EDITORIAL
E-mobility

Dear Reader,
With transportation accounting for about one fifth of worldwide anthropogenic carbon emissions, it presents a clear case for decarbonization and electrification. Globally, the market share of new all-electric automobiles has grown to five percent (from virtually nothing some years ago). In some countries the figure is far higher: In Norway, for example, more than 50 percent of new cars are now electric. And this is only the beginning.
The changeover from fossil fuel to electric is not just a question of replacing one power source by another, but is creating an entire new infrastructure, from the management of energy sources down to the physical charger.
There is much more to electric transportation than cars. Since its early days, ABB has been closely connected to railway electrification. Electrification is also re-shaping the bus market, and even ships are going emission-free. These and many more aspects are explored in the present issue of ABB Review.
Enjoy your reading.

Bazmi Husain Chief Technology Officer

-- 6

ABB REVIEW

E-mobility

04|2019
14

The transformational change of electric mobility is a race to put new technologies to work for the benefit of businesses, society, and the environment. ABB helps get electricity to more users when and where it's needed and, in the case of motorspots, drive race cars across the finish line.

Racing into the future with the

ABB FIA Formula E Championship

Electrifying the Niagara Falls

Maid of the Mist ferries

Welcome aboard hydrogen QRV?

The electric bus range is a matter

of perspective

The future of the power grid

in the coming era of e-mobility

EV infrastructure innovation

through collaboration

ABB REVIEW

E -MOBILITY

--
E-MOBILITY
Racing into the future with the ABB FIA Formula E Championship

Photo 01: Germain Hazard/DPPI

04|2019

R ac ing into the fu tu re

01
The ABB FIA Formula E Championship a class of motorsport for electric-powered cars presents not just a thrilling racing spectacle but also a versatile platform upon which to test and demonstrate e-mobility electrification and digitalization technologies.

Anthony Rowlinson Asea Brown Boveri Ltd Zurich, Switzerland
anthony.rowlinson@ ch.abb.com

ABB REVIEW

E -MOBILITY

Gen2 (Season 5) Gen1 (Season 14)

Top speed (km/h)

280

225

Acceleration, 0100 km/h (s)

2.8

3.0

Power in race mode (kW/hp)

200/270

180/240

Maximum power, Attack Mode (kW) 250 (335)

n/a

Battery capacity (kWh)

54 (full race length)

28 (car swap, mid-race)

Battery voltage (V)

900

700

Battery weight (kg)

385

320

Minimum weight (kg)

900

880

Race length

45 min + 1 lap

Track dependent

The global e-mobility revolution has many forms: experimental electric aircraft, autonomous ferries, fast-charging bus fleets, or the increasingly familiar sight of Web-connected electric vehicles (EVs) on public roads.
However, there is one e-mobility arena that takes the prize for high-profile, pioneering innovation: the ABB FIA Formula E Championship. This annual event pits 22 of the world's most talented drivers against each other in the most advanced electric race cars yet created. The championship has been

running since its inauguration in Beijing in 2014 and has been title-partnered by ABB since January 2018 1.
The sound of silence Perhaps the most notable aspect of ABB Formula E is the noise or, more accurately, the lack thereof. As the world's first global, all-electric motor-racing category, the race series was born of an idea that would shatter one of the most dearly held conventions in motorsport: that racing should be ear-splittingly noisy, thanks to highly tuned internal combustion engines spinning at up to 20,000 rpm.
-- The ABB FIA Formula E Champion ship pits 22 of the world's most talented drivers against each other in the most advanced electric race cars yet created.
Since its inception, ABB Formula E has taken a radically different approach by adopting battery-powered cars driven by high-efficiency electric powertrains that use some of the world's most advanced e-mobility technology. As they compete on ever

Photos 02, 05: Germain Hazard/DPPI

04|2019

R ac ing into the fu tu re

-- 01 Nissan team "Nissan e-Dams" action during the 2019 Formula E Championship at Marrakesh, Morocco.
-- 02 The roar of Formula One is replaced by the quiet whine of some of the most advanced e-mobility technology on the planet. Here, the 2019 Formula E Championship in January in Santiago de Chile, Chile.
-- 03 Gen2 cars compared with Gen1.
-- 04 Exploded diagram of a Formula E car.
-- 05 The 2019 Formula E Championship in Hong Kong. Jean-Éric Vergne of France driving the Gen2 DS E-Tense for the DS TECHEETAH team.

more city-center racetracks around the globe, the cars' characteristic, muted high-pitched whine is becoming a familiar replacement for the roar of petrol-driven vehicles of other racing series 2.
Going from strength to strength In under five years, ABB Formula E has blossomed from an audacious start-up, that was dismissed as a niche curio by both hardcore motorsport fans and the less visionary quarters of the automotive sector, into a sporting property of such relevance that major car manufacturers are now pushing their way into the championship, keen to flaunt their e-mobility credentials through competition success. Already the likes of Audi, BMW, Nissan and Jaguar field leading teams; next season they will be joined by blue-chip industry titans Porsche and Mercedes-Benz.

