FCC - DECLARATION OF CONFORMITY:
Model: GX420d conforms to the following specification: FCC Part 15, Subpart B, Section 15.107(a) and
Section 15.109(a) Class B digital device
Supplemental Information: This device complies with Part 15 of the FCC Rules. Operation is subject to the
following Two Conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for Class B Digital Devices, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a residential environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the product manuals, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or television reception, the
user is encouraged to do one or more of the following measures:
RReorient or relocate the receiving antenna.
RIncrease the separation between the equipment and receiver.
RConnect the equipment into an outlet on a circuit different from that to which the receiver is connected.
RConsult the dealer or an experienced radio/TV technician for help.
FCC - RADIATION EXPOSURE STATEMENT:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
The user is cautioned that any changes or modifications not expressly approved by Zebra Technologies could
void the user's authority to operate the equipment. To ensure compliance, this printer must be used with
shielded communication cables.
Use only power supplies listed in this manual and/or recommended and approved by Zebra Technologies.
INDUSTRY CANADA NOTICE:
This device complies with Industry Canada ICES-003 class B requirements.
Cet equipement est conforme a NMB-003 classe B de la norm Industrielle Canadian.
Utilice sólo adaptadores con las siguientes características eléctricas y que estén debidamente certificados de
acuerdo a la legislación vigente. El uso de otros adaptadores podría dañar el dispositivo y anular la garantía
además de provocar riesgos al usuario.
Características de entrada: 100-240V; 50-60Hz; 2,8A
Características de salida: 24Vdc; 4,17A (100W max)
Es dürfen nur zugelassene Adapter mit den folgenden elektrischen Kennzeichen benutzt werden. Die
Verwendung anderer Adapter könnte die Vorrichtung beschädigen oder den Benutzer gefährden.
Nennwerte: Eingang: 100-240VAC, 50-60Hz, 2,8A
Ausgang: 24VDC, 4,17A (100W max)
사용자 안내문
B급기기(가정용 정보통신기기)
이 기기는 가정용으로 전자파적합등록을 한 기기로서 주거지역에서는 물론 모든 지역에서 사용할 수 있습
니다.
기기의 명칭/(모델명) 인쇄 기계 GX420t / GX430t
인증받은자의 상호 Zebra Technologies International LLC
제조자/제조국가 Zebra Technologies Corporation/USA
