Welcome
Thank you for choosing the ASUS AiGuru S2 Wireless Skype Phone Kit. It will
allow you to make phone using your broadband connection. This Phone is specially
designed to facilitate the manipulation of the service and features provided by SkypeTM.
What is SkypeTM
SkypeTM is free and simple software that enables you to make free calls anywhere in
the world in minutes. If you are tired of paying outrageous fees for telephony, SkypeTM
is for you!
SkypeTM is quick and easy to install. Just download it, register, and within minutes
you can use the ASUS AiGuru S2 Wireless Skype Phone to call your friends on
SkypeTM. SkypeTM calls have excellent sound quality and are highly secure with end-
to-end encryption. Best of all, SkypeTM does not require you to recongure your rewall
or router - it just works! SkypeTM is a registered trademark of Skype Technologies S.A.
and all rights related to it are reserved. It is not in any way connected to ASUSTek
Computer, Inc. To create an account, download the SkypeTM program, and know more
about this program, visit www.skype.com.
“Get AiGuru S2 Phone convenience when you use SkypeTM!
Now you do not have to sit in front of your computer when you want to talk to your
friends. With the Skype application running on your PC, the handset can read and
display your contact list on its built-in illuminated display. Just choose who you want to
talk to from the menu, press a button, and get ready to talk.
x
Of course, the handset supports SkypeOutTM dialing as well as your Skype contact list.
The handset rings when you have a SkypeTM or SkypeInTM call coming in, and shows
the caller’s ID on the screen. You can hit the Mute button for privacy, or use the loud-
speaker function to let everyone join in. You can put an existing call on hold and allow
callers to leave a message on the answer machine, and retrieve voice mail with ease.
In short, the ASUS AiGuru S2 Wireless Skype Phone Kit gives you all the
functionality of a regular phone, through SkypeTM. You get the convenience of a
wireless phone and all its features, plus the high-quality voice reception that you get
from SkypeTM on your PC, without being tied to your computer
xi
Package contents
Check your phone package for the following items:
AiGuru S2 phone User manual Quick Start Guide
Wireless Link USB
dongle extension Battery Support CD
Wireless Link USB dongle
USB cable
xii
System requirements
• PC running Microsoft® Windows® XP (SP2) / 2000 (SP4)
• At least 1 GHz processor
• At least 256 MB RAM
• At least 40 MB free hard disk drive space
• Internet connection: Dial-up, broadband, or cable modem (at least 33.6 Kbps)
We recommend a broadband connection. Voice quality may vary
depending on the connection speed.)
• Skype™ version 3.0.0.198 recommended (bundled in the support CD)
Specications
Dimension 116(L) x 47(W) x 12.3(H) mm
Weight 100 g
Wireless standard IEEE 802.11 b+g @11/54 Mbps, 2.4 GHz, with
auto-fallback and auto-channel selection
I/O 128 x 128 Dot matrix STNLCD
0.5 W Speaker
Receiver
Mini USB port
2.5 mm 2-channel Earphone jack
Keypad Alphanumeric keys
End key
Call key
Navigation keys
Right soft key
Left soft key
Asterisk key
(Continued on the next page)
xiii
Features Skype™, SkypeIn™, SkypeOut™, Skype™ Conference
support
Contacts list, call list Search
Call rejecting, call receiving, call redial, hold
Hands-free speaker out
Caller ID display
Operating distance Indoors: 30 m*
Outdoors: 100 m*
Power duration Li-ion 3.7 V 750 mAH, 25 hours standby, 2.5 talk hours
Charging 3 hours USB full charging
Wireless receiver Wireless Link dongle (UI) mounted on the PC or
notebook
Sofware to install AiGuru S2 Utility
Wireless Link dongle driver
Accessories Support CD
User Manual
Quick Start Guide
Battery
USB cable
Wireless Link dongle
Wireless Link dongle 3D 180º USB extension
Specications
* According to free space test. The operating distance may be shorter
or interfered if there are walls, barriers, or interferences in the home
layout or operating environment.
xiv
3-13
AiGuru S2 Wireless Skype Phone
3.4 WiFi Music
Your AiGuru S2 phone can function as a Windows Media Player or iTunes remote
controller, allowing you to play audio les while you are away from your computer,
within the operating range of the WLAN module.
