User Manuel HTML Version

User Manuel

Axon 7 Mini

User Manual

About This Manual

Thank you for choosing this ZTE mobile device. In order to keep

your device in its best condition, please read this manual and

keep it for future reference.

No part of this publication may be quoted, reproduced, translated

or used in any form or by any means, electronic or mechanical,

including photocopying and microfilm, without the prior written

permission of ZTE Corporation.

Notice

ZTE Corporation reserves the right to make modifications on print

errors or update specifications in this guide without prior notice.

This manual has been designed with the utmost care to ensure

the accuracy of its content. However, all statements, information

and recommendations contained therein do not constitute a

warranty of any kind, either expressed or implied. Please refer to

For Your Safety to be sure to use your phone properly and safely.

We offer self-service for our smartphone users. Please visit the

ZTE official website (at www.zteusa.com) for more information on

self-service and supported product models. Information on the

website takes precedence.

Disclaimer

ZTE Corporation expressly disclaims any liability for faults and

damages caused by unauthorized modifications of the software.

Images and screenshots used in this manual may differ from the

actual product. Content in this manual may differ from the actual

product or software.

Trademarks

ZTE and the ZTE logos are trademarks of ZTE Corporation.

Google and Android are trademarks of Google, Inc.

The Bluetooth® trademark and logos are owned by the Bluetooth

SIG, Inc. and any use of such trademarks by ZTE Corporation is

under license.

microSDXC Logo is a trademark of SD-3C, LLC.

Manufactured under license from Dolby Laboratories. Dolby,

Dolby Atmos, and the double-D symbol are trademarks of Dolby

Laboratories.

Qualcomm® Snapdragon™ processors are products of

Qualcomm Technologies, Inc.

Qualcomm and Snapdragon are trademarks of Qualcomm

Incorporated, registered in the United States and other countries.

Used with permission.

Other trademarks and trade names are the property of their

respective owners.

Version No.: R1.0

Edition Time: July 29, 2016

Contents

Getting Started ......................................................... 7

Getting to Know Your Phone ............................................... 7

Knowing the Keys ................................................................ 9

Installing the nano-SIM Cards and Storage Card .............. 10

Charging the Battery.......................................................... 12

Using the Touch Screen .................................................... 14

Getting to Know the Home Screen .................................... 17

Personalizing .......................................................... 19

Using Do Not Disturb Mode ............................................... 19

Applying New Wallpapers .................................................. 20

Setting the Theme ............................................................. 21

Setting the Home Screen Transition Effect ........................ 21

Protecting Your Phone With Screen Locks ........................ 21

Protecting Your Phone With Sound Lock ........................... 22

Using Your Fingerprint ....................................................... 22

Knowing the Basics ............................................... 24

Monitoring the Phone Status ............................................. 24

Managing Notifications ...................................................... 25

Connecting to Networks and Devices .................. 26

Connecting to Mobile Networks ......................................... 26

Connecting to Wi-Fi ........................................................... 28

Exchanging Data via NFC ................................................. 29

Using Tap & Pay ................................................................ 30

Using USB On-The-Go (OTG) ........................................... 31

Phone Calls ............................................................ 32

Placing and Ending Calls ................................................... 32

Answering or Rejecting Calls ............................................. 32

Checking Voicemail ........................................................... 33

Contacts ................................................................. 34

Adding a New Contact ....................................................... 34

Add a Contact to Favorites ................................................ 35

Email ....................................................................... 36

Setting Up the First Email Account .................................... 36

Writing and Sending an Email ............................................ 36

Reply to or Forward an Email ............................................ 37

Messaging .............................................................. 38

Opening the Messaging Screen ......................................... 38

Sending a Message ........................................................... 38

Replying to a Message ...................................................... 39

Camera ................................................................... 40

Capturing a Photo .............................................................. 40

Recording a Video ............................................................. 42

Using Other Camera Modes .............................................. 43

For Your Safety ...................................................... 45

General Safety ................................................................... 45

FCC RF Exposure Information (SAR) ................................ 46

FCC Regulations ............................................................... 48

Hearing Aid Compatibility (HAC) regulations for Mobile

Phones .............................................................................. 49

Distraction ......................................................................... 51

Product Handling ............................................................... 52

Electrical Safety ................................................................. 56

Radio Frequency Interference ........................................... 58

Explosive Environments .................................................... 60

Getting Started

Getting to Know Your Phone

Earpiece/Speaker

Proximity & light

sensor

Touch screen

Front camera

nano-SIM

microSDXC

card tra

Speaker

Main microphone

Charging/USB

Type-C jack

Indicator light

Power key

Headset jack

uxiliar

microphone

Dual-flash

Fingerprint

sensor

Volume key

Back camera

Knowing the Keys

Key Function

Power key

 Press and hold to turn on or off airplane

mode, control vibration, restart, or shut down.

 Press to turn off or on the screen display.

Volume key Press or hold either end of the key to turn the

volume up or down.

Home key

 Touch to return to the home screen from any

application or screen.

 Touch and hold to use Google Search.

Back key

 Touch to go to the previous screen.

 Touch and hold when the screen is unlocked

to use voice command.

Recent apps key Touch to see recently used apps.

