab ON
(locked or write pro-
tected)
Write protect tab OFF
(unlocked or write
enabled)
Disk Operations
75
Disk Song Playback
This function allows you to play back song data on commercially available GM
(General MIDI), Yamaha DOC (Disk Orchestra Collection), or Clavinova Diskla-
vier Piano Soft disks. It also allows you to play back Standard MIDI File (SMF)
format 0 data.
1Insert the disk into the disk drive.
Once the disk is inserted, the DGX-500/300 will automatically switch to the
Song mode.
2Select the desired song number.
Use the numeric keypad or the [+]/[-] buttons.
The disk song numbers are from 101 to 199.
3Start the selected song.
Press the [START/STOP] button.
4If you want to change to another song, repeat step 2 above.
5Stop the song.
Press the [START/STOP] button.
For details, see “Selecting and Playing a Song,” page 57.
Song name and number
D-Song01
101
• The tempo setting of some com-
mercially available disk songs is
fixed. These songs are called
“free-tempo software.” When
playing back free-tempo song
data on the DGX-500/300, the
measure display shows “F t” and
the beat display does not flash.
Also, the measure number in the
display does not match the actual
measure number of playback,
and only gives you an indication
of how much of the song has
played back.
Some of song files on the
included sample disk are also
free-tempo software.
Disk Operations
76
Save
You can save User songs (song #201 - #205) to floppy disks.
1Insert a formatted floppy disk.
2Press the [SAVE] button.
Change the Track Octave Setting for a Disk Song Track
When a disk song is playing and the note data exceeds the limit of
A-1 – C7 (DGX-500), E0 – G6 (DGX-300), an “OVER” indication
flashes and
Q
or
W
appears in the display. If this happens, you can adjust
the track octave setting of the relevant track up or down to compensate.
1Select the Track Octave function.
Press the right Overall button, until “OCTAVE” appears in the display
2Change the Track Octave setting.
To set a positive octave value, press the number button, 0, 1, or 2.
To set a negative value, simultaneously hold down the [-] button and press the
appropriate number button, 1 or 2.
OCTAVE
0
001
• The Track Octave setting can
only be changed when the Song
is stopped.
• If the [SAVE] button is pressed
when there is no floppy disk
inserted into the disk drive, a “No
disk” message appears at the top
of the display, and all disk opera-
tions will be disabled.
• When the floppy disk’s write-pro-
tect tab is set to ON ( page 74) or
the disk is a purposely “copy-pro-
tected” disk, a “Protect” mes-
sage appears, indicating that the
Save function is not possible.
Indicates new file name
UF_00nnn
s--
Disk Operations
77
If you wish to overwrite the data already saved to an existing file, use the [+]/
[-] buttons to select the file you want to overwrite.
To exit from the Save screen, press the [UTILITY] button repeatedly.
3If necessary change the file name.
The DGX-500/300 automatically creates a file name ( for example
“UF_00nnn” ) for the file you are about to save. If you want to enter a more
descriptive name for easier file identification (and this is recommended), this
can be done directly from the keyboard.
A file name can consist of up to 8 characters. Each key on the keyboard
enters a different character, printed directly under the key (you cannot write
over the file extension following the period at the end of the file name). The
A#5 and B5 keys move the cursor backward and forward within the file
name. Use these keys to place the cursor where you want to enter or change
a character. The Delete key (C6) deletes the character at the cursor position.
To exit from the Save screen, press the [UTILITY] button repeatedly.
4Press the [EXECUTE] button.
To exit from the Save screen, press the [UTILITY] button repeatedly.
Filename
s-U
• Even if you chose a file where
data is already saved because
you want to overwrite the data,
renaming the file will cause the
new data to be saved in a differ-
ent file, and the old data won’t be
overwritten.
A#5B5 C6
• If you have selected a file to
which data has already been
saved, “yES Over Wr?” will
appear on the top line of the dis-
play.
Filename
YES
Disk Operations
78
5Execute the Save operation.
Press the [+] button (“YES”), and the Save operation will start. Once started,
the operation cannot be canceled.
As the file is saving, “Saving” will appear on the top line of the display.
To avoid saving the file, press the [-] button (“NO”) instead of the [+] button
(“YES”).
To exit from the Save screen, press the [UTILITY] button repeatedly.
When the operation is completed, the following display briefly appears.
• If there isn’t enough space on the
disk, a “DiskFull” message
appears, and you will not be able
to save any data. You can delete
unneeded files on the disk (page
80), or replace the disk with a
new one and repeat the save
operation.
• If a write error occurs during a
save operation, an “Error” mes-
sage appears. If the error reoc-
curs after repeating the save
operation, there could be some-
thing wrong with the disk. Insert
a different disk in the drive and
retry the save operation.
Saving
s-U
• While the file is being saved
(the DISK IN USE lamp is lit),
never eject the floppy disk or
turn the power off.
Complete
Saving files in SMF Format 0
The DGX-500/300 can also save song data in SMF (Standard MIDI File) Format 0. To do this:
2-1 In step #2 of the above Save operation, after pressing the [SAVE]
button, press the [SAVE] button again to call up the SMF Save
mode.
2-2 Press the [EXECUTE] button.
2-3 Select a song for saving, if necessary, using the [+]/[-] buttons.
2-4 Press the [EXECUTE] button.
Continue with step #3 of the Save operation above.
to SMF?
User1
S-S
Disk Operations
79
Load
Once you’ve saved your User data onto a floppy disk, you can reload that data
back to the DGX-500/300. You can also load style data from the included disk or
commercially available Yamaha Style File disks.
1Insert the floppy disk into the disk drive.
2Press the [LOAD] button.
Press the [LOAD] button again to exit from the LOAD screen.
3Select the file to load.
Use the [+]/[-] buttons.
4Press the [EXECUTE] button.
5Execute the Load operation.
Press the [+] button (“YES”), and the Load operation will start. Once started,
the operation cannot be canceled.
As the file is loading, “Loading” will appear on the top line of the display.
When the operation is completed, the following display briefly appears.
If you do not intend to load the file, press the [-] button (“NO”) instead of the
[+] button (“YES”).
To exit from the LOAD screen, press the [LOAD] button.
• If the [LOAD] button is pressed
when there is no floppy disk
inserted into the disk drive, a “No
disk” message appears at the top
of the display, and all disk opera-
tions will be disabled.
This case is user file. Style file indicates “L-S”.
Filename
L-U
• If the disk contains no file, the
display shows “No file” indicating
that the Load function is not pos-
sible.
Filename
L-U
• When data is loaded from a
floppy disk to the DGX-500/300,
the data already in the memory of
the DGX-500/300 will be
replaced by the data on the disk.
Save important data into a disk
file before doing the operation.
Sure?
YES
• While the file is loading (the
DISK IN USE lamp is lit), never
eject the floppy disk or turn the
power off.
Loading
L-U
Complete
Disk Operations
80
Utility – Delete
This function allows you to delete individual files of User data you’ve saved to
floppy disk.
1Insert the floppy disk into the disk drive.
2Press the [UTILITY] button.
The filename will appear at the top of the display.
To exit from the UTILITY screen, press the [UTILITY] button twice.
3Select the file to be deleted.
Use the [+]/[-] buttons.
4Press the [EXECUTE] button.
5Execute the delete operation.
Press the [+] button (“YES”), and the Delete operation will start. Once
started, the operation cannot be canceled.
As the file is deleting, “Deleting” will appear on the top line of the display.
When the operation is completed, the following display briefly appears.
If you do not intend to delete the file, press the [-] button (“NO”) instead of
the [+] button (“YES”).
To exit from the UTILITY screen, press the [UTILITY] button twice.
• If the [UTILITY] button is pressed
when there is no floppy disk
inserted into the disk drive, a “No
disk” message appears at the top
of the display, and all disk opera-
tions will be disabled.
• When the floppy disk’s write-pro-
tect tab is set to ON (see page
74) or the disk is a purposely
“copy-protected” disk, a “Protect”
message appears, indicating that
the Utility function is not possible.
• SMF files are indicated by “d-s”.
This case is user file
Filename
d-U
• Only files that were created on
the DGX-500/300 and were
saved as files (User song, etc.)
can be deleted. When there are
no files on disk that the DGX-
500/300 can delete, the FOR-
MAT display appears instead of
DELETE, when the [UTILITY]
button is pressed.
Filename
d-U
Filename
YES
• While the file is being deleted
(the DISK IN USE lamp is lit),
never eject the floppy disk or
turn the power off.
Deleting
d-U
Complete
Disk Operations
81
Utility – Formatting an Unformatted Disk
1Insert the unformatted floppy disk into the disk drive.
A “Format?” message will appear at the top of the display.
Press the [UTILITY] button to exit from the FORMAT screen.
2Press the [EXECUTE] button.
3Execute the Format operation.
Press the [+] button (“YES”), and the Format operation will start. Once
started, the operation cannot be canceled.
During formatting, “Formatin” will appear at the top of the display.
When the operation is completed, the following display briefly appears.
If you do not intend to format the disk, press the [-] button (“NO”) instead of
the [+] button (“YES”).
To exit from the UTILITY screen, press the [UTILITY] button.
Format?
CUE
• If you insert an unformatted disk
with the write protect tab in the
ON position into the drive, a “Pro
-
tect” message appears. Eject the
disk, move the protect tab to the
OFF position, and reinsert it in
the drive.
• If a disk that cannot be read by
the DGX-500/300 is inserted
into the disk drive, it will be
treated the same as an unfor-
matted floppy disk. Take care
not to erase important data by
accidentally formatting a disk.
Sure?
YES
• While formatting is in progress
(the DISK IN USE lamp is lit) ,
never eject the disk or turn the
power off.
Formatin
072
Complete
Disk Operations
82
Utility – Formatting a Previously Formatted Disk
This function is useful for quickly deleting unnecessary files from an already for-
matted disk. Be careful when using this operation, since it automatically deletes
all data on the disk.
1Insert the floppy disk into the disk drive.
2Press the [UTILITY] button.
This calls up the Delete operation (page 80). The filename will appear at the
top of the display. When there are no files on disk that the DGX-500/300 can
delete, the FORMAT display appears instead of DELETE, when the [UTIL-
ITY] button is pressed. In this situation, step #2 is unnecessary.
3Press the [UTILITY] button again.
This calls up the Format operation.
“Format?” will appear at the top of the display.
4Press the [EXECUTE] button.
5Execute the Format operation.
Press the [+] button (“YES”), and the Format operation will start. Once
started, the operation cannot be canceled. During formatting, “Formatin”
will appear at the top of the display.
When the operation is completed, the following display briefly appears.
If you do not intend to format the disk, press the [-] button (“NO”) instead of the
[+] button (“YES”). To exit from the operation, press the UTILITY button.
• If the [UTILITY] button is pressed
when there is no floppy disk
inserted into the disk drive, a “No
disk” message appears at the top
of the display, and all disk opera-
tions will be disabled.
This case is user file
Filename
L-U
• When the floppy disk’s write-pro-
tect tab is set to ON (see page
74) or the disk is a purposely
“copy-protected” disk, a “Protect”
message appears, indicating that
the Utility function is not possible.
Format?
CUE
Sure?
YES
• While formatting is in progress
(the DISK IN USE lamp is lit) ,
never eject the disk or turn the
power off.
• If data is already saved on the
disk, be careful not to format it.
If you format the disk, all the
previously recorded data will
be deleted.
Formatin
072
Complete
83
MIDI Functions
The DGX-500/300 is MIDI-compatible, featuring MIDI IN and MIDI OUT terminals and providing a
variety of MIDI-related controls. By using the MIDI functions you can expand your musical
possibilities. This section explains what MIDI is, and what it can do, as well as how you can use
MIDI on your DGX-500/300.
What Is MIDI?
No doubt you have heard the terms “acoustic instrument” and “digital instru-
ment.” In the world today, these are the two main categories of instruments. Let’s
consider an acoustic piano and a classical guitar as representative acoustic instru-
ments. They are easy to understand. With the piano, you strike a key, and a ham-
mer inside hits some strings and plays a note. With the guitar, you directly pluck a
string and the note sounds. But how does a digital instrument go about playing a
note?
As shown in the illustration above, in an electronic instrument the sampling note
(previously recorded note) stored in the tone generator section (electronic circuit)
is played based on information received from the keyboard. So then what is the
information from the keyboard that becomes the basis for note production?
For example, let’s say you play a “C” quarter note using the grand piano sound on
the DGX-500/300 keyboard. Unlike an acoustic instrument that puts out a reso-
nated note, the electronic instrument puts out information from the keyboard such
as “with what voice,” “with which key,” “about how strong,” “when was it
pressed,” and “when was it released.” Then each piece of information is changed
into a number value and sent to the tone generator. Using these numbers as a
basis, the tone generator plays the stored sampling note.
● Example of Keyboard Information
Voice number (with what voice) 01 (Live! Grand)
Note number (with which key) 60 (C3)
Note on (when was it pressed) and
note off (when was it released)
Timing expressed numerically (quarter note)
Velocity (about how strong) 20 (strong)
Acoustic guitar note production Digital instrument note production
Pluck a string and the body
resonates the sound.
