WatchNET Access Integrated Security Systems Software

WatchNET Access Software Overview

WatchNET Access software is a powerful, network-based enterprise-level security management software that accommodates widely-dispersed applications with an unlimited number of users, controlling thousands of doors and allowing simultaneous access to the system. Its enhanced user experience makes navigation and operation easy and intuitive. The platform offers the ultimate balance between power and affordability in a network environment, with the flexibility to securely connect controllers directly on the network or over RS-485. It is a fully integrated solution for Access Control, Intrusion Detection, CCTV, Time & Attendance, and Building Management.

The software supports Windows 7 and Windows 8 Professional versions and databases such as MSSQL and MS Access. It allows multiple users with different access levels to simultaneously access the system. The system supports stand-alone, small two-four door installations, medium-sized installations, and enterprise global systems. Licensing is a one-time cost based on hardware and functionalities needed, with the ability to add features as the organization grows.

Software Features:

• Easy Icon-based navigation
• Choice of colors & sounds for every event
• Auto Detection of Controllers on the network
• Auto or Manual Backup of the Database
• Exporting Events
• Searching / Add / Delete quickly
• Interactive dynamic maps
• NVR / IP Camera Video Integration
• Event Email Notification
• Pop-up screens on specific events
• Unlimited Users and User Profiles
• SQL Database Standard
• Remote Access Support
• Email Alerts
• Flow Control - Logical Scenario response configuration
• Time and Attendance Built-In
• Visitor Management
• Event Response Configuration
• Alarms and Alert functionality
• Muster / Evacuation Support
• Lockdown and Active Shooter Scenario Supported
• iOS and Android apps available for remote control of doors
• Graphic Design - 4 layers of site-maps
• Doors Operation from ANY client (based on permission)
• Software in multiple languages

Scan and Enroll Controllers on the Network

The system setup is made easy with WatchNET software. Once hardware is wired and plugged into the network, the software scans for all installed controllers and lists them. Auto or Manual configuration is possible for detected controllers. Operators can choose between Auto download or Manual download to controllers. WatchNET Access panels can be connected via COM port or TCP/IP. Controller dip switches need to be correctly set before scanning.

Software Event Monitoring

The pop-up function ensures that in the event of an alarm, the appropriate map pops up. Alarms can be acknowledged, and actions recorded. The system provides real-time status display and control of all devices on the map. Operators can monitor entry of personnel in real-time, with the person's database picture and credentials displayed. This feature facilitates video verification through camera pictures. The system also enables specific events to pop up boxes from different areas of the screen. Event colors can be configured for different organizations.

Distinctive System Features

• Active Directory Integration
• Interactive Guard Tour
• Integrated & Independent Elevator Control
• Integrated & Independent I/O Monitoring
• Web & Mobile Interface

Additional Modules of WatchNET Access Software

WatchNET Access Control software is a powerful application that allows a combination of systems' electronic security in the organization to a central management system. It offers control of all security components, diverse automated responses, easy time control, and advanced customization. The software provides a comprehensive solution for security needs of organizations of all sizes, enabling implementation and assimilation of unique features according to customer needs, while maintaining high performance and stability.

External Modules:

• Microsoft® Active Directory (AD) Integration Module
• Multi-Server (Client Software License)
• Module Badge Design and Printing Module
• Time Attendance Module
• Guard Tour Module
• BACnet Module for BMS Integration
• Visitor Management Module
• Hotel Lock Client Module
• Elevator module
• CCTV Integration Module
• Intrusion Alarm System Integration Module
• VingCard Integration Module

Microsoft® Active Directory (AD) Integration Module

WAS-AF-AD Module: WatchNET Access Control uses Microsoft® Active Directory (AD) for integrated solutions. Bidirectional Microsoft Active Directory Cardholder Sync enables Active Directory user records to be replicated to WatchNET Access Control Software cardholder records. This integration facilitates centralized management and synchronization of Windows user accounts with Security Center's administrator and cardholder accounts. Adding Windows users in Active Directory automatically creates Security Center users and/or cardholders. Synchronization is automated, saving time and reducing errors. Cardholder Sync allows for cardholder permissions and information to be transferred from Active Directory, eliminating data duplication and minimizing the possibility of data errors.

Key Advantages of Active Directory Integration:

• Up-to-date security software and physical facilities access.
• Promotes cooperation, sharing of data, and consistency.
• Streamlines user management, reducing human error.
• Simplifies cardholder management, increasing productivity.
• Automated synchronization eliminates paperwork for managing employee access.
• Security groups are visible within Security Center for quick selection.