NOTE:

The Home key, Back key, Recent apps key and Menu key are

located at the bottom of screen. You can touch to hide them,

or swipe up from the bottom to restore them.

Installing the nano-SIM Cards and

Storage Card

Your phone supports two nano-SIM cards, or you can use one

nano-SIM card and one microSDXC card (optional, not included).

A microSDXC card can be installed or removed while the phone

is turned on. You need to unmount the microSDXC card before

removing it.

WARNING!

To avoid damage to the phone, do not use any other kind of SIM

cards, or any non-standard nano-SIM card cut from a SIM card.

You can get a standard nano-SIM card from your service

provider.

1. Insert the tip of the tray eject tool into the hole next to the

nano-SIM card tray on the left side of the phone.

2. Place the nano-SIM/microSDXC card on the tray with the

gold-colored contacts facing down. Then carefully slide the

tray back into place.

NOTE:

When two nano-SIM cards are installed, pay attention to the

following restrictions.

 If one nano-SIM card connects to 4G LTE, the other card can

only connect to 3G or 2G networks.

 You can use either card for mobile data service. See Manage

the nano-SIM Cards on how to switch.

 If one card is connected to a phone call, the other card is

unreachable.

nano-SIM 1 (right)

and 2 (left)

nano-SIM 1 (right)

and microSDXC (left)

Charging the Battery

Your phone’s battery should have enough power for the phone to

turn on, find a signal, and make a few calls. You should fully

charge the battery as soon as possible.

If the battery is low, there will be a pop-up message on the

screen. As you charge your phone, the screen can show you the

exact battery level on the status bar.

WARNING!

Use only ZTE-approved chargers and USB Type-C cables. The

use of unapproved accessories could damage your phone or

cause the battery to explode.

CAUTION:

Do not change the built-in rechargeable battery in your phone by

yourself. The battery can only be changed by ZTE or ZTE

authorized service provider.

NOTE:

Use the charger that comes in-box with your phone to charge the

battery. It’s specially built to support QuickCharge 2.0.

1. Connect the adapter to the charging jack.

2. Connect the charger to a standard AC power outlet. If the

phone is on, you’ll see a charging icon, such as or ,

appear on the status bar.

3. Disconnect the charger when the battery is fully charged.

NOTE:

If the battery is extremely low, the phone may not power on even

while charging. In this case, charge the phone at least for 20

minutes before trying to power on again. Contact the customer

service if you still cannot power on the phone after prolonged

charging.

Using the Touch Screen

Your phone’s touch screen enables you to control actions

through a variety of touch gestures.

 Touc h

When you want to type using the onscreen keyboard, select

items on the screen such as the application and settings

icons, or press the onscreen buttons, simply touch them with

your finger.

 Touch and Hold

To open the available options for an item (for example, a

message or link in a web page), touch and hold the item.

 Swipe or Slide

To swipe or slide means to quickly drag your finger vertically

or horizontally across the screen.

 Drag

To drag, press and hold your finger with some pressure

before you start to move your finger. While dragging, do not

release your finger until you have reached the target position.

 Pinch

In some apps (such as Maps, web browser, and Gallery), you

can zoom in and out by placing two fingers on the screen at

once and pinching them together (to zoom out) or spreading

them apart (to zoom in).

 Rotate the screen

For most screens, you can automatically change the screen

orientation from portrait to landscape by turning the phone

sideways.

NOTE:

The auto-rotate feature needs to be enabled for the screen

orientation to automatically change. Touch the Home key >

Settings > Display and switch on Auto-rotate screen. You

can also access the screen rotation control by sliding down

the status bar twice and touch Auto-rotate.

Getting to Know the Home Screen

The home screen is the starting point for your phone’s

applications, functions, and menus. You can customize your

home screen by adding folders, widgets, and more.

Extended Home Screen Panels

Your home screen is extendable, providing more space for

folders, widgets, and more. Simply swipe left or right on the home

screen to see the extended panels. You can add or remove home

screen panels, or adjust their order.

Status bar

Primary icons

Widgets

Folder

Navigation bar

Personalizing

Using Do Not Disturb Mode

You can limit interruptions with Do not disturb mode. This mode

silences your phone so that it doesn’t make sounds or vibrate

when you don’t want it to.

To turn on Do not disturb mode:

1. Touch the Home key > Settings > All settings > Sounds &

vibration > Do not disturb > Do not disturb.

2. Touch Always or Scheduled as you need.

 Touch Always to turn on the Do not disturb feature

immediately, which keeps on until you turn it off.

 Touch Scheduled to if you want the feature turned on and

off automatically during specific periods.

3. If you select Scheduled, touch Days, Start time, and End

time to specify the periods during which Do not disturb is on.

To set exceptions for Do not disturb mode:

You can set reminders, certain calls and messages as exceptions

when Do not disturb mode is on, so these ringtones, sounds and

vibration are not turned off.

1. Touch the Home key > Settings > All settings > Sounds &

vibration > Do not disturb.

2. When Do not disturb is on, touch the switches next to the

items you want to allow. Touch Messages or Calls and set

who can alert you of their messages or calls.

NOTES:

 The Do not disturb feature will not silence your alarms.

 To set exceptions based on apps, touch the Home key >

Settings > All settings > Notifications. Select an app and

switch on Sound allowed in Do not disturb.

