PREFACE
ThismanualprovidesinstallationinstructionsforInterReachSpectrum®RemoteAccessUnits
(RAUs).Table1liststhestandardRAUsthataresupportedinthisdocument.
Table1.SupportedSpectrumStandardRemoteAccessUnits
Catalog Number Description
Standard RAUs
SPT-M1-8519-1 Spectrum, 850-1900 Main RAU
SPT-S1-8519-22 Spectrum, 850 Path 2-1900 Path 2 Secondary RAU
SPT-S1-8090-1 Spectrum, 800-900 SMR Secondary RAU
SPT-S1-80AWS-1 Spectrum, 800-2100AWS Path 1 Secondary RAU
SPT-S1-8019-22 Spectrum, 800 Path 2-1900 Path 2 Secondary RAU
SPT-S2-70AWS-1-SISO Spectrum, 700 SISO-2100AWS Path 1 SEC RAU, UpperC-LowerABC
SPT-S2-70AWS-22-SISO Spectrum, 700 Path 2 SISO-2100AWS Path 2 SEC RAU, UpperC-LowerABC
SPT-S1-7070-1-MIMO Spectrum, 700 MIMO Secondary RAU, UpperC-LowerABC
SPT-M1-AWS19-11 Spectrum, 2100AWS Path 1-1900 Path 1 Main RAU
SPT-S1-AWS19-12 Spectrum, 2100AWS Path 1-1900 Path 2 Secondary RAU
SPT-S1-2121-1-MIMO Spectrum, 2100AWS MIMO Secondary RAU
High Power RAUs
SPT-M3-8519-11-HP Spectrum, 850 Path1-1900 HP Main RAU
SPT-S3-8519-22-HP Spectrum, 850 Path2 - 1900 HP Path2 Secondary RAU
SPT-S3-70AWS-11-HP Spectrum, 700 Path1 uC/LABC-AWS HP Path1 Secondary RAU
SPT-S3-70AWS-22-HP Spectrum, 700 Path2 uC/LABC-AWS HP Path2 Secondary RAU
InterReachSpectrumUserDocumentation
TheInterReachSpectrumuserdocumentationisintendedforsystemadministrators,engineers
andinstallersresponsibleforplanning,administering,configuring,andmaintainingTE
ConnectivityInterReachSpectrumsystems.Table1liststhemanualsthatcorrespondtothis
InterReachSpectrumrelease.
Table2.InterReachSpectrumUserDocumentation
Title TECP Number
InterReachSpectrumElementManagementSystem8.1UserManual TECP-77-215
InterReachSpectrumHostUnitInstallationGuide TECP-77-220
InterReachSpectrumExpansionModuleGroupInstallationGuide TECP-77-221
InterReachSpectrumRemoteAccessUnitInstallationGuide TECP-77-222
FlexWavePrismOADMSpliceBoxInstallationGuide TECP-77-208
InterReach Spectrum User Documentation
InterReach Spectrum Remote Access Unit Installation Guide Page 3
TECP-77-222 • Issue 1 • November 2012 © 2012 TE Connectivity Ltd.
AccessingUserDocumentationontheTECustomerPortal
AccesstotheCustomerPortalrequiresauseraccountandpassword.Ifyoudonothavean
account,clickontheregistrationlinkontheLogInpage.
1ClickonthefollowingURLlinkorentertheURLintoyourwebbrowser,andthenpressEnter
onyourkeyboard:
https://www.te.com/commerce/uso/myaccount.do
2ClickMy Account > TE/Wireless Portal.
3OntheCustomerPortalHomepage,clickManualsandDataSheets.
4IntheManuals and Data Sheets Sectionspanel,clickontheproductnameofthedocumentyouneed
toaccess.
5Clickonthetitleofthemanualthatyouneedtoopen/download.
DocumentCautionsandNotes
Twotypesofmessages,identifiedbelow,appearinthetext:
CAUTION! Cautiontextindicatesoperationsorstepsthatcouldcausepersonalinjury,induceasafety
probleminamanageddevice,destroyorcorruptinformation,orinterruptorstopservices.
NOTE: Notetextcontainsinformationaboutspecialcircumstances.
FCC: ThisequipmentcomplieswiththeapplicablesectionsofTitle47CFR,Part22
(800MHzCellular),Part24(1900MHz‐PCS),Part90(800/900‐SMR),andPart27
(700MHz,2100MHz‐AWS).
Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothecondition
thatthisdevicedoesnotcauseharmfulinterference.
NOTE: The U.S. Federal Communications Commission (FCC) has developed guidelines
for evaluation of human exposure to RF emissions. The guidelines incorporate limits
for Maximum Permissible Exposure (MPE) for power density of transmitter operating at
frequencies between 300 kHz and 100 GHz. Limits have been set for portable, mobile,
and fixed equipment. TE Connectivity products fall in the category of fixed equipment;
products intended to be permanently secured and exposures are evaluated for
distances greater than 40cm (15.75”). Portable devices fall into exposures of less than
20cm, where SAR evaluations are used.
Antenna gain is restricted to 390mW ERP (. 8 30mW EIRP) in order to satisfy RF exposure
compliance requirements. If higher than 38 5mW ERP, routine MPE evaluation is needed.
The antennas should be installed to provide at least 40cm from all persons to satisfy
MPE requirements of FCC Part 2, 2.1091.
UL/CUL: Thiswillbeinstalledinarestrictedaccesslocation.Thisequipmentcomplies,
perULandCUL50,StandardforEnclosuresforElectricalEquipment.
UL/CUL: ThisequipmentcomplieswithULandCUL60950‐1StandardforSafetyfor
InformationTechnologyEquipment,includingElectricalBusinessEquipment.
UL/CUL: AllInterReachSpectrumRAUsarePlenumratedandsuitableforusein
environmentalairspaceinaccordancewithSection300‐22(C)oftheNationalElectrical
Code,andSections2‐128,12‐010(3)and12‐100oftheCanadianElectricalCode,Part1,
CSAC22.1.
