Zhongshan K-mate General Electronics Co., Ltd Bluetooth headset BTE018 User s manual
Users Manual
BTE018
Bluetooth mono headset
User’s manual
Brief introduction
…………………………………………..…1
1. Bluetooth wireless communication technology…...........................1
2. About BTE018………………………………………………..…...1
Before use………………………………………………..1
1. Overview…………………………………….....................…….…1
2. Charging the headset……………………………………...….....…2
Getting started……………………………………......…2
1. Power on/off………..………………………………..................….2
2. Pairing with a Bluetooth mobile phone………………..…..………3
3. Replacing ear cap…………………………………….…..….…….3
4. Making a call with the headset………………….............................4
5. Re-connecting with a Bluetooth device………..………….....….....5
6. LED indicator……………………………………………….….….5
7. Indication tone……………………………………………….….…6
Care and maintenance……………………………..……6
FAQs………. …………………………………………….7
Specifications…………………….….…………………...8
Welcome to use this Bluetooth mono headset, BTE018. Please read this
user’s manual carefully before use.
Brief introduction
1.
Bluetooth wireless communication technology
Bluetooth is a standard of close range radio-communication technology that
was drawn up by Ericsson, IBM, Intel, Nokia and Toshiba. With Bluetooth
technology, we can achieve the highest transmission rate among mobile
phones, computers, printers, PDAs and other devices. The max transmission
range of class II is 10 meters while the max transmission range of class I can
reach up to 100 meters.
2. About BTE018
BTE018 is a Bluetooth mono headset. It has the following features:
Answer a call, end a call and reject a call
Redial last number
Voice dial (This function needs to be supported by your mobile phone)
Call transfer between BTE018 and your mobile phone
Microphone mute
Before use
1. Overview
1
1
Multi-function button (MFB): Power on/power off/answer a
call/end a call/reject a call/cancel calling/microphone mute/call
transfer/redial last number/voice dial
2 Built-in microphone
3 Ear cap
4 Loudspeaker
5 Charging jack
6 LED indicator
2. Charging the headset
The headset comes with a built-in rechargeable battery, prior to using it, it is
recommended to charge the battery fully for the first time.
Connect the charger to a computer USB port or a standard power outlet and
the charger plug to the charging jack of the headset. The red LED is on
while charging. It takes about 1.5 hours to charge the battery fully. When
charging is completed, the red LED is off.
When the headset is on and the battery becomes low, the LED flashes red
and the headset emits a string of indication tones every 15 seconds. Please
recharge the battery fully as described above.
Warning:
1) The battery is recycled.
2) Batteries (battery pack or batteries installed) shall not be exposed to
excessive heat place, such as sunshine, fire or the like.
Getting started
1. Power on/off
Function Operation LED indicator
Power on Press and hold MFB button
for 3 5 seconds
Blue LED is on for 1
second
Power off Press and hold MFB button
for 3 5 seconds
Red LED is on for 1
second
Entering
pairing
mode
Make sure BTE018 is off,
then press and hold MFB
button for 6 7 seconds
LED flashes red and
blue alternately
Remark: In order to save power, the headset will turn off automatically if
no devices can be connected after 10 minutes.
2
2. Pairing with a Bluetooth mobile phone
Prior to using the headset for the first time, you have to pair it with a
Bluetooth-enabled mobile phone. The pairing procedures are subject to
different models of mobile phones. Please refer to your mobile phone’s
user’s manual for further information. The general pairing procedures are as
follows:
1) Place the headset and Bluetooth mobile phone where they are easily
viewable by no more than 1 meter apart;
2) Enter BTE018’s pairing mode (please refer to “Power on/off”);
3) Activate your mobile phone’s Bluetooth function and set your mobile
phone to search for Bluetooth devices within range, and select “BTE018”
from the list of devices shown;
4) According to the indication, enter password or PIN No:”0000”
5) If prompted by your mobile phone to connect, select “Yes” (this will vary
among mobile phone models);
6) Go back to your mobile phone’s main menu. For certain mobile phone
models, a headset icon will be shown on the screen.
You should now be able to make and receive a call using the headset.
Remarks:
Pairing mode will last 2 minutes. The headset will switch to standby
mode automatically if on devices can be connected after 2 minutes. If
you want to continue pairing the headset with a Bluetooth device, please
turn off the headset first and then try re-pairing according to steps 1 6
mentioned above.
After successful pairing, the headset and your mobile phone will
remember each other, it will no need to repair next time. The headset can
remember 8 paired devices. When the number of devices exceeds 8, the
first one will be replaced.
3. Replacing ear cap
Four different sizes of ear caps are included. You can replace the ear cap
according to ear size and personal preferences.
Herein take replacing large ear cap for example, what you need to do are:
1) Remove the large ear cap from the loudspeaker;
2) Put the small ear cap onto the loudspeaker.
