ZEGO ELECTRONIC 15RX Copter of Surveyor Drone User Manual

ZEGO ELECTRONIC COMPANY LIMITED Copter of Surveyor Drone

User Manual

Specifications
Drone power...............3.7V, 250
mAh lithium polymer battery
Remote Control
power..................4×AAA batteries
Control Distance........65 ft. (20m)
Specifications are subject to change
and improvement without notice.
Actual product may vary from the
images found in this document.
CHOKING HAZARD! Small
parts. Not for children under
3 years.
Lithium Battery Notes
• Followthemanufacturer’s
instructions for charging the
drone and do not charge longer
than recommended. Unplug the
charging cable when the drone is
charged.
• Donotpunctureorcrush.Donot
disassemble.
• Donotdisposeoflithiumbatter-
ies in the trash.
• Iftheelectrolyteinthecells
should get on your skin, thor-
oughly wash with soap and water.
Ifintheeyes,rinsethoroughly
withcoolwater.Immediatelyseek
medical attention.
• Donotattempttochargeor
operate damaged toys.
FCC Information
This equipment has been tested and
found to comply with the limits for
a Class B digital device, pursuant to
Part15oftheFCCRules.Theselimits
are designed to provide reasonable
protection against harmful interfer-
ence in a residential installation. This
equipment generates, uses, and
can radiate radio frequency energy
and, if not installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications. However, there is
no guarantee that interference will
not occur in a particular installation.
Ifthisequipmentdoescauseharmful
interference to radio or television
reception, which can be determined by
turning the equipment off and on, the
user is encouraged to try to correct
the interference by one or more of the
following measures:
• Reorientorrelocatethereceiving
antenna.
• Increasetheseparationbetween
the equipment and receiver.
• Connecttheequipmentinto
an outlet on a circuit different
from that to which the receiver is
connected.
• Consultyourdealer or an
experienced radio/TV technician
for help.
Ifyoucannoteliminatetheinterfer-
ence,theFCCrequiresthatyoustop
using your equipment. Changes or
modifications not expressly approved
by the party responsible for compli-
ancecouldvoidtheuser’sauthorityto
operate the equipment.
This device complies with Part 15 of
theFCCRules.Operationissubjectto
the following two conditions: (1) this
device may not cause harmful interfer-
ence, and (2) this device must accept
any interference received, including
interference that may cause undesired
operation.
Limited Warranty
Go to www.radioshack.com/help for
details.
RadioShack Customer Relations
300RadioShackCircle,FortWorth,
TX 76102
www.radioshack.com
WehopeyouenjoyyourSurveyorCamera Drone from RadioShack.
Congratulations!NoFAARegistrationisrequiredforthisdrone.Pleaseread
thisuser’sguidebeforeusingyourdrone.
©2016 GeneralWirelessOperationsInc.Allrightsreserved.
RadioShackisaregisteredtrademarkusedunderlicensebyGeneralWirelessOperationsInc.dbaRadioShack.
06A16
6001433
Printed in China
Package Contents
• Surveyor Camera Drone  •USBChargingCable
• SparePropellers(4) •2.4GHzRemoteControl
• User’sGuide   •3.7V,250mAhLithium-polymerbattery
Age 12+
SURVEYOR
CAMERA DRONE
Charge the Drone Battery
1. Use the USB charging cable to connect the battery to a USB
powersource.TheLEDontheUSBconnectorlightsredduring
charging, and turns off when charging is complete.
A full charge takes about 45 minutes, and provides up to 5
minutes of flight time.
2. After charging, unplug the charging cable. Do not attempt to
overcharge.
3. Openthedronebatterycompartmentdoortoconnectthebattery
socketcables.Thedrone’s4LEDsflash.Tuckthebatteryandwires
neatly inside the compartment and secure the door.
CAUTION:
• Use only the supplied lithium battery and cable, or ones with the
same specification to charge. Using any other batteries, cables or
different specifications may damage the drone.
• After playing, let thebattery cool before charging.
Battery Notes
• Disposeofoldbatteriespromptlyandproperly.Donotburnorburythem.Useonlyfreshbatteriesoftherequiredsizeand
recommended type.
• Do not mix old and new batteries, different types of batteries (standard, alkaline, or rechargeable), or rechargeable
batteries of different capacities.
• Remove batteries during longer storage periods.
Install Batteries in the Remote Control
1. Turn off the controller.
2. Openthebatterycompartmentandinsert4×AAAbatteries(not
included), matching the polarity symbols (+ and –) marked inside
the compartment. Replace the battery cover securely with the
screws.
Note: Iftheremotecontrol’sLEDflashesduringuse,thebatteriesare
low and should be replaced.
3
LED
Camera Lens
Front LEDs (white)
Back LEDs (green)
Propeller (4)
6001433_UG_Eng.indd 1 6/21/2016 6:55:36 PM
Left/Right Slide Trim
Forward/Reverse
Movement Trim
Throttle Steering
Forward
Ascend
Slide
right
Turn
right
Slide
left
Turn
left
Push
(Stunt mode)
Push
(High/low
speed)
Descend
LED
Flashing=Searching
On=Paired
Backward
About Easy and Expert Fly Modes
This drone is designed with 2 play modes.
• Expert: select this mode when you are ready
