ThisinstallationguideprovidesinstallationinstructionsforInterReachSpectrum®RemoteAccessUnits(RAUs).
Preliminary - for standards compliance testing only.
Not for distribution to customer.
Main Remote Access Unit
Secondary Remote Access Unit
Page2InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution
©2014 TEConnectivityLtd. TECP77222Issue2 • 300001759666RevB•March2014
Table1liststhestandardRAUsthataresupportedinthisdocument.
RevisionHistory
DocumentCautionsandNotes
Twotypesofmessages,identifiedbelow,appearinthetext:
CAUTION! Cautionsindicateoperationsorstepsthatcouldcausepersonalinjury,induceasafetyprobleminamanageddevice,
destroyorcorruptinformation,orinterruptorstopservices.
NOTE: Notescontaininformationaboutspecialcircumstances.
Table1. SupportedSpectrumStandardRemoteAccessUnits
CatalogNumberDescription
StandardRAUs
SPTM185191Spectrum,8501900MainRAU
SPTS1851922 Spectrum,850Path21900Path2SecondaryRAU
SPTS180901*Spectrum,800900SMRSecondaryRAU
SPTS180AWS1*Spectrum,8002100AWSPath1SecondaryRAU
SPTS1801922*Spectrum,800Path21900Path2SecondaryRAU
SPTS270AWS1SISO Spectrum,700SISO2100AWSPath1SECRAU,UpperCLowerABC
SPTS270AWS22SISO Spectrum,700Path2SISO2100AWSPath2SECRAU,UpperCLowerABC
SPTS170701MIMO Spectrum,700MIMOSecondaryRAU,UpperCLowerABC
SPTM1AWS1911 Spectrum,2100AWSPath11900Path1MainRAU
SPTS1AWS1912 Spectrum,2100AWSPath11900Path2SecondaryRAU
SPTS121211MIMO Spectrum,2100AWSMIMOSecondaryRAU
HighPowerRAUs
SPTM3801931HP*Spectrum,800Path3‐1900HPPath1MainRAU
SPTM3851911HP Spectrum,850Path11900HPPath1MainRAU
SPTS3262612HP Spectrum,2600HPPath1‐2600HPPath2SecondaryRAU
SPTS370AWS11HP Spectrum,700Path1uC/LABCAWSHPPath1SecondaryRAU
SPTS370AWS22HP Spectrum,700Path2uC/LABCAWSHPPath2SecondaryRAU
SPTS3801922HP*Spectrum,800Path21900HPPath2SecondaryRAU
SPTS3851922HPSPT
S3801922HP
Spectrum,850Path2‐1900HPPath2SecondaryRAU
*ThisRAUisClassBSignalBooster;see“Part90SignalBoosters”onpage 26.
Issue DocumentDate TechnicalUpdates
1February2013 Initialrelease.
2March2014 Addssupportforthe2600HPPath1‐2600HPPath2SecondaryRAU;the800Path3‐1900HP
Path1MainRAU,andthePath21900HPPath2SecondaryRAU.
Addstorqueinformation;see“ConnecttheIFEUtotheMRAU”onpage 11and“Connectthe
MRAUtoSRAUs”onpage 12.
InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution Page3
TECP77222Issue2 • 300001759666RevB•March2014 ©2014 TEConnectivityLtd.
PRODUCTOVERVIEW
InterReachSpectrumsupportsupto8bandsinasinglesystem.Eachantennalocationsupportsthosebandsin
modular,grouppairings.EachlocationincludesaMainRemoteAccessUnit(MRAU)thatcanpoweruptothree
additionalSecondaryRAUs(SRAUs),eachofwhichsupporttwopoweramplifierpairsforatotalofeight
amplifiers.MRAUsandSRAUsaregroupedlogicallybasedoncommonserviceprovidergroupingsandinclude:
850/1900,700/700MIMO,800/900SMR,700SISO/AWS,and800/AWS.Addingfrequencyisassimpleas
plugginginanSRAUtotheexistingMRAU(seeTable 4onpage 17throughTable 6onpage 19in“Specifications”).
RAUsareavailableintwodifferentoutputpoweroptions:StandardandHighPower.Thesecanbe“mixedand
matched”onasystemtomeetthespecificneedsofavenue.
SinceSpectrumcanbeconfiguredtosupportasmanyasfourcascadedrunsofsixteentotalExpansionModule
Groups,thesystemconfigurationpossibilitiesareseeminglyendlessandcanscaletosinglesystemsthatinclude
asmanyas128MRAUlocations,witheachofthoselocationssupportingbetweenoneandeightRFbands.And
eachofthosebandlocationsoffers26dBm(P1dB)or31dBm(P1dB)ofoutputpowerbasedonselecting
standardorHighPower(HP)RAUs.
ThesystemmaybescaledtoaddnewbandsorRAUlocationsitesas‐neededandoffersgreatserviceflexibility
andperformancerelativetoshared,wide‐bandamplifiersystems.Eachserviceprovidermaycontroltheirband
ofinterestandenjoythepredictabilityinconsistentserviceateachRAUlocationindependentofwhatother
operatorsaredoingorthelengththesignaltravelstotheservicearea.
TheRAUsaretypicallymountedaboveceilingtilesorinout‐of‐sightlocationsascloseaspossibletotheservice
area.
Page4InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution
©2014 TEConnectivityLtd. TECP77222Issue2 • 300001759666RevB•March2014
Figure 1illustrateshowRFandIFsignalsaresentbetweenSpectrumunitsandmodules.
NOTE: AllFWDportsonallModulesarecolorcodedredandallREVportsarecolorcodedblue,whichmakestheDRU,IFEU,
andRAUcablingprocesseasiertocomplete.
Figure1.REVandFWDSignalsfortheRAU
NOTE: ThisbookreferstotheOmniAntenna(42140727),whichistheantennathatTEConnectivityrecommends.Other
antennasmaybeused.ForfurtherinformationontheOmniAntenna,see“OmniAntennaSpecifications”onpage 25.