UL: ThisequipmentisULPlenumratedunderUL2043.
CAUTION! Modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Standards Certification
InterReach Spectrum Remote Access Unit Installation Guide Page 5
TECP-77-222 • Issue 1 • November 2012 © 2012 TE Connectivity Ltd.
PRODUCTOVERVIEW
InterReachSpectrumsupportsupto8bandsinasinglesystem.Eachantennalocationsupports
thosebandsinmodular,grouppairings.EachlocationincludesaMainRemoteAccessUnit
(MRAU)thatcanpoweruptothreeadditionalSecondaryRAUs(SRAUs),eachofwhichsupport
twopoweramplifierpairsforatotalofeightamplifiers.MRAUsandSRAUsaregroupedlogically
basedoncommonserviceprovidergroupingsandinclude:850/1900,700/700MIMO,800/900
SMR,700SISO/AWS,and800/AWS.AddingfrequencyisassimpleasplugginginanSRAUtothe
existingMRAU.
RAUsareavailableintwodifferentoutputpoweroptions:StandardandHighPower.Thesecan
be“mixedandmatched”onasystemtomeetthespecificneedsofavenue.
SinceSpectrumcanbeconfiguredtosupportasmanyasfourcascadedrunsofsixteentotal
ExpansionModuleGroups,thesystemconfigurationpossibilitiesareseeminglyendlessandcan
scaletosinglesystemsthatincludeasmanyas128MRAUlocations,witheachofthoselocations
supportingbetweenoneandeightRFbands.Andeachofthosebandlocationsoffers26dBm
(P1dB)or31dBm(P1dB)ofoutputpowerbasedonselectingstandardorHighPower(HP)RAUs.
ThesystemmaybescaledtoaddnewbandsorRAUlocationsitesas‐neededandoffersgreat
serviceflexibilityandperformancerelativetoshared,wide‐bandamplifiersystems.Eachservice
providermaycontroltheirbandofinterestandenjoythepredictabilityinconsistentserviceat
eachRAUlocationindependentofwhatotheroperatorsaredoingorthelengththesignaltravels
totheservicearea.
TheRAUsaretypicallymountedaboveceilingtilesorinoutof‐sightlocationsascloseaspossible
totheservicearea.
Product Overview
Page 6 InterReach Spectrum Remote Access Unit Installation Guide
© 2012 TE Connectivity Ltd TECP-77-222 Issue 1 November 2012
Figure1illustrateshowRFandIFsignalsaresentbetweenSpectrumunitsandmodules.
LINK STATUS
SECONDARY
REV
SECONDARY
FWD
SECONDARY
REV
SECONDARY
FWD
LINK STATUS
REV IF OUT REV SECONDARY PORTS
1 2 3
FWD SECONDARY PORTS
1 2 3
FWD IF IN
LINK STATUS
Host
SRAU
MRAU
Power
Supply
IFEU
DRU
IF
RF
Omni
Antenna
R
F
R
F
x
x x
xx
x x
xx
x x
xx
x
x x
xx
x x
xx
x x
xx
x
REMOTE
SYSTEM II
IF DART
XXXXXXXXXX
BW XX MHz
FWD
IF OUT
REV
IF IN
PWR
STATUS
REMOTE
IF DART
XXXXXXXXXX
BW XX MHz
FWD
IF OUT
REV
IF IN
PWR
STATUS
REMOTE
IF DART
XXXXXXXXXX
BW XX MHz
FWD
IF OUT
REV
IF IN
PWR
STATUS
REMOTE
IF DART
XXXXXXXXXX
BW XX MHz
FWD
IF OUT
REV
IF IN
PWR
STATUS
REMOTE
IF
IF
HOST
SYSTEM II
RF DART
SMR900
FWD 935-940
REV 896-901
REV
RF OUT
FWD
RF IN
FWD NOT TO
EXCEED +5 dBm
PWR
STATUS
HOST
RF DART
SMR900
FWD 935-940
REV 896-901
REV
RF OUT
FWD
RF IN
FWD NOT TO
EXCEED +5 dBm
PWR
STATUS
HOST
RF DART
SMR900
FWD 935-940
REV 896-901
REV
RF OUT
FWD
RF IN
FWD NOT TO
EXCEED +5 dBm
PWR
STATUS
HOST
RF DART
SMR900
FWD 935-940
REV 896-901
REV
RF OUT
FWD
RF IN
FWD NOT TO
EXCEED +5 dBm
PWR
STATUS
HOST
NOTE: Units shown are not to scale.
NOTE: AllFWDportsonallModulesarecolorcodedredandallREVportsarecolorcodedblue,which
makestheDRU,IFEU,andRAUcablingprocesseasiertocomplete.
Figure1.REV and FWD Signals for the RAU
NOTE: ThisbookreferstotheOmniAntenna(4214M727),whichistheantennathatTEConnectivity
recommends.Otherantennasmaybeused.ForfurtherinformationontheOmniAntenna,see
“AppendixC:OmniAntenna”onpage29.
Main Remote Access Units
InterReach Spectrum Remote Access Unit Installation Guide Page 7
TECP-77-222 • Issue 1 • November 2012 © 2012 TE Connectivity Ltd.
MainRemoteAccessUnits
TheMainRemoteAccessUnit(MRAU)receivesFWDIFsignalsfromanIFExpansionUnit(IFEU),
whichispartoftheSpectrumExpansionModuleGroup,using75CATVcable.TheMRAU
convertstheIFsignalstoRFandsendsthemtoapassiveRFantennausing50coaxialcable.The
MRAUalsoreceivesconfigurationinformationandpowerfromandsendsitsstatusinformation
totheIFEU.
TheMRAUreceivesREVRFsignalsfromapassiveRFantennausing50coaxialcable.Itconverts
thesignalstoIFandsendsthemtotheIFEUusing75CATVcable.