Applying New Wallpapers

You can set the wallpaper for the home screen and lock screen.

1. Touch the Home key > Settings > All settings > Themes &

wallpapers > Wallpapers.

2. Set the wallpaper for the home screen or the lock screen.

 Touch Home screen wallpaper or Lock screen

wallpaper and select a built-in static wallpaper, or touch

Gallery to select a picture, crop it, and use it as the

wallpaper.

 While setting the lock screen wallpaper, you can touch

ZTE Locker > Apply to get dynamically changing pictures

for the lock screen.

NOTE:

Other ways to set the home screen wallpaper and the lock screen

wallpaper:

 Touch and hold an empty area of the home screen and select

Customize launcher > Wallpapers tab. Then select a built-in

image, a live wallpaper, or an image from your gallery.

 If ZTE Locker is used for the lock screen wallpaper, you can

swipe up from the bottom of the lock screen and touch Lock

screen settings to download new wallpapers, select a layout,

or choose wallpaper for today.

Setting the Theme

1. Touch the Home key > Settings > All settings > Themes &

wallpapers > Themes.

2. Select a theme you like.

Setting the Home Screen Transition

Effect

1. Touch and hold an empty place on the home screen.

2. Touch Customize launcher > Effects.

3. Pick an effect and the phone will demonstrate how it works.

Touch other effects until you find the favorite one.

Protecting Your Phone With Screen

Locks

You can protect your phone by creating a screen lock. When it is

enabled, you need to swipe up on the screen, draw a pattern or

enter a numeric PIN or password to unlock the phone’s screen

and keys.

1. Touch the Home key > Settings > All settings > Security >

Screen lock.

2. Touch Swipe, Pattern, PIN or Complex password.

Protecting Your Phone With Sound

Lock

You can record your voice as the screen lock password. Others

cannot unlock your phone even if they say the same words.

1. Touch the Home key > Settings > All settings > Voiceprint.

2. Touch Start now > Tap to record or Record again to start

recording your voice password. The password must contain

at least two different words.

3. Follow the screen prompts to record your voice three times

and touch OK.

NOTE:

Your sound lock works when a screen lock (Pattern, PIN or

Complex password) is enabled. Swipe right in the lock

screen to unlock with your voice.

Using Your Fingerprint

With the fingerprint sensor on the back of your phone, you can

simply press the fingerprint sensor to take photos, or answer

calls.

NOTE:

The fingerprint feature is only usable when the screen lock

(Pattern, PIN or Complex password) is enabled. When the

screen lock is reset to Swipe, all registered fingerprints are

erased.

1. Touch the Home key > Settings > All settings >

Fingerprint.

2. Touch Register or Fingerprint > Add fingerprint.

3. Follow the prompts to record the center and then the edges of

a finger.

4. Touch OK.

NOTE:

Touch an existing fingerprint record to change its name or delete

it.

Set Fingerprint Actions

1. Touch the Home key > Settings > All settings >

Fingerprint.

2. Touch the switches next to Wake up and unlock your

phone, Take photo, or Answer call.

 Wake up and unlock your phone: When the screen lock

(Pattern, PIN or Complex password) is enabled, you

can wake up the phone and unlock it with a registered

fingerprint.

 Take photo: Press the fingerprint sensor to take a photo

when the Camera app is opened. No fingerprint

verification is needed.

 Answer call: Press the fingerprint sensor to answer

incoming calls. No fingerprint verification is needed.

Knowing the Basics

Monitoring the Phone Status

The status bar at the top of the home screen provides phone and

service status icons on the right side. Below are some of the

icons you may see.

EDGE connected No signal

HSPA+ connected Signal strength

4G LTE connected No nano-SIM card installed

Silent mode Airplane mode

Vibration mode Bluetooth® on

Do not disturb mode Connected to a Wi-Fi® network

Battery low Wi-Fi in use

Battery partially drained Speakerphone on

Battery full Phone microphone off

/ Battery charging GPS on

Alarm set NFC on

Portable Wi-Fi hotspot on Wired headset connected

Managing Notifications

Notification Icons

The status bar at the top of the home screen provides notification

icons on the left. Below are some of the icons you may see.

New SMS Upcoming event

New message(s) from

the Email app

New Wi-Fi network

detected

/ New message(s) from

the Gmail™ app Downloading data

Missed call Sending data

Call in progress USB connected

Call on hold USB tethering on

/ Song playing

Connecting to Networks and

Devices

Connecting to Mobile Networks

Manage the nano-SIM Cards

Your phone supports two nano-SIM card working at the same

time. You can turn on or off the nano-SIM cards, choose the

default card for calls and data, set the network mode or other

mobile network options for each card.

To turn on or off a card:

1. Touch the Home key > Settings > All settings > Dual SIM

settings.

2. Touch the switch next to a card.

NOTE:

You can touch a card name to edit the name or view the number

of the card.

To set the default card for calling and data:

1. Touch the Home key > Settings > All settings > Dual SIM

settings.

2. Touch the mobile data switches to turn on or off mobile data, or

touch Default SIM for calling or Default SIM for calling by

voice & motion and select a card.

NOTE:

You can use either card for mobile data service, but not both at

the same time.