LINK STATUS
SECONDARY
REV
SECONDARY
FWD
SECONDARY
REV
SECONDARY
FWD
LINK STATUS
REV IF OUT REV SECONDARY PORTS
1 2 3
FWD SECONDARY PORTS
1 2 3
FWD IF IN
LINK STATUS
Host
SRAU
MRAU
Power
Supply
IFEU
DRU
IF
RF
Omni
Antenna
R
F
R
F
x
x x
xx
x x
xx
x x
xx
x
x x
xx
x x
xx
x x
xx
x
REMOTE
SYSTEM II
IF DART
XXXXXXXXXX
BW XX MHz
FWD
IF OUT
REV
IF IN
PWR
STATUS
REMOTE
IF DART
XXXXXXXXXX
BW XX MHz
FWD
IF OUT
REV
IF IN
PWR
STATUS
REMOTE
IF DART
XXXXXXXXXX
BW XX MHz
FWD
IF OUT
REV
IF IN
PWR
STATUS
REMOTE
IF DART
XXXXXXXXXX
BW XX MHz
FWD
IF OUT
REV
IF IN
PWR
STATUS
REMOTE
IF
IF
HOST
SYSTEM II
RF DART
SMR900
FWD 935-940
REV 896-901
REV
RF OUT
FWD
RF IN
FWD NOT TO
EXCEED +5 dBm
PWR
STATUS
HOST
RF DART
SMR900
FWD 935-940
REV 896-901
REV
RF OUT
FWD
RF IN
FWD NOT TO
EXCEED +5 dBm
PWR
STATUS
HOST
RF DART
SMR900
FWD 935-940
REV 896-901
REV
RF OUT
FWD
RF IN
FWD NOT TO
EXCEED +5 dBm
PWR
STATUS
HOST
RF DART
SMR900
FWD 935-940
REV 896-901
REV
RF OUT
FWD
RF IN
FWD NOT TO
EXCEED +5 dBm
PWR
STATUS
HOST
NOTE: Units shown are not to scale.
InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution Page5
TECP77222Issue2 • 300001759666RevB•March2014 ©2014 TEConnectivityLtd.
MainRemoteAccessUnits
TheMainRemoteAccessUnit(MRAU)receivesFWDIFsignalsfromanIFExpansionUnit(IFEU),whichispart
oftheSpectrumExpansionModuleGroup,using75CATVcable.TheMRAUconvertstheIFsignalstoRFand
sendsthemtoapassiveRFantennausing50coaxialcable.TheMRAUalsoreceivesconfigurationinformation
andpowerfromandsendsitsstatusinformationtotheIFEU.
TheMRAUreceivesREVRFsignalsfromapassiveRFantennausing50coaxialcable.Itconvertsthesignalsto
IFandsendsthemtotheIFEUusing75CATVcable.
MRAUPorts,Cable,andConnectors
Ref# Component Device Function
1RFSubMiniatureversionA
(SMA)cable(1)
50RFSMAtoSMAcable ConnectstwoRFbandstogetherwhenthereisonly
oneNtypeconnectorontheRAU.
2 Antennaport(s) 50Ntypeconnector Connectstoanantenna.SeeTable 2onpage 9.
3FWDIFINconnector Fconnectorport ConnectstotheIFEUFWDModuleIFOUTconnector
viaCATVcable.
4FWD
SECONDARYPORTS(1‐3) Fconnectorports ConnecttoaSRAUSECONDARYFWDconnectorvia
CATVcable.
5REVSECONDARYPORTS(1‐3) Fconnectorports ConnecttoaSRAUSECONDARYREVconnectorvia
CATVcable.
6REVIFOUTconnector Fconnectorport ConnectstotheIFEUREVModuleIFINconnectorvia
CATVcable.
(1) TheAWS/PCSMRAUsdoNOThaveanRFSMAcable—theyhavetwoAntennaports.
REV IF OUT REV SECONDARY PORTS
1 2 3
FWD SECONDARY PORTS
1 2 3
FWD IF IN
LINK STATUS
1 2
36 54
Page6InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution
©2014 TEConnectivityLtd. TECP77222Issue2 • 300001759666RevB•March2014
MRAULEDs
Ref#LED LEDColor Description
1FWDSECONDARYPORT
(1‐3)
•Green •Downstreamunitcorrectlyconnected;unithasnoalarmsora
Minoralarmisactive.
•BlinkingGreen • SRAUorbandissetoutofservice.
•Yellow •FWDcableconnectedtoSRAU,noREVcableconnected.
•Blinking
yellow
•FWDandREVcablesarenotconnectedtothesameport
number(incorrectlypaired).
•Red •Majoralarmindownstreamunit,faultlockout,orSRAU
disconnected.
•Off •NoSRAUpreviouslyconnected.
2LINK
•Green •MRAUreceivingcommunicationsfromtheIFEU.
•Red •MRAUhasnotreceivedcommunicationsfromtheIFEUformore
than90seconds.
•Off •Duringinitialpowerup,MRAUispoweringupandwaitingfor
IFEUcommunications.
3STATUS
•Green •UnithasnoalarmsoraMinoralarmisactive.
•Blinkinggreen • Unitorbandissetoutofservice.
•Red •Majoralarmdetected.
4REVSECONDARYPORT
(1‐3)
•Green •Downstreamunitcorrectlyconnected,unithasnoalarmsor
minoralarm
•BlinkingGreen • SRAUorbandissetoutofservice.
•Blinking
Yellow
•FWDandREVcablesarenotconnectedtothesameport
number(incorrectlypaired).
•Red •Majoralarmindownstreamunit,faultlockout,orSRAU
disconnected.
•Off •NoSRAUpreviouslyconnected.
5FWDIFIN
•Green •MRAUispoweredoncorrectly.
•Yellowor
Blinking
Yellow
•ThereisanIFEUFWDconnection,butthereisnoIFEUREV
connectionortheIFEUREVconnectionispairedincorrectly.
•Off •CableisnotconnectedtotheIFEUFWDport.
REV IF OUT REV SECONDARY PORTS
1 2 3
FWD SECONDARY PORTS
1 2 3
FWD IF IN
LINK STATUS
415
2 3
InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution Page7
TECP77222Issue2 • 300001759666RevB•March2014 ©2014 TEConnectivityLtd.