MRAUPorts,Cable,andConnectors
REV IF OUT REV SECONDARY PORTS
1 2 3
FWD SECONDARY PORTS
1 2 3
FWD IF IN
LINK STATUS
1 2
36 54
Ref # Component Device Function
1RF SubMiniature version A
(SMA) cable (1)
50 RF SMA-to-SMA cable Connects two RF bands together when there is only one
N-type connector on the RAU.
For cases when there is an N-type connector for each RF
band (700MIMO or PCS/AWS), there will not be an SMA
cable.
2Antenna port(s) 50 N-type connector Connects to an antenna. See Table 3 on page 11.
3FWD IF IN connector F connector port Connects to the IFEU FWD Module IF OUT connector via
CATV cable.
4FWD SECONDARY PORTS (1 - 3) F connector ports Connect to a SRAU SECONDARY FWD connector via
CATV cable.
5REV SECONDARY PORTS (1 - 3) F connector ports Connect to a SRAU SECONDARY REV connector via
CATV cable.
6REV IF OUT connector F connector port Connects to the IFEU REV Module IF IN connector via
CATV cable.
(1) The AWS/PCS MRAUs does NOT have an RF SMA cable, and has two Antenna ports.
Product Overview
Page 8 InterReach Spectrum Remote Access Unit Installation Guide
© 2012 TE Connectivity Ltd TECP-77-222 Issue 1 November 2012
MRAULEDs
REV IF OUT REV SECONDARY PORTS
1 2 3
FWD SECONDARY PORTS
1 2 3
FWD IF IN
LINK STATUS
415
2 3
Ref # LED LED Color Description
1FWD SECONDARY PORT
(1 - 3)
2LINK
3STATUS
4REV SECONDARY PORT
(1 - 3)
5FWD IF IN
Green Downstream unit correctly connected; unit has no alarms or a
Minor alarm is active.
Blinking Green SRAU or band is set out-of-service.
Yellow FWD cable connected to SRAU, no REV cable connected.
Blinking Yellow FWD and REV cables are not connected to the same port number
(incorrectly paired).
Red Major alarm in downstream unit, fault lockout, or SRAU
disconnected.
Off No SRAU previously connected.
Green MRAU receiving communications from the IFEU.
Red MRAU has not received communications from the IFEU for more
than 90 seconds.
Off During initial power up, MRAU is powering up and waiting for IFEU
communications.
Green Unit has no alarms or a Minor alarm is active.
Blinking Green Unit or band is set out-of-service.
Red Major alarm detected.
Green Downstream unit correctly connected, unit has no alarms or minor
alarm
Blinking Green SRAU or band is set out-of-service.
Blinking Yellow FWD and REV cables are not connected to the same port number
(incorrectly paired).
Red Major alarm in downstream unit, fault lockout, or SRAU
disconnected.
Off No SRAU previously connected.
Green MRAU is powered on correctly.
•Y
ellow or
Blinking Yellow
There is an IFEU FWD connection, but there is no IFEU REV
connection or the IFEU REV connection is paired incorrectly.
Off Cable is not connected to the IFEU FWD port.
Secondary Remote Access Units
InterReach Spectrum Remote Access Unit Installation Guide Page 9
TECP-77-222 • Issue 1 • November 2012 © 2012 TE Connectivity Ltd.
SecondaryRemoteAccessUnits
ASecondaryRemoteAccessUnit(SRAU)receivesFWDIFsignalsfromtheMRAU,using75
CATVcable.TheSRAUconvertstheIFsignalstoRFandsendsthemtoapassiveRFantennausing
50coaxialcable.TheSRAU,throughtheMRAU,alsoreceivesconfigurationinformationand
powerfromandsendsitsstatusinformationtotheIFEU.
TheSRAUreceivesREVRFsignalsfromapassiveRFantennausing50coaxialcable.Itconverts
thesignalstoIFandsendsthemtotheMRAUusing75CATVcable.
SRAUPorts,Cable,andConnectors
142
3
LINK STATUS
SECONDARY
REV
SECONDARY
FWD
SECONDARY
REV
SECONDARY
FWD
LINK STATUS
Ref
#
Component Device Function
1SECONDARY REV connector F connector port Connects to one of the MRAU REV SECONDARY ports (1 - 3)
via CATV cable.
2RF SMA cable (1)
50 RF SMA-to-SMA cable
Connects two RF bands together when there is only one
N-type connector on the RAU.
For cases when there is an N-type connector for each RF band
(700MIMO or PCS/AWS), there will not be an SMA cable.
3Antenna port(s) 50 N-type connector Connects to an antenna. See Table 3 on page 11.
4SECONDARY FWD connector F connector port Connects to one of the MRAU FWD SECONDARY ports (1 - 3)
via CATV cable.
(1) The 700 MIMO SRAUs does NOT have an RF SMA cable, and has two Antenna ports.
Product Overview
Page 10 InterReach Spectrum Remote Access Unit Installation Guide
© 2012 TE Connectivity Ltd TECP-77-222 Issue 1 November 2012
SRAULEDs
LINK STATUS
SECONDARY
REV
SECONDARY
FWD
SECONDARY
REV
SECONDARY
FWD
LINK STATUS
312
Ref # LED LED Color Description
1 LINK
2STATUS
3SECONDARY FWD
•Green •SRAU receiving communications from the IFEU.
Red SRAU has not received communications from the IFEU for more than 90
seconds.
Off During initial power up, SRAU is powering up and waiting for IFEU
communications.
Green Unit has no alarms or a Minor alarm is active.
Blinking Green Unit or band is set out-of-service.
Red Major alarm detected.
Green SRAU is powered on correctly.
Yellow or
Blinking Yellow
There is an MRAU FWD connection, but there is no MRAU REV connection
or the MRAU REV connection is paired incorrectly.
Off Cable is not connected to the MRAU FWD port.
RAU N Connectors
InterReach Spectrum Remote Access Unit Installation Guide Page 11
TECP-77-222 • Issue 1 • November 2012 © 2012 TE Connectivity Ltd.
RAUNConnectors
EachRAUalsohasoneortwo50N‐typeconnectorsthatconnecttoapassiveantenna.Table3
liststhenumberofN‐typeconnectorsavailableoneachRAUmodel.
