Addendum ADCP-75-237
ADC In-Building 850 and 1900 MHz Wireless
Repeater - User Manual Addendum
PRODUCT DESCRIPTION
This publication provides basic information about the ADC In-Building 850 and 1900
MHz Wireless Repeater. Place this addendum with ADCP-75-237.
The repeater transmits RF in both directions to provide indoor wireless coverage. The
device connected via coax to a donor antenna that is typically located on a rooftop or
external wall building, directed at the donor cell-site. The repeater is mounted inside the
building distributes the RF over coax to an indoor antenna located in the desired coverage
area.
Wireless Repeater Nominal Specifications:
PARAMETER SPECIFICATION REMARKS
System bandwidth 15 + 5 MHz - PCS
A or B Band - Cellular
Frequency range (TX) 1930 – 1990 MHz - PCS
869 – 894 MHz - Cellular
Out-of-band emissions -13 dBm per 1 MHz bandwidth
from 30 MHz to 20 GHz
Passband Gain 60.0 dB
Composite RF Output power
(see Note 1 at end of table) +13 dBm (20.0 mWatts) at
antenna port
Gain variation ± 3 dB over temp and unit-to-
unit
Gain flatness
Band flatness
Channel flatness
± 1.5 dB across freq. range
± 1.0 dB across any 1.25 MHz
channel
Mounting Wall mounted
Operating Temperature -5° C to +45° C
Antenna Connector 50 ohm N-Type (Female)
50 ohm SMA-Type (Female) 50 ohm impedance
Voltage Input 100-240 VAC, 47-63 Hz
Note 1: Per Industry Canada Section 5.3 - The Manufacturer's rated output power of this equipment is for single
carrier operation. For situations when multiple carrier signals are present, the rating would have to be reduced by
3.5 dB, especially where the output signal is re-radiated and can cause interference to adjacent band users. This
power reduction is to be by means of input power or gain reduction and not by an attenuator at the output of the
device."
Mailing Address: P.O. Box 1101, Minneapolis, Minnesota 55440-1101
World Headquarters: Minneapolis, Minnesota USA +1.952.938.8080 www.adc.com
STANDARDS CERTIFICATION
FCC: This equipment complies with the applicable sections of Title 47 CFR Part 22 (850
MHz Cellular and Part 24 (1900 MHz PCS).
IC: This equipment complies with the applicable sections of RSS-131. The term “IC:” before
the radio certification number only signifies that Industry Canada Technical Specifications
were met.
Caution: Modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
Note: To comply with Maximum Permissible Exposure (MPE) requirements, antennas must
be installed to provide at least 20 centimeters of separation from all persons per FCC
47CFR, Part 2.1091 and IC RSS-102, Section 2.5.2.