3
4. Making a call with the headset
Function Status of
BTE018 Operation
Cancel calling Calling Short press MFB button once
Answer a call Incoming ring Short press MFB button once
Reject a call Incoming ring Press and hold MFB button for
about 2 seconds
End a call During a call Short press MFB button once
Call transfer
(headset to mobile
phone)
During a call Press and hold MFB button for
about 3 seconds
Call transfer
(mobile phone to
headset)
During a call Press and hold MFB button for
about 3 seconds
Microphone mute During a call Short press MFB button twice
Cancel mute
During a call
(Microphone
mute)
Short press MFB button twice
Voice dial
Standby mode
and connected
to a device
Press and hold MFB button for
about 2 seconds
Redial last
number
Standby mode
and connected
to a device
Short press MFB button twice
Clear pairing list Charging in
progress
Press and hold MFB button for
about 1 second and then blue
LED is on for 1 second
4
Remarks:
Not all mobile phones support all functions listed above. Please refer to
your mobile phone’s user’s manual for further information.
When pressing the answer button on some mobile phones, the call will be
transferred to the mobile phone. You have to transfer the call to the
headset by using call transfer function of the headset or operating on the
mobile phone. Please refer to your mobile phone’s user’s manual for
further.
Please be advised to turn off your mobile phone’s Bluetooth function if
you are not going to make a call with the headset in anytime soon.
5. Re-connecting with a Bluetooth device
1) Automatic connecting
Every time BTE018 is turned on, it will connect to the last connected
device automatically.
2) Connecting manually
When BTE018 is in standby mode and doesn’t connect to a Bluetooth
device, press MFB button once, the headset will connect to the last
connected device .
Remarks:
BTE018 only tries to connect to the last connected HFP device.
Please enable Bluetooth on your Bluetooth device before trying to
connect.
On some Bluetooth devices, take some Nokia mobile phones for example,
you need to set up “allow automatic connecting” on the phone.
6. LED indicator
1) When it is charging
LED indicator Status of BTE018
Red LED is on Charging in progress
Red LED is off Charging finished
5
2) When it is not charging
LED indicator Status of BTE018
LED flashes red and blue alternately Pairing mode
Blue LED flashes once every 2
seconds
Standby mode (not connected
to a Bluetooth device)
Blue LED flashes twice every 5
seconds
Standby mode (connected to a
Bluetooth device)
Blue LED flashes quickly Incoming call
Blue LED flashes once every 4
seconds
Calling
Blue LED flashes once every 4
seconds
During a call
Red LED flashes Low power
7. Indication tone
Indication tone Status of BTE018
Two “DU” tones every 10
seconds Microphone mute
A string of indication tones
every 15 seconds Low power
Care and maintenance
Read the following recommendations before using the headset. Following
these you will be able to enjoy our product for many years.
Consider turning the headset off before placing it in your pocket or bag.
If the MFB button is accidentally depressed, your mobile phone may
place an unintended call.
Do not expose the headset to liquid, moisture or humidity to avoid the
product’s internal circuit being affected.
Don’t use abrasive cleaning solvents to clean the headset.
Do not expose the headset to extremely high or low temperature as this
will shorten the life of electronic devices, destroy the battery or distort
certain plastic parts.
Don’t dispose of the headset in a fire as it will result in an explosion.
Don’t expose the headset to contact with sharp objects as this will cause
scratches and damage.
6
Don’t attempt to disassemble the headset as it may get damaged if you
are not professional.
In case the product doesn’t function properly, send it to the store you bought
it. The staff will help you to solve the problem.
FAQs
1 Why does red LED flash ?
The headset is low power, it needs to be recharged.
2 Why isn’t red LED on when charging?
a) Please make sure the charger connects well with the headset;
b) When you doesn’t use the headset for a long time, the battery may dry up.
At this time, you need to charge the battery for 30 minutes, and then the
red LED will be on.
3 How far is the effective range between the headset and Bluetooth
mobile phone?
According to the Bluetooth standard, the max. controllable range of Class
II headset is 10 meters. It varies under different environment.
4 What to do when my mobile phone can not search and find the
headset?
Your mobile phone will not find the headset if the headset and your
mobile phone are not under the pairing mode. Make sure the headset is
under the pairing mode and in the effective working range, and then the
headset can be paired and connected.
5 Why can’t I hear the voice from the headset?
a) Make sure the headset is power on;
b) Ensure the volume of the headset is not too low or mute;
c) Make sure the headset connects well with your mobile phone;
d) Ensure the distance between the headset and your mobile phone is in the
normal working scope.
6 Why is there no voice when making a call with the headset?
a) Make sure your mobile phone is in the strong signal area;
7
b) Ensure the headset is in the function range.
7. I can’t turn off the headset. What shall I do now?
When you start charging the headset, it will turn off automatically.
Specifications
Bluetooth version Bluetooth V2.1+EDR
Bluetooth profiles HSP and HFP
Operating distance 10 meters Class II
Talk time Up to 3.5 hours
Standby time 80 hours
Charging input voltage/current DC 5V 250mA
Charging time About 1.5 hours
Dimensions 32×22×11mm
Weight 6g
Notes:
1. This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
2. Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
3. Excessive sound pressure from earphones and headphones can cause
hearing loss.
8
