Zebra Technologies SB1 SMART BADGE User Manual USERS MANUAL 2

Zebra Technologies Corporation SMART BADGE USERS MANUAL 2

Contents

USERS MANUAL 2

SB1
REGULATORY
GUIDE
Motorola Solutions, Inc.
1301 E. Algonquin Rd.
Schaumburg, IL 60196-1078, U.S.A.
http://www.motorolasolutions.com
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and
the Stylized M Logo are trademarks or registered
trademarks of Motorola Trademark Holdings, LLC and
are used under license. All other trademarks are the
property of their respective owners.
© 2012 Motorola Solutions, Inc. All Rights Reserved.
72-162415-01 Rev. 1 — May 2012
Features Regulatory Information
This device is approved under Motorola Solutions, Inc.
This guide applies to model numbers: SB1.
All Motorola devices are designed to be compliant with
rules and regulations in locations they are sold and will be
labeled as required.
Local language translations are available at the following
website: http://supportcentral.motorola.com
Any changes or modifications to Motorola equipment, not
expressly approved by Motorola, could void the user's
authority to operate the equipment.
Declared maximum operating temperature: 50°C.
Wireless Devices Country Approvals
Regulatory markings, subject to certification, are applied
to the device signifying the radio(s) is/are approved for use
in the following countries: United States, Canada, Japan,
China, S. Korea, Australia, and Europe 1.
Please refer to the Declaration of Conformity (DoC) for
details of other country markings. This is available at http:/
/www.motorola.com/doc.
Note 1: For 2.4GHz or 5GHz Products: Europe includes,
Austria, Belgium, Bulgaria, Czech Republic, Cyprus,
Denmark, Estonia, Finland, France, Germany, Greece,
Hungary, Iceland, Ireland, Italy, Latvia, Liechtenstein,
Lithuania, Luxembourg, Malta, Netherlands, Norway,
Poland, Portugal, Romania, Slovak Republic, Slovenia,
Spain, Sweden, Switzerland and the United Kingdom.
Country Roaming
This device incorporates the International Roaming
feature (IEEE802.11d) which will ensure the product
operates on the correct channels for the particular country
of use.
Health and Safety Recommendations
Ergonomic Recommendations
• Reduce or eliminate repetitive motion
• Maintain a neutral postures
• Reduce or eliminate excessive force
• Keep objects that are used frequently within easy
reach
• Perform tasks at correct heights
• Reduce or eliminate vibration
• Reduce or eliminate direct pressure
• Provide adjustable workstations
• Provide adequate clearance
• Provide a suitable working environment
• Improve work procedures.
Please observe all warning notices with regard to the
usage of wireless devices.
Potentially Hazardous Atmospheres -
Fixed Installations
You are reminded of the need to observe restrictions on
the use of radio devices in fuel depots, chemical plants
etc. and areas where the air contains chemicals or
particles (such as grain, dust, or metal powders).
Safety in Aircraft
Switch off your wireless device whenever you are
instructed to do so by airport or airline staff. If your device
offers a 'flight mode' or similar feature, consult airline staff
as to its use in flight.
Wireless devices transmit radio frequency energy and
may affect medical electrical equipment.
Wireless devices should be switched off wherever you are
requested to do so in hospitals, clinics or healthcare
facilities. These requests are designed to prevent possible
interference with sensitive medical equipment.
Pacemakers
Pacemaker manufacturers recommended that a minimum
of 15 cm (6 inches) be maintained between a handheld
wireless device and a pacemaker to avoid potential
interference with the pacemaker. These recommendations
are consistent with independent research and
recommendations by Wireless Technology Research.
Persons with pacemakers:
• Should ALWAYS keep the device more than 15 cm
(6 inches) from their pacemaker when turned ON.
• Should not carry the device in a breast pocket.
• Should use the ear furthest from the pacemaker to
minimize the potential for interference.
• If you have any reason to suspect that interference is
taking place, turn OFF your device.
Other Medical Devices
Please consult your physician or the manufacturer of the
medical device, to determine if the operation of your
wireless product may interfere with the medical device.
Safety Information
Reducing RF Exposure - Use Properly
Only operate the device in accordance with the
instructions supplied.
International
The device complies with internationally recognized
standards covering human exposure to electromagnetic
fields from radio devices. For information on “International”
human exposure to electromagnetic fields refer to the
Motorola Declaration of Conformity (DoC) at http://
www.motorola.com/doc.