2. The handset screen will display the
song list you select in your AiGuru
S2 PC utility. Press the left soft key
to start enjoying the music.
3.4.1 Play mode
You are able to switch the play mode to Repeat and Random.
1. From the idle screen, press the
left soft key to display the main
menu and select WiFi Music or
press key to enter WiFi Music
directly.
1. From the playback screen, press
the left soft key (Mode).
2. From the Mode menu, highlight
Play Mode and press the left soft
key (Select) to conrm.
3-14 Chapter 3: Getting to know the phone menu and using the Skype™ features
3.4.2 Sound mode
The WiFi Music function of AiGuru S2 provides different sound modes for the music
playing. You can change the mode to suit the music genre or your mood.
1. From the playback screen, press the left soft key (Mode).
3. From the Play Mode menu, select
Repeat to repeat the whole playlist
or Random to shufe the play
order. You can activate these two
mode together.
4. After the repeat or the random mode is selected, the repeat icon or the
random icon or both of them will appear on the playback screen.
2. From the Mode menu, highlight
Sound Mode and press the left
soft key (Select) to conrm.
3. From the Sound Mode menu,
highlight a mode and press the left
soft key (Select) to conrm.
4. After the selection, the sound mode will appear on the playback screen.
The WiFi Music functions only in the WiFi mode.
3-15
AiGuru S2 Wireless Skype Phone
3.5 System info.
The System Info. menu offers the information such as WiFi status, Mac address, and
rmware version.
2. From the System Info. screen,
select WiFi Status and press the
left soft key to Enter.
3. The WiFi Status screen opens.
3.5.1 WiFi Status
1. From the idle screen, press the left
soft key to display the main menu
and select System Info..
3-16 Chapter 3: Getting to know the phone menu and using the Skype™ features
3.5.2 Mac Address
1. From the System Info. screen,
select Mac Address and press
the left soft key to Enter.
2. The Mac Address screen opens.
Both WiFi Status and Mac Address will not appear on the System
Info. list when in the USB mode.
3.5.3 Firmware Version
1. From the System Info. screen,
select Firmware Version and press
the left soft key to Enter.
2. The Firmware Version screen
opens.
3-17
AiGuru S2 Wireless Skype Phone
3.6 Settings
In the Settings menu, you can congure settings of AiGuru S2 wireless skype phone,
including language, display, keypad lock, or you can restore to the default setting.
2. From the Settings screen, select
Language and press the left soft
key to Enter.
3. The Language screen opens, and
you can highlight the language you
want to use. Press the left soft key
(Select) to conrm.
3.6.1 Language
1. From the idle screen, press the left
soft key to display the main menu
and select Settings.
3-18 Chapter 3: Getting to know the phone menu and using the Skype™ features
2. Highlight Backlight Time and press
the left soft key to Select.
3. From the Backlight Time menu,
you can select a screen backlight
time and press the left soft key to
Select.
3.6.2 Display
Backlingt Time
1. From the idle screen, press the left soft key to display the main menu and
select Settings.
2. From the Settings screen, select
Display and press the left soft key to
Enter.
Unless you set the backlight time to Always On, the handset display
darkens when the backlight time is up and blackens after one-minute
idle to minimize battery energy consumption. Press any key to light up
the display.
3-19
AiGuru S2 Wireless Skype Phone
The display will not blacken under three conditions: (1) the handset is
connected to the PC and charging, (2) during a call, and (3) the WiFi
Music is functioning.
Brightness
1. From the idle screen, press the left soft key to display the main menu and
select Settings.
2. From the Settings screen, select Display and press the left soft key to Enter.
3. Highlight Brightness and press the
left soft key to Select.
