USERS MANUAL
MAIN UNIT
BUTTONS
Re-connect Volume Control
Re-connect Button
Use this button to disconnect the current connection and return to pairing
mode.
Volume Control Buttons
Increase and decrease the volume
LED
Red LED: Charging the built-in battery.
Blue LED flashing quickly: Unit is in paring mode and ready to connect to
your phone or Bluetooth Device. Go to your phone's Bluetooth setting to
connect.
Blue LED flashing slowly: Bluetooth connected
POWER UP
Switch the Power knob to 'ON' to power on the unit.
When the battery is low, you can hear the "Ting-ting" sound from the speaker, you
must connect the Mini USB cable to the DC in Jack to charge the Built-in battery,
and the Red LED turn on.
When fully charged, the Red LED turn off.
CONNECTION
Audio Input
Play audio from any device with a headphone jack or audio output, connect to.the
speaker's Line in jack used the Line in cable
Bluetooth connection
The speaker can play the wireless steam audio from any Bluetooth device within
10m. Just follow the steps:
1. Go to the setting of your Bluetooth device and enable BLUETOOTH, and search
Bluetooth device.
2. When " BTS-C001AA" appears, select it.
3. If asked for password, please enter"0000".
4. If Bluetooth connected, the Blue LED will flash slowly.
TROUBLESHOOTING
Hearing Distortion
A. Lower the volume on the speaker an/or phone/bluetooth device.
B. Make sure the speaker is charged up.
Not Loud Enough
A. Turn up the volume on your phone/bluetooth device or the speaker.
B. Make sure it's charged up.
Unable To Pair With Bluetooth Device.
A. Confirm that your phone/device is Bluetooth compatible.
B. Follow "Bluetooth connection" instructions
Experiencing Signal Loss Or Dropouts Via Blluetooth
A. Move the speaker closer to your phone/device.
B. Make sure the battery is charged up.
C. Turn off the speaker and your phone/device,then power on and reconnect
SPECIFICATIONS
Battery Life: Up to 3h (varies by volume level and audio content)
Power: 2W x 2
Dimensions: 150mm x 57mm x 40mm
Weight：265g
ACCESSERIES
AC Adaptor: 5V/1A
USB Cable: 1pcs
Line in Cable: 1pcs
CAUTIONS
To ensure the proper operation, all the safety and operating instructions should
be read carefully before connection and operation.
To prevent fire or shock hazard, DO NOT expose the Speaker to rain or
moisture.
Do not expose the Speaker extreme temperatures, excessive moisture, rain or
sand. Never use this device in high temperature or in high humidity. The best
operating temperature is between 5°C~40°C.
Do not place the appliance on or near a hot gas flame, electric element, and
REAR VIEW
heaters or in areas subjected to direct sunlight.
Don't block any ventilation openings.
Clean the Speaker only with a dry cloth.
This product is intended to be used only with the power supply provided.
The socket-outlet shall be installed near the equipment and shall be easily
accessible.
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC CAUTION
This device complies with part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment This device and its antenna must not be co-located or
operating in conjunction with any other antenna or transmitter.