Table3.NumberofNConnectorsonRAUs
Catalog Number Description Number of RF
N Connectors*
Standard RAUs
SPT-M1-8519-1 Spectrum, 850-1900 Main RAU 1
SPT-M1-AWS19-11 Spectrum, 2100AWS Path 1-1900 Path 1 Main RAU 2
SPT-S1-2121-1-MIMO Spectrum, 2100AWS MIMO Secondary RAU 2
SPT-S1-7070-1-MIMO Spectrum, 700 MIMO Secondary RAU, UpperC-LowerABC 2
SPT-S1-8019-22 Spectrum, 800 Path 2-1900 Path 2 Secondary RAU 1
SPT-S1-8090-1 Spectrum, 800-900 SMR Secondary RAU 1
SPT-S1-80AWS-1 Spectrum, 800-2100AWS Path 1 Secondary RAU 1
SPT-S1-8519-22 Spectrum, 850 Path 2-1900 Path 2 Secondary RAU 1
SPT-S1-AWS19-12 Spectrum, 2100AWS Path 1-1900 Path 2 Secondary RAU 2
SPT-S2-70AWS-1-SISO Spectrum, 700 SISO-2100AWS Path 1 SEC RAU, UpperC-LowerABC 1
SPT-S2-70AWS-22-SISO Spectrum, 700 Path 2 SISO-2100AWS Path 2 SEC RAU, UpperC-LowerABC 1
High Power RAUs
SPT-M3-8519-11-HP Spectrum, 850 Path1-1900 HP Main RAU 1
SPT-8519-22-HP Spectrum, 850 Path2 - 1900 HP Path2 Secondary RAU 1
SPT-S3-70AWS-11-HP Spectrum, 700 Path1 uC/LABC-AWS HP Path1 Secondary RAU 1
SPT-S3-70AWS-22-HP Spectrum, 700 Path2 uC/LABC-AWS HP Path2 Secondary RAU 1
* There are two bands per RAU, which results in two N connectors. When there is one N connector, the two bands are
combined internally and both bands use the single N connector.
Install the RAUs and Antennas
Page 12 InterReach Spectrum Remote Access Unit Installation Guide
© 2012 TE Connectivity Ltd TECP-77-222 Issue 1 November 2012
INSTALLTHERAUSANDANTENNAS
FollowthestepsintheorderprovidedtoinstalltheRAUsandantennas.
MounttheRAUsandAntennas
GeneralSafetyPrecautions
CAUTION! Wetconditionsincreasethepotentialforreceivinganelectricalshockwheninstallingorusing
electricallypoweredequipment.Topreventelectricalshock,neverinstalloruseelectrical
equipmentinawetlocationorduringalightningstorm.
CAUTION! ThissystemisaRFTransmitterandcontinuouslyemitsRFenergy.Maintainaminimum8inch
(20cm)clearancefromtheantennawhilethesystemisoperating.Wheneverpossible,shut
downtheRANbeforeservicingtheantenna.
NOTE: RAUsaresuitableforuseinenvironmentalairspaceinaccordancewithSection30022(c)ofthe
NationalElectricalCode,andSections2128,12010(3)and12100oftheCanadianElectrical
Code,Part1,CSAC22.1.
CAUTION! InstallRAUsinindoorlocationsonly.Donotconnectanantennainstalledinanoutdoorlocation
toaRAU,unlessitisinanapprovedAOCweatherproofNEMA4housing.
CAUTION! AttachallRAUssecurelytoastationaryobject(thatis,awall,pole,orceilingbrackets).Tomount
aRAUsecurelytoawall,ceilingbracket,orpole,use#6diameterfastenersinthefourslotted
mountingholes.
CAUTION! Dothefollowingtomaintainproperventilation:
Keepatleast76mm(3inch)clearancearoundtheRAU.
DonotstackRAUsontopofeachother.
AlwaysmounttheRAUwiththesolidface(containingthemountingholes)againstthe
mountingsurface.
NOTE: YoucanplacetheRAU,withoutitsfasteninghardware,onaflatsurface,suchasashelf,desk,
cabinet,oranyotherhorizontalsurfacethatallowsstableplacement,withthemountingbase
facingdowntothemountingsurface.
CAUTION! IfinstallingtheRAUonaflatsurface,thesurfacemustbeabletoholdaminimum7poundload
securely.
General Safety Precautions
InterReach Spectrum Remote Access Unit Installation Guide Page 13
TECP-77-222 • Issue 1 • November 2012 © 2012 TE Connectivity Ltd.
Dothefollowing,intheorderpresented,tomounttheRAUsandantennas:
1MountallMRAUandSRAUsinthelocationsmarkedonthefloorplans.
2Installthepassiveantennasaccordingtothemanufacturer’sinstallationinstructions.
NOTE: Itiscommonpracticetoinstallpassiveantennasbelowtheceiling.Ifyouinstallapassive
antennaabovetheceiling,whenestimatingtheantennacoveragearea,accountforadditional
lossduetotheceilingmaterial.
3Connectapassivemulti‐bandantennatotheNconnectoroneachRAUusingcoaxialcable
withtheleastamountoflosspossible.(See“AppendixC:OmniAntenna”onpage29for
informationontheOmniAntennaports.)
Omni Antenna
False Ceiling
SRAU N1
REV IF OUT REV SECONDARY PORTS
1 2 3
FWD SECONDARY PORTS
1 2 3
FWD IF IN
LINK STATUS
LINK STATUS
SECONDARY
REV
SECONDARY
FWD
MRAU N1
Coaxial cable
Coaxial cable
CAUTION! FirmlyhandtightentheNconnector.DONOTovertightentheconnector.
Install the RAUs and Antennas
Page 14 InterReach Spectrum Remote Access Unit Installation Guide
© 2012 TE Connectivity Ltd TECP-77-222 Issue 1 November 2012
ConnecttheIFEUtotheMRAU
NOTE: TheIFEUshouldbepoweredupbeforestartingthisprocedure;seetheInterReachSpectrum
ExpansionModuleGroupInstallationGuide(TECP77167).