For further information on the safety of RF energy from
wireless devices - see
http://responsibility.motorolasolutions.com/index.php/
ourapproach/wirelesscommhealth/
Europe
Handheld Devices
This device was tested for typical body-worn operation.
Use only Motorola tested and approved belt-clips,
holsters, and similar accessories to ensure EU
Compliance.
US and Canada
Handheld Devices
This device was tested for typical body-worn operation.
Use only Motorola tested and approved belt-clips,
holsters, and similar accessories to ensure FCC
Compliance. The use of third-party belt-clips, holsters, and
similar accessories may not comply with FCC RF
exposure compliance requirements, and should be
avoided.
Complies with IEC/EN60825-1:2001 & IEC/
EN62471:2006.
Label reads:
1. LED LIGHT DO NOT STARE DIRECTLY INTO
OPTICAL INSTRUMENTS. CLASS 1M LED
PRODUCT
Batteries
Battery Safety Guidelines
• The area in which the units are charged should be
clear of debris and combustible materials or chemicals.
Particular care should be taken where the device is
charged in a non commercial environment.
• Follow battery usage, storage, and charging guidelines
found in the user's guide.
• Improper battery use may result in a fire, explosion, or
other hazard.
• To charge the mobile device battery, the battery and
charger temperatures must be between +32ºF and
+104ºF (0ºC and +40ºC)
• Do not use incompatible batteries and chargers. Use of
an incompatible battery or charger may present a risk
of fire, explosion, leakage, or other hazard. If you have
any questions about the compatibility of a battery or a
charger, contact Motorola Solutions Global Customer
Support.
• For devices that utilize a USB port as a charging
source, the device shall only be connected to products
that bear the USB-IF logo or have completed the USB-
IF compliance program.
• Do not disassemble or open, crush, bend or deform,
puncture, or shred.
• Severe impact from dropping any battery-operated
device on a hard surface could cause the battery to
overheat.
• Do not short circuit a battery or allow metallic or
conductive objects to contact the battery terminals.
• Do not modify or remanufacture, attempt to insert
foreign objects into the battery, immerse or expose to
water or other liquids, or expose to fire, explosion, or
other hazard.
• Do not leave or store the equipment in or near areas
that might get very hot, such as in a parked vehicle or
near a radiator or other heat source. Do not place
battery into a microwave oven or dryer.
• Battery usage by children should be supervised.
• Please follow local regulations to promptly dispose of
used re-chargeable batteries.
• Do not dispose of batteries in fire.
• Seek medical advice immediately if a battery has been
swallowed.
• In the event of a battery leak, do not allow the liquid to
come in contact with the skin or eyes. If contact has
been made, wash the affected area with large amounts
of water and seek medical advice.
• If you suspect damage to your equipment or battery,
contact Motorola Solutions Global Customer Support
to arrange for inspection.
Use with Hearing Aides
When some wireless devices are used near some hearing
devices (hearing aids and cochlear implants), users may
detect a buzzing, humming, or whining noise. Some
hearing devices are more immune than others to this
interference noise, and wireless devices also vary in the
amount of interference they generate. In the event of
interference you may want to consult your hearing aid
supplier to discuss solutions.
Hearing devices may also be measured for immunity to
this type of interference. Your hearing device manufacturer
or hearing health professional may help you find results for
your hearing device. The more immune your hearing aid
is, the less likely you are to experience interference noise
from mobile phones.
E-paper
Display
Scan Button
LED
Bar Code
Reader
Side Button
Lanyard Slot
Charging Contacts
Interface Contacts
Module
Mounting
Magnets
CAUTION Only use Motorola approved and UL
Listed accessories, battery packs and battery
chargers.
Do NOT attempt to charge damp/wet mobile
computers or batteries. All components must be dry
before connecting to an external power source.
CAUTION Operation of the device without
regulatory approval is illegal.
CAUTION In order to avoid or minimize the
potential risk of ergonomic injury follow the
recommendations below. Consult with your local
Health & Safety Manager to ensure that you are
adhering to your company’s safety programs to
prevent employee injury.
Warnings for Use of Wireless
Devices
Safety in Hospitals
RF Exposure Guidelines
LED Devices
PRELIMINARY
Radio Frequency Interference
Requirements-FCC
Note: This equipment has been tested
and found to comply with the limits for a
Class B digital device, pursuant to Part
15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or
television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and
receiver
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected
• Consult the dealer or an experienced radio/TV
technician for help.