SecondaryRemoteAccessUnits
ASecondaryRemoteAccessUnit(SRAU)receivesFWDIFsignalsfromtheMRAU,using75CATVcable.The
SRAUconvertstheIFsignalstoRFandsendsthemtoapassiveRFantennausing50coaxialcable.TheSRAU,
throughtheMRAU,alsoreceivesconfigurationinformationandpowerfromandsendsitsstatusinformationto
theIFEU.
TheSRAUreceivesREVRFsignalsfromapassiveRFantennausing50coaxialcable.Itconvertsthesignalsto
IFandsendsthemtotheMRAUusing75CATVcable.
SRAUPorts,Cable,andConnectors
Ref
#
Component Device Function
1SECONDARYREVconnector Fconnectorport ConnectstooneoftheMRAUREVSECONDARYports(1‐3)
viaCATVcable.
2RFSMAcable(1)
50RFSMAtoSMAcable
ConnectstwoRFbandstogetherwhenthereisonlyone
NtypeconnectorontheRAU.
ForcaseswhenthereisanNtypeconnectorforeachRF
band(700MIMOorPCS/AWS),therewillnotbeanSMA
cable.
3Antennaport(s) 50Ntypeconnector Connectstoanantenna.SeeTable 2onpage 9.
4SECONDARYFWDconnector Fconnectorport ConnectstooneoftheMRAUFWDSECONDARYports(1‐
3)viaCATVcable.
(1) The700MIMOSRAUdoesNOThaveanRFSMAcable;ithastwoAntennaports.
142
3
LINK STATUS
SECONDARY
REV
SECONDARY
FWD
SECONDARY
REV
SECONDARY
FWD
LINK STATUS
Page8InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution
©2014 TEConnectivityLtd. TECP77222Issue2 • 300001759666RevB•March2014
SRAULEDs
Ref#LED LEDColor Description
1LINK
•Green •SRAUreceivingcommunicationsfromtheIFEU.
•Red •SRAUhasnotreceivedcommunicationsfromtheIFEUformorethan90
seconds.
•Off •Duringinitialpowerup,SRAUispoweringupandwaitingforIFEU
communications.
2 STATUS
•Green •UnithasnoalarmsoraMinoralarmisactive.
•BlinkingGreen • Unitorbandissetoutofservice.
•Red •Majoralarmdetected.
3SECONDARYFWD
•Green •SRAUispoweredoncorrectly.
•Yellowor
Blinking
Yellow
•ThereisanMRAUFWDconnection,butthereisnoMRAUREVconnection
ortheMRAUREVconnectionispairedincorrectly.
•Off •CableisnotconnectedtotheMRAUFWDport.
LINK STATUS
SECONDARY
REV
SECONDARY
FWD
SECONDARY
REV
SECONDARY
FWD
LINK STATUS
312
InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution Page9
TECP77222Issue2 • 300001759666RevB•March2014 ©2014 TEConnectivityLtd.
RAUNConnectors
EachRAUalsohasoneortwo50N‐typeconnectorsthatconnecttoapassiveantenna.Table 2liststhenumber
ofN‐typeconnectorsavailableoneachRAUmodel.
Table2. NumberofNConnectorsonRAUs
CatalogNumberDescription NumberofRF
N
Connectors*
StandardRAUs
SPTM185191Spectrum,8501900MainRAU 1
SPTM1AWS1911 Spectrum,2100AWSPath11900Path1MainRAU2
SPTS121211MIMO Spectrum,2100AWSMIMOSecondaryRAU 2
SPTS170701MIMO Spectrum,700MIMOSecondaryRAU,UpperCLowerABC2
SPTS1801922 Spectrum,800Path21900Path2SecondaryRAU 1
SPTS180901Spectrum,800900Path1SMRSecondaryRAU 1
SPTS180AWS1Spectrum,8002100AWSPath1SecondaryRAU 1
SPTS1851922 Spectrum,850Path21900Path2SecondaryRAU 1
SPTS1AWS1912 Spectrum,2100AWSPath11900Path2SecondaryRAU2
SPTS270AWS1SISO Spectrum,700SISO2100AWSPath1SECRAU,UpperCLowerABC 1
SPTS270AWS22SISO Spectrum,700Path2SISO2100AWSPath2SECRAU,UpperCLowerABC 1
HighPowerRAUs
SPTM3801931HP Spectrum,800Path3‐1900HPPath1MainRAU 1
SPTM3851911HP Spectrum,850Path11900HPPath1MainRAU 1
SPTS3262612HP Spectrum,2600HPPath1‐2600HPPath2SecondaryRAU 2
SPTS370AWS11HP Spectrum,700Path1uC/LABCAWSHPPath1SecondaryRAU 1
SPTS370AWS22HP Spectrum,700Path2uC/LABCAWSHPPath2SecondaryRAU 1
SPTS3801922HP Spectrum,800Path21900HPPath2SecondaryRAU 1
SPTS3851922HP Spectrum,850Path2‐1900HPPath2SecondaryRAU 1
*TherearetwobandsperRAU,whichresultsintwoNconnectors.WhenthereisoneNconnector,thetwobandsare
combinedinternallyandbothbandsusethesingleNconnector.
Page10 InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution
©2014 TEConnectivityLtd. TECP77222Issue2 • 300001759666RevB•March2014
INSTALLTHERAUSANDANTENNAS
FollowthestepsintheorderprovidedtoinstalltheRAUsandantennas.
MounttheRAUsandAntennas
CAUTION! Wetconditionsincreasethepotentialforreceivinganelectricalshockwheninstallingorusingelectricallypowered
equipment.Topreventelectricalshock,neverinstalloruseelectricalequipmentinawetlocationorduringalightning
storm.
CAUTION! ThissystemisaRFTransmitterandcontinuouslyemitsRFenergy.Maintainaminimum8inch(20cm)clearancefrom
theantennawhilethesystemisoperating.Wheneverpossible,shutdowntheRANbeforeservicingtheantenna.
NOTE: RAUsaresuitableforuseinenvironmentalairspaceinaccordancewithSection30022(c)oftheNationalElectrical
Code,andSections2128,12010(3)and12100oftheCanadianElectricalCode,Part1,CSAC22.1.
CAUTION! InstallRAUsinindoorlocationsonly.DonotconnectanantennainstalledinanoutdoorlocationtoaRAU,unlessitis
inanapprovedAOCweatherproofNEMA4housing.