4. Use the navigation keys to adjust
the value. Scroll right to increase
the brightness and left to decrease
the brightness.
The conguration value of brightness is between -2 to 2.
3-20 Chapter 3: Getting to know the phone menu and using the Skype™ features
3.2.3 Keypad Lock
Keypad LockLocking the keypad
To lock the keypad automatically:
1. Press the left soft key to display
the Menu and select Settings .
3. Select Auto to set the keypad
auto-locked. The default setting is
Manual.
2. Scroll down to the Keypad Lock
item, then press the left soft key to
Enter.
4. Idle for 20 seconds, the keypad
locks itself.
To lock the keypad manually:
1. Press the left soft key.
2. Hold the asterisk key to lock the key pad.
3-21
AiGuru S2 Wireless Skype Phone
Unlocking the keypad
To lock the keypad:
1. Press the left soft key.
3. The main screen then appears,
indicating that the keypad is ready
to use.
2. Press the asterisk key to unlock the
keypad.
3-22 Chapter 3: Getting to know the phone menu and using the Skype™ features
3.6.4 Load Default
To load the default settings:
1. From the idle screen, press the left
soft key to display the main menu
and select Settings.
2. From the Settings screen, select
Load Default and press the left soft
key to Enter.
3. A message appears, asking for
conrmation.
4. Pr ess the left soft key (Yes) to
conrm or the right soft key (No) to
stop the default loading.
5. After the the loading completes, the
screen shows Default set.
Appendix
Reference information
This chapter describes PC-cillin rewall settings and provides safety notices, an FAQ section
as well as ASUS’ contact information.
A-2 Appendix: Reference information
A.1 Setting PC-cillin™
If you installed PC-cillin™ Internet Security software in your computer, make the
following settings before installing AiGuru S2 Utility.
1. Open Trend Micro PC-cillin
Internet Security, click Network
Security tab, then click Personal
Firewall.
2. On Personal Firewall screen,
click Add.
A-3
AiGuru S2 Wireless Skype Phone
3. Key in ASUS in Prolename
eld, then click OK.
4. Select Exception List tab, and
click Add.
A-4 Appendix: Reference information
5. Add AiGuruIn
a. Description: AiGuruIn
b. Target: Select Speciedapplication
and point to the location where the
application is saved.
c. Connection: Incoming
d. Action: Allow
e. Protocol: TCP/UDP
d. Port(s): All ports
f. IP Setting: All IP Addresses
6. Add AiGuruOut
a. Description: AiGuruOut
b. Target: Select Speciedapplication
and point to the location where the
application is saved.
c. Connection: Outgoing
d. Action: Allow
e. Protocol: TCP/UDP
d. Port(s): All ports
f. IP Setting: All IP Addresses
A-5
AiGuru S2 Wireless Skype Phone
7. Back to the Personal Firewall
screen, select ASUS in Choose
prole eld, then click Apply.
A-6 Appendix: Reference information
A.2 Notices
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE
STATEMENT
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
CAUTION:
Any changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)This device may not cause harmful interference and
(2)This device must accept any interference received, including interference that may
cause undesired operation.
A-7
AiGuru S2 Wireless Skype Phone
A.3 Safety statements
Regulatory Information/Disclaimers
Installation and use of this Wireless LAN device must be in strict accordance with
the instructions included in the user documentation provided with the product. Any
changes or modications (including the antennas) made to this device that are not
expressly approved by the manufacturer may void the user’s authority to operate
the equipment. The manufacturer is not responsible for any radio or television
interference caused by unauthorized modication of this device, or the substitution
of the connecting cables and equipment other than manufacturer specied. It is the
responsibility of the user to correct any interference caused by such unauthorized
modication, substitution or attachment. Manufacturer and its authorized resellers
or distributors will assume no liability for any damage or violation of government
regulations arising from failing to comply with these guidelines.
Use on the supplied antenna. Unauthorized antenna,modification,
or attachments could damage the transmitter and may violate FCC
regulations.