Multi-Server (Client Software)

WAS-PRO-CL1 Module: The Client licensed feature of WatchNET Access Control Software improves its ability to operate effectively in a distributed environment, including multiple sites separated by large geographical distances and connected via low bandwidth or intermittently available networks.

Improved Operational Efficiency:

• Multi-Server allows organizations to link the management capabilities of multiple sites, improving operational efficiency and decreasing operational vulnerability.
• Gain access with a single card to multiple sites on a Multi-Server network.
• If one site needs evacuation, another site can take on the responsibility of monitoring and managing it.
• Servers can be aggregated to share information, allowing tracking of cardholder location status.
• Mitigates dependency on a Wide Area Network (WAN) for evacuation reporting and site monitoring.

A diagram shows Application Server - A, Controller - A, Controller - B, Database Server, and Application Server - B and Application Server - C connected in a network.

Module Badge Design & Printing Module

WAS-AF-CP Module: This optional licensed feature allows the design and production of encoded and/or photo identification cards. An extensive range of options are available for formatting card layouts, including creating backgrounds, importing images and logos, adding text, and incorporating barcodes, QR codes, and personalized cardholder data.

Features and Benefits:

• User-friendly interface.
• 'Snap-to-grid' options for precise object positioning.
• Ability to copy and create subsequent layouts from a completed first layout.
• One centralized source of cardholder information.
• Easily design, print, and assign badges or name tags.
• Create custom designs, import, or use built-in templates.
• Completely configurable, template-based WYSIWYG designer.
• Drag and drop functionality.
• Supports any Windows printer.

Operators can print employee cards immediately through any professional card printer, choosing a template for each person or department.

Time Attendance Module

WAS-AF-WTA Module: WatchNET Access Integrated Security Management Software provides Time & Attendance reports. Working hours are set as per company policies, with allowances for late arrival or early departure. The system compares employee IN and OUT times against set rules to generate reports based on selected parameters. Reports can be generated per employee or department and saved in various formats (PDF, Excel, TXT, HTML, RTF, XML, CSV). This information can be imported into third-party software for payroll and HR management.

Features and Benefits:

• Two database options: MS SQL or MS Access.
• Card issuing and authorization with up to 32 operator rights levels.
• Data Backup and exportable working sheets.
• Supports work tables for every department or person.
• Annual holiday setting and temporary time setting.
• Polling work table for weekly, monthly, annual.
• Daily work tables.
• Reports for daily, weekly, monthly, annual based on people and department.
• Multiple operator rights levels management.

Interactive Map

WatchNET Access provides a comprehensive graphical monitoring and control system. Map Maker allows for four layers of visual maps of different sites, buildings, floors, and areas. Users can view controller components and monitor their real-time status (locks, sensors, exit buttons, inputs, and outputs). Users can also change component status by right-clicking on the component. All maps and controller components displayed are dynamic and change their graphical icon based on their physical status (e.g., lock opened).

eMap Features and Benefits:

WatchNET Access Control Software includes an advanced system of synoptic maps, enabling the establishment of detailed facility maps that include all hardware components. It allows full control of component conditions directly from the map, providing a powerful tool for control and monitoring.

Advanced Event Management System

WatchNET Access Control Software includes an advanced event management system with a wide range of tools and capabilities. The system supports over 300 types of events and allows the creation of automatic and manual conditionings for each hardware component or event type.

Features and Benefits:

• Alerts for proper/improper use of proximity tags and fingerprints.
• Hardware event alerts, including burglary detection and disturbed doors.
• Identification of communication problems for controllers, cameras, and alarms.
• Receipt of fault indications from all connected systems.
• Real-time event management with unique color and sound association for each event.
• Automatic sending of emails, network packages, and exported files.
• Unlimited event storage.
• Advanced reporting system, easy to operate.

The system interface displays events with options for acknowledging, filtering, and exporting.

Intrusion Alarm System Integration Module

WAS-INT-IAP Module: WatchNET Access Control Software supports the connection of common control systems and allows full control within systems, receiving real-time indications, integrating alarms into synoptic maps, and providing custom alerts.