4FollowtheserulesfortheCATVcableswhenconnectingtheIFEUtotheMRAU:
TheFWDandREVcablesshouldbeclosetothesamelength.
TheFWDandREVcablesshouldbethesamecabletype(bothRG6orbothRG11).
ApairofCATVcablesconnectseachMRAUtotheIFEU.TheIFEUREVModuleIFINport
andtheIFEUFWDModuleIFOUTportmustmatch.Forexample,ifIFEUREVModuleIF
INPort3isused,useIFEUFWDModuleIFOUTPort3.
RefertoAppendixB:75OhmCATVCableonpage24forinformationonmaximumRG‐6
orRG‐11CATVcablelengths.
5TestthecableterminationforeachCATVcablebeforeinstallingit.
6ConnectFconnectorCATVcablesontheIFEUandMRAU,intheordergivenbelow.
IftheLEDsdonotperformasdescribedinthisprocedure,referto“MRAULEDs”onpage8.
aConnectaCATVcablefromoneoftheIFEUFWDModuleIFOUTconnectors(1‐8)tothe
MRAUFWDIFINconnector.
bConfirmthattheMRAUFWDIFINLEDisyellow,whichindicatesacorrectphysical
connection.
cConnectaCATVcablefromtheIFEUREVModuleIFINconnector(1‐8)totheMRAUREV
IFOUTconnector,makingsurethatyoupairtheportusedtothesameportnumber
selectedinStep6a.
Iftheconnectioniscorrect,theMRAUpowersupandtheMRAUFWDIFINLEDturns
green.
REV IF OUT REV SECONDARY PORTS
1 2 3
FWD SECONDARY PORTS
1 2 3
FWD IF IN
LINK STATUS
IFEU
Step 6a
To an antenna
MRAU
Step 6b
Step 6c
KEY: IFEU FWD Module IF OUT connector to MRAU FWD IF IN connector
IFEU REV Module IF IN connector to MRAU REV IF OUT connector
Connect the IFEU to the MRAU
InterReach Spectrum Remote Access Unit Installation Guide Page 15
TECP-77-222 • Issue 1 • November 2012 © 2012 TE Connectivity Ltd.
Install the RAUs and Antennas
Page 16 InterReach Spectrum Remote Access Unit Installation Guide
© 2012 TE Connectivity Ltd TECP-77-222 Issue 1 November 2012
ConnecttheMRAUtoSRAUs
CAUTION! Topreventinterference,donotinstallan850/1900MRAUantennanearan800/900SRAU.The
850MHzbandmustbe20feetawayfromthe800/1900SRAU’spassiveantenna.
7Useoneofthefollowing6’and20’CATVRG6jumpers,availableforpurchasefromTE
Connectivity,toconnectanMRAUtoSRAUs.
TE Connectivity
Part Number
Description Note
300469-0 6’ RG-6 Cable; F Male to F Male CATV cable that connects the MRAU to SRAUs. Two
cables required per SRAU.
300469-1 20’ RG-6 Cable; F Male to F Male CATV cable that connects the MRAU to SRAUs. Two
cables required per SRAU.
8TestthecableterminationforeachCATVcablebeforeinstallingit.
9ConnectFconnectorCATVcablesfromtheMRAUtoanSRAU,intheordergivenbelow.Ifthe
LEDsdonotperformasdescribedinthisprocedure,referto“SRAULEDs”onpage10.
aConnectaCATVcablefromanMRAUFWDSECONDARYPORT(1,2,or3)Fconnectorto
theSRAUSECONDARYFWDFconnector.
bConfirmthattheSRAUSECONDARYFWDLEDisyellow,whichindicatesacorrect
physicalconnection.
cConnectaCATVcablefromanMRAUREVSECONDARYPORT(1,2,or3)Fconnectorto
theSRAUSECONDARYREVFconnector,matchingthesameportnumberselectedinStep
9a.Thatis,ifinStep9ayouconnectedanFconnectortotheMRAUFWDSECONDARY
PORT1,thepairedCATVcablemustconnecttotheMRAUREVSECONDARYPORT1.
Iftheconnectioniscorrect,theSRAUpowersupandtheSRAUSECONDARYFWDLED
turnsgreen.
MRAU
REV IF OUT REV SECONDARY PORTS
1 2 3
FWD SECONDARY PORTS
1 2 3
FWD IF IN
LINK STATUS
KEY: MRAU FWD Secondary port to SRAU Secondary FWD port
MRAU REV Secondary port to SRAU Secondary REV port
LINK STATUS
SECONDARY
REV
SECONDARY
FWD
SECONDARY
REV
SECONDARY
FWD
LINK STATUS
SRAU
To an antenna
To an antenna
To an IFEU
REV Module
IF IN connector
(1 - 8)
To an IFEU
FWD Module
IF OUT connector
(1 - 8)
Step 9a
Step 9b
Step 9c
Connect the MRAU to SRAUs
InterReach Spectrum Remote Access Unit Installation Guide Page 17
TECP-77-222 • Issue 1 • November 2012 © 2012 TE Connectivity Ltd.
Install the RAUs and Antennas
Page 18 InterReach Spectrum Remote Access Unit Installation Guide
© 2012 TE Connectivity Ltd TECP-77-222 Issue 1 November 2012
10 RepeatStep9toinstalluptotwomoreSRAUs,aspersystemdesign.
REV IF OUT REV SECONDARY PORTS
1 2 3
FWD SECONDARY PORTS
1 2 3
FWD IF IN
LINK STATUS
LINK STATUS
SECONDARY
REV
SECONDARY
FWD
LINK STATUS
SECONDARY
REV
SECONDARY
FWD
LINK STATUS
SECONDARY
REV
SECONDARY
FWD
MRAU
SRAU1
SRAU2
SRAU3
To an IFEU FWD Module
IF OUT connector (1 - 8)
To an IFEU REV Module
IF IN connector (1 - 8)
To an antenna
To an antenna
To an antenna
To an antenna
KEY: FWD
REV
ConfiguretheMRAUsandSRAUs
RefertotheInterReachSpectrum™ElementManagementSystem7.3UserManual(TECP‐77‐200)
forinformationonhowtoconfiguretheMRAUsandSRAUs.