Control Mobile Data Use When Roaming

1. Touch the Home key > Settings > All settings > Dual SIM

settings > Cellular networks.

2. Touch a card tab at the top.

3. Check or uncheck the Data roaming box.

NOTE:

Data roaming may incur significant roaming charges.

Select Network Type

1. Touch the Home key > Settings > All settings > Dual SIM

settings > Network mode.

2. Touch a nano-SIM card name.

3. Touch the type of network you prefer to connect to.

Set Access Point Names

To connect to the Internet you can use the default Access Point

Names (APN). And if you want to add a new APN, please contact

the service provider to get the necessary information.

1. Touch the Home key > Settings > All settings > Dual SIM

settings > Cellular networks.

2. Touch a card tab at the top.

3. Touch Access Point Names.

4. Touch .

5. Touch each item to enter the information you get from your

service provider.

6. Touch > Save to complete.

NOTE:

To set the APN to default settings, touch > Reset to default.

Select Network Operator

1. Touch the Home key > Settings > All settings > Dual SIM

settings > Cellular networks.

2. Touch a card tab at the top.

3. Touch Network operators.

4. Touch Search networks to search for all available networks

and select one to register manually. You can also touch

Choose automatically to select preferred network

automatically.

Connecting to Wi-Fi

Wi-Fi is a wireless networking technology that can provide

Internet access at distances of up to 300 feet, depending on the

Wi-Fi router and your surroundings.

Turn Wi-Fi On and Connect to a Wi-Fi

Network

1. Touch the Home key > Settings > All settings > Wi-Fi.

2. Slide the Wi-Fi switch to turn on Wi-Fi.

3. Touch a network name to connect to it.

4. If the network is secured, enter the password and touch

Connect.

NOTE:

Your phone automatically connects to previously used Wi-Fi

networks when they are in range.

Add a Wi-Fi Network

You can add a Wi-Fi network if the network does not broadcast its

name (SSID), or add a Wi-Fi network when you are out of range.

To connect to a secured network, you first need to get the

security details from the network's administrator.

1. Touch the Home key > Settings > All settings > Wi-Fi.

2. Slide the Wi-Fi switch to turn on Wi-Fi.

3. Touch > Add network.

4. Enter the network SSID (name). If necessary, enter security

or other network configuration details.

5. Touch Save.

Exchanging Data via NFC

Near Field Communication (NFC) allows your phone to exchange

data with another NFC-enabled device when they touch each

other or in close proximity.

Depending on the applications that you have installed on your

phone, you might be able to use your phone as a transit pass or

as an access pass. To use this feature, just bring the devices

together.

To turn on and use NFC:

1. Touch the Home key > Settings > All settings > More.

2. Slide the NFC switch to the on position.

3. If you want to share web pages, contact information,

YouTube videos or other content on your phone to another

NFC-capable device, touch Android Beam and slide the

switch to the on position.

Using Tap & Pay

You can tap and pay with your phone at the merchants that

accept contactless payments.

Set Up Tap & Pay

To tap and pay, you must turn on NFC on your phone.

1. Touch the Home key > Settings > All settings > More.

2. Slide the NFC switch to the on position.

Manage Apps Using Tap & Pay

If you have more than one app that lets you tap and pay, you can

choose a default. Your default app is the one you’ll automatically

use when you tap and pay at a store. You can browse Google

Play Store for more payment apps. Your payment apps need to

support the tap and pay functionality in order to show up. Money

transfer apps and Android Beam aren’t supported.

To set your default payment app:

1. Open the payment app and turn on tap and pay.

2. Touch the Home key > Settings > All settings > Tap & pay.

3. Select your default payment app.

Turn off Tap & Pay

You can turn off tap & pay in two ways:

 Turn off NFC on your phone. Touch the Home key >

Settings > All settings > More and then slide the NFC

switch to the off position. This also turns off Android Beam

and other NFC features.

 Turn off the tap & pay functionality in your payment app. Not

all payment apps support this option.

Using USB On-The-Go (OTG)

Your phone supports USB On-The-Go. You can connect the phone

and a USB peripheral device (such as a USB flash drive, a USB

mouse, or a USB keyboard) with an OTG adapter cable.

For example, when you connect the phone with a USB flash drive,

you can browse the files on the flash drive; connect the phone with

a USB mouse and you can navigate the phone with the mouse.

Phone Calls

You can place calls from the Phone app, the Contacts app, or

other apps or widgets that display contact information. Wherever

you see a phone number, you can usually touch it to dial.

Placing and Ending Calls

Place a Call by Dialing

1. Touch the Home key > > Phone.

2. If the dialpad is closed, touch to display it.

3. Enter the phone number or the contact name with the dialpad.

Touch to delete incorrect digits.

4. Touch below the keypad to dial.

NOTE:

To make an international call, touch and hold the 0 key to enter

the plus (+) symbol. Next, enter the country code, followed by the

city/area code and then the phone number.

End a Call

During a call, touch on the screen.

Answering or Rejecting Calls

When you receive a phone call, the incoming call screen opens,

displaying the caller ID or the information about the caller that

you've entered in the Contacts app. You can answer or reject the

call, or reject it with a text message.

Answer a Call

When you receive a phone call, slide down to answer the

call.