-- ABB Formula E showcases advanced electrification technology, connected mobility and urban transport solutions.
The championship is flourishing because of the relevance of its proposition at a time of growing concern over matters of sustainability, energy efficiency, pollution and urban congestion. In a single package that maintains a visceral sporting appeal at its core, ABB Formula E can showcase

MOTOR Peak power increased to 250 kW. Top speed of 280 kph/174 mph

SAFETY New "halo" head protection incorporating LED lights to show Attack Mode and Fanboost is active
TYRES All-weather tyres last the full race as there is no longer a car swap

BR AKES New brake-by-wire system improving regenerative braking system
BATTERY Gen2 battery gains 95 percent more energy for just 20 percent more weight
04

ABB REVIEW

E -MOBILITY

simultaneously: advanced electrification technology; urban transport solutions; the latest ideas in connected mobility; smart city visions and developments in sustainable power generation.
Putting the "E" into ABB Formula E At the heart of the championship is a field of fast, electric racing cars driven by 22 of the world's most talented drivers many of whom have been drawn from Formula 1 racing.

the inner workings. This much is relatively conventional and typical of almost any contemporary single-seat racer.
-- It is behind the driver that the defining hardware of an ABB Formula E race car is hidden.

Each of the 11 two-car, two-driver, teams competes with their own variant of the same basic machine: an open-cockpit single-seater built around an impact-resistant and highly protective carbon-f iber monocoque, which cocoons the driver. The suspension is hung from this central component and aerodynamic bodywork cloaks

But it is behind the driver that the defining hardware of an ABB Formula E race car is hidden. Instead of a fuel tank, internal combustion engine and a multi-speed, semi-automatic gearbox, the "Gen2" racer, introduced in 2019, has a large, high-efficiency battery, one or two motors and a single-speed transmission 35. These are the elements that put the "E" into ABB Formula E.

04|2019

R ac ing into the fu tu re

-- 06 The Gen2's improved battery performance means the mid-race car changeover can be dispensed with.
-- 07 Recently introduced electronic control of regenerative braking systems has further improved car performance.
-- 08 The racing version of the Jaguar I-PACE benefits from ABB trackside charging technology.

Better batteries The cars' batteries are built and supplied by McLaren Applied Technologies (MAT) a sister company of the famous McLaren racing team. The batteries are common to every car and central to the car's performance.

"regen balance" was controlled by the driver but electronic control introduced for season five has enhanced the process 7. This is precisely the kind of sophisticated energy management technology that is invaluable to car manufacturers in developing class-leading road models.

Weighing around 385 kg, the battery is both larger and heavier than the unit supplied for the earlier generation of cars that raced from seasons one to four and its peak output of 900V is an increase of 200V over the previous technology. It permits peak power of 250kW approximately 330bhp and can propel the cars to top speeds of around 280km/h.
More significant than these headline figures, however, is that the battery's increased capacity and efficiency allows ABB Formula E cars to complete a full race distance on a single charge. Over the first four seasons of racing, technological limitations meant that drivers would drive half the race in one car then swap to an identical machine with a full battery.
While this unique changeover procedure provided a distinctive ABB Formula E spectacle, it also drew attention to a specific consumer hesitancy that has hindered widespread EV adoption: range anxiety. The Gen2 car's bigger battery pack counters that concern, however, thanks to a 95 percent energy increase for a 20 percent weight gain 6. In this aspect more than any other, ABB Formula E has demonstrated the rapid pace of technical advancement across the e-mobility landscape.
MAT's Gen2 battery pack was developed with particular regard for temperature management. Its internal lithium cells are highly sensitive to temperature: too cool and efficiency is not optimized; too hot and output life suffers. Homogenous cooling across the multiple individual cells inside the pack was, therefore, a key design goal.
Technology test platform Elsewhere beneath the aggressively styled bodywork of the Gen2 cars lie experimental technical developments. ABB Formula E provides an ideal rigorous environment in which companies can put their new technology through its paces. For example, twin-motor installations, where each motor is dedicated to one rear wheel (rather than the drive from a single motor being split between two) have been evaluated for potential traction and drivetrain efficiency benefits.

Taking charge ABB has brought its technical expertise to the Jaguar I-PACE eTROPHY series that supports ABB Formula E at 10 races this season.
The Jaguar I-PACE all-electric SUV was named the 2019 Car of the Year at the New York International Auto Show by a panel of 86 motoring journalists from 24 countries, just weeks after it claimed the European Car of Year title. The race-prepared version of the I-PACE is powered at the trackside by custom-made variants of ABB's Terra 53 DC charger 8. To meet the demands for a charger that could be both mobile at racetracks and easily transported between them, ABB commissioned a team of its engineers to reconfigure a standard Terra unit into a smaller package, with wheels, for easy freighting and maneuverability. By mid-season, the charger units had operated with a 100 percent success rate.
-- The Gen2 car's bigger battery pack has a 95 percent energy increase for a 20 percent weight gain.
These are exciting times for ABB Formula E, with the championship in rude health and further ABB technical collaborations under discussion. As a platform upon which to test pioneering e-mobility technology and show the world the capabilities of electric vehicles, the championship is unparalleled. As Sébastien Buemi, a driver for Nissan e.Dams (a Formula E team), Season 2 champion and ABB ambassador, sums up: "When we compete in ABB
· Formula E, it feels like we are driving the future."

All cars incorporate regenerative braking systems that harvest significant amounts of energy during the many intensive decelerations on the circuit. Until this season, each car's so-called