CAUTION! AttachallRAUssecurelytoastationaryobject(thatis,awall,pole,orceilingbrackets).TomountaRAUsecurelytoa
wall,ceilingbracket,orpole,use#6diameterfastenersinthefourslottedmountingholes.
CAUTION! Dothefollowingtomaintainproperventilation:
Keepatleast76mm(3inch)clearancearoundtheRAU.
DonotstackRAUsontopofeachother.
AlwaysmounttheRAUwiththesolidface(containingthemountingholes)againstthemountingsurface.
NOTE: YoucanplacetheRAU,withoutitsfasteninghardware,onaflatsurface,suchasashelf,desk,cabinet,oranyother
horizontalsurfacethatallowsstableplacement,withthemountingbasefacingdowntothemountingsurface.
CAUTION! IfinstallingtheRAUonaflatsurface,thesurfacemustbeabletoholdaminimum7poundloadsecurely.
Dothefollowing,intheorderpresented,tomounttheRAUsandantennas:
1MountallMRAUandSRAUsinthelocationsmarkedonthefloorplans.
2Installthepassiveantennasaccordingtothemanufacturer’sinstallationinstructions.
NOTE: Itiscommonpracticetoinstallpassiveantennasbelowtheceiling.Ifyouinstallapassiveantennaabovetheceiling,
whenestimatingtheantennacoveragearea,accountforadditionallossduetotheceilingmaterial.
InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution Page11
TECP77222Issue2 • 300001759666RevB•March2014 ©2014 TEConnectivityLtd.
3Connectapassivemulti‐bandantennatotheNconnectoroneachRAUusingcoaxialcablewiththeleast
amountoflosspossible.(See“OmniAntennaSpecifications”onpage 25forinformationontheOmniAntenna
ports.)
CAUTION! FirmlyhandtightentheNconnector.DONOTovertightentheconnector.
ConnecttheIFEUtotheMRAU
NOTE: TheIFEUshouldbepoweredupbeforestartingthisprocedure;seetheInterReachSpectrumExpansionModuleGroup
InstallationGuide(TECP77167).
4FollowtheserulesfortheCATVcableswhenconnectingtheIFEUtotheMRAU:
TheFWDandREVcablesshouldbeclosetothesamelength.
TheFWDandREVcablesshouldbethesamecabletype(bothRG6orbothRG11).
ApairofCATVcablesconnectseachMRAUtotheIFEU.TheIFEUREVModuleIFINportandtheIFEU
FWDModuleIFOUTportmustmatch.Forexample,ifIFEUREVModuleIFINPort3isused,useIFEU
FWDModuleIFOUTPort3.
Referto“75‐OhmCATVCableRequirementsandSpecifications”onpage 20forinformationonmaximum
RG‐6orRG‐11CATVcablelengths.
5TestthecableterminationforeachCATVcablebeforeinstallingit.
Omni Antenna
False Ceiling
SRAU N1
REV IF OUT REV SECONDARY PORTS
1 2 3
FWD SECONDARY PORTS
1 2 3
FWD IF IN
LINK STATUS
LINK STATUS
SECONDARY
REV
SECONDARY
FWD
MRAU N1
Coaxial cable
Coaxial cable
Page12 InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution
©2014 TEConnectivityLtd. TECP77222Issue2 • 300001759666RevB•March2014
6ConnectFconnectorCATVcablesontheIFEUandMRAU,intheordergivenbelow.
IftheLEDsdonotperformasdescribedinthisprocedure,referto“MRAULEDs”onpage 6.
aConnectaCATVcablefromoneoftheIFEUFWDModuleIFOUTconnectors(1‐8)totheMRAUFWDIF
INconnector.
bConfirmthattheMRAUFWDIFINLEDisyellow,whichindicatesacorrectphysicalconnection.
cConnectaCATVcablefromtheIFEUREVModuleIFINconnector(1‐8)totheMRAUREVIFOUT
connector,makingsurethatyoupairtheportusedtothesameportnumberselectedinStep6a.
Iftheconnectioniscorrect,theMRAUpowersupandtheMRAUFWDIFINLEDturnsgreen.
NOTE: TorqueappliedtotheFconnectorCATVcablesshouldbe7±5%inlbs.
ConnecttheMRAUtoSRAUs
CAUTION! Topreventinterference,donotinstallan850/1900MRAUantennanearan800/900SRAU.The850MHzbandmust
be20feetawayfromthe800/1900SRAU’spassiveantenna.
7Useoneofthefollowing6’and20’CATVRG6jumpers,availableforpurchasefromTEConnectivity,to
connectanMRAUtoSRAUs.
8TestthecableterminationforeachCATVcablebeforeinstallingit.
TEPartNumber Description Note
30046906’RG6Cable;FMaletoFMale CATVcablethatconnectstheMRAUtoSRAUs.TwocablesrequiredperSRAU.
300469120’RG6Cable;FMaletoFMale CATVcablethatconnectstheMRAUtoSRAUs.TwocablesrequiredperSRAU.
Step 6a
IFEU
REV IF OUT REV SECONDARY PORTS
1 2 3
FWD SECONDARY PORTS
1 2 3
FWD IF IN
LINK STATUS
MRAU
To an antenna
Step 6c
KEY:
IFEU FWD Module IF OUT connector to MRAU FWD IF IN connector
IFEU REV Module IF IN connector to MRAU REV IF OUT connector
Step 6b
InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution Page13
TECP77222Issue2 • 300001759666RevB•March2014 ©2014 TEConnectivityLtd.
9ConnectFconnectorCATVcablesfromtheMRAUtoanSRAU,intheordergivenbelow.IftheLEDsdonot
performasdescribedinthisprocedure,referto“SRAULEDs”onpage 8.
aConnectaCATVcablefromanMRAUFWDSECONDARYPORT(1,2,or3)FconnectortotheSRAU
SECONDARYFWDFconnector.
bConfirmthattheSRAUSECONDARYFWDLEDisyellow,whichindicatesacorrectphysicalconnection.
cConnectaCATVcablefromanMRAUREVSECONDARYPORT(1,2,or3)FconnectortotheSRAU
SECONDARYREVFconnector,matchingthesameportnumberselectedinStep9a.Thatis,ifinStep9a
youconnectedanFconnectortotheMRAUFWDSECONDARYPORT1,thepairedCATVcablemust
connecttotheMRAUREVSECONDARYPORT1.
