Zinwave 305-0007 305-0007 Distributed Antenna System Remote Unit User Manual InstallandConfig5000 v50 rev1 draft addendum

Zinwave Ltd 305-0007 Distributed Antenna System Remote Unit InstallandConfig5000 v50 rev1 draft addendum

Users manual 1

Remote Unit with FCC ID: FCC ID UPO302-1107 only supports services in the following bands of
operation:
Rule
Downlink Frequency
Part Band Range (MHz) Service Modulation
90
VHF Public Safety
150.8 –156.2475
157.1875 –161.575
161.775 –161.9625
162.0125 –173.4
P25
C4FM (QPSK)
FM
FM ±2.5kHz dev'n
UHF Public Safety
406.1
- 420
421
- 430
P25
C4FM (QPSK)
FM
FM ±2.5kHz dev'n
FM
FM ±5.0kHz dev'n
456.0
–462.5375
462.7375
- 467.5375
467.7375 - 512.0
P25
C4FM (QPSK)
FM
FM ±2.5kHz dev'n
FM
FM ±5.0kHz dev'n
74
UHF PMSE
470
–608
614
–679.9
FM
FM ±75kHz dev'n
90
700MHz Public
Safety
769 –775
758
-768
698 - 758
P25
C4FM (QPSK)
OpenSky
4-level GFSK
Band 14
LTE
64 QAM
27
700MHz LTE
LTE
64 QAM
90
22
800MHz Public
Safety
851 –854, 854- 861
862
- 869
851
–854, 854- 861
862 - 869
P25
C4FM (QPSK)
OpenSky
4-level GFSK
800MHz SMR
FM & EDACS
FM ±5.0kHz dev'n
900MHz ESMR
935 - 940
LTE
64-QAM
800MHz ESMR
854 –861
862
- 869
869
- 894
929 - 930
EVDO
(QPSK+QAM)
QPSK + QAM
FD-LTE
QPSK + QAM
Cellular
UMTS
QPSK
HSPA/HSPA+
16-QAM/64-QAM
CDMA
QPSK
CDMA2000
Ev-DO
8PSK, 16-QAM
929 Paging
FSK
FSK
931 Paging
931 - 932
FSK
FSK
viii Installation and Configuration
xxxxxxxxxxxxx
799 - 805
162.0375 - 173.4
xxxxxxxxxxxxxxxx
Rule
Downlink Frequency
Part Band Range (MHz) Service Modulation
24
PCS
1930 - 1995
GSM
GMSK
EDGE
8-PSK
UMTS
QPSK
HSPA/HSPA+
16-QAM/64-QAM
FDD LTE (band
2/25)
QPSK + QAM
CDMA
QPSK
CDMA2000
Ev-DO
8PSK, 16-QAM
27
AWS
2110 - 2180
UMTS
QPSK
HSPA/HSPA+
16-QAM/64-QAM
FD-LTE (band
4)
16-QAM/64-QAM
FD-LTE (band
10)
16-QAM/64-QAM
AWS-4
2180 –2200
FD-LTE
16-QAM/64-QAM
WCS
2345 - 2360
FD-LTE
16-QAM/64-QAM
BRS/EBS
2496 –2690
LTE
16-QAM/64-QAM
The Remote Unit is a Licensed Transmitter with authorization to transmit the services. See the
Technical Specification for more information.
FCC Cautionary note
Any changes or modifications in construction of this equipment which are not expressly approved by
the party responsible for compliance could void the user's authority to operate the equipment.
FCC Verification : Primary and Secondary Hub
This device complies with part 15 of the FCC Rules. Operation is subject to the followings two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This is a Class A Digital Device
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
Note: This is Class A product (as defined in EN 55032). In a domestic environment this product may
cause radio interference, in which case the user may be required to take adequate measures.
Installation and Configuration ix
