Note 1: Per Industry Canada Section 5.3 - The rated output power of this equipment is for single

carrier operation. For situations where multiple carrier signals are present, the rating would have

to be reduced by 3.5 dB, especially where the output signal is re-radiated and can cause

interference to adjacent band users. This power reduction is to be by means of input power or

gain reduction and not by an attenuator at the output of the device.

Spurious (in-band self gener-

ated)

–110 dBm referred to input ALC not invoked

Intermodulation –62 dBc two tones at –50 dBm

System noise figure 8 dB at mid-band ALC not invoked

Configurable RF output

Range

Step size

31 dB

1 ± 0.5 dB ± 10% of attenuation

monotonic

Blocking dynamic range 70 dB

Level limiting ALC threshold –40 dBm ± 3 dB instantaneous

Level limiting ALC range 30 dB

RF Forward and Reverse Path

Modulation Accuracy

Service–Mod Type–Parameter

TDMA–π/4-DQSK–rms EVM

GSM–GMSK–rms phase error

EDGE–8PSK–rms EVM

EIA-97D–CDMA–rho factor

4º

0.97%

Table 2-7. SCS 1900 MHz System Nominal Specifications, continued

PARAMETER SPECIFICATION REMARKS
