Zoom Telephonics Inc X6 Wireless ADSL/2/2+ Modem/Router
Users Manual
ADSL X6 User Guide 1
ZOOM ADSL X6
Quick Start
This Quick Start tells you how to install your X6 with a Windows®
PC. Detailed information and installation instructions for
Macintosh and Linux are in the User Guide on the CD. The X6
requires that you have ADSL service, which is usually called DSL
in the USA.
1 Turn on the Windows computer that you will use for
setup. This can be any Windows Vista™, XP, 2000, Me or
98 computer with an available Ethernet port.
For Windows Vista only: You must follow these steps to turn on
Telnet Client:
a Click Start, select Control Panel, then double-click Programs and
Features.
b In Programs and Features, in the Tasks pane, click Turn
Windows features
on or off.
c At the User Account Control message, click Continue.
d In the Windows Features dialog box, select Telnet Client, click
OK, and wait
while the feature is configured.
e In the Uninstall or Change a Program window, click the Close box
to exit.
2 Close any open programs, including any antivirus software
or pop-up blockers.
3 Insert the supplied CD into the CD drive of your
computer. The CD should start automatically. (If the CD
does not start automatically, click the Windows Start button,
click Run, and then type E:\setup.exe, where E is the letter
of your CD drive.)
4 Follow the on-screen prompts for the Install Assistant.
Congratulations! Your installation is complete.
To test your installation, open your browser and go to a familiar
Web site. If your browser works, installation is complete for the
computer you used for setup. If you’d like, you can also connect
other computers to the X6, as discussed on the next page. If your
browser doesn't work, see the Troubleshooting Tips on page 3.
ADSL X6 User’s Guide 2
Note: At this point, if you haven’t already done so, we
recommend that you put an ADSL filter on every phone
connected to the ADSL phone line. DO NOT put a filter
between the X6 and the wall jack that it is connected to.
(In some countries, including the UK, a splitter is supplied
with the X6. The PHONE line plug of the splitter plugs into
the wall jack that has ADSL service, and the X6 plugs into
the splitter's MODEM jack, which is not filtered. The
PHONE jack, for an optional telephone, is filtered.)
ADSL X6 User Guide 3
Connecting Additional Computers to the X6
You can connect other computers to the X6 two ways. You can use a wired
connection by plugging an Ethernet cable between the Ethernet port of your
computer (or game station) and any one of the X6’s four Ethernet (LAN) ports, or
you can establish a wireless connection from another computer that has
Wireless-B or Wireless-G capability.
Wired Ethernet Connection
1 Shut down the computer or game station that you want to connect to the X6.
2 Plug an Ethernet cable into one of the X6’s LAN ports and then into the
Ethernet port of the computer or game station. Then turn on the computer or
game station.
3 Open your Web browser and try to connect to a familiar Web address.
Wireless Connection
First you should determine whether the computer that you want to connect
has built-in wireless capability. Most current notebooks and laptops do; most
desktops don’t.
If your computer has built-in wireless capability
It’s easy to find out if your computer has wireless capability. If it does, your
computer will connect automatically to the X6 network. Just turn it on and the
message Wireless network detected. Click here for available networks will
appear in the task bar in the lower right hand corner of your screen. Click the
message box and select zoom. Then open your Web browser and go to a familiar
web site.
If you don’t get this message and want to check for wireless capability, right-click My
Computer and select Properties. Click Hardware, then the Device Manager button.
Look for Network Adapter and click the plus (+) sign. If your computer has a built-in
wireless device, you’ll see wireless in the list of devices – for example, Ethernet
wireless adapter. If a wireless network device isn’t listed, your computer most likely
does not have built-in wireless capability.
If your computer doesn’t have built-in wireless capability
If you want wireless capability, you will need to install a wireless adapter such as
a USB or PCI Adapter. For a notebook or laptop you can also use a PC Card
adapter.
1 See the instructions that came with your adapter and install it on your
computer.