Based on playing information from the keyboard, a
sampling note stored in the tone generator is played
through the speakers.
LR
Tone Generator
(Electronic circuit)
Sampling
Note
Sampling
Note
Playing the keyboard
GM System Level 1
“GM System Level 1” is an addition to the MIDI standard which ensures that any GM-compati-
ble music data can be accurately played by any GM-compatible tone generator, regardless of
manufacturer. The GM mark is affixed to all software and hardware products that support GM
System Level 1. The DGX-500/300 supports GM System Level 1.
MIDI Functions
84
MIDI is an acronym that stands for Musical Instrument Digital Interface, which
allows electronic musical instruments to communicate with each other, by send-
ing and receiving compatible Note, Control Change, Program Change and various
other types of MIDI data, or messages.
The DGX-500/300 can control a MIDI device by transmitting note related data
and various types of controller data. The DGX-500/300 can be controlled by the
incoming MIDI messages which automatically determine tone generator mode,
select MIDI channels, voices and effects, change parameter values and of course
play the voices specified for the various parts.
MIDI messages can be divided into two groups: Channel messages and System
messages. Below is an explanation of the various types of MIDI messages which
the DGX-500/300 can receive/transmit.
● Channel Messages
The DGX-500/300 is an electronic instrument that can handle 16 channels. This is
usually expressed as “it can play 16 instruments at the same time.” Channel mes-
sages transmit information such as Note ON/OFF, Program Change, for each of
the 16 channels.
● System Messages
This is data that is used in common by the entire MIDI system. System messages
include messages like Exclusive Messages that transmit data unique to each
instrument manufacturer and Realtime Messages that control the MIDI device.
The messages transmitted/received by the DGX-500/300 are shown in the MIDI
Implementation Chart on page 102.
Message Name DGX-500/300 Operation/Panel Setting
Note ON/OFF Messages which are generated when the keyboard is played. Each
message includes a specific note number which corresponds to the
key which is pressed, plus a velocity value based on how hard the
key is stuck.
Program Change Voice number (along with corresponding bank select MSB/LSB set-
tings, if necessary).
Control Change Messages that are used to change some aspect of the sound (mod-
ulation, volume, pan, etc.).
Message Name DGX-500/300 Operation/Panel Setting
Exclusive Message Reverb/chorus/DSP settings, etc.
Realtime Messages Start/stop operation
MIDI Terminals
In order to exchange MIDI data between multiple
devices, each device must be connected by a cable.
The MIDI terminals of the DGX-500/300 are located on
the rear panel.
MIDI IN Receives MIDI data from another MIDI device.
MIDI OUT Transmits the DGX-500/300’s keyboard information as MIDI
data to another MIDI device.
• Special MIDI cables (sold sepa-
rately) must be used for connect-
ing to MIDI devices. They can be
bought at music stores, etc.
• Never use MIDI cables longer
than about 15 meters. Cables
longer than this can pick up noise
which can cause data errors.
MIDI Functions
85
Connecting to a Personal Computer
By connecting your DGX-500/300’s MIDI terminals to a personal computer, you
can have access to a wide variety of music software.
When using a MIDI interface device installed in the personal computer, connect
the MIDI terminals of the personal computer and the DGX-500/300.
Use only special MIDI cables when connecting MIDI devices.
● Connect the MIDI terminals of the DGX-500/300 to the MIDI
terminals of the personal computer.
● When using a MIDI interface with a Macintosh series com-
puter, connect the RS-422 terminal of the computer (modem
or printer terminal) to the MIDI interface, as shown in the dia-
gram below.
● When connecting to a computer with a USB interface, use the
Yamaha UX16 USB/MIDI Interface. Connect the UX16 and the com-
puter with a standard USB cable, then make the proper MIDI con-
nections between the DGX-500/300 and the UX16.
Computer
(sequencer software)
DGX-500/300
MIDI OUT
MIDI IN
MIDI IN
MIDI OUT
Computer
(sequencer software)
DGX-500/300
MIDI IN
MIDI OUT
MIDI Interface
RS-422
• When using a Macintosh series
computer, set the MIDI interface
clock setting in the application
software to match the setting of
the MIDI interface you are using.
For details, refer to the owner’s
manual for the software you are
using.
Viewing the Notation for MIDI
Channel 1
• The DGX-500/300 has a special
function that lets you view the
notes of the MIDI data (channel 1
only) on the display.
IN
OUT
Computer
(sequencer software)
DGX-500/300
MIDI IN
MIDI OUT
UX16
USB
MIDI Functions
86
Local Control
This function lets you enable or disable keyboard control over the DGX-500/
300’s voices. This would come in handy, for example, when recording notes to
MIDI sequencer. If you are using the sequencer to play back the voices of the
DGX-500/300, you would want to set this to “off” — in order to avoid getting
“double” notes, both from the keyboard and from the sequencer. Normally, when
playing the DGX-500/300 by itself, this should be set to “on.”
1Select the MIDI operations.
Press the left Overall button, repeatedly if necessary, until MIDI is selected.
2Select the Local Control parameter.
Press “1” on the numeric keypad to select operation #1, Local Control.
If the LOCAL display appears instead of INITSEND in step #1 above, step
#2 is unnecessary.
3Press the [+]/[-] buttons.
Set Local Control to on or off, as desired.
Indicates MIDI is selected
INITSEND
-01
LOCAL
on
• No sound is output from the
DGX-500/300 when Local ON/
OFF is set to OFF.
MIDI Functions
87
Using Initial Setup Send with a Sequencer
The most common use for the Initial Setup Send function is in recording a song
on a sequencer that is intended for playback with the DGX-500/300. Essentially,
this takes a “snapshot” of the DGX-500/300 settings and sends that data to the
sequencer. By recording this “snapshot” at the start of the song (before any actual
performance data), you can instantly restore the necessary settings on the DGX-
500/300. Provided there is a pause in the song, you could also do this in the mid-
dle of a song — for example, completely changing the DGX-500/300 settings for
the next section of the song.
■ Sending Initial Setup Data • • • • • • • • • • • • • • • • • • • • • • • • • •
1First, set up the sequencer for recording.
The actual procedure may differ depending on your particular equipment and
software.
Ideally, you should leave two or more measures of silence (no performance
data) before the song begins. The Initial Setup data should then be recorded
to this space in the song.
2Select the MIDI operations.
Press the left Overall button, repeatedly if necessary, until MIDI is selected.
3Select the Initial Setup Send operation.
Press “2” on the numeric keypad to select operation #2, Initial Setup Send.
If the INITSEND display appears instead of LOCAL in step #2 above, step
#3 is unnecessary.
4Press the [START/STOP] button.
Start the Initial Setup Send operation.
INITSEND
MIDI Functions
88
5Start recording on the sequencer, then send the Initial
Setup data.
Start recording on the sequencer in the normal way, then — with as little delay as
possible — press the [+] button to actually start transmitting the data.
An “End” message briefly appears in the display when the operation is complete.
6Stop recording on the sequencer.
Stop recording on the sequencer in the normal way. Make sure that any sub-
sequently recorded performance data is recorded at least one measure fol-
lowing the Initial Setup data.
External Clock
This determines whether the style and song playback functions are controlled by
the DGX-500/300’s internal clock (off) or by MIDI clock data from an external
sequencer or computer (on).
This should be set to on when you want to have style or song playback follow the
external device (such as a rhythm machine or a sequencer). The default setting is
off.
1Press the [TEMPO] button.
2Set the instrument to External Clock.
Press and hold the [+] button until the value “280” is indicated, then press
the [+] button once more to select “ECL” (External Clock) in the display.
To return to the Internal Clock setting, simply select a Tempo value from 32
to 280.
End
• When the Initial Setup Send
operation is completed, the DGX
-
500/300 automatically returns to
the previous panel condition.
• If External Clock is set to ON,
style or song playback will not
start unless external clock are
received.
MIDI LSB receive cancel.
Set to receive or not receive the LSB data of BANK SELECT.
Press and hold the lowest key and turning on the power.
Turning on the power again normally, “MIDI LSB receive cancel” return to normal.
DGX-500 DGX-300
89
Troubleshooting
Problem Possible Cause and Solution
When the DGX-500/300 is turned on or off, a pop-
ping sound is temporarily produced.
This is normal and indicates that the DGX-500/300 is receiving elec-
trical power.
When using a mobile phone, noise is produced. Using a mobile phone in close proximity to the DGX-500/300 may
produce interference. To prevent this, turn off the mobile phone or
use it further away from the DGX-500/300.
There is no sound even when the keyboard is
played or when a song is being played back.
Check that nothing is connected to the PHONES/OUTPUT jack on
the rear panel. When a set of headphones is plugged into this jack,
no sound is output.
Check the Local Control on/off. (See page 86.)
Playing keys in the right hand section of the key-
board does not produce any sound.
When using the Dictionary function (page 50), the keys in the right
hand section are used only for entering the chord root and type.
The sound of the voices or rhythms seems unusu-
al or strange.
The battery power is too low. Replace the batteries. (See page 10.)
The song or style does not start playback. Check the External Clock. (See page 88.)
The auto accompaniment doesn’t turn on, even
when pressing the [ACMP] button.
Make sure the Style mode is active before using the auto accompa-
niment. Press the [STYLE] button to enable style operations.
The accompaniment does not sound properly. Make sure that the Accompaniment Volume (page 46) is set to an ap-
propriate level.
Make sure that the Split Point (page 49) is set to an appropriate value.
When playing back one of the Pianist styles (#124
- #135), the rhythm cannot be heard.
This is normal. The Pianist styles have no drums or bass — only pi-
ano accompaniment. The accompaniment of the style can only be
heard when accompaniment is set to ON and keys are played in the
auto accompaniment area of the keyboard.
Not all of the voices seem to sound, or the sound
seems to be cut off.
The DGX-500/300 is polyphonic up to a maximum of 32 notes. If the
Dual voice or Split voice is being used and a style or song is playing
back at the same time, some notes/sounds may be omitted (or “sto-
len”) from the accompaniment or song.
A strange “flanging” or “doubling” sound occurs
when using the DGX-500/300 with a sequencer.
(This may also sound like a “dual” layered sound
of two voices, even when Dual is turned off.)
When using the accompaniment with a sequencer, set MIDI Echo (or
the relevant control) to “off.” (Refer to the owner’s manual of your par-
ticular device and/or software for details.)
The footswitch (for sustain) seems to produce the
opposite effect. For example, pressing the foot-
switch cuts off the sound and releasing it sustains
the sounds.
The polarity of the footswitch is reversed. Make sure that the foot-
switch plug is properly connected to the FOOT SWITCH jack before
turning on the power.
Do not press the pedal while turning the power on.
The sound of the voice changes from note to note. The AWM tone generation method uses multiple recordings (sam-
ples) of an instrument across the range of the keyboard; thus, the ac-
tual sound of the voice may be slightly different from note to note.
90
Data Backup & Initialization
■ Data Backup • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
Except for the data listed below, all DGX-500/300 panel settings are reset to their
initial settings whenever the power is turned on. The data listed below are backed
up — i.e. retained in memory — as long as an AC adaptor is connected or a set of
batteries is installed.
• User Song Data
• Song Volume
• Registration Memory Data
• Registration Memory Bank Number
• Metronome Volume
• Touch On/Off
• Tuning
• Grade On/Off
■ Data Initialization • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
All data can be initialized and restored to the factory preset condition by turning
on the power while holding the highest (rightmost) white key on the keyboard.
“CLr Backup” will appear briefly on the display.
• All Registration Memory and
User song data, plus the other
settings listed above, will be
erased and/or changed when
the data initialization proce-
dure is carried out.
• Carrying out the data initializa-
tion procedure will usually
restore normal operation if the
DGX-500/300 freezes or begins
to act erratically for any rea-
son.
Backup
CLr
DGX-500 DGX-300
91
Voice List
■ Maximum Polyphony • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
The DGX-500/300 has 32-note maximum polyphony. This means that it can play
a maximum of up to 32 notes at once, regardless of what functions are used. Auto
Accompaniment uses a number of the available notes, so when Auto Accompani-
ment is used the total number of available notes for playing on the keyboard is
correspondingly reduced. The same applies to the Split Voice and Song functions.
• The Voice List includes MIDI pro-
gram change numbers for each
voice. Use these program
change numbers when playing
the DGX-500/300 via MIDI from
an external device.
• Some voices may sound continu-
ously or have a long decay after
the notes have been released
while the sustain pedal (foot-
switch) is held.
●Panel Voice List
Voice
No.