NOTE:

To silence the ringer before answering the call, you can press the

Volume key or the Power key.

Reject a Call

When you receive a phone call, slide up to reject the call.

You can also touch to reject the call and select a preset text

message or write one to send to the caller.

Checking Voicemail

If you have set the phone to divert calls to voicemail, callers can

leave voicemail messages when they cannot reach you. Here’s

how to check the messages they left.

1. Touch the Home key > > Phone.

2. If the dialpad is closed, touch to display it.

3. Touch and hold the 1 key in the dialer. If prompted, enter your

voicemail password.

4. Follow the voice prompts to listen to and manage your

voicemail messages.

Contacts

You can add contacts on your phone and synchronize them with

the contacts in your Google account or other accounts that

support contact syncing.

To see your contacts, touch the Home key > Contacts. From

there, you can touch the tabs on the top of the screen to quickly

switch to contact groups or the Phone app.

Adding a New Contact

1. Touch the Home key > Contacts.

2. Touch > to add a new contact.

3. Touch the account field near the top of the screen to choose

where to save the contact. You can save the contact on the

phone, a nano-SIM card, or a web account you have added on

the phone.

4. Enter the contact name, phone numbers, email addresses,

and other information.

5. Touch Save.

Add a Contact to Favorites

You can add the contacts you use frequently to favorites so that

you can find them quickly.

1. Touch the Home key > Contacts.

2. Touch a contact and then touch at the top.

Touch in the home screen and select Email. Use it to

receive and send emails from your webmail or other accounts,

using POP3 or IMAP, or access your Exchange ActiveSync

account for your corporate email needs.

Setting Up the First Email Account

1. Touch the Home key > > Email.

2. Select an email server and enter the email address and

password.

3. Touch LOG IN to let the phone retrieve the network

parameters automatically.

4. Follow the on-screen instructions to finish the setup.

Your phone will show the inbox of the email account and start to

download email messages.

Writing and Sending an Email

1. Open your email Inbox and touch .

NOTE:

If you have more than one email account added on the

phone, touch the Cc/Bcc line to show the sender

information and select the account you want to use for

sending the message.

2. Enter a contact name or email address in the To field.

Separate each recipient with a comma. You can also touch

to select recipients from your contacts.

3. Enter the email subject and compose the email text.

4. Touch to add images, videos and other types of files as

attachments.

5. Touch at the top right of the screen to send the

message.

Reply to or Forward an Email

1. Open the email you want to reply to or forward from the Inbox.

2. Do the following as you need:

 To reply to the sender, touch > Reply.

 To reply to the sender and all recipients of the original

email, touch > Reply all.

 To forward the email to someone else, touch >

Forward.

3. Edit your message and touch .

Messaging

You can use Messaging to exchange text messages (SMS) and

multimedia messages (MMS).

Opening the Messaging Screen

Touch the Home key > .

Sending a Message

1. On the Messaging screen, touch at the bottom.

2. Add recipients by one of the following ways.

 Touch the To field and manually enter the recipient’s

number or the contact name. If the phone presents a few

suggestions, touch the one you want to add.

 Select recipients from your contacts or call log by

touching .

3. Touch the Enter a message field and enter the message

text.

4. If you want to send a multimedia message, touch to

add a subject or attach a file to the message.

5. Touch . If two nano-SIM cards are installed, touch

or to send with nano-SIM card 1 or 2.

NOTE:

You can also include email addresses as recipients for a

multimedia message.

NOTE:

Do not add a message subject or any attachment if you want to

send a text message. Otherwise you may be charged for a

multimedia message.

Replying to a Message

Messages you receive are appended to existing threads of the

same number. If the new message comes from a new number,

a new thread is created.

1. On the Messaging screen, touch the thread that has the

message you want to reply to.

2. Type your reply in the text box at the bottom. You can touch

if you want to reply with an MMS.

3. Touch . If two nano-SIM cards are installed, touch

or to send with nano-SIM card 1 or 2

Camera

You can use your phone to take photos and record videos.

Photos and videos are stored on the phone’s internal storage.

You can copy them to your computer or access them in the

Gallery app.

Capturing a Photo

1. Touch the Home key > .

2. Aim the camera at the subject and make any necessary

adjustment. Auto camera mode is used by default.

Number Function

1 Switch between the front and back cameras.

2 Set a time delay before the camera takes a picture

automatically after you touch the shutter icon.

3 Turn on or off the High-Dynamic Range (HDR) feature, only

available for the back camera.

4 Change the flash setting, only available for the back

camera.

5 Change the camera settings.

6 Switch among video camera, photo camera, or manual

photo camera mode.

7 Exit the camera.

8 Select a color effect or other special effects.

9 Capture a picture.

10 Capture a LIVE photo.

11 View pictures and videos you have taken.

12 Use special photo or video camera modes including as

Super night, Panorama, Magic exposure, Multi-exposure,

Slow motion, and Timelapse.

WARNING!

Keep a safe distance when using the flash. Do not point the

flash towards the eyes of people or animals.

NOTE:

You can spread or pinch on the screen to zoom in or out

before taking pictures.

3. Touch the area where you want the camera to focus, or

leave the camera to autofocus on the center of the image.