2 Using the configuration application (sometimes called a Configuration Monitor
or Manager, or Utility) that came with the adapter, do a site survey or scan to
find available networks in your area. (Many configuration manager
applications have a Scan button, Scan Network tab or something similar to
help you find an available network.)
3 When you do the scan, you will see a list of networks identified by an SSID
(Service Set Identifier). Select the Zoom SSID. This is the SSID of the X6
wireless network that you want to use to connect to the Internet.
4 Once connected, open your Web browser and try to connect to a familiar
Web address.
Setting Up Wireless Security
We recommend that you wait until your X6 and any other computers are connected
to the network before setting up security. To set up security for your network, the X6
supports WPA2, WPA, or WEP. Please see the User Guide on the CD for setup
ADSL X6 User’s Guide 4
instructions. You will need to know that admin is the User Name and zoomadsl is
the Password (in lowercase letters).
Setting Advanced Features
The options that are set by default when your X6 is installed are sufficient for
most users. However, those who want or need to change the X6’s settings can
do so using the Advanced Setup page. To open this page, you first log in to the
Zoom Configuration Manager:
1 Open your Web browser. Type 10.0.0.2 in the address bar then press Enter.
2 In the login box, type admin for User Name and zoomadsl for Password in
lowercase letters.
3 Click the Advanced Setup button at the top of the page. Click a button to
choose a feature.
For more information about using the Advanced features, please see the User Guide on the
CD,
Troubleshooting Tips
Problem
My X6’s LINK light is solidly lit, but my computer cannot connect to the Internet.
Check these items:
• If you are using an Ethernet port, check that the X6’s LAN light is on. If the
light is not on, reboot your computer. If the light is still not on, check that a
working Ethernet cable connects from the X6's Ethernet port to an Ethernet
port of your computer.
• Ensure that you have typed your ADSL username and password correctly. To
check your username and password, insert the CD and run the Install
Assistant again.
Problem
My X6’s LINK light continually blinks and does not stay solidly lit.
Check these items:
• Verify that your service provider has turned on your ADSL service. If you’re not
sure, you can place a call to your service provider’s customer support to verify
this.
• Your X6 may not have connected to your Internet service. Turn off the X6, and
then turn it back on and wait a few minutes for the browser to work. Check
your connections.
• Verify that the X6 is connected to a jack with ADSL service. Also, make sure
there isn’t a phone filter between the X6 and the wall jack that the X6 is
connected to.
• Your phone cord may be defective. Try a different phone cord.
If You Need Help
Zoom is ready to help. Please go to www.zoom.com and select Technical
Support. From here you can register your X6 and/or contact our technical
support experts and/or use our intelligent database SmartFactstm and/or get
warranty information.
If you choose to call a Zoom technician, the appropriate number depends on your
country:
US: (561) 241-7170
UK: 0870 720 0090
Other (US number) (561) 997-9683
ADSL X6 User Guide 5
Regulatory Information
U.S. FCC Part 68 Statement
This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA.
The unit bears a label on the back which contains among other information a product identifier in
the format US:AAAEQ##TXXXX. If requested, this number must be provided to the telephone
company.
This equipment uses the following standard jack types for network connection: RJ11C.
This equipment contains an FCC compliant modular jack. It is designed to be connected to the
telephone network or premises wiring using compatible modular plugs and cabling which comply
with the requirements of FCC Part 68 rules.
The Ringer Equivalence Number, or REN, is used to determine the number of devices which may
be connected to the telephone line. An excessive REN may cause the equipment to not ring in
response to an incoming call. In most areas, the sum of the RENs of all equipment on a line should
not exceed five (5.0).
In the unlikely event that this equipment causes harm to the telephone network, the telephone
company can temporarily disconnect your service. The telephone company will try to warn you in
advance of any such disconnection, but if advance notice isn't practical, it may disconnect the
service first and notify you as soon as possible afterwards. In the event such a disconnection is
deemed necessary, you will be advised of your right to file a complaint with the FCC.