Radio Transmitters (Part 15)
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
Radio Frequency Interference
Requirements - Canada
This Class B digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe B est conforme à la
norme NMB-003 du Canada.
Radio Transmitters
This device complies with RSS 210 of Industry Canada.
Operation is subject to the following two conditions: (1)
this device may not cause harmful interference and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Ce dispositif est conforme à la norme CNR-210 d'Industrie
Canada applicable aux appareils radio exempts de
licence. Son fonctionnement est sujet aux deux conditions
suivantes: (1) le dispositif ne doit pas produire de
brouillage préjudiciable, et (2) ce dispositif doit accepter
tout brouillage reçu, y compris un brouillage susceptible
de provoquer un fonctionnement indésirable.
Label Marking: The Term “IC:” before the radio certification
only signifies that Industry Canada technical specifications
were met.
IC: Soft Label
The IC ID will be displayed on system shut-down.
Frequency of Operation
WARNING: This is a Class A product. In a domestic
environment this product may cause radio interference in
which case the user may be required to take adequate
measures.
Statement of Compliance
Motorola hereby, declares that this device is in compliance
with the essential requirements and other relevant
provisions of Directive 1999/5/EC, 2004/108/EC and 2006/
95/EC. A Declaration of Conformity may be obtained from
http://www.motorola.com/doc.
Japan (VCCI) - Voluntary Control Council for
Interference
Class B ITE
ߎߩⵝ⟎ߪޔᖱႎಣℂⵝ⟎╬㔚ᵄ㓚ኂ⥄ਥⷙ೙ද⼏ળ
㧔㨂㧯㧯㧵㧕ߩၮḰߦၮߠߊࠢ࡜ࠬ $ ᖱႎᛛⴚⵝ⟎ߢߔޕ
ߎߩⵝ⟎ߪޔኅᐸⅣႺߢ૶↪ߔࠆߎߣࠍ⋡⊛ߣߒߡ޿߹
ߔ߇ޔߎߩⵝ⟎߇࡜ࠫࠝ߿࠹࡟ࡆ࡚ࠫࡦฃାᯏߦㄭធߒ
ߡ૶↪ߐࠇࠆߣޔฃା㓚ኂࠍᒁ߈⿠ߎߔߎߣ߇޽ࠅ߹ߔޕ
ขᛒ⺑᣿ᦠߦᓥߞߡᱜߒ޿ขࠅᛒ޿ࠍߒߡਅߐ޿ޕ
Korea Warning Statement for Class B ITE
Other Countries
Chile
“Este equipo cumple con la Resolución No 403 de 2008,
de la Subsecretaria de telecomunicaciones, relativa a
radiaciones electromagnéticas.”
China
ড়Ḑ䆕˖
Mexico
Restrict Frequency Range to: 2.450 - 2.4835 GHz.
South Korean
␭䚨 ⱨ㉔㉘⽸ ⏈㤸䑀䝰 㐔 ᴴ⏙㉥㢨 㢼㡰⳴⦐ 㢬⮹㙼㤸Ḱ
Ḵ⥜═ ㉐⽸㏘⏈ 䚔 ㍌ 㛺㏩⏼␘ .
Taiwan
咉䋲
Ԣࡳ⥛䳏⊶䔏ᇘᗻ䳏″ㅵ⧚䕺⊩
㄀कѠṱ
㍧ൟᓣ䁡䄝ড়ḐПԢࡳ⥛ᇘ丏䳏″ˈ䴲㍧䀅ৃˈ݀ৌǃଚ
㰳៪Փ⫼㗙ഛϡᕫ᪙㞾䅞᳈丏⥛ǃࡴ໻ࡳ⥛៪䅞᳈ॳ䀁㿜
П⡍ᗻঞࡳ㛑DŽ
㄀कಯṱ
Ԣࡳ⥛ᇘ丏䳏″ПՓ⫼ϡᕫᕅ䷓亯㟾ᅝܼঞᑆ᫒ড়⊩䗮ֵ
˗㍧ⱐ⧒᳝ᑆ᫒⧒䈵ᰖˈឝゟेذ⫼ˈϺᬍ୘㟇⛵ᑆ᫒ᰖ
ᮍᕫ㑐㑠Փ⫼DŽ
ࠡ䷙ড়⊩䗮ֵˈᣛձ䳏ֵ㽣ᅮ԰ὁП⛵㎮䳏䗮ֵDŽ
Ԣࡳ⥛ᇘ丏䳏″䷜ᖡফড়⊩䗮ֵ៪Ꮉὁǃ⾥ᅌঞ䝿Ⱆ⫼䳏
⊶䔏ᇘᗻ䳏″䀁٭Пᑆ᫒DŽ
Thailand
ࡳ࠻࡚࡮ࡻࡤ࠾ࡵࡎ࡚࠻ࡘࡐࡩ࠻ࡘࡴ࡜ࡧࡤࡒ࠸࡚ࡊࡐ࡬ࡼ
ࡘ࡬࠻࡞ࡩࡘࡡࡤࡋ࠻࡜ࡼࡤ࠾ࡌࡩࡘ࠹ࡼࡤ࠸ࡪࡢࡐࡋ࠹ࡤ࠾࠸ࡎࡁ 
English: For EU Customers: All products at the end of their life
must be returned to Motorola for recycling. For information on
how to return product, please go to:
http://www.motorola.com/recycling/weee
Français : Clients de l'Union Européenne : Tous les produits
en fin de cycle de vie doivent être retournés à Motorola pour
recyclage. Pour de plus amples informations sur le retour de
produits, consultez : http://www.motorola.com/recycling/weee.