NOTE:

In Auto camera mode, when you touch the screen to focus,

the exposure bar appears beside the focus point. You

can drag up or down to adjust the exposure.

4. Lightly touch . The Volume key can also be used to take

a photo.

NOTE:

When you use the front camera, you can also touch or

BEAUTIFY to use smile detection or beauty face.

Recording a Video

You can record normal-speed video clips. The back camera

also allows you to record slow motion or time lapse video.

1. Touch the Home key > .

2. Touch VIDEO if you want to capture a normal-speed video.

To capture slow motion or time lapse video, touch … >

SLOW MOTION or TIMELAPSE.

3. Aim the camera at the subject. You can touch any area on

the screen that you want the camcorder to focus on before

and during recording.

NOTE:

You can spread or pinch on the screen to zoom in or out

before and during recording.

NOTE:

When you touch the screen to focus during normal-speed

recording, the exposure bar appears beside the focus

point. You can drag up or down to adjust the exposure.

4. Touch to start recording a normal-speed video clip, or

touch to record a slow motion or time lapse video.

NOTE:

While the normal-speed or slow-motion recording is in

progress, touch to pause the recording. When you

record a normal-speed or time-lapse video, touch to

save the frame as a separate photo.

5. Touch or to stop recording.

Using Other Camera Modes

Besides capturing photos and videos in the traditional way, your

camera app offers other powerful and interesting camera

modes. Touch … in the viewfinder screen to find them all.

 SUPER NIGHT: Capture pictures in low-light environment.

 PANORAMA: Capture panorama pictures.

 MAGIC EXPOSURE: Capture water flow, star trail, or car

trail.

 MULTI EXPOSURE: Capture two pictures for collage.

 SLOW MOTION: Capture slow motion video clips.

 TIME LAPSE: Set the time interval between each frame

when you shot time lapse videos with the back camera.

For Your Safety

General Safety

Don’t make or receive

handheld calls while

driving. Never text while

driving.

Don’t use at gas stations.

Keep your phone at least

15 mm away from your

ear or body while making

calls.

Your phone may produce a

bright or flashing light.

Small parts may cause

choking. Don’t dispose of your

phone in fire.

Your phone can produce

a loud sound.

To prevent possible

hearing damage, do not

listen at high volume levels

for long periods.

Avoid contact with

anything magnetic. Avoid extreme

temperatures.

Keep away from

pacemakers and other

electronic medical

devices.

Avoid contact with liquids.

Keep your phone dry.

Turn off when asked to in

hospitals and medical

facilities.

Do not attempt to

disassemble your phone.

Turn off when told to in

aircrafts and airports.

Only use approved

accessories.

Turn off when near

explosive materials or

liquids.

Don’t rely on your phone

as a primary device for

emergency

communications.

FCC RF Exposure Information (SAR)

This phone is designed and manufactured not to exceed the

emission limits for exposure to radio frequency (RF) energy set

by the Federal Communications Commission of the United

States.

During SAR testing, this device was set to transmit at its highest

certified power level in all tested frequency bands, and placed

in positions that simulate RF exposure in usage against the

head with no separation, and near the body with the separation

of 10 mm. Although the SAR is determined at the highest

certified power level, the actual SAR level of the device while

operating can be well below the maximum value. This is

because the phone is designed to operate at multiple power

levels so as to use only the power required to reach the network.

In general, the closer you are to a wireless base station

antenna, the lower the power output.

The exposure standard for wireless devices employs a unit of

measurement known as the Specific Absorption Rate, or

SAR. The SAR limit set by the FCC is 1.6 W/kg.

This device is complied with SAR for general population

/uncontrolled exposure limits in ANSI/IEEE C95.1-1992 and

had been tested in accordance with the measurement methods

and procedures specified in IEEE1528.

The FCC has granted an Equipment Authorization for this

model phone with all reported SAR levels evaluated as in

compliance with the FCC RF exposure guidelines. SAR

information on this model phone is on file with the FCC and can

be found under the Display Grant section of

www.fcc.gov/oet/ea/fccid after searching on FCC ID:

SRQ-ZTEB2017G.

For this device, the highest SAR value for this model phone when

tested was 1.00W/kg for head, 0.77W/kg for Body-worn and

0.97W/kg for hotspot.

While there may be differences between the SAR levels of

various phones and at various positions, they all meet the

government requirement.

SAR compliance for body-worn operation is based on a

separation distance of 10 mm between the unit and the human

body. Carry this device at least 10 mm away from your body to

ensure RF exposure level compliant or lower to the reported

level. To support body-worn operation, choose the belt clips or

holsters that do not contain metallic components to maintain a

separation of 10 mm between this device and your body.

RF exposure compliance with any body-worn accessory that

contains metal was not tested nor certified, and using such

body-worn accessory should be avoided.

FCC Regulations

This mobile phone complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1) This

device may not cause harmful interference, and (2) this device

must accept any interference received, including interference

that may cause undesired operation.

This mobile phone has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications. However, there is no guarantee that

interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference

by one or more of the following measures:

 Reorient or relocate the receiving antenna.

 Increase the separation between the equipment and receiver.

 Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

 Consult the dealer or an experienced radio/TV technician for

help.

CAUTION:

Changes or modifications not expressly approved by the party

responsible for compliance could void the user’s authority to

operate the equipment.