Iftheconnectioniscorrect,theSRAUpowersupandtheSRAUSECONDARYFWDLEDturnsgreen.
NOTE: TorqueappliedtotheFconnectorCATVcablesshouldbe7±5%inlbs.
MRAU
REV IF OUT REV SECONDARY PORTS
1 2 3
FWD SECONDARY PORTS
1 2 3
FWD IF IN
LINK STATUS
KEY:
MRAU FWD Secondary port to SRAU Secondary FWD port
MRAU REV Secondary port to SRAU Secondary REV port
LINK STATUS
SECONDARY
REV
SECONDARY
FWD
SECONDARY
REV
SECONDARY
FWD
LINK STATUS
SRAU
To an antenna
To an antenna
To an IFEU
REV Module
IF IN connector
(1 - 8)
To an IFEU
FWD Module
IF OUT connector
(1 - 8)
Step 9a
Step 9b
Step 9c
Page14 InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution
©2014 TEConnectivityLtd. TECP77222Issue2 • 300001759666RevB•March2014
10 RepeatStep 9toinstalluptotwomoreSRAUs,aspersystemdesign.
ConfiguretheMRAUsandSRAUs
RefertotheInterReachSpectrum™ElementManagementSystem7.3UserManual(TECP‐77‐200)forinformation
onhowtoconfiguretheMRAUsandSRAUs.
SPECIFICATIONS
RemoteAccessUnitSpecifications
OperatingTemp 25°Cto+50°C
StorageTemperature 40°Cto+70°C
Humidity 10%to95%noncondensing
Dimensions 11.50"Wx3.50"Hx9.00"D
Weight 7.49Pounds
PowerSource +54Vdc(fromIFEU)
SpectrumSystemSpecifications
RFSpecification
SupportedFrequencyBlocks 2perRemoteAntennaUnit;18perHostUnit
Bandwidth 1.5to75MHznoncontiguous
InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution Page15
TECP77222Issue2 • 300001759666RevB•March2014 ©2014 TEConnectivityLtd.
PropagationDelay
SystemDelay <12microsecondsperDRUlink
(Forexample,inacascadeof3DRUs,theoverallSystemDelaycouldbe
upto36microseconds.ThisdoesnotincludeFiberDelay,justSystem
Delayalongeachsegmentofthecascade.)
DelayManagementDigital (ManualorAutomatic)
NominalPassbandBandwidthsandGains
FrequencyBandsSupported 850Cellular;800iDEN;900iDEN;1900PCS;2100AWS;2600LTE;700
UpperC/LowerABC
Table3.
RFFrequency
TX RX
850Cell
Bandwidth 869894 824849
Gain(dB) 40 30
800SMR
Bandwidth 851869 806824
Gain(dB) 40 30
900SMR
Bandwidth 935940 896901
Gain(dB) 40 30
1900PCS
Bandwidth 19301995 1850191
5
Gain(dB) 40 30
2100AWS
Bandwidth 21102155 1710175
5
Gain(dB) 40 30
2600LTE
Bandwidth 26202690 2500257
0
Gain(dB) 40 30
700UpperC
Bandwidth 746756 776786
Gain(dB) 40 30
700LowerABC
Bandwidth 728746 698716
Gain(dB) 40 30
Page16 InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution
©2014 TEConnectivityLtd. TECP77222Issue2 • 300001759666RevB•March2014
Low/Medium
PowerLevel
700900MHz
Typical
Low/Medium
PowerLevel
19002600MHz
Typical
High
PowerLevel
19002600MHz
Typical3
TX RX TX RX TX RX
Averagegainwith180mCATV
at25°C(77°F)(dB)
401/43230 401/43230 48 30
Ripplewith180mCATV(dB) 2.5 3.0 3.5 4.0 3.5 4.0
OutputIP3(dBm) 38 38 43
InputIP3(dBm) 888
Output1dBCompressionPoint(dBm) 26 26 31
NoiseFigure1HU1EMG8RAUs(dB) 17 17 17
NoiseFigure1HU4EMG32RAUs(dB) 23 23 23
1LowPowerisdefinedhereasaStandardMRAUusedwith
StandardSRAUs;seeTable 4onpage 17.
2MediumPowerisdefinedhereasaHighPowerMRAUused
withStandardSRAUs;seeTable 5onpage 18.
3HighPowerisusedtodefineaHighPowerMRAUusedwith
HighPowerSRAUs;seeTable 6onpage 19.
InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution Page17
TECP77222Issue2 • 300001759666RevB•March2014 ©2014 TEConnectivityLtd.
CompositePowerOutofRAU
Table4. LowPowerLevel:StandardMRAUwithSRAUs
PowerperCarrier(dBm)perBand
RFFrequency NumberofRFCarriers
TX RX 1Pout 2Pout 4POut 8Pout
StandardMRAUs:
850Cell 869894 824849
26.0 20.0 14.0 9.0 GSM
SPTM185191 23.0 17.5 12.0 8.0 EDGE
SPTM1AWS1911 15.0 12.0 9.0 6.0 CDMA
15.0 12.0 9.0 6.0 WCDMA
StandardSRAUs 15.0 12.0 9.0 6.0 LTE
SPTS180901
800SMR 851869 806824
17.5 14.0 10.0 6.5 iDEN
SPTS170701MIMO 26.0 19.5 13.5 8.5 APCO25C4FM
SPTS180AWS1 15.0 12.0 9.0 6.0 CDMA
SPTS270AWS1SISO 15.0 12.0 9.0 6.0 LTE
SPTS270AWS22SISO 900SMR 935940 896901 17.5 14.0 10.0 6.5 iDEN
SPTS1AWS1912 26.0 20.0 13.5 9.0 APCO25C4FM
SPTS121211MIMO
1900PCS 19301995 18501915
26.0 20.0 14.0 9.0 GSM
SPTS1801922 23.0 17.5 12.0 8.0 EDGE
SPTS1851922 15.0 12.0 9.0 6.0 CDMA
15.0 12.0 9.0 6.0 WCDMA
15.0 12.0 9.0 6.0 LTE
2100AWS 21102155 17101755 15.0 12.0 9.0 6.0 WCDMA
15.0 12.0 9.0 6.0 LTE
700UpperC 746756 776786 15.0 12.0 9.0 6.0 LTE
700LowerABC 728746 698716
Page18 InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution
©2014 TEConnectivityLtd. TECP77222Issue2 • 300001759666RevB•March2014
1SeepowerpercarrierofHPMRAUfromTable 6onpage 19.