Español: Para clientes en la Unión Europea: todos los
productos deberán entregarse a Motorola al final de su ciclo de
vida para que sean reciclados. Si desea más información
sobre cómo devolver un producto, visite: http://
www.motorola.com/recycling/weee.
Deutsch: Für Kunden innerhalb der EU: Alle Produkte müssen
am Ende ihrer Lebensdauer zum Recycling an Motorola
zurückgesandt werden. Informationen zur Rücksendung von
Produkten finden Sie unter http://www.motorola.com/recycling/
weee.
Italiano: per i clienti dell'UE: tutti i prodotti che sono giunti al
termine del rispettivo ciclo di vita devono essere restituiti a
Motorola al fine di consentirne il riciclaggio. Per informazioni
sulle modalità di restituzione, visitare il seguente sito Web:
http://www.motorola.com/recycling/weee.
Português: Para clientes da UE: todos os produtos no fim de
vida devem ser devolvidos à Motorola para reciclagem. Para
obter informações sobre como devolver o produto, visite: http:/
/www.motorola.com/recycling/weee.
Nederlands: Voor klanten in de EU: alle producten dienen aan
het einde van hun levensduur naar Motorola te worden
teruggezonden voor recycling. Raadpleeg http://
www.motorola.com/recycling/weee voor meer informatie over
het terugzenden van producten.
Polski: Klienci z obszaru Unii Europejskiej: Produkty wycofane
z eksploatacji nale¿y zwróciæ do firmy Motorola w celu ich
utylizacji. Informacje na temat zwrotu produktów znajduj¹ siê
na stronie internetowej http://www.motorola.com/recycling/
weee.
Čeština: Pro zákazníky z EU: Všechny produkty je nutné po
skonèení jejich životnosti vrátit spoleènosti Motorola
k recyklaci. Informace o zpùsobu vrácení produktu najdete na
webové stránce: http://www.motorola.com/recycling/weee.
Eesti: EL klientidele: kõik tooted tuleb nende eluea lõppedes
tagastada taaskasutamise eesmärgil Motorola'ile.
Lisainformatsiooni saamiseks toote tagastamise kohta
külastage palun aadressi: http://www.motorola.com/recycling/
weee.
Magyar: Az EU-ban vásárlóknak: Minden tönkrement terméket
a Motorola vállalathoz kell eljuttatni újrahasznosítás céljából. A
termék visszajuttatásának módjával kapcsolatos tudnivalókért
látogasson el a http://www.motorola.com/recycling/weee
weboldalra.
Slovenski: Za kupce v EU: vsi izdelki se morajo po poteku
življenjske dobe vrniti podjetju Motorola za reciklažo. Za
informacije o vraèilu izdelka obišèite: http://www.motorola.com/
recycling/weee.
Svenska: För kunder inom EU: Alla produkter som uppnått sin
livslängd måste returneras till Motorola för återvinning.
Information om hur du returnerar produkten finns på http://
www.motorola.com/recycling/weee.
Suomi: Asiakkaat Euroopan unionin alueella: Kaikki tuotteet
on palautettava kierrätettäväksi Motorola-yhtiöön, kun tuotetta
ei enää käytetä. Lisätietoja tuotteen palauttamisesta on
osoitteessa http://www.motorola.com/recycling/weee.
