IRay Technology 02110113 802.11abgn Mini PCIe module User Manual
iRay Technology (Shanghai) Ltd. 802.11abgn Mini PCIe module
Contents
- 1. User manual
- 2. Users Manual-1
- 3. Users Manual-2
User manual
![](/img.php?id=2803362&img=bg1.png)
WPEA-121N
PRODUCT SPECIFICATION
Standard
IEEE802.11a; IEEE802.11b; IEEE 802.11g; IEEE 802.11n
Bus Interface
PCI Express
Form Factor
PCIe half mini card
Data Rate
802.11b:
11, 5.5, 2, 1 Mbps;
802.11g:
54, 48, 36, 24, 18, 12, 9, 6 Mbps
802.11a:
54, 48, 36, 24, 18, 12, 9, 6 Mbps
802.11n:
MCS 0 to 15 for HT20MHz
MCS 0 to 15 for HT40MHz
Media Access Control
CSMA/CA with ACK
Modulation Techniques
802.11b:
CCK, DQPSK, DBPSK
802.11a/g:
64 QAM, 16 QAM, QPSK, BPSK
802.11n:
64 QAM, 16 QAM, QPSK, BPSK
Network architecture
Infrastructure mode
Operating Channel
2.4GHz
11: (Ch. 1-11) – United States
13: (Ch. 1-13) – Europe
14: (Ch. 1-14) – Japan
5GHz
12: USA
19: EU
8: Japan
![](/img.php?id=2803362&img=bg2.png)
Frequency Range
2.4G
2.412 ~ 2.4835 GHz
5G
5.15 ~ 5.85 GHz
Transmit Output Power
-2x2(Tolerance:+-2dBm)
802.11b
17dBm@11M
802.11a
5180,5240,5320,5400MHz 12dBm@54M
5500,5600,5700,5825MHz 11dBm@54M
802.11g
16dBm@54M
802.11n(measured by 1 spatial)
2.4G
15dBm@MCS7_HT20
14dBm@MCS7_HT40
5G
HT20:
5180,5240MHz 12dBm@MCS7
5320,5400MHz 11dBm@MCS7
5500,5700MHz 10dBm@MCS7
5745,5825MHz 9dBm@MCS7
HT40:
5180,5240MHz 11dBm@MCS7
5320,5400MHz 10dBm@MCS7
5500,5700MHz 9dBm@MCS7
5745,5825MHz 8dBm@MCS7
![](/img.php?id=2803362&img=bg3.png)
Transmit Output Power
-2x2(Tolerance:+-2dBm)
802.11n(measured by 2 spatial)
2.4G
17dBm(MCS7_HT20)
16dBm(MCS7_HT40)
5G
HT20:
5180,5240MHz 15dBm@MCS15
5320,5400MHz 14dBm@MCS15
5500,5700MHz 11dBm@MCS15
5745,5825MHz 11dBm@MCS15
HT40:
5180,5240MHz 14dBm@MCS15
5320,5400MHz 13dBm@MCS15
5500.5700MHz 11dBm@MCS15
5745,5825MHz 11dBm@MCS15
Receiver Sensitivity
802.11b -85dBm@11M
802.11a -76dBm@54M
802.11g -76dBm@54M
802.11n
2.4G
-90dBm@MCS0_HT20
-75dBm@MCS7_HT20
-88dBm@MCS0_HT40
-72dBm@MCS7_HT40
5G
-90dBm@MCS0_HT20
-74dBm@MCS7_HT20
-89dBm@MCS0_HT40
-71dBm@MCS7_HT40
![](/img.php?id=2803362&img=bg4.png)
Security
WPA, WPA-PSK, WPA2, WPA2-PSK, WEP 64bit & 128bit,
IEEE. 802.1x with EAP support (LEAP, WPA2/AES with EAP-TLS,
PEAP-MSCHAPv2 , EAP-FAST, single-sign-on with LEAP)
)
Cisco CCX
CCX V5 support
Radio stream
2x2 multiple-input multiple-output (MIMO) with two spatial streams
Operating Voltage
3.3 V ±10% I/O supply voltage
OS supported
Windows 2000/XP/Vista/Win7/ Linux
Power Consumption
TX Mode: 600mA
RX Mode: 237mA
Associated Idle: 11mA
RF-off Mode: 9mA
Antenna Type
2 U.FL RF connectors
Antenna
1 Ant. Type PIFA Model No.
Peak Gain (dBi) 2.4G -2.4 5.15~5.25GHz -5.1 5.725~5.850GHz -3.6
2 Ant. Type PIFA Model No.
Peak Gain (dBi) 2.4G -2.4 5.15~5.25GHz -5.1 5.725~5.850GHz -3.6
PMT0073
PMT0073
![](/img.php?id=2803362&img=bg5.png)
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or
transmitter.
For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other
channels is not possible.
This device is restricted to indoor use.
![](/img.php?id=2803362&img=bg6.png)
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
This module is intended for OEM integrator.
The OEM integrator is still responsible for the FCC compliance requirement of the end product, which
integrates this module.
Appropriate measurements (e.g. 15 B compliance) and if applicable additional equipment authorizations (e.g.
Verification , Doc) of the host device to be addressed by the integrator/manufacturer.
IMPORTANT NOTE:
This module is intended for OEM integrator. The OEM integrator is still responsible for the FCC compliance
requirement of the end product, which integrates this module.
20cm minimum distance has to be able to be maintained between the antenna and the users for the host this
module is integrated into. Under such configuration, the FCC radiation exposure limits set forth for an
population/uncontrolled environment can be satisfied.
Any changes or modifications not expressly approved by the manufacturer could void the user's authority to
operate this equipment.
USERS MANUAL OF THE END PRODUCT:
In the users manual of the end product, the end user has to be informed to keep at least 20cm separation with
the antenna while this end product is installed and operated. The end user has to be informed that the FCC
radio-frequency exposure guidelines for an uncontrolled environment can be satisfied. The end user has to
also be informed that any changes or modifications not expressly approved by the manufacturer could void
the user's authority to operate this equipment. If the size of the end product is smaller than 8x10cm, then
additional FCC part 15.19 statement is required to be available in the users manual: This device complies
with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) this device may not cause
harmful interference and (2) this device must accept any interference received, including interference that
may cause undesired operation.
![](/img.php?id=2803362&img=bg7.png)
LABEL OF THE END PRODUCT:
The final end product must be labeled in a visible area with the following " Contains TX FCC ID:
2ACHK-02110113 ". If the size of the end product is larger than 8x10cm, then the following FCC part 15.19
statement has to also be available on the label: This device complies with Part 15 of FCC rules. Operation is
subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device
must accept any interference received, including interference that may cause undesired operation.
Professional installation
Section 15.204(b) states that an approved "transmission system" must always be marketed as a complete
system including the antenna.
