User Manual Insert
![](/img.php?id=2102651&img=bg1.png)
IMPORTANT SAFETY INSTRUCTIONS
Before you install or use the apparatus, you must read and understand these Important Safety
Instructions. At all times, when using the apparatus, you must follow these Important Safety
Instructions to reduce the risk of fire, electrical shock and injury to persons.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
9. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
10. Only use attachments/accessories specified by the manufacturer.
11. Use only with the cart, stand, tripod, bracket, or table specified by
the manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
12. Unplug this apparatus during lightning storms or when unused for
long periods of time.
13. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
In addition to the Important Safety Instructions, please read the Safety Information
overleaf.
504T0498500
CONNECTING TO THE AC POWER SUPPLY
You must not plug your set-top box into the power supply until you have connected your set-top
box to the other equipment in your system.
This product is intended to be supplied with an approved listed Pace Direct Plug-In
AC/DC power adapter marked Class 2 or LPS and rated 12V, 1.5A for all IPW8000x series
models.
On the power supply unit there is a label that specifies the correct AC power supply input for it.
Do not connect the power supply unit to any supply voltage other than this.
Always connect the DC cord from the power supply unit to your set-top box before you insert the
power supply unit into the wall socket-outlet.
To disconnect power from your set-top box, always remove the power supply unit from the wall
socket-outlet (i.e., not by removing the DC cord from your set-top box). Therefore you must
install your set-top box near to the wall socket-outlet, which should be easily accessible.
If you are in any doubt about the power supply cord, its plug or its connection, or are not
certain that the electrical outlets you are using are properly wired and grounded, consult
a qualified electrician before proceeding any further.
INSTALLATION
The installation of your set-top box should be carried out by a qualified installer and should
conform to local codes.
Pace and are trademarks and/or registered trademarks of Pace plc.
Other trademarks listed herein are the property of their respective owners.
The model and serial number and electrical rating of your set-top box are on a label on its base.
Copyright © 2013 Pace plc. All rights reserved.
![](/img.php?id=2102651&img=bg2.png)
SAFETY INFORMATION
In addition to the Safety Information, please read
the Important Safety Instructions overleaf.
This digital set-top box has been manufactured and
tested with your safety in mind. However, improper use
can result in potential electric shock, property damage
or fire hazards. To avoid defeating the safeguards that
have been built into your set-top box, please observe
the precautions discussed in this document.
Warnings on your set-top box’s power
supply unit
The lightning flash with arrowhead symbol, within a
triangle, is intended to alert you to the presence of un-
insulated “dangerous” voltages within your set-top box’s
power supply unit that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within a triangle is intended to
alert you to the presence of important instructions in the
literature accompanying your set-top box.
Other warnings
To reduce the risk of electric shock, do not remove the
cover of your set-top box or its power supply unit. There
are no user-serviceable parts inside them. To reduce
the risk of fire or electric shock, do not expose this set-
top box to rain or moisture. Do not perform any
servicing unless you are qualified to do so. Refer all
servicing to qualified service personnel. Servicing the
set-top box yourself will invalidate the warranty. On the
base of your set-top box there is a tamper-evident label
that states ‘warranty void if broken or removed’.
Power sources
You must operate your set-top box only from the type of
power source indicated on the marking label. If you are
not sure of the type of power supply to your home,
consult your dealer or local power company. If you
move your set-top box between locations at different
temperatures, allow it to reach room temperature before
you apply power to it.
Overloading
Do not overload wall outlets, extension cords or other
power outlets as this can result in a risk of fire or
electric shock. To avoid possible damage to your set-
top box or to a connected TV or component, all AC
power cords must be plugged into properly wired
outlets. As with all electrical products, connection to
faulty or defective components, or the failure to connect
your set-top box to a properly wired outlet, may cause
sparking, property damage or damage to any TV or
other component connected to your set-top box and
pose a fire hazard.
Risk of fire or scorching
Never place open flame sources, such as lighted
candles, on or adjacent to your set-top box.
Placement and mounting
Do not place your set-top box on an unstable or uneven
surface. Your set-top box may fall, causing serious
injury to a child or adult and serious damage to your
set-top box. If you mount your set-top box, for example
to a wall or ceiling, follow the manufacturer’s
instructions and use a mounting accessory
recommended by the manufacturer. See also item 11 in
the Important Safety Instructions.
Ventilation
Slots and openings in the casing of your set-top box are
provided for ventilation, to ensure reliable operation of
your set-top box and to protect it from overheating.
• never block the ventilation openings by placing your
set-top box on a bed, sofa, rug or other similar
surface;
• never cover the ventilation openings with items such
as newspapers, tablecloths or curtains;
• do not place your set-top box in a built-in installation
such as a bookcase or rack unless proper ventilation
is provided or you have adhered to the manufacturer’s
instructions;
• maintain a minimum distance of 3 inches around your
set-top box for sufficient ventilation.
See also item 7 in the Important Safety Instructions.
Ambient temperature
The operating temperature range of your set-top box is
32-104°F. If the ambient temperature around your set-
top box falls outside this range, you must correct this in
order for your set-top box to work correctly and safely.