Bank Select
MIDI
Program
Change#
Voice Name
MSB LSB
PIANO
001 000 113 000 Live! Grand
002 000 112 000 Grand Piano
003 000 112 001 Bright Piano
004 000 112 003 Honky-tonk Piano
005 000 112 002 MIDI Grand Piano
006 000 113 002 CP 80
007 000 112 006 Harpsichord
E. PIANO
008 000 114 004 Galaxy EP
009 000 112 004 Funky Electric Piano
010 000 112 005 DX Modern Elec. Piano
011 000 113 005 Hyper Tines
012 000 114 005 Venus Electric Piano
013 000 112 007 Clavi
ORGAN
014 000 118 018 Cool! Organ
015 000 112 016 Jazz Organ 1
016 000 113 016 Jazz Organ 2
017 000 112 017 Click Organ
018 000 116 016 Bright Organ
019 000 112 018 Rock Organ
020 000 114 018 Purple Organ
021 000 118 016 16'+2' Organ
022 000 119 016 16'+4' Organ
023 000 114 016 Theater Organ
024 000 112 019 Church Organ
025 000 113 019 Chapel Organ
026 000 112 020 Reed Organ
ACCORDION
027 000 113 021 Traditional Accordion
028 000 112 021 Musette Accordion
029 000 113 023 Bandoneon
030 000 112 022 Harmonica
GUITAR
031 000 112 024 Classical Guitar
032 000 112 025 Folk Guitar
033 000 113 025 12Strings Guitar
034 000 112 026 Jazz Guitar
035 000 113 026 Octave Guitar
036 000 112 027 Clean Guitar
037 000 117 027 60’s Clean Guitar
038 000 112 028 Muted Guitar
039 000 112 029 Overdriven Guitar
040 000 112 030 Distortion Guitar
BASS
041 000 112 032 Acoustic Bass
042 000 112 033 Finger Bass
043 000 112 034 Pick Bass
044 000 112 035 Fretless Bass
045 000 112 036 Slap Bass
046 000 112 038 Synth Bass
047 000 113 038 Hi-Q Bass
048 000 113 039 Dance Bass
STRINGS
049 000 112 048 String Ensemble
050 000 112 049 Chamber Strings
051 000 112 050 Synth Strings
052 000 113 049 Slow Strings
053 000 112 044 Tremolo Strings
054 000 112 045 Pizzicato Strings
055 000 112 055 Orchestra Hit
056 000 112 040 Violin
057 000 112 042 Cello
058 000 112 043 Contrabass
059 000 112 105 Banjo
060 000 112 046 Harp
CHOIR
061 000 112 052 Choir
062 000 113 052 Vocal Ensemble
063 000 112 053 Vox Humana
064 000 112 054 Air Choir
SAXOPHONE
065 000 112 064 Soprano Sax
066 000 112 065 Alto Sax
067 000 117 066 Sweet Tenor
068 000 114 066 Breathy Tenor
069 000 112 066 Tenor Sax
070 000 112 067 Baritone Sax
071 000 112 068 Oboe
072 000 112 069 English Horn
073 000 112 070 Bassoon
074 000 112 071 Clarinet
TRUMPET
075 000 112 056 Trumpet
076 000 112 059 Muted Trumpet
077 000 112 057 Trombone
078 000 113 057 Trombone Section
079 000 112 060 French Horn
080 000 112 058 Tuba
BRASS
081 000 112 061 Brass Section
082 000 113 061 Big Band Brass
083 000 119 061 Mellow Horns
084 000 112 062 Synth Brass
085 000 113 062 Jump Brass
086 000 114 062 Techno Brass
Voice
No.
Bank Select
MIDI
Program
Change#
Voice Name
MSB LSB
Voice List
92
FLUTE
087 000 114 073 Sweet Flute
088 000 112 073 Flute
089 000 112 072 Piccolo
090 000 112 075 Pan Flute
091 000 112 074 Recorder
092 000 112 079 Ocarina
SYNTH LEAD
093 000 112 080 Square Lead
094 000 112 081 Sawtooth Lead
095 000 112 085 Voice Lead
096 000 112 098 Star Dust
097 000 112 100 Brightness
098 000 115 081 Analogon
099 000 119 081 Fargo
SYNTH PAD
100 000 112 088 Fantasia
101 000 113 100 Bell Pad
102 000 112 091 Xenon Pad
103 000 112 094 Equinox
104 000 113 089 Dark Moon
PERCUSSION
105 000 112 011 Vibraphone
106 000 112 012 Marimba
107 000 112 013 Xylophone
108 000 112 114 Steel Drums
109 000 112 08 Celesta
110 000 112 014 Tubular Bells
111 000 112 047 Timpani
112 000 112 010 Music Box
SPLIT
113 000 112 000 Acoustic Bass/Live! Grand
114 000 112 001 Finger Bass /Grand Piano
115 000 112 005 Fretless Bass/DX Modern
Elec. Piano
116 000 112 011 Acoustic Bass/Vibraphone
117 000 113 061 Fretless Bass/Brass
Section
118 000 112 082 Analogon/Sawtooth Lead
119 000 112 007 Slap Bass/Clavi
120 000 112 073 Classical Guitar/Sweet
Flute
121 000 112 000 String Ensemble/Live!
Grand
122 000 112 052 Vox Humana/Choir
DRUM KITS
123 127 000 000 Standard Kit 1
124 127 000 001 Standard Kit 2
125 127 000 008 Room Kit
126 127 000 016 Rock Kit
127 127 000 024 Electronic Kit
128 127 000 025 Analog Kit
129 127 000 027 Dance Kit
130 127 000 032 Jazz Kit
131 127 000 040 Brush Kit
132 127 000 048 Symphony Kit
133 126 000 000 SFX Kit 1
134 126 000 001 SFX Kit 2
Voice
No.
Bank Select
MIDI
Program
Change#
Voice Name
MSB LSB
●XG Voice List
Voice
No.
Bank Select
MIDI
Program
Change#
Voice Name
MSB LSB
PIANO
135 000 000 000 Grand Piano
136 000 001 000 Grand Piano KSP
137 000 018 000 Mellow Grand Piano
138 000 040 000 Piano Strings
139 000 041 000 Dream
140 000 000 001 Bright Piano
141 000 001 001 Bright Piano KSP
142 000 000 002 Electric Grand Piano
143 000 001 002 Electric Grand Piano KSP
144 000 032 002 Detuned CP80
145 000 040 002 Layered CP 1
146 000 041 002 Layered CP 2
147 000 000 003 Honky-tonk Piano
148 000 001 003 Honky-tonk Piano KSP
149 000 000 004 Electric Piano 1
150 000 001 004 Electric Piano 1 KSP
151 000 018 004 Mellow Electric Piano 1
152 000 032 004 Chorus Electric Piano 1
153 000 040 004 Hard Electric Piano
154 000 045 004 Velocity Crossfade Electric
Piano 1
155 000 064 004 60’s Electric Piano 1
156 000 000 005 Electric Piano 2
157 000 001 005 Electric Piano 2 KSP
158 000 032 005 Chorus Electric Piano 2
159 000 033 005 DX Electric Piano Hard
160 000 034 005 DX Legend
161 000 040 005 DX Phase Electric Piano
162 000 041 005 DX + Analog Electric Piano
163 000 042 005 DX Koto Electric Piano
164 000 045 005 Velocity Crossfade Electric
Piano 2
165 000 000 006 Harpsichord
166 000 001 006 Harpsichord KSP
167 000 025 006 Harpsichord 2
168 000 035 006 Harpsichord 3
169 000 000 007 Clavi
170 000 001 007 Clavi KSP
171 000 027 007 Clavi Wah
172 000 064 007 Pulse Clavi
173 000 065 007 Pierce Clavi
CHROMATIC
174 000 000 008 Celesta
175 000 000 009 Glockenspiel
176 000 000 010 Music Box
177 000 064 010 Orgel
178 000 000 011 Vibraphone
179 000 001 011 Vibraphone KSP
180 000 045 011 Hard Vibraphone
181 000 000 012 Marimba
182 000 001 012 Marimba KSP
183 000 064 012 Sine Marimba
184 000 097 012 Balimba
185 000 098 012 Log Drums
186 000 000 013 Xylophone
187 000 000 014 Tubular Bells
188 000 096 014 Church Bells
Voice List
93
189 000 097 014 Carillon
190 000 000 015 Dulcimer
191 000 035 015 Dulcimer 2
192 000 096 015 Cimbalom
193 000 097 015 Santur
ORGAN
194 000 000 016 DrawOrg
195 000 032 016 Detuned DrawOrg
196 000 033 016 60’s DrawOrg 1
197 000 034 016 60’s DrawOrg 2
198 000 035 016 70’s DrawOrg 1
199 000 036 016 DrawOrg 2
200 000 037 016 60’s DrawOrg 3
201 000 038 016 Even Bar
202 000 040 016 16+2"2/3
203 000 064 016 Organ Bass
204 000 065 016 70’s DrawOrg 2
205 000 066 016 Cheezy Organ
206 000 067 016 DrawOrg 3
207 000 000 017 Percussive Organ
208 000 024 017 70’s Percussive Organ
209 000 032 017 Detuned Percussive Organ
210 000 033 017 Light Organ
211 000 037 017 Percussive Organ 2
212 000 000 018 Rock Organ
213 000 064 018 Rotary Organ
214 000 065 018 Slow Rotary
215 000 066 018 Fast Rotary
216 000 000 019 Church Organ
217 000 032 019 Church Organ 3
218 000 035 019 Church Organ 2
219 000 040 019 Notre Dame
220 000 064 019 Organ Flute
221 000 065 019 Tremolo Organ Flute
222 000 000 020 Reed Organ
223 000 040 020 Puff Organ
224 000 000 021 Accordion
225 000 032 021 Accord It
226 000 000 022 Hamonica
227 000 032 022 Harmonica 2
228 000 000 023 Tango Accordion
229 000 064 023 Tango Accordion 2
GUITAR
230 000 000 024 Nylon Guitar
231 000 016 024 Nylon Guitar 2
232 000 025 024 Nylon Guitar 3
233 000 043 024 Velocity Guitar Harmonics
234 000 096 024 Ukulele
235 000 000 025 Steel Guitar
236 000 016 025 Steel Guitar 2
237 000 035 025 12-string Guitar
238 000 040 025 Nylon & Steel Guitar
239 000 041 025 Steel Guitar with Body
Sound
240 000 096 025 Mandolin
241 000 000 026 Jazz Guitar
242 000 018 026 Mellow Guitar
243 000 032 026 Jazz Amp
244 000 000 027 Clean Guitar
Voice
No.
Bank Select
MIDI
Program
Change#
Voice Name
MSB LSB
245 000 032 027 Chorus Guitar
246 000 000 028 Muted Guitar
247 000 040 028 Funk Guitar 1
248 000 041 028 Muted Steel Guitar
249 000 043 028 Funk Guitar 2
250 000 045 028 Jazz Man
251 000 000 029 Overdriven Guitar
252 000 043 029 Guitar Pinch
253 000 000 030 Distortion Guitar
254 000 040 030 Feedback Guitar
255 000 041 030 Feedback Guitar 2
256 000 000 031 Guitar Harmonics
257 000 065 031 Guitar Feedback
258 000 066 031 Guitar Harmonics 2
BASS
259 000 000 032 Acoustic Bass
260 000 040 032 Jazz Rhythm
261 000 045 032 Velocity Crossfade Upright
Bass
262 000 000 033 Finger Bass
263 000 018 033 Finger Dark
264 000 027 033 Flange Bass
265 000 040 033 Bass & Distorted Electric
Guitar
266 000 043 033 Finger Slap Bass
267 000 045 033 Finger Bass 2
268 000 065 033 Modulated Bass
269 000 000 034 Pick Bass
270 000 028 034 Muted Pick Bass
271 000 000 035 Fretless Bass
272 000 032 035 Fretless Bass 2
273 000 033 035 Fretless Bass 3
274 000 034 035 Fretless Bass 4
275 000 096 035 Synth Fretless
276 000 097 035 Smooth Fretless
277 000 000 036 Slap Bass 1
278 000 027 036 Resonant Slap
279 000 032 036 Punch Thumb Bass
280 000 000 037 Slap Bass 2
281 000 043 037 Velocity Switch Slap
282 000 000 038 Synth Bass 1
283 000 018 038 Synth Bass 1 Dark
284 000 020 038 Fast Resonant Bass
285 000 024 038 Acid Bass
286 000 035 038 Clavi Bass
287 000 040 038 Techno Synth Bass
288 000 064 038 Orbiter
289 000 065 038 Square Bass
290 000 066 038 Rubber Bass
291 000 096 038 Hammer
292 000 000 039 Synth Bass 2
293 000 006 039 Mellow Synth Bass
294 000 012 039 Sequenced Bass
295 000 018 039 Click Synth Bass
296 000 019 039 Synth Bass 2 Dark
297 000 032 039 Smooth Synth Bass
298 000 040 039 Modular Synth Bass
299 000 041 039 DX Bass
300 000 064 039 X Wire Bass
Voice
No.