Remote Access Unit Specifications
InterReach Spectrum Remote Access Unit Installation Guide Page 19
TECP-77-222 • Issue 1 • November 2012 © 2012 TE Connectivity Ltd.
APPENDIXA:SPECIFICATIONS
RemoteAccessUnitSpecifications
OperatingTemp 25°Cto+50°C
StorageTemperature 40°Cto+70°C
Humidity 10%to95%noncondensing
Dimensions 11.50"x9.00"x3.50"
Weight 7.49Pounds
PowerSource +54Vdc(fromIFEU)
SpectrumSystemSpecifications
Low/Medium
PowerLevel
700900MHz
Typical
Low/Medium
PowerLevel
19002100MHz
Typical
High
PowerLevel
19002100MHz
Typical
TX RX TX RX TX RX
Averagegainwith180mCATV
at25°C(77°F)(dB)
401/43230 401/43230 48 30
Ripplewith180mCATV(dB) 2.5 3.0 3.5 4.0 3.5 4.0
OutputIP3(dBm) 38 38 43
InputIP3(dBm) ‐8 ‐8 ‐8
Output1dBCompressionPoint(dBm) 26 26 31
NoiseFigure1HU‐1EMG‐8RAUs(dB) 17 17 17
NoiseFigure1HU‐4EMG‐32RAUs(dB) 23 23 23
1 LowPowerisdefinedhereasaStandardMRAUused
withStandardSRAUs.
2 MediumPowerisdefinedhereasaHighPowerMRAU
usedwithStandardSRAUs.
RFSpecification
SupportedFrequencyBlocks 2perRemoteAntennaUnit;18perHostUnit
Bandwidth 1.5to75MHznoncontiguous
FrequencyBandSupported 850Cellular;800iDEN;900iDEN;1900PCS;2100AWS;
700UpperCLowerABC
PropagationDelay
SystemDelay <12microseconds
DelayManagementDigital (ManualorAutomatic)
RF Frequency
TX RX
850 Cell
Bandwidth 869-894 824-849
Gain (dB) 40 30
800 SMR
Bandwidth 851-869 806-824
Gain (dB) 40 30
900 SMR
Bandwidth 935-940 896-901
Gain (dB) 40 30
1900 PCS
Bandwidth 1930-1995 1850-1915
Gain (dB) 40 30
2100 AWS
Bandwidth 2110-2155 1710-1755
Gain (dB) 40 30
700 Upper C
Bandwidth 746-756 776-786
Gain (dB) 40 30
700 Lower ABC
Bandwidth 728-746 698-716
Gain (dB) 40 30
Appendix A: Specifications
Page 20 InterReach Spectrum Remote Access Unit Installation Guide
© 2012 TE Connectivity Ltd TECP-77-222 Issue 1 November 2012
NominalPassbandGains
Composite Power Out of RAU
InterReach Spectrum Remote Access Unit Installation Guide Page 21
TECP-77-222 • Issue 1 • November 2012 © 2012 TE Connectivity Ltd.
CompositePowerOutofRAU
Table4.LowPowerLevel:StandardMRAUwithSRAUs
Power per Carrier (dBm) per
Band
RF Frequency Number of RF Carriers
TX RX 1
P-out
2
P-out
4
P-Out
8
P-out
Standard MRAUs:
850 Cell 869-894 824-849
26.0 20.0 14.0 9.0 GSM
SPT-M1-8519-1 23.0 17.5 12.0 8.0 EDGE
SPT-M1-AWS19-11 15.0 12.0 9.0 6.0 CDMA
15.0 12.0 9.0 6.0 WCDMA
Standard SRAUs 15.0 12.0 9.0 6.0 LTE
SPT-S1-8090-1
800 SMR 851-869 806-824
17.5 14.0 10.0 6.5 iDEN
SPT-S1-7070-1-MIMO 26.0 19.5 13.5 8.5 APCO 25 C4FM
SPT-S1-80AWS-1 15.0 12.0 9.0 6.0 CDMA
SPT-S2-70AWS-1-SISO 15.0 12.0 9.0 6.0 LTE
SPT-S2-70AWS-22-SISO 900 SMR 935-940 896-901 17.5 14.0 10.0 6.5 iDEN
SPT-S1-AWS19-12 26.0 20.0 13.5 9.0 APCO 25 C4FM
SPT-S1-2121-1-MIMO
1900 PCS 1930-1995 1850-1915
26.0 20.0 14.0 9.0 GSM
SPT-S1-8019-22 23.0 17.5 12.0 8.0 EDGE
SPT-S1-8519-22 15.0 12.0 9.0 6.0 CDMA
15.0 12.0 9.0 6.0 WCDMA
15.0 12.0 9.0 6.0 LTE
2100 AWS 2110-2155 1710-1755 15.0 12.0 9.0 6.0 WCDMA
15.0 12.0 9.0 6.0 LTE
700 Upper C 746-756 776-786 15.0 12.0 9.0 6.0 LTE
700 Lower ABC 728-746 698-716
Table5.MediumPowerLevel:HighPowerMRAUs1usedwithStandardSRAUs
Power per Carrier (dBm) per
Band
RF Frequency Number of RF Carriers
TX RX 1
P-out
2
P-out
4
P-Out
8
P-out
850 Cell 869-894 824-849
26.0 20.0 14.0 9.0 GSM
23.0 17.5 12.0 8.0 EDGE
18.0 15.0 12.0 9.0 CDMA
18.0 15.0 12.0 9.0 WCDMA
Standard SRAUs 18.0 15.0 12.0 9.0 LTE
SPT-S1-8090-1
800 SMR 851-869 806-824
17.5 14.0 10.0 6.5 iDEN
SPT-S1-7070-1-MIMO 26.0 19.5 13.5 8.5 APCO 25 C4FM
SPT-S1-80AWS-1 18.0 15.0 12.0 9.0 CDMA
SPT-S2-70AWS-1-SISO 18.0 15.0 12.0 9.0 LTE
SPT-S2-70AWS-22-SISO 900 SMR 935-940 896-901 17.5 14.0 10.0 6.5 iDEN
SPT-S1-AWS19-12 26.0 19.5 13.5 8.5 APCO 25 C4FM
SPT-S1-2121-1-MIMO
1900 PCS 1930-1995 1850-1915
26.0 20.0 14.0 9.0 GSM
SPT-S1-8019-22 23.0 17.5 12.0 8.0 EDGE
SPT-S1-8519-22 18.0 15.0 12.0 9.0 CDMA
18.0 15.0 12.0 9.0 WCDMA
18.0 15.0 12.0 9.0 LTE
2100 AWS 2110-2155 1710-1755 18.0 15.0 12.0 9.0 WCDMA
18.0 15.0 12.0 9.0 LTE
700 Upper C 746-756 776-786 18.0 15.0 12.0 9.0 LTE
700 Lower ABC 728-746 698-716
Appendix A: Specifications
Page 22 InterReach Spectrum Remote Access Unit Installation Guide
© 2012 TE Connectivity Ltd TECP-77-222 Issue 1 November 2012
1 SeepowerpercarrierofHPMRAUfromTable6onpage23.
Table6.HighPowerLevel:HighPowerMRAUwithHighPowerSRAUs
Power per Carrier (dBm) per
Band
RF Frequency Number of RF Carriers
TX RX 1
P-out
2
P-out
4
P-Out
8
P-out
850 Cell 869-894 824-849
26.0 20.0 14.0 9.0 GSM
High Power MRAU 23.0 17.5 12.0 8.0 EDGE
SPT-M3-8519-11-HP 18.0 15.0 12.0 9.0 CDMA
18.0 15.0 12.0 9.0 WCDMA
High Power SRAUs 18.0 15.0 12.0 9.0 LTE
SPT-S3-70AWS-11-HP
800 SMR 851-869 806-824
17.5 14.0 10.0 6.5 iDEN
SPT-S3-70AWS-22-HP 26.0 19.5 13.5 8.5 APCO 25 C4FM
SPT-S3-8519-22-HP 18.0 15.0 12.0 9.0 CDMA
18.0 15.0 12.0 9.0 LTE
900 SMR 935-940 896-901 17.5 14.0 10.0 6.5 iDEN
26.0 19.5 13.5 8.5 APCO 25 C4FM
1900 PCS 1930-1995 1850-1915
26.0 23.0 19.0 14.0 GSM
26.0 22.5 17.0 13.0 EDGE
23.0 20.0 17.0 14.0 CDMA
23.0 20.0 17.0 14.0 WCDMA
23.0 20.0 17.0 14.0 LTE
2100 AWS 2110-2155 1710-1755 23.0 20.0 17.0 14.0 WCDMA
23.0 20.0 17.0 14.0 LTE
700 Upper C 746-756 776-786 18.0 15.0 12.0 9.0 LTE
700 Lower ABC 728-746 698-716
Composite Power Out of RAU
InterReach Spectrum Remote Access Unit Installation Guide Page 23
TECP-77-222 • Issue 1 • November 2012 © 2012 TE Connectivity Ltd.
Appendix B: 75-Ohm CATV Cable
Page 24 InterReach Spectrum Remote Access Unit Installation Guide
© 2012 TE Connectivity Ltd TECP-77-222 Issue 1 November 2012
APPENDIXB:75OHMCATVCABLE
The75‐OhmCATVCable:
connectstheIFEUtoMRAU(s)andtheMRAU(s)totheSRAU(s)
transmits(FWD)multibandandreceives(REV)IFsignals
deliversDCelectricalpowertotheRAUs.TheSpectrumIFEUDCvoltageoutputis+54Vdc
nominal.IftheIFEUreachesitscurrentlimit,acurrent‐limitingcircuitprotectsit.
carriesconfigurationandstatusinformation
uses75type‐Fconnectorswithcaptivecenterpins.
CATVCableRequirements
BeldenCATVcableorequivalentisrequired(seeFigure2).
FortheRG‐6cable,useaBelden1695ACoax.
FortheRG‐11cable,useaBelden7732ACoax.
RG-11
Belden 1695A Coax
RG-6
Belden 7732A Coax
NOTE: TEConnectivityrequiressolidcoppercenterconductorCATVcableforproperDCvoltagetothe
RAUandmaximumdistances.
Figure2.Belden 1695A and 7732A Coax Cables
UseRG‐6orRG‐11CATVcablebetweentheIFEUandMRAU,thetypicallengthsofwhichare
listedbelow.
Cable Type
Minimum Length Maximum Length
Meters Feet Meters Feet
RG-6 0 0 125 410
RG-11 0 0 180 590
Belden 1695A Coax Specifications
InterReach Spectrum Remote Access Unit Installation Guide Page 25
TECP-77-222 • Issue 1 • November 2012 © 2012 TE Connectivity Ltd.
UseonlyRG6CATVcablebetweentheMRAUandSRAU,thelengthsofwhicharelistedbelow.
RG-6 Cable Meters Feet
Typical 26.56
800/900 iDEN to 850 CELL 619.68
800 AWS to 850 CELL 619.68
Belden1695ACoaxSpecifications
Description
RG‐6/Utype,18AWGsolid0.040‐inchbarecopperconductor,plenum,foamFEPinsulation,
Duofoil®+tinnedcopperbraidshield(95%coverage),Flamarrest®jacket.