From time to time, the telephone company may make changes in its facilities, equipment, or
operations which could affect the operation of this equipment. If this occurs, the telephone
company is required to provide you with advance notice so you can make the modifications
necessary to obtain uninterrupted service.
There are no user serviceable components within this equipment. See Warranty flyer for repair or
warrantee information.
It shall be unlawful for any person within the United States to use a computer or other electronic
device to send any message via a telephone facsimile unless such message clearly contains, in a
margin at the top or bottom of each transmitted page or on the first page of the transmission, the
date and time it is sent and an identification of the business, other entity, or individual sending the
message and the telephone number of the sending machine or of such business, other entity, or
individual. The telephone number provided may not be a 900 number or any other number for
which charges exceed local or long distance transmission charges. Telephone facsimile machines
manufactured on and after December 20, 1992, must clearly mark such identifying information on
each transmitted message. Facsimile modem boards manufactured on and after December 13,
1995, must comply with the requirements of this section.
This equipment cannot be used on public coin phone service provided by the telephone company.
Connection to Party Line Service is subject to state tariffs. Contact your state public utility
commission, public service commission, or corporation commission for more information.
U.S. FCC Part 15 Emissions Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
6 ADSL X6 User Guide
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly
approved by the party responsible for compliance could void the
user's authority to operate this equipment.
This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
IMPORTANT NOTE: FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 20cm between the
radiator & your body.
Industry Canada Emissions Statement
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing
Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel
brouilleur du Canada.
Industry Canada Notice to Users (Industry Canada Statement)
Operation is subject to the following two conditions:
(1)This device may not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
Industry Canada CS03 Statement
NOTICE: This equipment meets the applicable Industry Canada Terminal Equipment Technical
Specifications. This is confirmed by the registration number. The abbreviation, IC, before the
registration number signifies that registration was performed based on a Declaration of Conformity
indicating that Industry Canada technical specifications were met. It does not imply that Industry
Canada approved the equipment.
The Ringer Equivalence Number (REN) for this terminal equipment is identified on the bottom label
of the equipment. The REN assigned to each terminal equipment provides an indication of the
maximum number of terminals allowed to be connected to a telephone interface. The termination
on an interface may consist of any combination of devices subject only to the requirement that the
sum of the Ringer Equivalence Numbers of all the devices does not exceed five.
AVIS : Le présent matériel est conforme aux spécifications techniques d’Industrie Canada
applicables au matériel terminal. Cette conformité est confirmée par le numéro d'enregistrement.
Le sigle IC, placé devant le numéro d'enregistrement, signifie que l’enregistrement s’est effectué
conformément à une déclaration de conformité et indique que les spécifications techniques
d'Industrie Canada ont été respectées. Il n’implique pas qu’Industrie Canada a approuvé le
matériel.
L'indice d'équivalence de la sonnerie (IES) du présent matériel est montré sur l'étiquette inférieure
du produit. L'IES assigné à chaque dispositif terminal indique le nombre maximal de terminaux qui
ADSL X6 User Guide 7
peuvent être raccordés à une interface téléphonique. La terminaison d'une interface peut consister
en une combinaison quelconque de dispositifs, à la seule condition que la somme d'indices
d'équivalence de la sonnerie de tous les dispositifs n'excède pas 5.
Electrostatic Discharge Statement
The unit may require resetting after a severe electrostatic discharge event.
Safety Notices
CAUTION: To reduce the risk of fire, use only the supplied phone cord or a
No.26 AWG or larger UL Listed or CSA Certified Telecommunication Line Cord.
Do not use this product near water, for example, in a wet basement or near a
swimming pool. Avoid using this product during an electrical storm. There may
be a remote risk of electric shock from lightning..