Bank Select
MIDI
Program
Change#
Voice Name
MSB LSB
Voice List
94
STRING
301 000 000 040 Violin
302 000 008 040 Slow Violin
303 000 000 041 Viola
304 000 000 042 Cello
305 000 000 043 Contrabass
306 000 000 044 Tremolo Strings
307 000 008 044 Slow Tremolo Strings
308 000 040 044 Suspense Strings
309 000 000 045 Pizzicato Strings
310 000 000 046 Orchestral Harp
311 000 040 046 Yang Chin
312 000 000 047 Timpani
ENSEMBLE
313 000 000 048 Strings 1
314 000 003 048 Stereo Strings
315 000 008 048 Slow Strings
316 000 024 048 Arco Strings
317 000 035 048 60’s Strings
318 000 040 048 Orchestra
319 000 041 048 Orchestra 2
320 000 042 048 Tremolo Orchestra
321 000 045 048 Velocity Strings
322 000 000 049 Strings 2
323 000 003 049 Stereo Slow Strings
324 000 008 049 Legato Strings
325 000 040 049 Warm Strings
326 000 041 049 Kingdom
327 000 064 049 70’s Strings
328 000 65 049 String Ensemble 3
329 000 000 050 Synth Strings 1
330 000 027 050 Resonant Strings
331 000 064 050 Synth Strings 4
332 000 065 050 Synth Strings 5
333 000 000 051 Synth Strings 2
334 000 000 052 Choir Aahs
335 000 003 052 Stereo Choir
336 000 016 052 Choir Aahs 2
337 000 032 052 Mellow Choir
338 000 040 052 Choir Strings
339 000 000 053 Voice Oohs
340 000 000 054 Synth Voice
341 000 040 054 Synth Voice 2
342 000 041 054 Choral
343 000 064 054 Analog Voice
344 000 000 055 Orchestra Hit
345 000 035 055 Orchestra Hit 2
346 000 064 055 Impact
BRASS
347 000 000 056 Trumpet
348 000 016 056 Trumpet 2
349 000 017 056 Bright Trumpet
350 000 032 056 Warm Trumpet
351 000 000 057 Trombone
352 000 018 057 Trombone 2
353 000 000 058 Tuba
354 000 016 058 Tuba 2
355 000 000 059 Muted Trumpet
356 000 000 060 French Horn
Voice
No.
Bank Select
MIDI
Program
Change#
Voice Name
MSB LSB
357 000 006 060 French Horn Solo
358 000 032 060 French Horn 2
359 000 037 060 Horn Orchestra
360 000 000 061 Brass Section
361 000 035 061 Trumpet & Trombone
Section
362 000 040 061 Brass Section 2
363 000 041 061 High Brass
364 000 042 061 Mellow Brass
365 000 000 062 Synth Brass 1
366 000 012 062 Quack Brass
367 000 020 062 Resonant Synth Brass
368 000 024 062 Poly Brass
369 000 027 062 Synth Brass 3
370 000 032 062 Jump Brass
371 000 045 062 Analog Velocity Brass 1
372 000 064 062 Analog Brass 1
373 000 000 063 Synth Brass 2
374 000 018 063 Soft Brass
375 000 040 063 Synth Brass 4
376 000 041 063 Choir Brass
377 000 045 063 Analog Velocity Brass 2
378 000 064 063 Analog Brass 2
REED
379 000 000 064 Soprano Sax
380 000 000 065 Alto Sax
381 000 040 065 Sax Section
382 000 043 065 Hyper Alto Sax
383 000 000 066 Tenor Sax
384 000 040 066 Breathy Tenor Sax
385 000 041 066 Soft Tenor Sax
386 000 064 066 Tenor Sax 2
387 000 000 067 Baritone Sax
388 000 000 068 Oboe
389 000 000 069 English Horn
390 000 000 070 Bassoon
391 000 000 071 Clarinet
PIPE
392 000 000 072 Piccolo
393 000 000 073 Flute
394 000 000 074 Recorder
395 000 000 075 Pan Flute
396 000 000 076 Blown Bottle
397 000 000 077 Shakuhachi
398 000 000 078 Whistle
399 000 000 079 Ocarina
SYNTH LEAD
400 000 000 080 Square Lead
401 000 006 080 Square Lead 2
402 000 008 080 LM Square
403 000 018 080 Hollow
404 000 019 080 Shroud
405 000 064 080 Mellow
406 000 065 080 Solo Sine
407 000 066 080 Sine Lead
408 000 000 081 Sawtooth Lead
409 000 006 081 Sawtooth Lead 2
410 000 008 081 Thick Sawtooth
411 000 018 081 Dynamic Sawtooth
412 000 019 081 Digital Sawtooth
Voice
No.
Bank Select
MIDI
Program
Change#
Voice Name
MSB LSB
Voice List
95
413 000 020 081 Big Lead
414 000 024 081 Heavy Synth
415 000 025 081 Waspy Synth
416 000 040 081 Pulse Sawtooth
417 000 041 081 Dr. Lead
418 000 045 081 Velocity Lead
419 000 096 081 Sequenced Analog
420 000 000 082 Calliope Lead
421 000 065 082 Pure Pad
422 000 000 083 Chiff Lead
423 000 064 083 Rubby
424 000 000 084 Charang Lead
425 000 064 084 Distorted Lead
426 000 065 084 Wire Lead
427 000 000 085 Voice Lead
428 000 024 085 Synth Aahs
429 000 064 085 Vox Lead
430 000 000 086 Fifths Lead
431 000 035 086 Big Five
432 000 000 087 Bass & Lead
433 000 016 087 Big & Low
434 000 064 087 Fat & Perky
435 000 065 087 Soft Whirl
SYNTH PAD
436 000 000 088 New Age Pad
437 000 064 088 Fantasy
438 000 000 089 Warm Pad
439 000 016 089 Thick Pad
440 000 017 089 Soft Pad
441 000 018 089 Sine Pad
442 000 064 089 Horn Pad
443 000 065 089 Rotary Strings
444 000 000 090 Poly Synth Pad
445 000 064 090 Poly Pad 80
446 000 065 090 Click Pad
447 000 066 090 Analog Pad
448 000 067 090 Square Pad
449 000 000 091 Choir Pad
450 000 064 091 Heaven
451 000 066 091 Itopia
452 000 067 091 CC Pad
453 000 000 092 Bowed Pad
454 000 064 092 Glacier
455 000 065 092 Glass Pad
456 000 000 093 Metallic Pad
457 000 064 093 Tine Pad
458 000 065 093 Pan Pad
459 000 000 094 Halo Pad
460 000 000 095 Sweep Pad
461 000 020 095 Shwimmer
462 000 027 095 Converge
463 000 064 095 Polar Pad
464 000 066 095 Celestial
SYNTH EFFECTS
465 000 000 096 Rain
466 000 045 096 Clavi Pad
467 000 064 096 Harmo Rain
468 000 065 096 African Wind
469 000 066 096 Carib
470 000 000 097 Sound Track
Voice
No.
Bank Select
MIDI
Program
Change#
Voice Name
MSB LSB
471 000 027 097 Prologue
472 000 064 097 Ancestral
473 000 000 098 Crystal
474 000 012 098 Synth Drum Comp
475 000 014 098 Popcorn
476 000 018 098 Tiny Bells
477 000 035 098 Round Glockenspiel
478 000 040 098 Glockenspiel Chimes
479 000 041 098 Clear Bells
480 000 042 098 Chorus Bells
481 000 064 098 Synth Mallet
482 000 065 098 Soft Crystal
483 000 066 098 Loud Glockenspiel
484 000 067 098 Christmas Bells
485 000 068 098 Vibraphone Bells
486 000 069 098 Digital Bells
487 000 070 098 Air Bells
488 000 071 098 Bell Harp
489 000 072 098 Gamelimba
490 000 000 099 Atmosphere
491 000 018 099 Warm Atmosphere
492 000 019 099 Hollow Release
493 000 040 099 Nylon Electric Piano
494 000 064 099 Nylon Harp
495 000 065 099 Harp Vox
496 000 066 099 Atmosphere Pad
497 000 067 099 Planet
498 000 000 100 Brightness
499 000 064 100 Fantasy Bells
500 000 096 100 Smokey
501 000 000 101 Goblins
502 000 064 101 Goblins Synth
503 000 065 101 Creeper
504 000 066 101 Ring Pad
505 000 067 101 Ritual
506 000 068 101 To Heaven
507 000 070 101 Night
508 000 071 101 Glisten
509 000 096 101 Bell Choir
510 000 000 102 Echoes
511 000 008 102 Echoes 2
512 000 014 102 Echo Pan
513 000 064 102 Echo Bells
514 000 065 102 Big Pan
515 000 066 102 Synth Piano
516 000 067 102 Creation
517 000 068 102 Star Dust
518 000 069 102 Resonant & Panning
519 000 000 103 Sci-Fi
520 000 064 103 Starz
WORLD
521 000 000 104 Sitar
522 000 032 104 Detuned Sitar
523 000 035 104 Sitar 2
524 000 096 104 Tambra
525 000 097 104 Tamboura
526 000 000 105 Banjo
527 000 028 105 Muted Banjo
528 000 096 105 Rabab
529 000 097 105 Gopichant
Voice
No.
Bank Select
MIDI
Program
Change#
Voice Name
MSB LSB
Voice List
96
●DJ Voice List
530 000 098 105 Oud
531 000 000 106 Shamisen
532 000 000 107 Koto
533 000 096 107 Taisho-kin
534 000 097 107 Kanoon
535 000 000 108 Kalimba
536 000 000 109 Bagpipe
537 000 000 110 Fiddle
538 000 000 111 Shanai
539 000 064 111 Shanai 2
540 000 096 111 Pungi
541 000 097 111 Hichiriki
PERCUSSIVE
542 000 000 112 Tinkle Bell
543 000 096 112 Bonang
544 000 097 112 Altair
545 000 098 112 Gamelan Gongs
546 000 099 112 Stereo Gamelan Gongs
547 000 100 112 Rama Cymbal
548 000 101 112 Asian Bells
549 000 000 113 Agogo
550 000 000 114 Steel Drums
551 000 097 114 Glass Percussion
552 000 098 114 Thai Bells
553 000 000 115 Woodblock
554 000 096 115 Castanets
555 000 000 116 Taiko Drum
556 000 096 116 Gran Cassa
557 000 000 117 Melodic Tom
558 000 064 117 Melodic Tom 2
559 000 065 117 Real Tom
560 000 066 117 Rock Tom
561 000 000 118 Synth Drum
562 000 064 118 Analog Tom
563 000 065 118 Electronic Percussion
564 000 000 119 Reverse Cymbal
SOUND EFFECTS
565 000 000 120 Fret Noise
566 000 000 121 Breath Noise
567 000 000 122 Seashore
568 000 000 123 Bird Tweet
569 000 000 124 Telephone Ring
570 000 000 125 Helicopter
571 000 000 126 Applause
572 000 000 127 Gunshot
573 064 000 000 Cutting Noise
574 064 000 001 Cutting Noise 2
575 064 000 003 String Slap
576 064 000 016 Flute Key Click
577 064 000 032 Shower
578 064 000 033 Thunder
579 064 000 034 Wind
580 064 000 035 Stream
581 064 000 036 Bubble
582 064 000 037 Feed
583 064 000 048 Dog
584 064 000 049 Horse
585 064 000 050 Bird Tweet 2
586 064 000 054 Ghost
Voice
No.
Bank Select
MIDI
Program
Change#
Voice Name
MSB LSB
587 064 000 055 Maou
588 064 000 064 Phone Call
589 064 000 065 Door Squeak
590 064 000 066 Door Slam
591 064 000 067 Scratch Cut
592 064 000 068 Scratch Split
593 064 000 069 Wind Chime
594 064 000 070 Telephone Ring 2
595 064 000 080 Car Engine Ignition
596 064 000 081 Car Tires Squeal
597 064 000 082 Car Passing
598 064 000 083 Car Crash
599 064 000 084 Siren
600 064 000 085 Train
601 064 000 086 Jet Plane
602 064 000 087 Starship
603 064 000 088 Burst
604 064 000 089 Roller Coaster
605 064 000 090 Submarine
606 064 000 096 Laugh
607 064 000 097 Scream
608 064 000 098 Punch
609 064 000 099 Heartbeat
610 064 000 100 Footsteps
611 064 000 112 Machine Gun
612 064 000 113 Laser Gun
613 064 000 114 Explosion
614 064 000 115 Firework
Voice
No.
Bank Select
MIDI
Program
Change#
Voice Name
MSB LSB
DJ
615 000 123 118 DJ Set 1
616 000 123 119 DJ Set 2
617 000 123 120 DJ Set 3
618 000 123 121 DJ Set 4
619 000 123 122 DJ Set 5
Voice
No.
Bank Select
MIDI
Program
Change#
Voice Name
MSB LSB
Voice List
97
●DJ Voice List
Voice No. 615 616 617 618 619
MSB/LSB/PC 0/123/118 0/123/119 0/123/120 0/123/121 0/123/122
Note No.