OverallPhysicalCharacteristics
Conductor OneCoax
18AWG
Solidstranding
BareCopper(BC)conductormaterial
0.040inchdiameter
Insulation Teflon®
FoamFluorinatedEthylenePropylene(FFEP)
0.170inchdiameter
OuterShieldLayer1Duofoil
®
Tape
AluminumFoilPolyesterTapeAluminumFoil
100%coverage
OuterShieldLayer2Braid
TinnedCopper(TC)
95%coverage
OuterJacket Flamarrest®
LowSmokePolyvinylChloride(LSPVC)
OverallCabling 0.234inchoverallnominaldiameter
Appendix B: 75-Ohm CATV Cable
Page 26 InterReach Spectrum Remote Access Unit Installation Guide
© 2012 TE Connectivity Ltd TECP-77-222 Issue 1 November 2012
OverallNominalElectricalCharacteristics
CharacteristicImpedance 75.000
Inductance 0.103H/ft.
CapacitanceConductortoShield 16.100(pF/ft.)
VelocityofPropagation 82(%)
Delay 1.240(ns/ft.)
ConductorDCResistance 6.400@20°C(/1000ft.)
OuterShieldDCResistance 2.800@20°C(/1000ft.)
Attenuation
Freq. (MHz) Attenuation (dB/100 ft.)
1.000 0.240
3.580 0.450
5.000 0.550
7.000 0.650
10.000 0.750
67.500 1.740
71.500 1.780
88.500 1.940
100.000 2.100
135.000 2.400
143.000 2.500
180.000 2.800
270.000 3.400
360.000 4.000
540.000 5.200
720.000 6.100
750.000 6.200
1000.000 7.300
1500.000 9.200
2000.000 10.900
2250.000 11.600
3000.000 13.700
Belden 7732A Coax Specifications
InterReach Spectrum Remote Access Unit Installation Guide Page 27
TECP-77-222 • Issue 1 • November 2012 © 2012 TE Connectivity Ltd.
Belden7732ACoaxSpecifications
Description
RG‐11/Utype,14AWGsolid0.064‐inchbarecopperconductor,plenum,foamFEPinsulation,
Duofoil®+tinnedcopperbraidshield(95%coverage),fluorocopolymerjacket.
OverallPhysicalCharacteristics
Conductor OneCoax
18AWG
Solidstranding
BareCopper(BC)conductormaterial
0.064inchdiameter
Insulation Teflon®
FoamFluorinatedEthylenePropylene(FFEP)
0.274inchdiameter
OuterShieldLayer1Duofoil
®
Tape
AluminumFoilPolyesterTapeAluminumFoil
100%coverage
OuterShieldLayer2Braid
TinnedCopper(TC)
95%coverage
OuterJacket Fluorocopolymer(PVDF)
OverallCabling 0.348inchoverallnominaldiameter
Appendix B: 75-Ohm CATV Cable
Page 28 InterReach Spectrum Remote Access Unit Installation Guide
© 2012 TE Connectivity Ltd TECP-77-222 Issue 1 November 2012
OverallNominalElectricalCharacteristics
CharacteristicImpedance 75.000
Inductance 0.091H/ft.
CapacitanceConductortoShield 16.300(pF/ft.)
VelocityofPropagation 83(%)
Delay 1.220(ns/ft.)
ConductorDCResistance 2.500@20°C(/1000ft.)
OuterShieldDCResistance 1.600@20°C(/1000ft.)
Attenuation
Freq. (MHz) Attenuation (dB/100 ft.)
1.000 0.150
3.580 0.260
5.000 0.300
7.000 0.340
10.000 0.400
67.500 1.200
71.500 1.240
88.500 1.400
100.000 1.500
135.000 1.780
143.000 1.840
180.000 2.090
270.000 2.600
360.000 3.100
540.000 3.890
720.000 4.570
750.000 4.680
1000.000 5.500
1500.000 6.910
2000.000 8.130
2250.000 9.200
3000.000 10.200
Belden 7732A Coax Specifications
InterReach Spectrum Remote Access Unit Installation Guide Page 29
TECP-77-222 • Issue 1 • November 2012 © 2012 TE Connectivity Ltd.
APPENDIXC:OMNIANTENNA
TheOmniAntenna(4214‐0727),showninFigure3,isaroundradomewiththefollowing
specifications:
Figure3.Omni Antenna
Port 1 Port 2 Port 3
Gain, typical 2 dBi @ 698-960 MHz 2 dBi @ 698-960 MHz 3 dBi @1710-2170 MHz
3 dBi @ 1710-2170 MHz 3 dBi @ 1710-2170 MHz 3 dBi @ 2496-2690 MHz
Nominal impedance 50 Ohm
Polarization Vertical
VSWR < 2:1
Port-to-port isolation >15 dB min, 22 dB typical
Power rating 5 Watt
Mechanical
Dimension of Antenna (DxH) 215 x 72 mm
Weight Less than or equal to 1.65 lbs (0.75kg), including pigtails
Connector N (male)
Cable (pigtail) length 6 feet, plenum rated cable
Color White, UV protected plastic for outdoor use
Mounting hardware Screws, anchor, and butterfly nut for ceiling tile mount
Environmental
Operating temperature - 40°C to + 65°C
Shipping and Handling ISTA Procedure 1A
Ingress protection IP-42
Flammability UL94V0 (Materials)
Compliance ROHS compliant
NOTE: TwoantennasperRAUisrequiredforMIMOperformance.
Appendix D: Contacting TE Connectivity
Page 30 InterReach Spectrum Remote Access Unit Installation Guide
© 2012 TE Connectivity Ltd TECP-77-222 Issue 1 November 2012
APPENDIXD:CONTACTINGTECONNECTIVITY
ContactingTEConnectivitybyTelephone
Sales
Asia Pacific +65-6294-9948
France 0800 914032
Germany 0180 2232923
Italy 0800 782374
Spain 900 983291
United Kingdom 0800 960236
USA or Canada 1-800-366-3891
Extension 73000
Connectivity Extension 73475
Wireless Extension 73476
Technical Support
USA or Canada 1-800-530-9960
Elsewhere +1-952-917-0761
OnlineAccesstoTEConnectivity
Customer Portal
https://www.te.com/commerce/uso/myaccount.do
Technical Support for Wireless Products
http://www.te.com/WirelessSupport

Navigation menu