The antenna(s) used for this transmitter must not be co-located

or operating in conjunction with any other antenna or

transmitter.

Hearing Aid Compatibility (HAC)

regulations for Mobile Phones

In 2003, the FCC adopted rules to make digital wireless

telephones compatible with hearing aids and cochlear implants.

Although analog wireless phones do not usually cause

interference with hearing aids or cochlear implants, digital wireless

phones sometimes do because of electromagnetic energy emitted

by the phone's antenna, backlight, or other components. Your

phone is compliant with FCC HAC regulations (ANSI C63.19-

2011). While some wireless phones are used near some hearing

devices (hearing aids and cochlear implants), users may detect a

buzzing, humming, or whining noise. Some hearing devices are

more immune than others to this interference noise and phones

also vary in the amount of interference they generate. The

wireless telephone industry has developed a rating system for

wireless phones to assist hearing device users in finding phones

that may be compatible with their hearing devices. Not all phones

have been rated. Phones that are rated have the rating on their

box or a label located on the box. The ratings are not guarantees.

Results will vary depending on the user's hearing device and

hearing loss. If your hearing device happens to be vulnerable to

interference, you may not be able to use a rated phone

successfully. Trying out the phone with your hearing device is the

best way to evaluate it for your personal needs.

This phone has been tested and rated for use with hearing aids

for some of the wireless technologies that it uses. However, there

may be some newer wireless technologies used in this phone

that have not been tested yet for use with hearing aids. It is

important to try the different features of this phone thoroughly

and in different locations, using your hearing aid or cochlear

implant, to determine if you hear any interfering noise. Consult

your service provider or the manufacturer of this phone for

information on hearing aid compatibility. If you have questions

about return or exchange policies, consult your service provider

or phone retailer.

M-Ratings: Phones rated M3 or M4 meet FCC requirements and

are likely to generate less interference to hearing devices than

phones that are not labeled. M4 is the better/higher of the two

ratings.

T-Ratings: Phones rated T3 or T4 meet FCC requirements and

are likely to be more usable with a hearing device’s telecoil (“T

Switch” or “Telephone Switch”) than unrated phones. T4 is the

better/ higher of the two ratings. (Note that not all hearing devices

have telecoils in them.)

Your phone meets the M4/T3 level rating.

Hearing devices may also be rated. Your hearing device

manufacturer or hearing health professional may help you find

this rating. For more information about FCC Hearing Aid

Compatibility, please go to http://www.fcc.gov/cgb/dro.

Distraction

Driving

Full attention must be given to driving at all times in order to

reduce the risk of an accident. Using a phone while driving (even

with a hands free kit) can cause distraction and lead to an

accident. You must comply with local laws and regulations

restricting the use of wireless devices while driving.

Operating Machinery

Full attention must be given to operating machinery in order to

reduce the risk of an accident.

Product Handling

General Statement on Handling and Use

You alone are responsible for how you use your phone and any

consequences of its use.

You must always turn off your phone wherever the use of a

phone is prohibited. Use of your phone is subject to safety

measures designed to protect users and their environment.

 Always treat your phone and its accessories with care and

keep it in a clean and dust-free place.

 Keep the screen and camera lens clean. Unclean screen or

camera lens may slow down the phone's reaction to your

operations or lower image quality.

 Clean the device and its accessories with a soft material such

as cleaning cloth for eyeglass lenses. Do not use alcohol or

other corrosive substances for cleaning or allow them to get

inside.

 Do not expose your phone or its accessories to open flames

or lit tobacco products.

 Do not expose your phone or its accessories to liquid,

moisture or high humidity.

 Do not drop, throw or try to bend your phone or its

accessories.

 Do not paint your phone or its accessories.

 Do not attempt to disassemble your phone or its accessories.

Only authorized personnel can do so.

 Do not expose or use your phone or its accessories in a

environment with or that can reach extreme temperatures,

minimum - [5] and maximum + [50] degrees Celsius.

 Do not place your phone inside or near heating equipments or

high pressure containers, such as water heaters, microwave

ovens, or hot cooking utensils. Otherwise, your phone may be

damaged.

 Please check local regulations for disposal of electronic

products.

 Do not carry your phone in your back pocket as it could break

when you sit down.

Small Children

Do not leave your phone and its accessories within the reach of

small children or allow them to play with it.

They could hurt themselves or others, or could accidentally

damage the phone.

Your phone contains small parts with sharp edges that may

cause an injury or may become detached and create a choking

hazard.

Demagnetization

To avoid the risk of demagnetization, do not allow electronic

devices or magnetic media to be close to your phone for a long

time.

Electrostatic Discharge (ESD)

Do not touch the nano-SIM card’s metal connectors.

Antenna

Do not touch the antenna unnecessarily.

Normal Use Position

When placing or receiving a phone call, hold your phone to your

ear, with the bottom towards your mouth.

Air Bags

Do not place a phone in the area over an air bag or in the air bag

deployment area as an airbag inflates with great force and

serious injury could result.

Store the phone safely before driving your vehicle.

Seizures/Blackouts

The phone can produce a bright or flashing light. A small

percentage of people may be susceptible to blackouts or

seizures (even if they have never had one before) when exposed

to flashing lights or light patterns such as when playing games or

watching video. If you have experienced seizures or blackouts or

have a family history of such occurrences, please consult a

physician.