Note DJ Set 1 DJ Set 2 DJ Set 3 DJ Set 4 DJ Set 5
036 C 1 BD Analog H Bass Drum Soft BD Analog H BD Analog H BD Analog H
037 C#1 Analog Side Stick Side Stick Analog Side Stick Analog Side Stick Analog Side Stick
038 D 1 Analog Snare 1 Snare M Analog Snare 1 Analog Snare 1 Analog Snare 1
039 D#1 Hand Clap Hand Clap Hand Clap Hand Clap Hand Clap
040 E 1 Analog Snare 2 Snare H Hard Analog Snare 2 Analog Snare 2 Analog Snare 2
041 F 1 Analog Tom 1 Floor Tom L Analog Tom 1 Analog Tom 1 Analog Tom 1
042 F#1 Analog HH Closed 1 Hi-Hat Closed Analog HH Closed 1 Analog HH Closed 1 Analog HH Closed 1
043 G 1 Analog Tom 2 Floor Tom H Analog Tom 2 Analog Tom 2 Analog Tom 2
044 G#1 Analog HH Closed 2 Hi-Hat Pedal Analog HH Closed 2 Analog HH Closed 2 Analog HH Closed 2
045 A 1 Analog Tom 3 Low Tom Analog Tom 3 Analog Tom 3 Analog Tom 3
046 A#1 Analog HH Open Hi-Hat Open Analog HH Open Analog HH Open Analog HH Open
047 B 1 Analog Tom 4 Mid Tom L Analog Tom 4 Analog Tom 4 Analog Tom 4
048 C 2 Analog Tom 5 Mid Tom H Analog Tom 5 Analog Tom 5 Analog Tom 5
049 C#2 Analog Cymbal Crash Cymbal 1 Analog Cymbal Analog Cymbal Analog Cymbal
050 D 2 Analog Tom 6 High Tom Analog Tom 6 Analog Tom 6 Analog Tom 6
051 D#2 Ride Cymbal 1 Ride Cymbal 1 Ride Cymbal 1 Ride Cymbal 1 Ride Cymbal 1
052 E 2 Chinese Cymbal Chinese Cymbal Chinese Cymbal Chinese Cymbal Chinese Cymbal
053 F 2 Ride Cymbal Cup Ride Cymbal Cup Ride Cymbal Cup Ride Cymbal Cup Ride Cymbal Cup
054 F#2 Tambourine Tambourine Tambourine Tambourine Tambourine
055 G2
Ohh2 FX01 ORCH signal Go
056 G#2
057 A2
058 A#2
059 B2
060 C 3
061 C#3
062 D 3
063 D#3
064 E 3
065 F3
066 F#3
067 G3
068 G#3
069 A3
070 A#3
071 B3
072 C 4
FX02 Onemoretime Onemoretime Uhh-Hit Huea
073 C#4
074 D 4
075 D#4
076 E 4
077 F4
078 F#4
079 G4
080 G#4
081 A4
082 A#4
083 B4
084 C 5 Joo Go GetUp Huihu GetUp
085 C#5 Reverse Ohh2 signal Joo Reverse
086 D 5 Huihu Heau Joo ComeOn Joo
087 D#5 FXTBrs FX02 FXTBrs Onemoretime FX01
088 E 5 Huea Huihu Go Go Ohh1
089 F 5 GetUp GetUp Huihu GetUp Ohh2
090 F#5 Ohh1 Reverse FX01 Huea Onemoretime
091 G 5 Go signal ComeOn Ohh2 ComeOn
092 G#5 Scratch 1 Scratch 1 Scratch 1 Scratch 1 Scratch 1
093 A 5 Scratch 2 Scratch 2 Scratch 2 Scratch 2 Scratch 2
094 A#5 Scratch 3 Scratch 3 Scratch 3 Scratch 3 Scratch 3
095 B 5 Scratch 4 Scratch 4 Scratch 4 Scratch 4 Scratch 4
096 C 6 Scratch 5 Scratch 5 Scratch 5 Scratch 5 Scratch 5
98
Style List
Serial No. Style Name
8 BEAT
001 8BeatModern
002 60’sGtrPop
003 8BeatAdria
004 60’s8Beat
005 8Beat
006 OffBeat
007 60’sRock
008 HardRock
009 RockShuffle
010 8BeatRock
16 BEAT
011 16Beat
012 PopShuffle1
013 PopShuffle2
014 GuitarPop
015 16BtUptempo
016 KoolShuffle
017 JazzRock
018 HipHopLight
BALLAD
019 PianoBallad
020 LoveSong
021 6/8ModernEP
022 6/8SlowRock
023 OrganBallad
024 PopBallad
025 16BeatBallad1
026 16BeatBallad2
DANCE
027 EuroTrance
028 Ibiza
029 HouseMusik
030 SwingHouse
031 TechnoPolis
032 Clubdance
033 ClubLatin
034 Garage1
035 Garage2
036 TechnoParty
037 UKPop
038 HipHopGroove
039 HipShuffle
040 HipHopPop
DISCO
041 70’sDisco1
042 70’sDisco2
043 LatinDisco
044 DiscoPhilly
045 SaturdayNight
046 DiscoChocolate
047 DiscoHands
SWING & JAZZ
048 BigBandFast
049 BigBandMid
050 BigBandBallad
051 BigBandShfl
052 JazzClub
053 Swing1
054 Swing2
055 Five/Four
056 JazzBallad
057 Dixieland
058 Ragtime
059 AfroCuban
060 Charleston
R & B
061 Soul
062 DetroitPop1
063 60’sRock&Roll
064 6/8Soul
065 CrocoTwist
066 Rock&Roll
067 DetroitPop2
068 BoogieWoogie
069 ComboBoogie
070 6/8Blues
COUNTRY
071 Country8Beat
072 CountryPop
073 CountrySwing
074 Country2/4
075 CowboyBoogie
076 CountryShuffle
077 Bluegrass
LATIN
078 BrazilianSamba
079 BossaNova
080 PopBossa
081 Tijuana
082 DiscoLatin
083 Mambo
084 Salsa
085 Beguine
086 GypsyRumba
087 RmbFlamenca
088 RumbaIsland
089 Reggae
BALLROOM
090 VienneseWaltz
091 EnglishWaltz
092 Slowfox
093 Foxtrot
094 Quickstep
Serial No. Style Name
095 Tango
096 Pasodoble
097 Samba
098 ChaChaCha
099 Rumba
100 Jive
TRADITIONAL
101 USMarch
102 6/8March
103 GermanMarch
104 PolkaPop
105 OberPolka
106 Tarantella
107 Showtune
108 ChristmasSwing
109 ChristmasWaltz
110 ScottishReel
111 Hawaiian
WALTZ
112 GuitarSerenade
113 SwingWaltz
114 JazzWaltz1
115 JazzWaltz2
116 CountryWaltz
117 OberWalzer
118 Musette
DJ
119 DJ-HipHop
120 DJ-DanceSwing
121 DJ-House
122 DJ-GarageHouse
123 DJ-PopR&B
PIANIST
124 Stride
125 PianoSwing
126 PianoRag
127 Arpeggio
128 Musical
129 Habanera
130 SlowRock
131 8BeatPianoBallad
132 PianoMarch
133 6/8PianoMarch
134 PianoWaltz
135 PianoBeguine
Serial No. Style Name
99
Music Database List
MDB No. MDB Name
POP HITS
001 AlvFever
002 Croco Rk
003 DayPdise
004 EasySday
005 GoMyWay
006 HowDeep!
007 HurryLuv
008 I’m Torn
009 Imagine
010 ISurvive
011 JustCall
012 JustWay
013 NikitTrp
014 ProudGtr
015 SailngSx
016 Sept.Pop
017 SultanSw
018 SweetLrd
019 ThnkMsic
020 TitanicH
021 WatchGrl
022 WhatALoo
023 WhitePle
024 YestDGtr
SWING & JAZZ
025 Alex Rag
026 Blue Set
027 DayOfW&R
028 HighMoon
029 MistySax
030 MoonLit
031 New York
032 PanthrSw
033 PatrolBr
034 PatrolSx
035 PetiteCl
036 RedRoses
037 SaintMch
038 SatinWd
039 SaxMood
040 SF Heart
041 ShearJz
042 Showbiz
043 SplnkyTb
044 SunnySde
045 TstHoney
046 TwoFoot5
047 WhatsNew
048 Wild Cat
049 WondrLnd
EASY LISTENING
050 BlackFst
051 CaliBlue
052 CiaoCpri
053 Close2U
054 DAmorStr
055 DolanesM
056 ElCondor
057 Entrtain
058 Frippers
059 LuckySax
060 LuvStory
061 MyPrince
062 OSoleMio
063 PalomaGt
064 PuppetBr
065 Raindrop
066 RedMouln
067 R’ticGtr
068 Schiwago
069 ShadowGt
070 SingRain
071 SmallWld
072 SpkSoft
073 SpnishEy
074 StrangeN
075 TieRibbn
076 TimeGoes
077 WhteXmas
078 WishStar
079 WondrWld
ROMANTIC BALLADS
080 AdelineB
081 ArgenCry
082 BeautBdy
083 Bl Bayou
084 CatMemry
085 CavaSolo
086 E Weiss
087 ElvGhett
088 Feeling
089 Fly Away
090 Fnl Date
091 GreenSlv
092 GtCncert
093 HrdToSay
094 LonlyPan
095 MBoxDnce
096 Mn Rivr
097 Norw.Flt
098 OnMyMnd
099 OverRbow
100 Red Lady
101 ReleseMe
102 SavingLv
103 Shore Cl
104 SierraMd
105 SilverMn
106 SmokyEye
107 SndOfSil
108 TblWater
109 WhisprSx
ROCK & FUSION
110 DavAgain
111 JumpRock
112 OyComCha
113 PickUpPc
114 RdRiverR
115 SatsfyGt
116 Sheriff
117 SmokeWtr
118 TwistAgn
119 VenusPop
RHYTHM & BLUES
120 AmazingG
121 BoogiePf
122 Clock Rk
123 CU later
124 HappyDay
125 JohnnyB
126 MercyBrs
127 RisingSn
128 S Preems
129 SuperStv
130 Yeh Orgn
HIP HOP HOUSE
131 2 of US
132 B Leave
133 Back St
134 FunkyTwn
135 KillSoft
136 MiamiTrn
137 Nine PM
138 SharpRap
139 SingBack
140 StrandD
MDB No. MDB Name
LATIN NIGHTS
141 BambaBrs
142 BambaFlt
143 BeHappy!
144 CopaLola
145 DayNight
146 Ipanema
147 MarinaAc
148 MuchoTrb
149 SmoothLt
150 SunOfLif
151 Sunshine
152 Tico Org
153 TrbWave
COUNTRY & WESTERN
154 BlownWnd
155 Bonanza
156 BoxerGtr
157 CntryRds
158 GreenGrs
159 Jambala
160 LondonSt
161 LooseEL
162 TopWorld
163 YlwRose
DISCO & PARTY
164 AlhHwaii
165 Babylon
166 Barbados
167 BirdySyn
168 FestaMex
169 HandsPty
170 LuvTheme
171 ModrnTlk
172 NxtAlice
173 PalomaFl
174 PubPiano
175 Tijuana
176 Why MCA?
BALLROOM
177 BrazilBr
178 CherryBr
179 CherryOr
180 DanubeWv
181 MantoStr
182 SandmnFx
183 SundyNvr
184 TangoPiz
185 Tea4Two
186 TulipWtz
187 YesSirQk
TRADITIONAL
188 AlpenTri
189 Balalaik
190 Ceilidh
191 CielPari
192 Cl Polka
193 Comrades
194 Funiculi
195 HappyPlk
196 Herzlin
197 HornPipe
198 JinglBel
199 Kufstein
200 MexiHat
201 MickyFlt
202 NavyAway
203 RlBarrel
204 SnowWtz
205 StarMrch
206 WashPost
207 WdCuttrs
208 XmasWalz
MDB No. MDB Name
100
Drum Kit List
• “ ” indicates that the drum sound is the same as “Standard Kit 1”.
• Each percussion voice uses one note.
• The MIDI Note # and Note are actually one octave lower than keyboard Note # and Note. For example, in “123:
Standard Kit 1”, the “Seq Click H” (Note# 36/Note C1) corresponds to (Note# 24/Note C0).
• Key Off: Keys marked “O” stop sounding the instant they are released.
• Voices with the same Alternate Note Number (*1 … 4) cannot be played simultaneously. (They are designed to be
played alternately with each other.)
