eMeet technology M1 Business Smart Assistant User Manual
Shenzhen eMeet technology Co.,Ltd Business Smart Assistant
User Manual
1 2 3 4 5
Packaging Contents
Guarantee
User Manual
Features
Thank you for purchasing eMeet product. OceCore M1 is
the perfect solution for conference calls with its compact
design and outstanding sound quality.
360º omni-directional audio pick up and
8M(26ft) Far-field voice recognition
Built-in VoiceIA™ algorithm to ensure high quality
sound
Plug and play via Bluetooth or USB
12 hours talk time, 20 hours music playback and 1
month standby time, fully charge 2-3 iphone 7
Compact and portable design, take your business
trip anywhere at any time
Supports internet calls, such as Skype, Google
Hangout, Microsoft Lync, Cisco, Avaya, etc
User Manual
OfficeCore M1
Overview
②
①
④
⑤
⑦
⑨
⑩
⑧
⑥
③
①Bluetooth ②Bluetooth / USB light
③Volume down ④Volume up
⑤Mic mute/ unmute ⑥Answer/ drop call
⑦LED indication ⑧Power on/ o
⑨USB output ⑩Micro USB input
Using Guide
• Power ON/OFF
Power on:
Press and hold the power button for 2
seconds until the LED indication turns blue.
Power o:
Press and hold the power button for 2
seconds until the LED indication turns blue.
Checking
battery level:
Press the power button and the LED
indication turns green to show the current
battery level.
• Connecting via Bluetooth
ON
eMeet
M1
≤ 10m
Bluetooth
Pairing
Mode
M1 enters Bluetooth pairing mode
automatically for the first use. Press and hold
Bluetooth button for 3 seconds to switch
Bluetooth device. Bluetooth light flashes fast.
Pairing with
Bluetooth:
Enable Bluetooth of your device and search
Bluetooth devices available. Select “eMeet M1” from
the list and start the pairing. If a PIN is requested,
enter “0000”. Bluetooth light is solid blue when the
connection is completed successfully.
Phone and
music via
Bluetooth:
Make phone calls and play music via Bluetooth
once connected.
• Connecting via USB
6 7 8 9 10 11
Technical Data
Speaker Rated Output
Power
3W RMS
Frequency Response: 20Hz~20KHz
Signal/Noise Ratio: ≥80dB
Bluetooth® Version V4.1
Bluetooth® Range 10m
Mic Sensibility: 26dBFS
Mic Frequency
Response:
100Hz-10KHz
Mic Direction: 360° omni-directional
Battery: 3.7V/5200mAh
Charging Time: 3-4 hours
Play Time:
12 hours (call); 20 hours (music,
varies by content and volume level)
Recharging Input: 5V/2A
Dimension: 110x110x29mm
Weight: 273 g (main unit)
Troubleshooting
Symptom Possible Causes Solution
Fail to turn on Low battery or
empty power Recharge
No sound Disconnected or
low volume
Check the
connection or
adjust volume of
connected device
Distorted or
unclear sound
Volume level too
high or too low
Adjust volume of
connected device
Fail to talk Wrong USB cable Use original USB
cable
Fail to recharge
M1
Malfunction of
charger or fully
recharged
Use a proper
charger
Warning
①Do not disassemble or repair the product yourself.
Always as for help from local dealer if necessary.
②To preserve battery lifespan, fully recharge the
product when not in use for a long period of time or at
low battery level.
③Never place the product near naked flames or other
heat sources, including direct sunlight.
④Danger of explosion if batteries are incorrectly
replaced. Replace only with the same or equivalent
type.
⑤The product should be placed in a dry, ventilated
place indoor. Never expose the product and
accessories to rain or water. Never cover the
ventilation slots or other openings on the product.
⑥To protect environment, exhausted batteries should
be disposed of properly or return to the manufacturer.
Use this product in the
areas of an altitude of
no more than 2000
meters only.
Use this product
in the non-tropical
regions only.
* The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc.
FCC
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates uses
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment o and on, the user
is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and
receiver.
-- Connect the equipment into an outlet on a circuit
dierent from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV
technician for help.
Changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation.
Entering USB
mode:
Connect M1 to your device by using a USB
cable and USB light turns solid orange.
Phone and
music via USB:
Make phone calls and play music once
connected via USB cable.
• Charging and Recharging
Notice: Power adapter is not provided,
customer need to buy separately.
Recharging M1:
Recharge M1 by using a USB charger with
DC 5V output or by connecting a laptop.
While recharging by a laptop, you can
make a call via M1 at the same time.
Power light is solid red while recharging
M1 .
Charging your
smartphone:
Use M1 as a portable battery to charge
your smartphone.
