Internet Setup
IP Address: 192.168.1.1
Username: admin
Password: 1234
Hardware Connections
Connect the power.
WAN/GPON
GREEN
PON not connected. Disconnect power and
repeat hardware connection steps.
PON connected and registered.
4
Connect a computer using an Ethernet cable.
PON connected but not registered.
1
3
4
VoIP registration failed.
VoIP registration is complete.
VoIP1
VoIP setting is not properly configured. Go to
the Web Configurator and configure VoIP
settings.
OFF
GREEN
RED
Connect a phone.
2
Make sure the LEDs are on and check the
GPON and VoIP LEDs.
1
2
3
WAN/GPON
WAN/GPON
VoIP1
VoIP1
OFF
GREEN
(blinking)
Quick Start Guide
C424G
Dual-Band Wireless AC/N GPON HGU with 4-port GbE LAN
2/2
Copyright © 2016 ZyXEL Communications Corp. All Rights Reserved
See the User's Guide at www.zyxel.com for more information.
1
Wall Mounting
23
Wireless
WPS
No WPS
WPS
2
Minutes
(Within 2 Minutes)
SSID
Wireless key
12
(In 1 second...)
(5 seconds)
WiFi 2.4G
(>5 seconds)
1
Press the WPS button until the
WiFi 2.4G LED flashes in orange.
2Press the WPS button on the client.
1
The SSID and wireless key are on the device's
bottom sticker.
2Find the device with its SSID. Enter wireless
key to connect.
12
Advanced Setup > Layer2 Interface > GPON Interface
ORANGE