Declaration of Conformity
Declaration of Conformity Overensstemmelseserklæring
Conformiteitsverklaring van de EU Déclaration de conformité
Konformitätserklärung ∆ήλωση Συμμόρφωσης
Dichiarazione di conformità Deklaracja zgodności
Declaração de Conformidade Declaración de conformidad
Konformitetsdeklaration Cam kết về sự tuân thủ ở Châu Âu
Manufacturer/Producent/Fabrikant/
Constructeur/Hersteller/Κατασκευαστής/Fabbric
ante/ Fabricante/Tillverkare/Nhà sản xuất
Zoom Technologies, Inc. 207 South Street
Boston, MA 02111 USA / 617-423-1072
www.zoom.com
Brand/Varemærke/Merk/Marque/Marke/Μάρκα/
Marchio/Marka/Marca/
Thương hiệu
Zoom DSL/ADSL X6 Wireless Modem
Type/Typ/Μάρκα/Tipo/Kiểu mẫu Series 1058 Models 5590C, 5591C
The manufacturer declares under sole responsibility that this equipment is compliant to
Directive 1999/5/EC via the following. This product is CE marked.
Producenten erklærer under eneansvar, at dette udstyr er i overensstemmelse med direktivet
1999/5/EC via følgende. Dette produkt er CE-mærket.
De fabrikant verklaart geheel onder eigen verantwoordelijkheid dat deze apparatuur voldoet aan
Richtlijn 1999/5/ EC op grond van het onderstaande. Dit product is voorzien van de CE-markering.
Le constructeur déclare sous son entière responsabilité que ce matériel est conforme à la
Directive 1999/5/EC via les documents ci-dessous. Ce produit a reçu le marquage CE.
Hiermit erklärt Zoom die Übereinstimmung des Gerätes modem mit den grundlegenden
Anforderungen und den anderen relevanten Festlegungen der Richtlinie 1999/5/EC. Dieses
Produkt ist das gekennzeichnete CE.
Ο κατασκευαστής δηλώνει με αποκλειστική του ευθύνη ότι αυτό το προϊόν συμμορφώνεται
με την Οδηγία 1999/5/ΕC μέσω των παρακάτω. Αυτό το προϊόν φέρει τη Σήμανση CE.
Il fornitore dichiara sotto la sola responsabilità che questa apparecchiatura è compliant a
1999/5/EC direttivo via quanto segue. Questo prodotto è CE contrassegnato.
Producent stwierdza że to urządzenie zostało wyprodukowane zgodnie z Dyrektywą
1999/5/EC. Jest to potwierdzone poprzez umieszczenie znaku CE na urządzeniu.
O fabricante declara sob sua exclusiva responsabilidade que este equipamento está
em conformidade com a Directiva 1999/5/EC através do seguinte. Este produto possui Marcação CE.
El fabricante declara bajo su exclusiva responsabilidad que este equipo satisface la Directiva
1999/5/EC por medio de lo siguiente. Este producto tiene marca CE.
Nhà sản xuất cam kết với trách nhiệm của mình là thiết bị này tuân theo Hướng dẫn
1999/5/EC thông qua các mục sau. Sản phẩm này được đánh dấu là CE.
73/23/EEC – LVD EN60950-1:2001
89/336/EEC – EMC EN301 489-1 V1.4.1: 2002
EN301 489-17 V1.2.1: 2002
EN55022-1998/A1: 2000 Class B/A2:2003
EN55024:1998/A1: 2001/A2: 2003
1999/5/EC EN300 328 v1.6.1: 2004
Andy Pollock
2 December, 2009
1058/TF, Boston, MA, USA
Director, Hardware Engineering/Direktør,
Hardware Engineering/Director, Sustaining
Engineering /Directeur, ingénierie de
soutien/Direktør, Sustaining Engineering
/∆ιευθυντής, Μηχανικής ∆ιατήρησης /Direttore,
Hardware Engineering /Dyrektor, Inżynieria
ciągła/Director, Engenharia de Manutençã
/Director, Ingeniería de apoyo/Giám Đốc Kỹ thuật
Phần cứng
