Zhongshan K-mate General Electronics Co., Ltd Bluetooth Transmitter for iPod BTT001
Users Manual
BTT001 1
BTT001
Bluetooth Transmitter for iPod
User Manual V2.0
Before using
1. About the BTT001
2. Overview
Start to use
1. Switching on/off the adaptor
2. Pairing with Bluetooth devices
3. Music remote control
4. Indicator LED
Care and maintenance
FAQs
Specification
BTT001 2
Welcome to use this stereo Bluetooth adaptor, BTT001. Before using it, please
read this user manual carefully
■ Before using
1. About BTT001
BTT001 is a Bluetooth adaptor. for iPod. It supports the following Bluetooth
profiles.
Profiles Description
A2DP (Advanced audio
distribution)
Stereo music play
AVRCP(Audio/video
remote control)
Music remote control(control the function of
pause、play、last song and next song)
As long as you plug the adaptor into the iPod, and pair with your stereo
Bluetooth receiver(such as stereo Bluetooth headsets or Bluetooth
speakers),you can enjoy music wirelessly. Additionally , you can remote
control your iPod through operating the receiver if your Bluetooth receiver
also supports AVRCP ,.
Using it as soon as you plug it in, no need to charge. It is very
convenient.
2. Overview
1 iPod dock connector——using it to connect with iPod
2 Indicator LED——status indication
BTT001 3
■ Start to use
1、Switching on/off the adaptor
Function Operation indicator light
Turn on Connect the adaptor with iPod Indicator flashes quickly
Turn off Take out the adaptor from iPod Indicator light is off
Note：please operate your iPod if the adaptor dose not work.
2、Pairing with Bluetooth devices
You can enjoy music wirelessly after pairing and connecting the adaptor
with Bluetooth receiver,. Before pairing, please make sure your
Bluetooth receiver supports A2DP profile. The steps are as follows:
1)、Keep the adaptor and your stereo Bluetooth receiver within 5 meters
2)、Turn on your Bluetooth receiver, and turn it to pairing mode.
3)、Connect the adaptor with iPod, make sure your iPod is on, the indicator
light will flash quickly..
4) 、The adaptor will search and pair with the Bluetooth receiver
automatically..
5)、After successful connecting the adaptor indicator LED will flash slower
than before. At this time, play music in the iPod .
Note：
● The adaptor can pair with stereo Bluetooth receivers which PIN Nos. are “0000”、
“1234”、“7777”or“8888”.
●Connecting with the last paired device automatically when turn on the adaptor.So,.If
you want to pair with other devices, please turn off the current receiver, and then start to
pair with new device.
3、Music remote control
You can remote control last song、next song、pause、revert to play through
operating the Bluetooth receiver. This function needs your Bluetooth receiver
to support AVRCP(audio/video remote control) profile. Please refer to your
user manual of Bluetooth receiver for further information.
4、Indicator LED
Indicator LED Status of adaptor
Blue LED flashes quickly Pairing mode or disconnect with
Bluetooth device
Blue LED flashes every 2 second connected with Bluetooth device
BTT001 4
■ Care and maintenance
Before using the Bluetooth adaptor, please read the following
recommendations ,It will help you to enjoy the product for many year.
● Keep dry and don’t put it in the wet place, in case of effecting the
interior circuit of product.
●Don’t put the product under the sunlight or place in hot areas. High
temperature will shorten the life of electronic device and distort certain plastic.
●Don’t expose the adaptor to extreme temperatures, which may damage
the internal circuit board.
●Don’t try to take apart the product. It may damage the product if you are
not professional
●Don’t fall off on the floor, or knock the hard substance, it may damage
interior circuit.
●Don’t use intensify chemical or detergent to clean the product
● Don’t scrap the surface with sharp things
● If the product can’t work normally, please send it to the regularly
asserted store, the staff will help you to solve problem warmly.
■ FAQs
1 Why can’t turn on the adaptor？
a) Please make sure the adaptor connect with iPod well。
b) Please operate iPod to make sure iPod is on.
2 Why the adaptor can’t be paired and connected？
a) Make sure Bluetooth receiver supports A2DP；
b) Make sure Bluetooth receiver is placed within 5 meters；
c Make sure Bluetooth receiver is in pairing mode.
3 Why no music from receiver？
a) Make sure adaptor connects with iPod well。
b) Please make sure iPod is playing music。
BTT001 5
■ specification
Bluetooth version Bluetooth V2.1
Bluetooth profiles
A
2DP, AVRCP
Frequency range 2.402GHZ-2.4835GHz
Effective range Up to 10m
Dimension 43.5*15*6.6mm
Weight 4.5g
Rating DC 3.3V, 40mA
Compatible iPods
iPod Nano 2nd Gen,
iPod Nano 3rd Gen,
iPod Classic,
iPod Touch,
iPhone,
3G Phone，
iPod Nano 4th Gen，
iPod Touch 2nd Gen
BTT001 6
Note
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