Repetitive Strain Injuries

To minimize the risk of Repetitive Strain Injury (RSI) when texting

or playing games with your phone:

 Do not grip the phone too tightly.

 Press the buttons lightly.

 Use the special features which are designed to minimize the

times of pressing buttons, such as Message Templates and

Predictive Text.

 Take many breaks to stretch and relax.

Emergency Calls

This phone, like any wireless phone, operates using radio signals,

which cannot guarantee connection in all conditions. Therefore,

you must never rely solely on any wireless phone for emergency

communications.

Loud Noise

This phone is capable of producing loud noises, which may

damage your hearing. Turn down the volume before using

headphones, Bluetooth stereo headsets or other audio devices.

Phone Heating

Your phone may become warm during charging and during

normal use.

Electrical Safety

Accessories

Use only approved accessories.

Do not connect with incompatible products or accessories.

Take care not to touch or allow metal objects, such as coins or

key rings, to contact or short-circuit in the battery terminals.

Never puncture the surface of the battery with sharp objects.

Connection to a Car

Seek professional advice when connecting a phone interface to

the vehicle electrical system.

Faulty and Damaged Products

Do not attempt to disassemble the phone or its accessories.

Only qualified personnel can service or repair the phone or its

accessories.

If your phone (or its accessories) has been submerged in water,

punctured, or subjected to a severe fall, do not use it until you

have taken it to be checked at an authorized service center.

CTIA Requirements

 Do not disassemble or open crush, bend or deform, puncture

or shred.

 Do not modify or remanufacture, attempt to insert foreign

objects into the battery, immerse or expose to water or other

liquids, expose to fire, explosion or other hazard.

 Only use the battery for the system for which it is specified.

 Only use the battery with a charging system that has been

qualified with the system per CTIA Certification Requirements

for Battery System Compliance to IEEE 1725. Use of an

unqualified battery or charger may present a risk of fire,

explosion, leakage, or other hazard.

 Do not short circuit a battery or allow metallic conductive

objects to contact battery terminals.

 Replace the battery only with another battery that has been

qualified with the system per this standard, IEEE-Std-1725.

Use of an unqualified battery may present a risk of fire,

explosion, leakage or other hazard.

 Promptly dispose of used batteries in accordance with local

regulations.

 Battery usage by children should be supervised.

 Avoid dropping the phone or battery. If the phone or battery is

dropped, especially on a hard surface, and the user suspects

damage, take it to a service center for inspection.

 Improper battery use may result in a fire, explosion or other

hazard.

 The phone shall only be connected to CTIA certified adapters,

products that bear the USB-IF logo or products that have

completed the USB-IF compliance program.

Radio Frequency Interference

General Statement on Interference

Care must be taken when using the phone in close proximity to

personal medical devices, such as pacemakers and hearing aids.

Pacemakers

Pacemaker manufacturers recommend that a minimum

separation of 15 cm be maintained between a mobile phone and

a pacemaker to avoid potential interference with the pacemaker.

To achieve this, use the phone on the opposite ear to your

pacemaker and do not carry it in a breast pocket.

Hearing Aids

People with hearing aids or other cochlear implants may

experience interfering noises when using wireless devices or

when one is nearby.

The level of interference will depend on the type of hearing device

and the distance from the interference source. Increasing the

separation between them may reduce the interference. You may

also consult your hearing aid manufacturer to discuss alternatives.

Medical Devices

Please consult your doctor and the device manufacturer to

determine if operation of your phone may interfere with the

operation of your medical device.

Hospitals

Turn off your wireless device when requested to do so in hospitals,

clinics or health care facilities. These requests are designed to

prevent possible interference with sensitive medical equipment.

Aircraft

Turn off your wireless device whenever you are instructed to do

so by airport or airline staff.

Consult the airline staff about the use of wireless devices

onboard the aircraft. If your device offers a ‘flight mode’, this must

be enabled prior to boarding an aircraft.

Interference in Cars

Please note that because of possible interference with electronic

equipment, some vehicle manufacturers forbid the use of mobile

phones in their vehicles unless a hands-free kit with an external

antenna is included in the installation.

Explosive Environments

Gas Stations and Explosive Atmospheres

In locations with potentially explosive atmospheres, obey all

posted signs to turn off wireless devices such as your phone or

other radio equipment.

Areas with potentially explosive atmospheres include fueling

areas, below decks on boats, fuel or chemical transfer or storage

facilities, and areas where the air contains chemicals or particles,

such as grain, dust, or metal powders.

Blasting Caps and Areas

Power off your mobile phone or wireless device when in a

blasting area or in areas posted power off “two-way radios” or

“electronic devices” to avoid interfering with blasting operations.

ZTE ZTEB2017G LTE/WCDMA/CDMA/GSM (GPRS) Multi-Mode Digital Mobile Phone User Manual SRQ ZTEB2017G

ZTE Corporation LTE/WCDMA/CDMA/GSM (GPRS) Multi-Mode Digital Mobile Phone SRQ ZTEB2017G

Contents

User Manuel

Navigation menu

Namespaces

Views

Navigation