Safety Information
Use only with supplied antenna. Unauthorized antenna, modification, or attachments
could damage the transmitter and may violate FCC regulations.
Any changes or modications not expressly approved in this manual
could void your authorization to use this device.
A-8 Appendix: Reference information
FCC RF Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for
an uncontrolled environment.
This equipment must not be co-located or operating in conjunction with any
other antenna or transmitter.
A-9
AiGuru S2 Wireless Skype Phone
Radio waves may affect electronic equipment or medical devices (e.g.,
pacemakers), which may cause malfunctions and possible injuries.If you
use a pacemaker or other medical device, consult your physician or the
manufacturer of the medical device before using the wireless networking
feature.
Industry Canada regulatory information
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Declaration of Conformity
This product complies with the Radio & Telecommunication Terminal
Equipment Directive (1995/5/EC), the Electromagnetic Compatibility
Directive (89/336/EEC), and Low Voltage Directive (73/23/EEC).
Compliance with these directives implies conformity to the following
European Standards:
EN 55022, EN55024, EN 300 328, EN 301 489-1 & 17, EN 60950, EN
50360, EN 50361
EU RF Exposure Statement
This equipment complies with EU RF radiation exposure limits of 2 W/kg.
802.11b=0.478 W/kg, 802.11g=0.4585W/kg
A-10 Appendix: Reference information
Wireless Operation Channel for Different Domains
North America 2.412-2.462 GHz Ch01 through Ch11
Japan 2.412-2.462 GHz Ch01 through Ch11
Europe ETSI 2.412-2.462 GHz Ch01 through Ch11
France Restricted Wireless Frequency Bands
Some areas of France have a restricted frequency band. The worst case maximum
authorized power indoors are:
• 10 mW for the entire 2.4 GHz band (2400 MHz–2483.5 MHz)
• 100 mW for frequencies between 2446.5 MHz and 2483.5 MHz
Channels 10 through 13 inclusively operate in the band
2446.6 MHz to 2483.5 MHz.
There are few possibilities for outdoor use: On private property or on the private
property of public persons, use is subject to a preliminary authorization procedure by
the Ministry of Defense, with maximum authorized power of 100mW in the 2446.5–
2483.5 MHz band. Use outdoors on public property is not permitted.
In the departments listed below, for the entire 2.4 GHz band:
• Maximum authorized power indoors is 100 mW
• Maximum authorized power outdoors is 10 mW
Departments in which the use of the 2400–2483.5 MHz band is permitted with an
EIRP of less than 100mW indoors and less than 10mW outdoors:
01 Ain Orientales 02 Aisne 03 Allier 05 Hautes Alpes
08 Ardennes 09 Ariège 11 Aude 12 Aveyron
16 Charente 24 Dordogne 25 Doubs 26 Drôme
32 Gers 36 Indre 37 Indre et Loire 41 Loir et Cher
45 Loiret 50 Manche 55 Meuse 58 Nièvre
59 Nord 60 Oise 61 Orne 63 Puy du Dôme
64 Pyrénées Atlantique 66 Pyrénées 67 Bas Rhin 68 Haut Rhin
70 Haute Saône 71 Saône et Loire 75 Paris 82 Tarn et Garonne
84 Vaucluse 88 Vosges 89 Yonne 90 Territoire de Belfort
94 Val de Marne
A-11
AiGuru S2 Wireless Skype Phone
This requirement is likely to change over time, allowing you to use your wireless LAN
card in more areas within France. Please check with ART for the latest information
(www.art-telecom.fr)
Your WLAN Card transmits less than 100 mW, but more than 10 mW.
UL Safety Notices
Required for UL 1459 covering telecommunications (telephone) equipment intended
to be electrically connected to a telecommunication network that has an operating
voltage to ground that does not exceed 200V peak, 300V peak-to-peak, and 105V
rms, and installed or used in accordance with the National Electrical Code (NFPA 70).