Table5. MediumPowerLevel:HighPowerMRAUs1usedwithStandardSRAUs
PowerperCarrier(dBm)perBand
RFFrequency NumberofRFCarriers
TX RX 1Pout 2Pout 4POut 8Pout
850Cell 869894 824849
26.0 20.0 14.0 9.0 GSM
23.0 17.5 12.0 8.0 EDGE
18.0 15.0 12.0 9.0 CDMA
18.0 15.0 12.0 9.0 WCDMA
StandardSRAUs 18.0 15.0 12.0 9.0 LTE
SPTS180901
800SMR 851869 806824
17.5 14.0 10.0 6.5 iDEN
SPTS170701MIMO 26.0 19.5 13.5 8.5 APCO25C4FM
SPTS180AWS1 18.0 15.0 12.0 9.0 CDMA
SPTS270AWS1SISO 18.0 15.0 12.0 9.0 LTE
SPTS270AWS22SISO 900SMR 935940 896901 17.5 14.0 10.0 6.5 iDEN
SPTS1AWS1912 26.0 19.5 13.5 8.5 APCO25C4FM
SPTS121211MIMO
1900PCS 19301995 18501915
26.0 20.0 14.0 9.0 GSM
SPTS1801922 23.0 17.5 12.0 8.0 EDGE
SPTS1851922 18.0 15.0 12.0 9.0 CDMA
18.0 15.0 12.0 9.0 WCDMA
18.0 15.0 12.0 9.0 LTE
2100AWS 21102155 17101755 18.0 15.0 12.0 9.0 WCDMA
18.0 15.0 12.0 9.0 LTE
700UpperC 746756 776786 18.0 15.0 12.0 9.0 LTE
700LowerABC 728746 698716
InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution Page19
TECP77222Issue2 • 300001759666RevB•March2014 ©2014 TEConnectivityLtd.
NOTE: ModelsSPTM3801931HPandSPTS3801922HP‐IndustryCanadaMeanOutputPoweris24.33dBm(800SMR)
and26.83dBm(1900PCS).
Table6. HighPowerLevel:HighPowerMRAUwithHighPowerSRAUs
PowerperCarrier(dBm)perBand
RFFrequency NumberofRFCarriers
TX RX 1Pout 2Pout 4POut 8Pout
850Cell 869894 824849
26.0 20.0 14.0 9.0 GSM
HighPowerMRAU 23.0 17.5 12.0 8.0 EDGE
SPTM3851911HP 18.0 15.0 12.0 9.0 CDMA
SPTM3801931HP 18.0 15.0 12.0 9.0 WCDMA
18.0 15.0 12.0 9.0 LTE
HighPowerSRAUs
800SMR 851869 806824
17.5 14.0 10.0 6.5 iDEN
SPTS370AWS11HP 26.0 19.5 13.5 8.5 APCO25C4FM
SPTS370AWS22HP 18.0 15.0 12.0 9.0 CDMA
SPTS3851922HP 18.0 15.0 12.0 9.0 LTE
SPTS3262612HP 900SMR 935940 896901 17.5 14.0 10.0 6.5 iDEN
SPTS3801922HP 26.0 19.5 13.5 8.5 APCO25C4FM
1900PCS 19301995 18501915
26.0 23.0 19.0 14.0 GSM
26.0 22.5 17.0 13.0 EDGE
23.0 20.0 17.0 14.0 CDMA
23.0 20.0 17.0 14.0 WCDMA
23.0 20.0 17.0 14.0 LTE
2100AWS 21102155 17101755 23.0 20.0 17.0 14.0 WCDMA
23.0 20.0 17.0 14.0 LTE
2600LTE 26202690 25002570 23.0 20.0 17.0 14.0 WCDMA
23.0 20.0 17.0 14.0 LTE
700UpperC 746756 776786 18.0 15.0 12.0 9.0 LTE
700LowerABC 728746 698716
Page20 InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution
©2014 TEConnectivityLtd. TECP77222Issue2 • 300001759666RevB•March2014
75OHMCATVCABLEREQUIREMENTSANDSPECIFICATIONS
The75‐OhmCATVCable:
connectstheIFEUtoMRAU(s)andtheMRAU(s)totheSRAU(s)
transmits(FWD)multibandandreceives(REV)IFsignals
deliversDCelectricalpowertotheRAUs.TheSpectrumIFEUDCvoltageoutputis+54Vdcnominal.Ifthe
IFEUreachesitscurrentlimit,acurrent‐limitingcircuitprotectsit.
carriesconfigurationandstatusinformation
uses75type‐Fconnectorswithcaptivecenterpins.
CATVCableRequirements
BeldenCATVcableorequivalentisrequired(seeFigure 2).
FortheRG‐6cable,useaBelden1695ACoax.
FortheRG‐11cable,useaBelden7732ACoax.
NOTE: TEConnectivityrequiressolidcoppercenterconductorCATVcableforproperDCvoltagetotheRAUandmaximum
distances.
Figure2.Belden1695Aand7732ACoaxCables
UseRG‐6orRG‐11CATVcablebetweentheIFEUandMRAU,thetypicallengthsofwhicharelistedbelow.
CableType
Minimum
Length
Maximum
Length
Meters Feet Meters Feet
RG6 0 0 125 410
RG11 0 0 180 590
RG-11
Belden 1695A Coax
RG-6
Belden 7732A Coax
InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution Page21
TECP77222Issue2 • 300001759666RevB•March2014 ©2014 TEConnectivityLtd.
UseonlyRG‐6CATVcablebetweentheMRAUandSRAU,thelengthsofwhicharelistedbelow.
Belden1695ACoaxSpecifications
Description
RG‐6/Utype,18AWGsolid0.040‐inchbarecopperconductor,plenum,foamFluorinatedEthylenePropylene(FEP)
insulation,Duofoil®+tinnedcopperbraidshield(95%coverage),Flamarrest®jacket.