For example, if the temperature is too high, switch on
the air conditioning.
Water and moisture
Do not expose this set-top box to dripping or splashing
and ensure that no objects filled with liquids, such as
vases, are placed on your set-top box. See also item 5
in the Important Safety Instructions.
Entry of objects and liquids
Never push objects of any kind into your set-top box
through openings as they may touch dangerous voltage
points or short-out parts that could result in fire or
electric shock. Never spill liquid of any kind on your set-
top box.
Handling
To avoid possible damage to the internal hard disk, do
not pick up or move your set-top box while it is
connected to the power supply. If you want to move
your set-top box, first stop any recording, then turn off
your set-top box and wait 60 seconds before
disconnecting it. You should handle your set-top box
carefully, as any damage you cause to an internal hard
disk (or any other component) will invalidate your
warranty.
Lightning Storms
For added protection for your set-top box during a
lightning storm, or when it is left unattended and unused
for long periods of time, disconnect your set-top box’s
power cord (see item 12 in the Important Safety
Information). Also disconnect the satellite dish, antenna
or cable system, and telecommunication line cord, from
your set-top box.
SAVE THIS INFORMATION FOR FUTURE
REFERENCE
DECLARATION OF CONFORMITY
FCC / Industry Canada Compliance
This device has been tested and certified as compliant
with the regulations and guidelines set forth in the
Federal Communication commission - FCC part 15 and
Industry Canada - ICES003 and RSS-210 Radio and
telecommunication regulatory requirements / Le présent
materiel est conforme aux specifications techniques
applicables d’Industrie Canada. Cet appareil numérique
de la classe [*] est conforme à la norme NMB-003 du
Canada.
Manufacturer: Pace
Model(s): IPW8000, IPW8000M
Part 15 of FCC Rules / IC RSS-210 - RSS GEN
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux normes CNR
d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux
deux conditions suivantes:(1) l'appareil ne doit pas
produire de brouillage, et (2) l'utilisateur de l'appareil
doit accepter tout brouillage radioélectrique subi, même
si le brouillage est susceptible d'en compromettre le
fonctionnement.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
the receiver.
• Connect the equipment to an outlet on a circuit that is
different from the circuit used by the receiver.
• Consult your dealer or an experienced radio/TV
technician for help.
CAUTION: Changes or modifications not expressly
approved by the party responsible for compliance could
void your authority to operate this equipment.
Failure to heed the Safety Information provided by
failing to connect to a properly wired outlet may void the
manufacturer’s warranty.
Users should be advised that high-power radars are
allocated as primary users (i.e. priority users) of the
bands 5250-5350 MHz and 5470-5725 MHz and that
these radars could cause interference and/or damage
to the LE-LAN device.
Les utilisateurs doivent être avisés que les radars de
haute puissance sont désignés utilisateurs principaux
(c.-à-d., qu'ils ont la priorité) pour les bandes 5250-
5350 MHz et 5650-5850 MHz et que ces radars
peuvent causer du brouillage et/ou des dommages aux
dispositifs LAN-EL.
The device for operation in the band 5150-5250MHz is
only for indoor use to reduce the potential for harmful
interference to co-channel mobile satellite systems.
Les dispositifs fonctionnant dans la bande 5150-5250
MHz sont réservés uniquement pour une utilisation à
l'intérieur afin de réduire les risques de brouillage
préjudiciable aux systèmes de satellites mobiles
utilisant les mêmes canaux.
Under Industry Canada regulations, this radio
transmitter may only operate using an antenna of a type
and maximum (or lesser) gain approved for the
transmitter by Industry Canada. To reduce potential for
radio interference to other users, the antenna type and
its maximum gain should be so chosen that the
equivalent isotropically radiated power (e.i.r.p.) is not
more than that necessary for successful
communication.
Conformément à la réglementation d'Industrie Canada,
le présent émetteur radio peut fonctionner avec une
antenne d'un type et d'un gain maximal (ou inférieur)
approuvé pour l'émetteur par Industrie Canada. Dans le
but de réduire les risques de brouillage radioélectrique
à l'intention des autres utilisateurs, il faut choisir le type
d'antenne et son gain de sorte que la puissance
isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas
l'intensité nécessaire à l'établissement d'une
communication satisfaisante.
MPE/SAR/RF Exposure Information
This device was verified for RF exposure and found to
comply with Council Recommendation 1999/519/EC
and FCC OET-65 RF exposure requirements. This
equipment complies with FCC radiation exposure limits
set forth for an uncontrolled environment.
WARNING: While this device is in operation, a
separation distance of at least 20 cm (8 inches) must be
maintained between the radiating antenna inside the
EUT and the bodies of all persons exposed to the
transmitter in order to meet the FCC RF exposure
guidelines. Making changes to the antenna or the
device is not permitted. Doing so may result in the
installed system exceeding RF exposure requirements.
This device must not be co-located or operated in
conjunction with any other antenna or radio transmitter.
Trade Name: Pace Americas
Responsible Party: 2Wire, Inc. d/b/a Pace Americas
Address: 1764 Automation Parkway
San Jose, CA 95131
Phone: (408) 428-9500