When using the device, basic safety precautions should always be followed to reduce
the risk of re, electric shock, and injury to persons, including the following:
• Do not use the device near water, for example, near a bath tub, wash bowl,
kitchen sink or laundry tub, in a wet basement or near a swimming pool.
• Do not use the device during an electrical storm. There may be a remote risk of
electric shock from lightning.
• Do not use the device in the vicinity of a gas leak.
Required for UL 1642 covering primary (nonrechargeable) and secondary
(rechargeable) lithium batteries for use as power sources in products. These batteries
contain metallic lithium, or a lithium alloy, or a lithium ion, and may consist of a single
electrochemical cell or two or more cells connected in series, parallel, or both, that
convert chemical energy into electrical energy by an irreversible or reversible chemical
reaction.
• Do not dispose the device battery pack in a re, as they may explode. Check
with local codes for possible special disposal instructions to reduce the risk of
injury to persons due to re or explosion.
• Do not use power adapters or batteries from other devices to reduce the risk of
injury to persons due to re or explosion. Use only UL certied power adapters or
batteries supplied by the manufacturer or authorized retailers.
A-12 Appendix: Reference information
Power Safety Requirement
Products with electrical current ratings up to 6 A and weighing more than 3 Kg must
use approved power cords greater than or equal to: H05VV-F, 3G, 0.75 mm2 or
H05VV-F, 2G, 0.75 mm2.
Nordic Cautions
A-13
AiGuru S2 Wireless Skype Phone
Proper Disposal
The symbol of the crossed out bin indicates that the product (electrical and electronic
equipment) should not be placed in municipal waste. Check local regulations for
disposal of electronic products.
A-14 Appendix: Reference information
Safety Warnings
Read the following safety warnings carefully before using your cell phone.
• This equipment is intended for use with power supplied from supplied battery
charger(s) and/or power supply unit(s). Other usage will invalidate any
certication given to this apparatus and may be dangerous.
• Switch off your phone when in an aircraft. The use of wireless phones in an
aircraft may be dangerous to the operation of the aircraft, disrupt cellular
networks, and may be illegal. Failure to observe this instruction may lead to
suspension or denial of phone services to the offender, legal action or both.
• Do not use the phone or phone equipment when at a refueling point.
• Observe restrictions on the use of radio equipment in fuel depots, chemical
plants, or where blasting operations are in progress.
• The use of the Alert device to operate a vehicle’s lights or horn on public roads is
not permitted.
You MUST exercise proper control of your vehicle at all times. Observe the following
safety precautions when driving:
• Do not use a hand-held telephone or microphone while you are driving.
• When driving, nd a safe place to stop the vehicle before using the phone.
• Do not speak into a hands-free microphone if it will distract you from driving.
• You MUST NOT stop on the hard shoulder of a motorway to answer or make a
call, except in an emergency.
• The radio equipment should be connected to the antenna via a non-radiating
cable (e.g. coaxial cable). The antenna must be mounted in a position such that
no part of the human body will normally rest close to any part of the antenna
unless there is an intervening metallic screen, such as a metallic roof.
A-15
AiGuru S2 Wireless Skype Phone
NOTES:
• In some areas where electric current is unstable, it is recommended that you
plug the charger to an AVR (AC Voltage Regulator) instead of direct connection
to a power outlet. Unstable power current may damage the charger and / or the
device.
• You can connect the USB charger or USB data cable to the device in only one
orientation. Incorrect insertion of the cable connector may cause short circuiting
and may damage the device.
A-16 Appendix: Reference information
A.4 Troubleshooting
When the phone and wireless settings are congured
properly, the main display should show the following.
This means that the phone is ready to use.
Following are some situations you might encounter, indicating that there is a problem
with the connection, and the possible actions you can take.
Message displayed Problem description Action to take
WiFi Disconnected 1. The phone was not
congured properly.
2. Communication
between the phone
and the Wireless Link
USB dongle is not
established.
Recongure the
phone settings.