OverallPhysicalCharacteristics
Conductor OneCoax
18AWG
Solidstranding
BareCopper(BC)conductormaterial
0.040inchdiameter
Insulation Teflon®
FoamFluorinatedEthylenePropylene(FFEP)
0.170inchdiameter
OuterShieldLayer1Duofoil
®
Tape
AluminumFoilPolyesterTapeAluminumFoil
100%coverage
OuterShieldLayer2Braid
TinnedCopper(TC)
95%coverage
OuterJacket Flamarrest®
LowSmokePolyvinylChloride(LSPVC)
OverallCabling 0.234inchoverallnominaldiameter
RG6Cable Meters Feet
Typical 26.56
800/900iDENto850CELL 619.68
800AWSto850CELL 619.68
Page22 InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution
©2014 TEConnectivityLtd. TECP77222Issue2 • 300001759666RevB•March2014
OverallNominalElectricalCharacteristics
CharacteristicImpedance 75.000
Inductance 0.103H/ft.
CapacitanceConductortoShield 16.100(pF/ft.)
VelocityofPropagation 82(%)
Delay 1.240(ns/ft.)
ConductorDCResistance 6.400@20°C(/1000ft.)
OuterShieldDCResistance 2.800@20°C(/1000ft.)
Attenuation
Freq.(MHz) Attenuation(dB/100ft.)
1.000 0.240
3.580 0.450
5.000 0.550
7.000 0.650
10.000 0.750
67.500 1.740
71.500 1.780
88.500 1.940
100.000 2.100
135.000 2.400
143.000 2.500
180.000 2.800
270.000 3.400
360.000 4.000
540.000 5.200
720.000 6.100
750.000 6.200
1000.000 7.300
1500.000 9.200
2000.000 10.900
2250.000 11.600
3000.000 13.700
InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution Page23
TECP77222Issue2 • 300001759666RevB•March2014 ©2014 TEConnectivityLtd.
Belden7732ACoaxSpecifications
Description
RG‐11/Utype,14AWGsolid0.064‐inchbarecopperconductor,plenum,foamFEPinsulation,Duofoil®+tinned
copperbraidshield(95%coverage),fluorocopolymerjacket.
OverallPhysicalCharacteristics
Conductor OneCoax
18AWG
Solidstranding
BareCopper(BC)conductormaterial
0.064inchdiameter
Insulation Teflon®
FoamFluorinatedEthylenePropylene(FFEP)
0.274inchdiameter
OuterShieldLayer1Duofoil
®
Tape
AluminumFoilPolyesterTapeAluminumFoil
100%coverage
OuterShieldLayer2Braid
TinnedCopper(TC)
95%coverage
OuterJacket Fluorocopolymer(PVDF)
OverallCabling 0.348inchoverallnominaldiameter
Page24 InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution
©2014 TEConnectivityLtd. TECP77222Issue2 • 300001759666RevB•March2014
OverallNominalElectricalCharacteristics
CharacteristicImpedance 75.000
Inductance 0.091H/ft.
CapacitanceConductortoShield 16.300(pF/ft.)
VelocityofPropagation 83(%)
Delay 1.220(ns/ft.)
ConductorDCResistance 2.500@20°C(/1000ft.)
OuterShieldDCResistance 1.600@20°C(/1000ft.)
Attenuation
Freq.(MHz) Attenuation(dB/100ft.)
1.000 0.150
3.580 0.260
5.000 0.300
7.000 0.340
10.000 0.400
67.500 1.200
71.500 1.240
88.500 1.400
100.000 1.500
135.000 1.780
143.000 1.840
180.000 2.090
270.000 2.600
360.000 3.100
540.000 3.890
720.000 4.570
750.000 4.680
1000.000 5.500
1500.000 6.910
2000.000 8.130
2250.000 9.200
3000.000 10.200
InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution Page25
TECP77222Issue2 • 300001759666RevB•March2014 ©2014 TEConnectivityLtd.
OMNIANTENNASPECIFICATIONS
TheOmniAntenna(4214‐0727),showninFigure3,isaroundradomewiththefollowingspecifications:
Figure3.OmniAntenna
NOTE: TwoantennasperRAUisrequiredforMIMOperformance.
CAUTION! Maximumgainantennaallowedis3dBi
Port1Port2Port3
Gain,typical 2dBi@698960MHz 2dBi@698960MHz 3dBi@17102170MHz
3dBi@17102170MHz 3dBi@17102170MHz 3dBi@24962690MHz
Nominalimpedance 50Ohm
Polarization Vertical
VSWR <2:1
Porttoportisolation >15dBmin,22dBtypical
Powerrating 5Watt
Mechanical
DimensionofAntenna(DxH) 215x72mm
Weight Lessthanorequalto1.65lbs(0.75kg),includingpigtails
Connector N(male)
Cable(pigtail)length 6feet,plenumratedcable
Color White,UVprotectedplasticforoutdooruse
Mountinghardware Screws,anchor,andbutterflynutforceilingtilemount
Environmental
Operatingtemperature ‐40°Cto+65°C
ShippingandHandling ISTAProcedure1A
Ingressprotection IP42
Flammability UL94V0(Materials)
Compliance ROHScompliant
Ceiling mount, vertically polarized, omni directional antenna
Page26 InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution
©2014 TEConnectivityLtd. TECP77222Issue2 • 300001759666RevB•March2014
STANDARDSCERTIFICATION
FederalCommunicationsCommission(FCC)
ThisequipmentcomplieswiththeapplicablesectionsofTitle47CFR,Part22(800MHzCellular),Part24(1900MHz‐PCS),
Part90(800/900‐SMR),andPart27(700MHz,2100MHz‐AWS).
Part90SignalBoosters
ThefollowingstatementisapplicabletothefollowingRAUsthataredocumentedinthisinstallationguide:
SPT‐M3‐8019‐31‐HP,SPT‐S1‐8019‐22,SPT‐S1‐8090‐1,SPT‐S1‐80AWS‐1,SPT‐S3‐8019‐22‐HP.