to fly at a higher speed and perform stunts.
• Ez (Easy) for beginners and new drone owners.
This operates at a slower speed to help you
focus on basic navigation and develop a feel of
thethrottle’ssensitivity.Bydefault,inEzmode,
the stunt and speed options are disabled
to prevent them from being accidentally
activated.
• Whenpairingandflyingforthefirsttime,we
recommend you use Ez for practising your
takeoff, steering and landing skills.
Pairing
1. Place the drone on level ground.
2. Turn on the remote control to Ez or Ex. The
remotecontrol’sLEDflashes.
3. Move the throttle all the way up and then
down to pair the remote control with the
drone.Thedrone’sbladesremainstillduring
pairing.Whenpaired,theLEDsonboththe
remote control and drone light steadily.
Note: Ifpairingfails,turnoffthedroneand
remote control and repeat the steps above, or
change locations to avoid electrical interference.
Fly Your Drone
1. After pairing, with the drone on the ground,
move the throttle forward to ascend. To
avoid ground air turbulence, fly the drone at
least 1 ft. (30cm) off the ground.
For advanced users: Hold the remote control
with one hand, resting your thumb on the
throttle. Toss the drone about 4 ft. (1.2m)
away from you, and move the throttle
forward to fly. The drone adjusts itself
automatically and flies smoothly.
2. Forspeedoptions,pairandflyinEx mode.
Push the steering control in to switch
between high speed (double beep) and low
speed (single beep).
IMPORTANT: Ifyourdronecrashesupsidedown,
pull the throttle down and switch off the remote
control first. Never touch the drone when blades
are still moving.
Trim Your Drone
Move the throttle forward and see how the drone
reacts.
Forward/Reverse Movement Trim:
Ifthedronetendstomoveforward,
press f; if it tends to move backward,
press g.
Left/Right Slide Trim:Ifthedrone
tends to slide right, press f; if it tends
to slide left, press g.
Note: The remote control beeps when you press
a trim control but stops beeping when you reach
maximum trim adjustment.
Land Your Drone
1. Slowly move the throttle backward to
descend. Avoid moving the throttle too
quickly, as it can stop the blades instantly
and cause the drone to crash.
2. After playing, turn off the remote control
andremovethedrone’sbattery.
Perform Stunts
IMPORTANT: Make sure there is enough space
for the drone to perform stunts without crashing
into objects or people.
1. Push the throttle control in so that the
remote control beeps repeatedly to enter
stunt mode.
2. Use the steering control to perform stunts:
• Front flip: Move steering forward
• Back flip: Move steering backward
• Barrel roll: Move steering right or left
3. The drone automatically exits stunt mode
after performing a stunt.
Using the Camera
1. InsertamicroSDcard
(not included) in the
card slot as shown. Push
the SD card in until it
clicks.
2. During flight, press once to take a photo,
or press and hold to record a video.
Release the button to stop recording.
3. After flying, to remove the SD card, press it
to eject.
Note: Before inserting the SD card, make sure it
has enough free space. The SD card fits the slot
only one way. Do not force it.
Troubleshooting
Drone does not respond
• Make sure the drone and remote control are
switched on and paired.
• Dronebatterymaybelow.Fullychargethe
battery. See “Charge the Drone Battery”.
• Make sure the drone is within the control range
(65 ft./20 m) and in line of sight.
Drone dicult to control
• The throttle control is very sensitive. Use small,
fine movements to control.
• Practice in Ez (Easy)mode.
• Propellers may be deformed/ damaged. Adjust
thepropellersbyhand.Ifyoucannotadjustthem,
replace with the spare propellers.
FLY SAFELY
• Adultsupervisionisrecommendedatalltimes.
• Flythedronesafely.Ifitcrashes,theSDcardmayfallout
and be lost.
• Keepeyes,hands,hair,andlooseclothingawayfrom
moving propellers.
• Donotflythedronenearoratotherpeopleoranimals.
• Whenflyingindoors,keepthedroneawayfromwalls,air
conditioning, air vents, fans, breakable objects, and other
obstacles.
• Whenflyingoutdoors,keepthedroneawayfrompower
lines, trees, weeds, and water.
• Donotflyyourdroneoverprivatepropertywhereyouare
not welcomed.
• Donotflyyourdronewhereemergencyrespondersare
working, or emergency aircraft are operating.
Ex/ OFF/ Ez
Expert/Off/Easymode
SD
Replace Damaged Propellers
The left and right propellers of the
drone are different (see color and A/B
orientation marking on underside). Make
sure you insert the correct propeller
in the correct location, otherwise the
drone will fail to take off.
To replace a damaged propeller, remove
the old one and press the new one onto
thepropelleraxle.Ifyoucannotremove
the old propeller by hand, carefully use pliers.
WARNING:
• Toavoidinjuryanddamage,inspectthepropellersfornicksandbreaksandmakesurethey
are securely attached before and after each flight. Replace nicked, chipped, cracked or
broken propellers.
• Useonlythesuppliedpropellers.Donotalter,modify,orcustomizethepropellers.
Back Blades (black)
Front Blades (grey)
A
B
B
A
6001433_UG_Eng.indd 2 6/21/2016 6:55:37 PM