Features and Benefits:

• Receive real-time status of areas.
• Arm/disarm sections at the touch of a button.
• Bypass/activation of areas and activating relays.
• Full fault indication.
• Combine areas on synoptic maps and change area status with a button press.
• Create custom system alerts and responses during an alarm.
• Full connection without creating dependency on the alarm system.

Supported Systems: ProSYS 16, ProSYS 40, ProSYS 128, ProSYS Plus, ProSYS LightSYS, PIMA Hunter-Pro 32, PIMA Hunter-Pro 96, PIMA Hunter-Pro 144, DSC PowerSeries PC1616, DSC PowerSeries PC1832, DSC PowerSeries PC1864.

CCTV Integration Module

WAS-INT-WIP Module: WatchNET Access Control Software supports the connection of common CCTV systems, enabling timely video capture, video bouncing during an event, combining cameras in synoptic maps, and backing up recordings directly from the software.

Features and Benefits:

• Create custom video bounces by doors, alarm areas, and other hardware components.
• Perform image capture and short recordings automatically during an event.
• Real-time video streaming directly from the software.
• Combine cameras on synoptic maps and view video at the touch of a button.
• Restore recordings of events directly from the software.
• Receive indication of loss of communication with a camera or recording component.

Video Integration: WatchNET Access software integrates seamlessly with CCTV systems via DVR/NVR and IP Cameras. Integration can be developed based on client requirements. Integration is achieved via TCP/IP communication. The software scans the network to identify DVRs, NVRs, or IP Cameras, and allows viewing live images from cameras on the maps. Cameras can be automatically brought up for events if tagged to doors. Snapshots or video clips can be recorded on specific events and recalled later.

BACnet Interface Module for BMS Integration

WatchNET BACnet Interface module provides data on BACnet/IP. It offers a simple and efficient way to integrate WatchNET Controllers with third-party building management systems. BACnet is a communications protocol for Building Automation and Control Networks.

WAS-BMS-INT Module:

• Combines security and building management for an additional layer of information and operational capabilities.
• Enables integration with selected third-party building management systems for a complete alarm and access management solution.
• Monitors points like Controller Online/Offline status, Door Status, AUX input and output status.
• Seamless integration to BACnet systems over TCP/IP (BACnet IP).
• Windows-style GUI for ease of configuration and data entry.
• Maps ACS Devices and Inputs to BACnet Objects.
• Defines how Access Control Alarms utilize BACnet Objects.
• Supports Operational/Non-Operational alarms, Duress and Tamper Alarms.

WAS-BMS-INT Module Features:

• Establishes an unlimited number of maps.
• Builds map trees and hierarchies up to 4 layers.
• Adjusts size, shape, and angle of map components.
• Uses smart icons that change based on element state.
• Automatic map bounce during an event, marking the relevant element.
• Option to add custom icons and buttons.

A visual representation of an Access Control System with multiple towers is shown.

Biometric Reader Integration

The WatchNET Access software integrates seamlessly with Biometric readers, allowing enrollment of cardholders and their fingerprints from a single screen. It is currently integrated with WatchNET Bio-metric readers and other well-known brands. Integration can be developed as per client's requirements. Initially, each reader is connected via USB to set its device parameters for TCP/IP communication. Once configured, biometric readers are plugged into the network and identified by the software. Fingerprints are enrolled simultaneously with card issuance using a USB fingerprint enrollment unit and downloaded to fingerprint units via TCP/IP. Biometric readers are listed in the card enrollment screen, and access can be granted based on cardholder access level.

The interface allows adding personnel, managing department lists, setting access levels, and enrolling fingerprints.

Guard Tour Module

WAS-AF-SGT Module: Patrol Online Module is a real-time application for Guard Patrol, supporting multi-time flash cards, leave of absence, overtime, and card adjustment functions. It supports shifting, cross-day work time, and multi-shifting. It offers various statements/reports and a rich condition combination search function, facilitating real-time patrol status. It is particularly suitable for high-security areas like prisons, public security organs, and high-grade communities.

Features and Benefits:

• Two database options: MS SQL or MS Access.
• Multiple operator rights levels management.
• Data Backup and exportable working sheets (Excel / TXT).
• Powerful team/group setting functions for convenient operation.
• Reflects real-time patrol status.
• Flexible setting of guard patrol points, routes, and schedules.
• Establishes patrol schedules and realizes schedule circulation.
• Various color cue functions with different display meanings for event types.
• Powerful reporting capabilities for various reports exportable by time, individuals, departments, shifting, and information.