See section “2.2.3
Handset Mode
Switch and WiFi
Congure”
No Service 1. The communication
between the phone and
the Wireless Link USB
dongle is established.
2. The AiGuru S2 Utility
has not been launched.
See section “2.2
Optimizing the
AiGuru S2 Utility
settings” to launch
the AiGuru S2 Utility.
Skype™ Logged Off 1. Skype™ is not launched
on your PC or logged in
with personal account.
2. There is no Internet
access.
Make sure that you
have Internet access
and that you have
launched and logged
into Skype™
Different from Ofine (Presence), the message Skype Logged Off
denotes some possible problems of the Skype utility or the lack of
internet access.
A-17
AiGuru S2 Wireless Skype Phone
A.5 FAQ
This section provides solutions to problems that may occur or questions commonly
encountered during the installation and operation of the ASUS AiGuru S2 Wireless
Skype Phone. Read the description below to solve your problems. If you cannot nd
an answer here, check the ASUS contact information at the end of the user manual.
Q1. Why is there no dial tone when I press the Talk & Recall button?
A1. Either the Wireless Link USB dongle is not properly connected to the PC, the
handset is too far from the Wireless Link USB dongle, or the battery is low (low
battery icon is displayed).
• Check the connections.
• Move closer to the Wireless Link USB Dongle unit.
• Charge the battery.
• If there is something wrong with Skype Program itself, please restart Skype.
Q2. Why does the screen show “WiFi Disconnect”?
A2. When the phone is out of the Wireless Link USB dongle’s operating range, the
phone will keep accessing its signal source for 30 seconds. If detecting the
signal fails, the screen shows the message “WiFi Disconnect” and the goes
into sleep mode.
To regain wireless access, move the handset closer to the Wireless Link USB
dongle and press any key on the handset for access retrieval.
Q3. Why is the battery icon “empty” although the handset has been charged
for 24 hours?
A3. The handset might not be connected to the PC correctly. It is also possible that
the handset’s battery is defective.
• Contact your dealer to purchase a new rechargeable battery.
• Make sure the battery icon is scrolling. If it is not, the battery is not charging.
Q4. Why is there no symbol on the display?
A4. This could mean that the battery is not charged or the Phone Kit is not properly
connected.
• Verify that you have set up the Phone Kit properly.
A-18 Appendix: Reference information
• Charge the battery.
Q5. Why is the audio quality poor sometimes ? (crackles/echoes, etc.)
A5. There may be interference from nearby electrical appliances or the Wireless
Link USB dongle is installed in a room with thick walls. If this is the case, move
the PC to a different location. If the handset is too far from the Wireless Link
USB dongle, move the handset closer.
Q6. Why can I not hear the other party clearly? Why is the speaker too loud/
too quiet?
A6. The speaker volume on your PC or on the handset may be set too low. Adjust
the volume to get better effect.
Q7. Why does the phone not ring when a call comes in?
A7. The ringer may be too small to hear. Adjust the volume of the ringer.
Q8. Why does the contact list/user status return a “NO SERVICE” message?
A8. This may be caused by not starting or logging into Skype™ properly. Verify that
you are logged into Skype™ and the program is running properly.
Another cause may be that the AiGuru S2 Utility or Wireless Link USB
dongle driver has not been launched on the PC, or the dongle plug may be
disconnected. Verify that the AiGuru S2 Utility and Wireless Link USB dongle
driver are functioning properly and that the dongle plug is properly connected.
Also, verify that the PC is not in standby/hibernate mode.
Q9. Why can I not SkypeOut?
A9. If 00, + or 011 is omitted, enter 00, + (double press the asterisk key) or 011
before the number you are dialing. If your Skype™ account has too little or no
credit left, purchase more credits on the Skype™ website. The handset may
have lost its link. Verify that the handset has a link with the Wireless Link USB
dongle.
Q10. Why am I not getting any tone response from Skype™?
A10. Either the Skype™ or the PC application have not started, the USB dongle is
not plugged in, your PC is in standby/hibernate mode, or your other party is
ofine.