Voice No. 123 124 125 126 127 128
MSB/LSB/PC 127/000/000 127/000/001 127/000/008 127/000/16 127/000/24 127/000/25
Keyboard MIDI Key
Off
Alternate
assign
Standard Kit 1 Standard Kit 2 Room Kit Rock Kit Electronic Kit Analog Kit
Note# Note Note# Note
25 C#013C#-1 3 Surdo Mute
26 D 0 14 D -1 3 Surdo Open
27 D#015D#-1 Hi Q
28 E 0 16 E -1 Whip Slap
29 F 0 17 F -1 4 Scratch Push
30 F#018F#-1 4 Scratch Pull
31 G 0 19 G -1 Finger Snap
32 G#020G#-1 Click Noise
33 A 0 21 A -1 Metronome Click
34 A#022A#-1 Metronome Bell
35 B 0 23 B -1 Seq Click L
36 C 1 24 C 0 Seq Click H
37 C#125C#0 Brush Tap
38 D 1 26 D 0 O Brush Swirl
39 D#127D#0 Brush Slap
40 E 1 28 E 0 O Brush Tap Swirl Reverse Cymbal Reverse Cymbal
41 F 1 29 F 0 O Snare Roll
42 F#130F#0 Castanet Hi Q 2 Hi Q 2
43 G 1 31 G 0 Snare H Soft Snare H Soft 2 SD Rock H Snare L SD Rock H
44 G#132G#0 Sticks
45 A 1 33 A 0 Bass Drum Soft Bass Drum H Bass Drum H
46 A#134A#0 Open Rim Shot Open Rim Shot 2
47 B 1 35 B 0 Bass Drum Hard Bass Drum H BD Rock BD Analog L
48 C 2 36 C 1 Bass Drum Bass Drum 2 BD Rock BD Gate BD Analog H
49 C#237C#1 Side Stick Analog Side Stick
50 D 2 38 D 1 Snare M Snare M 2 SD Room L SD Rock L SD Rock L Analog Snare 1
51 D#239D#1 Hand Clap
52 E 2 40 E 1 Snare H Hard Snare H Hard 2 SD Room H SD Rock Rim SD Rock H Analog Snare 2
53 F 2 41 F 1 Floor Tom L Room Tom 1 Rock Tom 1 E Tom 1 Analog Tom 1
54 F#242F#1 1 Hi-Hat Closed Analog HH Closed 1
55 G 2 43 G 1 Floor Tom H Room Tom 2 Rock Tom 2 E Tom 2 Analog Tom 2
56 G#244G#1 1 Hi-Hat Pedal Analog HH Closed 2
57 A 2 45 A 1 Low Tom Room Tom 3 Rock Tom 3 E Tom 3 Analog Tom 3
58 A#246A#1 1 Hi-Hat Open Analog HH Open
59 B 2 47 B 1 Mid Tom L Room Tom 4 Rock Tom 4 E Tom 4 Analog Tom 4
60 C 3 48 C 2 Mid Tom H Room Tom 5 Rock Tom 5 E Tom 5 Analog Tom 5
61 C#349C#2 Crash Cymbal 1 Analog Cymbal
62 D 3 50 D 2 High Tom Room Tom 6 Rock Tom 6 E Tom 6 Analog Tom 6
63 D#351D#2 Ride Cymbal 1
64 E 3 52 E 2 Chinese Cymbal
65 F 3 53 F 2 Ride Cymbal Cup
66 F#354F#2 Tambourine
67 G 3 55 G 2 Splash Cymbal
68 G#356G#2 Cowbell Analog Cowbell
69 A 3 57 A 2 Crash Cymbal 2
70 A#358A#2 Vibraslap
71 B 3 59 B 2 Ride Cymbal 2
72 C 4 60 C 3 Bongo H
73 C#461C#3 Bongo L
74 D 4 62 D 3 Conga H Mute Analog Conga H
75 D#463D#3 Conga H Open Analog Conga M
76 E 4 64 E 3 Conga L Analog Conga L
77 F 4 65 F 3 Timbale H
78 F#466F#3 Timbale L
79 G 4 67 G 3 Agogo H
80 G#468G#3 Agogo L
81 A 4 69 A 3 Cabasa
82 A#470A#3 Maracas Analog Maracas
83 B 4 71 B 3 O Samba Whistle H
84 C 5 72 C 4 O Samba Whistle L
85 C#573C#4 Guiro Short
86 D 5 74 D 4 O Guiro Long
87 D#575D#4 Claves Analog Claves
88 E 5 76 E 4 Wood Block H
89 F 5 77 F 4 Wood Block L
90 F#578F#4 Cuica Mute Scratch Push Scratch Push
91 G 5 79 G 4 Cuica Open Scratch Pull Scratch Pull
92 G#580G#4 2 Triangle Mute
93 A 5 81 A 4 2 Triangle Open
94 A#582A#4 Shaker
95 B 5 83 B 4 Jingle Bell
96 C 6 84 C 5 Bell Tree
97 C#685C#5
98 D 6 86 D 5
99 D#687D#5
100 E 6 88 E 5
101 F 6 89 F 5
102 F#690F#5
103 G 6 91 G 5
C1
F1
B1
D1
C#1
D#1
G1
G#1
A1
A#1
F#1
E1
F0
B0
D0
C#0
D#0
G0
G#0
A0
A#0
F#0
E0
C2
F2
B2
D2
C#2
D#2
G2
G#2
A2
A#2
F#2
E2
C3
F3
B3
D3
C#3
D#3
G3
G#3
A3
A#3
F#3
E3
C4
F4
B4
D4
C#4
D#4
G4
G#4
A4
A#4
F#4
E4
C5
F5
B5
D5
C#5
D#5
G5
G#5
A5
A#5
F#5
E5
C6
F6
D6
C#6
D#6
G6
F#6
E6
Drum Kit List
101
Voice No. 123 129 130 131 132 133 134
MSB/LSB/PC 127/000/000 127/000/27 127/000/32 127/000/40 127/000/48 126/000/000 126/000/001
Keyboard MIDI Key
Off
Alternate
assign
Standard Kit 1 Dance Kit Jazz Kit Brush Kit Symphony Kit SFX Kit 1 SFX Kit 2
Note# Note Note# Note
25 C#013C#-1 3 Surdo Mute
26 D 0 14 D -1 3 Surdo Open
27 D#015D#-1 Hi Q
28 E 0 16 E -1 Whip Slap
29 F 0 17 F -1 4 Scratch Push
30 F#018F#-1 4 Scratch Pull
31 G 0 19 G -1 Finger Snap
32 G#020G#-1 Click Noise
33 A 0 21 A -1 Metronome Click
34 A#022A#-1 Metronome Bell
35 B 0 23 B -1 Seq Click L
36 C 1 24 C 0 Seq Click H
37 C#125C#0 Brush Tap
38 D 1 26 D 0 O Brush Swirl
39 D#127D#0 Brush Slap
40 E 1 28 E 0 O Brush Tap Swirl Reverse Cymbal
41 F 1 29 F 0 O Snare Roll
42 F#130F#0 Castanet Hi Q 2
43 G 1 31 G 0 Snare H Soft AnSD Snappy
SD Jazz H Light
Brush Slap L
44 G#132G#0 Sticks
45 A 1 33 A 0 Bass Drum Soft AnBD Dance-1 Bass Drum L
46 A#134A#0 Open Rim Shot AnSD OpenRim
47 B 1 35 B 0 Bass Drum Hard AnBD Dance-2 Gran Cassa
48 C 2 36 C 1 Bass Drum AnBD Dance-3 BD Jazz BD Jazz Gran Cassa Mute
Cutting Noise
Phone Call
49 C#237C#1 Side Stick
Analog Side Stick
Cutting Noise 2
Door Squeak
50 D 2 38 D 1 Snare M AnSD Q SD Jazz L Brush Slap Marching Sn M Door Slam
51 D#239D#1 Hand Clap String Slap Scratch Cut
52 E 2 40 E 1 Snare H Hard
AnSD Ana+Acoustic
SD Jazz M Brush Tap Marching Sn H Scratch
53 F 2 41 F 1 Floor Tom L Analog Tom 1 Jazz Tom 1 Brush Tom 1 Jazz Tom 1 Wind Chime
54 F#242F#1 1 Hi-Hat Closed
Analog HH Closed 3
Telephone Ring 2
55 G 2 43 G 1 Floor Tom H Analog Tom 2 Jazz Tom 2 Brush Tom 2 Jazz Tom 2
56 G#244G#1 1 Hi-Hat Pedal
Analog HH Closed 4
57 A 2 45 A 1 Low Tom Analog Tom 3 Jazz Tom 3 Brush Tom 3 Jazz Tom 3
58 A#246A#1 1 Hi-Hat Open
Analog HH Open 2
59 B 2 47 B 1 Mid Tom L Analog Tom 4 Jazz Tom 4 Brush Tom 4 Jazz Tom 4
60 C 3 48 C 2 Mid Tom H Analog Tom 5 Jazz Tom 5 Brush Tom 5 Jazz Tom 5
61 C#349C#2 Crash Cymbal 1 Analog Cymbal Hand Cym. L
62 D 3 50 D 2 High Tom Analog Tom 6 Jazz Tom 6 Brush Tom 6 Jazz Tom 6
63 D#351D#2 Ride Cymbal 1 Hand Cym.Short L
64 E 3 52 E 2 Chinese Cymbal
Flute Key Click
Car Engine Ignition
65 F 3 53 F 2 Ride Cymbal Cup
Car Tires Squeal
66 F#354F#2 Tambourine Car Passing
67 G 3 55 G 2 Splash Cymbal Car Crash
68 G#356G#2 Cowbell Analog Cowbell Siren
69 A 3 57 A 2 Crash Cymbal 2 Hand Cym. H Train
70 A#358A#2 Vibraslap Jet Plane
71 B 3 59 B 2 Ride Cymbal 2 Hand Cym.Short H Starship
72 C 4 60 C 3 Bongo H Burst
73 C#461C#3 Bongo L Roller Coaster
74 D 4 62 D 3 Conga H Mute Analog Conga H Submarine
75 D#463D#3 Conga H Open Analog Conga M
76 E 4 64 E 3 Conga L Analog Conga L
77 F 4 65 F 3 Timbale H
78 F#466F#3 Timbale L
79 G 4 67 G 3 Agogo H
80 G#468G#3 Agogo L Shower Laugh
81 A 4 69 A 3 Cabasa Thunder Scream
82 A#470A#3 Maracas Analog Maracas Wind Punch
83 B 4 71 B 3 O Samba Whistle H Stream Heartbeat
84 C 5 72 C 4 O Samba Whistle L Bubble FootSteps
85 C#573C#4 Guiro Short Feed
86 D 5 74 D 4 O Guiro Long
87 D#575D#4 Claves Analog Claves
88 E 5 76 E 4 Wood Block H
89 F 5 77 F 4 Wood Block L
90 F#578F#4 Cuica Mute Scratch Push
91 G 5 79 G 4 Cuica Open Scratch Pull
92 G#580G#4 2 Triangle Mute
93 A 5 81 A 4 2 Triangle Open
94 A#582A#4 Shaker
95 B 5 83 B 4 Jingle Bell
96 C 6 84 C 5 Bell Tree Dog Machine Gun
97 C#685C#5 Horse Laser Gun
98 D 6 86 D 5 Bird Tweet 2 Explosion
99 D#687D#5 Firework
100 E 6 88 E 5
101 F 6 89 F 5
102 F#690F#5 Ghost
103 G 6 91 G 5 Maou
C1
F1
B1
D1
C#1
D#1
G1
G#1
A1
A#1
F#1
E1
F0
B0
D0
C#0
D#0
G0
G#0
A0
A#0
F#0
E0
C2
F2
B2
D2
C#2
D#2
G2
G#2
A2
A#2
F#2
E2
C3
F3
B3
D3
C#3
D#3
G3
G#3
A3
A#3
F#3
E3
C4
F4
B4
D4
C#4
D#4
G4
G#4
A4
A#4
F#4
E4
C5
F5
B5
D5
C#5
D#5
G5
G#5
A5
A#5
F#5
E5
C6
F6
D6
C#6
D#6
G6
F#6
E6
102
MIDI Implementation Chart
YAMAHA [ Portable Grand™ ] Date:12-MAR-2002
Model DGX-500,DGX-300 MIDI Implementation Chart Version : 1.0
Transmitted Recognized Remarks
Function...
Basic Default 1 - 16 1 - 16 *1
Channel Changed x x
Default 3 3
Mode Messages x x
Altered ************** x
Note 0 - 127 0 - 127
Number : True voice ************** 0 - 127
Velocity Note ON o 9nH,v=1-127 o 9nH,v=1-127
Note OFF o 9nH,v=0 o 9nH,v=0 or 8nH
After Key's x x
Touch Ch's x x
Pitch Bend x o
0,32 o o Bank Select
1 x *2 o Modulation wheel
6 o o Data Entry
38 x *2 o Data Entry
7 o o Part Volume
Control 10 o o Pan
11 x *2 o Expression
Change 64 o o Sustain
71 x *2 o Harmonic Content
72 x *2 o Release Time
73 x *2 o Attack Time
74 x *2 o Brightness
91,93,94 o o Effect Depth
96,97 x o RPN Inc,Dec
100,101 x *2 o RPN LSB,MSB
84 x *2 o Portamento Cntrl
Prog o 0 - 127 o 0 - 127
Change : True # **************
System Exclusive o *3 o *3
: Song Pos. x x
Common : Song Sel. x x
: Tune x x
System : Clock o o
Real Time: Commands o *4 o *4
Aux :All Sound OFF o o(120,126,127)
:Reset All Cntrls x o(121)
:Local ON/OFF x o(122) *5
:All Notes OFF x o(123-125)
Mes- :Active Sense o o
sages:Reset x x
Mode 1 : OMNI ON , POLY Mode 2 : OMNI ON ,MONO o : Yes
Mode 3 : OMNI OFF, POLY Mode 4 : OMNI OFF,MONO x : No
MIDI Implementation Chart
103
NOTE:
*1 By default (factory settings) the DGX-500/300 ordinarily functions as a 16-
channel multi-timbral tone generator, and incoming data does not affect
the panel voices or panel settings. However, the MIDI messages listed
below do affect the panel voices, auto accompaniment, and songs.
• MIDI Master Tuning
• System exclusive messages for changing the Reverb Type, Chorus
Type, and DSP Type.
