Voxx Accessories PNP100 Projector Bluetooth Speaker User Manual
Voxx Accessories Corp. Projector Bluetooth Speaker
User manual
![](/img.php?id=2975526&img=bg1.png)
What’s in the box?
(1) Projector (1) Power adapter (3) Image wheels
2. LOAD AN IMAGE WHEEL 3. TURN ON THE PROJECTOR
Getting started
1. PLUG IN THE PROJECTOR
Plug the right-angle end of
the power adapter into the
DC IN jack on the bottom of
the projector.
Run the cable through the
cable trough on the bottom
of the projector. Then place
the projector on a flat
surface.
Plug the other end of
the power adapter into a
working outlet or surge
protector.
Bottom of the projector
Cable trough
On the back of the projector,
slide the image wheel door
into the FOR DISC ACCESS
position.
Take out the wheel drawer
above the image wheel door.
Please an image wheel on
the wheel drawer. Make sure
the UP label is facing up.
Put the wheel drawer back
into the image wheel door.
Slide the image wheel
door up, into the FOR
PROJECTION position.
IMPORTANT: The projector
will not illuminate unless
the image wheel door is in
the up (FOR PROJECTION)
position.
Back of the projector
Image wheel door
(down position)
Wheel drawer
To turn the projector on: Press the
PROJECTOR button on the front
of the projector.
To adjust brightness of the
projector (or turn it off): Press the
PROJECTOR button repeatedly to
cycle through the settings (high,
medium, low, and off).
4. ADJUST THE PROJECTOR POSITION
Front of the projector
Make sure the image wheel door
on the back of the projector is in
the FOR PROJECTION position
(pushed up).
Pull the projector lever below the
image wheel door to adjust the
projector position so that it points
where you want. Image wheel door
(up position)
Back of the projector
Projector lever
Everyday use
PLAYING SOUNDS
The Project Nursery Sight + Sound Projector offers a variety
of soothing lullabies and nature sounds, as well as white
noise, to calm baby.
To cycle through these
sounds: Press the SOUND
button on the front of the
projector. Each press goes to
a different selection.
To adjust the volume: Press
the VOLUME – or + button.
To turn sounds off: Press the
SOUND OFF button on the
top of the projector
Front of the projector
![](/img.php?id=2975526&img=bg2.png)
![](/img.php?id=2975526&img=bg3.png)
Quick Start Guide
PAIRING WITH YOUR PHONE
(BLUETOOTH)
The Project Nursery Sight & Sound Projector can also play
music from your smartphone or other Bluetooth device.
Here’s how to set it up.
Press and hold the
BLUETOOTH button on the
front of the projector until
the indicator light next to
this button starts blinking.
Enable Bluetooth on your
smartphone or other device
(if it isn’t already enabled).
USING THE TIMER
Front of the projector
Indicator
Choose “Sight+Sound” from the list of pairing options on
your smartphone. (If it’s not in the list, choose “Scan” from
your phone’s Bluetooth menu.)
The speaker gives an audio signal when it’s finished pairing and
connecting to your smartphone. The indicator turns solid blue.
Note: The process of enabling Bluetooth and connecting varies from device to
device. See your device’s owners manual for more information and specific
instructions.
Bluetooth Wireless Connection Tips
• Make sure the Bluetooth capability of your device is turned on.
• The Bluetooth wireless connection works up to a range of roughly 33 feet (10
meters). This range may vary, however, based on other factors, such as room
layout, wall material, obstacles, your device’s Bluetooth performance, etc. If
you’re having problems connecting to this speaker, move closer to it.
• If your device asks you for a password to connect, use “0000”.
Front of the projector
The timer shuts the projector
and sound off automatically
after a set amount of time.
To set the timer: Press the
TIMER button on the front of
the projector.
The TIMER indicator on the
top front of the projector
shows the amount of time
on the timer: 15, 30, or 60
minutes.
Press TIMER to cycle
through these options or
turn the timer off.
USING THE LIGHT
The front of the Sight & Sound
Projector offers soft area
illumination in three levels of
brightness, to complement the
projector lighting.
To turn the light on: Press the
LIGHT button on the front of the
projector.
To adjust or turn off the light:
Press the LIGHT button repeatedly
to cycle through the settings (high,
medium, low, and off).
Front of the projector
Questions?
Just call 1-844-393-7338 or visit ProjectNursery.com
©2016 Voxx Accessories Corp.
3502 Woodview Trace, Suite 220
Indianapolis, IN 46268 PNP100 QSG 00