Dansk: Til kunder i EU: Alle produkter skal returneres til
Motorola til recirkulering, når de er udtjent. Læs oplysningerne
om returnering af produkter på: http://www.motorola.com/
recycling/weee.
Εηνά: Γα π  ..: Όα α ποα, ο ο
 α  ου, ππ α πφοα 
Motorola γα αα. Γα π ποφο
χ   ποφ  ποο, πφ 
υ http://www.motorola.com/recycling/weee ο
αυο.
Malti: Għal klijenti fl-UE: il-prodotti kollha li jkunu waslu fl-
aħħar tal-ħajja ta' l-użu tagħhom, iridu jiġu rritornati għand
Motorola għar-riċiklaġġ. Għal aktar tagħrif dwar kif għandek
tirritorna l-prodott, jekk jogħġbok żur: http://www.motorola.com/
recycling/weee.
Slovenski: Za kupce v EU: vsi izdelki se morajo po poteku
življenjske dobe vrniti podjetju Motorola za reciklažo. Za
informacije o vračilu izdelka obiščite: http://www.motorola.com/
recycling/weee.
Slovenčina: Pre zákazníkov z krajín EU: Všetky výrobky
musia byť po uplynutí doby ich životnosti vrátené spoločnosti
Motorola na recykláciu. Bližšie informácie o vrátení výrobkov
nájdete na: http://www.motorola.com/recycling/weee.
Lietuvių: ES vartotojams: visi gaminiai, pasibaigus jų
eksploatacijos laikui, turi būti grąžinti utilizuoti į kompaniją
„Motorola“. Daugiau informacijos, kaip grąžinti gaminį, rasite:
http://www.motorola.com/recycling/weee.
Latviešu: ES klientiem: visi produkti pēc to kalpošanas mūža
beigām ir jānogādā atpakaļ Motorola otrreizējai pārstrādei. Lai
iegūtu informāciju par produktu nogādāšanu Motorola, lūdzu,
skatiet: http://www.motorola.com/recycling/weee.
TURKISH WEEE Statement of
Compliance
EEE Yönetmeliğine Uygundur
Software Support
Motorola wants to ensure that customers have the latest
release of entitled software at the time of product
purchase.
To confirm that your Motorola Enterprise Mobility device
shipped with the latest release of entitled software, visit:
www.motorolasolutions.com/support. Check for the latest
software from Software Downloads > Product Line/
Product > Go.
If your device does not have the latest entitled software
release as of your product purchase date, please e-mail a
request to Motorola at:
entitlementservices@motorolasolutions.com.
You must include the following essential device
information with your request:
• Model number
• Serial number
• Proof of purchase
• Title of the software download you are requesting.
If it is determined by Motorola Solutions that your device is
entitled to the latest software release, you will receive an
e-mail containing a link directing you to a Motorola Web
site to download the appropriate software.
Service Information
If you have a problem using the equipment, contact your
facility’s Technical or Systems Support. If there is a
problem with the equipment, they will contact the Motorola
Solutions Global Customer Support at: http://
www.motorolasolutions.com/support.
For the latest version of this guide go to: http://
supportcentral.motorola.com.
Warranty
For the complete Motorola hardware product warranty
statement, go to: http://www.motorolasolutions.com/
warranty.
Motorola reserves the right to make changes to any
product to improve reliability, function, or design. Motorola
does not assume any product liability arising out of, or in
connection with, the application or use of any product,
circuit, or application described herein. No license is
granted, either expressly or by implication, estoppel, or
otherwise under any patent right or patent, covering or
relating to any combination, system, apparatus, machine,
material, method, or process in which Motorola products
might be used. An implied license exists only for
equipment, circuits, and subsystems contained in
Motorola products.
Marking and European
Economic Area (EEA)
韥눺ꙹ ꩡ끞녅껽驩ꓭ
% 鞾韥韥
 閵뇊끞
ꗞꭖ뭪겕韥韥 
넩韥韥鱉閵뇊끞 % 鞾  냱ꈑ
놹녅볁놶뼞麦ꈒ냹
뼑韥韥ꈑ꫑늱ꈑ閵뇊꾅꫑ꩡ끞뼍鱉
阸냹ꑞ놶
냱ꈑ뼍ꐥ ꑝ麕덵꾢꾅꫑ꩡ끞뼕ꯍ
넽걪鱽鲙 
Waste Electrical and Electronic
Equipment (WEEE)
PRELIMINARY

Navigation menu