*2 Messages for these control change numbers cannot be transmitted from
the DGX-500/300 itself. However, they may be transmitted when playing
the accompaniment, song or using the Harmony effect.
*3 Exclusive
<GM System ON> F0H, 7EH, 7FH, 09H, 01H, F7H
• This message automatically restores all default settings for the instru-
ment, with the exception of MIDI Master Tuning.
<MIDI Master Volume> F0H, 7FH, 7FH, 04H, 01H, ll, mm, F7H
• This message allows the volume of all channels to be changed simul-
taneously (Universal System Exclusive).
• The values of “mm” is used for MIDI Master Tuning. (Values for “ll” are
ignored.)
<MIDI Master Tuning> F0H, 43H, 1nH, 27H, 30H, 00H, 00H, mm, ll, cc,
F7H
• This message simultaneously changes the tuning value of all chan-
nels.
• The values of “mm” and “ll” are used for MIDI Master Tuning.
• The default value of “mm” and “ll” are 08H and 00H, respectively. Any
values can be used for “n” and “cc.”
<Reverb Type> F0H, 43H, 1nH, 4CH, 02H, 01H, 00H, mmH, llH, F7H
• mm : Reverb Type MSB
• ll : Reverb Type LSB
Refer to the Effect Map (page 104) for details.
<Chorus Type> F0H, 43H, 1nH, 4CH, 02H, 01H, 20H, mmH, llH, F7H
• mm : Chorus Type MSB
• ll : Chorus Type LSB
Refer to the Effect Map (page 104) for details.
<DSP Type> F0H, 43H, 1nH, 4CH, 02H, 01H, 40H, mmH, llH, F7H
• mm : DSP Type MSB
• ll : DSP Type LSB
Refer to the Effect Map (page 104) for details.
<DRY Level> F0H, 43H, 1nH, 4CH, 08H, 0mH, 11H, llH, F7H
• ll : Dry Level
• 0m : Channel Number
*4 When the accompaniment is started, an FAH message is transmitted.
When accompaniment is stopped, an FCH message is transmitted.When
the clock is set to External, both FAH (accompaniment start) and FCH
(accompaniment stop) are recognized.
*5 Local ON/OFF
<Local ON> Bn, 7A, 7F
<Local OFF> Bn, 7A, 00
Value for “n” is ignored.
MIDI Implementation Chart
104
● REVERB
● CHORUS
● DSP
TYPE
MSB
TYPE LSB
00 01 02 08 16 17 18 19 20
000 No Effect
001 (1)Hall1 (2)Hall2
002 Room (3)Room1 (4)Room2
003 Stage (5)Stage1 (6)Stage2
004 Plate (7)Plate1 (8)Plate2
005...127 No Effect
TYPE
MSB
TYPE LSB
00 01 02 08 16 17 18 19 20
000...064 No Effect
065 Chorus Chorus2
066 Celeste Chorus1
067 Flanger Flanger1 Flanger2
068...127 No Effect
TYPE
MSB
TYPE LSB
00 01 02 08 16 17 18 19 20
000 No Effect
001 (1)Hall1 (2)Hall2
002 Room (3)Room1 (4)Room2
003 Stage (5)Stage1 (6)Stage2
004 Plate (7)Plate1 (8)Plate2
005 Delay L,C,R (26)Delay L,C,R
006 (27)Delay L,R
007 (28)Echo
008 (29)Cross Delay
009
(9)Early Reflection1 (10)Early Reflection2
010 (11)Gate Reverb
011 (12)Reverse Gate
012...019 No Effect
020 (30)Karaoke
021...064 No Effect
065 Chorus (14)Chorus2
066 Celeste (13)Chorus1
067 Flanger
(15)Flanger1
(16)Flanger2
068 Symphonic (17)Symphonic
069 Rotary Speaker
(19)Rotary Speaker1
070 Tremolo (21)Tremolo1
071 Auto Pan (24)Auto Pan
(20)Rotary Speaker2
(22)Tremolo2
(23)Guitar Tremolo
072 (18)Phaser
073 Distortion
074 (33)Overdrive
075
(34)Amp Simulation
(31)Distortion Hard
(32)Distortion Soft
076 (37)3Band EQ (35)EQ Disco
(36)EQ Telephone
077 (38)2Band EQ
078 Auto Wah (25)Auto Wah
079...127 No Effect
■Effect map
* If the received value does not contain an effect type in the TYPE LSB, the LSB will be directed to TYPE 0.
* The numbers in parentheses in front of the Effect Type names correspond to the number indicated in the display.
* By using an external sequencer, which is capable of editing and transmitting the system exclusive messages and param-
eter changes, you can select the Reverb, Chorus and DSP effect types which are not accessible from the DGX-500/300
panel itself. When one of the effects is selected by the external sequencer, “ - ” will be shown on the display.
105
• Be careful not to confuse parts, and be sure to install all parts in the
correct direction. Please assemble in accordance with the sequence
given below.
• Assembly should be carried out by at least two persons.
• Be sure to use the correct screw size, as indicated above. Use of
incorrect screws can cause damage.
• Be sure to tighten all screws upon completing assembly of each unit.
• To disassemble, reverse the assembly sequence given below.
The parts shown in the “Assembly Parts” illustration will
be used. Follow the assembly instructions and select
the parts as needed.
Keyboard Stand Assembly (DGX-500 only)
Have a phillips-head (+) screwdriver ready.
w Joint connectors
q 6 x 70 mm round head screws
ZAttach the stand bases.
Making sure that the boards are facing the proper direc-
tion (the holes should face inside), insert the joint connec-
tors w into the holes as shown. The joint connectors have
been installed properly if you can see a plus mark on the
connector.
Attach the stand bases to the rear of the side boards,
using the 6 x 70 mm round head screws q.
1
q6 x 70 mm round head screws (4 pcs.)
wJoint connectors (4 pcs.)
e3.5 x 16 mm tapping screws (12 pcs.)
r6 x 30 mm round head screws (4 pcs.)
t5 x 16 mm round head screws (4 pcs.)
yAngle brackets (4 pcs.)
Back board
Side boards
Stand bases
■ Assembly Parts (DGX-500 only)
106
XAttach the angle brackets.
Attach the angle brackets y to the side boards using
the 3.5 x 16 mm tapping screws e.
2
CAttach the back board.
Attach the back board, using the 6 x 30 mm round head
screws r.
• Be careful not to drop the back board or touch the sharp metal
fittings.
3
y Angle brackets
e 3.5 x 16 mm tapping screws
r 6 x 30 mm round head screws
107
VPut the keyboard on the stand.
Carefully place the keyboard on the side boards.
Slowly move the keyboard so that the holes on the bot-
tom of the keyboard are properly aligned with the holes on
the angle brackets.
• Be careful not to drop the keyboard or to get your fingers
caught between the keyboard and the stand parts.
4
BInstall the keyboard to the stand.
Fix the keyboard to the angle brackets, using the 5 x 16
mm round head screws t.
■Post-assembly checklist
Once you’ve assembled the stand, check the following
points:
• Are there any parts left over?
➔If so, read the assembly instructions again and correct
any errors you might have made.
• Is the instrument clear of doors and other movable fixtures?
➔If not, move the instrument to an appropriate location.
• Does the instrument make a rattling noise when you play it
or move it?
➔If so, properly tighten all screws.
• Also, if the keyboard makes a creaking noise or seems
unsteady when you play it, refer carefully to the assembly
instructions and diagrams and retighten all screws.
5
t 5 x 16 mm round head screws
108
Specifications
Keyboards
• DGX-500......88 standard-size keys (A-1 - C7), with Touch
Response and Dynamic Filter.
• DGX-300......76 standard-size keys (E0 - G6), with Touch
Response and Dynamic Filter.
Display
• Large multi-function LCD display (backlit)
Setup
• STANDBY/ON
• MASTER VOLUME : MIN - MAX
Panel Controls
• OVERALL (L, R), SONG, VOICE, STYLE, M.D.B.,
PORTABLE GRAND, SPLIT, METRONOME, [0]-[9],
[+](YES), [-](NO), DEMO, TOUCH, HARMONY, DUAL,
DICTIONARY, L, R, TEMPO/TAP
Voice
• 122 panel voices + 12 drum kits + 480 XG voices + 5 DJ voices
• Polyphony : 32
STYLE
• 135 styles + Disk
• Accompaniment Control : ACMP, SYNC STOP,
SYNC START, START/STOP,
INTRO ENDING,
MAIN/AUTO FILL
• Fingering : Multi fingering
• Accompaniment Volume
Music Database
• 208
Yamaha Educational Suite
• Dictionary
• Lesson 1-4
One Touch Setting
• Voice (for each style or song)
Overall controls
Effects
• Reverb : 8 types
• DSP : 38 types
• Harmony : 26 types
Song
• 100 Songs + 5 User Songs
• Song Clear, Track Clear
Recording
• Song
User Song : 5 Songs
Recording Tracks : 1, 2, 3, 4, 5, Accompaniment
Disk
• Song Playback
• Save
• Load
• Delete
• Format
MIDI
• Initial Send
• Local on/off
Auxiliary jacks
• PHONES/OUTPUT, DC IN 12V, MIDI IN/OUT,
FOOT SWITCH
Amplifier
• 6.0W + 6.0W
Speakers
• 12cm x 2 + 3cm x 2
Power Consumption
• UL / CSA : 19W
• CE : 18W
(when using PA-5D or PA-5C power adaptor)
Power Supply
• Adaptor : Yamaha PA-5D or PA-5C AC power adaptor
• Batteries :
Six “D” size, R20P (LR20) or equivalent batteries
Dimensions (W x D x H)
• DGX-500 ............... 1,380 x 430 x 173 mm
(54-1/3" x 16-15/16" x 6-3/4")
• DGX-300 ............... 1,178 x 410 x 168 mm
(46-3/8" x 16-1/8" x 6-5/8")
Weight
• DGX-500 ............... 14 kg (30 lbs., 14 oz.)
DGX-500 Stand..... 7.6 kg (16 lbs., 12.)
• DGX-300 ............... 10 kg (22 lbs., 1 oz.)
Supplied Accessories
• DGX-500 ............... Keyboard stand
Footswitch
Music Rest
Data Disk
Owner’s Manual
Song Book
• DGX-300 ............... Music Rest
Data Disk
Owner’s Manual
Song Book
* Specifications and descriptions in this owner’s manual are for information
purposes only. Yamaha Corp. reserves the right to change or modify prod-
ucts or specifications at any time without prior notice. Since specifications,
equipment or options may not be the same in every locale, please check
with your Yamaha dealer.
• Transpose
• Accompaniment/Song Volume
• Metronome Volume
• PITCH BEND RANGE
• Tuning
• MIDI
• Harmony
• Reverb
• DSP
• Grade
• Lesson Track L/R
• Track Octave
Optional Accessories
• DGX-500
• Headohones : HPE-150
• AC power adapter : PA-5D, PA-5C
• DGX-300
• Headphones : HPE-150
• AC power adaptor : PA-5D, PA-5C
• Footswitch : FC4, FC5
• Keyboard stand : LG-100
109
Misc.
+/- buttons........................................25
A
AC Power adaptor............................10
accessory jacks ................................11
accompaniment sections..................45
Accompaniment Split Point.............49
Accompaniment Track.....................63
Accompaniment Volume .................46
accompaniment, playing..................39
Auto Accompaniment......................38
B
Bank.................................................55
Batteries...........................................10
Beat display .....................................57
beat marks........................................57
C
Chord Names ...................................52
Chord Type ......................................52
Chords, About..................................51
Chords, Fingered .............................47
Chords, Single Finger......................47
Clearing, Song .................................65
D
DEMO button ..................................14
Demo songs .....................................14
Dictionary ........................................50
DISK ORCHESTRA .......................73
DJ Voice List....................................97
Drum Kit Voice Chart....................100
DSP..................................................34
DSP types ........................................36
Dual Voice DSP ...............................27
Dual Voice Octave ...........................27
Dual Voice Reverb ...........................27
Dual Voice Select.............................27
Dual Voice Volume ..........................27
E
Effects..............................................33
Ending..............................................39
External clock..................................88
F
Fill-in ...............................................45
Fingered chords ...............................47
Footswitch .......................................11
G
GM System Level 1.........................83
Grade ...............................................72
H
Harmony ......................................... 35
HARMONY button......................... 35
Harmony types................................ 37
Headphones..................................... 11
I
Indicator .......................................... 20
Initial Setup Send............................ 87
Initialization .................................... 90
Intro................................................. 41
K
Keyboard stand assembly
(DGX-500 only)............................ 105
L
Lesson ............................................. 67
M
M.D.B. (music database) ................ 53
Main Voice DSP.............................. 27
Main Voice Reverb.......................... 27
Main Voice Volume ......................... 27
Metronome...................................... 22
MIDI ............................................... 83
MIDI channels ................................ 84
MIDI Implementation Chart ......... 102
MIDI LSB Receive cancel .............. 88
MIDI terminals ............................... 84
Multi Fingering ............................... 47
MUSIC DATABASE....................... 53
Music Rest ...................................... 21
N
numeric keypad............................... 25
O
One Touch Setting........................... 28
Overall buttons................................ 20
P
PHONES/OUTPUT jack .................. 9
Pitch Bend....................................... 31
Portable Grand ................................ 22
Q
Quick Guide.................................... 12
R
RECORD button ............................. 62
recording, song................................ 62
Registration Memory ...................... 55
Reverb ............................................. 33
Reverb types.................................... 36
Root................................................. 51
S
sections (accompaniment)............... 45
Single Finger chords .......................47
Song Clear....................................... 65
SONG MEMORY ........................... 63
song recording................................. 62
Song Volume ................................... 61
songs, recording .............................. 62
songs, selecting and playing............ 57
Specifications ................................ 108
Split ................................................. 28
Split Point........................................ 49
STYLE FILE................................... 73
styles, selecting ...............................38
SUSUTAIN ..................................... 11
Sync Start ........................................ 40
Sync Stop ........................................43
T
Tap ................................................... 40
Tempo (song)................................... 60
Tempo (style)................................... 44
Time Signature ................................ 23
TOUCH button ................................ 32
Touch Sensitivity............................. 32
track (song)...................................... 63
Track Octave ................................... 76
tracks, muting.................................. 63
Transpose ........................................ 29
Troubleshooting .............................. 89
Tuning ............................................. 29
U
User songs ....................................... 62
V
Voice List......................................... 91
voices, Drum Kit ........................... 100
voices, selecting and playing........... 24
voices, XG....................................... 92
X
XG voices........................................ 92
Index
Limited Warranty
90 DAYS LABOR 1 YEAR PARTS
Yamaha Corporation of America, hereafter referred to as Yamaha, warrants to the original consumer of a product included in the categories listed
below, that the product will be free of defects in materials and/or workmanship for the periods indicated. This warranty is applicable to all models
included in the following series of products:
SERIES OF ELECTRONIC KEYBOARDS
If during the first 90 days that immediately follows the purchase date, your new Yamaha product covered by this warranty is found to have a defect
in material and/or workmanship, Yamaha and/or its authorized representative will repair such defect without charge for parts or labor.