WARNING.ThisisNOTaCONSUMERdevice.ItisdesignatedforinstallationbyFCCLICENSEESandQUALIFIED
INSTALLERS.YouMUSThaveanFCCLICENSEorexpressConsentofanFCCLicenseetooperatethisdevice.Unauthorized
usemayresultinSignificantforfeiturepenalties,includingpenaltiesinexcessof$100,000foreachcontinuingviolation.
IndustryCanada(IC)
ThisequipmentcomplieswiththeapplicablesectionsofRSS‐131‐ZoneEnhancersfortheLandMobileService.Theterm
“IC:”beforetheradiocertificationnumberonlysignifiesthatIndustryCanadaTechnicalSpecificationsweremet.
TheManufacturer'sratedoutputpowerofthisequipmentisforsinglecarrieroperation.Forsituationswhenmultiple
carriersignalsarepresent,theratingwouldhavetobereducedby3.5dB,especiallywheretheoutputsignalisre‐radiated
andcancauseinterferencetoadjacentbandusers.Thispowerreductionistobebymeansofinputpowerorgainreduction
andnotbyanattenuatorattheoutputofthedevice.
NOTE: TheU.S.FederalCommunicationsCommission(FCC)hasdevelopedguidelinesforevaluationofhumanexposureto
RFemissions.TheguidelinesincorporatelimitsforMaximumPermissibleExposure(MPE)forpowerdensityof
transmitteroperatingatfrequenciesbetween300kHzand100GHz.Limitshavebeensetforportable,mobile,and
fixedequipment.TEConnectivityproductsfallinthecategoryoffixedequipment;productsintendedtobe
permanentlysecuredandexposuresareevaluatedfordistancesgreaterthan40cm(15.75”).Portabledevicesfallinto
exposuresoflessthan20cm,whereSARevaluationsareused.
Antennagainisrestrictedto1.5WERP(2.49WEIRP)inordertosatisfyRFexposurecompliancerequirements.
Ifhigherthan1.5WERP,routineMPEevaluationisneeded.Theantennasshouldbeinstalledtoprovideat
least40cmfromallpersonstosatisfyMPErequirementsofFCCPart2,2.1091.
ThisdevicecomplieswithIndustryCanadalicence‐exemptRSSstandard(s).Operationissubjecttothefollowingtwo
conditions:(1)thisdevicemaynotcauseinterference,and(2)thisdevicemustacceptanyinterference,including
interferencethatmaycauseundesiredoperationofthedevice.
LeprésentappareilestconformeauxCNRd’IndustrieCanadaapplicablesauxappareilsradioexemptsdelicence.
L’exploitationestautoriséeauxdeuxconditionssuivantes:(1)l’appareilnedoitpasproduiredebrouillage,et(2)
l’utilisateurdel’appareildoitacceptertoutbrouillageradioélectriquesubi,mêmesilebrouillageestsusceptibled’en
compromettrelefonctionnement.
Thedevicemeetstheexemptionfromtheroutineevaluationlimitsinsection2.5ofRSS102andcompliancewithRSS‐102
RFexposure,userscanobtainCanadianinformationonRFexposureandcompliance.
Ledispositifrencontrel'exemptiondeslimitescourantesd'évaluationdanslasection2.5deRSS102etlaconformitéà
l'expositiondeRSS‐102rf,utilisateurspeutobtenirl'informationcanadiennesurl'expositionetlaconformitéderf.
UL/CUL
Thisequipmentwillbeinstalledinarestrictedaccesslocation.Thisequipmentcomplies,perULandCUL50,Standardfor
EnclosuresforElectricalEquipment.
ThisequipmentcomplieswithULandCUL60950‐1StandardforSafetyforInformationTechnologyEquipment,including
ElectricalBusinessEquipment.
AllInterReachSpectrumRAUsarePlenumratedandsuitableforuseinenvironmentalairspaceinaccordancewithSection
300‐22(C)oftheNationalElectricalCode,andSections2‐128,12‐010(3)and12‐100oftheCanadianElectricalCode,Part
1,CSAC22.1.
InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution Page27
TECP77222Issue2 • 300001759666RevB•March2014 ©2014 TEConnectivityLtd.
ThisequipmentisULPlenumratedunderUL2043.
CAUTION! Modificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecouldvoidtheuser'sauthorityto
operatetheequipment.
ACCESSINGUSERDOCUMENTATIONONTHETECUSTOMERPORTAL
YoucanaccessadditionaluserdocumentationontheTECustomerPortal,asdescribedbelow.
1ClickonthefollowingURLlink:
https://www.te.com/portal/wireless/
(Alternatively,entertheprecedingURLintoyourwebbrowser,andthenpressENTERonyourkeyboard.)
2AccesstotheCustomerPortalrequiresauseraccountandpassword.OntheSignInpage,dooneofthe
following:
Ifyouhaveanaccount,intheAlreadyRegistered?SignInNowpanel,enteryourEmailandPassword,and
thenclickSignIn.
Ifyoudon’thaveanaccount,underCreateanAccount,clickRegisterNowandfollowtheprompts.
3OntheWirelessCustomerPortalhomepageintheKnowledgeCenterpanel,clicktheManualsandDataSheets
link.
4OntheManualsandDataSheetspage,dothefollowing:
aIntheDocumentRepositorypanel,scrolltothesectionfortheproductlineofthedocumentthatyouwant
toaccess.
bClickonthetitleofthemanualthatyouwishtoopen.
c(Optional)SavethePDFtoyourcomputer.
Page28 InterReachSpectrumRemoteAccessUnitInstallationGuide‐PreliminaryNotforDistribution
©2014 TEConnectivityLtd. TECP77222Issue2 • 300001759666RevB•March2014
CONTACTINGTECONNECTIVITY
TelephoneNumbers
Sales
AsiaPacific +6562949948
France 0800914032
Germany 01802232923
Italy 0800782374
Spain 900983291
UnitedKingdom 0800960236
USAorCanada 18003663891
Extension 73000
ConnectivityExtension 73475
WirelessExtension 73476
TechnicalSupport
USAorCanada 18005309960
Elsewhere +19529170761
OnlineAccess
CustomerPortal
https://www.te.com/portal/wireless/
TechnicalSupportforWirelessProducts
http://www.te.com/WirelessSupport
www.te.com/wireless

Navigation menu