• Make sure both Skype™ and the PC application is/are started on the PC and
running properly.
A-19
AiGuru S2 Wireless Skype Phone
• Make sure the phone is set up correctly.
• Wait for the remote party to be online.
Q11. Why can I not hear any sound from the phone while the Wireless Link
USB dongle is plugged in to the PC and the wireless setup is properly
established?
A11. When the Wireless Link USB dongle is plugged in to the USB port of your PC,
the Phone Voice stream will be routed to the handset. If you cannot hear any
voice from the phone, check the setting of Sound Devices in SkypeTM. Go
to Skype™ > Tools > Options > Sound Devices and make the following
settings:
Audio In: Virtual Cable 1
Audio Out: Virtual Cable 2
Ringing: Virtual Cable 2
Q12. Why can I not hear any sound from the PC speakers for normal PC
operation while the Wireless Link USB Dongle is plugged in to the PC?
A12. The PC default audio setting might be in the wrong order. You can change back
the setting of your PC audio by going to Control panel > Sound > Speech
and Audio Device > Sound and Audio Device > Audio. Check Only use
default devices.
Q13. What will I do if the phone is out of operating range? How come no signal
is detected?
A13. When the phone is out of the Wireless Link USB dongle’s operating range, the
phone will keep accessing its signal source for 30 seconds. If detecting the
signal fails, the screen shows the message “WiFi Disconnect” and then goes
into sleep mode.
To regain the connection, move the handset closer to the Wireless Link USB
dongle and press any key on the handset for access retrieval.
A-20 Appendix: Reference information
Q14. Why can I not hear any music when using WiFi Music on the phone?
A14. Please check whether the setting of Windows Media Player is muted or not. If
yes, disable the setting. Or refer to Q&A11. for answers.
Q15. What will I do if I would like to use other Skype devices, or headset rather
than this phone? What if I cannot hear any sound from other Skype
devices or headset rather than this phone?
A15. If you cannot hear any voice from other Skype devices or headset, you may
1. Completely turn off the software utility of this phone, AiGuru S2 Utility, and
restart Skype™
2. Check the setting of Sound Devices in Skype™. Go to Skype™ > Tools>
Options >Sound Devices and make the following settings:
Audio In: Desired Skype Device or windows default device
Audio Out: Desired Skype Device or Windows default device
Ringing: Desired skype Device or Windows default device
A-21
AiGuru S2 Wireless Skype Phone
ASUS contact information
ASUSTeK COMPUTER INC. (Taiwan)
Technical Support
Hotline 0800-093-456 (Toll-free call from Taiwan only)
Fax +886-2-2895-9254
E-mail http://vip.asus.com/eservice/techserv.aspx
Web site http://taiwan.asus.com.tw
ASUSTeKCOMPUTERINC.(Asia-Pacic)
Technical Support
Hotline +886-2-2894-3447
Fax +886-2-2890-7698
E-mail http://vip.asus.com/eservice/techserv.aspx
Web site http://www.asus.com
ASUS COMPUTER INTERNATIONAL (America)
Technical Support
Motherboard and General Product Support
E-mail http://vip.asus.com/eservice/techserv.aspx
Telephone +1-502-995-0883 (select option 3)
Fax +1-502-933-8713
ASUS COMPUTER GmbH (Germany and Austria)
Technical Support
Hotline (MB/Others) +49-2102-9599-0
Notebook +49-2102-959910
Fax +49-2102-959911
Email http://www.asus.de/support/support.htm
Website http://www.asus.de
A-22 Appendix: Reference information
ASUS contact information
ASUS Holland B.V. (Netherlands)
Notebook Hotline +31-(0)591-668190
Fax +31-(0)591-666853
Email http://vip.asus.com/eservice/techserv.aspx
(Notebook, MB, VGA only)
ASUS COMPUTER (China)
Telephone +86-10-82667575
Email http://vip.asus.com.cn/eservice/techserv.aspx

Navigation menu