If parts should be required after this 90 day period but within the one year period that immediately follows the purchase date, Yamaha will, subject
to the terms of this warranty, supply these parts without charge. However, charges for labor, and/or any miscellaneous expenses incurred are the
consumers responsibility. Yamaha reserves the right to utilize reconditioned parts in repairing these products and/or to use reconditioned units as
warranty replacements.
THIS WARRANTY IS THE ONLY EXPRESS WARRANTY WHICH YAMAHA MAKES IN CONNECTION WITH THESE PROD-
UCTS. ANY IMPLIED WARRANTY APPLICABLE TO THE PRODUCT, INCLUDING THE WARRANTY OF MERCHANT ABILITY
IS LIMITED TO THE DURATION OF THE EXPRESS WARRANTY. YAMAHA EXCLUDES AND SHALL NOT BE LIABLE IN ANY
EVENT FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES.
Some states do not allow limitations that relate to implied warranties and/or the exclusion of incidental or consequential damages. Therefore, these
limitations and exclusions may not apply to you.
This warranty gives you specific legal rights. You may also have other rights which vary from state to state.
CONSUMERS RESPONSIBILITIES
If warranty service should be required, it is necessary that the consumer assume certain responsibilities:
1. Contact the Customer Service Department of the retailer selling the product, or any retail outlet authorized by Yamaha to sell the product for
assistance. You may also contact Yamaha directly at the address provided below.
2. Deliver the unit to be serviced under warranty to: the retailer selling the product, an authorized service center, or to Yamaha with an explanation
of the problem. Please be prepared to provide proof purchase date (sales receipt, credit card copy, etc.) when requesting service and/or parts
under warranty.
3. Shipping and/or insurance costs are the consumers responsibility.* Units shipped for service should be packed securely.
*Repaired units will be returned PREPAID if warranty service is required within the first 90 days.
IMPORTANT: Do NOT ship anything to ANY location without prior authorization. A Return Authorization (RA) will be issued that has
a tracking number assigned that will expedite the servicing of your unit and provide a tracking system if needed.
4. Your owners manual contains important safety and operating instructions. It is your responsibility to be aware of the contents of this manual and
to follow all safety precautions.
EXCLUSIONS
This warranty does not apply to units whose trade name, trademark, and/or ID numbers have been altered, defaced, exchanged removed, or to fail-
ures and/or damages that may occur as a result of:
1. Neglect, abuse, abnormal strain, modification or exposure to extremes in temperature or humidity.
2. Improper repair or maintenance by any person who is not a service representative of a retail outlet authorized by Yamaha to sell the product, an
authorized service center, or an authorized service representative of Yamaha.
3. This warranty is applicable only to units sold by retailers authorized by Yamaha to sell these products in the U.S.A., the District of Columbia,
and Puerto Rico. This warranty is not applicable in other possessions or territories of the U.S.A. or in any other country.
Please record the model and serial number of the product you have purchased in the spaces provided below.
Model___________________________ Serial #________________________________ Sales Slip #________________________________
Purchased from____________________________________________________________ Date______________________________________
(Retailer)
YAMAHA CORPORATION OF AMERICA
Electronic Service Division
6600 Orangethorpe Avenue
Buena Park, CA 90620
KEEP THIS DOCUMENT FOR YOUR RECORDS. DO NOT MAIL!
HEAD OFFICE Yamaha Corporation, Pro Audio & Digital Musical Instrument Division
Nakazawa-cho 10-1, Hamamatsu, Japan 430-8650
Tel: 053-460-3273
[PK] 22
For details of products, please contact your nearest Yamaha or the
authorized distributor listed below.
Pour plus de détails sur les produits, veuillez-vous adresser à Yamaha ou
au distributeur le plus proche de vous figurant dans la liste suivante.
Die Einzelheiten zu Produkten sind bei Ihrer unten aufgeführten
Niederlassung und bei Yamaha Vertragshändlern in den jeweiligen
Bestimmungsländern erhältlich.
Para detalles sobre productos, contacte su tienda Yamaha más cercana
o el distribuidor autorizado que se lista debajo.
CANADA
Yamaha Canada Music Ltd.
135 Milner Avenue, Scarborough, Ontario,
M1S 3R1, Canada
Tel: 416-298-1311
U.S.A.
Yamaha Corporation of America
6600 Orangethorpe Ave., Buena Park, Calif. 90620,
U.S.A.
Tel: 714-522-9011
MEXICO
Yamaha de Mexico S.A. De C.V.,
Departamento de ventas
Javier Rojo Gomez No.1149, Col. Gpe Del
Moral, Deleg. Iztapalapa, 09300 Mexico, D.F.
Tel: 686-00-33
BRAZIL
Yamaha Musical do Brasil LTDA.
Av. Rebouças 2636, São Paulo, Brasil
Tel: 011-853-1377
ARGENTINA
Yamaha de Panamá S.A. Sucursal de Argentina
Viamonte 1145 Piso2-B 1053,
Buenos Aires, Argentina
Tel: 1-4371-7021
PANAMA AND OTHER LATIN
AMERICAN COUNTRIES/
CARIBBEAN COUNTRIES
Yamaha de Panamá S.A.
Torre Banco General, Piso 7, Urbanización Marbella,
Calle 47 y Aquilino de la Guardia,
Ciudad de Panamá, Panamá
Tel: 507-269-5311
THE UNITED KINGDOM
Yamaha-Kemble Music (U.K.) Ltd.
Sherbourne Drive, Tilbrook, Milton Keynes,
MK7 8BL, England
Tel: 01908-366700
IRELAND
Danfay Ltd.
61D, Sallynoggin Road, Dun Laoghaire, Co. Dublin
Tel: 01-2859177
GERMANY/SWITZERLAND
Yamaha Europa GmbH.
Siemensstraße 22-34, 25462 Rellingen,
F.R. of Germany
Tel: 04101-3030
AUSTRIA
Yamaha Music Austria
Schleiergasse 20, A-1100 Wien Austria
Tel: 01-60203900
THE NETHERLANDS
Yamaha Music Nederland
Kanaalweg 18G, 3526KL, Utrecht, The Netherlands
Tel: 030-2828411
BELGIUM
Yamaha Music Belgium
Keiberg Imperiastraat 8, 1930 Zaventem, Belgium
Tel: 02-7258220
FRANCE
Yamaha Musique France,
Division Claviers
BP 70-77312 Marne-la-Vallée Cedex 2, France
Tel: 01-64-61-4000
ITALY
Yamaha Musica Italia S.P.A.
Viale Italia 88, 20020 Lainate (Milano), Italy
Tel: 02-935-771
SPAIN/PORTUGAL
Yamaha-Hazen Electronica Musical, S.A.
Ctra. de la Coruna km. 17, 200, 28230
Las Rozas (Madrid) Spain
Tel: 91-201-0700
GREECE
Philippe Nakas S.A.
Navarinou Street 13, P.Code 10680, Athens, Greece
Tel: 01-364-7111
SWEDEN
Yamaha Scandinavia AB
J. A. Wettergrens Gata 1
Box 30053
S-400 43 Göteborg, Sweden
Tel: 031 89 34 00
DENMARK
YS Copenhagen Liaison Office
Generatorvej 8B
DK-2730 Herlev, Denmark
Tel: 44 92 49 00
FINLAND
F-Musiikki Oy
Kluuvikatu 6, P.O. Box 260,
SF-00101 Helsinki, Finland
Tel: 09 618511
NORWAY
Norsk filial av Yamaha Scandinavia AB
Grini Næringspark 1
N-1345 Østerås, Norway
Tel: 67 16 77 70
ICELAND
Skifan HF
Skeifan 17 P.O. Box 8120
IS-128 Reykjavik, Iceland
Tel: 525 5000
OTHER EUROPEAN COUNTRIES
Yamaha Europa GmbH.
Siemensstraße 22-34, 25462 Rellingen,
F.R. of Germany
Tel: 04101-3030
Yamaha Corporation,
Asia-Pacific Music Marketing Group
Nakazawa-cho 10-1, Hamamatsu, Japan 430-8650
Tel: 053-460-2312
TURKEY/CYPRUS
Yamaha Europa GmbH.
Siemensstraße 22-34, 25462 Rellingen,
F.R. of Germany
Tel: 04101-3030
OTHER COUNTRIES
Yamaha Music Gulf FZE
LB21-128 Jebel Ali Freezone
P.O.Box 17328, Dubai, U.A.E.
Tel: 971-4-881-5868
HONG KONG
Tom Lee Music Co., Ltd.
11/F., Silvercord Tower 1, 30 Canton Road,
Tsimshatsui, Kowloon, Hong Kong
Tel: 2737-7688
INDONESIA
PT. Yamaha Music Indonesia (Distributor)
PT. Nusantik
Gedung Yamaha Music Center, Jalan Jend. Gatot
Subroto Kav. 4, Jakarta 12930, Indonesia
Tel: 21-520-2577
KOREA
Yamaha Music Korea Ltd.
Tong-Yang Securities Bldg. 16F 23-8 Yoido-dong,
Youngdungpo-ku, Seoul, Korea
Tel: 02-3770-0661
MALAYSIA
Yamaha Music Malaysia, Sdn., Bhd.
Lot 8, Jalan Perbandaran, 47301 Kelana Jaya,
Petaling Jaya, Selangor, Malaysia
Tel: 3-703-0900
PHILIPPINES
Yupangco Music Corporation
339 Gil J. Puyat Avenue, P.O. Box 885 MCPO,
Makati, Metro Manila, Philippines
Tel: 819-7551
SINGAPORE
Yamaha Music Asia Pte., Ltd.
11 Ubi Road #06-00, Meiban Industrial Building,
Singapore
Tel: 65-747-4374
TAIWAN
Yamaha KHS Music Co., Ltd.
10F, 150, Tun-Hwa Northroad,
Taipei, Taiwan, R.O.C.
Tel: 02-2713-8999
THAILAND
Siam Music Yamaha Co., Ltd.
121/60-61 RS Tower 17th Floor,
Ratchadaphisek RD., Dindaeng,
Bangkok 10320, Thailand
Tel: 02-641-2951
THE PEOPLE’S REPUBLIC OF CHINA
AND OTHER ASIAN COUNTRIES
Yamaha Corporation,
Asia-Pacific Music Marketing Group
Nakazawa-cho 10-1, Hamamatsu, Japan 430-8650
Tel: 053-460-2317
AUSTRALIA
Yamaha Music Australia Pty. Ltd.
Level 1, 99 Queensbridge Street, Southbank, Victoria
3006, Australia
Tel: 3-9693-5111
NEW ZEALAND
Music Houses of N.Z. Ltd.
146/148 Captain Springs Road, Te Papapa,
Auckland, New Zealand
Tel: 9-634-0099
COUNTRIES AND TRUST
TERRITORIES IN PACIFIC OCEAN
Yamaha Corporation,
Asia-Pacific Music Marketing Group
Nakazawa-cho 10-1, Hamamatsu, Japan 430-8650
Tel: 053-460-2312
NORTH AMERICA
CENTRAL & SOUTH AMERICA
EUROPE
AFRICA
MIDDLE EAST
ASIA
OCEANIA

Navigation menu
